N
ot many brands are tattooed into fesh. That kind of loyalty only comes with tested and proven
performance. We make the fnest silencers on the market and stand by our products. So do our customers.
They are a rare breed who understands what it means to embrace the Second Amendment, exercise it and
defend it.
To be clear, you don’t just buy an AAC product, you join a community – one that upholds the highest ideals
of freedom, backed by the highest levels of innovation. From our large bore silencers built for the most elite
military units around the world to the creation of the hottest round on the planet, our 300 AAC Blackout
subsonic ammunition, we Kill the Noise.
Today, 39 states allow the possession and use of silencers, and more are ready to drop the ill-conceived laws
that have restricted silencer use for too long. Silencing is not a crime. Find out how you can own a piece of
American freedom at www.Advanced-Armament.com.
George Kollitides
Chief Executive Offcer
T
oday, more and more citizens are discovering the benefts of
silenced shooting. From competitive tactical shooters to parents
taking their kids to the range for the frst time, silencers have made
their way into the mainstream of American shooting culture. Join the
movement and see how much you’ve been missing with your
old-school noise maker, like being able to converse while shooting and
hearing action noise and bullet impact.
Once you go silent, you never want to
shoot any other way.
51T
90T
THREAD
TOOL INCLUDED
Many of our silencers are easily disassembled for cleaning and
maintenance using the provided tool(s).
THREAD MOUNT
Thread mount silencers rely on the traditional arrangement of screw
threads to join a silencer to the muzzle of the host frearm. This simple
and robust system is most commonly found on rimfre and centerfre
pistol silencers, and some centerfre rife silencers. The advantages of
the thread mount are lower cost compared to fast-attach silencers and
the versatility of being able to use one silencer on multiple hosts with
the same muzzle threads.
RATCHET MOUNT
™
(51T)
The revolutionary Ratchet Mount™ System is the most intuitive
silencer mounting system available. Users are able to securely install
the silencer on the weapon in under three seconds with one hand and
without the use of tools. A spring biased ratchet latch engages teeth
on the mount and prevents the silencer from loosening during use.
To combat fouling, the very action of dismounting a Ratchet Mount™
silencer breaks the bonds of copper and carbon that can solder less
inspired silencer designs to their muzzle devices. Installation is as
simple as threading the silencer onto the mount’s ACME threads until
tight. Removal requires a squeeze of the ratchet latch lever while
unscrewing the silencer.
RATCHET MOUNT
™
(90T)
If the 51 tooth Ratchet Mount™ system was revolutionary, the new
90 tooth Ratchet Mount™ is evolutionary. Based on feedback from
customers, AAC designers confgured a new family of BLACKOUT™
fash hiders and muzzle brakes with a 90 tooth gear and revised
bearing surface. This revised mounting geometry provides a rock-solid
interface between the silencer and host frearm, reducing point of
impact shift and enhancing accuracy.
AAC
®provides sonic camouÞage with
a design philosophy called SCILENT
®,
which blends state-of-the-art computer
design and high-tech metallurgy. Around
here this means you’ll see things in this
catalog you don’t normally see. To help
you navigate what’s what, use this handy
guide to the left.
PAGE No.
MEET JOHN...
06
WHY JOHN BACKS AAC
®07
UNDYING SPIRIT
08
BENEFITS OF SILENCER USE
09
SILENCING IS NOT A CRIME!
10
ARE SILENCERS LEGAL?
11
RIMFIRE SILENCERS
12
PISTOL SILENCERS
14
RIFLE SILENCERS
18
COMPLETE RIFLES
26
300BLK RIFLES™
27
300BLK UPPERS™ & AMMO
28
300BLK H-R HANDI-RIFLE
®29
300BLK MODEL7™
29
MUZZLE DEVICES
30
ACCESSORIES
32
LIFESTYLE
33
WHAT’S WHAT.
Icon DeÝnition Key
which blends state-of
g p
p y
BRAND CHAMPION
MEET JOHN...
BIO:
John Hollister’s Current Position:
Advanced Armament Corp., Product Manager
Advanced Armament Corp. Sales Manager:
2 years
Law Enforcement Firearms Instructor:
25 years
Range Master/Armorer:
20 years
Factory Trained Armorer:
12 manufactures
International Association of Law Enforcement Firearms Instructors
Member:
15 years
National Rife Association:
Life Member
Competitive Shooter:
IPSC, IDPA, 3 Gun, GSSF
Advanced Armament Customer:
Since 2002
American Silencer Association Board Member:
2012
Member of the American Gun Culture:
Lifetime
“My frst exposure to a modern frearms silencer design was about
1985. My old department hosted a SWAT demo that included
a MP5SD 9mm sub-machine gun. The MP5SD is an integrally
suppressed design that was AMAZING. After that I was hooked.
I never wanted to shoot a loud gun again. Loud Guns Suck!
I am the biggest fan of the 300 AAC BLACKOUT
™
cartridges there
is. The 300BLK is the cartridge I always wanted. Not only does
it give you the size and sound of the MP5SD platform, but our
MPW 9” PDW is about a pound and a half lighter as well. BUT, the
300 AAC BLACKOUT
™
also has the ability to fre full power rife
DESIGN &
CONSTRUCTION
WHY JOHN BACKS AAC
®
DESIGN & MATERIALS
There is more to a successful silencer design than
lathe turning a handful of parts that ft together,
disrupt gas fow, and look good on the end of your
favorite roscoe. Of equal importance is the material
in which the silencer is rendered. Application
awareness and painstaking research are necessary
to determine if stainless steel, Inconel
®, aluminum,
Titanium, or a combination thereof is warranted to
provide a product that will meet the performance and
durability expectations of the customer.
The R&D department at AAC
®is responsible for
asking the tough questions and coming up with the
answers. Our R&D staff is an interesting group of
thinkers from diverse backgrounds and disciplines
under whose unique focus no design challenge stands
a chance.
Hours are spent analyzing the performance of
prototypes and the infuence they have on the host
frearm. Sound performance is captured, examined,
and archived for future analysis using a Brüell and
Kjaer digital pulse system designed in conjunction
R&D also calculate the optimum wall thickness of
the outer tube to provide the greatest strength and
durability with the least amount of accuracy-robbing
heat mirage.
TECHNOLOGY HIGHLIGHTS
Circumferential Robotic Fusion Welding
AAC
®pioneered the use of robotic welders to
improve production throughput and insure the
consistency and strength of our welding processes.
The custom designed CNC welders used at AAC
®apply a circumferential fusion weld at the junction
of each baffe and adjacent structural component.
The end result is a welded array of components with
the same structural integrity as a monolithic core
machined from a solid billet.
Electro Discharge Machine (EDM) Taper Bore
The heat from even the most consistently controlled
welding process can induce stresses and distortion
in a welded assembly. To ensure the projectile path
through the silencer is concentric with the bore of the
host frearm, all AAC
®rife silencers are installed on
fxtures that mimic the mounting architecture of the
rife muzzle threads or fast-attach mount. While held
in precise alignment, the fnal tapered projectile path
is cut using a wire EDM process that leaves no burrs
or debris in the silencer.
with AAC
®. The effects of back pressure are studied
with high speed digital video recordings using a
high speed video camera. And since you never really
know a design until you destroy it, we perform a
comprehensive postmortem examination on the
wreckage using a scanning electron microscope.
Knowing what it takes to break your invention is one
of the frst steps toward building the perfect beast.
The interior of a 5.56mm rife silencer is a hostile
environment of blow-torch temperatures from
super-heated muzzle gasses and fying supersonic particles
of unburned gun powder. The baffe cores in all
AAC
®5.56mm and 7.62mm fast-attach silencers are
made from Inconel
®718. This special grade of high
nickel alloy is used in jet engines, Formula 1 cylinder
heads, and by NASA in rocket motors. Inconel
®718
is expensive and diffcult to form and machine, but
a lesser grade of material would fall short of our
customer’s expectations for durability.
The attention to correct material selection doesn’t
stop with the baffes. Using long equations that look
more like hieroglyphics than math, the inventors in
This is Brian. Brian is “Branded for Life” with our logo on
his forearm. Brian is a U.S. Army Ranger who was injured
in Afghanistan in 2010, resulting in the loss of both legs
below the knee. Heroes like Brian are what drive us to create
equipment that won’t fail in the feld. Everyone working at
AAC
®lives and breathes with an unequalled passion for our
products and customers.
This passion was ignited nearly 20 years ago by a group of
hard-core gun enthusiasts who knew they could make silencers
that exceeded the standard of the day. With the confdence
and balls-out attitude of an industrial rock band and the genius
of MIT graduates, they dedicated themselves to ceaseless
innovation and an obsessive drive to challenge the status quo.
AAC
®quickly set new standards for military and commercial
silencer design and performance and became the largest
silencer manufacturer in the world.
Every silencer we create is a product of our proprietary
SCILENT
®design philosophy. The SCILENT
®design process
starts with broad concepts from product “wish-lists” from
our commercial and military customers. AAC’s
®core group of
thinkers and designers render and refne these concepts in
the virtual world of solid-model engineering. Design effciency
is analyzed using the latest computational fuid dynamics
and fnite-element analysis software before our inventions
take shape as prototypes that are tested for sound, fash,
and durability. Only the most cutting-edge, effective products
survive this process and make it to the fnal product stage…
and into this catalog.
UNDYING SPIRIT.
This is
is for
UNDYING
IT
UNDYING SPIRIT
UNDYING SPIRIT
SILENCER
BENEFITS
Silencers are the world’s best hearing protection from the potentially harmful and painful effects of gunfre noise. Silencers protect the shooter and
those nearby from permanent hearing threshold shift that can result from exposure to a single unsilenced gun shot.
• A silencer helps a shooter maintain command and control by enabling team members to communicate during live åre exercises or in combat.
• By virtually eliminating muzzle ýash, silencers prevent “blooming” of night vision equipment and help preserve unaided night vision.
• Silencers generally improve accuracy when used on riýes by promoting the harmonic stabilization of the barrel and reducing gas-induced
instability as the projectile exits the muzzle.
• Silencers enable more accurate and rapid follow-up shots by reducing recoil and muzzle ýip.
• Silencers allow new shooters to learn more quickly by minimizing recoil and muzzle blast, allowing the instructor’s commands to be clearly
heard.
• For military and law enforcement, when every member of the team goes SCILENT™, the opposition is instantly identiåable by their muzzle
ýash and noise.
SILENCING IS
NOT A CRIME!
Want to really
get a handle on
silencers?
Visit
aaccanU.com
, where you’ll
fnd everything you need to know
about federal laws pertaining to
silencers, how to become a silencer
owner, the “Do’s and Don’ts” of
ownership, and everything
in-between.
Whether you’re a licensed frearms
dealer or an individual interested
in personal silencer ownership, we
provide a comprehensive curriculum
covering everything from legality
issues to silencer history, cleaning
and maintenance, and much, much
more.
Learn everything you need to know
about silencers at
aaccanU.com
BuT IT REALLy ShOuLd BE
CALLEd A SuPPRESSOR, RIGhT?
Want to start a debate hotter than Georgia asphalt? Just sit down
with your shooting buddies and start talking about silencers. You can
bet good money that someone is going to stand up and tell you, “It’s a
suppressor, not a silencer.” Let’s end that argument once and for all.
IT’S A SILENCER!!
In 1908, Hiram P. Maxim, son of machine gun inventor Hiram
S. Maxim, realized that his shooting may be disruptive to the
neighbors. Maxim, a considerate genius with a degree in mechanical
engineering from MIT, developed the frst silent fre arm, with what
he called a “Silencer”. Essentially, Maxim’s invention worked the
same as a muffer on a car. Hot and often still burning gas fies out of
the gun and rapidly expands in the air at supersonic speed, creating a
BANG when a shot is fred.
Maxim realized that if he could trap that gas in a confned space and
allow it to cool as it expanded through a series of baffes, the sound
of the rapidly heated air could be reduced.
Maxim’s invention was extraordinarily popular and could be bought at
local hardware stores or through the mail for $3.25. Even though
Maxim stopped production of frearm silencers in 1930, his design
remains as the foundation for every silencer made.
Ly
ARE SILENCERS
LEGAL?
Does not recognize
your right to own
silencers
Does recognize
your right to own
silencers
yes!
Silencers fall under the purview of the
National Firearms Act (NFA) and are
regulated by the NFA Branch of the
Bureau of Alcohol, Tobacco, Firearms, and
Explosives (BATFE). To purchase or legally
possess a silencer, you must:
• Be at least 21 years of age to purchase
a silencer from a dealer.
• Be a resident of the United States.
• Be legally eligible to purchase a årearm.
• Pay a one-time $200 Transfer Tax.
• Reside in one of the 39 states that
currently allow civilian ownership of
silencers: AK, AL, AR, AZ, CO, CT, FL,
GA, ID, IN, KS, KY, LA, MD, ME, MI,
MO, MS, MT, NC, ND, NE, NH, NM,
NV, OH, OK, OR, PA, SC, SD, TN, TX,
UT, VA, WA, WI, WV, AND WY.
For more information, visit
RIMFIRE
SILENCERS
ELEMENT2™
MOUNT
U.S. industry standard 1/2-28
TPI rear mount for simple and
secure mounting on a wide
range of rimfre hosts.
TUBE
Titanium (ELEMENT2™) or
6061-T6 aluminum (PILOT2™ and
PRODIGY™) for lightweight and
durability.
SERVICEABLE
Easily disassembled for
cleaning and maintenance
using provided tool(s).
Most silencer buyers fnd the compact size,
ultra-quiet sound signature and low feeding cost of a
silenced rimfre pistol or rife simply irresistible.
FLEXIBILITY
All AAC
®Rimfre silencers are “Full
Auto” rated. The Element2™ allows
owners to not only shoot 22LR, but
17MACHII, 17HMR, and .22 Magnum.
1
2
3
4
ELEMENT2™
Say hello to the best selling high-performance rimfre silencer on the market. Introduced in early 2012, the Element2™ improves upon the original Element™ with an outer tube and fush ft rear mount of durable, light weight Titanium alloy. The stainless steel baffes and front end cap can be easily removed for cleaning and maintenance with the supplied end cap spanner and baffe removal tool. The Element2™ is rated for use on .22LR rifes and pistols and rifes chambering .17HMR, .17 Mach II, and .22 Magnum.
PRODIGY™
The PRODIGY™ is the world’s frst commercially successful silencer to offer lightweight modular construction, simple user takedown, and ultra-high-performance in a single design. A patented feature on the inside of the PRODIGY™ tube enables users to quickly and easily separate it from the core for cleaning and routine maintenance. The monolithic slant-baffe core of the PRODIGY™ delivers world-class sound reduction on .22LR rifes and handguns.
ELEMENT2™ 22LR 22MAG 17HMR 17MachII 4.1 ounces 5.25” 1.0” 17-4PH SS, Titanium Cerakote™ Direct Thread 41dB 115dB* $550 22LR ONLY 3.75 ounces 5.22” 1.0” 6061-T6, 7075-T6 17-4PH SS T3 Hard Anodized, SCARmor™ Direct Thread 38dB 120dB* $350
CALIBER(S):
WEIGHT:
LENGTH:
DIAMETER:
MATERIALS:
FINISH:
ATTACHMENT:
REDUCTION:
SOUND
PRESSURE
LEVEL:
MSRP:
PILOT2™ 22LR ONLY 3.6 ounces 5.79” 1.0” 6061-T6, 7075-T6, 416 SS T3 Hard Anodized Direct Thread 40dB 116dB* $495 PRODIGY™ SPECSRIMFIRE SILENCERS
PILOT2™
Since its introduction ten years ago, the PILOT™ series has been a bestseller based on solid performance and value. The PILOT2™ improves upon this winning formula with the ability to be easily disassembled using the supplied end cap spanner. The fawless cosmetics and classic lines of PILOT2™ are equally at home on both .22LR rifes and handguns.
*Walter p-22, CCI Standard Velocity .22lr ®
PISTOL
SILENCERS
ADAPTERS
Manufactured from heat
treated stainless steel,
ASAP™ adapter pistons are
available for all popular host
pistol muzzle threads.
ASAP™ SYSTEM
Assured Semi-Automatic
Performance System
counteracts the silencer’s
weight and allows the host
pistol to cycle reliably.
1
2
3
TUBE
The outer body of AAC
®pistol
silencers are Titanium (Ti-RANT™
series) or hard coat anodized aluminum
(Evolution9™).
BAFFLES
Baffe cores are comprised of heat treated
SCARmor™ coated stainless steel for long
service life. Subsequent baffes are hardcoat
anodized aluminum alloy for light weight and
durability. Highly evolved “K” baffes are used
to maximize effciency.
4
Pistol silencers are a balance of sound
reduction, durability, weight, and size.
Ti-RANT-9
®PISTOL SILENCERS
EVOLUTION-9™
The EVO-9™ has been the industry standard 9mm pistol silencer for a decade and is still among the most effcient models available. The fully integrated, all stainless steel ASAP™ System of the EVO-9™ allows a broad spectrum of host pistols to function fawlessly. Compact and lightweight, the EVO-9™ preserves the balance and handling characteristics of the host pistol and makes full-time suppressed use a reality. With the available fxed-barrel spacer and TRIAD™ 3-lug mount, the EVO-9™ can provide double or triple duty on pistols, subguns, and other hosts.
For weapons with non-moving barrels, a fxed barrel spacer is available to ensure safe and reliable operation.
The ASAP™ System used in the Evo 9™ and Ti-RANT™ series ensures reliable operation of locked breach semi-automatic hosts. ASAP™ pistons are available in all relevant muzzle threads for use on multiple hosts.
CALIBER(S): WEIGHT: LENGTH: DIAMETER: MATERIALS: FINISH: REDUCTION: MSRP: SOUND PRESSURE LEVEL: ATTACHMENT: 9mm 9.7 ounces 7.73” 1.25” 6061-T6 7075-T6 17-4PH
Anodized ASAP™ Piston
System 34dB*
*H&K USP 9mm, Glock 17, Remington 147gr. MCL9mm9
126dB (Dry) $650
DID YOU KNOW?
SPECS
®
PISTOL SILENCERS
Ti-RANT
®
The Ti-RANT® series are ultra-high-performance silencers for 9mm and .45 Auto handguns. Advanced material
selection gives the Ti-RANT® series unequalled durability despite compact dimensions and light weight. The fully
serviceable design enables users to remove the SCARmor™ coated 17-4PH blast baffe and hardcoat anodized 7075-T6 aluminum baffes from the Grade 9 Titanium tube for cleaning and maintenance using the supplied end cap spanner.
The highly evolved “K” baffes used in the Ti-RANT® series deliver class leading performance when shot dry. For added
sound and fash reduction, a wet charge of 5cc’s of water will increase performance by up to 30% and will remain effective for 20 to 50 shots.
Class-defning sound reduction is worthless if your silenced handgun is unreliable. To insure fawless functioning
with all popular host pistols, the Ti-RANT® series incorporates a second generation ASAP™ booster system. The fully
integrated ASAP™ System of the Ti-RANT® series enables fawless semi-automatic operation and can be quickly and
easily disassembled for cleaning and maintenance without the use of tools.
FULLY USER-SERVICEABLE
With the supplied end cap spanner, the front
end cap can be removed for access to the
baffes for cleaning and maintenance.
EASY CLEANING
The piston housing assembly features tool-less removal for easy cleaning of the ASAP™ system, exchanging threaded pistons, or installing the new three lug adapter.
Ti-RANT-9S
®Ti-RANT-9
®Ti-RANT-45
®Ti-RANT-45S
® Ti-RANT-9® 9mm 8.6 ounces 7.75” 1.38” Grade 9 Ti, 17-4PH, 7075-T6 Cerakote™ ASAP™ Piston System 34-38dB Dry* 41dB Wet* $850 9mm 7.6 ounces 5.07” 1.38” Grade 9 Ti, 17-4PH, 7075-T6 Cerakote™ ASAP™ Piston System 22dB Dry* 28dB Wet* $795 .45 Auto † 11.5 ounces 8.74” 1.38” Grade 9 Ti, 17-4PH, 7075-T6 Cerakote™ ASAP™ Piston System 30dB Dry** 41dB Wet** $850 .45 Auto † 9.2 ounces 6.42” 1.38” Grade 9 Ti, 17-4PH, 7075-T6 Cerakote™ ASAP™ Piston System 18dB Dry*** 28dB Wet*** $795CALIBER(S):
WEIGHT:
LENGTH:
DIAMETER:
MATERIALS:
FINISH:
ATTACHMENT:
REDUCTION
DRY:
REDUCTION
WET:
MSRP:
Ti-RANT-9S® Ti-RANT-45® Ti-RANT-45S®
SPECS
*Sig Sauer P226, Remington 147gr 9mm **Sig Sauer P220, Remington 230gr 45 Auto ***H&K 45C, Remington 230gr 45 Auto NSN: 100-50-158-73166
RIFLE
SILENCERS
MOUNT
Ratchet Mount™ prevents
loosening during use and allows
one-handed installation or removal
in seconds.
CORE
360-degree fusion-welded
Inconel
®718 core for
extreme durability.
1
2
3
BORE
Precision EDM’d tapered bore
assures alignment.
TUBE
316L stainless steel, futed, and
stepped for weight savings.
4
The engineering and design built into each AAC
®rife
silencer result in the quietest, lightest, most durable and
compact silencers available anywhere.
M4-2000™
RIFLE SILENCERS
51T
762-SDN-6™
The AAC® 7.62-SDN-6™ is a compact fast-attach sound and fash suppressor for 7.62x51mm and 300 AAC
BLACKOUT™ (7.62x35mm) weapons. It features a 360-degree fully welded Inconel® baffe stack and front end
cap to maximize durability on select fre 7.62mm hosts. The 762-SDN-6™ also functions as a superb
multi-caliber suppressor, providing excellent performance on 7.62 NATO, 300 AAC®, 6.8 SPC, 6.5, and 5.56mm NATO.
When employed on a 300 AAC BLACKOUT™, the overall SPL of 126 dB with subsonic ammo is as quiet as the legendary 9mm HK MP5-SD. NSN: 100-50-159-77126.
51T Ratchet Mount™
The ability to securely install a silencer with one hand in less than fve seconds using an intuitive motion and gross motor skills has made the 51T Ratchet Mount™ the best selling fast-attach system in history.
motion and Ratchet
CALIBER(S): WEIGHT: LENGTH: DIAMETER: MATERIALS: FINISH: REDUCTION: MSRP: SOUND PRESSURE LEVEL: ATTACHMENT: 7.62mm NATO/ 300BLK 20.0 ounces 7.66” (6.55” added) 1.50” Iconel® 718, 316L Cerakote™ 51T Ratchet™ 25dB* 39dB**
*14.5” KAC Battle Rife, M80 **9” 300 AAC MPW, Rem 220gr 143dB*
126dB** $1,050
SPECS
RIFLE SILENCERS
RANGER3™ 5.56mm NATO 13.8 ounces 6” (Added 4.20”) 1.5” Iconel® 718, 316 SS Cerakote™ 1/2-28 Thread 28dB*, 30dB* 143dB*, 126dB* 5.56mm NATO 17.6 ounces 6.625” (Added 5.10”) 1.5” Iconel® 718, 316 SS Cerakote™ 51T Ratchet Mount™ 32dB**, 34dB** 132dB**, 136dB**CALIBER(S):
WEIGHT:
LENGTH:
DIAMETER:
MATERIALS:
FINISH:
ATTACHMENT:
REDUCTION:
SOUND
PRESSURE
M4-2000™ SPECSRANGER3™
The RANGER3™ is a compact and lightweight direct-thread silencer for 5.56mm hosts. The ½-28 mount of the RANGER3™ has been signifcantly restyled and redesigned to be stronger and lighter with integrated wrench fats to facilitate easy installation and removal. The RANGER3™ features the same circumferentially fusion welded baffe core of the M4-2000™ for full-time-use durability.
M4-2000™
For more than a decade the M4-2000™ has been the industry standard fast-attach silencer for 5.56mm hosts. Through a rigorous commitment to continuous improvement, the M4-2000™ has consistently been the recipient of innovations that have resulted in a smaller, lighter, and more effcient silencer. The 51T Ratchet Mount™ enables users to install or remove the M4-2000™ in less than three seconds using an intuitive motion and gross motor skills. The M4-2000™’s extreme durability makes 100% suppressed possible on barrels as short as 10”. This is the gold standard in 5.56mm suppression - the best overall balance of sound, weight, durability, and size. NSN: 100-50-154-34656.
THREAD
51T
®
RIFLE SILENCERS
MINI4™ 5.56 NATO 13.5 ounces 5.25” (Added 2.80”) 1.5” Iconel® 718, 316L CeraKote™ 51T Ratchet Mount™ 22dB* 139dB* $895 300BLK ONLY 14.9 ounces 5.75” (added 3.30”) 1.5” Iconel® 718, 316L CeraKote™ 51T Ratchet Mount™ 16.2dB, 17.3dB** 153.3dB, 141dB** $895CALIBER(S):
WEIGHT:
LENGTH:
DIAMETER:
MATERIALS:
FINISH:
ATTACHMENT:
REDUCTION:
SOUND
PRESSURE
LEVEL:
MSRP:
MINI7™ SPECSMINI4™/MINI7™
The Mini4™ (5.56) and Mini7™ (7.62) are ultra-compact silencers for CQC rifes and carbines. Don’t let their size fool you; the Mini4™ and Mini7™ are packed with hard-use technology. Both have fully welded Inconel® 718 baffe cores and feature the industry standard 51T Ratchet Mount™. Although they are designed to present a compact profle, the Mini4™ and Mini7™ signifcantly reduce the sound and fash signatures of their intended host frearms.
51T
MINI4™
MINI7™
*14.5” Colt M4,M193 **Mini 7: 16” H&K417,M80, 16” AAC MPW, Remington 220gr, 300BLK ®
RIFLE SILENCERS
CALIBER(S):
WEIGHT:
LENGTH:
DIAMETER:
MATERIALS:
FINISH:
ATTACHMENT:
REDUCTION:
SOUND
PRESSURE
SPECSCYCLONE™
The CYCLONE™ is a direct thread silencer for 7.62 x 51 (.308) precision rifes. The fully welded baffe core of the CYCLONE™ was designed with an emphasis on accuracy.
The Inconel® 718 blast baffe and subsequent 316L stainless steel baffes all feature a
symmetrical rear face to shear as much gas as possible from the projectile path without creating any asymmetric turbulence that can have a negative impact on accuracy.
THREAD
HUNTER™
The HUNTER™ is a direct-thread silencer designed specifcally for rifes and carbines chambering the 7.62 x 35mm (300 AAC BLACKOUT™) cartridge. Based on the baffe core design from a silencer for a compact 300BLK sub-machine gun, the HUNTER™ delivers an improbable sound signature of
124 dB with 220 grain Remington 300BLK subsonic ammunition fred through an AAC® MPW with a
9” barrel. Although the intended hosts for the HUNTER™ are chambered for 300BLK, the HUNTER™
is constructed using the same fully welded construction as all other AAC® rife silencers and can
therefore be used on 7.62 x 51 (.308) rifes with 16” or longer barrels.
THREAD 7.62 NATO 22.4 ounces 9.5” (Added 8.75”) 1.5” Iconel® 718, 316L Cerakote™ 5/8-24, M18x1 Thread on 30dB, 33dB* 134dB, 137dB* CYCLONE™ HUNTER™ 7.62 NATO 21.4 ounces 7.30” (Added 6.55”) 1.5” Iconel® 718, 316L Cerakote™ 5/8-24, M18x1 Thread on 27dB, 29dB* 137dB, 139dB* ®
RIFLE SILENCERS
300-TM™ 300WM 15 ounces 9.30” (Added 8.70”) 1.5” Grade 5 & 9 Ti Cerakote™ 5/8-24, M18x1 Thread on 28-33dB* 138-143dB* $1,195 300WM 13.9 ounces 9.5” (Added 8.90”) 1.5” Grade 5 & 9 Ti Gun-Kote™ 90T Ratchet 28-33dB* 138-143dB* $1,795CALIBER(S):
WEIGHT:
LENGTH:
DIAMETER:
MATERIALS:
FINISH:
ATTACHMENT:
REDUCTION:
SOUND
PRESSURE
LEVEL:
MSRP:
MK13-SD™ SPECS300-TM™
Based on the military tested and adopted Mk13-SD™, the 300-TM™ is a thread mounting suppressor for bolt action 7.62mm NATO and .300 Winchester Magnum rifes. Combining the simplicity of direct-thread mounting with an ultra-lightweight, high strength, titanium body provides precision rife users with an unparalleled value. The monolithic baffe core of the 300-TM™ is tuned to deliver class-leading accuracy and minimal point of impact shift.
THREAD
MK13-SD™
Available for the frst time to the commercial market, the military chosen Mk13-SD™ is an ultra-lightweight, fast-attach, high performance sound and fash suppressor for bolt action rifes chambered in 7.62mm NATO and .300 Winchester Magnum. The Grade 5 titanium monolithic baffe core and Grade 9 titanium tube give the Mk13-SD™ an improbable weight of 13.9 ounces and the durability to withstand the pressures and temperatures found at the muzzle of .300 Winchester Magnum rifes. Despite its small size and light weight, the Mk13-SD™ delivers greater sound reduction and accuracy than any similarly sized competing models. NSN: 1005-01-599-7024.
90T
*20” Remington 700 .300WM, Remington 180gr., PSP R300W2 ®
TiTAN-Ti™
The lightweight TiTAN-Ti™ is a direct thread silencer for bolt action precision rifes chambering the powerful .338 Lapua Magnum cartridge. Despite its light weight, the TiTAN-Ti™ features an incredibly tough, fully welded, two-piece construction of durable and corrosion resistant Titanium alloy. The patented Hyposone™ monolithic baffe module of the TiTAN-Ti™ delivers excellent sound reduction and helps reduce the recoil of the hard-kicking .338 Lapua Magnum cartridge.
TiTAN-QD™
The TiTAN-QD™ is a lightweight, fast-attach silencer for bolt action precision rifes chambered for the hard-hitting long range .338 Lapua Magnum and .300 Winchester Magnum cartridges. The all-Titanium, fully-welded TiTAN-QD™ features AAC’s 90T Ratchet Mount™ fast attach system and a patented Hyposone™ baffe module for the utmost in sound reduction and accuracy. The TiTAN-QD™ is in service with U.S. and Coalition forces around the globe, and is currently being delivered as part of the package to the U.S. Army on the XM2010 precision rife.
THREAD
RIFLE SILENCERS
TiTAN-Ti™ 338LM 21.0 ounces 10.0” (added 8.0”) 1.85” Grade 5 & 9 Titanium Cerakote™ 5/8-24, 3/4-24, m18x1, m18x1.5 Thread on 34dB* 132dB* 338LM 20 ounces 10” (Added 8.4”) 1.85” Grade 5 & 9 Titanium Gun-Kote™ 90T Ratchet™ 32dB* 138dB*CALIBER(S):
WEIGHT:
LENGTH:
DIAMETER:
MATERIALS:
FINISH:
ATTACHMENT:
REDUCTION:
SOUND
PRESSURE
TiTAN-QD™ SPECS 90T ®CYCLOPS™
The CYCLOPS™ is a “fast-attach” silencer for bolt action and single shot rifes chambering the .50 BMG cartridge. The revolutionary design of the CYCLOPS™ signifcantly reduces blast overpressure and environmental disturbance while reducing the sound signature at the shooter/spotters ear to well below the risk limit for sustaining permanent hearing loss. The CYCLOPS™ is constructed of specially heat-treated, high-strength alloys and is CNC fusion welded to withstand the intense pressures of the .50 BMG cartridge. The CYCLOPS™ couples to a proprietary muzzle brake that features a scaled-up version using the AAC Ratchet Latch™ fast-attach system.
MG-SD™
The military-chosen MG-SD™ is a single unit solution for reducing the sound and fash signature of 5.56mm and 7.62mm light machine guns. Designed from the ground-up to handle the unrelenting heat and abrasive
blasting of sustained fring, the MG-SD™ features a rugged monolithic core of heat treated Inconel® 718. The
core is fully circumferentially welded to the Inconel® outer tube and 316 stainless steel “fast-attach” mount.
The MG-SD™ couples to a BLACKOUT® fash hider using the evolutionary new rock-solid 90 tooth Ratchet
Taper Mount™. Reducing the sound, fash, and dust signature of belt-fed light machine guns saves lives in combat and preserves the hearing of the shooter and nearby support personnel. NSN: 1005-01-599-7029.
RIFLE SILENCERS
CYCLOPS™50BMG 4lbs., 15oz. 15.75” (Added 12.65”) 2.5” Alloy Steel SCARmor™ 50BMG Ratchet 32dB* 137dB* $2,500 7.62 NATO 31 ounces 7.63” (Added 5.2”) 1.50” Iconel®, 316 SS Cerakote™ 90T Ratchet™ 25dB**, 26dB*** 139dB**, 139dB*** $2,295
CALIBER(S):
WEIGHT:
LENGTH:
DIAMETER:
MATERIALS:
FINISH:
ATTACHMENT:
REDUCTION:
SOUND
PRESSURE
LEVEL:
MSRP:
MG-SD™ SPECS 90T 90T*29” MacMillan TAC-50, M-33 ball measured at shooter’s ear **FN M249, M855 ***FN M240B, M80 ®
COMPLETE
RIFLES
COMPLETE RIFLES
Advanced Armament Corp. complete rifes are
available as 9” and 12.5” NFA-registered SBRs
and 16” Carbines.
AAC
®300BLK 9” PDW
CALIBER: BARREL: MUZZLE DEVICE: BOLT CARRIER
GROUP: RAIL: GRIP: STOCK:
Magpul® MOE
Free-foating quad rail sized to match length of barrel AAC 51T BLACKOUT®
fash hider 1:7 5R twist, 5/8-24 thread,
4150 CMV steel, M4 feed ramp, SCARmor™ coated bore,
chamber, and exterior 300 AAC BLACKOUT™
(7.62 x 35mm) Magpul
® CTR
Nickel Boron (Ni-B) UCT EXO coated carrier and cam pin. Phosphated and shot-penned carpenter 158® bolt. Custom Extractor Spring and wide temperature range green O-ring
SPECS 16” CARBINE MSRP: $1,599.95 12.5” SBR 9” SBR PDW
300 AAC BLACKOUT™
Introducing the AAC Multi Purpose Weapon (MPW). Complete MPW’s are available chambered in 300 AAC BLACKOUT™ as 9” and 12.5” factory NFA-registered SBRs and 16” carbines. These content-rich MPW’s come packed with features that today’s black gun shoppers consider mandatory on a top-tier AR.
The bolt carrier features a proprietary design with a modifed cam path and a nickel-boron fnish to enhance reliability and ease of cleaning. The carrier key, is heat-treated for durability and is properly staked. The bolt
is machined from Carpenter 158® steel and is shot peened for durability. The extractor spring, buffer, and
o-ring are a proprietary design specifed by AAC engineers. MPW barrels use 1/7 twist 5R rifing. The entire barrel, including bore and chamber, are fnished in tough, corrosion resistant SCARmor™ to provide high hardness and longevity greater than chrome-lining without impeding accuracy. The barrel and DI gas system are protected by a free-foating forearm with 1913 accessory attachment points. The pictogram marked lower receiver features a Geissele two stage trigger. The six position mil-spec collapsing stock, pistol grip, and trigger guard are all sourced from MagPul.
300 AAC BLACKOUT UPPERS™
These feature rich 300 AAC BLACKOUT™ upper receiver assemblies drop right onto an existing AR lower receiver. Please note that users must possess an approved tax stamp for a short barreled rife prior to installing a 9” or 12.5” upper receiver assembly on their lower receiver.
The bolt carrier features a proprietary design with a modifed cam path and a nickel-boron fnish to enhance reliability and ease of cleaning. The carrier key is heat treated for durability and is properly staked.
The bolt is machined from Carpenter 158® steel and is shot peened for durability. The extractor spring, buffer, and o-ring are a proprietary design specifed by AAC engineers. MPW barrels use 1/7 twist 5R
rifing. The entire barrel, including bore and chamber, are fnished in tough, corrosion resistant SCARmor™ to provide high hardness and longevity greater than chrome-lining without impeding accuracy. The barrel and DI gas system are protected by a free-foating forearm with 1913 accessory attachment points.
300 AAC BLACKOUT™ AMMUNITION
The 300 AAC BLACKOUT™ cartridge is a .30 caliber solution for the AR-15 platform that simply requires changing the barrel. All other components from a mil-spec AR-15 are compatible with the 300 BLK™ cartridge, right down to the magazines which function perfectly with no reduction in capacity. The 300 BLK™ cartridge has as much energy from a 16” barrel as 223/5.56mm does from a 24” barrel. Even from a 10” barrel, 300 BLK™ matches the energy of 223/5.56mm from a 16” barrel, but with a much heavier payload for improved terminal ballistics and enhanced performance through intermediate barriers.
MSRP: $1,080
CALIBER: BARREL: MUZZLE DEVICE: BOLT CARRIER GROUP:
AAC 51 Tooth BLACKOUT®
Flash Suppressor 1:7 5R twist, 0.740 Dia at muzzle,
5/8-24 Threads, 4150 CMV Steel, M4 Feed-Ramps, SCARmor™ coated bore,
chamber, and exterior 300 AAC BLACKOUT™
(7.62 x 35mm)
Nickel Boron (Ni-B) UCT EXO coated carrier and cam pin. Phosphated and shot-penned carpenter 158® bolt. Custom Extractor Spring and wide temperature range green O-ring
SPECS
HANDI-RIFLE® 300 AAC BLACKOUT™ (110-240gr) 16.2”, 1:7 twist, threaded: 5/8-24, phosphatized fnish Glass Filled polymer 6.9 lbs H&R Handi-Rife® H&R® Transfer Bar $359.95 300 AAC BLACKOUT™ (110-240gr) 16”, 1:7 5R twist, threaded: 5/8-24, Black Nitride (incl. chamber and bore)
Glass Filled polymer 6 lbs., 8 oz. Remington Model 7, Black Phosphate X-Mark Pro®, external adjustment $899
CALIBER:
BARREL:
STOCK:
WEIGHT:
ACTION:
TRIGGER:
MSRP:
MODEL 7™ SPECS300 AAC BLACKOUT MODEL 7 RIFLE™
AAC’s MODEL 7 rife in 300 AAC BLACKOUT™ offers an accurate, compact, and lightweight package for hunting or target shooting. The MODEL 7 action is made by Remington to AAC’s specifcations and is topped with a 20 MOA scope rail. The legendary Remington
X-Mark Pro® trigger is factory set for 3.5 lbs and provides a crisp let off for precision shooting. The barrel is threaded 5/8-24 at the
muzzle and features 5R rifing with a 1:7 twist. All surfaces of the barrel are treated with SCARmor™, providing a hard, corrosion resistant fnish superior to chrome lining but with the accuracy potential of a stainless barrel. The AAC MODEL 7 is delivered with a durable, glass-flled, polymer stock with an adjustable cheek riser.
®
300 AAC BLACKOUT HANDI-RIFLE
®Introduced in 2012, the H&R® model AAC Handi-Rife® chambered in 300 AAC BLACKOUT™ has proven to be one of the most fun and
popular rifes on the market today. This durable, optics ready, break action, single shot rife is ideal for the beginner and great fun for the experienced shooter. It has been confgured for silencer use with a lightweight 16.1” barrel with 5/8-24 threads and a 1/7 twist. The rife accurately delivers rounds down range whether feeding it heavy subsonic or high performance hunting ammunition. The phosphate steel action and barrel are complimented by the super tough, glass flled, black polymer furniture. All models are equipped
MUZZLE DEVICES
AAC offers a comprehensive line of muzzle devices, from non-silencer mount
fash hiders to 51T and 90T silencer mounting BLACKOUT™ fash hiders and
muzzle brakes, to the BRAKEOUT™ combination fash hider/muzzle brake.
NON-SILENCER MOUNT
BLACKOUT™
51T BLACKOUT™
51T MUZZLE
BRAKE
90T MUZZLE
BRAKE
®51T BLACKOUT
®MUZZLE BRAKE
.50BMG
CYCLOPS™
BRAKE
90T TITAN-QD™
MUZZLE BRAKE
NON-SILENCER
MOUNT BRAKE
51T BLACKOUT
®FLASH HIDER
NON-SILENCER
MOUNT FLASH
HIDER
51T BRAKEOUT
®COMPENSATOR
The BRAKEOUT® is a 51T silencer mounting muzzle device that embodies design aspects of both a fash hider and muzzle brake. Available in 5.56mm and 7.62mm. Consistently rated as the best
fash hider on the market today,
the BLACKOUT® is available in a
wide variety of thread pitches to ft most of today’s commercial and military rifes.
Introduced in 2009 in response to requests for a muzzle brake version of our suppressor
mount, the BLACKOUT® muzzle
brake provides incredible recoil reduction and the durability you
expect from AAC® products. It is
perfectly at home on precision rifes as well as carbines and minimizes muzzle rise during shooting. Brakes are available in calibers 5.56mm, 7.62mm, .300WM, .338LM, and .50BMG.
MUZZLE DEVICES
To see our entire line of Muzzle Devices, please visit us online at:
www.advanced-armament.com
DON’T SEE WHAT YOU NEED?
ACCESSORIES
EVOLUTION™ and
Ti-RANT
®ASAP™
ADAPTER PISTONS
ROCKSETT
FIXED BARREL
SPACERS
SHIM KITS
MOLLE POUCH
TRIAD ADAPTER
ELEMENT™ and
PILOT2™ BAFFLE
REMOVER TOOL
SILENCER END CAP
SPANNER TOOL
To see our entire line of Accessories, please visit us online at:
www.advanced-armament.com
LIFESTYLE
HEADWEAR
MENSWEAR
WOMENSWEAR
POSTERS
STICKERS
PATCHES
To see our entire line of Lifestyle Products, please visit us online at:
www.advanced-armament.com
APPENDIX
SOUND MEASUREMENT
Unless otherwise specifed, all the silencer performance data in this catalog was collected with a Brüel & Kjær digital pulse system using the widely employed industry standard microphone placement of 1 meter to the left of the muzzle at a height of 1. 6 meters.
What this means is that when we tell you how well our silencers work, we’ve got the numbers to back it up. We’re not padding the test data in our favor, we go by the military’s rigid and exact testing methods and procedures.
Patents issued:
US7587969(B2),US7588122(B2),US7600606(B2),US7610710(B2),US7610992(B2),US7661349(B1),US7743693(B1),US7743693(X601),US7789009(B1),US7874238(B2),US787423-8(B2), US7905170(B1), US7905171(B1), US7926404(B2), US7987944(B1), US8096222(B2), US8272306(B1), USD577409(S), USD577410(S), USD582502(S), USD582503(S), USD584786(S), USD584787(S), USD585518(S), USD591382(S), USD598066(S), USD610221(S)
Patents Pending:
US20110056111(A1), US20110088540(A1), US20120145478(A1),
(1) For more information on sound testing procedures, refer to Al Paulson’s scholarly work, “Silencer History and Performance” Volumes 1(2) & 2(3).
WHY WE CHOOSE TO PUBLISH PERFORMANCE DATA
We publish sound reduction numbers as a service to our customer base, especially the frst-time buyer. When you run across a manufacturer that offers a “general” estimation
of performance or posts no performance data at all, you have to ask yourself what they’re hiding. AAC® silencers are in service with the U.S. military after undergoing rigorous
evaluation at such esteemed testing facilities as the Naval Surface Warfare Center (Crane Division), Aberdeen Proving Ground, and Picatinny Arsenal. Anyone seeking verifcation need look no further than open discussion forums such as silencertalk.com, as well as the articles published in Guns & Weapons for Law Enforcement and Special Weapons for Military and Police by world-renowned silencer authority Al Paulson. Copies of many of these articles are available for download in PDF format at www.advanced-armament.com.
1.
United States of America. Department of Defense.MIL-STD-1474D. 12 Feb. 1997. 9 Jan. 2008. <http://hfetag.dtic.mil/docshfs/mil-std-1474d.pdf>.
2.
Paulson, Al C. “Silencer History and Performance:Sporting and Tactical Silencers.” Vol. 1. Boulder: Paladin Press, 1996.
LEGAL TERMS
GSA SALES
All AAC® silencers and accessories are available by calling Joe Bolmarcich at (336) 317-6884.
SPECIFICATIONS
AAC® is committed to delivering the most up-to-date, state-of-the-art products, and maintains a rigorous R&D program. Due to this, prices and specifcations are subject to change without
notice.
LIFETIME LIMITED WARRANTY
AAC® will repair, or replace free of charge, any silencer manufactured by AAC® for the duration of this lifetime warranty. This warranty is of unlimited duration, and covers, at Advanced
Armament Corp. and its affliates’ discretion, service, repair, and/or replacement of damaged products caused by normal use.
This warranty does not cover damage to the silencer and/or host frearm resulting in whole or in part from criminal, abusive or negligent use, improper or careless handling, unauthorized modifcations, defective, improper hand-loaded or reloaded ammunition, or neglect. Any repairs to the unit made necessary by these factors will be invoiced to the owner. Further, baffe strikes which are not due to a defect in workmanship are not covered by this warranty. Centerfre rife caliber silencers are not warranted for use on barrels less than 10.5” in length.
Negligent or abusive use is defned as utilizing the silencer in a way that is likely to result in premature wear or damage to either the silencer or the host frearm. Further, the warranty does not cover prohibited usage as described in our various owners manuals.
This expressed limited lifetime warranty is the only warranty on this product. This product is sold “as is” and has no implied warranties, merchantability, or ftness for a particular purpose. There are no warranties which exceed beyond the description put forth hereto. If your silencers are not covered under this warranty, you may have the silencer replaced for half the most current retail price and subject to any and all transfer fees required by the BATFE.
QUESTIONS?
Call 770.925.9988, or visit us online at www.advanced-armament.com.
AAC, Blackout, Brakeout, Scilent, and Ti-Rant are trademarks of Advanced Armament Corp., LLC. Barnes TSX and TSX are trademarks of Barnes Bullets, LLC. X-Mark Pro is a trademark of RA Brands, L.L.C.. Handi-Rife is a trademark of Remington Arms Company, LLC. Carpenter No. 158 is a trademark of CRS Holdings Inc.. Cerakote is a trademark of NIC Industries, Inc.. Glock is a trademark of GLOCK Gessellschaft mbH. Gun-Kote is a trademark of Brownells Inc.. HK and USP are trademarks of Heckler & Koch. Inconel is a trademark of Special Metals Corporation. MagPul is a trademark of MagPul Industries Corp.
Inconel® is a registered trademark of Special Metals Corporation.
All photography is property of Advanced Armament Corp.
