Wire Line

(1)

F A S T ,

S A F E ,

D E P E N D A B L E ,

E F F I C I E N T ,

W I R E L I N E

E Q U I P M E N T

W I R E L I N E E Q U I P M E N T

(2)

Quality Assurance

National Oilwell’s commitment to quality goes beyond its accreditations and certifications. In an effort to provide wellhead pressure control equipment that exceeds industry standards, National Oilwell now supplies certification data books standard with all new assemblies sold. The certification data books provide the user and well owners with the assurance that the equipment they are using is designed and manufactured according to stringent industry standards. The certification data book provides complete traceability of a tool from the original mill heat number to the final pressure test, and is traceable by a unique indentification number stamped on each part of an assembly.

Documents included in the data book are: • Documentation Index

• Copy of ISO 9001 Certification

• Certificate of Compliance which lists all applicable codes and standards • Traceability Log which lists all critical components by part number

along with identification traceability number

• Hydrostatic/Functional Test Certificate with test recorder chart • Drawing with Parts List

In addition to the standard certification data books provided, Bowen Quality Assurance Department will provide, upon request, the following records. These records are retained for a period of five (5) years:

• Material Test Report • Heat Treat Certification • Mechanical Test Report

• Inspection Certificate — dimensional, hardness, visual • Magnetic Particle Examination

• Radiograph Inspection of Welds

• Weld Procedure Qualifications (if applicable) • 100% Dimensional Inspection

• Quality Plans

For customers operating in the North Sea area, or requiring third party verification, Bowen is fully accredited to ISO 9001 by Det Norske Veritas (DNV) to provide equipment certified to the British specification DOE SI 289 and Norwegian Petroleum Directorate (NPD) as well as compliance to API requirements.

Some of the codes, standards, specifications and agencies, as applicable, followed and utilized by National Oilwell’s Quality Assurance/Control Program are:

API (American Petroleum Institute) Standards apply to all facets

of manufacturing and fabrication, including Q1 Quality. ASME (American Society of Mechanical Engineers) Bowen maintains

ASME Certifications of Authorization for “U” and “UM” pressure vessels constructed under Section VIII, Division 1.

ASNT (The American Society for Non-Destructive Testing)

Bowen inspectors are qualified to ASNT-TC-1A for Magnetic Particle and Liquid Penetrant Examination.

AWS (American Welding Society) Structural welding.

DOE (Department of Energy – U.K.) Offshore Installations, SI 289.

DNV (Det Norske Veritas) Certifying agency for design reviews

and type or case approvals.

NACE (National Assocation of Corrosion Engineers)

Specification MR-01-75, 1984 Rev., for products used in hydrogen sulfide service (H2S).

NPD (Norwegian Petroelum Directorate)

Data books for North Sea equipment.

NVS (Norsk Verktedsindutis Standardiseringssentol)

Norsk Standard 5801, Quality Assurance System.

Ordering Information

National Oilwell sales/service centers located in oil producing areas throughout the world (see back cover). Call our Houston headquarters directly, or contact the office nearest you for your sales, spare parts, or technical needs.

To help us provide fast, accurate response to your sales, spare parts, and technical needs, please provide as much of the following information as possible:

Your company information: Equipment Information: • Company name and address • Service and pressure rating • Invoice address • Union connection • Purchase order number • Equipment inside diameter

ISO-9001

Certified Quality System Quality Assurance

(3)

Wireline Equipment Index

Bowen Manual Blowout Preventers ... 114

Bowen Hydraulic Blowout Preventers ... 115

Bowen Slide-Lok Blowout Preventers ... 116

Bowen Slide-Lok II Blowout Preventers ... 117

Bowen Manual Tool Traps ... 118

Bowen Hydraulic Tool Traps ... 119

Bowen Series II Tool Catchers ... 120

Bowen Series II Safety Ball Check Valves ... 121

Bowen Series II Grease Injection Control Heads ... 122 – 123 Bowen Grease Head/Tool Catcher/Ball Check Rig-Up Options ... 124

Bowen Seal Elastomers Quick Reference Guide ... 125

Bowen Manual Line Wipers ... 126

Bowen Hydraulic Line Wipers ... 127

Bowen Measuring Line Stuffing Boxes ... 128

Bowen Tubing and Casing Risers ... 129

Bowen Union Risers ... 130

Bowen SS Series Lightweight Risers ... 131

Bowen Pump-In Subs ... 132

Bowen Chemical/Inhibitor Injection Subs ... 133

Bowen Quick Unions, Blanking Plugs, Caps, and Test Fixtures ... 134

Bowen Quick Union Specifications ... 135

Bowen Crossover Adapters ... 136

Bowen Wellhead Adapters ... 137

Bowen Sub Sea Blowout Preventers ... 138

Bowen Snubbing and Universal Blowout Preventers ... 139

Bowen Composite Rigging Sheaves and Accessories ... 140 – 141 Bowen Hydraulic Hand Pump Assemblies ... 142

Bowen Grease Hoses and Accessories ... 143

Bowen Grease Injection Systems Introduction ... 144

Bowen Grease Injection Units Reference Guide ... 145

Bowen 15,000 psi Grease Injection and Hydraulic Control Unit ... 146 – 147 Bowen 10,000 psi Grease Injection and Hydraulic Control Unit ... 148 – 149 Bowen 10,000 psi Grease Injection Unit ... 150 – 151 Bowen 5,000 psi Grease Injection Unit ... 152 – 153 Bowen 5,000 psi Grease Injection and Hydraulic Control Unit ... 154 – 155 Bowen 5,000 and 10,000 psi Drum-Mounted Grease Injection Units ... 156

Bowen Portable Pressure Test Unit ... 157

Bowen Pressure Control Equipment Transport Skid ... 158

Bowen 10 hp Air Compressor With Diesel Engine ... 159

Wireline Fishing Tools Bowen Hydraulic Wireline Jars ... 160

Bowen Knuckle Joints ... 160

Bowen Knuckle Jars ... 160

Bowen Single-Strand Rope Sockets ... 161

Bowen Slip-Type Rope Sockets, Overload Releasing ... 161

Bowen Series 160 Side Door Overshots ... 162

Bowen Wireline Retrievers ... 163

Bowen Sinker Bars ... 163

Bowen Tubular Jars ... 163

Line Wipers ... P. 126 – 127

Grease Injection

Control Heads ... P. 122 – 123 Line Wipers ... P. 126 – 127 Measuring Line Stuffing Boxes .... P. 128

Manual Tool Traps ... P. 118 Hydraulic Tool Traps ... P. 119 Safety Ball Check Valves ... P. 121 Tool Catchers ... P. 120

Tubing/Casing Risers ... P. 129 Integral Union Risers ... P. 130 SS Lightweight Risers ... P. 131 Pump-In Subs ... P. 132 Inhibitor Injection Subs ... P. 133

Hydraulic BOPs ... P. 115 Slide-Lok BOPs ... P. 116 – 117 Other BOPs ... P. 138 – 139

Wellhead Adapters ... P. 137 Blanking Caps & Plugs ... P. 134 Crossover Adapters ... P. 136 Quick Unions ... P. 134 – 135

(4)

Bowen Manual BOP: 5,000 psi and Up Working Pressure – H2S Service Type \ ID 21_⁄ 2 3 4 41⁄2 5 51⁄2 61⁄2 Single 57677 61809 61071 61339 – 66456 61145 117 147 315 355 – 400 515 Twin 63514 63384 63515 – – – 61148 196 290 570 – – – –

Bowen Manual BOP: 5,000 psi Working Pressure – Standard Service

Type \ ID 21_⁄ 2 3 4 41⁄2 5 51⁄2 61⁄2 Single 51647 51652 61062 61067 65174 51665 70642 87 lbs 106 lbs 222 lbs 250 lbs – 280 678 lbs Twin 51650 51654 61064 61069 – 72865 72551 144 lbs 209 lbs 419 lbs 480 lbs – – 1050 lbs

Bowen Manual Blowout Preventers

Bowen Manual BOPs are mechanical devices that utilize manually oper-ated stems to actuate the rams. The rams are designed to seal around the wireline, slickline, or coiled tubing.

Features

• Lightweight, compact and dependable. • Forged bodies.

• Single and twin configuration available. • Flush-type equalizer valve.

• H2S or standard service. • 21_⁄

2" to 61⁄2" I.D. available.

• Heavy-duty rams.

• 3,000 to 5,000 psi working pressure.

Bowen Manual Blowout Preventer

(5)

Bowen Hydraulic BOP: 10,000 psi Working Pressure – Standard Service Type \ ID 21_⁄ 2 3 4 41⁄2 5 51⁄2 61⁄2 Single 51923 51927 79360 79363 79965 – – 143 lbs 180 lbs 407 lbs 450 lbs – – – Twin 60701 51929 79358 79362 68349 81271 – 232 lbs 306 lbs 808 lbs 895 lbs – – –

Bowen Hydraulic BOP: 5,000 psi Working Pressure – H2S Service

Type \ ID 21_⁄ 2 3 4 41⁄2 5 51⁄2 61⁄2 Single 57678 63460 63461 79715 80318 63916 70993 128 lbs 161 lbs 346 lbs – – – 671 lbs Twin 63382 61111 61074 78200 71767 – 73867 215 lbs 330 lbs 654 lbs – – – 1030 lbs

Bowen Hydraulic BOP: 10,000 psi Working Pressure – H2S Service

Type \ ID 21_⁄ 2 3 4 41⁄2 5 51⁄2 61⁄2 Single 53820 55103 79333 79514 146294 – – 157 lbs 193 lbs 447 lbs 495 lbs – – – Twin 68436 58207 79515 – 150792 – – 255 lbs 336 lbs 883 lbs – – – –

Bowen Hydraulic BOP: 5,000 psi Working Pressure – Standard Service

Type \ ID 21_⁄ 2 3 4 41⁄2 5 51⁄2 61⁄2 Single 51922 51926 61040 61053 80117 51938 60615 117 lbs 180 lbs 315 lbs 355 lbs – 480 lbs 610 lbs Twin 51924 51928 61048 61057 72545 67138 70399 196 lbs 300 lbs 613 lbs 730 lbs – 820 lbs 1020 lbs

Bowen Hydraulic Blowout Preventers

Bowen Hydraulic BOPs are hydraulically actuated devices designed to seal around wireline, slickline, or coiled tubing. Bowen equips all Hydraulic BOPs with manually operated stems to allow closing in the event of a hydraulic failure, or to lock the rams closed when they are left closed for extended periods. These preventers are equipped standard with equalizer valve assemblies. A bleed-off valve is optional.

Features

• Lightweight, compact and dependable. • Forged bodies.

• Single and twin configuration available. • Flush-type equalizer valve.

• H2S or standard service. • 21_⁄

• Heavy-duty rams.

• 3,000 to 15,000 psi working pressure. Twin Hydraulic Blowout Preventer Weep hole and indicators are optional.

See page 123 for union size and information.

(6)

5,000 psi Working Pressure: Standard Service Type \ ID 21_⁄ 2 3 4 Single 146899 146919 154809 342 lbs 342 lbs – Twin 146901 146921 154810 630 lbs 630 lbs – Triple 146915 154808 154811 955 lbs 955 lbs – Quad 154807 153072 154812 – – –

5,000 psi Working Pressure: H2S Service

Type \ ID 21_⁄₂ ₃ ₄ Single 146903 146923 154813 342 lbs 342 lbs – Twin 146905 146925 154814 680 lbs 680 lbs – Triple 146907 150270 154815 955 lbs 955 lbs – Quad 146929 154817 154816 – – –

10,000 psi Working Pressure: Standard Service

Type \ ID 21_⁄

2 3 4

Single 154793 154796 154799

355 lbs 355 lbs –

Twin 154794 154797 154800

15,000 psi Working Pressure: Standard Service

Type \ ID 21_⁄

2 3 4

Single 155296 155298 155302

355 lbs 355 lbs –

Twin 155064 155299 155303

Bowen Slide-Lok Blowout Preventers

The Bowen Slide-Lok Blowout Preventer is a low profile heavy-duty BOP that was originally designed for use with coiled tubing. Because of its ease of maintenance and its low profile it is also used for wireline operations. Slide-Lok BOPs are available with union or flange connections and may also be ordered with optional removable connections.

Features

• Slide-Lok design allows fast removal of actuator cylinder and rams for easy maintenance.

• Low profile, solid block body is available in single, twin, triple, and quad configurations.

• Keyless ram bore for easy ram inversion for grease injection between rams. The keyless ram bore is easier to repair.

• Standard equalizer valve. (Optional manifold block is available.) • H2S or standard service.

• 21_⁄

• Sturdy and easy-to-see ram position indicators. • 5,000 to 15,000 psi working pressure.

Bowen Triple Slide-Lok Blowout Preventer

Bowen Slide-Lok Blowout Preventers

(7)

Bowen Twin Slide-Lok II BOPs: 5,000 psi and Up Working Pressure

Type \ ID 21_⁄ 2 3 Standard 154825 154826 – – H₂S 154825 154827 – –

10,000 psi Working Pressure

Type \ ID 21_⁄

2 3

Standard 153721 154828

– –

H2S 153222_– 154829_–

Bowen Slide-Lok II Blowout Preventers

The Bowen Slide-Lok II Blowout Preventer has all the benefits of the original Slide-Lok, but it is 50 percent lighter. The Slide-Lok II is the product of 30 years experience in wireline BOP manufacturing. It provides protection against blowouts during wireline operations. The low profile, compact Slide-Lok II is rated for 5,000 and 10,000 psi working pressure and is available for H2S and standard service.

Features

• Lightweight, forged steel body. • Low profile.

• Slide-Lok design for easy maintenance. • Keyless ram bore provides easy ram inversion

for grease injection between rams. • New block-style equalizer valve. • H2S or standard service. • Sturdy ram position indicators. • 5,000 to 10,000 psi working pressure. • Convenient handle storage. • 21_⁄

2" to 3" I.D. available.

Bowen Twin Slide-Lok II Blowout Preventer The Slide-Lok II is also available in a manual 5,000 psi working pressure version.

Optional: Multi-Valve Manifold Assembly part number 154239/005.

Bowen Slide-Lok II Blowout Preventers

(8)

Bowen Manual Tool Trap: 5,000 psi Working Pressure – Standard Service WP \ ID 2 21_⁄ 2 3 4 41⁄2 5 51⁄2 5,000 psi 13220 12460 12600 81178 46024 11650 11650 22 lbs 48 lbs 63 lbs 71 lbs 150 lbs 190 lbs 199 lbs Union 12520 12685 17885 20280 12410 12410 64524

Bowen Manual Tool Traps

Bowen Manual Tool Traps are designed to prevent wireline tools from

falling downhole in the event the wireline is inadvertently pulled out of the cable head. Bowen Manual Tool Traps are tough, dependable, and easy to operate and maintain. They are rated up to 5,000 psi working pressure and are available from 2" to 61_⁄₂_{" I.D.}

The Stop Dog and weighted Handle ensure that the Tool Trap stays in the closed or catch position. The handle also provides a convenient visual indication of the stop dog’s position.

Features

• Compact, lightweight design.

• Low torque stop dog and handle (opening and closing). • External position indicator handle.

• 2" to 61_⁄

2" I.D. available. • 5,000 psi working pressure.

Bowen Tools recommends the use

of Hydraulic Tool Traps in H2S environments.

Other connections are available upon request.

(9)

Bowen Hydraulic Tool Trap: Standard Service WP \ ID 21_⁄ 2 3 4 41⁄2 5 51⁄2 61⁄2 5,000 psi 154616 154625 154837 155000 155004 155006 155006 110 lbs 110 lbs – – – – – 10,000 psi 154400 154628 154838 154947 – – – 110 lbs 135 lbs – – – – – 15,000 psi 154834 154835 154836 – – – – – – – – – – –

Bowen Hydraulic Tool Trap: H2S Service

WP\ ID 21_⁄₂ ₃ ₄ ₄1_⁄₂ ₅ ₅1_⁄₂ ₆1_⁄₂ 5,000 psi 154616 154345 154631 155008 155010 155014 155016 110 lbs 110 lbs 187 lbs – – – – 10,000 psi 154622 154106 154839 – 155012 – – 120 lbs 162 lbs – – – – – 15,000 psi 154130 154152 154840 – – – – 167 lbs 205 lbs – – – – –

Bowen Hydraulic Tool Traps

The Bowen Hydraulic Tool Trap is a safety device installed at the bottom of the lubricator or wellhead setup, normally just above the BOP. It prevents the loss of wire tool strings downhole if the wireline is stripped from the rope socket. A tool stop with an opening larger than the wireline, but smaller than the sub-surface tool, prevents the tool from passing through.

Features

• External stop dog (flapper) position indicator. • Positive torsion spring ensures flapper return. • Carrying handle protects indicator. • Single-acting hydraulic piston design. • 21_⁄

• 5,000 psi to 15,000 psi working pressure. • H2S or standard service.

• Manual override.

National Oilwell recommends the use

of Hydraulic Tool Traps in H2S environments.

(10)

H2S Service WP \ ID 21_⁄ 2 3 4 5,000 psi 154134 154634 154844 76 lbs 84 lbs – 10,000 psi 154234 154338 154846 84 lbs 101 lbs – 15,000 psi 154123 154153 154848 94 lbs 107 lbs –

Bowen Series II Tool Catcher: Standard Service WP \ ID 21_⁄₂ ₃ ₄ 5,000 psi 154134 154634 154843 76 lbs 84 lbs – 10,000 psi 154035 154635 154845 76 lbs 84 lbs – 15,000 psi 154841 154842 154847 – – –

Bowen Series II Tool Catcher

The Bowen Tool Catcher is designed to catch the fishing neck of the tool string if the wireline is inadvertently parted. The catcher assembly is fail-safe while in the catch position. Hydraulic pressure is only needed to release the fishing neck.

Bowen’s unique design utilizes four spring-loaded pawls to catch the fishing neck. This proven design will engage fishing neck sizes ranging from 1" thru 13_⁄

4" O.D. without changing parts. The Bowen Tool Catcher is the most compact, lightest designed tool catcher currently on the market.

The Tool Catcher is available in two models: a union upper connection by union bottom connection design and a flow tube integral ball check valve upper connection by union bottom connection design. The integration of the tool catcher and ball check valve significantly reduces the overall height. The customer will also realize a price reduction by purchasing the integrated assembly as opposed to purchasing two separate assemblies.

Features

• Lightweight and compact design (shorter stack height). • Catches 1" to 13_⁄₄_{" (nominal) fish neck without modifying}

catch mechanism.

• Single-action spring actuated catch mechanism ensures positive engagement.

• Integral ball check and flow tube connection for reduction in height and weight (optional)

Union by union models and other compatible unions available upon request. Contact National Oilwell Sales Department.

(11)

H2S Service WP \ ID 21_⁄ 2 3 4 5,000 psi 154016 154340 154025 18 lbs 34 lbs 53 lbs 10,000 psi 154023 154341 154046 39 lbs 53 lbs 59 lbs 15,000 psi 154020 154022 154850 47 lbs 53 lbs –

Bowen Series II Safety Ball Check: Standard Service WP \ ID 21_⁄ 2 3 4 5,000 psi 154016 154339 154025 18 lbs 34 lbs 53 lbs 10,000 psi 154017 154019 154026 18 lbs 34 lbs 59 lbs 15,000 psi 154021 154027 154849 37lbs 59 lbs –

Bowen Safety Ball Check Valve

The Bowen Safety Ball Check Valve is one of many redesigned tools devel-oped and manufactured by Bowen for wireline applications. These check valves are automatic pressure shutoff valves designed for use with wireline lubricators. The check valve is located near the upper end of the lubricator, just below the pack-off assembly. If the wireline is broken and blown out, or accidentally pulled from the lubricator, the well pressure will be safely shut in by the Safety Ball Check Valve.

The redesigned Safety Ball Check Valve is available with specified union connections compatible with either standard or H2S service union assemblies.

Features

• Low actuation pressure. • Fail-safe automatic closure. • Compact design.

• Easy to install ball check housing. • 5,000 psi to 15,000 psi working pressure. • H2S or standard service.

Other compatible unions available upon request. Please contact National Oilwell Sales Department. Use Retrofit Kit 153996 for old style check valves.

Bowen Series II

(12)

Bowen Grease Injection Control Heads

In wireline operations where high pressure exists, reduction of wellhead pressure applied to the pack-off rubbers is essential to reduce the friction on the wireline to a minimum, and to effect a complete seal. Maintaining a complete seal is of prime importance where the operation being performed will not tolerate the loss of fluid, or where loss of fluid and gases would present a major hazard, such as on offshore rigs or near populated areas.

The Bowen Grease Injection Control Head was specifically designed to perform this wireline sealing function in the most efficient and economical manner available. It will maintain a complete seal, with zero loss of fluid or spray (a must when working with high pressure and H2S).

Bowen Series II

(13)

Bowen Series II Grease Injection Control Heads

WP 5,000 10,000 10,000 15,000 15,000

Packing Single Single Tandem Single Tandem

Part Number 154504* 154504* 154533 72364 153651

Weight 63 lbs 63 lbs 95 lbs 160 lbs 192 lbs

Bottom Subs

Bottom Sub Part Number Union I.D. Service Working Pressure Union Series Thread O.D. Seal Bore w_⁄

o Ball Check With Ball Check

5,000 475 4.75 3.75 12688/039 154575 Standard 10,000 475 4.75 3.75 50810 154673 21_⁄ 2 15,000 634 6.31 4.38 58461 154675 5,000 475 4.75 3.75 148914 154575 H2S 10,000 634 6.31 4.38 53620 154676 15,000 632 6.31 3.75 79856 154677 5,000 550 5.50 4.38 12121/039 154678 Standard 10,000 551 5.50 4.88 63282 154679 3 15,000 825 8.25 6.00 148125/039 154680 5,000 550 5.50 4.38 25866/039 154681 H2S 10,000 702 7.00 4.75 62275 154682 15,000 700 7.00 4.38 149273 154683 5,000 703 7.00 5.13 147316 154756 Standard 10,000 825 8.25 6.00 147315 154680 4 15,000 889 8.87 6.50 68318/039 154684 5,000 703 7.00 5.13 80234 154757 H2S 10,000 825 8.25 6.00 147317 154758 15,000 887 8.87 5.50 79771/039 154685

See page 123 for union size and information. * Use Line Wiper 154129

The Bowen Grease Injection Control Heads are available with single pack-off and dual pack-offs, and most are available with top connections for adding a Bowen Line Wiper. The use of additional pack-offs or line wipers are for conditions that require added sealing or cable cleaning.

The Bowen Grease Injection Control Heads are supplied with a flow tube pin connection down for rigging up to various types and sizes of connections. For well pressures from 5,000 psi to 10,000 psi, three flow tubes are generally used. For pressures higher than 10,000 psi, four or more tubes are used. Additional flow tubes can be added if well or operating conditions demand it. Specify type of lower connection and measured line size to assure proper flow tube fit.

All grease injection control heads are rated for H₂S. Lower connection used will dictate service.

Bowen Series II

(14)

Grease Head/Ball Check Grease Head Grease Head Grease Head

Ball Check

Head Catcher Ball Check/Head Catcher Ball Check/Head Catcher Integrated Assembly

Head Catcher Represents a Ball Check Valve

Bowen Grease Head/Tool Catcher/ Ball Check Rig-Up Options

(15)

Physical Parameters and Environmental Usage

Chemicals and Compounds Found in Wells or Used in Well Servicing

General Service B-1001 A B C B A B B D D D D A A C

Hostile Environment B-2001 A D A A A A C C C C A A A C

Extreme High Temp. B-3001 A A A B – A A – – – – – A C

Low Temperature B-4001 A – – B B – – D – – – – A A

High Temperature B-5001 A D D C A C C – – – – C A D

General Service

Bowen Elastomer Reference No. B-1001

Basic Compound: Nitrile

General Description: Nitrile is the most widely used elastomer in the seal

industry. Nitrile provides excellent compression set, tear and abrasion resis-tance and maybe used in limited H2S environments where seal replacement is frequent.

Trade Names: Buna-N, Hycar

Temperature Range: –20° to 250°F

Recommended For: Ketones, esters, amines, halogens. (Nitrile does not

possess good resistance to ozone, sunlight, or weather.)

Bowen Compound: Formulated for maximum sealing for outer seals and

line size inner seals.

Hostile Environment

(High Temperature/H2S/CO2) Bowen Elastomer Reference No. B-2001

Basic Compound: Fluorocarbon

General Description: Fluorocarbon combines resistance to a broader range

of chemicals than any other elastomer. Fluorocarbon has excellent high temperature properties and chemical resistance. It performs well in hostile environments.

Trade Names: Viton, Fluorel, FKM.

Recommended For: Petroleum oils and fluids, silicone fluids and greases,

halogenated hydrocarbons, acids, H2S, and CO2.

Not Recommended For: Ketones, amines, hot hydrofluoric or

chloro-sulfonic acids.

Bowen Compound: Formulated for maximum sealing at high

tempera-tures for outer seals and inner seals.

Extreme High Temperature

Basic Compound: Tetrafluoroelthylene propylene

General Description: New elastomer with good chemical resistance and

excellent high temperature properties.

Trade Names: Aflas, Xenox, TFEP.

Temperature Range: 32° to 450°F

Recommended For: Ketones, esters, amines, and halogens.

Not Recommended For: Ketones, amines, hot hydrofluoric or

chloro-sulfonic acids.

Bowen Compound: Formulated for maximum sealing at high

tempera-tures and steam for outer seals and inner seals.

Low Temperature

Basic Compound: Epichlorohydrin

General Description: Epichlorohydrin is a relatively recent addition

to the petroleum resistant elastomers. Epichlorohydrin has very good low temperature properties and may be used in H2S and CO2 environments.

Trade Names: Hydrin, Herclor, ECO.

Recommended For: Low temperature sealing, petroleum oils

and fluids. Epichlorohydrin has excellent resistance to ozone and weather.

Not Recommended For: Medium to high temperatures, ketones, esters,

amines, or halogens.

Bowen Compound: Formulated for maximum sealing at low temperatures.

High Abrasion

Basic Compound: Polyurethane

General Description: Polyurethane exhibits outstanding tensile strength

and abrasion resistance.

Trade Names: Urethane, Lubrithane, AU, EU.

Temperature Range: 32° to 200°F

Recommended For: Petroleum oils and fluids, high shock loads, high

pressure, and related adverse conditions. (Good resistance to ozone and weather.)

Not Recommended For: Hot water, glycol, ammonia benzene, halogen,

ketones, acids, or steam.

Bowen Compound: Formulated for maximum sealing under adverse

conditions for outer seals, inner seals, inner seal inserts, and line rubber.

Reference Guideline for Effective Usage: A = Good to Excellent

B = Fair to Good C = Good to Poor D = Not Recommended Elastomers for specialized applications are available. Contact Bowen for recommendations.

Petroleum Products Steam Elevated T

emp.

H2

S

CO

2

Acids Alkalis Ketones Esters Amines Halogens Alcohol, Methanol, Ethanol, Glycerol Silicone Glycol

Bowen Seal Elastomers Quick Reference Guide

(16)

Bowen Casing Line Wipers

I.D. Wiper Type Working Pressure Line Size Standard Bottom Connection Weight (lbs) Part Number

61_⁄₄ _Casing _3,000 7_⁄₃₂_{– 1} _{7 – 8 Thread Pin} ₉₁ ₁₈₈₄₀

61_⁄

2 Casing 3,000 7⁄32 – 1 7 – 8 Thread Box 91 17583

61_⁄₂ _Casing _3,000 7_⁄₃₂_{– 1} _{7 Stub Acme Box} ₉₁ ₁₇₇₀₅

23_⁄₄ _Automatic _1,000 3_⁄₁₆_–7_⁄₈ ₃1_⁄₂_{O.D. LP Pin} ₃₉ ₈₀₀₀

35_⁄₈ _Automatic _1,500 3_⁄₁₆_–7_⁄₈ ₄1_⁄₂_{O.D. LP Pin} ₇₀ ₉₈₀₀

Bowen Manual Line Wipers

I.D. Wiper Type Working Pressure Line Size Standard Bottom Connection Weight (lbs) Part Number

19_⁄₆₄ _Tubing _5,000 1_⁄₈_–5_⁄₁₆ ₂3_⁄₈_{EUE Pin} ₁₇ ₁₀₉₇₀

113_⁄₁₆ _Tubing _5,000 1_⁄₈_–3_⁄₄ ₂3_⁄₈_{EUE Pin} ₂₁ ₁₄₄₁₅

25_⁄₁₆ _Tubing _5,000 3_⁄₁₆_{– 1} ₃1_⁄₂_{O.D. EUE Pin} ₃₁ ₁₀₄₉₅

113_⁄₁₆ _Solid _2,500 3_⁄₁₆_–3_⁄₄ ₂7_⁄₈_{EUE Pin} ₂₀ ₁₄₁₂₅

25_⁄₁₆ _Solid _5,000 3_⁄₁₆_{– 1} ₂7_⁄₈_{EUE Pin} ₄₀ ₁₀₄₀₀

5 Casing 3,000 7_⁄

32 – 1 51⁄2 – 8 Thread Pin 68 19460

5 Casing 3,000 7_⁄₃₂_{– 1} ₅1_⁄₂_{Stub Acme Box} ₆₈ ₁₈₂₆₁

Bowen Line Wipers

Bowen Line Wipers are designed to wipe wirelines clean and to prevent

loss of well fluids as these wirelines are removed from oil wells. Line Wipers are also used (in low pressure wells) to seal or “pack-off” around stranded cable. In this application, the flow of fluids and gases is minimized. Bowen Line Wipers are rugged, safe, dependable, and easy to operate.

Bowen Casing Line Wiper Bowen Manual Line Wiper

(17)

Bowen Hydraulic Line Wipers

I.D. Working Pressure Line Size Standard Bottom Connection* Weight (lbs) Part Number

13_⁄₄ _5,000 1_⁄₈_–1_⁄₂ _{2" LP Box} ₃₀ ₁₅₄₁₂₉ 13_⁄ 4 5,000 1⁄8 – 1⁄2 Union Series 475 37 154129 11_⁄₈ _5,000 1_⁄₈_–1_⁄₂ ₂3_⁄₈_{EUE Pin} ₃₅ ₃₄₅₄₇ 113_⁄₁₆ _5,000 1_⁄₈_–3_⁄₄ ₂7_⁄₈_{EUE Pin} ₅₀ ₅₇₁₇₆ 25_⁄₁₆ _5,000 1_⁄₈_{– 1} ₂7_⁄₈_{EUE Pin} ₈₀ ₁₉₄₄₀ 5 5,000 1_⁄₈_{– 1} ₅1_⁄₂_Box ₁₁₂ ₂₆₅₄₀ 5 5,000 1_⁄ 8 – 1 51⁄2 Stub Acme 112 35620 61_⁄₄ _3,000 7_⁄₃₂_{– 1} _{7 – 8 Thread Pin} ₁₂₆ ₂₂₆₆₀ 69_⁄₁₆ _3,000 7_⁄₃₂_{– 1} _{7 – 8 Thread Pin} ₁₃₀ ₂₂₇₂₂ 69_⁄₁₆ _3,000 7_⁄₃₂_{– 1} _{7 – 8 Thread Pin} ₁₂₆ ₂₂₆₆₁ 617_⁄₃₂ _5,000 7_⁄₃₂_{– 1} _{7 – 5 Thread Acme} ₁₃₀ ₄₃₆₃₆

*Other bottom connections are available upon request. Please contact National Oilwell Sales Department. Bowen Line Wipers are available in a variety of sizes from 2" tubing

through 7" casing. They are also available in manual and hydraulically operated models. Please specify line size and bottom connection when ordering.

Features • Lightweight. • Economical. • Easy maintenance.

• 3,000 to 5,000 psi working pressure.

154129 Series II Bowen Hydraulic Line Wiper

(18)

Bowen Measuring Line Stuffing Box

Working Pressure Line Size Standard Bottom Connection Service Weight (lbs) Part Number

5,000 0.072 – 0.108 23_⁄

8 EUE Pin Standard 21 27490

10,000 0.072 – 0.108 Bowen Union Pin 17885 Standard 33 44677

10,000/15,000 0.072 – 0.108 Bowen Union Pin 37692 H2S 55 37060

15,000 0.072 – 0.108 Bowen Union Pin 22922 Standard 52 52053

Bowen Measuring Line Stuffing Box

Bowen Measuring Line Stuffing Boxes are designed to pack-off solid

wireline of all sizes ranging from 0.062" through 0.108" line. Pack-off for 0.125" line is also available.

If the line is inadvertently broken or the tools are stripped off while working under pressure, the Bowen Stuffing Boxes utilize a blowout plug to auto-matically shut-in well pressure.

Bowen Measuring Line Stuffing Boxes are available in 5,000 psi to 15,000 psi working pressure, and for use in H2S or standard service. An EUE pin connection or integral Bowen Pin Section (with retainer nut on bottom) is also available.

A lightweight aluminum Sheave Bracket Assembly to be used in conjunction with the stuffing box is available in 7", 10", or 14" sizes.

Hydraulic Hand Pump Assemblies and optional high temperature packing are also available.

Bowen Measuring Line Stuffing Boxes

(19)

Bowen Tubing/Casing Risers: Standard Service

Working Union Approx. Part Numbers

O.D. I.D. Pressure Connection Weight (lbs/ft) 4 Ft. Long 6 Ft. Long 8 Ft. Long 10 Ft. Long

23_⁄₈ _1.995 _5,000 ₁₂₅₂₀ _4.4 ₁₅₅₁₇₇ ₁₅₅₁₇₈ ₁₅₅₁₇₉ ₁₅₅₁₈₀ 27_⁄ 8 2.441 5,000 154000 6.2 80921 153726 80609 148594 33_⁄ 4 2.992 5,000 12120 8.8 155181 155182 155183 152604 51_⁄₂ _4.892 _5,000 ₁₂₄₁₀ _17.0 ₁₅₅₁₈₄ ₁₅₅₁₈₅ ₁₅₅₁₈₆ ₁₅₅₁₈₇ 7 6.094 5,000 51890 32.0 155188 155189 155190 155191

Bowen Tubing/Casing Risers: H2S Service

23_⁄ 8 1.995 5,000 39530 4.4 155160 155161 155162 155163 27_⁄₈ _2.441 _5,000 ₁₅₄₀₀₀ _6.2 ₁₅₄₆₄₉ ₁₅₃₇₂₆ ₁₅₁₇₄₇ ₁₅₄₆₅₀ 33_⁄ 4 2.992 5,000 25865 8.8 155164 155165 155166 155167 51_⁄ 2 4.892 5,000 50991 17.0 155168 155169 155170 155171 7 6.094 5,000 60735 32.0 155172 155173 155174 155175

Bowen Slimline Casing Risers: Standard Service

51_⁄ 2 4.892 5,000 6.75-4AC.SL 17.0 155066/006 155066/007 155066/005 155066/008 75_⁄ 8 6.765 5,000 9.00-4AC.SL 33.7 155291/005 155291/006 155291/007 155291/008 75_⁄ 8 6.765 3,000 8.50-4AC.SL 29 147182/006 147182/005 147182/007 147182/008

See page 123 for union size and information. Bowen Tubing and Casing Risers

Bowen Tubing and Casing Risers are available in a variety of sizes

and standard lengths to meet our customer’s requirements. Bowen Tubing and Casing Risers are available from 23_⁄

8" O.D. through 75⁄8" O.D. and are

rated at 3,000 psi to 5,000 psi working pressure. These Risers are available in H2S or standard service models. Bleed-off ports and valves are available upon request.

Features

• Economical and lightweight. • Safety factor in compliance with API.

(20)

Bowen Union Risers

Bowen Union Risers are manufactured from alloy steel and are

avail-able from 4 feet to 12 feet in length. An integral Bowen Union connection is standard, but other types of connections are also available upon request. The Union Risers are rated at 5,000 psi to 15,000 psi working pressure, and they are available in standard or H2S service models. Bleed-off ports and valves are available upon request.

Features

• Continuous joint union riser (one-piece construction). • Safety factor in compliance with API.

• Effects of side loading considered in design.

Bowen Union Risers: Standard Service

Approx. Part Numbers

O.D. I.D. Working Pressure Union Connection Weight (lbs/ft) 4 Ft. Long 8 Ft. Long 10 Ft. Long

31_⁄₈ ₂1_⁄₂ _5,000 ₁₂₆₈₅ _– ₃₆₀₃₆ ₃₆₀₃₆ ₃₆₀₃₆ 31_⁄ 4 21⁄2 10,000 17885 11.5 51254 51254 51254 33_⁄ 4 21⁄2 15,000 29923 20.9 52048 52048 52048 33_⁄ 4 3 10,000 17885 8.8 31049 31049 31049 4 3 10,000 17880 – 20040 20040 20040 51_⁄ 4 4 10,000 22550 30.9 31758 31758 31758

Bowen Union Risers: H2S Service

Approx. Part Numbers

O.D. I.D. Working Pressure Union Connection Weight (lbs/ft) 4 Ft. Long 8 Ft. Long 10 Ft. Long 31_⁄ 4 21⁄2 5,000 44105 11.5 78452 78452 78452 31_⁄ 2 21⁄2 10,000 37691 16.0 45948 45948 45948 33_⁄₄ ₃ _5,000 ₄₄₁₀₅ _13.6 ₇₉₆₀₈ ₇₉₆₀₈ ₇₉₆₀₈ 41_⁄₄ ₂1_⁄₂ _15,000 ₅₉₉₈₀ _– ₆₁₃₀₁ ₆₁₃₀₁ ₆₁₃₀₁ 41_⁄ 4 3 10,000 37691 – 57448 57448 57448 51_⁄ 4 3 15,000 58158 – 59372 59372 59372 51_⁄ 2 4 10,000 50991 – 58745 58745 58745

(21)

PUMP-IN SUBS

Bowen SS Series Lightweight Risers

Bowen SS (Severe Service) Series Lightweight Riser

The Bowen SS Series Lightweight Riser is the result of National Oilwell’s commitment to product improvement. The SS Series Lightweight Riser is made from corrosion resistant material and is rated at 10,000 psi working pressure.

A 66% reduction of weight makes the SS Riser easier to maneuver and handle. The interface between the union and threaded riser tube employs a proprietary dual seal arrangement. The primary seal is metal-to-metal, with a secondary backup o-ring seal. All this is done without any com-promise to structural integrity. Well site integrity is enhanced when the SS Series equipment is used.

The Bowen SS Riser is readily available in 3" and 41_⁄

16" sizes and is rated

at 10,000 psi working pressure.

Features

• Severe Service (SS) corrosion resistant amterial suitable for H₂S and CO₂ service, NACE approved

• Dual seal arrangement: metal-to-metal and o-ring • 66% lighter than a conventional riser

• Longer life, less maintenance • No painting required • Low makeup torque

Bowen SS Lightweight Riser with Bowen 43_/₄_{– 4 x 2 Unions}

Part Number ID Working Pressure Connection Length Weight

156538/004 3 10,000 43_⁄₄_{– 4 x 2 (3.750 SB)} ₄ ₅₂ 156538/006 3 10,000 43_⁄ 4 – 4 x 2 (3.750 SB) 6 70 156538/008 3 10,000 43_⁄ 4 – 4 x 2 (3.750 SB) 8 88 156538/010 3 10,000 43_⁄ 4 – 4 x 2 (3.750 SB) 10 106

Note: 41_{/16" ID is available upon request.}

Bowen SS Lightweight Riser with Bowen 43_/₄_{– 4 Unions}

Part Number ID Working Pressure Connection Length Weight

157061/004 3 10,000 43_⁄ 4 – 4 (3.750 SB) 4 52 157061/006 3 10,000 43_⁄ 4 – 4 (3.750 SB) 6 70 157061/008 3 10,000 43_⁄ 4 – 4 (3.750 SB) 8 88 157061/010 3 10,000 43_⁄₄_{– 4 (3.750 SB)} ₁₀ ₁₀₆

(22)

Bowen Pump-In Subs

Bowen Pump-In Subs: Standard Service

I.D. Working Pressure Union Side Outlet Part Number 5,000 12685 2" LP Box 80591 21_⁄ 2 10,000 17885 WECO 1502 155193 15,000 29923 WECO 2202 155195 5,000 12120 2" LP Box 155218 3 10,000 17880 WECO 1502 155220 15,000 148124 WECO 2202 155222

Bowen Pump-In Subs: H2S Service

I.D. Working Pressure Union Side Outlet Part Number 5,000 154000 2" LP Box 155192 21_⁄ 2 10,000 37691 WECO 1502 155194 15,000 59980 WECO 2202 155196 5,000 25865 2" LP Box 155219 3 10,000 50058 WECO 1502 155221 15,000 58158 WECO 2202 155223

Bowen Pump-In Subs

Bowen Pump-In Subs are designed to provide convenient access for pump-ing fluids into the well or bleedpump-ing of lubricator pressure. They are available with several variations of side outlet ports. Bowen Pump-In Subs are avail-able in I.D. sizes ranging from 21_⁄

2" to 71⁄16" with a wide range of side outlet

(23)

Bowen Chemical/Inhibitor Injection Sub

The Bowen Chemical/Inhibitor Injection Sub is designed for injecting cable corrosion inhibitor or anti-icing agents directly onto the wireline as it enters or exits the lubricator string during wireline service operations. Utilizing union connections, the Injection Sub is installed directly below the grease control head or slickline stuffing box. The supply system is connected to the side inlet port where inhibitor or anti-icing agents can be injected as needed. Internal felt wipers aid in coating the wireline with injection fluids and limit the amount of fluids lost in the well bore.

Bowen Chemical/Inhibitor Injection Subs

Bowen Chemical/Inhibitor Injection Sub: H2S Service

I.D. Working Pressure Union Series Weight (lbs) Part Number

5,000 475 52 63115 21_⁄ 2 10,000 634 – 78587 15,000 632 102 72365 5,000 550 – – 3 10,000 702 92 71612 15,000 700 – 149268 4 5,000 703 – –

Bowen Chemical/Inhibitor Injection Sub: Standard Service

I.D. Working Pressure Union Series Weight (lbs) Part Number

5,000 475 41 36245 21_⁄₂ _10,000 ₄₇₅ ₅₅ ₃₆₆₆₅ 15,000 634 65 73975 5,000 550 47 25026 3 10,000 551 89 73772 15,000 825 – – 4 5,000 703 – –

(24)

Bowen Quick Unions

Bowen Quick Unions are self-aligning and particularly well suited

for tub-ing lubricators. These Unions only require hand tightening to seal. Unions are designed for fast, easy makeup and are available in I.D. sizes ranging from 2" to 71_⁄

16" and for working pressures from 3,000 psi to 20,000

psi. These Unions are also available in H2S and standard service models.

Features • Easy connections. • Resistant to cross threading. • Lightweight.

Quick Union

Blanking Plug

Blanking Cap

Bowen Blanking Plugs, Caps, and Test Fixtures

Blanking Plugs and Blanking Caps are available for use on all Bowen

Unions and on an assortment of other types of connections. Blanking Plugs and Blanking Caps are used as Test Fixtures when pressure testing equipment. They are also used as night caps for temporarily shutting in well pressure. Both the Blanking Plug and Blanking Cap assemblies generally come equipped with a port for connecting gauges and bleed-off valves.

Bowen Quick Unions, Blanking Plugs, Caps, and Test Fixtures

(25)

Bowen Quick Unions: H2S Service

Working Union Thread Seal Pin Box Retainer Retainer Blanking Blanking Lifting Box Pin

I.D. Pressure Series O.D. Bore Section Section Nut Split Nut Plug Cap Bail Protect Protect

5,000 475 4.75 33_⁄₄ ₄₄₁₀₇ ₄₄₁₀₆ ₁₂₆₈₆ ₇₀₄₈₈ ₆₄₃₂₈ ₁₅₃₄₁₄ ₅₀₇₇₆ ₅₀₈₃₁ ₅₀₈₃₂ 21_⁄ 2 10,000 634 6.31 43⁄8 37692 37693 29921 70485 54456 74759 145660 53548 53549 15,000 632 6.31 33_⁄ 4 29922 29919 29921 70485 71966 145142 – 53548 53549 5,000 550 5.50 43_⁄ 8 25866 25867 12123 70486 34667 – 62694 60030 60031 3 10,000 702 7.00 43_⁄ 4 50059 50060 36043 67437 63038 – – 60723 60724 15,000 700 7.00 43_⁄₈ ₅₈₁₅₉ ₅₈₁₆₀ ₃₆₀₄₃ ₆₇₄₃₇ ₈₁₀₄₅ ₈₁₀₄₃ _– ₆₀₇₂₃ ₆₀₇₂₄ 5,000 703 7.00 51_⁄ 4 68818 68819 36043 67437 74749 – – – – 4 10,000 825 8.25 6 50992 50993 22553 67439 66416 78065 66363 61032 61033 15,000 887 8.87 51_⁄ 2 79771 79772 79773 79774 80599 80598 – – – 41_⁄ 2 5,000 825 8.25 6 50992 50993 22553 67439 66416 78065 66363 61032 61033 10,000 889 8.87 61_⁄ 2 66222 66223 66221 67440 66751 – – 63204 63205 5 5,000 826 8.25 63_⁄ 4 44093 44094 12412 67442 68618 – – 77174 77175 51_⁄₂ 5,000 890 8.87 7 1_⁄ 4 68824 68825 64527 – 72569 – – – – 10,000 915 9.15 63_⁄ 4 61465 61464 61470 149959 149992 149993 – 155233 155234 61_⁄ 2 5,000 988 9.87 8 60736 60737 51893 67438 79021 – – 78987 78988 10,000 1350 13.50 10 153158 153157 153159 153160 – – – – –

Bowen Quick Unions: Standard Service

Working Union Thread Seal Pin Box Retainer Retainer Blanking Blanking Lifting Box Pin

I.D. Pressure Series O.D. Bore Section Section Nut Split Nut Plug Cap Bail Protect Protect

5,000 475 4.75 33_⁄₄ ₁₂₆₈₈ ₁₂₆₈₇ ₁₂₆₈₆ ₇₀₄₈₈ ₁₂₅₂₆ ₁₄₅₉₁₂ ₅₀₇₇₆ ₅₀₈₃₁ ₅₀₈₃₂ 21_⁄ 2 10,000 475 4.75 33⁄4 17886 17887 17888 67414 17925 145912 50776 50831 50832 15,000 634 6.31 43_⁄ 8 29922 29919 29921 70485 55669 53523 53458 53548 53549 5,000 550 5.50 43_⁄ 8 12121 12122 12123 70486 13175 – 62694 60030 60031 3 10,000 551 5.50 47_⁄₈ ₁₇₈₈₁ ₁₇₈₈₂ ₁₇₈₈₃ ₇₀₄₈₃ ₁₇₈₉₅ _– ₆₂₆₉₄ ₆₀₀₃₀ ₆₀₀₃₁ 15,000 825 8.25 6 148125 148126 22553 67439 – – 66363 61032 61033 5,000 703 7.00 51_⁄ 4 36041 36042 36043 67437 39419 149132 79634 60723 60724 4 10,000 825 8.25 6 22551 22552 22553 67439 – – – 61032 61033 15,000 889 8.87 61_⁄₂ ₆₈₃₁₈ ₆₈₃₁₉ ₆₆₂₂₁ ₆₇₄₄₀ _– _– _– ₆₃₂₀₄ ₆₃₂₀₅ 41_⁄ 2 5,000 826 8.25 6 3_⁄ 4 12411 12413 12412 67442 21050 145653 – 77174 77175 10,000 825 8.25 6 22551 22552 22553 67439 31919 – 66363 61032 61033 5 5,000 826 8.25 6 3_⁄ 4 12411 12413 12412 67442 21050 145653 – 77174 77175 10,000 889 8.87 61_⁄ 2 68318 68319 66221 67440 66751 – – 63204 63205 51_⁄ 2 5,000 890 8.87 7 1_⁄₄ ₆₄₅₂₅ ₆₄₅₂₆ ₆₄₅₂₇ _– ₇₂₅₆₉ _– _– _– _– 10,000 1063 10.62 8 68066 68065 61481 67441 – – – – – 61_⁄ 2 5,000 988 9.87 8 51891 51892 51893 67438 65542 – – 78987 78988 10,000 1300 13.00 91_⁄ 2 77962 77961 66259 70528 70862 – 74156 74157 74158

(26)

Bowen Crossover Adapters

Bowen Crossover Adapters are designed to safely connect lubricator

sections with different end connections. An Adapter can be a combination of a Bowen box section by Bowen pin section and retainer nut, or a combina-tion of a Bowen box seccombina-tion by a tool joint conneccombina-tion (as specified). Bowen Crossover Adapters are manufactured from alloy steel and are available for H2S or standard service.

Features

• 2" to 61_⁄

2" I.D. available.

(27)

Bowen Wellhead Adapter: Standard Service

Flange I.D. Union I.D. Ring Groove Working Pressure Union Series Thread O.D. Seal Bore Weight (lbs) Part Number

21_⁄ 2 R-24 5,000 475 4.75 3.75 35 146753 21_⁄₁₆ 2 1_⁄ 16 BX152 10,000 406 4.06 3.00 26 41280 21_⁄₂ _BX152 _10,000 ₄₇₅ _4.75 _3.75 ₄₂ ₅₁₄₄₆ 21_⁄ 2 BX152 15,000 634 6.31 4.38 50 59539 21_⁄₂ _R-27 _5,000 ₄₇₅ _4.75 _3.75 ₄₀ ₄₈₅₈₆ 29_⁄₁₆ ₂1_⁄₂ _BX153 _10,000 ₄₇₅ _4.75 _3.75 ₄₅ ₄₁₅₉₉ 3 BX153 10,000 551 5.50 4.88 51 145718 21_⁄₂ _R-35 _5,000 ₄₇₅ _4.75 _3.75 ₇₀ ₄₉₁₄₈ 3 R-35 5,000 550 5.50 4.38 65 152123 31_⁄ 16 21_⁄₂ _BX154 _10,000 ₄₇₅ _4.75 _3.75 ₃₆ ₅₁₄₄₈ 3 BX154 10,000 551 5.50 4.88 70 41593 41_⁄₂ _BX154 _10,000 ₈₂₅ _8.25 _6.00 ₈₅ ₁₅₀₀₇₇ 21_⁄₂ _BX154 _15,000 ₆₃₄ _6.31 _4.38 ₉₀ ₇₀₀₃₈ 4 R-39 5,000 703 7.00 5.25 120 149878 41_⁄ 2 R-39 5,000 826 8.25 6.75 96 149871 41_⁄ 16 3 BX155 10,000 551 5.50 4.88 121 81298 41_⁄ 2 BX155 10,000 825 8.25 6.00 100 152289 21_⁄ 2 BX155 15,000 634 6.31 4.38 150 77966 51_⁄₈ ₅ _R-44 _5,000 ₈₂₆ _8.25 _6.75 ₁₈₀ ₁₅₀₉₃₄ 71_⁄₁₆ ₆1_⁄₂ _R-46 _3,000 ₉₈₈ _9.87 _8.00 ₁₉₀ ₁₅₀₉₉₇

Bowen Wellhead Adapter: H2S Service

Flange I.D. Union I.D. Ring Groove Working Pressure Union Series Thread O.D. Seal Bore Weight (lbs) Part Number

21_⁄₂ _R-24 _5,000 ₄₇₅ _4.75 _3.75 ₃₅ ₅₈₈₄₇ 21_⁄₁₆ 2 1_⁄₂ _BX152 _10,000 ₆₃₄ _6.31 _4.38 ₄₅ ₅₁₇₆₇ 3 BX152 10,000 702 7.00 4.75 50 63487 21_⁄₂ _BX152 _15,000 ₆₃₂ _6.31 _3.75 ₅₄ ₇₇₉₃₀ 21_⁄₂ _R-27 _5,000 ₄₇₅ _4.75 _3.75 ₄₀ ₅₈₈₄₈ 29_⁄₁₆ 2 1_⁄₂ _BX153 _10,000 ₆₃₄ _6.31 _4.38 ₆₅ ₅₁₇₆₈ 3 BX153 10,000 702 7.00 4.75 65 63486 21_⁄₂ _BX153 _15,000 ₆₃₂ _6.31 _3.75 ₇₀ ₆₀₁₉₀ 21_⁄₂ _R-35 _5,000 ₄₇₅ _4.75 _3.75 ₇₀ ₅₈₈₄₉ 3 R-35 5,000 550 5.50 4.38 70 150494 21_⁄₂ _BX154 _10,000 ₆₃₄ _6.31 _4.38 ₈₅ ₅₁₇₆₉ 31_⁄ 16 3 BX154 10,000 702 7.00 4.75 90 63470 4 BX154 10,000 825 8.25 6.00 90 68101 21_⁄₂ _BX154 _15,000 ₆₃₂ _6.31 _3.75 ₉₆ ₇₇₉₃₁ 3 BX154 15,000 700 7.00 4.38 64 59373 21_⁄₂ _R-39 _5,000 ₄₇₅ _4.75 _3.75 ₈₉ ₅₈₈₅₀ 4 R-39 5,000 703 7.00 5.25 102 79922 41_⁄₁₆ ₆1_⁄₂ _R-39 _5,000 ₉₈₈ _9.87 _8.00 ₁₀₂ ₁₅₁₃₃₈ 21_⁄₂ _BX155 _10,000 ₆₃₄ _6.31 _4.38 ₈₉ ₅₁₇₇₀ 3 BX155 10,000 702 7.00 4.75 121 63037 4 BX155 10,000 825 8.25 6.00 130 71238 51_⁄₈ ₅ _R-44 _5,000 ₈₂₆ _8.25 _6.75 ₁₈₀ ₁₄₉₂₉₀ 71_⁄ 16 4 R-46 5,000 703 7.00 5.25 187 150492 61_⁄₂ _R-46 _5,000 ₉₈₈ _9.87 _8.00 ₁₈₇ ₁₅₀₁₅₅

Bowen Wellhead Adapters

Bowen Wellhead Adapter flanges are manufacturer from alloy steel and

are designed to provide a means of connecting the wireline lubricator assembly to the wellhead.

Bowen Wellhead Adapter flanges are manufactured with an API flange connec-tion on bottom and a union box connecconnec-tion on top.

For information on blanking plug assemblies that can be used in conjunction with Wellhead Adapters, see page 94.

Features

• One-piece construction.

• Models available for 3,000 psi to 15,000 psi working pressure. • H2S or standard service.

• 21_⁄

(28)

Bowen Sub Sea Blowout Preventers

Bowen Sub Sea Blowout Preventers are constructed from special

alloy steel and are specially designed to seal off or shear coiled tubing and wireline during sub sea well servicing operations. Bowen Sub Sea Blowout Preventers are low profile, hydraulically actuated units that are available with single or dual bore. The hydraulic actuator assemblies utilize an auto-matic locking device that locks the rams in the closed position and does not require the use of sequencing valves, thus reducing size and cost. Bowen Sub Sea Blowout Preventers are available in working pressures from 5,000 psi to 15,000 psi.

For more information on this Blowout Preventer please contact your local National Oilwell representative.

(29)

Bowen Snubbing Blowout Preventers: H2S Service

I.D. (in) Working Pressure Type Standard Connection Max. Size Pipe Pack-Off Weight (lbs) Part Number 29_⁄

16 20,000 Single 29⁄16 6 BX 20,000 psi Flange 1.90 O.D. Tubing 1,450 79289

31_⁄

16 20,000 Single 31⁄16 6 BX 20,000 psi Flange 23⁄8 O.D. Tubing – 146309

41_⁄

16 15,000 Single 41⁄16 6 BX 15,000 psi Flange 27⁄8 O.D. Tubing 1,850 78684

41_⁄

16 15,000 Twin 41⁄16 6 BX 15,000 psi Flange 27⁄8 O.D. Tubing 3,510 79288

41_⁄

16 20,000 Single 41⁄16 6 BX 20,000 psi Flange 27⁄8 O.D. Tubing – 81296

71_⁄

16 10,000 Single 71⁄16 6 BX 10,000 psi Flange 59⁄16 O.D. Tubing 2,200 63642

Bowen Universal Blowout Preventers: H2S Service

I.D. (in) Working Pressure Type Standard Connection Max. Size Pipe Pack-Off Weight (lbs) Part Number 29_⁄

16 15,000 Single 58158 Union 1.90 O.D. Tubing 400 80214

29_⁄

16 15,000 Single 29⁄16 6 BX 15,000 psi Flange 1.90 O.D. Tubing 420 80794

29_⁄

16 15,000 Twin 58158 Union 1.90 O.D. Tubing – 80242

29_⁄₁₆ _15,000 _Twin ₂9_⁄₁₆_{6 BX 15,000 psi Flange} _{1.90 O.D. Tubing} _– ₈₀₇₉₆

41_⁄

16 10,000 Single 41⁄16 6 BX 10,000 psi Flange 27⁄8 O.D. Tubing 750 77136

41_⁄

16 10,000 Twin 41⁄16 6 BX 10,000 psi Flange 27⁄8 O.D. Tubing – 77140

Snubbing Blowout Preventer

Universal Blowout Preventer Bowen Snubbing

and Universal Blowout Preventers

National Oilwell manufactures Bowen Snubbing and Universal

Blowout Preventers that are designed to seal off tubing strings during

well servicing operations which require snubbing pipe into or out of a well under pressure. Both of these rugged blowout preventers feature high pressure ratings in a compact size.

The popular snubbing blowout preventers are completely hydraulic and are designed for fast ram seal removal and replacement. Both blowout pre-venters are rated for H2S service and are available with internal diameters that range from 29_⁄₁₆_{" to 7}1_⁄₁₆_{". Working pressures range from 10,000 psi to}

20,000 psi.

For more information on these Blowout Preventers please contact your local National Oilwell representative.

Bowen Snubbing and

(30)

Bowen Sheave Specifications

Sheave Wheel Diameter

Item 14 Inch 17 Inch 20 Inch 26 Inch

Wireline Diameter Lines up to 5_⁄₁₆_" _{Lines up to}15_⁄₃₂_" _{Lines up to}1_⁄₈_" _{Lines up to}5_⁄₈_"

Width at Axel Shaft 51_⁄

2 inches 51⁄2 inches 51⁄2 inches 51⁄2 inches

Height (handle to clevis pin) 27 inches 30 inches NA 39 inches

Sheave Weight 31 pounds 33 pounds 30 pounds 74 pounds

Proof Test Load 22,500 pounds 30,000 pounds 30,000 pounds 48,000 pounds

Safe Working Load 15,000 pounds 20,000 pounds 20,000 pounds 32,000 pounds

Bowen Composite Rigging Sheaves: 14 Inch Wheel Diameter

Clevis Type

Nominal Line Size* AWS EYE HES SWS

3_⁄

16" 154124/015 154124/016 154124/017 154124/018

7_⁄

32" 154124/019 154124/020 154124/021 154124/022

1_⁄₄_" _154124/023 _154124/024 _154124/025 _154124/026

Bowen Composite Rigging Sheaves and Accessories

(31)

Clevis Type

7_⁄ 32" 154125/021 154125/022 154125/023 154125/024 1_⁄₄_" _154125/025 _154125/026 _154125/027 _154125/028 5_⁄ 16" 154125/029 154125/030 154125/031 154125/032 3_⁄ 8" 154125/033 154125/010 154125/034 154125/035

Clevis Type

3_⁄ 8" – 0.390" 154126/053 N/A 154126/058 154126/054 7_⁄₁₆_{" –}15_⁄₃₂_" _154126/055 _N/A _154126/056 _154126/050 17_⁄ 32" 154126/051 N/A 154126/061 154126/062 5_⁄ 8" 154126/052 N/A 154126/064 154126/065

Bowen Rigging Sheave Accessories

Part Numbers

Item 14 Inch 17 Inch 20 Inch 26 Inch

Sheave Assembly 154124/005 154125/005 154295/005 154126/005

Hand Guard 154204/005 154204/005 154204/005 154203/005

Rig-Up Yoke 154460/005 154460/005 154460/005 154460/005

Floor Stand 154127/005 154127/005 154127/005 154128/005

Composite Rigging Sheaves

In a continuing effort to provide state of the art products, National Oilwell is pleased to offer a full line of Composite Rigging Sheaves and accessories for wireline operations. These Sheaves are quickly proving to be the industry standard. Design criteria for the Composite Rigging Sheaves includes:

• Lightweight: The Composite Sheaves are up to 60 percent lighter than conventional sheaves.

• Safety: The Composite Sheaves were designed with personal safety in mind. A unique protective cover and guide prevent hands and clothing from becoming entangled. These Sheaves are much less likely to cause injury than other designs.

• Improved Wireline Life: The innovative polymeric sheave wheel has

* Line size up to 10% smaller than groove size is permissible with Wireline Technologies Composite Sheave Wheel. Note: When ordering Sheave Assemblies specify line size and clevis type.

endured years of actual field testing and has been proven to cause less wear to the line. Reduced line friction and increased bend radius of the sheave wheel also contribute to less wear on the line.

• Durability and Strength: Designed to withstand the abuses of the rig site, the sheaves have high impact poly covers with cast 17-4 PH stainless steel components. Pull tests, traceability, mag particle inspection and X-ray inspection are standard procedures with each sheave.

National Oilwell offers full support of this product line. This support includes accessories and replacement parts. Servicing of these composite rigging sheaves is also available at National Oilwell districts around the world.

The composite rigging sheaves are available in 14", 17", 20" and 26" diameters. Accessories include hand guards and floor stands. Contact National Oilwell for more information regarding this product.

Composite Rigging Sheaves and Accessories

(32)

Bridle Assembly

I.D. Working Pressure BOP Size (in) Part Number

0.25 3,000 21_⁄

2" – 61⁄2" 154172*

Hydraulic Hose*: 3,000 psi Working Pressure

I.D. Length (ft) Connection Part Number

0.25 50 1_⁄ 4" NPT 19066/050 0.25 75 1_⁄ 4" NPT 19066/075 0.25 100 1_⁄ 4" NPT 19066/100 0.25 120 1_⁄₄_{" NPT} _19066/120 0.25 150 1_⁄ 4" NPT 19066/150 Hand Pumps

Max. Pressure Reservoir Capacity (in3₎ _{Primary Use} _{Part Number}

10,000 120 Line Wiper 19073/038

3,000 120 Line Wiper, Measuring Line Stuffing Box, Single-Acting Tool Trap, Single-Acting Tool Catcher 31661/010

3,000 120 Blowout Preventer, Tool Catcher, Tool Trap 22223/022

3,000 120 Twin Blowout Preventer 38646/009

Hydraulic Quick Disconnect Fittings: 1_{⁄4" NPT – 3,000 psi Working Pressure}

Bowen Hydraulic Hand Pump Assemblies

Bowen Hydraulic Hand Pump Assemblies are lightweight,

depend-able, economical, and safe. They provide convenient operation of hydrau-lically actuated equipment. Each hand pump assembly is designed and manufactured for use with a specific hydraulically actuated unit, and they are equipped with the necessary hoses and quick disconnects.

OPEN CLOSE OPEN CLOSE OPEN CLOSE OPEN CLOSE

Hydraulic Hand Pump Assemblies

Bridle Assembly

Hydraulic Hose

*Hoses include 1_⁄

4" male and female Quick Disconnects

Bowen Hydraulic

(33)

Grease Hose Adapters

I.D. Working Pressure Connection Part Number

0.31 20,000 1" – 12 Swivel Nut Male x 0.56" AEMP (13_⁄

16" – 16 Thread) 154216/005

0.44 20,000 1" – 12 Swivel Nut Male x 0.75" AEMP (0.75" NPSM Thread) 154182/005

0.44 20,000 1" – 12 Swivel Nut Male x 1" – 12 Male 154183/005

0.31 20,000 3_⁄

4" – 16 Swivel Nut Male x 0.56" AEMP (13⁄16" – 16 Thread) 154184/005

0.33 20,000 3_⁄

4" – 16 Swivel Nut Male x 0.75" AEMP (0.75" NPSM Thread) 154185/005

0.31 10,000 1" – 12 Swivel Nut Male x 1_⁄₂_{" NPT Male} _214904/005

0.31 10,000 3_⁄

4" – 16 Swivel Nut Male x 1⁄2" NPT Male 154187/005

0.31 20,000 1" – 12 Swivel Nut Male x 11_⁄

8" Flow Line 154215/005

Grease Hose Connectors

I.D. Working Pressure Connection Part Number

0.50 10,000 0.50" Union Assembly With 1_⁄₂_{" NPT Female} _28080/005

0.50 10,000 0.50" Union Thread Half With 1_⁄

2" NPT Female 28083/005

0.50 10,000 0.50" Union Plain Half With 1_⁄

2" NPT Female28081/005

0.50 10,000 0.50" Union Nut 28082/005

0.44 20,000 High Pressure Quick Disconnect Assembly With 0.75" – Swivel Nut Male 154187/005 0.25 20,000 High Pressure Quick Disconnect Assembly With 0.56" AEMP Female 154851/005 0.25 15,000 High Pressure Quick Disconnect Assembly With 1_⁄₂_{" NPT Female} _154852/005

Grease Hoses

I.D. Working Pressure Length (ft) Type Connection Part Number

0.50 10,000 50 Polyflex 1_⁄ 2" NPT Male 154180/050 0.50 10,000 75 Polyflex 1_⁄₂_{" NPT Male} _154180/075 0.50 10,000 100 Polyflex 1_⁄ 2" NPT Male 154180/100 0.50 10,000 120 Polyflex 1_⁄ 2" NPT Male 154180/120

0.33 20,000 50 Polyflex 0.75" – 16 Swivel Nut Female 154188/050

0.33 20,000 75 Polyflex 0.75" – 16 Swivel Nut Female 154188/075

0.50 20,000 100 Polyflex 1" – 12 Swivel Nut Female 154189/100

0.50 20,000 120 Polyflex 1" – 12 Swivel Nut Female 154189/120

0.50 10,000 50 Waterblast 1_⁄

4" NPT Male x 1⁄2" Quick Union 154853/050

0.25 10,000 50 Waterblast 1_⁄

0.50 10,000 50 Waterblast 1_⁄

0.50 10,000 75 Waterblast 1_⁄

0.50 10,000 100 Waterblast 1_⁄₂_{" NPT Male x}1_⁄₂_{" Quick Union} _154854/100

0.50 10,000 120 Waterblast 1_⁄

0.50 10,000 150 Waterblast 1_⁄

0.50 10,000 50 Polyflex 1_⁄₂_{" NPT Male x}1_⁄₂_{" Quick Union} _154854/050

0.50 10,000 75 Polyflex 1_⁄

0.50 10,000 100 Polyflex 1_⁄

0.50 10,000 120 Polyflex 1_⁄₂_{" NPT Male x}1_⁄₂_{" Quick Union} _154855/120
