2 24 OTP Encoder
Block Diagram Features
· Operating voltage: 2V~12V
· Low power consumption
· Built-in oscillator needs only 5% resistor
· 0/2/4/8 data selectable
· 224maximum address and data codes
· Easy interface with an RF or IR medium
· One time programmable process
· Data active: D0~D7
· Minimal external components
· HT6P20/A/B: 8-pin DIP/NSOP package HT6P20/D: 16-pin DIP/NSOP package
General Description
The HT6P20 is a CMOS LSI encoder designed for remote control system applications. It en- codes 24 bits of information and then serially transmits it via the DOUT pin upon receipt of transmission enable (DATA pins: D0~D7) sig- nals. The combination of address and data bits of the HT6P20 is designed using one time pro-
grammable process. In addition, the chip offers various packaging for flexible combination of programmable address/data so as to meet vari- ous applications. Its programmable ad- dress/data is transmitted together with the anti-code bits via RF or infrared transmission medium upon receipt of a trigger signal.
Applications
· Burglar alarm system
· Smoke and fire alarm system
· Garage door controllers
· Car door controllers
· Security system
· Cordless telephones
· Other remote control systems
O s c i l l a t o r
P r o g r a m m i n g C i r c u i t C o n t r o l U n i t
A d d r e s s C o u n t e r
D a t a L a t c h V P P
S I O
M i x e r &
D r i v e r D O U T
O S C 1 O S C 2
P G M D 0 D 7
Pin Assignment
Note: The customer code and control code have been programmed into HT6P20A/B/D by Holtek¢s factory process.
The blank device HT6P20 is not programmed, it can be programmed by Holtek¢s programming kit.
Warning: The 8-pin blank device only allows programming as HT6P20A type.
The 16-pin blank device allows programming as one of HT6P20/D type. After program- ming the HT6P20 pin name are the same as one of HT6P20D, which is determined by the kit programming procedure.
Pin name ²NC² stands for no connection (floating).
1234 8765
S I O V P P V D D D O U T P G M
V S S O S C 2 O S C 1
2 4 - A d d r e s s
0 - D a t a 2 0 - A d d r e s s
4 - D a t a
1 6 1 5 1 4 1 3 1 2 1 1 1 0
9
12345678
D 0 P G M S I O V P P V D D D O U T O S C 1 O S C 2 D 1
D 2 D 3 V S S N C N C N C N C
1234 8765
N C V D D D O U T O S C 1 D 0
D 1 V S S O S C 2
2 2 - A d d r e s s 2 - D a t a
B l a n k d e v i c e B l a n k d e v i c e
1 6 1 5 1 4 1 3 1 2 1 1 1 0
9
12345678
D 0 P G M S I O V P P V D D D O U T O S C 1 O S C 2 D 1
D 2 / N C D 3 / N C V S S D 4 / N C D 5 / N C D 6 / N C D 7 / N C
H T 6 P 2 0 A
8 D I P / N S O P H T 6 P 2 0 B
8 D I P / N S O P H T 6 P 2 0 D 1 6 D I P / N S O P
H T 6 P 2 0 1 6 D I P / N S O P
1234 8765
S I O V P P V D D D O U T P G M
V S S O S C 2 O S C 1
H T 6 P 2 0 8 D I P / N S O P
Pad Assignment Pad Coordinates
Unit: mmPad No. X Y
1 -956.50 762.75
2 -1123.00 498.75
3 -1123.00 236.25
4 -1123.00 -86.25
5 -1123.00 -261.25
6 -1123.00 -583.75
7 -1027.50 -776.75
8 -852.50 -776.75
9 -530.00 -776.75
10 -355.00 -776.75
11 -180.00 -776.75
12 142.50 -776.75
13 317.50 -776.75
14 640.00 -776.75
15 815.00 -776.75
16 1137.50 -776.75
17 1118.00 -466.75
18 1118.00 -205.75
19 489.00 772.05
20 223.50 789.75
Pin Description
HT6P20D
Pin No. Pin Name I/O Internal
Connection Description
161~3 D0~D3 I CMOS IN
Pull-high Data input and transmission enable (active low) They can be externally set to VSS or left open.
4 VSS ¾ ¾ Negative power supply, ground
5~8 NC ¾ ¾ No connection
9 OSC2 O OSCILLATOR Oscillator output pin 10 OSC1 I OSCILLATOR Oscillator input pin
11 DOUT O CMOS OUT Data serial transmission output
12 VDD ¾ ¾ Positive power supply
13 VPP I ¾ Programming power supply, VDDfor normal opera-
tion
14 SIO I/O CMOS Programming address/control code input and mode
1 2 3
4 5
6
7 8 9 1 0 1 1 1 2 1 3 1 4 1 5 1 6
1 7 1 8 1 9
2 0
( 0 , 0 ) S I O
P G M D 0
D 1
D2 D3 VSS D4 D5 D6 D 7
O S C 2 O S C 1
DOUT
VDD
VPP NC
N C
NC
NC
Chip size: 2590 ´ 2010 (mm)2
* The IC substrate should be connected to VSS in the PCB layout artwork.
Approximate internal connection circuits
Absolute Maximum Ratings
Supply Voltage ...-0.3V to 12V Storage Temperature...-50°C to 125°C Input Voltage...VSS-0.3V to VDD+0.3V Operating Temperature ...-20°C to 75°C Note: These are stress ratings only. Stresses exceeding the range specified under ²Absolute Maxi- mum Ratings² may cause substantial damage to the device. Functional operation of this de- vice at other conditions beyond those listed in the specification is not implied and prolonged exposure to extreme conditions may affect device reliability.
Electrical Characteristics
Ta=25°CSymbol Parameter Test Conditions
Min. Typ. Max. Unit
VDD Conditions
VDD Operating Voltage ¾ ¾ 2 ¾ 12 V
ISTB Standby Current 12V Oscillator stops ¾ 1 2 mA
IDD Operating Current 12V No load
fOSC=3kHz ¾ 200 400 mA
VIH ²H² Input Voltage ¾ ¾ 0.8VDD ¾ VDD V
VIL ²L² Input Voltage ¾ ¾ 0 ¾ 0.2VDD V
RPH D0~D7 Pull-high Resistance 12V ¾ ¾ 150 300 kW
IDOUT Output Current
Source 5V 0.9VDD -2 -5 ¾ mA
12V 0.9VDD -6.5 -15 ¾ mA
Sink 5V 0.1VDD 2 5 ¾ mA
12V 0.1VDD 6 15 ¾ mA
fOSC Oscillator Frequency 12V ROSC=1.4MW ¾ 3 ¾ kHz
C M O S I N / O U T C M O S I N
P u l l - h i g h O S C I L L A T O R
O S C 1 O S C 2
C M O S O U T
V D D
Programming timing of the HT6P20D (B0~B3=1010)
Functional Description
Programming
The HT6P20 is a one time programmable encod- ing integrated circuit. The programmable codes consist of 4-bit control codes and 24-bit address codes. Before using the device, first program the internal 4 control bits and 24 address bits. Then, to program the address and control codes, con- nect the PGM pin to VSS, allowing the SIO pin to receive control and address codes from the con- tinuously transmitting programming kit. The control codes (B0~B3) and address timing are re- spectively shown on the Table and the Figure for Programming Timing. In the programming pro- cess, the mode bit (B0) has to be programmed first. The 0/2/4/8 data number is selected by the address along with the data format bits (B1,B2).
The HT6P20, in addition, provides a polarity bit (B3) to select the polarity of the output data.
Various packages of the HT6P20 offer program- mable combinations of address/data to meet various application needs.
Table 1: Control code
·Mode control (B0)
B0 Function
0 Not programmed
1 Programmed
·Address and data format (B1,B2)
B2 B1 Code Format
0 0 A0~A23
0 1 A0~A21 + D1~D0
1 0 A0~A19 + D3~D0
1 1 A0~A15 + D7~D0
·Polarity control (B3)
B3 Data Output Polarity
0 Negative polarity 1 Positive polarity
The HT6P20A/D can be programmed by the SIO pins. The HT6P20B, on the other hand, is programmed for 2-data and positive polarity application.
B 0 B 1 B 2 B 3
P o l a r i t y c o n t r o l
A d d r e s s a n d d a t a f o r m a t M o d e c o n t r o l
O S C 2 ( 3 k H z )
P G M
S I O
B 0 B 1 B 2 B 3 A 0 A 1 A 2 A 3 A 18 A 19 A 2 0 A 2 1A 2 2 A 2 3
P r o g r a m m i n g P r o g r a m m i n g
b i t
N o t e : ( 1 ) B 0 ~ B 3 a r e c o n t r o l c o d e s ( 2 ) A 0 ~ A 2 3 a r e a d d r e s s c o d e s
( 3 ) A 2 0 ~ A 2 3 s t a n d s f o r d o n ' t c a r e f o r t h e H T 6 P 2 0 D
1 0 1 0 0 1 0 0 1 0 X X X X
1C
Normal operation
The HT6P20 encodes and transmits address/data to a decoder upon receipt of a trigger signal. The address codes of the HT6P20A are always transmitted as long as power (VDD) is supplied. The trans- mission function of the HT6P20B/D is enabled by the D0~D7 pins (active low). The following is the transmission timing of the HT6P20:
A complete code word of the HT6P20D consists of 3 periods as shown below.
The HT6P20A/B/D detects the logic state of the internal programmed address and the external data pins, and then transmits the detected information during the code period. Each address/data bit can be set to one of the following two logic states:
" O n e "
" Z e r o "
f o s c
A d d r e s s / D a t a b i t
a n t i - c o d e p e r i o d ( 4 b i t s ) p i l o t p e r i o d
( 2 3 c l o c k s ) a d d r e s s c o d e p e r i o d d a t a c o d e p e r i o d 1 / 3 b i t
( A 0 ~ A 1 9 , 6 0 c l o c k s ) ( D 3 ~ D 0 , 1 2 c l o c k s )
0 01 1
f o s c
D O U T 1 c l o c k
A complete code word for the HT6P20D
E n c o d e r D O U T
< 1 w o r d D 0 ~ D 7
> 1 w o r d
Transmission timing
Flowchart
Application Circuits
V P P S I O V S S
V D D D O U T O S C 1 O S C 2
R o s c
7234568
P G M D 0 D 1
D 2 D 3
N C N C N C
N C 9
1 0 1 1 1 2 1 3 1 4
1 1 6
1 5
H T 6 P 2 0 D R o s c @ 1 . 4 M W
+ 1 2 V T r a n s m i t t e r C i r c u i t
V P P S I O P G M V S S
V D D D O U T O S C 1 O S C 2 R o s c
1234 5687
H T 6 P 2 0 A R o s c @ 1 . 4 M W
T E
+ 1 2 V
T r a n s m i t t e r C i r c u i t
L E D
L E D S t a n d b y m o d e
T r a n s m i s s i o n e n a b l e d ? N o
N o
Y e s
Y e s A d d r e s s / d a t a w o r d s
t r a n s m i t t e d
T r a n s m i s s i o n s t i l l e n a b l e d
A d d r e s s / d a t a w o r d s t r a n s m i t t e d c o n t i n u o u s l y
P o w e r o n
P G M = 0 ? N o
Y e s P r o g r a m m i n g
m o d e
N o
Y e s P r o g r a m m i n g
c o m p l e t e d ?
N o t e : O n e t i m e p r o g r a m m a b l e
Note: In order to prevent the IC from getting damaged due to the latch up, the 100W resistor or the LED which can also be a transmission indicator is indispensible when VDD=9V~12V.
T r a n s m i t t e r C i r c u i t
V P P S I O V S S
V D D D O U T O S C 1 O S C 2
R o s c
7234568
P G M D 0 D 1
D 2 D 3
N C N C N C
N C 9
1 0 1 1 1 2 1 3 1 4
1 1 6
1 5
H T 6 P 2 0 D R o s c @ 1 . 4 M W
+ 1 2 V
1 0 0 W 0 . 1 m F
V P P S I O V S S
V D D D O U T O S C 1
O S C 2 R o s c
7234568
P G M D 0 D 1 D 2 D 3
N C N C N C
N C 9
1 0 1 1 1 2 1 3 1 4
1 1 6
1 5
H T 6 P 2 0 D R o s c @ 1 . 4 M W
+ 1 2 V T r a n s m i t t e r C i r c u i t
L E D 0 . 1 m F
1 0 0 W V P P
S I O V S S
V D D D O U T O S C 1
O S C 2 R o s c
7234568
P G M D 0 D 1 D 2 D 3
N C N C N C
N C 9
1 0 1 1 1 2 1 3 1 4
1 1 6
1 5
H T 6 P 2 0 D R o s c @ 1 . 4 M W T r a n s m i t t e r C i r c u i t
L E D 4 . 7 k W
+ 1 2 V
0 . 1 m F 1 0 0 W 1 0 0 k W
