Unique customised
facade solutions
Windows, doors and entire glass facades in wood/aluminium or wood/GRP
PROFILE
FRAmINg yOUR bUIlDINg PROjECT VISIONS
It is PRO TEC’s clear objective to become the leading supplier of innovative architectural facade solutions, customised to meet the specific demands and visions of our customers. Our success is closely linked to our ability to provide value within our areas of expertise.
• The comfort of freedom to design • High quality architectural designs • Innovative functionality and materials • Outstanding energy performances • Complete building process services • Durable and long lasting quality
Welcome to the PRO TEC facade solutions.
Customised facade solutions
5. SECURED by DESIgN
Customised security solutions that match the needs of the project, e.g. a bank, psychiatric institution or police station.
1. WIND lOAD - NO PROblEm
Windows designed for wind loads reduces the demand for steel
structures. Large facade spread can be achieved without compromise.
3.INNER FRAmES IN WOOD
Interior frames made in pine. Other woods are available upon request - including both interior and exterior frames made in hardwood.
6. COmPlETE FACADES
Extreme flexibility. A complete framework for the overall facade solution can be delivered, ready for insulation and clad-ding as required.
7. hIDDEN CAblES
Gain a cable free environment. Get the cables out of the way and into the window frame with a window solution from PRO TEC.
UW = 0,61 W/m²K
Dense and slim. A PRO TEC 7®
window solution combines exceptional thermal insulation with a very slim and elegant profile.
2. lESS FRAmE - mORE lIghT
More light for the project. PRO TECs integrated facade solutions are available with or without the double frames, at your request.
4. glASS mEETS glASS
Uninterrupted views. All products are designed to allow constructing step glazing solutions with 2 - or 3-layer glass.
City of Westminster College
Paddington Green Campus, London
Create individual facade expressions with innovative product solutions
and find attractive services, supporting the entire building process.
Freedom to design
6 4 5 3 2 7 1 2 3A-house
Islands Brygge 79, Copenhagen, Denmark
WINDOWS, DOORS AND ENTIRE FACADE SECTIONS
Intelligent PRO TEC systems consist of windows, doors and entire glass facades made in wood/aluminium or wood/GRP. The award-winning solutions are developed from close coorporation with leading architects and contractors, and offers the comfort of freedom
to design. Some of the unique PRO TEC profiles are made of fiberglass reinforced polyester (GRP) ensuring slim profiles and exceptional thermal insulation.
Numerous possibilities are at hand - framing architectural visions in truly custom-made solutions. Find more inspiration in the many PRO TEC cases.
The well renowned PRO TEC products offer all the possibilities of
combining elegant slim profiles with the beauty of warm wood.
Aesthetic expressions of quality
You can see a complete overview of all our
profiles on the www.protecwindows.com, where you can also download the detailed CAD drawings.
Customer segments & value
Engineers Architects Contractors Builders Installers Homeowners
“ Find your explicit
advantages listed at
www.protec-facades.com”
116 11 4 42A VAlUAblE APPROACh TO FACADE SOlUTIONS
PRO TEC offers the freedom of design, by supplying innovative architectural facade solutions. Intelligent systems and products can be customised to meet your specific demands within expression, functionality and energy performance. You have optimum flexibility in creating visionary projects and can choose from many types of wood, colors, door and window handles.
Creating the optimum indoor climate is a corner stone. PRO TEC products are certified energy savers, and offers exceptional isolation performances. They can be fitted to match your expecta-tions and demands for the building project
- enabling the right climate in your project - ensuring customer satisfaction.
We support the complete value chain and add value to every aspect of a building process - ensuring your satisfaction - by realising architectural visions in unique
customised facade solutions. Visit www.protec-facades.com to learn more.
The Silo in the green
Aarhus, Denmark - Voted the world’s best housing
At PRO TEC you will always find a window solution to match your architectural
challenges. Here are an introduction to the different advantages and potentials.
PRO TEC 7® mUlTI SlIm lINE WITh EXCEPTIONAl ISOlATION
With the PRO TEC 7® multi products you are ensured an optimal indoor
climate. The windows are made of fiberglass reinforced polyester (GRP) en-suring thin profiles and exceptional thermal insulation as one the most slim and energy friendly solutions. A very economically attractive choice for low energy buildings. PRO TEC 7® multi reduces cold drafts, and problems with
internal condensation and mould growth are avoided. The slim window systems have a large glass ratio and a great inflow of light.
PRO TEC 7® multi is perfect for large facades offering uncompromising
functionality, flexibility and endless possibilities. It provides space for large glass facades with window depths up to 50 mm. PRO TEC 7® multi is
manufactured on modern automated production lines, which ensures few errors and low production costs.
SlIm DESIgN WITh EXCEPTIONAl ISOlATION AND U-VAlUES. ENDlESS POSSIbIlITIES - WINDOWS, DOORS AND FACADES. bETTER ECONOmy AND ShORT PAy bACK TImE.
PRO TEC ClASSIC+ WITh PlUS-ENERgy AS STANDARD
PRO TEC Classic+ is timeless, traditional design made from wood / alu-minum. It is a plus-energy window with an excellent energy balance and U-values - providing more heat for the building than it loses. Classic+ has a very deep, energy-efficient 3-layer glass (48-50 mm) and is suitable for low-energy buildings. It complies with even the most demanding energy requirements. Classic+ can also be produced in hard/dark wood.
Since the window performs like a radiator, it lowers the heating bills, and benefits the environment. It provides a comfortable environment where children can play straight up against the window - without drafts and cold spots. PRO TEC Classic+ is a perfect choice for large facades and offers a high degree of flexibility.
EXCEllENT ENERgy bAlANCE AND U-VAlUES. EFFECTIVE ISOlATION AND bETTER ECONOmy. WINDOWS, DOORS, SlIDINg DOORS AND FACADES.
PRO TEC ClASSIC OPTImISED ISOlATION AS STANDARD
PRO TEC Classic is energy-optimised and meets the requirements of BR-10 providing an excellent energy balance. PRO TECs Classic standard energy window is now optimised for future demands.
It is not without reason that the flexible and elegant Classic for many years has been one of Denmark’s favourite windows. The window requires minimal maintenance, and PRO TEC offers a complete service. You can have tailor-made solutions with the possibility of creating major facade elements. The sleek and elegant PRO TEC Classic frames and sills allow lots of natural light into the building. PRO TEC Classic can also be produced in hard/dark wood.
ATTRACTIVE INTEllIgENT SySTEm.
INFINITE POSSIbIlITIES FOR INDIVIDUAl SOlUTIONS. WINDOWS, DOORS, SlIDINg DOORS AND FACADES. Optimum flexibility for design freedom
PRO TECs architectural products are extremely flexible as design, product and production is ingenious in both solutions and processes. This accomodates the architects need for unique tailormade solutions for each project. PRO TEC therefore supports the realisation, and strives for the perfect - to get as close as possible to the vision for the building. Designed for wind load
Our products are rated for wind loads as big facade spreads can be achieved without compromise - where the use of secondary steel reinforcement or reduced vertical spread was otherwise required.
42/16 construction
With juxtaposed elements for very long or tall vertical spreads, one can avoid the double frames, and achieve an endless facade, which appears as an uninterrupted profile with a unique look.
hardwood expressions
Classic and Classic+ series is designed so that the hard wood may be used in the inner frame or, for example. in inner and / or outer frame so unique facade expressions can be obtained. glass meets glass in the corners
All our products are designed to allow con-structing step glazing solutions with 2 - or 3-layer glass.
Focus on optimising security
PRO TEC offers customized security solutions that match the specific project needs, be it a bank, a psychiatric institution or police station. The Classic series complies with Secured by Design standard regarding intrusion security. Service and +5 years warranty
PRO TEC offers an annual service agreement on all delivered elements and simultaneously extends the product warranty with +5 years. No condensation or mould growth Advanced and highly composite profiles effectively insulates between the wood and aluminum in the windows.
Product offering at a glance
Valuable systems = numerous possibilities
“ High-profiled
architectural
product designs”
P
R
O T
EC 7
®m
ult
i
P
R
O T
EC C
la
ss
ic
+
P
R
O T
EC C
la
ss
ic
PRO TEC Classic (hard/dark wood).
Woodlands Country Club
Örkelljunga, Sweden. - Scandinavian simplicity andAmerican wooden house architecture
Services in the building process
PRE-PROjECT COUNSEllINg
Get a good overview and input into your project’s opportunities and potential solutions - from the initial phase. Get help with your procurement descriptions and advice on home safety as well as your project’s potential overall economy - products, installation, after sales services, energy, etc.
• Advice and inspiration - face to face / telephone • Discussing and generating ideas for your project • Discussions about the possibility of special solution
/ product development to customized solutions • provide chop-cut / sales samples of selected products • provide energy / optimisation advice for your facades • Estimates of the total economy of your project
INSPIRATIONAl TOOlbOX
You will find an inspiring and professional online toolbox with PRO TEC. Read the latest news and cases at www.protec-facades.com - and find the detailed product info and drawings in 2D and 3D collected at
www.protecvinduer.com - everything relevant for your projects are continuously updated.
• Inspiring reference projects / cases / images • Input to the design of facades / design / solutions
(windows, doors, sliding doors, custom solutions) • Find window details (sectional drawings 2D, 3D) • Find mounting / assembly principles
• Design of wind load (Frame depth)
PROjECT OPTImISATION
Free project assistance in the development phase. In close collaboration with architects, we advise on the optimization of products, function, safety, sound and energy require-ments, as well as U and G values for the solution of your specific window challenges in the project.
• Project optimisation / Value-Engineering • Price optimisations (materials, function,
acces-sories, custom solutions)
• Product 0ptimisations (function, safety) • Energy Optimisations for the project
• Total economy (products, installation, after sales, energy conservation)
ORDER ClARIFICATION
The order clarification ensures a 100% detailed project cost and energy optimisation. Efficient Project Management plans and man-age packman-age flow, optimisation of schedules for delivery and e.g. hooks for crane by unloading - adapted to the continuous supply for long project schedules, etc..
• Constitution of time schedules
• Preparation of package plans - optimising workflow (by floor, per facade, unloading etc) • Installation consulting, details / drawings • Review of possible price optimisations • Review of possible energy optimisations
DElIVERy & ON SITE START SERVICES
Strong logistics ensures on-time delivery at the construction site from the agreed pack-age plans for the sequential workflow. We know our products and offer to meet at the building site to demonstrate the correct in-stallation - for free. A Startup Service, which will ensure error-free installation.
• Effective delivery - in agreed and tagged flow • At project delay - rent warehouse / storage space • Options - assembly of complex facade solutions by certified installers can be provided
• Start Service - Free on-site installation advice - ensures efficient and correct error-free installation
AFTER-SAlES SERVICES
Customer satisfaction is ensured through project monitoring and quality assurance. Customer service is in focus, ensuring a competent, fair and fast solution-oriented handling of complaints. Service Packages with maintenance every 2 years and +5 years extra warranty to secure the investment.
• Service package - adjustment, cleaning and lubrication and +5 years extra warranty • Security package for selected products - tested according to BS7950
• Servicebox with appropriate equipment for maintenance
• Spare part deliveries during the warranty period
1 2 3 4 5 6
PRO TEC can supply valuable support for every step of the
building process. Right from when your initial idea is
con-ceived we can assist you through to the finish – and beyond.
Enghaveskråningen
Holstebro, Denmark 1 2 3 4 5 6 14 15Børnehuset Bøgen
Kindergarten for approx. 100 children , Copenhagen N, Denmark.
PRO TEC have developed window systems offering extremely low heat loss and a large energy
contribution. This enables developers to renovate and build in a more energy-efficient way.
Sustainability and energy conservation
Certified energy savers
UP TO hAlF OF ThE WARmINg DISAPPEARS
Nearly half the energy used for heating buildings in Denmark disappears as heat loss through windows, doors and facades.
SUPER ENERgy-EFFICIENT WINDOWS REDUCE CO2 EmISSIONS
PRO TEC develops, manufactures and sells high-tech and super insulating low-energy windows, so the buildings lose less energy and emit less CO2.
PlUS ENERgy WINDOWS ACTS AS A RADIATOR
In addition, we manufacture plus-energy windows, giving more energy to the building than it loses. And we deliver products and know-how to manufacturers of passive houses.
lONg lIFE mEANS lESS RESOURCE CONSUmPTION
PRO TEC products are maintenance friendly and have a long life, so less resources are used to maintain and replace products.
gOOD INDOOR ClImATE AND NO CONDENSATION
We manufacture products that minimize condensation and mould and gives residents and users a good indoor climate, more daylight and less cold drafts.
A CONSCIOUS ChOICE OF mATERIAlS
PRO TEC only uses materials that meet our aspirations to contribute positively to the environment and manufacture sustainable products.
CE mARK
A CE mark on a product ensures product movement inside the EU mar-ket. EU Directives requires CE marking on a range of products and the harmonized standards describe the demands to environmental, health and safety. The new standard includes performance characteristics for windows and exterior doors without fire resistance and / or smoke density capacity.
DANISh WINDOW VERIFICATION (DWV)
DWV verifies that the members of the window industry comply to the standards for Technical Requirements. Control is carried out by the Danish Technological Institute.
DWV must approve any new window construction before it is put into production. It is an important part of ongoing quality control, that the production does not deviate from the specifications and design drawings, which form the basis for approval.
ThE ENERgy mANAgEmENT AND ThE WINDOW INDUSTRy
Energy efficient PRO TEC windows are certified. PRO TEC windows have joined a new voluntary labeling of energy efficient windows established by the Energy Management
and the Window Industry. Energy labels show on a scale from A to F, how energy efficient the window is. All PRO TECs windows are labeled A, B or C, and therefore complies with all Building prescribed requirements in Denmark (BR10) - as well as future requirements.
gRP - bENEFITS ThE ENVIRONmENT by SAVINg ENERgy
With GRP, one is able to achieve excellent insulation properties. This means that the windows of GRP reduces heat loss from buildings and thus have a significant impact on the society’s reduction of CO2. As a Plus energy window it creates even more energy than it loses.
GRP does not rot or rust. Since GRP is not degraded by wind and weather, no energy and resources are used on producing new windows to replace old ones. GRP is nearly maintenance free in the lifetime of the product, thus reducing the need for paint and other chemicals for frequent maintenance.
GRP profiles are suitable for recycling and they are being recycled right now, although the quantities are small because of GRPs longevity. GRP is manufactured with a very low energy consumption, approx. 1/5 of the production energy used for aluminum. Moreover, GRP is lightweight and reduces the energy demand for transport, handling and assembly.
A
rg
um
en
ts
C
er
tif
ic
at
io
ns
U
-v
al
ue
s
AT ThE FOREFRONT OF ENERgy CONSERVATION REqUIREmENTS
The continuous demands for reductions in energy consumption and CO2 emitted emissions requires innovative solutions. PRO
TEC is at the forefront of high-tech window systems such as PRO TEC 7® and PRO TEC Classic+. The solutions ensures an
ex-tremely low heat loss and provides a large energy contribution, so the buildings lose less energy and emit less CO2 .
CERTIFIED ISO9001: 2008 qUAlITy mANAgEmENT
Quality is one of our most important competitive parameters that we keep full focus on. PRO TEC works actively to create quality improvement in all areas of the company. As the founda-tion of this work, we use the internafounda-tional ISO quality standards as an effective management tool, and the company was in 2011 ISO9001: 2008 certified.
10 yEAR WARRANTy ON SURFACE TREATmENT
Through a strong collaboration between PRO TEC and our
paint supplier, we implemented in 2010 a new super efficient surface treatment that ensures a uniform and durable surface, on which we offer a full 10 year warranty.
FOCUS ON SECURITy: SECURED by DESIgN
The acknowledged PRO TEC Classic system complies with the Secured By Design requirements, developed by the British po-lice. Experience shows that if a burglar can not gain access in under 3 minutes, he often abandons his undertaking. Certified windows and doors can resist professional attacks, with the use of crowbars, screwdrivers and chisels for over 3 minutes.
18 19
UW = 0,61 W/m2K
With a window solution made of GRP from the PRO TEC 7® series, exceptional
It is PRO TEC’s clear objective to become the leading supplier of innovative architectural facade solutions, customised to meet the specific demands and visions of our customers. Our success is closely linked to our ability to provide value within our areas of expertise.
• The comfort of freedom to design • High quality architectural designs • Innovative functionality and materials • Outstanding energy performances • Complete building process services • Durable and long lasting quality 1 PRO TEC - Pre-project Counselling
2 PRO TEC - Inspirational Toolbox 3 PRO TEC - Project Optimisation 4 PRO TEC - Order Clarification
5 PRO TEC - Delivery & On site Start Services 6 PRO TEC - After-Sales Services
We support all relations and add value to every aspect of a building process - ensuring your satisfaction - by realising architectural visions in unique customised facade solutions.
PRO TEC VINDUER A/S
Nybovej 34 · DK-7500 Holstebro · T: +45 9741 3077 · F: +45 9741 3060 · [email protected] · www.protec-facades.com
1 2 3 4 5 6
Freedom to design - with innovative product solutions and
services supporting the entire building process
Valuable support for every step of the building process
