The benchmark for

fl exibility

.

Whether as a single-line scanner for high-density codes, for example, in analysis

automation, with raster optics for reading trays in intra-logistics applications or

for inspecting industrial or printed products: the compact bar code readers of

the BCL 20 series convince with their high level of flexibility and handling

reliabili-ty in all areas.

The broad selection of optics also allows the scanners to be used in difficult

installation situations and in a wide range of applications, both in networks as

well as a standalone solution. Furthermore, the BCL 20 series convinces with its

outstanding reading performance through the automatic adaptation of the

receiver unit to the reading task on each scan. For an extended reading field,

such as that of a bar code reader with focusing function, the new BCL 20 S B is

availabe for higher resolution codes.

By means of simple online commands it is possible to set the reading task

without knowledge of the code. The PC-based BCL-Config tool, which is

avail-able for all Leuze bar code readers, is used to access the full function range.

Simple online commands make it possible to set the reading task without

know-ledge of codes. The BCL Config tool, which can be used for the entire function

range, is available for all bar code readers from Leuze electronic Connectivity.

Connection to industrial or Ethernet-based networks is now done directly via our

MA 200i modular interfacing units.

Laser scanners of the BCL 20 series –

as variable as your requirements demand.

(3)

(4)

Universally

usable –

fast

integration –

simple

to operate.

integration –

Various optics models: Different models with front or lateral beam exit

ena-ble optimum use of the installation space. Depending on the code alignment,

single-line or raster scanners offer optimised reading capacity

High, constant scanning rate up to 1000 scans/s: Considerable increase in

the reading reliability through multiple decoding of the read codes, even during

fast processes

Large depth of field and wide opening angle: High reading capacity with codes

having line thicknesses as narrow as 150 μm facilitates front or lateral reading

on your goods

Integrated multiNet: Up to 31 scanners can be networked in Leuze electronic's

own scanner network with minimal installation effort and, if desired, integrated

via gateways to the fieldbus level or directly to the host

Simple operation: With the aid of online commands such as AutoConfig, the

scanner can be set optimally, even without knowledge of the code

Easy configuration: The PC-based BCL-Config operating software for all Leuze

bar code readers simplifies adjustments and direct communication with the

scanner through graphical configuration

Blue laser diodes with extended reading field without focus adjustment for

higher resolution codes and optimized optics for glossy and cylindrical objects.

(5)

Light source

gew

hgagh

föjfäää

BCL 21

Integrated RS 485 interface and

RS 232 service interface

Freely configurable or direct connection to the

Leuze electronic multiNet network

1 switching input and 1 switching output

Connect up to 31 scanners to one master in the

Leuze electronic multiNet

BCL 22

Integrated, freely configurable RS 232 interface

Standalone operation or daisy chain with up to four

BCL 22 devices

2 switching inputs and 2 switching outputs

Direct connenction to PROFIBUS or other networks via

modular connector units as gateways

multiNet

Interface variants and

connector units.

Both systems are available with a 15-pin Sub-D connector or with a system plug for directly connecting to a modular connector unit.

Modular connector units BCL 21 BCL 22

MA 22 DC MA 2 MA 4 (D) 1xx MA 4 (D) MA 42 IS/DP-k

MA 200i PROFINET IO/RT, PROFIBUS DP, INTERBUS, Ethernet _{TCP/IP, UDP, IP, EtherCAT, DeviceNet, CANopen} PROFINET IO/RT, PROFIBUS DP, INTERBUS, Ethernet _{TCP/IP, UDP, IP, EtherCAT, DeviceNet, CANopen}

Mounting devices BT 20 BT 21

BCL 21

multi Net

BCL 22

Fig.: BCL 21/22

Front beam exit

Fig.: BCL 21/22

(6)

Technical data

Optical data BCL 21 BCL 22 BCL 2x S B

Type line or raster scanner (10 lines) line or raster scanner (10 lines) line scanner

Light source laser diode, red, approx. 650 nm laser diode, red, approx. 650 nm laser diode, blue, approx. 405 nm

Beam exit front or lateral front or lateral front or lateral

Scanning rate 800 scans/s (N-/F-optics), _{1000 scans/s (M-optics)} 800 scans/s (N-/F-optics), _{1000 scans/s (M-optics)} 800 scans/s (B-optics)

Max. usable opening angle approx. 65° approx. 65° approx. 65°

Optics models / resolution N-/M-/F-optics, see reading fi eld curves N-/M-/F-optics, see reading fi eld curves N-/M-/F-optics, see reading fi eld curves

Read distance see reading fi eld curves see reading fi eld curves see reading fi eld curves

Laser safety class Class 2 acc. to EN 60825-1, CDRH

(U.S. 21 CFR 1040.10)

Class 2 acc. to EN 60825-1, CDRH (U.S. 21 CFR 1040.10)

Bar code data

Code types 2/5l, Code 39, Code 93, Code 128,

EAN 128, EAN/UPC, EAN add-on, Codabar (monarch), Pharmacode

2/5l, Code 39, Code 93, Code 128, EAN 128, EAN/UPC, EAN add-on, Codabar (monarch), Pharmacode

Number of codes per scan 6 6 6

Number of codes per reading gate 62 62 62

Electrical data

Interface RS 485 RS 232 RS 232

Protocols Leuze Standard, multiNet, Ack/Nak Leuze Standard, multiNet, Ack/Nak,

3964, DC

Leuze Standard, multiNet, Ack/Nak, 3964, DC

Baud rate 110 ... 115200 baud 110 ... 115200 baud 110 ... 115200 baud

Data formats 7, 8, 9 data bits

none, even, odd parity 1, 2 stop bit(s)

7, 8, 9 data bits none, even, odd parity 1, 2 stop bit(s)

Service interface RS 232, 9600 baud, 8 data bits,

no parity, 1 stop bit

RS 232, 9600 baud, 8 data bits, no parity, 1 stop bit

Switching inputs/outputs 1 switching input, 1 switching output 2 switching inputs, 2 switching outputs 2 switching inputs, 2 switching outputs

Operating voltage 10 … 30 V DC 10 … 30 V DC 10 … 30 V DC

Power consumption max. 3.2 VA max. 3.2 VA max. 3.2 VA

Operating and display elements

LEDs 1 Pwr/Err LED, 1 Decode LED 1 Pwr/Err LED, 1 Decode LED 1 Pwr/Err LED, 1 Decode LED

Mechanical data

Protection class IP 54 IP 54 IP 54

Weight 180 g (0.8 m)/260 g (3 m cable) 180 g (0.8 m)/260 g (3 m cable) 180 g (0.8 m)/260 g (3 m cable)

Dimensions (W × H × D) 82 × 68 × 28 mm3 _{82 × 68 × 28 mm}3 _{82 × 68 × 28 mm}3

Housing plastic ABS / PC plastic ABS / PC plastic ABS / PC

Environmental data

Operating temperature range 0 °C … +40 °C 0 °C … +40 °C 0 °C … +40 °C

Storage temperature range -20 °C … +60 °C -20 °C … +60 °C -20 °C … +60 °C

Air humidity max. 80% rel. humidity, non- condensing max. 80% rel. humidity, non- condensing max. 80% rel. humidity, non- condensing

Vibration IEC 60068-2-6, FC test IEC 60068-2-6, FC test IEC 60068-2-6, FC test

Shock IEC 60068-2-27, Ea test IEC 60068-2-27, Ea test IEC 60068-2-27, Ea test

Electromag. compatibility IEC 61000-6-2, -6-3 IEC 61000-6-2, -6-3 IEC 61000-6-2, -6-3

Certifi cations

(7)

Reading fi eld curve, N-optics

Reading fi eld curve, M-optics

20 0 40 60 80 100 120 140 160 180 200 220 240 260 -50 -100 50 100 150 -150 m = 0,3 m = 0,5 m = 0,8 m = 0,2 m = 0,2 m = 0,3 m = 0,5 m = 0,8

Reading field width [

mm ] Read distance [mm] 10 0 20 30 40 50 60 70 80 90 100 10 -10 -20 -30 -40 -50 20 30 40 50 60 -60 m = 0,2 m = 0,1 5 m = 0,15 m = 0,2

mm

]

Read distance [mm]

Reading fi eld curve, SB-optics

-90 -60 -30 -80 -50 -20 -70 -40 -10 0 30 60 90 20 50 80 10 40 70 0 20 40 60 80 100 120 140 160 180 200 220 240 m = 0.3 mm m = 0.2 mm m = 0.165 mm m = 0.3 mm m = 0.2 mm m = 0.165 mm

mm ] Read distance [mm] 220 240 260 m = 0,5 m = 0,8 m = 0,3 m = 0,5 m = 0,8 40 0 80 120 160 200 240 280 320 360 400 440 480 -50 -100 50 100 150 -150 m = 0,8 m = 1,0 m = 0,5 m = 0,5 m = 0,8 m = 1,0

mm

]

Read distance [mm]

Reading fi eld curve, F-optics

(8)
