Complete Heating Cable Solutions
Danfoss Floor Heating Electrical
www.danfoss.in
Danfoss - Electrical Floor Heating
Danfoss provides efficient heating,be it at home, in your bathroom or living room, at the office, in a workshop, sports hall or virtually any where that requires comfortable warmth.
Danfoss underfloor heating is used in connection on with new building or can be fitted on top of the old flooring,e.g.when renovating a bathroom.
Danfoss underfloor heating can be used as the only heating source in the room, or as an additional source of heat, making the floor comfortably warm.
Danfoss Floor heating systems have a life expectancy similar to the rest of the electrical installation in a house.
Danfoss solution is very effective in Turkhish Bath heating. Walking area, seats, walls and central stone is heated up with Danfoss cables.
Generally Devireg touch screen thermostat is suggested for hammams. Intelligent timer will make your Turkhish Bath warm enough before you start your pleasure...
Optimum Comfort
Danfoss electrical floor heating gives you the luxury and comfort of a warm floor as well as a pleasant room temper- ature.
1
2
3
4
5
Sound Operating Economy The intelligent Danfoss thermostat ensures accurate temperature control with minimal energy use.
Invisible Heating
Installed beneath the floor gives com- plete freedom when furnishing your room.
Simple Installation
Being ultra thin, less than 3 mm, the Danfoss heating mat’s can be installed just below the surface within the floor compound.
Durable
The Danfoss electrical floor heating products, manufactured in Europe by Danfoss NS, has a 10 year warranty
71 years
experience.
20 years
warranty.
Danfoss - Ice - Snow Melting Systems
Danfoss provides a high-tech solutions to efficiently fight against ice and snow
An ice and snow melting system from Danfoss is an investment in comfort and safety,making concerns about sudden building damages and driver, pedestrian safety unnecessary.
Efficient heat control ensures a good overall economy Danfoss™ thermostats and sensors ensure that the absolute minimum amount of energy is used to achieve optimum results.
Application Areas
The most typical Danfoss ice and snow melting applications on ground are car parks, driveways, pavements, outdoor steps, loading platforms and bridges.
In addition, the system is a financially sound investment as roofs, drainpipes, and roof gutters are always expensive to renovate after a harsh winter.
A Danfoss ice and snow melting system consists of a heating cable, an electronic thermostat and installation accessories.
Danfoss - Permafrost Protection
Frost protection of floors in cold stores, ice stadiums etc. It might seem contradictious to heat up the floor construction in a cold store,- but it is actually a necessity in order to protect the building.
In cold rooms and cold stores where the temperature is constantly between -20 and -30 °C, coldness will still be given off to the surroundings even though the floor is well insulated. This means that the materials which are in contact with the ground, such as foundation and floor areas, will absorb the cold and the ground will freeze.
The water content in the ground/
soil will expand and this can cause considerable damages due to frost erosion. The same problem also appears in ice stadiums, which are artificially frozen. A Danfoss frost protection system prevents damages on the buidings foundation and floors.
The super cooling problems can be avoided by installing a Danfoss frost protection system consisting of Danfoss heating cables controlled by a Danfoss thermostat. The heating cables build up a border between the cold surface and the underground and maintains a frost free soil temperature.
Mist free mirror!
Danfoss™ Mirror Heating
Small bathrooms in particular suffer from the misting mirror problem.
No matter how well the room is ventilated,the combination of high humidity and heat results in misted mirrors. But the problem can be solved in an easy and, more importantly, elegant way by installing an electrical Danfoss mirror heating mat in the tile adhesive behind the mirror. The heating mat behind the mirror quickly heats up the mirror, and misted mirror is avoided.
Mist free comfort at a low running cost
By installing the Danfoss mirror heating mat so that it switches on with the rest of the light in the bathroom - like a ventilator - you get mist free comfort with an energy consumption of a 60W
light bulb. And you only use energy while being in the bathroom with the light on!
Easy installation
The Danfoss mirror mat is easy to install and an experienced DIY man can install the heating mat behind the mirror.
But please remember an authorised installer must make the connection to the power supply.
Devireg™ 330-series
One thermostat in five editions Applications:
• Indoor room heating
• Indoor comfort heating
• Pipe tracing
The Devireg™ 330 is the preferred choice for several applications.
Devireg™ 330 is supplied in five seperate editions each with a different temperature range.
Thermostat 535
Benefits:
• 2-pole safety breaker
• Low standby consumption
• Timer thermostat
• Optional sensing functions
• Sensor failure monitoring
• LED indication for fault
• Frost protection
DEVIflex™ 18T (DTIP)
DEVIflex™ 18T is a high-performance, flexible electrical heating cable that complies with the M2 requirements of the tough IEC 60800:2009 standard.
Its round profile makes it simple to install in a wide range of indoor floor constructions. It also features a clearly visible round cold lead to avoid accidentally installing heated cable in the conduit.
DEVIflex™ is a fully screened twin conductor cable with a tough red PVC outer sheath. Top-quality materials and rugged construction mean that we are happy to supply all DEVIflex™
cables with our unique 20-year DEVI warranty™.
• Easy to install
•
•
Flexible cable
•
Safe and robust
•
Long life-time
Type Value
DEVIwarranty™ 20 years
220V - 240V Operation voltage
Construction
18 W/m Output
Round, twin conductor with screen, one cold lead
65° C Ø 6.9 mm Cable dimensions
Max. ambient temperature
1500N Deformation strength
500N Pulling strength
•
Standard compliance:
•
with IEC60800:2009
PEX
Third party approval by SEMKO
Conductor insulation
PVC Outer sheath
Screen
Cold lead 2.3 m DTCL, earthed
-5° C Min. installation temperature
Min. bending radius 6 x cable diameter (Ø)
DEVIflex™ 10T (DTIP)
DEVIflex™ 10T is a high-performance, flexible electrical heating cable that complies with the M2 requirements of the tough IEC 60800:2009 standard.
Its round profile makes it simple to install in a wide range of indoor floor constructions and pipe tracing systems.
It also features a clearly visible round cold lead to avoid accidentally installing heated cable in the wall pipe.
DEVIflex™ is a fully screened twin conductor cable with a tough red PVC outer sheath. Top-quality materials and rugged construction mean that we are happy to supply all DEVIflex™
cables with our unique 20-year DEVIwarranty™.
DEVIreg™ Touch
DEVIreg™ Touch is first of all build on the insight, that using an electric floor heating thermostat has, so far, been
“first time every time”.
Secondly, DEVIreg™ Touch is build on the insight, that a sturdy reliable product is better than smart but fragile features.
When floors in flats, houses, basements or patios are renovated, electric floor heating can be added without breaking up the old floor. Likewise in new build.
To balance the comfort with energy use a timer thermostat is installed.
But the need for comfort is changing on a weekly, daily and sometime even hourly basis and that actual accessibility of the thermostat become essential to the end user.
Do not install floor heating systems without a floor sensor when the heating element is installed on or beneath wooden surfaces and other surfaces sensitive to temperature!
• Easy to install
•
•
Flexible cable
•
Safe and robust
•
Long life-time
Type Value
DEVIwarranty™ 20 years
220V - 240V Operation voltage
Construction
10 W/m Output
Round, twin conductor with screen, one cold lead
65° C Ø 6.9 mm Cable dimensions
Max. ambient temperature
1500N Deformation strength
500N Pulling strength
•
Standard compliance:
•
with IEC60800:2009
PEX
Third party approval by SEMKO
Conductor insulation
PVC Outer sheath
Screen
Cold lead 2.3 m DTCL, earthed
-5° C Min. installation temperature
Min. bending radius 6 x cable diameter (Ø)
Product features:
Installer features
• Interface developed and tested with end users and installers
• Compatible with several frame systems for electrical appliances
• Patented compatibility with both single and multiple frames
• Setup according to room and floor type (wooden floor safe)
• Optional setup via code for multi- ple installations
• Support several foreign NTC
sensors
• Patented read-out and read-in of setup code for long distance web support
• Web based automated replace- ment system
End user features
• Fully flexible and intuitive timer
• 2” touch display in modern discreet design
• Shortcut button for Away, Frost
Protection, Timer off and Off mode
• Stop energy waste package - Low CA value
- Open window detection - Consumption meter
- 3rd generation forecast function with optimum start up and shut down
• Sensor failure monitoring
• Standard compliance EN 60730 certified by SEMKO
Danfoss Link™
-wireless control,comfort and convenience
Danfoss Link™ is a new and innovative electrical floor heating control system.
The system consists of a centrally placed main unit used to control sensors and thermostats throughout
the house. This means that you can control the temperatures of your entire house from one central controller.
It is a simple and user friendly system that invites to be used. The user friendliness is supported by the minimalistic design without a wealth of confusing buttons.
The system is very easy and intuitive to use, but if in doubt there is help available right at your fingertips.
The easy central heating control saves energy, as it is very simple to setup temperature lowering at night, and when going on holiday to lower t he temperature in all rooms. Danfoss Link™is the heating control system of the future, and it builds on a scalable platform, so that when new requirements arise,the system is built to expand with its needs.
The idea of the Danfoss Link™ is to link together your heating system wirelessly and control it from one central point.
