Evolving Gasification technology to provide Innovative Low Carbon Solutions for the European Market

(1)

Refinery Polygen

Chemicals Electricity

Synthetic Natural Gas

Transportation Fuels

GE’s Gasification Technology

Evolving Gasification technology to provide

Innovative Low Carbon Solutions for the

European Market

Ilya Solovyev, Solutions Sales Executive

New Horizons in Gasification. Rotterdam, 10-13 March 2014.

GE Power & Water

(2)

2

Disclaimer

© 2013 General Electric Company.

GE Proprietary Information - The information contained in this document

is General Electric Company (GE) proprietary information. It is the

property of GE and shall not be used, disclosed to others or reproduced

without the express written consent of GE, including, but without

limitation, it is not to be used in the creation. manufacture. development,

or derivation of any repairs, modifications, spare parts, or configuration

changes or to obtain government or regulatory approval to do so, if

consent is given for reproduction in whole or in part, this notice and the

notice set forth on each page of this document shall appear in any such

reproduction in whole or in part. The information contained in this

document may also be controlled by the US export control laws.

Unauthorized export or re-export is prohibited.

(3)

3

Installed fleet by the numbers

GE has

gasifiers in commercial

operation

… the

largest fleet

in the

industry … with

additional

gasifiers in development, engineering,

or construction at

plants …

and a

global presence

in

different countries.

157

95

25

(4)

4

Refineries

Chemicals

Coal to liquids

Ammonia

Oxochemicals: Butanol, Ethylhexanol Hydrogen Steam Power Methanol Formaldehyde MTBE Acetic acid Amine DME Urea Ammonia nitrate/sulfate

Syngas out

(H

₂

+ CO)

Power (IGCC) Greenfield Polygen Refueling Site repowering Transportation fuels

Gasification technology

Methanation Substitute natural gas

Feedstock in

• Coal • Pet coke • Asphalt • Heavy Oil • Vacuum Residue • Natural Gas • Process gas

(5)

(6)

6

GE’s IGCC solution

• Features GE gasification and syngas power block technology and equipment

• Configured for increased efficiency, availability, and operability

• Low emissions

Coal

Pet. Coke Heavy Oil Blends

Flexible fuels

Integrated configuration

Reliable Products

Power Steam Hydrogen CO₂ (for EOR)

(7)

7

Plant Performance

• 618 MW net, 38.5% plant eff. HHV • 85% coal to power availability

• Lower emissions than super critical pulverized coal (SCPC)

• Reduced water consumption when compared to SCPC

• Useful byproducts

Plant Configuration (2x2x1)

• (2) GE gasification trains

• (2) GE 7F Syngas gas turbine/generator sets • (2) Heat recovery steam generators (HRSGs),

two pressure re-heat with selective catalytic reduction

• (1) GE steam turbine/generator set~360MW • NG for start-up/back-up fuel/co-fire

World’s Largest IGCC

• Duke Energy … overall manager • GE Power & Water … process

engineering package + engineered equipment, plant distributed control system

• Bechtel Power … Detailed engineering and construction support services

(8)

8

Radiant Syngas Cooler

Improved Feed Injector Advanced Refractory

207 G13-34 Steam Turbine

GE Water

Low Emissions Carbon Island Ready

Mark* VIe Controls

GE Technology Edwardsport

7F Syngas Turbines

(9)

(10)

10

Efficient pollutant removal

Pre-Combustion PM, Hg, Su

Pulverized coal

• Pollutants are removed after the coal is burned

• The gas volume treated is 300 times the gas volume of an IGCC plant

• Criteria and HAPS emissions are above an average IGCC plant

• Combustion produces large quantities of waste and consumes more water than IGCC

IGCC

• Gasification cleans the syngas before combustion

• High pressure and low volume provide favorable economics for pollutant removal

• IGCC offers increased fuel diversity, reduced emissions, and increased siting and permitting flexibility

Boiler SCR ESP/_FF Carbon Injection FF FGD WESP CO₂

(11)

11

IGCC emissions approach NGCC levels

Sulfur

Lowest permitted sulfur emissions

from a U.S. coal plant today

• Emits 0.01 lb/MMBtu

• Best PC is 0.05 lb/MMBtu

Mercury

Superior, cost-efficient Hg removal

NOX

Lowest NOX permitted plant using

bituminous coals today in the US

• Emits 0.02 lb/MMBtu

• Best PC is 0.05 lb/MMBtu

• 62% less CO • CO2capture ready • 33% less NO_x • 75% less SO_x

IGCC benefits compared to supercritical pulverized coal in the U.S.

Source: GE internal data, average of 30 permits granted .02 .05 .01 Advanced PC/SCPC IGCC capability NGCC 0.00 0.05 0.10 0.15

Average recent

permit data

Best individual

plant

Lb/MMBTU

NO_x SO_X PM10 .02 .01 .01 .02 .02

(12)

12

Gasification … more than just BTUs

Coal composition

Carbon

Nitrogen

Sulfur

Ash

Volatiles

Hydrogen

Combustion

CO

₂

NO

_X

SO

_X

Ash

100 H

₂

O

Gasification yields

CO

N

₂

H

₂

S

Vitrified

slag

1

Used in manufacture of industrial chemicals heating value

Inert gas for process Useful in manufacture of chemicals and/or saleable by-product

Saleable by-product

Low volatiles saves on disposal

(13)

(14)

14

Methanol value chain

Simplest alcohol … one C atom

Substitute for gasoline or diesel in

automobiles

• Low pollution, high performance

• Versatile fuel … economically attractive

Formaldehyde MTBE Acetic acid Methylamine Gasoline blending DME Methyl Methacrylate Solvents Olefins Biodiesel

Fuel Cell (hydrogen carrier) Ethylene

Propylene

Gasoline/Diesel Gas Turbine fuel

Fuels

Chemicals

(15)

15

GE Gasification Gas Cooling & Shift Oxygen Coal 2,6 mil t/year Sulfur 30 kt/y Sulphur Removal & Recovery

Shenhua Baotou Coal to MTO

MeOH

Wastewater Pretreatment

Location: Baotou, Inner Mongolia, China

Feedstock: Coal

Design Capacity: 352 t/h

Operation Pressure: 65 bar

Gasifier Size: 5+2 x 900 ft³ Quench

>96% availability PP & PE 1,8 MM t/y _{PE 300 kt/y} C4 100 kt/y C5 25 kt/y PP 300 kt/y

(16)

16

Ammonia value chain

Nitric Acid and nitrates Synthetic fibers - nylon Refrigeration Pharmaceuticals Urea Ammonium Salts

H

Bleaching agent

Basic building block for nearly all

fertilizers that contain nitrogen

Base compound for a variety of

chemicals and solvents

Fertilizers

Chemicals

(17)

17

Gas Cooling & Shift Oxygen Coal 0.5 mil t/year Sulfur 5 kt/y Sulphur Removal & Recovery

Dahua Fertilizer, Coal to Ammonia

Ammonia

Wastewater Pretreatment

Location: Dalian, China

Feedstock: Coal

Design Capacity: 1,000t/d

Operation Pressure: 87 bara

Gasifier Size: 2+1, 450ft³ Quench

Start-up Date: 2009

>94% availability

Final Peoduct

300KM t/y _{Soda 600 kt/y} Nitramine 200 kt/y Nitric acid 30 kt/y Compound fertilizer 500kt/y Mg(OH)2 Firemaster10kt/y GE Gasification

Photo or pcture

to be added

(18)

18

Fuel

Flexibility

Quench Gasifiers

Up to 87 bar

Improving

RAM/Operations

GE Quench Gasification Technology

Advanced Refractory

2 X Life

450 cuft 900 cuft 1,800 cuft

Safety Systems Latest release Improved Feed Injector 50% X Life Syngas 87 bar

Integrated Gasification Solutions

5%-10% MeOH cost 5% capex + Up to 18 MW per train MeOH Production GE O&G Expander _Syngas Electricity Coal Refining Residuals Natural Gas Blends

(19)

(20)

20

>90% availability (no spare) GE Gasification Gas Cooling Oxygen Visbreaker Tar 150 t/h Sulfur Sulphur Removal & Recovery Steam to Refinery LP = 85 t/h

Refinery polygeneration

GE Combined Cycle Hydrogen Production H2 to Refinery 40,000 Nm3/h Wastewater Pretreatment Filter Cake to metals reclaimer

Location: Sarroch (Cagliari), Sardinia, Italy

Feedstock: Visbreaker tar

Design Capacity: 50 t/h (per gasifier)

Gasifier Size: 3 x 900 ft³

Power Block: 550MW – 3x109E CC Units

Power to Grid 551 MW

Steam to Refinery MP = 100 t/h

(21)

21

Refinery emissions reduction

Source: Data provided with permission of ISAB Energy Services on behalf of ERG

E

m

is

si

o

n

s

(m

g

/N

m

3

)

1700

500

80

400

200

50

74 ₅₂

10

0

200

400

600

800 1000

1200

1400

1600

1800

SOx

NOx

Particulates

Refinery before gasification DM 12/07/90 Authority limits

(22)

(23)

23

Low Rank Coal Envelope

0 5 10 15 20 25 30 35 40 45 50 0 5 10 15 20 25 30 35 40

Ash (%)

M

o

is

tu

re

(%

)

GE Extended

Slurry Process

Conventional GE

Slurry Process

(24)

24

New Plants

• Wider coal envelope

• System-level

improvement

• Higher efficiency

Retrofit

• Economic

• Responsive

• Flexibility

Why is extended slurry needed?

(25)

25

0 5 10 15 20 25 30 35 40 45 50 0 5 10 15 20 25 30 35 40

Ash (%)

M

o

is

tu

re

(%

)

Case study

600KTA coal-to-chemical project

- 5.0%

Standard OXYGEN consumption

- 2.0%

Standard COAL consumption

+ 3.0%

Effective syngas content

- 9.0%

Standard OXYGEN consumption

- 4.0%

Standard COAL consumption

+ 3.0%

Effective syngas content

(26)
