International Journal of Advanced Research in
Computer Science and Software Engineering
Research Paper
Available online at:
www.ijarcsse.com
Performance of Data Warehousing Based Social Network
Analysis in Cloud Computing Using Crawler Algorithm
J.Gobinath1 D.Revathi2
Asst Professor, IT Dept. Asst Professor, MCA Dept.
Rajiv Gandhi college of Engineering Vel Tech High Tech DR Rangarajan DR Sakunthala Sriperumbudur, Chennai, India Engineering College, Avadi, Chennai, India
Abstract: Cloud computing has been recognized as extremely time-consuming tasks as well as large storage space and it is necessary for order to store the social data, especially to deal with the data in the World Wide Web. We proposed a data warehousing and analyzing system which is based on the concept of cloud computing. The system has also been implemented and evaluated under the proposed environment with different cloud computing approaches.
Keywords: Social Networks Analysis, Cloud Computing, Map Reduce, BSP
I. Introduction
Social Networks Analysis (SNA) [3] is a very suitable and important research method for analyzing the social data structure to understand the characteristics of a network. Furthermore, the analysis results can be applied to many useful areas, such as marketing, the detection of crime and terrorists, recently, the web data are the main t a r g e t i n many researches about using information technology in the area of social networks analysis. However, the data in the web are usually very messy and noisy, as well as the size of the data is always e x t r e m e l y large.
Thus, researchers us ua l l y need to spend large amount of resources and time to collect data, to pre-process data, to perform different means of social networks analyses (very high dimensional matrix computation and the processing of networks graph) as well as to visualize the social networks. In the other hand, large storage space i s a l s o necessary to store the large amount of social data. Cloud computing is the current buzzword in the air [2]. The name “Cloud Computing “was inspired by the cloud symbol that's often used to represent the Internet in flow charts and diagrams. In short cloud computing means using the Internet for all computer needs. Cloud computing is a natural evolution of the widespread adoption of virtualization, service-oriented architecture, autonomic and utility computing [1]. Cloud computing is therefore a very suitable solution for SNA and which can also be used to enhance the efficiency and performance of related researches.
To overcome the rece nt problems and difficulties in SNA by applying the techniques. Therefore, a system has been proposed which is based on the concept o f c lo ud c o mp u t i n g . The s ys te m no t o n l y a d a t a warehousing system but also a SNA engine can be used to perform different SNA analyses with high performance, t h e system will be implemented as well as the performance will be tested by using different techniques of cloud computing.
II. Literature Review A. Social Network Analysis
Social network analysis is developed to understand the relationship between “actors”, and the term actor can be a person, an organization, an event or an object. In a social network, each actor is presented as a node and each pair of nodes can be connected by lines to show the relationships. The social network structure graph is a graph that formed by those lines and nodes, and social network analysis is therefore a methodology the relationships. The social network[3][4] structure graph is a graph that formed by those lines and nodes, and social network analysis is therefore a methodology that used to understand the graph and the relationships and actors in the social network .
There are three important elements that included in a social network: actors, ties, and relationships. Actors are the essential elements in the social network to define the people, events or objects. Ties are used to construct the relationship between actors by using a mean of path to establish the relationship directly or indirectly. Ties can also be divided into strong tie and weak tie according to the strength of the relationships; they are also useful for discovering the subgroups of the social network. The most important measurements of SNA include network size, diameter, density, centrality and structure holes. Size is a measurement to measure the amount of nodes or links in a network, and the measurement of diameter is to measure the amount of nodes between two nodes in a network. Density is used to calculate the closeness of a network. These measurements are common used in many social network related researches and will be used in this paper as well.
B. Cloud Computing
March - 2013, pp. 202-206
defined as an Internet service which provides extensible services dynamically over the Internet. According to the provided services, cloud computing can be categorized as SaaS (Software as a Service), PaaS (Platform as a service) and IaaS (Infrastructure as a Service)[7]. Proposed another cloud computing categorization which categorizes cloud computing as “pubic cloud” and “private cloud” with a consideration of the integration of hardware Equipment and software services .
Fig: 1: The architecture of cloud computing
The Map Reduce technique which is proposed by Google is a very famous instance of public cloud computing, it can be used for computer programs that need to process and generate large amount of data. For example, Map Reduce has been used to generate the index of Google and it also has the strength in data locality, fault tolerant and parallel process. This s t r e n g t h i s h e l p f u l f o r Map Reduce t o enhance t h e performance. However, Map Reduce has its weakness i n mathematical graph process. In social networks analysis researches, the computation and processing of graph is essential. Therefore, how to deal with this problem is a very important issue to implement cloud computing for social networks analysis.
The problem that discussed above about Map Reduce can be solved by applying a BSP (Bulk Synchronous Parallel) model to perform “super step“ repeatedly and using the concept of parallel processing . BSP to solve the problem of Map Reduce. The proposed system architecture try to apply and implement a BSP based cloud computing technique for the data processing requirement of social networks analysis.
III. Proposed System Architecture And Analysis
According to the research background and literature review, we proposed system architecture for social data warehousing and analyzing. According to different tasks in the system architecture, the components in the system can be divided into three different parts, which are front-end data collection components, intermediate system
analysis components and analysis results producing components.
1) Front-end data collection components
In the system, well-designed crawling programs are included as one of the front-end data collection components. The data front-end data collection system collects social data from different social networking websites in different locations. First will collect data from some famous social Networking.
Websites, such as Facebook[5] (www.facebook.com), plurk (www.plurk.com) and wretch (www.wretch.cc) etc. The collected data by crawling agents will then be stored in distributed environment.
2) Intermediate system analysis components
After collecting front and data collection and then data are stored in the system are raw data. Then the s ys t e m w i l l provide data after d i f fe r e nt level o f processing to users according to their requirements. BSP will be used as the technique to play as role to process social data according t o d i f f e r e n t algorithms, w h i c h i s b a s e d o n structure of Master/Worker. In the system, Master has to assign works to workers and to acquire the processing results. Workers will perform the works according to the assignment form the Master. The assignments could be data pre-processing, social networks analysis or visualization.
3) Analysis result producing components
After performing appropriate algorithms by the Intermediate system analysis components, the analysis result producing components will play as a role to produce results to fit the analysis requirements of users. The users can either send requests to the provided web based interface or API (Application P r o g r a m I nter face ). The main c o n c e r n o f the analysis result producing components is the ability of cross- platform and the web based interface and API will be able to communicate between different platforms.
4) System Design
March - 2013, pp. 202-206
user to interact, send queries, and acquire the analysis results. The system is designed based on the idea of “Interoperability” which allows the users to manipulate data and perform analysis by using different operating systems or platforms.
Fig: 2: The architecture of the proposed system
Fig: 3: The use case diagram of the proposed system
It shows the use case diagram of the proposed system. By using the system, the users can extract raw data in the social data warehouse or pre-processed data after data cleaning, or relationship matrix which transformed from the raw data. Users c a n a l s o s e n d reque st s t o a s k t h e c l o ud computing platform to perform social networks analysis and to show the analysis results. The social network analysis measurements [5][6] that included in this system include: network diameter, degree centrality, c l o s e n e s s centrality, between centrality. In additional, the users can also acquire the visualized network graph of appropriate social networks.
IV. Experiments Design And Performance Evaluation
To test the proposed system as well as to compare the performance when adopting different cloud computing in the system, a serial of experiments has been designed. In this section, we will first introduce the design of the experiments and then present the results of the performance evaluation for discussion.
1. The Design of the Experiments
In order to test the system performance,[8] we have designed a serial of experiments. The front-end data collection components have been chosen as the test target, as it could be the most time-consuming tasks in the entire system. Therefore, [8][9]the experiment designed is by running crawling process on two different platforms. One bases on Map Reduce, t h e other Bulk Synchronous Parallel (BSP). The former creates a simple programming model for developers easily manipulating large data set, the latter consists of simple steps addressing the distributed processing real life graphs. The implementations of BSP and Map Reduce involved in the experiment are Apache's Hadoop Map Reduce and A p a c he Hama.[9] The purpose of the experiment is to compare the crawler performance executed on these two major platforms. The procedure for such testing starts with:
1st, the client submits a job which encapsulates crawling algorithm for Map Reduce and BSP platform respectively. 2nd, the crawler fetches the designated pages according to the given URL list.
March - 2013, pp. 202-206
inspired by the Google file system.
The pseudo code of the algorithm with Map Reduce
Input : A set of framework names F ={Map Reduce, Hama}. An input url list path points to a file, which contains a list of websites L = <l1, l2... ln> such that I=string. An output path p points to a file, which will store web pages to be crawled, p=string.
Output : A file which contains crawled web pages P = <p1, p2, ..., pn> 1 if f = Map Reduce
2 then map phase
3 for every URL <- l1 to ln 4 do pn <- crawl (URL) 5 collect (URL, pn)
6 reduce phase
7 for every URL <- l1 to ln 8 do save (URL, pn) to p 9 else if f = Hama
10 then read url-list
11 for every URL <- l1 to ln 12 do pn <- crawl (URL) 13 collect (URL, pn) 14 bsp sync () 15 while URL <- l1 to ln 16 do save (URL, pn) to p 17 output p
I t is the performance comparison of implementing BSP and Map Reduce in the system
Fig: 4: Performance Evaluation
X-axis shows the Number of URLs and the y-axis shows the execution time by second. From the analysis result i t s h o w s M a p R e d u c e h a s b e t t e r performance w h e n dealing with 100 URLs. However, with the increasing of the number of URLs, Hama BSP needs less time to accomplish the designed tasks a n d the performance i s m u c h b e t t e r t h a n Map Reduce.
V. Conclusion and Future Research
A system architecture has been proposed which is based on the concept of cloud computing. The main idea of the system is to deal with the difficulties of recent social networks analysis researches. The system is designed to store social d a t a in the data warehouse a n d t o p e r f o r m s o c i a l networks analysis and other processing. To evaluate the performance of the system and by this to decide the main cloud computing technique that used in the s y s t e m , i t h a s d e s i g n e d experiments t o p e r f o r m a crawling algorithm under specific environment. The evaluation results show that BSP have better performance than Man Reduce.
REFERENCES
[1] Armbrust, M., Fox, A., Griffith, R., Joseph, A. D., Katz, R., Andy Konwinski, A., Lee, G., Patterson, D., Rabkin, A., Stoica, I., and Zaharia, M. A view of cloud computing. Communications of ACM, 53(4):50–58, 2010.
[2] Birman, K., Chockler, G., and Renesse, R. V. (2009) Toward a Cloud Computing Research Agenda. SIGACT News, 40(2), pp.68–80.
March - 2013, pp. 202-206
of Computer- Mediated Communication, 13(1), 2007.
[4] Fu F., C h e n X ., L i u L ., a n d W a n g , L . (2007), “ Social Dilemmas in an Online Social Network: The Structure and Evolution of Cooperation", Physics Letters A, Vol 371, 2007, pp.58
[5] God bole, N., Srinivasaiah, M., Skiena, S. (2007), "Large-Scale Sentiment Analysis for News and Blogs", in Proceedings of ICWSM 2007, Boulder, Colorado, USA.
[6] Goodreau, S. M. (2007), “Advances in Exponential Random Graph (p*) Models Applied to A Large Social Network", Social Network, Vol. 29, 2007, pp.231-248.
[7] Grossman, R. L. (2009). The case for cloud computing. IT Professional, 11(2), pp.23–27.
[8] Jin, Y. Z., Matsuo, Y., and Ishizuka, M. (2007), “Extracting Social N e t w o r k s a m o n g V a r i o u s Entities o n t h e Web", I n Proceedings of the Fourth European Semantic Web Conference, 2007.
[9] Ting, I. H. (2008) “Web Mining Techniques for On-line Social Networks Analysis” In Proceedings of the 5th International Conference on Service Systems and Service Management, Melbourne, Australia, 30 June-2 July 2008, pp. 696-700.
[10] Xue, W., Shi, J. W., and Yang, B... (2010) X-RIME: Cloud- Based Large Scale Social Network Analysis. In Proceedings of the 7th I n t e r n a t i o n a l Conference on Service Computing (IEEE SCC), July 5-10, 2010, Miami, Florida, USA
