Audi A8

Audi A8

manufactured and marketed by the German automaker Audisince 1994. Succeeding theAudi V8, and now in its third generation, the A8 has been offered with both front- or permanentall-wheel drive—and in short- and long-wheelbase variants. The first two generations em-ployed theVolkswagen Group D platform, with the cur-rent generation deriving from theMLB platform. After the original model’s 1994 release, Audi released the sec-ond generation in late 2002, and the third and current it-eration in late 2009.

Notable for being the first mass-market car with an alu-minium chassis, all A8 models have used this construc-tion method co-developed withAlcoaand marketed as the Audi Space Frame.[1]

A mechanically-upgraded, high-performance version of the A8 debuted in 1996 as the Audi S8. Produced exclu-sively at Audi’sNeckarsulmplant, unlike the donor A8 model, the S8 has been available only in short-wheelbase form and is fitted standard with Audi’squattroall-wheel drive system.

1

First generation (D2, Typ 4D;

1994–2002)

1.1

Development

Audi Space FrameConcept Car

In 1982, Ferdinand Piëch signed an agreement with Aluminum Company of America. The objective was to design and develop a car that would be substantially lighter than any other vehicles in its class (to compensate

for the fact that standard all-wheel drive was around 100 kg heavier than competitors’ rear-wheel drive). In the late 1980s, it was decided that the target vehicle would be a successor to the V8 (Typ 4C) flagship introduced in 1988. By 1991, a final design by Chris Bird and Dirk van Braeckel was chosen and frozen for series production in 1992. In September 1993, theAudi Space Frame(ASF) Concept was unveiled at the 1993Frankfurt Motor Show (IAA) as a D2 Typ 4D prototype in polished aluminum. Pilot production began in December 1993 and develop-ment ended in early 1994, at a total cost of $700 million (£418.1 million).[5]

1.2 Introduction

The Audi A8 (Typ 4D) was presented in February 1994 and debuted at the 1994 Geneva Auto Show in March, with full-scale factory production commencing in June 1994,[2]_{although it was not until October 1996, for the} 1997model yearthat it became available in North Amer-ica. Unlike its predecessor, theAudi V8model, which was built on an existingsteel platform, the A8 debuted on the then-newVolkswagen Group D2 platform, an all aluminium monocoque, marketed as the “Audi Space Frame” (ASF), which helped to reduceweightand pre-serve structural rigidity. Thesaloon/sedan was offered in both the A8 (standard wheelbase), and the A8 L ex-tended or long-wheelbase(LWB) version. The A8 L adds 5 inches (127 mm) of rear legroom. Updates to the car in 1997 included the addition of six interiorairbags.[6][7][8]

Pre-facelift Audi A8 (D2) 4.2 quattro (Germany) 1

2 1 FIRST GENERATION (D2, TYP 4D; 1994–2002)

Facelift Audi A8 L (D2) 4.2 quattro (US)

First series production Audi withW12engine (Germany) In 1997, Audi introduced the first series production ESP Electronic stability control for all-wheel drive vehicles (Audi A8 and Audi A6). World first production car with both front and rearside airbags.

For 1997, the new A8 was available with either front-wheel drive(FWD), or theTorsen-basedquattro perma-nent four-wheel drive. The FWD models are powered by a2.8-litre V6 engine, producing 142kilowatts (193 PS; 190bhp), and a 3.7-litreV8 engineproducing 171.5 kilowatts (233 PS; 230 bhp), while the quattro received a 4.2-litre V8producing 220 kilowatts (299 PS; 295 bhp). The A8 is available with standard luxury amenities, in-cluding dual-zoneclimate control, wood and leather in-terior trim, 14-way power and heated seats, and an en-hancedBoseaudio system.

In 1999, Audi’s flagship receivedside curtain airbags, new colours, and restructuring of option packages. The North American “warm weather package” added a solarsunroof which allows the interior ventilation fans to run, keep-ing the interior cool while the car is parked with the en-gine turned off. Changes to all models included a larger passenger-side mirror, and a first aid kitlocated in the rear centre armrest.

In 1999 for the 2000model year came a minor front-end restyle, with new, larger, clearheadlights, a revised grille, and lower front valance with standard projection fog lamps. On the interior, the seats received a new, hor-izontal stitch pattern. Also, the3.7-litre V8FWD model was dropped, leaving the 2.8 V6 model and the long-wheelbase and short-long-wheelbase 4.2-litre quattro. These restyled cars also featured revised external door handles and an integrated radio antenna. For 2000, the North American A8 line-up was expanded to include the A8 L. In 2001, Audi introduced its newW12 engine, a compact 6.0-litre unit developed by effectively mating twoVR6 enginestogether at the crankshaft. The engine quickly became available in the A8, though only to European and

Asian customers. From its introduction through its dis-continuation in 2003, only 750 of the D2 “W12” models were produced. 2001 also marked the debut of the high-performance S8 variant in North American markets. In 2002, the A8 L received standardxenon high-intensity discharge lamp(HID) headlights, and a heated steering wheel. Atyre pressure monitoring system (TPMS), an updated Symphony II stereo, and new exterior colours were also added. For 2002, all A8 variants received a trunk/boot interior release lever to facilitate escape in the event an individual became trapped within.

Factory production of this generation ceased at Number 105,092[9]_{on August 4, 2002.}[2]

1.3 Coupé (prototype)

In 1997, IVM Automotive of Munich, Germany built a two-door Audi A8 Coupé. The car was unveiled at the 1997Geneva Motor Show. Audi contracted IVM to build theprototype, and was considering production of the vehicle. Thecoupéhad a re-engineered aluminium body, shorter than the production A8 saloon. Like the Mercedes-Benz CL-Class, there was no central “B” pil-lar, giving the car a seamless design with a gradually slop-ing roofline. The car included custom leather seats which could seat four. Ultimately, Audi decided not to put the A8 Coupé into production, citing lower-than-expected sales figures for the similarBMW 8 Seriesand Mercedes-Benz S-Class Coupé. Only one A8 Coupé was ever built. The single prototype, painted in a colour called “Ming Blue pearl”, remains the property of IVM Automotive, and resides in Munich. Its last public appearance was in 2002 on a series of test drives.

1.4 S8

Facelift Audi S8 (D2; US)

3

Audi introduced the S8 4.2 quattro into the European market in 1996. The S8 followed the naming conven-tion of other high-performance Audi “S” models such as the Audi A6-derived S6 and was similar in vein of Mercedes-Benz AMGmodels. In markets such as the UK, the S8 was only available with the automatic trans-mission. Cosmetically, Audi differentiated the S8 from the A8 with solid aluminium alloy door mirror housings, chrome-effect beltline and lower frontgrilletrim, and pol-ished twin exhaust pipes, along with subtle “S8” badging. 14-way power adjustable and heated sports front seats with memory function were fitted as were heated rear seats. Standardalloy wheelswere 18-inch castaluminium alloy“Avus” six-spoke style. After the 1999 facelift, 20-inch polished nine-spoke RS wheels became an option. In 2002, 18-inch nine-spoke RS wheels became a no-cost option.

At the same time of the A8’s facelift in late 1999, the S8 received the same cosmetic upgrades. This update marked the release of the S8 to the North American mar-ket. Production of the D2 series S8 ended in September 2002.

The D2 series S8 featured an uprated, 250 kW (335 hp) version of the 4.2-litre V8 with four valves per cylin-der. From late 1999, Audi increased this to five valves per cylinder with power increased to 265 kilowatts (355 hp) and 430 newton metres (317 lb·ft). From launch in 1996, European-market models came standard with a six-speed manual transmission. A sports-recalibrated version of theZF 5HP24five-speedtiptronicautomatic, featur-ing “Dynamic Shift Programme” (DSP) was released a year later and was the only transmission available in most other markets.

A retuned, 20-millimetre (0.8 in) lowered sports suspen-sion included a 30 percent stiffer spring rate and 40 per-cent more compression damping in theshock absorbers. Speed-sensitive "servotronic" power assisted steering was also standard.

ThebrakesfeaturedBosch5.3anti-lock braking system (ABS), with electronic brakeforce distribution (EBD), and worked radially ventilated frontdiscs. From 2002, an upgraded Bosch 5.7electronic stability programme be-came standard fitment.

1.5

Engines

2

Second generation (D3, Typ 4E;

2002–2009)

The second-generation Audi A8 (Typ 4E) built on the Volkswagen Group D3 platformwas unveiled via press release in July 2002 and introduced in November 2002 in Europe[2][10]_{and in June 2003 in the United States. The}

2004 Audi A8 4.2 quattro sedan (Australia; pre-facelift)

model was longer than the previous generation, with room for four or five large adult occupants in the cabin, depend-ing on rear seat configuration. The D3 development pro-gram began in 1996, with the design process commenc-ing in Ingolstadt in 1997. The whole Audi design stu-dio based in Ingolstadt first contributed sketch propos-als, from which numerous different themes emerged. Six of them were developed into full size clay models and worked up in a traditional manner adjacent to full size tape drawings. At least three one quarter scale models were produced to explore other design variations. The six full size exterior clay models were reduced to two in late 1998 and these continued to be refined in parallel for a year. At the end of 1999 the final theme selection was made, byMiklós Kovácsand Imre Hasanic the main contributing designers. This lengthy development time was in part due to the body being made from aluminium, a material less able to take the small radii of sharp feature lines such as those on the (steel bodied) A4 (B6) designed in 1998.

In parallel to the exterior design development the inte-rior design was progressed with a total of four full size models produced and the production car’s horizontally themed instrument panel design dominant from early on, with Norbert Schneider, Mark Bergold and Enzo Roth-fuss the main contributing designers.

Grouping major controls nearer the driver for a more driver focused identity whilst creating a more airy and spacious feel were early priorities for the interior design team was headed by Jurgen Albamonte. This was in part facilitated by theMulti Media Interface(MMI) designed by Jurgen Schröder, that pioneered on the D3 A8 after theAudi Avantissimoconcept car preview, and also by class leading colour and trim from Barbara Krömeke and Melinda Jenkins.

Under the supervision of Dany Garand, during the first half of 2000 exterior and interior clay models were dig-itized and developed using digital design tools in a sup-porting, not leading, capacity. The D3 final production design was later frozen in the summer of 2000 for an Au-gust 2002 start of production.[11]

4 2 SECOND GENERATION (D3, TYP 4E; 2002–2009)

The A8 was previewed 2001Frankfurt Motor Showby theAudi Avantissimoconcept car. This concept intro-duced much of the technology later available on the se-ries production A8 D3, including: Multi Media Inter-face, 6-speed automatic transmission with shift paddles, V8 biturboengine (S8), self-levelling adaptive air sus-pension withcontinuously controlled damping, electric park brake, bi-xenon headlights with static Adaptive Front Lighting System (AFS) curve headlights, dash-board, driver identification systems withfingerprint scan-ner.

As with the previous version, two body variants of the second generation A8 are offered, the A8 (standard, or short wheelbase), and the long-wheelbase(LWB) A8 L. The A8 L adds 120 mm (4.7 inches) to the rear legroom and 11 mm (0.43 in) to the overall height of the car.

2.1

Innovations

• World premiere ofMulti Media Interface(MMI) in-caruser interface(similar to BMWiDrive) • Multiplexedhigh speedMOST Bus optical fiberdata

networks (interconnecting tens ofmicroprocessors on commondatabusses), integrated with MMI. • First Audi withBi-Xenon HID headlampsfor both

low and high beam

• World premiere of staticAdaptive Front Lighting System (AFS)curve headlights (fromHella)[12] • First Audi with 4-wheel Adaptive Air Suspension

andContinuous Damping Control(CDC)-(Skyhook suspension).

• First Audi GPSnavigation systemwithDVDmaps • First Audi with six-speed automatic transmission

(Tiptronic)

• First Audi featuringdriver identification system. In 2005, newinternal combustion enginesbecame avail-able. For European and Asian market customers, the entry-level 3.0-litreV6 enginewas replaced with a new 3.2-litre unit featuring Fuel Stratified Injection (FSI), which it shared with theAudi B7 A4andAudi C6 A6. The top-of-the-line W12 version debuted that year. The advantage of theW12 enginelayout is its compact pack-aging, allowing Audi to build a 12-cylinder sedan with all-wheel drive, whereas a conventional V12 could only have a rear-wheel drive configuration as it would have no space in the engine bay for a differential and other components required to power the front wheels. In fact, Audi’s 6.0-litre W12 is actually slightly smaller by overall dimensions than the 4.2-litre V8.[13]

In addition to the added power trains, Audi restyled the D3 platform A8 range slightly in 2005, giving all variants

Audi A8 L 3.0 TDI (facelift)

a taller, widertrapezoidalsingle-frame grille. The top-of-the-lineW12 enginedW12 version was the first model to be equipped with this grille;V8 enginedmodels were fitted with the new grille the following year.[13]

The D3 generation A8 introduced the 235 kW (315 hp) 4.2-litreTurbocharged Direct Injection(TDI)V8 engine (subsequently uprated to 240 kW (322 hp)). The engine uses two turbochargersand twointercoolers, with each turbocharger functioning exclusively for one bank of four cylinders.

The adaptive air suspension gives the vehicle clearance a range from its normal 120 mm up to 145 mm in lift mode and down to 95 mm in the Autobahn mode, which is automatically activated when a speed of more than 120 km/h is maintained for more than 30 seconds.[14] In September 2005 Audi became the first car maker to offer the 1,000-watt 14-channelICEpowersound system option fromBang & Olufsen.[15][16]

The unique, motorized Bang & Olufsen tweeter in a 2008 Audi A8

2.2 2007 Facelift

• Full speed rangeadaptive cruise controlACC Plus, can now brake until stop

2.4 S8 5.2 FSI quattro 5

• Braking guard radar-guidedforward collision warn-ingsystem

• Side Assist" detects cars in the A8’s blind spots • Lane assisthelps when the driver attempts to change

lanes without signalling first.

2.3

A8 L W12 quattro Security

Armored A8 (Czech president)

It is an armoured vehicle with B6+ and B7 (European standard) ballistic ratings. It includes a W12 engine rated 331 kW (450 PS) and 580 N·m (428 lbf·ft), emergency exit system featuring pyrotechnic blown-out doors, fire extinguisher system with spray jets located in the engine compartment, underbody and in the wheel arches; smoke extractor in passenger compartment, run flat tires, bul-let proof windows, the full protection plus package and LED flashers in the exterior mirrors. Buyers are also of-fered facility to dispatch two drivers on a special training course.[18]

2.4

S8 5.2 FSI quattro

The S8 high-performance sports variant, now called the “Audi S8 5.2 FSI quattro” was announced in the last quar-ter of 2005 and full production started in June 2006 and ended in September 2009.[19]

The S8 includes subtle detailing to distinguish it from its related A8. Thetrapezoidal“single-frame”grille bears the characteristic Audi “S model” vertical strut detail which are highlighted in a chrome finish. “S8” badging is displayed front and rear, whilst “V10” badges are dis-played on each front wing above the side-repeater indica-tors. The rear boot-lid incorporates a subtle rear spoiler, and the rear is finished with four chromed oval exhaust tailpipes. AdaptiveXenon-plushigh-intensity discharge (HID) headlamps include static turning lights, along with “swiveling” dynamic cornering lights. Daytime running lampsare fivelight-emitting diodes(LEDs) incorporated

into acloverleafdesigned reflector, incorporated into the mainheadlamphousing.

Pre-facelift Audi S8 (D3; US)

Pre-facelift Audi S8 (D3; Europe)

The D3 series S8 features a 5.2-litre all-aluminium al-loyfour-valves per cylinderV10petrol engine. This en-gineis a derivative of theLamborghini Gallardo's original 5.0-litreLamborghini V10,[20]_{which was also developed} under the Volkswagen Group ownership. On this Audi-only variant, compared to the Lamborghini engine, it fea-tures a longerstrokeand widerbore—which increases the displacementof the engine, and produces more torque at lower revs, making it more suitable for the larger and heavier full-sized luxury Audi application. It produces 331 kW (444 hp) of power and 540 N·m (398 lb·ft) of torque. By having its bore whittled out an additional 2 millimetres (0.1 in), displacement in the S8 application increases from 5.0- to 5.2-litres. The engine also features Audi’s direct-injection system, calledFuel Stratified In-jection(FSI).[21]

Facelift Audi S8 (D3; US)

6 3 THIRD GENERATION (D4, TYP 4H; 2009–PRESENT)

Facelift interior

A sports-optimisedZF 6HP26-A61 six-speed tiptronic automatic transmission with “Dynamic Shift Pro-gramme” (DSP) and “sport” mode, with steering wheel mounted paddle-shifters, is the only offering. Output is transmitted via Audi’s quattro all-wheel drive system, initially using the Torsen T-2 50:50 dynamic centre differential, and from 2007 for the 2008 model year, utilising the Torsen T-3 asymmetric dynamic centre differential, with a “default” torque distribution of 40 percent to the frontaxleand 60 percent to the rear. The S8’s top speed is electronically limited to 250 km/h (155 mph). Audi’s factory performance claims indicate a 0 to 100 km/h (0 to 62 mph) time of 5.1 seconds whilst consuming 98RONunleaded petrol. The S8 has similar performance to Audi’s own top-of-the-line A8 L W12, though the W12 is more expensive, has more torque, and built on a longer wheelbase.[21]_{Compared to} the A8 L W12, the S8 has sportier mechanical features such as a firmer suspension, larger wheels, and ceramic brakes. The shorter wheelbase and 10-cylinder engine save weight for better handling, but at 5.4 seconds from 0–60 mph the S8 trails the W12.[22][23][24]

The S8, like its related A8, utilises a multi-linksuspension layout front and rear, with pressurised air springs. How-ever, for the S8, the effective spring and damper rates are noticeably firmer, along with re-engineered suspen-sion mounts.

The brake system consists of radially ventilateddiscsall round. The discs are clamped with gloss-black painted dual-piston calipers up front, and a single-piston sliding caliper at the rear, coupled to an electro-mechanical park-ing brake. ABoschESP 5.7 (later upgraded to ESP 8.0) electronic stability control, with ABS, brake assist, EBD complete the brake system. Optional “Audi ceramic” carbon fibre-reinforced silicon carbide(C/SiC) compos-ite front and rear brakes are available, which use radially vented, and floatingSGL Carbondiscs, with anthracite grey painted twelve-piston fixedBrembomonobloc alloy calipers. Standardalloy wheelsconsist of 20-inch “S de-sign” alloy wheels.

2.5 A8L

Centennial

Limited

Edition

(2009–)

The A8L Centennial Limited Edition ( A8L ) is a limited (800 units total) version of the A8L 3.0 FSI with multitronic and the A8L 6.0 W12 quattro for the Chinese market, commemorating Audi’s 100th anniver-sary. It included horizontal chrome-plated front grille (from the A8L 6.0 W12 quattro), “V6” metal logo at the upper left of the air-inlet grille (A8L 3.0 FSI), LED day-time running lights, heated leather steering wheel, 19-inch 12-spoke polished aluminium alloy wheels, heated steering wheel in grey leather with beige stitching, Bang & Olufsen advanced audio system, Alcantara equipment bag, Assam ash red veneer, floor mat with aluminium trim, a metal 'Audi exclusive' commemorative logo at inn door trims.

The vehicles went on sale on the 18 October 2009 as 2010 model year vehicles.[25][26][27]

2.6 Engine variants

InNorth America, only the 4.2 V8, 5.2 V10, and 6.0 W12 petrol engines are available. The 4.0 TDI was discontin-ued when the 4.2 TDI was introduced.

3 Third generation (D4, Typ 4H;

2009–present)

3.1 Initial release

Interior

Changes include:[30]

• Full LED headlamps with Automatic high beam switching or Audi adaptive light (Xenon) with variable headlight range control

• enhanced MMI Multi Media Interface with touchpad&handwriting recognitionfor the phone

3.1 Initial release 7

GPS navigation display with 3D computer graphics and

Google Earth, enhanced MMI Multi Media Interface with

touchpad&handwriting recognitionvisible below climate control

Multi Media Interface menu, music section, display integrated in front right side seat, view from rear seat

Infrared Night Vision Assistant

and navigation system, usingNvidia Tegra System on a chipfor very high processing speed.

• optional 1,400 wattBang & Olufsensound system. • driver assistance systemsnetworked usingFlexRay

technology.[31]

• Hard disk driveGPS navigation with3D computer graphicswithGoogle Earth.,[32]

• navigation system coordinates input to the adaptive headlights, transmission,adaptive cruise controland

electronic stability control.[30]

• Infrared Night Vision Assistant with pedestrian recognition[30]

• broadband internet with UMTS 3G and WLAN-Hotspot

• First production Audi with a Collision avoidance system: Pre sense[30] _{(similar to Mercedes-Benz}

Pre-Safe). The full version of the system (Pre Sense Plus) works in four phases. In the first phase, the system provides warning of an impending accident, while the hazard warning lights are activated, the side windows and sunroof are closed and the front seat belts are tensioned. In the second phase, the warning is followed by light braking, strong enough to win the driver’s attention. The third phase initi-ates autonomous partial braking at a rate of 3 m/s² (9.8 ft/s²). The fourth phase decelerates the car at 5 m/s² (16.4 ft/s²) followed by automatic deceler-ation at full braking power, roughly half a second before projected impact. A second system, called (Pre Sense Rear), is designed to reduce the con-sequences of rear-end collisions. The sunroof and windows are closed and seat belts are prepared for impact. The optional memory seats are moved for-ward to protect the car’s occupants. The system uses sensor fusionwith twinradarand a mono camera[33] and was introduced in 2010.

3.1.2 A8 (L) (2010–)

The third-generation Audi A8 (L) (Typ 4H) is based on the Volkswagen Group MLB platform, but retains the Audi Space Frame aluminium construction of the pre-vious A8, making it the lightest all-wheel drive car in the full-size luxury segment, while also giving it best-in-class fuel economy.[34][35]_{The quattro all-wheel drive system} splits torque with a default bias of 40 percent front and 60 percent rear.

The vehicle was unveiled in Design Miami 2009 on 30 November 2009.,[36][37]_{followed by the 2010 North} American International Auto Show.[38]

Early models include A84.2 FSIquattro (372PS), A8 3.0 TDI quattro (250PS), A8 4.2 TDI quattro (350PS).[39] A8 3.0 TDI (204PS) was added later.[40]

Initial internal combustion engine options comprise 4.2-litre Fuel Stratified Injection (FSI) petrol and Turbocharged Direct Injection (TDI) diesel V8s, with 273 kW (366 hp) and 258 kW (346 hp) respectively. A 3.0-litre V6 TDI with either 184 kilowatts (247 hp) or 150 kilowatts (201 hp) will be available later. A 6.3-litre W12 engineonly for the long wheelbase model was made available in 2010, and compared to its predecessor it has a larger displacement and direct fuel injection.[41]_All en-gines are mated to the new eight-speedZF 8HPautomatic

8 3 THIRD GENERATION (D4, TYP 4H; 2009–PRESENT)

transmission. Although other Audi vehicles such as the 2010Audi S4and 2011Audi A7had switched from the 4.2l V8 to the 3.0L supercharged V6, the Audi A8 re-tained a higher-output 4.2L V8 as the base engine for the 2011 and 2012 model years in North America.

Taiwan models went on sale on the 11th November 2010 . Early models include 3.0 TFSI quattro (290PS).[42] 3.1.3 A8 L (2010–present)

The vehicle was unveiled in Auto China 2010.,[43][44] followed by the 2011 Taipei Motor Show (A8 L W12 quattro).[45]

German models went on sale in the fall of 2010. Early models include a 3.0 TFSI quattro (290PS), a 4.2 FSI quattro (372PS), a W12 6.3 FSI quattro (500PS), a 3.0 TDI quattro (250PS) and a 4.2 TDI quattro (350PS).[46] Taiwan models went on sale on the 11th November 2010. Early models include a 3.0 TFSI quattro (290PS) and a 4.2 FSI quattro (372PS).[42]_{The A8L W12 quattro was} added in 2011.[47]_{the A8L 4.0 TFSI quattro was added} in 2012.[48]

Chinese models went on sale in 2011. Early models in-clude an A8L 3.0 TFSI low quattro (289PS), and an A8L 3.0 TFSI high quattro (333PS).[49]

3.1.4 A8 hybrid concept (2010)

The concept vehicle includes a 2.0 TFSI engine rated at 211 PS (155 kW; 208 bhp) and 350 N·m (258.15 lbf·ft)@1500–4200 rpm, a disc-shaped electric motor rated 45 PS (33 kW; 44 bhp) and 211 N·m (155.63 lbf·ft), lithium-ion battery, luggage space of 400 liters (14.13 cu-bic feet), 21-inch wheels with 265/35 tires, Prism Silver body colour with Spectra Flair accent colour, 'hybrid' let-tering on both front fenders, illuminated doorsteps with 'hybrid' insignia.[50][51]

The vehicle was unveiled in 2010 at The Geneva Motor Show.[52]

3.1.5 A8 L long-term evolution broadband proto-type (2011)

It is a version of the A8 L demonstrating 4G long-term evolution (LTE) broadband technology. Devel-oped in collaboration with Alcatel-Lucent, the car’s mobile broadband connection is a fourth generation (‘4G’) technology with data transfer speeds of up to 100Mbit/s.[53][54]

During the 2011Consumer Electronics Showin Las Ve-gas, Rupert Stadler, Chairman of the Board of Man-agement of AUDI AG, announced that LTE technology would be used in cars by early 2011. The A8 L prototype was unveiled weeks later.[55]

3.1.6 A8 L Security (2011–present)

The A8 L Security is an armoured version of the A8 L with class VR 7 ballistic protection standard (tested as per BRV 2009 guidelines), resistance to explosions against a military hand grenade (tested as per ERV 2010 guidelines), with certain areas of the armouring complies with the criteria for class VR 9 and VR 10, a core safety cell made from hot-formed armoured steel, aramide fab-ric, ceramics, special alloyed aluminium and multilayer glass; overlapping protective materials at the joints, alu-minum side sills with solid steel sections, alualu-minum alloy armored floor, side windows, windshield and rear win-dow made of special glass with a polycarbonate coating; optional electromechanical window openers, closing as-sist feature comes standard for the doors, communica-tion box in the luggage compartment (light ceramic doors, aluminum frame), optional battery and the fuel tank pro-tection, two-way communication system with a speaker in the single-frame grille and microphones for the cabin and exterior, an emergency exit system with pyrotechni-cal separating screws in the hinges, fire extinguisher sys-tem, emergency fresh-air system with two oxygen car-tridges, a smoke extractor for the passenger compart-ment, an LED signaling system for convoy travel, flash-ing lights, a siren, a preparation for professional mobile radio systems, a flag holder, a permanently installed tele-phone, an accident data recorder, an additional rearview camera and a heated windshield plus partially heated side windows, four-zone climate control system with an ion-izer to freshen the air, electric rear blinds, the sonorous Bose surround sound system and a TV tuner, rear are two individual seats with power adjustment, front comfort seats with heating and optional massage and ventilation functions, standard full-leather package, optional relax-ation seat (adjustable right-hand rear seat with a power-adjustable footrest, heating and massage), optional center console with large storage compartments and rear seat entertainment system with two 10.2-inch displays, op-tional folding table, opop-tional refrigerator opop-tional park-ing heater, Bluetooth car phone online, integrated UMTS module, optional separate telephone handsets, 19-inch forged wheels featuring in semipolished two-tone finish, 255/720 tires with a high load index of 117, synthetic rings on the rims, optional full-size spare tire.[56] The first model included a W12 engine rated 368 kW (500 PS) and 625 N·m (461 lbf·ft), with delivery began in late summer 2011. An additional engine model with improved fuel efficiency went on sale in 2012.[57][58][59] The vehicle was unveiled at the 2011 Geneva Motor Show.[60]

3.2 2013 model year update 9

3.1.7 A8 hybrid (2012–present)

2011 Audi A8 Hybrid D4

2011 Audi A8 L W12 quattro tiptronic in phantomblack

Audi S8 D4

The production version includes an electric motor rated at 40 kW (54 PS) and 210 N·m (155 lbf·ft), 1.25kWh lithium-ion battery, 18-inch 10-spoke alloy wheels in turbine blades design (optional 19-inch), hybrid badges, metallic paint finish (optional Arctic Silver body colour), three-zone automatic air conditioning, LED headlights, and a BOSE sound system. Pure electric mode is avail-able for either a top speed of 100 km/h (62 mph) or for up to 3 kilometres (2 mi) at a constant speed of 60 km/h (37 mph). It went on sale in 2012.[62][63][64]

The vehicle was unveiled at the 2011 Frankfurt Motor Show.[65][66]

3.1.8 A8 L W12 Audi exclusive concept

It is a limited (50 units) version of the A8 L W12 with seats upholstered in Cognac-colored leather byPoltrona Frau, inlays made from the wood olive ash natural, light gray-brown veneer, sill trims with “Audi exclusive con-cept” lettering, deep-pile carpeting.

The vehicle was unveiled at the 2011 Frankfurt Motor Show.[67]

3.1.9 A8 L hybrid

The long wheelbase version of the A8 hybrid was unveiled in 2010 at the Beijing Auto Show.[68]

3.1.10 S8 4.0 TFSI quattro (2012–)

The D4 series Audi S8 4.0 TFSI quattro went on sale in 2012. Like the previous iteration, the S8 costs less than the A8 L W12.[69][70]

The S8 can accelerate from 0 to 100 km/h (0 to 62 mph) in 4.2 seconds. It is powered by a4.0-litre TFSI biturbo V8 engine with 382 kW (512 hp). The engine utilises cylinder deactivation so it can run as a V4 for better fuel economy.[69]_{The S8’s engine is shared with theBentley}

Continental GT, while a detuned variant of the engine makes 420 hp which is found in the 2013Audi S6,Audi S7, and Audi A8. Direct competitors include the BMW Alpina B7 and Mercedes-Benz S63 AMG, which also have biturbo V8 engines.[71][72]

The vehicle was unveiled at the 2011 Frankfurt Auto Show, and went on sale in spring 2012.[73]

Taiwan models went on sale in 2013.[74] 3.1.11 Engines

3.1.12 Marketing

As part of the Audi A8 launch in Taiwan, Audi built up Audi pavilion in XYi district, with Tom Dixon in-vited for the launch event. Yu-Cheng Chou and Chun-Ten Lin’s art works were displayed with A8.[76]

The Audi A8 3.0 TFSI quattro (290PS) was used in Transporter: The Series.[77]

3.2 2013 model year update

Early German A8 models include 3.0 TFSI quattro (290PS), 4.0 TFSI quattro (420PS), 3.0 TDI (204PS), 3.0 TDI quattro (250PS), 3.0 TDI clean diesel quattro (250PS), 4.2 TDI quattro (350PS), A8 L W12 quattro (500PS), A8 hybrid 2.0 TFSI. Early German A8 L Se-curity models include 4.0 TFSI quattro, W12 6.3 FSI quattro.[78]

The updated A8 uses LED headlight technology, with automatic high beam lighting,Osramsupplies the LEDs whileHellasupplies the headlamp itself.[79]

Early US models include the A8(L) 3.0 TFSI quattro (333PS), the A8(L) 4.0 TFSI quattro, the S8 4.0 TFSI quattro and the A8 L W12 6.3 FSI quattro. The A8 3.0 TFSI quattro and A8 4.0 TFSI quattro replaced the A8 4.2 FSI quattro.[80] _{The A8 3.0 TDI clean diesel quattro} (240PS) was unveiled at the 2012 L.A. Auto Show, and was set to go on sale in Spring 2013 as a 2014 model

10 3 THIRD GENERATION (D4, TYP 4H; 2009–PRESENT)

year vehicle.[81] _{The A8 L 3.0 TDI clean diesel quattro} (240PS) was set to go on sale in Spring 2013 on sale as a 2014 model year vehicle.[82]

Chinese models include the A8L 30 FSI (204PS), the A8L 40 hybrid, the A8L 45 TFSI quattro (290PS), the A8L 55 TFSI quattro (333PS), the A8L W12 FSI quat-tro and the S8 4.0 TFSI quatquat-tro.[83][84][85]

3.2.1 Engines

The A8 L 2.0 TFSI hybrid is sold as an A8L 40 hybrid in China.

The A8 L 3.0 TFSI quattro (290PS) is sold as an A8L 45 TFSI quattro in China.

3.2.2 Transmission

All models include an 8-speed tiptronic transmission.

3.2.3 Production

2013–2014 Audi A8 and S8 vehicles equipped with a standard sunroof, manufactured between March 12, 2013 and July 15, 2013 were recalled due to possible shattering of sunroof glass panel.[86]

3.2.4 Marketing

As part of the 2013 S8 4.0 TFSI quattro launch in the US, a TV commercial called 'Suspect' was produced in association with Venables Bell & Partners, USA, Furlined, The Whitehouse, 740 Sound Design & Mix, Lime Studios;[87] _{starring Abigail Spencer.}[88] _{The ad} takes cues from quintessential heist films with the S8 taking center stage against a mysterious and suspenseful bank robbery scene. As the thrill escalates, viewers will be left deciding whether a true robbery has transpired, or if the scene was purely a figment of the driver’s imagina-tion. With the power, speed and innovation of the S8 at the driver’s fingertips, it’s easy to get carried away behind the wheel of an Audi S model. The spot closes with the tagline “Heighten Every Moment.” The commercial was premiered during the 2012 NFL season kick-off game on 05-09-2012. The “Suspect” commercial featuring the Audi S8 would also air in NFL on CBS and NBC, and se-lect cable networks, including: Food, FX, National Geo-graphic, ESPN, USA, CNN, and AMC. A 30-second ver-sion would also be viewable on CNN.com, Reuters.com, Wired.com, Yahoo! and more.[89][90]

Audi A8 Facelift

Audi A8 Facelift Rear View

State of the artMatrix LED, digitally controlled adaptive non-glare multi-LED headlamp technology.

3.3 2014 model year facelift

3.3.1 A8, S8, A8 Audi exclusive concept, A8 hybrid (2013–)

Changes include:[91]

• Multi Media Interfacewith fasterTegra 3-Processor andLong Term Evolutionbroadband Internet. • First worldwide series production car with digitally

controlled, full-LED glare-free adaptivehighbeam: Matrix LED.[92] _{The high-beam comprises 25}

in-3.3 2014 model year facelift 11

dividual light-emitting diodes per unit that can be switched on and off or dimmed individually depend-ing on the situation. This enables the headlight sys-tem to react extremely precisely to other vehicles while always brightly illuminating the road. Ad-ditional features of the new headlights are the in-telligent cornering light, new-look daytime running lights and dynamic turn signals. The lighting system in the A8 uses predictive route data from the nav-igation system to adjust the distribution of light in response to the current driving situation. In combi-nation with the optional Navigation plus with MMI touch, the system recognizes route data contained in the navigation system, such as curves and road clas-sifications.

• Cornering light. Using predictive route data sup-plied by the MMI navigation plus, the focus of the Matrix LED beam is shifted towards the bend even before the driver turns the steering wheel.[93] • Night Vision Assistant can now recognize larger

animals in addition to pedestrians. Pedestrian Marker Lights work together with the optional night vision assistant. As soon as apedestrianis de-tected in a critical range in front of the vehicle, in-dividual LEDs flash briefly three times in succession to alert that person, who is then clearly visible to the driver[93]

• Head-up display

• Standard electromechanical power steering (op-tional dynamic steering varies its ratio with the car’s speed)

• Active lane assist, which makes slight steering ad-justments when necessary

• Park assistsystem with 360° display,

• Side assist Blind spot monitor coupled with ex-panded version of the standard pre sense basic safety system

• Active noise cancellation (ANC) for A8 L W12 quattro, cylinder on demand with six-cylinder mode. • Additionalnoise damping

• Other changes: altered trunk layout with optional power trunk closing assist, flatter rear LED lights joined together by a continuous chrome strip, re-designed bumper houses two rhomboid tailpipes (except S8), available wheel sizes up to 21 inches with 275/35-series tires, optional sport differential (standard on S8 and A8 4.2 TDI clean diesel quat-tro)

The A8 Audi Exclusive Concept is a limited (50 units) version of the A8 L W12 quattro with interior leather upholstery from Italian furniture manufacturer Poltrona

Frau in the color Agatha cognac, inlays are made of fine grain olive ash natural silver brown, Tierra Del Fuego body colour. Production was set to begin at the quattro GmbH facility in Neckarsulm starting in March 2014.[94] The Audi S8 includes a four-cylinder mode with ANC, two elliptical dual tailpipes, dynamic steering, sport differential, adaptive air suspension sport with an S-specific setup, 20-inch wheels, S8 emblems on front brake calipers, optional Audi design selection black/Vermont brown with Carbon twill copper inlays.

The Audi A8 hybrid includes a custom Audi luggage set for the trunk.

The vehicles were unveiled at the 2013 Frankfurt Mo-tor Show, followed by 2014 Detroit Auto Show,[95]₂₀₁₄ Toronto Auto Show.[96]

German models arrived at German Audi dealerships in November 2013. Early A8 models include 3.0 TFSI tro (310PS), 4.0 TFSI quattro (435PS), 3.0 TDI quat-tro clean diesel (258PS), 4.2 TDI clean diesel quatquat-tro (385PS), A8 L W12 quattro (500PS), A8 hybrid 2.0 TFSI (211/245PS), S8 4.0 TFSI quattro (520PS).[97][98] US models went on sale as 2015 model year vehicles. Early models included A8 3.0 (L) TFSI quattro (310PS), A8 (L) 4.0 TFSI quattro (435PS), A8 L 3.0 TDI quat-tro clean diesel (258PS), A8 L W12 quatquat-tro (500PS), S8 4.0 TFSI quattro (520PS).[99] _{Engines are the same in} Canada as the US but PS ratings are higher due to less emission control devices needed.

3.3.2 A8 L Security (2014–)

Available in V8 4.0 TFSI or W12 FSI engines, it is an armoured version of A8 L with VR 7 ballistic protec-tion standard in accordance with the BRV 2009 guide-line, with VR 9 and VR 10 in certain areas, and ex-plosives resistance tested in accordance with the ERV 2010 guideline (Explosion Resistant Vehicles). The oc-cupant cell is made of heat-formed armor steel, aramide fabric, ceramic, a special aluminum alloy, and multi-laminated glass, with protective materials overlap at tran-sitions. The aluminum side sills incorporate ballistic-proof profiles. The armor-plated vehicle floor made from a special aluminum alloy for explosive weapons resis-tance. Door windows, windshield and rear window in-corporate special glass with a splinter-inhibiting polycar-bonate layer on the inside, with doorstop function and op-tional electromechanical side windows. Other opop-tional security equipment include emergency exit system with pyrotechnic fracture bolts in the hinges detach the door from the body, fire extinguisher system with two tanks and nozzles spray to wheel arches, onto the underbody and tank, and into the engine compartment; emergency fresh-air system with two pressurized cartridges housed in the protected zone, security start with remote radio sig-nal engine start, selective unlocking of doors, a smoke

ex-12 5 REFERENCES

tractor for the interior, an LED signal system for convoy driving, pennant holder, flashing lights, a siren, a prepa-ration for or installation of analog and digital radio net-works for security authorities and organizations, a built-in phone, an accident data recorder, an additional rear camera, a heated windshield including partly heated side windows. Other features included LED (V8 4.0 TFSI) or Matrix LED (W12 FSI) headlights, quattro permanent all-wheel drive, armor-plated (ceramic doors, aluminum frame) communications box in the trunk with a supple-mentary battery, optional battery and fuel tank protec-tion, intercom system with a loudspeaker in the Single-frame grille and microphones for the interior and the ve-hicle’s surroundings, two electrically adjustable individ-ual seats in the rear, front comfort seats with optional with massage and ventilation functions (optional front-passenger relaxation seat with electric-control footrest, ventilation and massage function), optional continuous center console with large storage compartments is also available, Rear Seat Entertainment with two 10.2-inch displays, optional folding table, a cool box and auxiliary heating; new Unicum leather interior upholstery, forged 19-inch wheels, 255/70 tires with high load index 117, polymer rings on the rims, direct-measurement tire pres-sure monitoring system, optional spare wheel, 4-zone au-tomatic air conditioning with an ionizer, electric rear blinds, Bose surround sound system, a TV tuner, park-ing system plus with surround view camera.

Delivery was set to begin in the third quarter of 2014.[100][101]

3.3.3 Engines 3.3.4 Transmission

All models include an 8-speed tiptronic transmission. 3.3.5 Production

The A8’s aluminum chassis was built at Neckarsulm plant.

4

Production

5

References

[1] Lawrence Ulrich (12 November 2010).“Speaking of Un-derstatements”. The New York Times.

[2] ETKAofficial factory data

[3] Mateja, Jim (1993-12-29). “Audi Puts Aluminum-car Plans In Gear”. Chicago Tribune.

[4] http://i184.photobucket.com/albums/x136/ GTO-Carsouce/audi.jpg

[5] Aluminium. Retrieved 14 July 2015.

[6] “Renaissance of the rings”. Retrieved 14 July 2015. [7] http://audi-q7.bootnetworks.com/

[8] “Audi A8 :: Top Cars ::". Retrieved 14 July 2015. [9] “Audi A8 Number 105,092 Initiates Change of

Genera-tion - AudiWorld”. AudiWorld. Retrieved 14 July 2015. [10] “Audi A8 Design”. Audi-Motors.net. 2006. Retrieved 4

March 2010.

[11] Livingstone, Sam.“The Audi A8 Design Story”. Car De-sign News. Retrieved 23 November 2012.

[12] http://www.kfztech.de/kfztechnik/elo/licht/

Lichttechnik_modern.htm Moderne Lichttechnik -Kurvenlicht - statisch und dynamisch (AFS)

[13] “2005 Audi A8 Review, Prices, Photos”. New Car Test

Drive. Retrieved 2010-10-03.

[14] “adaptive air suspension”. Audi A8 Betriebsanleitung

[Audi A8 Operating Instructions] (in German).Audi AG. 2008. p. 151.

[15] Preisliste A8 S8 A8 W12 (633/1512.80.00) (in German). Audi AG. October 2006. p. 16.

[16] Krøyer, Kent (13 March 2005). “Audi med indbygget koncertsal fra B&O” [Audi with built in concert hall from B&O](in Danish). Mediehuset Ingeniøren A/S. Re-trieved 6 November 2014.

[17] Homes, Jake (August 2007). “2008 Audi A8 – Auto Shows”.Car and Driver. Retrieved 20 January 2010. [18] Chris Shunk RSS feed (2007-03-05).“A $685k Audi A8

that will blow its own doors off”. Autoblog.com. Re-trieved 2012-04-08.

[19] “Audi A8 W12 and Audi S8 cancelled for 2010 | Cars UK | UK Car News”. Cars UK. 2009-04-25. Archived from

the originalon 19 September 2010. Retrieved 2010-10-03.

[20] “Review on CNet”. Reviews.cnet.com. 2009-02-06. Re-trieved 2010-10-20.

[21] “2007 Audi S8 – First Drive Review – Auto Reviews”. Car and Driver. Retrieved 2011-04-02.

[22] Clark, Michael (July 9, 2009). “Inside Story: 2009 Audi S8”. Canadian Driver. Archived fromthe originalon Au-gust 13, 2009. Retrieved November 12, 2009.

[23] “Sports Sedans Supreme: 2007 Maserati Quattroporte Executive GT vs 2007 Audi S8 vs 2007 Mercedes-Benz S63 – Latest News, Features, and Road Tests – Automo-bile Magazine”. Automobilemag.com. 2010-12-13. Re-trieved 2011-04-02.

[24] “2009 Audi A8 4.2 V8, A8L, W12, S8 V10 – Used Car Review / Specs / Handling / Performance Parts”. Jb-carpages.com. 2007-03-03. Retrieved 2011-04-02. [25] “Audi A8L Centennial Limited Edition”. Retrieved 14

13

[26] " A8L 105.8-254 ". Retrieved 14 July 2015.

[27] “AutoNet :AUDI A8L !".

Re-trieved 14 July 2015.

[28] Automobile Revue 2007. Bern: Espace Media Groupe. 2007. pp. 113–114.ISBN 978-3-905386-07-3. [29] “Audi Considering 8-Speed Transmissions for Majority of

Its Lineup”. Archivedfrom the original on 17 February 2010. Retrieved 17 February 2010.

[30] https://www.audi-mediaservices.com/publish/ms/ content/en/public/pressemitteilungen/2010/02/01/the_ new_audi_a8__.htmlThe new Audi A8 – The sportiest sedan in the luxury class

[31] “2011 Audi A8 4.2 FSI First Drive”. Archivedfrom the original on 11 February 2010. Retrieved 16 February 2010.

[32] White, Joseph B. (20 January 2010). “Virtual Dash-boards: The Next Must-Have?".The Wall Street Journal. p. B11.

[33] “Extensive safety in the new Audi A8. Bosch predictive emergency braking system goes into series production”. Retrieved 2 June 2010.

[34] Peterson, Thane (2010-10-05).“Review: 2011 Audi A8”.

BusinessWeek. Retrieved 2011-02-02.

[35] “Winding Road - Comparison Test: 2012 BMW 750Li xDrive vs. 2012 Audi A8L 4.2”. Retrieved 14 July 2015. [36] “Audi Media Site : Home : Home”. Audiusanews.com. 2009-11-27. Archivedfrom the original on 25 October 2010. Retrieved 2010-10-03.

[37] “World premiere of new Audi A8 in Miami”. Audi AG. 2009-11-27.

[38] “AutoNet :2010 :2011 , AUDI

A8 ". Retrieved 14 July 2015.

[39] “The new Audi A8 – The sportiest sedan in the luxury class”. Audi MediaCenter. Retrieved 14 July 2015. [40] “The new Audi A8 – The sportiest sedan in the luxury

class”. Audi MediaCenter. Retrieved 14 July 2015. [41] “Audi A8 first drive”. Retrieved 9 June 2010.

[42] “AutoNet : ,AUDI A8 412 ".

Retrieved 14 July 2015.

[43] “AutoNet :2010 : AUDI A8

L , ". Retrieved 14 July 2015.

[44] “AutoNet :2010 :AUDI

A8L , !". Retrieved 14 July

2015.

[45] “AutoNet :2012 AUDI : ,A8L

W12 ". Retrieved 14 July 2015.

[46] “The new high-tech flagship of the brand – The Audi A8 L”. Audi MediaCenter. Retrieved 14 July 2015.

[47] “AutoNet : ,AUDIA8L W12

quat-tro ". Retrieved 14 July 2015.

[48] “AutoNet : ,AUDI A8L V8 4.0 TFSI

quattro 599 ". Retrieved 14 July 2015.

[49] “AutoNet : !AUDI A8L !".

Retrieved 14 July 2015.

[50] Jonathon Ramsey RSS feed.“Geneva 2010: Audi A8 Hy-brid a concept in name only”. Autoblog.com. Retrieved 2012-04-08.

[51] “The efficiency standard – the Audi A8 hybrid”. Audi

Me-diaCenter. Retrieved 14 July 2015.

[52] “AutoNet :2010 :A8 Hybrid A1

e-tron ,AUDI ". Retrieved 14 July 2015. [53] “Audi A8 L Prototype gets state-of-the-art broadband

connection”. Audi.co.uk. 2011-03-21. Retrieved 2012-04-15.

[54] “Audi A8 prototype gets broadband internet capability”. Worldcarfans.com. Retrieved 2012-04-15.

[55] “Audi A8 with broadband Internet connection”. Audi-mediaservices.com. 2011-02-16. Retrieved 2012-04-15. [56] “High-Security Audi A8 planned for High Contingency”.

AudiSite.com. 2011-02-16. Retrieved 2011-02-21.

[57] Jeff Glucker RSS feed (2011-02-16).“Audi A8 L Secu-rity blends serious protection with luxury and style”. Au-toblog.com. Retrieved 2012-04-08.

[58] “Audi Canada”. Retrieved 14 July 2015.

[59] “Audizine: News: High-security version of the Audi A8 soon to be launched”. Retrieved 14 July 2015.

[60] “Audi’s A8L Security So Bombproof, It Can Even Survive the Phaeton”. Car and Driver. 2011-02-18.

[61] “AutoNet : ,A8 L Security !".

Retrieved 14 July 2015.

[62] Sebastian Blanco RSS feed.“Audi spills the beans on pro-duction 37 mpg A8 Hybrid”. Autoblog.com. Retrieved 2012-04-08.

[63] “Pakete > A8 > Audi Deutschland”. Retrieved 14 July 2015.

[64] “Consistently efficient – the Audi A8 hybrid”. Audi

Me-diaCenter. Retrieved 14 July 2015.

[65] “2011 :AUDI A8

Hy-brid , Hybrid ". AUTONET. 2011-08-25.

[66] “2011 : ,AUDI A8

Hy-brid ". AUTONET. 2011-09-15.

[67] Drew Phillips (2011-09-15). “Audi adds more luxury to the A8L W12 with the Exclusive Concept”. Auto-blog.com.

[68] “Car stars shine at Auto China 2010”. Retrieved 14 July 2015.

14 5 REFERENCES

[69] Jacquot, Josh (2011-10-26).“2013 Audi S8 First Drive”. Insideline.com. Retrieved 2012-05-25.

[70] “Driven: 2012 Audi S8”. Fourtitude.com. 2011-11-16. Retrieved 2012-05-25.

[71] “2012 Audi S8 – 2012 Audi S8 First Drive Review on”. Roadandtrack.com. 2011-09-07. Retrieved 2012-05-25. [72] “New 2013 Audi A8 4.0T Premium 4dr All-wheel Drive quattro Sedan for sale in Richmond, British Columbia | LP Auto”. Newcars.lpauto.ca. 05-01. Retrieved 2012-05-25.

[73] “World Premiere of Audi S Models at the IAA 2011”.

Audi MediaCenter. Retrieved 14 July 2015.

[74] “AutoNet :AUDI S Model ,

S8 ". Retrieved 14 July 2015.

[75] “The Audi A8 Pricing and Specification Guide Valid from April 2012”(PDF). Retrieved 2012-04-15.

[76] “JC & Associates Communications, Inc.-case studies”. Retrieved 14 July 2015.

[77] “AutoNet : ,AUDI

A8 ". Retrieved 14 July 2015.

[78] “Audi MediaCenter”. Audi MediaCenter. Retrieved 14 July 2015.

[79] “Osram: You'll see more LED headlights”. Automotive

News. Retrieved 14 July 2015.

[80] Steven J. Ewing.“Audi adds 420-HP 4.0T V8 to A8, up-graded 3.0L TDI to Q7 for 2013”. Autoblog. Retrieved 14 July 2015.

[81] Seyth Miersma.“Audi confirms four new TDI diesel mod-els headed for US”. Autoblog. Retrieved 14 July 2015. [82] Steven J. Ewing. “Audi prices 2014 A8L TDI from

$82,500*". Autoblog. Retrieved 14 July 2015. [83] Audi A8L W12 (2012.10)

[84] Audi A8L hybrid (2013.06)

[85] Audi S8 (2012.10)

[86] Noah Joseph. “Audi also calling in A8, S8 over sunroof issue”. Autoblog. Retrieved 14 July 2015.

[87] “Audi S8: Suspect”. Retrieved 14 July 2015.

[88] “Q: Who is the hot girl in the Audi S8 “Suspect”...”. Re-trieved 14 July 2015.

[89] Zach Bowman.“S8 ad to air in NFL kickoff game tonight as Audi recommits to Super Bowl”. Autoblog. Retrieved 14 July 2015.

[90] Audi Kicks Off NFL Season with First-Ever Campaign for S Models

[91] https://www.audi-mediaservices.com/publish/ms/ content/en/public/pressemitteilungen/2013/08/21/audi_ a8.htmlComposure redefined – the Audi A8

[92] http://www.audi.com/com/brand/en/ vorsprung_durch_technik/content/2013/10/

audi-a8-in-a-new-radiant-light.html Audi Matrix LED Headlights

[93] http://www.audi.com/com/brand/en/ vorsprung_durch_technik/content/2013/10/

audi-a8-in-a-new-radiant-light.html Audi Matrix LED

[94] “The A8 Audi exclusive concept”. Audi MediaCenter. Re-trieved 14 July 2015.

[95] Viknesh Vijayenthiran. “2015 Audi A8 And S8 U.S. Specs Announced”. Motor Authority. Retrieved 14 July 2015.

[96] Greg Migliore. “Autoblog - We Obsessively Cover the Auto Industry”. Autoblog. Retrieved 14 July 2015. [97] “More composed than ever – the new Audi A8”. Audi

MediaCenter. Retrieved 14 July 2015.

[98] John Neff. “2015 Audi A8 rises to meet the challenge [w/video]". Autoblog. Retrieved 14 July 2015.

[99] Chris Bruce. “Refreshed 2015 Audi A8 starts at $77,400*". Autoblog. Retrieved 14 July 2015.

[100] “The new Audi A8 L Security – Supreme protection for passengers”. Audi MediaCenter. Retrieved 14 July 2015. [101] Noah Joseph. “Audi reveals new beefed-up A8 L

Secu-rity”. Autoblog. Retrieved 14 July 2015.

[102] http://www.volkswagenag.com/vwag/vwcorp/info_ center/en/publications/2003/03/annual_report_2002. -bin.acq/qual-BinaryStorageItem.Single.File/vw_gb_ 2002_en.pdf

[103] “Kom_engl_2602_1320.qxd” (PDF). Archived (PDF) from the original on 12 January 2011. Retrieved 2011-02-02.

[104] untitled

[105] “Volkswagen AG Annual Report 2008”(PDF).Archived

(PDF) from the original on 10 January 2011. Retrieved 2011-02-02. [106] http://www.volkswagenag.com/vwag/vwcorp/info_ center/en/publications/2010/03/Annual_Report_2009. -bin.acq/qual-BinaryStorageItem.Single.File/Y_2009_e. pdf [107] http://www.volkswagenag.com/content/vwcorp/info_ center/en/publications/2013/03/Y_2012_e.bin.html/ binarystorageitem/file/GB+2012_e.pdf [108] http://www.audi.com/content/dam/com/EN/ investor-relations/financial_reports/annual-reports/ 2013_audi_annual_report.pdf [109] http://www.audi.com/content/dam/com/EN/ investor-relations/financial_reports/annual-reports/ 2014_audi_annual_report.pdf

15

6

External links

• Audi pages: A8, Audi A8 L Security,A8 hybrid (concept)

16 7 TEXT AND IMAGE SOURCES, CONTRIBUTORS, AND LICENSES

7

Text and image sources, contributors, and licenses

7.1

Text

• Audi A8 Source:https://en.wikipedia.org/wiki/Audi_A8?oldid=692557889Contributors: Yooden, Modster, Djmutex, Andres, Morven, Topbanana, Smithd, Vespristiano, RedWolf, Seano1, Cecropia, Decrypt3, DocWatson42, Bobblewik, SamH, Mx2000~enwiki, Sfoskett, Milkmandan, Arcfire, Nard the Bard, Horsten, Pc13, Stombs, Sietse Snel, Hektor, Interiot, Atlant, Craigy144, EricS, Fritzpoll, Denniss, Dan100, Thryduulf, TomTheHand, Tabletop, Jagvar, Vossanova, Palica, Osunick, Rjwilmsi, Angusmclellan, MLRoach, Fred Bradstadt, FlaBot, WEKS, Bgwhite, YurikBot, RussBot, Arado, Shell Kinney, Lavenderbunny, RadioKirk, Welsh, Castletower, Syrthiss, Ozkaplan, Sardanaphalus, Attilios, SmackBot, Marc Lacoste, Deon Steyn, Boris Barowski, Tomh009, Gilliam, Ohnoitsjamie, Chris the speller, Gold-Dragon, BrendelSignature, The359, Letdorf, William Allen Simpson, Rrburke, Wes!, Jwy, MichaelBillington, Monzadave, Xen 1986, Take Me Higher, SashatoBot, Euchiasmus, Biivii, Accurizer, Beetstra, BSI, Otduff, Iridescent, Denis1210~enwiki, HennessyC, NaBUru38, Bravada, Cydebot, The Green Fish, Djdreamcars, Carzmaniac, Dancter, Ol4ever, Splateagle, Thijs!bot, Jmg38, Anupam, Ultegra, Escar-bot, MacMan2626, Bull-Doser, CZmarlin, Prolog, Lugia 1985, Rsocol, OSX, Fishsnacks, Lklundin, IFCAR, Magioladitis, SynergyStar, Firebladed, Janadore, Soulbot, Jcarr99, VectorD, MiPe, R'n'B, 72Dino, 328cia, Biglovinb, Mato Rei, Packa (renamed sock), Trilogy wiki, Mattmils03, Broadbot, Elvir.doc~enwiki, Dirkbb, Feudonym, Typ932, Le Fou, Zhour24, LAEsquire, Carmaker1, Swaq, Peter.shaman, Capitalismojo, Anchor Link Bot, Yaubrandon, Regushee, Squash Racket, ImageRemovalBot, Snigbrook, Maaher, Niceguyedc, DragonBot, Winston365, Sun Creator, 842U, Teutonic Tamer, El bot de la dieta, Mgdiesel, Cantor575, Johnuniq, Sylvestersteele, Chryslerforever1988, Red wikireader, Vijaysub, Kotakkasut, Netrat, Anticipation of a New Lover’s Arrival, The, Addbot, Woo456~enwiki, Pearll’s sun, MrOl-lie, Lightbot, Pradico, Luckas-bot, Yobot, C2451, Amirobot, AnomieBOT, Piano non troppo, Mapleleafaudi, James British, Citation bot, ArthurBot, LilHelpa, Mr.choppers, Egausmcdon, GrouchoBot, MR.Texan281, FrescoBot, Luckyhawky, Hallucegenia, Biker Biker, Rogriv, Aizuku, Navigator84, Stigness, Jimmihendrix 001, Reach Out to the Truth, DARTH SIDIOUS 2, RjwilmsiBot, WiiKiBoyz, Cha-pakan, Audio CD, DASHBot, FAEP, Japanesevehicles100, RenamedUser01302013, TheAutoJunkie, Havel1997, AvicBot, Danforth 3, RaymondSutanto, TIckman1, Iramendra, ChuispastonBot, ClamDip, ClueBot NG, Mepolypse, Bjohns86, CaridExp, Catlemur, Socckee, RememberCharlie, Its019, Widr, Mtking, Demon Hill, BG19bot, AhMedRMaaty, MusikAnimal, Jle65gts5260, MonkeyKingBar, Vi-suunome, BattyBot, Jacktacko92, Dedymataram, ChrisGualtieri, Coldbolt, Tcomotcom, Олег73рус, Touranushertz, Carguy1701, Faizan, Epicgenius, JTtheOG, Pzxpjy, Jaylick, Wheelbase&lengthguy, Vincent 3060, Mr-fix, Jacoversmith3, Martyn.w223, Abdallat123, Monkbot, Wroom, EurovisionNim, OoeeLila, Channi07, JMB86, Miteshputhran, Hossftrano and Anonymous: 291

7.2

Images

• File:1st-Audi-S8.jpg Source:https://upload.wikimedia.org/wikipedia/commons/b/b7/1st-Audi-S8.jpgLicense: Public domain Contrib-utors: Own work Original artist: IFCAR

• File:1st_Audi_A8_L_4.2_--_03-21-2012.JPG Source: https://upload.wikimedia.org/wikipedia/commons/7/76/1st_Audi_A8_L_4.2_ --_03-21-2012.JPGLicense: Public domain Contributors: Own work Original artist: IFCAR

• File:2004_Audi_A8_(4E)_4.2_quattro_sedan_(2015-07-14)_02.jpg Source: https://upload.wikimedia.org/wikipedia/commons/7/73/ 2004_Audi_A8_%284E%29_4.2_quattro_sedan_%282015-07-14%29_02.jpgLicense: Public domain Contributors: Own work Original artist:OSX

• File:2007-Audi-S8.jpg Source:https://upload.wikimedia.org/wikipedia/commons/4/46/2007-Audi-S8.jpgLicense: Public domain Con-tributors: Own work Original artist: IFCAR

• File:A8_W12.JPG Source:https://upload.wikimedia.org/wikipedia/commons/7/74/A8_W12.JPGLicense: Public domain Contributors: english Wikipedia Original artist: Jagvar

• File:AUDI_A8_4.2_Quattro_-_Czech_President.jpeg Source: https://upload.wikimedia.org/wikipedia/commons/4/43/AUDI_A8_4. 2_Quattro_-_Czech_President.jpegLicense: Public domain Contributors: Own work Original artist:Tomáš Havlíček

• File:Audi-A8-Japan.JPG Source:https://upload.wikimedia.org/wikipedia/commons/3/3e/Audi-A8-Japan.JPGLicense: CC BY-SA 3.0 Contributors: Own work Original artist:Kirakiraouji

• File:AudiA8BangAndOlufsenTweeterLens.JPG Source: https://upload.wikimedia.org/wikipedia/commons/0/01/ AudiA8BangAndOlufsenTweeterLens.JPGLicense: CC BY-SA 4.0 Contributors: Own work Original artist:Lklundin

• File:Audi_A8_2.0_T_Hybrid_(6147658222).jpg Source: https://upload.wikimedia.org/wikipedia/commons/1/11/Audi_A8_2.0_T_ Hybrid_%286147658222%29.jpgLicense: CC BY 2.0 Contributors:Audi A8 2.0 T HybridOriginal artist:Autoviva

• File:Audi_A8_2013_(11209745734).jpg Source: https://upload.wikimedia.org/wikipedia/commons/e/eb/Audi_A8_2013_ %2811209745734%29.jpgLicense: CC BY 2.0 Contributors:Audi A8 2013Original artist:Robert Basicfrom Germany

• File:Audi_A8_2013_(11209772425).jpg Source: https://upload.wikimedia.org/wikipedia/commons/1/12/Audi_A8_2013_ %2811209772425%29.jpgLicense: CC BY 2.0 Contributors:Audi A8 2013Original artist:Robert Basicfrom Germany

• File:Audi_A8_2013_(11209789925).jpg Source: https://upload.wikimedia.org/wikipedia/commons/e/ec/Audi_A8_2013_ %2811209789925%29.jpgLicense: CC BY 2.0 Contributors:Audi A8 2013Original artist:Robert Basicfrom Germany

• File:Audi_A8_2013_(11209827626).jpg Source: https://upload.wikimedia.org/wikipedia/commons/7/7c/Audi_A8_2013_ %2811209827626%29.jpgLicense: CC BY 2.0 Contributors:Audi A8 2013Original artist:Robert Basicfrom Germany

• File:Audi_A8_2013_(11209843023).jpg Source: https://upload.wikimedia.org/wikipedia/commons/5/5a/Audi_A8_2013_ %2811209843023%29.jpgLicense: CC BY 2.0 Contributors:Audi A8 2013Original artist:Robert Basicfrom Germany

• File:Audi_A8_2013_(11209949525).jpg Source: https://upload.wikimedia.org/wikipedia/commons/8/87/Audi_A8_2013_ %2811209949525%29.jpgLicense: CC BY 2.0 Contributors:Audi A8 2013Original artist:Robert Basicfrom Germany

• File:Audi_A8_I_4.2_quattro_Facelift_front_20101002.jpg Source: https://upload.wikimedia.org/wikipedia/commons/7/7c/Audi_ A8_I_4.2_quattro_Facelift_front_20101002.jpgLicense: Attribution Contributors: own photo Original artist:S 400 HYBRID

• File:Audi_A8_I_4.2_quattro_Facelift_rear_20101002.jpg Source:https://upload.wikimedia.org/wikipedia/commons/9/95/Audi_A8_ I_4.2_quattro_Facelift_rear_20101002.jpgLicense: Attribution Contributors: own photo Original artist:S 400 HYBRID

7.3 Content license 17

• File:Audi_A8_L_D3_II.Facelift_20090720_front.JPG Source: https://upload.wikimedia.org/wikipedia/commons/9/93/Audi_A8_L_ D3_II.Facelift_20090720_front.JPGLicense: Attribution Contributors: Own work (own photo) Original artist:S 400 HYBRID

• File:Audi_A8_L_W12_quattro_tiptronic_Phantomschwarz_Heck.JPG Source: https://upload.wikimedia.org/wikipedia/commons/ d/d9/Audi_A8_L_W12_quattro_tiptronic_Phantomschwarz_Heck.JPGLicense: CC BY 3.0 Contributors: Own work Original artist:

Thomas doerfer

• File:Audi_S8_(D4,_Facelift)_–_Frontansicht,_16._August_2014,_Essen.jpg Source: https://upload.wikimedia.org/wikipedia/ commons/c/cc/Audi_S8_%28D4%2C_Facelift%29_%E2%80%93_Frontansicht%2C_16._August_2014%2C_Essen.jpg License: CC BY-SA 3.0 de Contributors: Own work Original artist:M 93

• File:Audi_S8_--_09-24-2011.jpg Source: https://upload.wikimedia.org/wikipedia/commons/7/76/Audi_S8_--_09-24-2011.jpg Li-cense: Public domain Contributors: Own work Original artist: IFCAR

• File:Audi_S8_V10_black_with_blue_fence.jpg Source:https://upload.wikimedia.org/wikipedia/commons/e/ef/Audi_S8_V10_black_ with_blue_fence.jpgLicense: CC BY-SA 3.0 Contributors: Own work Original artist:Rimshot

• File:Audi_S8_rear_20080303.jpg Source: https://upload.wikimedia.org/wikipedia/commons/5/57/Audi_S8_rear_20080303.jpg Li-cense: CC-BY-SA-3.0 Contributors: Own work Original artist:Rudolf Stricker

• File:Audi_S8_schwarz_hl_1024x768.jpg Source: https://upload.wikimedia.org/wikipedia/commons/3/3a/Audi_S8_schwarz_hl_ 1024x768.jpgLicense: CC-BY-SA-3.0 Contributors: Own work Original artist: Matti Blume,MB-one17:05, 12 May 2006 (UTC) • File:Audi_Space_Frame.JPG Source: https://upload.wikimedia.org/wikipedia/commons/3/30/Audi_Space_Frame.JPGLicense: CC

BY-SA 3.0 Contributors: Own work Original artist:L.Kenzel

• File:Commons-logo.svg Source:https://upload.wikimedia.org/wikipedia/en/4/4a/Commons-logo.svgLicense: ? Contributors: ? Original artist: ?

• File:Folder_Hexagonal_Icon.svg Source:https://upload.wikimedia.org/wikipedia/en/4/48/Folder_Hexagonal_Icon.svgLicense: Cc-by-sa-3.0 Contributors: ? Original artist: ?

• File:S8_D3_cockpit_2009.jpg Source: https://upload.wikimedia.org/wikipedia/commons/c/ce/S8_D3_cockpit_2009.jpgLicense: CC BY 2.0 Contributors:FlickrOriginal artist:Sven from Schilde, Belgium

7.3

Content license
