Pre-Bid RFI # 01 - RESPONSE

(1)

Pre-Bid RFI # 01 -

RESPONSE

#1 Page A201 Demo note 4 states “Contractor shall coordinate all demolition of hazardous materials

with hazardous material contractor, if any.

Prior to start of construction and during construction.” Please provide an asbestos/lead report

asap for the site.

RESPONSE

-

District to provide HazMat report.

#2 Per detail 2/A2.01 new handrail on building at ramp, Detail 7/A802 shows blocking for new

handrail. What is the existing finish inside that room?

RESPONSE

-

Match Existing finish which is gypsum board and vinyl wall covering.

#3 Page A/201 shows new upper and lower cabinets on the west walls of rooms SE-1 and SE-2. It

appears that the HVAC return grill, thermostat and electrical panel will be Obstructed, if upper cabinets

are installed in these locations (See attached Marked-up plan page (PRE-BID RFI no.3 A201))

RESPONSE

-

Delete upper cabinets from scope of work in each classroom. Shift new base cabinets with

sink to location under the window in each classroom.

#4 Room SE-1 Has wire mold on wall where new sink location is depicted on drawing. There is no

mention of this wire mold on the demo plan. (See marked up Plan page PRE-BID RFI no.3 A201)

Please advise.

RESPONSE

-

Same response as item #4.

#5 Room that has the existing sink for restroom facilities has a window style air conditioner installed

under the window through the wall. Please provide framing, interior and exterior repair notes/details

for this location. (see attached marked-up plan page PRE-BID RFI no.5 A201 and picture)

RESPONSE

-

Infill wall to match existing framing and exterior siding and paint to match existing siding.

Use FRP finish at interior wall per note 6 on A-601

#6 Please verify that existing window in New student restroom H/C toilet area has existing Privacy

Film. Page A201 Detail 2.

RESPONSE

-

Provide Privacy film

#7 Page A201 detail 2, time out room, off of Room SE-1, no flooring noted. Please advise.

RESPONSE

-

Provide Carpet same as SE-1

#8 Page A201 per Legend Shaded 2x4 studs at 16” O.C. These are depicting new and existing walls

please clarify what is new and what is existing. Is there additional demo not shown?

RESPONSE

-

The 2x8 plumbing wall is new. (Shall be 2x8 per structural, not 2x6 as shown on A-201) The

2x4 walls shaded in gray on 2/A-201 are new walls. See revised sheet A-201.

Per 1/A-201, demo openings at existing walls as required for new doors & windows, frame openings per

plan, details 1 & 2 sht. A-802.

#9 Page S304 Detail’s 3 & 4 call out for 2x8 stud wall which contradicts Legend on page A201 that

states 2x6 stud wall.

(2)

#10 Demo plan does not call out demolition of existing ceiling or flooring in middle room area where

new restrooms, changing room and time out rooms are to go.

RESPONSE

-

Demo ceiling and flooring in the middle room areas

#11 Per page A201 windows are noted by a hexagonal symbol with an “A” noted as typical? Unable to

find window schedule. Please provide.

RESPONSE

-

Provide Type A as fixed Windows 48”X48” Tempered, typical.

#12 Drinking fountain shown on G002 referring to detail

8 /A802, what are the supply and waste piping

requirements? What is the wall covering/finish material on the inside of the restroom? Will it be

necessary to access plumbing below the floor of this relocatable restroom building? If so, what is the

flooring material?

RESPONSE

-

Locate new drinking fountain at north side of this building where existing fountain occurs.

Remove existing Drinking Fountain. See revised sht. G-002

#13 Page G002 Building Data and Overall Site Plan, outlined for reference to detail 1 & 2/A201 please

confirm that room 330 is not part of this scope.

RESPONSE

-

Provide Fire Alarm per E-102 approved plans for room 330

Attachments include:

1. District provided Hazmat Report

2. GC provided attachment - Pre-Bid RFI no.3 A201

3. GC provided attachment - Pre-Bid RFI no.5 A201

4. Revised sheet # G-002 Site Plan Add-01

5. Revised sheet # A-201 Floor Plan Add-01

6. Revised sheet # A-6001 Add-01

(3)

+ + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + | | | | | | | | | | | ||| ||| ||| | || | | | | | | | | | | | | | | | | | | | | | | | | | | | ||| ||| V V V V V V V V V V V V V V V V V V V V V V V V V V V V V V V V V V WINDOW, TYP COT/BED

9'-6"

10'-0"

5'-5"

14'-6"

(E)WINDOW V.I.F. (E)WINDOW V.I.F. (E)WINDOW V.I.F. CABINET & SINK CABINET & SINK WINDOW, TYP (N)CARPET (N)CARPET FLOORING SHEET VINYL (E)WINDOW W/PRIVACY FILM PARTIAL HEIGHT WALL (E)WINDOW V.I.F. E A A E A A A A B A B A A A-601 A B C D 22 A-801 2 A-802 (N)CARPET 22 A-801 TYP TYP TYP 4 A-601 A B FE FE 2% MAX 2% MAX MAX 2% MAX 2% 2388.75 CONC 2389.17 TC 2388.67 CONC 2388.75 CONC 2389.19 TC 2388.69 CONC (MATCH EX) 2388.84 TC 2388.34 CONC (MATCH EX) MAX 2% MAX 5% (MATCH EX) (MATCH EX)

PROVIDE 2" DRAINAGE GAP IN CURB AT EACH CORNER, FLUSH W/ LANDING

(MATCH EX) (MATCH EX) 5'-6" CLR 5'-0" CLR 2388.78 CONC 2389.28 TC 2388.78 CONC 5'-6" CLR 5'-0" CLR MAX 5% MAX _5% MAX 5% 2389.23 TC 2388.73 CONC 2388.70 CONC 2388.70 CONC (MATCH EX) MAX 2% MAX 5% (MATCH EX) (MATCH EX) MAX 2% SLOPE 1:12 MAX 4'-0" MIN (MATCH EX) 4'-0" MIN 2387.51 CONC 2387.46 CONC

SAWCUT AND REMOVE/REPLACE PORTION OF (E) CONCRETE RAMP AND WALK W/ EXCESSIVE CROSS SLOPE FLOOR DRAIN CARPET VINYL A-601 A A EQUIP. ACCESS PANEL SEE MECH MAX 2% MAX 2% MAX 2% MAX 2%

6'-0" MIN

LANDING

5'-0"

6 A-802 7 A-802 5 A-802 HANDRAIL PER DETAIL TYP 24" MIN 24" MIN 18" _MIN 12" MIN 34" MIN 30X48 CLR 30X48 CLR 30X48 CLR 4 A-601 A B 2 A-601 A B C D A-601 A B C D A-601 A B C D 11 A-801 2 A-802 TYP

5'-5"

(5'-0"MIN CLR)

5'-0" MIN

12" MIN 9 A-802 EQUIP. ACCESS PANEL SEE F.A. PLAN. TYP

+ + + + | | | | | | | | | | | ||| ||| || | | || | | | | | | | | | | | | | | | | | | | | | | | | | | | ||| ||| | | | | || | || | | | | | | | | | ||| ||| ||| ||| ||| ||| ||| ||| | | | | | | | | | V V V V V V V V V V V V V V V V V V V V V V V V (E)WINDOW V.I.F. (E)WINDOW V.I.F. (E)WINDOW V.I.F. DEMO (E)CARPET DEMO (E)CARPET (E)WINDOW V.I.F. (E)WALL TO REMAIN, V.I.F. (E)WALL TO REMAIN, V.I.F. (E)DOOR TO REMAIN, V.I.F. (E)DOOR TO REMAIN, V.I.F. DEMO (E)WALLS & PLUMBING FIXTURES, VERIFY EXACT LOCATION

DEMO (E)CABINET & SINK, VERIFY EXACT LOCATION

SAWCUT AND DEMO (E) AC RAMP AT DOOR TO BE REMOVED

SAWCUT AND DEMO (E) CONCRETE AT DOOR TO REMAIN

SAWCUT AND DEMO (E) AC AND CONCRETE LANDING AT DOOR TO REMAIN

5'-6"

6'-6"

4'-6"

C

REMOVE (E) CARPET AND BASEBOARD PER PLAN.

REMOVE (E) FLOORING, SHEET VINYL AND BASEBOARD PER PLAN. DEMO (E) NON-BEARING WALLS PER PLAN.

DEMO (E) PLUMBING FIXTURES AND PIPING AS REQUIRED. PROVIDE AND INSTALL ROUGH PLUMBING AS REQUIRED FOR PLUMBING FIXTURE.

HW-01

3 EA. HINGE FBB199 4.5 X 4.5 NRP 630 STA

1 EA. PRIVACY LOCK 22-50-8250XLWILXWBS 630 SGT

1 EA. CLOSER 350-CPS 689 SGT

1 EA. KICK PLATE K0050 10" X 34" B4E 630 TRM

1 EA. COAT HOOK 3071 626 TRM

1 EA. THRESHOLD 271A X290ASX36" 628 PEM

1 EA. SWEEP 18100CP 628 PEM

1 EA. DRIP CAP 345A (INSTALL@HEAD AS REQ.) 628 PEM

1 EA. SEAL 29344CP HD/JAMBS 628 PEM

HW-02

1 EA. PASSAGE SET 8215LWILXWBS 626 SGT

1 EA. MOP PLATE KOO5O 4"X34"XB4E 630 TRM

1 EA. OH STOP 594S 626 STG

1 EA. STOP W127CS OR 1214 628 TRM

1 EA. SILENCER 1229A GR TRM

NOTES:

1. CONTRACTOR / HARDWARE SUPPLIER TO REVIEW HARDWARE

AND KEYING REQUIREMENTS WITH FACILITIES DIRECTOR.

2. MANUFACTURES: STA - STANLEY; PEM-PEMCO; SGT-SARGENT;

TRM-TRIMCO, OR APPROVED EQUAL. MATERIAL / FINISH:

SCWD SOLID CORE WOOD DOOR HM HOLLOW METAL

PT PAINT SG STAIN GRADE

DOOR NOTES:

1. THRESHOLD / TRANSITION STRIP REFER TO DETAIL 21/A-801

2. REQUIRED DOOR CLEARANCES REFER TO DETAIL 3/A-802

DOOR SCHEDULE

TYPE SIZE DOOR FRAME CLOSER HDWR_NO. REMARKS

WIDTH HT. THK. 3'-0" 7'-0" 1 3/4" MAT'L FIN. SCWD PT MAT'L FIN. HM PT YES HW-01 101A 102A 103A 104B 105B 3'-0" 7'-0" 1 3/4" SCWD PT HM PT YES HW-01 3'-0" 7'-0" 1 3/4" SCWD PT HM PT YES HW-02 3'-0" 7'-0" 1 3/4" SCWD PT HM PT YES HW-02 3'-0" 7'-0" 1 3/4" SCWD PT HM PT YES HW-01 HALF-LITE HALF-LITE HALF-LITE

1. DEMO (E) FINISHES AS REQUIRED TO COMPLETE WORK AS

INDICATED. PATCH AND MATCH TO EXISTING.

2. CONTRACTOR TO COORDINATE EXTENT OF DEMOLITION OF

INTERIOR WALLS AND CEILING WITH FLOOR PLAN DRAWINGS.

3. CONTRACTOR SHALL COORDINATE ALL DEMOLITION OF

HAZARDOUS MATERIALS WITH HAZARDOUS MATERIAL CONTRACTOR, IF ANY. PRIOR TO START OF CONSTRUCTION AND DURING CONSTRUCTION.

4. CONTRACTOR SHALL TAKE PRECAUTIONS WHEN SAW CUTTING

(E) CONCRETE SLAB. CONTRACTOR SHALL NOT DISTURB ANY STRUCTURAL ELEMENTS INCLUDING BUT NOT LIMITED TO FOOTINGS, BEAMS, ETC.

5. ONLY PARTITION WALLS ARE PERMITTED TO BE DEMOLISHED.

SHEAR WALLS AND LOAD BEARING WALLS SHALL NOT BE REMOVED, U.O.N.

TIERRA BONITA E.S.

RELOCATABLE

CLASSROOM REMODEL

CONSULTANT STAMP ARCHITECT STAMP PROJECT OWNER: SHEET TITLE: DRAWN BY:

44820 N. 27TH ST. EAST

LANCASTER, CA 93535

SHEET NO. DATE: CONSULTANTS: REVISIONS

THE ARCHITECT DOES NOT REPRESENT THAT THESE PLANS OR THE SPECIFICATIONS ARE SUITABLE FOR ANY SITE OTHER THAN THE ONE FOR WHICH THEY WERE SPECIFICALLY PREPARED. THE ARCHITECT DISCLAIMS RESPONSIBILITY FOR THESE PLANS AND SPECIFICATIONS IF THEY ARE USED IN WHOLE OR IN PART AT ANY OTHER SITE.

JOB NUMBER: 019021.01

NO. DATE DESCRIPTION

#

MAY 1, 2019

ALAN NOELLE ENGINEERING 1616 ANACAPA ST.

SANTA BARBARA, CA 93101

TEL (805) 563-5444 FAX (805) 456-5901 BMA MECHANICAL

100 CROSS STREET, STE. 204 SAN LUIS OBISBO, CA 93401 TEL (805) 544-4269

AGENCY APPROVAL

PROJECT TITLE & SITE:

EASTSIDE UNION

SCHOOL DISTRICT

45006 30TH ST. E

LANCASTER, CA 93535

802 EAST COTA STREET. SUITE A

SANTA BARBARA, CA 93103

TEL (805) 963-1955

STORK, WOLFE & ASSOCIATES 555 CHORRO STREET, STE. A1 SAN LUIS OBISBO, CA 93405 TEL (805) 548-8600

APPLICATION NO. FILE NO.

03-120076

19-90

STANTEC

290 CONEJO RIDGE AVE. THOUSAND OAKS, CA 93161 TEL (805) 230-1266

2 (E) RELOCATABLE SPECIAL ED CLASSROOM - FLOOR PLAN & PARTIAL SITE PLAN

1/4" = 1'-0"

DEMOLITION PLAN,

FLOOR PLAN &

PARTIAL SITE PLAN

A-201

1 (E) RELOCATABLE SPECIAL ED CLASSROOM - DEMOLITION PLAN

1/4" = 1'-0"

LEGEND

(E) WALL TO REMAIN

DEMOLITION (E) FRAMING, FINISHES, PLUMBING, ELECTRICAL, FLOORING & ETC. 2X4 STUDS AT 16" O.C.

2X6 STUDS AT 16" O.C.

2X4 STUDS AT 16" O.C. PARTIAL HEIGHT WALL (48" A.F.F.)

SIGNAGE PER DETAIL 14/A-801 FIRE EXTINGUISHER

KEYNOTES

#

HARDWARE GROUP

FE

DEMOLITION NOTES:

DSA

D E P A R T M E N T O F G E N E R A L S E R V I C E S DIVISION OF THE STATE ARCHITECT

DSA

DIVISION OF THE STATE ARCHITECT

DSA

IDENTIFICATION STAMP DIV. OF THE STATE ARCHITECT

APP:

INC:

REVIEWED FOR SS FLS ACS DATE: ✔ ✔ ✔

03-120076

08/17/2020

HVAC return grills

Electrical panels

Wire Mold

Thermostat

(4)

(5)

(6)

+ + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + | | | | | | | | | | | ||| ||| ||| | || | | | | | | | | | | | | | | | | | | | | | | | | | | | ||| ||| V V V V V V V V V V V V V V V V V V V V V V V V V V V V V V V V V V WINDOW, TYP COT/BED

9'-6"

10'-0"

5'-5"

14'-6"

(E)WINDOW V.I.F. (E)WINDOW V.I.F. (E)WINDOW V.I.F. CABINET & SINK CABINET & SINK WINDOW, TYP (N)CARPET (N)CARPET FLOORING SHEET VINYL (E)WINDOW W/PRIVACY FILM PARTIAL HEIGHT WALL (E)WINDOW V.I.F. E A A E A A A A B A B A A A-601 A B C D 22 A-801 2 A-802 (N)CARPET 22 A-801 TYP TYP TYP 4 A-601 A B FE FE 2% MAX 2% MAX MAX 2% MAX 2% 2388.75 CONC 2389.17 TC 2388.67 CONC 2388.75 CONC 2389.19 TC 2388.69 CONC (MATCH EX) 2388.84 TC 2388.34 CONC (MATCH EX) MAX 2% MAX 5% (MATCH EX) (MATCH EX)

(MATCH EX) (MATCH EX) 5'-6" CLR 5'-0" CLR 2388.78 CONC 2389.28 TC 2388.78 CONC 5'-6" CLR 5'-0" CLR MAX 5% MAX _5% MAX 5% 2389.23 TC 2388.73 CONC 2388.70 CONC 2388.70 CONC (MATCH EX) MAX 2% MAX 5% (MATCH EX) (MATCH EX) MAX 2% SLOPE 1:12 MAX 4'-0" MIN (MATCH EX) 4'-0" MIN 2387.51 CONC 2387.46 CONC

SAWCUT AND REMOVE/REPLACE PORTION OF (E) CONCRETE RAMP AND WALK W/ EXCESSIVE CROSS SLOPE FLOOR DRAIN CARPET VINYL A-601 A A EQUIP. ACCESS PANEL SEE MECH MAX 2% MAX 2% MAX 2% MAX 2%

6'-0" MIN

LANDING

5'-0"

6 A-802 7 A-802 5 A-802 HANDRAIL PER DETAIL TYP 24" MIN 24" MIN 18" _MIN 12" MIN 34" MIN 30X48 CLR 30X48 CLR 30X48 CLR 4 A-601 A B 2 A-601 A B C D A-601 A B C D A-601 A B C D 11 A-801 2 A-802 TYP

5'-5"

(5'-0"MIN CLR)

5'-0" MIN

+ + + + | | | | | | | | | | | ||| ||| || | | || | | | | | | | | | | | | | | | | | | | | | | | | | | | ||| ||| | | | | || | || | | | | | | | | | ||| ||| ||| ||| ||| ||| ||| ||| | | | | | | | | | V V V V V V V V V V V V V V V V V V V V V V V V (E)WINDOW V.I.F. (E)WINDOW V.I.F. (E)WINDOW V.I.F. DEMO (E)CARPET DEMO (E)CARPET (E)WINDOW V.I.F. (E)WALL TO REMAIN, V.I.F. (E)WALL TO REMAIN, V.I.F. (E)DOOR TO REMAIN, V.I.F. (E)DOOR TO REMAIN, V.I.F. DEMO (E)WALLS & PLUMBING FIXTURES, VERIFY EXACT LOCATION

DEMO (E)CABINET & SINK, VERIFY EXACT LOCATION

SAWCUT AND DEMO (E) AC AND CONCRETE LANDING AT DOOR TO REMAIN

5'-6"

6'-6"

4'-6"

C

HW-01

HW-02

NOTES:

DOOR NOTES:

DOOR SCHEDULE

SHEAR WALLS AND LOAD BEARING WALLS SHALL NOT BE REMOVED, U.O.N.

TIERRA BONITA E.S.

RELOCATABLE

CLASSROOM REMODEL

44820 N. 27TH ST. EAST

LANCASTER, CA 93535

SHEET NO. DATE: CONSULTANTS: REVISIONS

#

MAY 1, 2019

ALAN NOELLE ENGINEERING 1616 ANACAPA ST.

TEL (805) 563-5444 FAX (805) 456-5901 BMA MECHANICAL

AGENCY APPROVAL

EASTSIDE UNION

SCHOOL DISTRICT

45006 30TH ST. E

LANCASTER, CA 93535

802 EAST COTA STREET. SUITE A

SANTA BARBARA, CA 93103

TEL (805) 963-1955

STORK, WOLFE & ASSOCIATES 555 CHORRO STREET, STE. A1 SAN LUIS OBISBO, CA 93405 TEL (805) 548-8600

03-120076

19-90

STANTEC

290 CONEJO RIDGE AVE. THOUSAND OAKS, CA 93161 TEL (805) 230-1266

2 (E) RELOCATABLE SPECIAL ED CLASSROOM - FLOOR PLAN & PARTIAL SITE PLAN

1/4" = 1'-0"

DEMOLITION PLAN,

FLOOR PLAN &

PARTIAL SITE PLAN

A-201

1 (E) RELOCATABLE SPECIAL ED CLASSROOM - DEMOLITION PLAN

1/4" = 1'-0"

LEGEND

(E) WALL TO REMAIN

KEYNOTES

#

HARDWARE GROUP

FE

DEMOLITION NOTES:

DSA

D E P A R T M E N T O F G E N E R A L S E R V I C E S DIVISION OF THE STATE ARCHITECT

DSA

IDENTIFICATION STAMP DIV. OF THE STATE ARCHITECT

APP:

INC:

REVIEWED FOR SS FLS ACS DATE: ✔ ✔ ✔

03-120076

08/17/2020

Window style air conditioner installed through the wall under window (see picture)

(7)

(8)

27TH STREET EAST

E. LANCASTER BLVD.

A-54379

(E)RELO.

RM 301

A-54379

(E)RELO.

RM 302

RM 303

_(E)RELO.

_A-54379

A-54379

(E)RELO.

RM 304

RM 305

_(E)RELO.

_A-54379

A-54379

(E)RELO.

RM 306

RM 307

_(E)RELO.

A-54379

RM 308

_(E)RELO.

A-54379

RM 309

_(E)RELO.

A-54379

(E)RELO.

RM 310

A-54379

TOILET

(E)RELO.

A-54379

(E)RELO

RR #1/ RR #2

A-54379

STAFF

(E)BLDG

S S G B S S G B S S G B B G

A-51548

CAFETERIA

(E)BUILDING

A-67286

NORTH WING

(E)BUILDING

A-67286

EAST WING

(E)BUILDING

(E) SHADE STRUCT. A-67286 (E) SHADE STRUCT. A-67286 (E) BUILDING 100 ADMINISTRATION OFFICE (E) TURF (E) HANDBALL BACKBOARD

(E) SOLAR PANEL STRUCTURE, TYP 03-113986

(E) SOLAR PANEL STRUCTURE, TYP

03-113986 SAFETY SURFACE

PLAY AREA

(E) PLAY AREA (E) F.H.

(E) F.H.

(E) 8 PARKING STALLS

(E) 4 PARKING

STALLS

(E) 1 ACC & 1 VAN ACC PARKING

A#101176

(E) HARDCOURTS

(E) AC PAVED DRIVE

(E) F.H. (E) F.H. (E) GATE 20'-0" (E) TURF (E) TURF (E) ELEC (E) ELEC S N G B G B (E) TURF (E) TURF (E) 1 ACC PARKING #A51548 AUTHORIZATION SIGN PER ₁₃ A-801 AUTHORIZATION SIGN PER 13 A-801 1 & 2 A-201

A-54379

(E)RELO

& CUSTODIAN

RM 325 / 326

A-54379

(E)RELO.

RM 311

A-54379

(E)RELO.

RM 320

A-54379

(E)RELO.

RM 312

A-54379

(E)RELO.

RM 313

A-54379

(E)RELO.

RM 314

A-54379

(E)RELO.

RM 315

A-54379

(E)RELO.

RM 316

A-54379

(E)RELO.

RM 317

A-54379

(E)RELO.

RM 318

A-54379

(E)RELO.

RM 319

A-54379

(E)RELO.

RM 321

A-54379

(E)RELO.

RM 322

A-54379

(E)RELO.

RM 323

A-54379

(E)RELO.

RM 324

A-54379

(E)RELO

RR #3

S

A-51548

(E)RELO.

RM 107

A-51548

(E)RELO.

RM 108

A-51548

(E)RELO.

RM 109

A-51548

(E)RELO.

RM 110

A-51548

(E)RELO.

RM 111

A-51548

(E)RELO.

RM 112

03-102188

(E)RELO.

RM 401

03-102188

(E)RELO.

RM 402

03-102188

(E)RELO.

RM 403

03-102188

(E)RELO.

RM 404

2 ACC & 1 VAN PARKING

CONSTRUCTED W/ 03-113986

(TO BE CERTIFIED W/ THIS PROJECT)

(E) 1 ACC PARKING #A51548 2 A-801 2 A-201 _{HI-LO D.F.} PER DETAIL 8 A-802 96'-0"Ø

FIRE ACCESS TURN-A-ROUND

03-102188

(E)RELO.

RM 330

A-54379

(E)RELO

SPECIAL ED

RM 327 & 329

G (E) GIRLS RESTROOM

B (E) BOYS RESTROOM

N (E) NURSES AREA RESTROOM

S (E) STAFF RESTROOM

BUILDING DATA &

OVERALL SITE PLAN

G-002

LEGEND

GENERAL NOTES

EXISTING BUILDING DATA

BLDG \

RELOCATABLE

OCC.

TYPE

CONST

TYPE

FIRE

SPRINKLER

USE

BLDG

HEIGHT

BLDG

AREA

ROOF

OH

TOTAL

AREA

ALLOW

AREA

100 E / A-2 / A-3 V-B YES

(E) ADMINISTRATION (E) CAFETERIA (E) CLASSROOMS (E) LIBRARY

33,568 SF

RM 107 RELOCATABLE E V-B NO (E) CLASSROOM 960 SF

RM 108 RELOCATABLE E / C / B-2 V-B NO (E) CLASSROOM 960 SF

RM 308 RELOCATABLE E V-B NO (E) CLASSROOM 1,440 SF

RM 309 RELOCATABLE E V-B NO (E) CLASSROOM 1,440 SF

RM 325, 326, & CUST.

RELOCATABLE E V-B NO

(E) 2-CLASSROOMS &

CUSTODIAN 2,400 SF

RM 327 & 329

RELOCATABLE E V-B NO

(E) 2-CLASSROOM &

TOILET ROOM 2,400 SF

RM 330RELOCATABLE E V-B NO (E) CLASSROOM 960 SF

RR #1 RELOCATABLE E V-B NO (E) RESTROOM 480 SF

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 A B C D E F G H I J

1 OVERALL SITE PLAN TIERRA BONITA ELEMENTARY SCHOOL

1" = 30' - 0"

TIERRA BONITA E.S.

RELOCATABLE

CLASSROOM REMODEL

44820 N. 27TH ST. EAST

LANCASTER, CA 93535

SHEET NO. DATE:

PLOT BY: MEnriquez

PLOT DATE: Mar 16, 2021 - 11:07am

Drawing name: H:\2019\19021-EUSD Tierra Bonita ES Special Ed Classroom\Bidding\Addenda\Addendum 01_PreBid RFIs\02-G-002 Site Plan Tierra Bonita ES.dwg

CONSULTANTS:

REVISIONS

#

MAY 1, 2019 ELECTRICAL ENGINEER ALAN NOELLE ENGINEERING 1616 ANACAPA ST.

TEL (805) 563-5444 FAX (805) 456-5901 MECHANICAL ENGINEER

BMA MECHANICAL

AGENCY APPROVAL

EASTSIDE UNION

SCHOOL DISTRICT

45006 30TH ST. E

LANCASTER, CA 93535

802 EAST COTA STREET. SUITE A

SANTA BARBARA, CA 93103

TEL (805) 963-1955

STRUCTURAL ENGINEER STORK, WOLFE & ASSOCIATES 555 CHORRO STREET, STE. A1 SAN LUIS OBISBO, CA 93405 TEL (805) 548-8600

03-120076

19-90

P.O.T. PATH OF TRAVEL (SEE NOTE 1) AREA OF WORK

(E) BUILDINGS NO WORK

FIRE DEPT. ACCESS

1. PATH OF TRAVEL (P.O.T.) AS INDICATED, IS A COMMON BARRIER FREE ACCESS

ROUTE WITHOUT ANY ABRUPT VERTICAL CHANGES EXCEEDING 1/2" BEVELED AT 1:2 MAXIMUM SLOPE, EXCEPT THAT LEVEL CHANGES DO NOT EXCEED 1/4" STABLE, FIRM, AND SMOOTH. PASSING SPACES (11B-403.5.3) AT LEAST 60"x60" ARE LOCATED NOT MORE THAN 200' APART. PARTS OF P.O.T. WITH

CONTINUOUS GRADIENTS HAVE 60" LEVEL AREAS (11B-403.7) NOT MORE THAN 400' APART. THE CROSS-SLOPE DOES NOT EXCEED 2% AND SLOPE IN THE DIRECTION OF TRAVEL IS LESS THAN 5% UNLESS OTHERWISE INDICATED. (POT) SHALL BE MAINTAINED FREE OF OVERHANGING OBSTRUCTIONS TO 80" MINIMUM (11B-307.4) AND PROTRUDING OBJECTS GREATER THAN 4"

PROJECTION FROM WALL AND ABOVE 27" AND LESS THAN 80" (11B-307.2). CONTRACTOR SHALL VERIFY PATH OF TRAVEL CONFORMS WITH THE ABOVE. PARKING CALCULATIONS

PER TABLE 11B-208.2

(E) TOTAL PARKING STALLS = 106

WITH (E) ACCESSIBLE PARKING STALLS = 4

INCLUDING (E) VAN ACCESSIBLE PARKING = 1

REQUIRED:

ACCESSIBLE PARKING STALLS FOR 106 TOTAL PARKING = 5 ACCESSIBLE STALLS INCLUDING 1 VAN ACCESSIBLE STALL.

PROVIDED:

TOTAL PARKING STALLS = 105

WITH 5 ACCESSIBLE STALLS INCLUDING 2 VAN ACCESSIBLE STALLS.

1

(9)

C 1 2 3

4 5

HW-01

HW-02

NOTES:

DOOR NOTES:

# #

DOOR SCHEDULE

SHEAR WALLS AND LOAD BEARING WALLS SHALL NOT BE REMOVED, U.O.N. + + + + | | | | | | | | | | | ||| ||| ||| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | ||| ||| | | | | | | | | | | | | | | | | | | ||| ||| ||| ||| ||| ||| ||| ||| | | | | | | | | | V V V V V V V V V V V V V V V V V V V V V V V V

SE-2

(E) SPECIAL ED

CLASSROOM

SE-1

(E) SPECIAL ED

CLASSROOM

(E)±40'-0"

(E)±24'-0"

(E)±12'-0"

(E)±24'-0"

(E)WINDOW V.I.F. (E)WINDOW V.I.F. (E)WINDOW V.I.F. DEMO (E)CARPET DEMO (E)CARPET (E)WINDOW V.I.F. (E)WALL TO REMAIN, V.I.F. (E)WALL TO REMAIN, V.I.F. (E)DOOR TO REMAIN, V.I.F. (E)DOOR TO REMAIN, V.I.F. DEMO (E)WALLS & PLUMBING FIXTURES, VERIFY EXACT LOCATION

DEMO (E)CABINET & SINK, VERIFY EXACT LOCATION (E)ROUGH PLUMBING TO REMAIN DEMO (E)CABINET &

SINK, VERIFY EXACT LOCATION (E)ROUGH PLUMBING TO REMAIN

±4'-0"

±7'-0"

±6'-6"

±8'-0" SAWCUT AND DEMO (E) AC

AND CONCRETE LANDING AT DOOR TO REMAIN 5'-6" 6'-6" ±8'-0" 4'-6" + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + | | | | | | | | | | | ||| ||| || | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | ||| ||| V V V V V V V V V V V V V V V V V V V V V V V V V V V V V V V V V V V V V V V

2388

SE-2

(E) SPECIAL ED

CLASSROOM

SE-1

(E) SPECIAL ED

CLASSROOM

RESTROOM

STUDENT

CLG. HT.±8'-0"

ROOM

CHANGING

CLG. HT.±8'-0"

(E)±60'-0"

(E)±40'-0"

(E)±24'-0"

(E)±12'-0"

(E)±24'-0"

WINDOW, TYP COT/BED

9'-6"

10'-0"

5'-5"

14'-6"

(E)WINDOW V.I.F. (E)WINDOW V.I.F. (E)WINDOW V.I.F. CABINET & SINK CABINET & SINK

ROOM

TIMEOUT

CLG. HT.±8'-0"

ROOM

TIMEOUT

CLG. HT.±8'-0" WINDOW, TYP (N)CARPET (N)CARPET FLOORING SHEET VINYL (E)WINDOW W/PRIVACY FILM PARTIAL HEIGHT WALL (E)WINDOW V.I.F. E A A E A A A A B A B A A 1 A-601 A B C D 104B 103A 102A 105B 101A A A A A A 22 A-801 2 A-802 (N)CARPET 22 A-801 TYP TYP TYP 4 A-601 A B 5 5 ₅ 5 FE FE 2% MAX 2% MAX MAX 2% MAX 2% 2388.75 CONC 2389.17 TC 2388.67 CONC 2388.75 CONC 2389.19 TC 2388.69 CONC (MATCH EX) 2388.84 TC 2388.34 CONC (MATCH EX) MAX 2% MAX 5% (MATCH EX) (MATCH EX)

(MATCH EX) (MATCH EX) 5'-6" CLR 5'-0" CLR 2388.78 CONC 2389.28 TC 2388.78 CONC 5'-6" CLR 5'-0" CLR MAX 5% MAX _5% MAX 5% 2389.23 TC 2388.73 CONC 2388.70 CONC 2388.70 CONC (MATCH EX) MAX 2% MAX 5% (MATCH EX) (MATCH EX) MAX 2% SLOPE 1:12 MAX 4'-0" MIN (MATCH EX) 4'-0" MIN 2387.51 CONC 2387.46 CONC 7'-7" (6'-0" MIN LANDING)

SAWCUT AND REMOVE/REPLACE PORTION OF (E) CONCRETE RAMP AND WALK W/ EXCESSIVE CROSS SLOPE 5 FLOOR DRAIN CARPET VINYL A-601 A A A-601 EQUIP. ACCESS PANEL SEE MECH MAX 2% MAX 2% MAX 2% MAX 2%

6'-0" MIN

LANDING

5'-0"

6 A-802 7 A-802 5 A-802 HANDRAIL PER DETAIL TYP 24" MIN 24" MIN 18" MIN 12" MIN 34" MIN 30X48 CLR 30X48 CLR 30X48 CLR 4 A-601 A B 2 A-601 A B C D 3 A-601 A B C D 3 A-601 A B C D 11 A-801 2 A-802 TYP

5'-5"

(5'-0"MIN CLR)

5'-0" MIN

(N)CARPET

TIERRA BONITA E.S.

RELOCATABLE

CLASSROOM REMODEL

44820 N. 27TH ST. EAST

LANCASTER, CA 93535

SHEET NO. DATE:

PLOT BY: MEnriquez

PLOT DATE: Mar 16, 2021 - 11:04am

Drawing name: H:\2019\19021-EUSD Tierra Bonita ES Special Ed Classroom\Bidding\Addenda\Addendum 01_PreBid RFIs\03-A-201 Floor Plan Tierra Bonita ES.dwg

CONSULTANTS:

REVISIONS

#

BMA MECHANICAL

AGENCY APPROVAL

EASTSIDE UNION

SCHOOL DISTRICT

45006 30TH ST. E

LANCASTER, CA 93535

802 EAST COTA STREET. SUITE A

SANTA BARBARA, CA 93103

TEL (805) 963-1955

03-120076

19-90

2 (E) RELOCATABLE SPECIAL ED CLASSROOM - FLOOR PLAN & PARTIAL SITE PLAN

1/4" = 1'-0"

DEMOLITION PLAN,

FLOOR PLAN &

PARTIAL SITE PLAN

A-201

1 (E) RELOCATABLE SPECIAL ED CLASSROOM - DEMOLITION PLAN

1/4" = 1'-0"

LEGEND

(E) WALL TO REMAIN

KEYNOTES

#

HARDWARE GROUP

FE

DEMOLITION NOTES:

1 03/15/21 PRE-BID RFI - ADD-01

1

1 1

(10)

2 1 7 6 7'-0" 6 6 6 ±4'-10" OPEN (44" MIN) 11 10 10 10 2'-10" MAX 11 SEE NOTE 1 7 SEE NOTE 1 13 14 13 13 13 14 SEE NOTE 1 2 2 2 10 8 13 13 13 2 10 3'-0" TYP 8 13 13 13 1 2 3

(E) FIXED WINDOW TO REMAIN V.I.F.

INTERIOR ALUM. FRAMED, FIXED WINDOWS, 1/4" SINGLE PANE TEMPERED, SEE DETAIL 2/A-802, U.O.N.

LAMINATE BASE CABINET WITH SINK

LAMINATE COUNTER WITH ±2" BACK SPLASH (ONE PIECE) LAMINATE UPPER CABINETS

FRP COLOR TO BE SELECTED BY OWNER.

SHEET VINYL WITH 6" COVED BASE. TO BE SELECTED BY OWNER. SEE DETAIL 23/A-801, TYP

RUBBER TOP SET BASE. TO BE SELECTED BY OWNER. PARTIAL HEIGHT WALL.

INTERIOR DOOR - STAIN GRADE SOLID CORE WITH HM FRAME, DOOR HARDWARE PER SPECIFICATIONS, SEE DETAIL 1/A-802, TYP.

SIGNAGE PER PLAN MIRROR PER PLAN

FINISHES: PAINT COLOR TO BE SELECTED BY OWNER. TOILET PARTITION PER SPEC'S, SEE DETAIL 24/A-801 4 5 6 7 8 9 10 11 12 13 14

SE-2

(E) SPECIAL ED

CLASSROOM

SE-1

(E) SPECIAL ED

CLASSROOM

_RESTROOM

STUDENT

(E)±9'-0" V.I.F. (E) CEILING (E) CEILING F.F. ±8'-0" EQUIP. ACCESS PANEL VARIES PER

(E)SLOPE OF ROOF, V.I.F.

HEIGHT VARIES PER SLOPE OF ROOF

F.S. TOP OF ROOF 2x6 C.J. PER STRUCT. 3 4 2'-10" MAX 1 8 13 8 13 1 2'-10" MAX 3 4 3'-2" 13 10 2 10 2 8 8 13 8 10 2 2 10 3'-2"

A-601

INTERIOR

ELEVATIONS &

SECTION

KEYNOTES

GENERAL NOTES

1. RESTROOM, TOILET AND ACCESSORY DIMENSIONS AND HEIGHT

REQUIREMENTS REFER TO DETAIL 10/A-801.

B

C

B

A

C

3/4" CABINET TOP

C

TOE SPACE

B

WALL CONNECTION

A

SIM. UPPER ISLAND TALL BASE/UPPER

A

SIM. CABINET 3/4" CABINET BOTTOM 10d @ 6"O.C.

NOTES: CABINET ANCHORAGE • VERTICAL LOAD REQUIREMENT PER:

TABLE 1607 A.1 CBC (PART 2 VOLUME 2, TITLE 24 CCR)

• LATERAL LOAD REQUIREMENT PER: ASCE 7-10 CHAPTER 13, TABLE 13.5-1

CONT PTDF 2x4 TOE BASE 16d @ 12"O.C.

WALL PER PLAN 4X BLOCKING

4X BLOCKING, TYP WALL PER PLAN

SIMPSON 0.145 PDPWL-300MG POWDER DRIVEN PINS W/16GA X 3/4" MIN STL WASHER @ 4-1/2" MIN-8" MAX FROM EA END & 16" MAX IN BETWEEN. (ICC-ESR 2138 OR APPROVED EQUAL 3/4" CABINET

BOTTOM, TYP U.O.N.

CONT PLYWD SHIM AS REQ'D, TYP #14 x 4" PAN HEAD PHILLIPS

W/1/2"Ø STL WASHER -2"

FROM END OF CABINET TOP & BOT. OF EA. CORNER & @ 16"O.C. 1/4" HARDBOARD BACK FINISH TO MATCH INTERIOR OF CABINET

#14 x 4" PAN HEAD PHILLIPS W/ 1/2" STL WASHER - 2" FROM END OF CABINET TOP & BOTTOM OF EA. CORNER & @ 16"O.C. HORIZ AND VERT

CONT PTDF 2 X 4 BASE 1/4" HARDBOARD BACK FINISH TO MATCH INTERIOR OF CABINET

1"

EMBED TYP

4"

CLR

5 TYPICAL CABINET CASEWORK ATTACHMENTS

SCALE: 1/4" = 1'-0"

TIERRA BONITA E.S.

RELOCATABLE

CLASSROOM REMODEL

44820 N. 27TH ST. EAST

LANCASTER, CA 93535

SHEET NO. DATE:

PLOT BY: MEnriquez

PLOT DATE: Mar 15, 2021 - 4:07pm

Drawing name: H:\2019\19021-EUSD Tierra Bonita ES Special Ed Classroom\Bidding\Addenda\Addendum 01_PreBid RFIs\05-A-601 Interior Elev.dwg

CONSULTANTS:

REVISIONS

#

BMA MECHANICAL

AGENCY APPROVAL

EASTSIDE UNION

SCHOOL DISTRICT

45006 30TH ST. E

LANCASTER, CA 93535

802 EAST COTA STREET. SUITE A

SANTA BARBARA, CA 93103

TEL (805) 963-1955

03-120076

19-90

2 SPECIAL ED - CHANGING ROOM

SCALE: 1/4" = 1'-0"

A

B

C

D

A

B

C

D

1 SPECIAL ED - STUDENT RESTROOMS

SCALE: 1/4" = 1'-0"

3 SPECIAL ED - TIME-OUT ROOM A (TIME-OUT ROOM B MIRROR IMAGE)

SCALE: 1/4" = 1'-0"

A

B

C

D

4A

SPECIAL ED - CLASSROOM SE-2

SCALE: 1/4" = 1'-0"

A

B

A

SECTION A-A

SCALE: 1/4" = 1'-0" 4 A-802 TYP 4 A-801 TYP

4 SPECIAL ED - CLASSROOM SE-1

SCALE: 1/4" = 1'-0"

A

B

9 A-801 5 A-601 9 A-801 5 A-601 1 1
