Custom Mounts For The Perfect Fit Save space in your compartment by installing our custom vehicle mount that snugly wraps around the EX50Li and secures it in place.
Vehicle Mount
Revolutionary Battery Operated Fire Fighting Fan
Stay Unplugged, Indefinitely! Swappable battery packs with enhanced IP66 water jet protection to protect against the inevitable sweep of the fire hose. The ability to have extra packs ready to go removes the limitations of other battery fan concepts, leading towards full corded fan replacement on the fire ground. 40V Lithium-Ion Battery Packs! Advanced, High Energy Density 432 Wh Lithium Ion battery system was designed specifically for the high draw and sustained run-time applications demanded of PPV fans.
EX50Li
Rapidly Charge Batteries External battery charger that can be mounted in a fire apparatus or at the fire department to rapidly charge two RAMFAN 40V batteries at the same time in 4 hours.
Battery Charger
Remain Cordless & Keep Ventilating During Extended Ops
Advanced, High Energy Density 40V, 6Ah Lithium-Ion battery packs are designed specifically for the high draw and sustained run-time applications demanded of RAMFAN blowers. Rapidly charge batteries in 4 hours with no memory loss effect after charging.
40V Battery Packs
Ramfan Next Generation Controller Intellisense™ E2 is exclusively available in RAMFAN blowers. Euramco’s latest generation of the Intellisense motor controller series, the E2 controller is tailor-made for firefighting and industrial operations. Its robust motor control algorithm is ideal for controlling motors in a broad range of industrial and firefighting, providing advanced capabilities and superior performance.
IntelliSense
™E2 Controller
Night Ops
400 Lumens of LED scene lights integrated into the shroud to illuminate the path in front of the blower. The energy efficient LEDs sip the power of the fan alleviating concern of dead batteries.
Integrated Shroud Platform
Enhanced FlowPath™ Control
The PowerStream® flow straighteners, standard equipment on EX and GX models, was the first flow straightening technology on PPV fans, increasing flow velocity and allowing more flexible setback positioning. Drawing on our nearly half century of experience in specialized rotational machinery, our engineering team has further refined the flow characteristics and efficiency of our PowerStream-equipped blowers by reducing boundary layer friction. We developed a secondary layer of flow, an outer friction-reducing layer, to more efficiently deliver the central mass volume flow needed to control the FlowPath™ deeper into the structure.
2nd Generation Flow Straightening
Innovations
EQUIPMENT READINESS IS A CRITICAL PART OF THE DESIGN CRITERIA FOR ANY PIECE OF FIREFIGHTING AND RESCUE EQUIPMENT. OPERATING WELL DURING A SINGLE
OPERATION, OR EVOLUTION, IS GOOD BUT FIRE AND RESCUE TEAMS ARE ON CALL FOR, AT LEAST, AN ENTIRE SHIFT. THE APPARATUS, AND ALL EQUIPMENT IN IT, ON THE
OTHER HAND MUST BE READY TO ROLL AT ANY TIME. IF THE EQUIPMENT IS SPENT AFTER A SINGLE USE, IT BECOMES COMPLETELY WORTHLESS, AND EVEN DANGEROUS,
ON THE NEXT CALL WHEN IT IS NO LONGER ABLE TO BE USED AS INTENDED. WHEN WE DESIGNED THE RAMFAN EX50LI, EQUIPMENT READINESS WAS AT THE TOP OF
OUR LIST. THIS MEANT SWAPPABLE BATTERY PACKS WERE NON-NEGOTIABLE. THE FAN SHOULD BE CAPABLE OF CONTINUOUS USE, DURING BACK TO BACK OPERATIONS,
WITHOUT BEING TAKEN OUT OF SERVICE FOR ABNORMALLY LONG CHARGE TIMES.
SOME MANUFACTURERS ANSWER THIS CHALLENGE BY TRYING TO SELL TWO FANS PER APPARATUS, TO “ALWAYS HAVE ONE READY TO GO”. THIS MAY PENCIL OUT WELL
FOR THEIR BUSINESS, BUT DOESN’T DO ANY FAVORS FOR FIRE DEPARTMENTS AND FIREFIGHTERS WHO ARE OPERATING ON LIMITED BUDGETS AND WITH LIMITED
COMPARTMENT SPACE. AND WITH THIS “TWO FAN OPTION,” THE FIRE DEPARTMENT MUST BUDGET $8,000 FOR 1-HOUR OF VENT TIME. THAT’S $130 PER MINUTE! IN
REALITY THOUGH, THEY SHOULD HAVE INVESTED A BIT MORE IN ENGINEERING INSTEAD OF RUSHING OUT A PRODUCT THAT IS NOT FIT FOR THE APPLICATION.
EDUCATED EVALUATIONS PRIOR TO EQUIPMENT PURCHASES ARE SO CRITICAL TO ENSURE THAT YOUR DEPARTMENT IS GETTING THE BEST VALUE AND PERFORMANCE
FOR YOUR BUDGET. WITH NEW BATTERY TECHNOLOGY CREEPING INTO THE FIREFIGHTING WORLD, THERE IS A LEVEL OF TECHNOLOGY THAT HASN’T REALLY BEEN SEEN
OR DISCUSSED BEFORE IN THE FIREHOUSE. THIS MEANS EVALUATIONS CAN BE MORE COMPLICATED, AS THE REAL DIFFERENCES--PRODUCT TO PRODUCT--ARE OFTEN IN
TERMS THAT YOU MAY NOT HAVE HEARD BEFORE.
HERE’S A COUPLE OF TERMS TO BRUSH UP ON:
PURCHASING COMMITTEES ARE TASKED WITH THE ACQUISITION OF NOT JUST EQUIPMENT BUT CAPABILITIES. WHAT YOU BUY NOW, YOU’RE LIKE GOING TO BE STUCK
WITH FOR THE NEXT DECADE OR MORE. WHILE STRUCTURES MAY BE BECOMING SAFER FROM FIRE DANGER, IN GENERAL, THEY ARE ALSO BURNING HOTTER AND FASTER
WHEN THEY DO IGNITE, REQUIRING FASTER RESPONSE TIMES AND REQUIRING THAT THE RESPONDERS ARE ON POINT WHEN THEY DO ARRIVE. YOU CAN ALWAYS TRAIN
THE ROOKIE TO BE BETTER IN TIME, BUT YOU’RE EQUIPMENT INVENTORY IS WHAT IT IS. DO YOUR HOMEWORK.
BRUSHLESS DC MOTOR
WATT HOURS (WH)
CHARGE CYCLES
SELF DISCHARGE RATE
2
1
3
4
ChargingBattery Weight Speed Gauge Maximum Range
AC Electric PPV
EX Series
The latest variable speed electric PPV fans with PowerStream® air straighteners for greater flow velocities and more flexible setback. Dual Current available on EX400 & EX500 models. EX500 and EX520 have optional integrated misting system.
EX400 EX420 EX500 EX520
ORDER # EB80600 EB88245 EK86500 EK86520
PPV AIRFLOW 11,391 cfm / 19,365 m3/hr 10,994 cfm / 18,690 m3/hr 11,540 cfm / 19,618 m3/hr 13,354 cfm / 22,702 m3/hr IMPELLER Nominal 16 in / 400 mm,
7-blade Nominal 16 in / 400 mm, 7-blade Nominal 18 in / 460 mm, 5-blade Nominal 18 in / 460 mm, 5-blade
WEIGHT 68 lbs / 31 kg 68 lbs / 31 kg 70 lbs / 32 kg 70 lbs / 32 kg
DIMENSIONS
(h/w/d) 22.6/17.4/18.5 in / 570/440/470 mm 22.6/17.4/18.5 in / 570/440/470 mm 23.5/21/18.5 in / 600/530/470 mm 23.5/21/18.5 in / 600/530/470 mm
NOISE 88dB@3ft/1m 84dB@10ft/3m 88db@3ft/1m 84db@10ft/3m 95dB@3ft/1m 91dB@10ft/3m 95dB@3ft/1m 91dB@10ft/3m
MOTOR 1.5 Hp / 1.1 kW 1.5 Hp / 1.1 kW 1.5 Hp / 1.1 kW 1.5 Hp / 1.1 kW
ELECTRIC 115V, 1ø, 15 or 20A, 60Hz 230V, 1ø, 10A 50/60Hz 115V, 1ø, 15 or 20A, 60Hz 230V, 1ø, 10A 50/60Hz
EV400 EV420
ORDER # EB80500 EB80510
PPV AIRFLOW 11,391 cfm / 19,365 m3/hr 11,391 cfm / 19,365 m3/hr IMPELLER Nominal 16 in / 400 mm, 7-blade Nominal 16 in / 400 mm, 7-blade
WEIGHT 68 lbs / 31 kg 68 lbs / 31 kg
DIMENSIONS
(h/w/d) 22.6/17.4/18.5 in / 570/440/470 mm 22.6/17.4/18.5 in / 570/440/470 mm
NOISE 88dB@3ft/1m 84dB@10ft/3m 88dB@3ft/1m 84dB@10ft/3m
MOTOR 1.5 Hp / 1.1 kW 1.5 Hp / 1.1 kW
ELECTRIC 115V, 1ø, 15 or 20A, 60Hz 230VAC, 1ø, 10A 50/60Hz
EF Series
Powerful Single-Speed electric PPV fan with a powder coated steel frame, all-terrain semi-pneumatic tires and full width retractable handle.
EV Series
Variable speed electric PPV fans with continuous airflow adjustment. Dual Current available on EV400 with the flip of a switch, power fan from GFCI 20A fire truck circuit OR 2kw generator to GFCI 15A house circuit. Built with a powder coated steel frame, all-terrain semi-pneumatic tires, full width retractable handle, and 0-20° tilt able handle.
EF390H
ORDER # EA5403
PPV AIRFLOW 11,765 cfm / 20,001 m³/hr
IMPELLER Nominal 16 in / 400 mm, 7-blade
WEIGHT 78 lbs / 35 kg DIMENSIONS (h/w/d) 23/17.5/18.5 in / 580/440/470 mm NOISE 95dB@3ft/1m / 91dB@10ft/3m MOTOR 2.2 Hp / 1.7 kW ELECTRIC 230V, 1ø, 12A, 50Hz
Revolutionary battery operated fire fighting fan
Swappable battery packs with enhanced IP66 water jet protection to protect against the inevitable sweep of the fire hose.
The latest technology integrated into this multi-purpose ventilator with swappable batteries. Used for PPV, Smoke Ejector, Confined Space or as a relay fan in large structure ventilation. Starts instantly on battery power and lasts 45 minutes at max speed or hours on low speed to keep air moving. Equipped with 2nd Generation PowerStream® air straighteners for advanced FlowPath™ control.
NEW
Battery PPV
EX50Li
ORDER # EL5500
PPV AIRFLOW 8,939 cfm / 15,187 m3/hr IMPELLER Nominal 18 in / 460 mm, 5-blade
RUN TIME
DC: 90 Minutes (4 battery packs) DC: 45 Minutes (2 battery packs) DC: 23 minutes (1 battery pack) AC: Unlimited
WEIGHT 54 lbs / 25 kg with two battery packs equipped50 lbs / 22.6 kg with one battery pack equipped 45 lbs / 20 kg without batteries
DIMENSIONS (h/w/d) 22/21/12 in / 558/533/304 mm MOTOR 0.8 Hp / 0.6 kW
ELECTRIC Universal input 85-260 VAC
PPV with 2nd Generation PowerStream flow straightening
Smoke Ejection
Exhausting fumes from the roof by laying it on its back
Confined Space Rescue
Relay fan in large structures
Integrated LED scene lights
IP66 ingress protection for motor and controllerBeautiful and Functional Form Factor
Always Ready.Swappable battery packs
Fail-proof redundancy
Latest Lithium-Ion Technology
IP66 Water resistantSwappable 40V Lithium-Ion Battery Packs
Advanced, High Energy Density 432 Wh Lithium-Ion battery system was designed specifically for the high draw and sustained run-time applications demanded of PPV fans. Engineered to do more than any other fan. The compact
and lightweight fan is a multi-purpose ventilator.
The ability to have extra packs ready to go removes the limitations of other battery fan concepts, leading towards full corded fan replacement on the fire ground.
1 RAMFAN EX50Li Multi-Purpose Ventilator
Order# EL5500 (115V) | EL5500-230 (230V)
2 Battery Charger
Order# R2C-5500DC | R2C-5500AC
3 Truck Compartment Mount Kit
Order# EL600K
4 Swappable 40V Lithium-Ion Battery Packs
SAFEST
SAFER
SAFE
Smoke Ejectors
EFC50/EFC120/EFC150
EFC50 EFC120 EFC150
ORDER # EA7000, EA7000-230 EA7300 EG8000, EG8000-230
MOTOR 0.5 Hp / 0.37 kW 1.2 Hp / 0.9 kW 1.5 Hp / 1.1 kW ELECTRIC 115/230V, 1ø, 50/60Hz 230V, 1ø, 50Hz 115/230V, 1ø, 50/60Hz FREE AIR Through Duct 15'/4.6 m w/ one 90° turn: 3,200 cfm / 5,440 m3/hr 3,750 cfm / 6,375 m3/hr 4,459 cfm / 7,580 m3hr 1,935 cfm / 3,289 m3/hr 2,700 cfm / 4,590 m3/hr 3,179 cfm / 5,404 m3hr WEIGHT 49 lbs / 22 kg 55 lbs / 25 kg 55 lbs / 25 kg APPROVALS
Heat-resistant Lexan® housing
*Certified Motor Only
*Certified Motor Only *
EFC50x/EFC120x/EFC150x
EFC50x EFC120x EFC150x
ORDER# EA7000X, EA7000X-230 EA7300X EG8000X, EG8000X-230
MOTOR 0.5 Hp / 0.37 kW 1.2 Hp / 0.9 kW 1.5 Hp / 1.1 kW ELECTRIC 115/230V, 1ø, 50/60Hz 230V, 1ø,50Hz 115/230V, 1ø, 50/60Hz FREE AIR Through Duct 15'/4.6 m w/ one 90° turn: 3,200 cfm / 5,440 m3/hr 3,750 cfm / 6,375 m3/hr 4,459 cfm / 7,580 m3hr 1,935 cfm / 3,289 m3/hr 2,700 cfm / 4,590 m3/hr 3,179 cfm / 5,404 m3hr WEIGHT 49 lbs / 22 kg 55 lbs / 25 kg 55 lbs / 25 kg APPROVALS
Heat-resistant Lexan® housing, and use an explosion-proof motor
* * *
EFi50xx/EFi120xx/EFi150xx
EFi50xx* EFi120xx EFi150xx
ORDER# EA8000XX, EA8000XX-230 EA8120XX, EA8120XX-110 EG8200XX, EG8200XX-230
MOTOR 0.5 Hp / 0.37 kW 1.2 Hp / 0.9 kW 1.5 Hp / 1.1 kW ELECTRIC 115/230V, 1ø, 50/60Hz 110/240V, 1ø, 50Hz 115/230V, 1ø, 50/60Hz FREE AIR Through Duct 15'/4.6 m w/ one 90° turn: 3,200 cfm / 5,440 m³/hr 1,935 cfm / 3,289 m3/hr 3,750 cfm / 6,375 m3/hr 2,700 cfm / 4,590 m3/hr 4,459 cfm / 7,580 m3/hr 3,179 cfm / 5,404 m3/hr WEIGHT 49 lbs / 22 kg 55 lbs / 25 kg 61 lbs / 28 kg APPROVALS
Euramco Safety’s specialty. Certified explosion-proof portable ventilators.
UB20xx M.E.D.™ (Manhole Entry Device) Order# EF7015-MEDXX (115V) EF8015-MEDXX (230V) M.E.D. allows rescue crew to ventilate a confined space without blocking entry, and maintain airflow while working. Package includes: UB20xx, Quick-Couple™ Canister with 4.6 m and 1.5 m of duct, Manhole Entry Device (M.E.D.), 90° Swivel Elbow, Universal Mount and 20 cm duct adapter for additional duct connections. UB20xx
Whole Unit Certified for safe use in explosive atmospheres Powerful, compact and lightweight Rugged, anti-static casing –
weatherproof, chemical resistant and dent resistant
Ultra-quiet operation Optional canister
XP Series
Purges hazardous gases safely. ATEX certified motor Equipped with
PowerStream® with greater setback distance
Working in an explosive atmosphere is inherently more dangerous than standard working environments. RAMFAN has ATEX certified motors that are completely enclosed for safe use in dangerous atmospheres.
UB20xx XP400 XP420 XP500 XP520 ORDER # EF7002 (115V) EF8002 (230V) (ventilator only) EF7015 (115V) (w/ canister) EF8015 (230V) (w/ canister)
EB80500X EB80500X-230 EB90600X EB90600X-230
FREE AIR Through Duct 15ft 1-90° turn 15ft 2-90° turns 25ft 1-90° turn 25ft 2-90° turns 980 cfm / 1,666 m3/hr 789 cfm / 1,341 m3/hr 666 cfm / 1,132 m3/hr 722 cfm / 1,227 m3/hr 614 cfm / 1,044 m3/hr 11,391 cfm / 19,365 m3/hr - - -10,994 cfm / 17,143 m3/hr - - -11,540 cfm / 19,618 m3/hr - -13,354 cfm / 22,702 m3/hr - -
-IMPELLER Nominal 8 in / 200 mm, 9-blade Nominal 16 in / 400 mm, 7-blade Nominal 16 in / 400 mm, 7-blade Nominal 18 in / 460 mm,5-blade Nominal 18 in / 460 mm,5-blade
WEIGHT 27 lbs / 12 Kg 68 lbs / 31 kg 68 lbs / 31 kg 72 lbs / 33 kg 72 lbs / 33 kg DIMENSIONS (h/w/d) 14/14/15.5 in / 350/350/390 mm 22.6/17.4/18.5 in / 570/440/470 mm 22.6/17.4/18.5 in /570/440/470 mm 23.5/21/18.5 in / 600/530/470 mm 23.5/21/18.5 in /600/530/470 mm NOISE 74dB@3ft 97dB@3ft 97dB@3ft 97dB@3ft 97dB@3ft MOTOR 0.33 Hp / 0.25 kW 1.5 Hp / 1.1 kW 1.5 Hp / 1.1 kW 1.5 Hp / 1.1 kW 1.5 Hp / 1.1 kW ELECTRIC 115/230V, 1ø, 50/60Hz 115V, 1ø, 50/60Hz 230V, 1ø, 50/60Hz 115V, 50/60Hz 230V, 1ø, 50/60Hz
AMPS – RUN 2A 15A 8A 15A 8A
APPROVALS
Hazardous Location Rescue
*Certified Motor Only
*
*
*
*
No more fans in your way while you get in and victims get out
No more tripping over cords or kicking over fans
Flexible positioning to get exactly the right spot for maximum performance
Less interior noise to interfere with communications
No other manufacturer can compete with our INDEPENDENTLY VERIFIED cfm and setback distances
Lightweight Gas Powered PPV
Go the Distance with PowerStream
®Gas Powered PPV
Gas Powered PPV
POWERSTREAM CONVENTIONAL
CLOSE RANGE: Both PowerStream®
and Conventional fans can operate in close range
of the door.
AT 18 FEET: Only PowerStream®
fans can be set back as far as 18 feet and be equally
effective as 6 feet. Effective Effective Not Effective Not Effective
PowerStream
®Technology, only from RAMFAN
PowerStream® ventilation results from a state-of-the-art combination of a fan impeller and stat
or that takes the cone of air you’ve always used for PPV and tightens it to keep it focused over longer distances without losing significant power. PowerStream® is like going from a fog nozzle to straight bore. You still get the same, dependable flow of air to ventilate a structure, you can just do it from farther away.
Ultra Lightweight
RAMFAN offers the lightest PPV fans on the market, providing the ultimate portability. Starting at only 36 lbs/16 kg, the GX200L can easily be carried with one hand. Light enough to carry up stairwells and deploy in large commercial buildings or powerful enough for PPV in residential houses. Equipped with PowerStream® air straighteners.
GF Series
Tried and True the GF series have been around since RAMFAN got its start. The economical gas fans are well known for their durability.
GX Series
RAMFAN gas powered fans set the standard in reliability and performance. Built with a superior steel “roll cage˝ design and WIDE-Trac semi-pneumatic urethane tires to endure rugged terrain. Convenient ONE-Step™ tilt adjustment to easily angle the fan over obstacles. Equipped with PowerStream® air straighteners for further setback distances.
GX200 GX200L Best in Class! GX310 GX350 GX400 ORDER # GH5010 GH5005 GE5022 PPV AIRFLOW 16,968 cfm / 28,846 m3/hr 18,705 cfm / 31,799 m3/hr 16,797 cfm / 28,555 m3/hr IMPELLER Nominal 18 in / 460 mm, 9-blade Nominal 18 in / 460 mm, 9-blade Nominal 21 in / 540 mm, 7-blade
RUN TIME 2 hrs 6 min 1 hr 50 min 1 hr 50 min
WEIGHT 82 lbs / 37 kg 84 lbs / 38 kg 88 lbs / 40 kg
DIMENSIONS (h/w/d) 21.6/21.7/19.6 in / 550/550/500 mm 21.6/21.7/19.6 in / 550/550/500 mm 24.9/25/22 in / 630/640/560 mm
NOISE 100dB@3ft/1m 95dB@10ft/3m 101dB@3ft/1m 97dB@10ft/3m 99dB@3ft/1m 95dB@10ft/3m MOTOR Honda GX160 4.8 Hp / 3.5 kW Honda GX200 5.5 Hp / 4.1 kW Honda GX200 5.5 Hp / 4.1 kW
GF164SE GF165 GF210
ORDER # GB5001HSE GA5006 GE5001
PPV AIRFLOW 11,653 cfm / 19,810 m³/hr 12,906 cfm / 21,940 m³/hr 17,670 cfm / 30,039 m³/hr
IMPELLER Nominal 16 in / 400 mm, 7-blade Nominal 16 in / 400 mm, 21-blade Nominal 21 in / 540 mm, 7-blade
RUN TIME 1 hr 58 min 2 hrs 6 min 2 hrs 6 min
WEIGHT 59 lbs / 27 kg 84 lbs / 38 kg 88 lbs / 40 kg
DIMENSIONS (h/w/d) 21/20/17 in / 530/510/430 mm 22/20.2/20 in / 560/510/510 mm 24.8/25.3/22.4 in / 630/640/570 mm
NOISE 96dB@3ft/1m 96dB@3ft/ 1m 96dB@3ft/1m
MOTOR Honda GC160 4.6 Hp / 3.4 kW Honda GX160 4.8 Hp / 3.5 kW Honda GX160 4.8 Hp / 3.5 kW
PowerStream
®Technology: Benefits of further setback distance 6–18ft/ 1.8–9.7m
GX200L GX200
ORDER # GG5500 GG5010
PPV AIRFLOW 12,820 cfm / 21,794 m3/hr 12,820 cfm/ 21,794 m3/hr IMPELLER Nominal 16 in / 400 mm,
7-blade Nominal 16 in / 400 mm, 7-blade
RUN TIME 1hr 40 min 1hr 40 min
WEIGHT 36 lbs / 17 kg 48 lbs / 22 kg
DIMENSIONS (h/w/d) 22/18.5/20 in /40/530/620 mm 21.5/19.5/20.5 in /550/500/520 mm
GX500 GX600 VX700 - Skid Mounted
ORDER # GD5005 GJ5005 GK5000 (GK5005 w/trailer)
PPV AIRFLOW 19,100 cfm / 32,470 m3/hr 32,500 cfm / 55,250 m3/hr 60,200 cfm / 105,400 m3/hr IMPELLER Nominal 24 in / 600 mm,
6-blade Nominal 28 in / 700 mm, 7-blade Nominal 28 in / 700 mm, 7-blade
RUN TIME 2 hrs 2 min 2 hrs 40 min 2 hrs 30 min
WEIGHT 137 lbs / 62 kg 175 lbs / 80 kg 220 lbs / 100 kg (920 lbs w/trailer) DIMENSIONS (h/w/d) 30/29/26.7 in / 760/740/680 mm 34.5/37.3/30.3 in /880/950/770 mm 49/33.3/47.3 in / 1,240/850/1,200 mm (skid mounted) 79.75/58/124 in (w/ trailer) NOISE 100dB@3ft/1m 96dB@10ft/3m 105dB@3ft/1m103dB@10ft/3m 105dB@3ft/1m103dB@10ft/3m
MOTOR Honda GX270 8.5 Hp / 6.3 kW Vanguard V-Twin 18 Hp / 13.4 kW Honda GX630 23 Hp / 17 kW
=
$
$
$
$
$
$
$
Houston, TexasHouston, TexasHouston, Texas
PPV
Online retailing today is filling warehouses everywhere with products. Adding these to the current inventory of big box stores, airports, high-rises and hotels, the need for tools to fight large structure fires is clear.
These large structures require massive PPV ventilation because you can’t support firefighting operations in a large structure with small structure equipment.
One huge fan doesn’t make sense anymore.
Until now, Large Structure Ventilators have been huge monsters that are difficult to move and maneuver, which can limit access to the structure on fire. They require a large storage space and have price tags that are budget-busters. This limits most cities to a single unit for the entire area.
RAMFAN LSV’s are the solution to these problems. The largest LSV is a 28" trailer mounted fan that is small enough for one person to ma-neuver but powerful enough to quickly pressurize a highrise stairwell and is offered at a price point so low you can buy 6 LSV’s for every one truck mounted fan.
Large Structure Ventilators (LVS) come of
age as online commerce grows
VX700
Watered Powered PPV
LSV = Large Structure Ventilators = Big fans for big buildings
Malls • Warehouses • Factories • Transportation Terminals • High-Rise Building Stairwells & Lobbies
Large volumes of high-velocity airflow is required for ventilating large and complex structures. Quickly removing smoke, gases, engine exhaust or particulates from a large confined area increases safety of both personnel and property, reducing the chances of toxic inhalation and general atmospheric danger.
GX500 GX600
Skid Mounted European Trailer Mounted
Variations
Continous Track Mounted
When it comes to equipment access which would you prefer: A single hub or a distributed network?
If your city owns one large truck mounted fan stored in a central location and you respond to a warehouse fire on the outskirts of the city the response time may be too long to get the equipment to the scene. But if you had a distributed network of large fans it would cut the response time in less than half.
Many large structures do not have sufficient fixed ventilation systems to quickly remove dangerous airborne gases and particulates that can cause bodily harm. When abnormal situations occur that require rapid ventilation to reduce airborne hazards, LSVs are mobilized to rapidly ventilate the space. Whether used by first responders or industrial safety teams, RAMFAN LSVs are designed to meet their rapid response missions with a simple, durable solution that fits the budget.
RAMFAN’s water powered blowers are the first choice of Naval Forces worldwide for smoke
removal, ventilation and equipment cooling.
Safe...
The water powered design eliminates the threat of electrical shock and minimizes explosion potential in dangerous gas environments.Efficient...
RAMFAN’s patented axial flow turbine technology leads the way in efficiently converting water power into high velocity airflow.Better...
The axial turbine is built with corrosion-proof materials for a long lasting life. PowerStream® air straighteners for flexible setback distances.Many water connection fittings available. Call for details.
WF390L
ORDER # WB5001LB, WB5001LNH, WB5001DIN (CCCF)
PPV AIRFLOW
SINGLE DOOR 10,886 cfm @150 psi / 18,506 m³/hr @1.0 MPa
PRESSURE NOMINAL:
MAX: 1.0MPa/150 psi1.7MPa/250 psi
IMPELLER Nominal 16 in / 400 mm, 7-blade
WEIGHT 60 lbs / 27 kg
DIMENSIONS (h/w/d) 22.8 /16.9/16 in / 580/430/410 mm MOTOR 5.2 HP @ 150 psi / 3.8 kw @ 1.0 MPa
WF540
ORDER # WD5010
PPV AIRFLOW
SINGLE DOOR 22,443 cfm @150 psi / 38,154 m³/[email protected]
PRESSURE NOMINAL:
MAX: 1.0MPa/150 psi1.7MPa/250 psi
IMPELLER Nominal 21 in / 540 mm, 7-blade
WEIGHT 75 lbs / 34 kg
Door Hanger Bar & Kit
Our Doorbar and Hanger Kit is easier to use, install and carry. The new adjustable straps on the hangers allow you to position the fan with less lateral movement and greater range of height. Straps connect
to the fan when not in use providing a handy carrying strap. The extended feet on the doorbar fit snug in the door jam for quick, easy set-up.
Order # Description For use with EA7092k Hanger Kit
For all Smoke Ejectors
EA7081 Doorbar
EA7095k Doorbar & Hanger Kit
EA8095K
(Hanger Kit) Hanger Kit EX50Li
Duct
Accessories
Image Disclaimer: We operate a policy of continuous product development. Images used are for illustration purposes only and may not be the latest version of the product.
Conductive Duct
Reinforced, anti-static duct safely conducts static electricity to the ground circuit of the blower. Constructed with flame retardant material and is crush resistant. Duct storage bags available for all
duct sizes. Storage bag included with duct purchase.
Duct bag also sold separately.
Order # Description For use with FDT-0815CBB 8" Conductive Reinforced duct, 15ft,
with storage bag UB20xx
FDT-0825CBB 8" Conductive Reinforced duct, 25ft,
with storage bag UB20xx
FDT-1615CBR 16" Conductive Reinforced duct, 15ft, with storage bag
EFC50x, EF150x, XP400, XP420, XP500, XP520
FDT-1625CBR 16" Conductive Reinforced duct, 25ft, with storage bag
EFC50x, EF150x, XP400, XP420, XP500, XP520
Layflat Duct
Fiber reinforced, collapsible duct.
Order # Description For use with FDT-1625SME 16"/40 cm, 25'/7.6 m (unreinforced) EF390H, EV400, EV420, EX400, EX420, XP400,
XP420, XP500, XP520, EFC50 , EFC150, EFC150x50(x)/120(x)/ 150(x)
FDT-L4X10SME
For use with all 16" (40 cm) fans
16"/40 cm with a 90˚bend (Unreinforced)
Duct Adapter/Reducer
New Adapter/Reducer allows your 18" (46cm) GX/EX blowers to be used with standard ECKO Flex 16" duct. Mounting points integrated into the outer shroud
do not interfere with airflow during normal PPV ops.
During ducted ops, 100% of the airflow is captured to create a high-pressure flow, reducing friction loss through the length of the duct.
Order # Description For use with
GH2211 Compatible with 18"/4.6 cm fan and 16"/40 cm GX310, GX350, EX500, EX520, XP500, XP520, EX50Li EL2211 Hour Meter
Keep track of regular scheduled maintenance (Factory install only)
Order # For use with
GX1515 GF210, GX200L, GX200, GX310, GX350, GX400, GX500, GX600, VX700
BIGbore™ Exhaust Diverter
Hose connects to adapterto divert exhaust away from flowpath.
Order # Description For use with
GF7115 BIGboreHose Assembly (2" dia x 12ft) ™ Exhaust Diverter Gas Fans
GF7110-KZ Add-on DIN std. (No hose) for BIGbore™ Exhaust Diverter GX200L, GX200
GF7120-BZ Add-on DIN std. (No hose) for BIGbore™ Exhaust Diverter GX310, GF165, GF210
GF7120-GZ Add-on DIN std. (No hose) for BIGbore™ Exhaust Diverter GX350, GX400
GF7110-LZ Add-on DIN std. (No hose) for BIGbore™ Exhaust Diverter GX500
Cooling Collars/Misters 16"-40 cm Blowers
Quick and cool rehabiliate with a cooling collar. Fitsaround duct adapter of blower injecting mist into airflow. Designed for use with a garden hose.
Order # Description For use with ED-MIST16 For use with all 16" (40 cm) fans Ramfan 16" Blowers
Standard Duct
Non-collapsible, reinforced duct is constructed from flame retardant material and is crush resistant. Duct storage bag included with each duct purchase.
Duct bag also sold separately.
Order # Description For use with FDT-1615BR 16" Reinforced duct, 15ft, with storage bag
16″ fans or duct adapter
FDT-1625BR 16" Reinforced duct, 25ft, with storage bag
Shoulder Strap
Our convenient strap to carry EX50Li on the shoulders.
Order # Description For use with
EL6013 Shoulder Strap EX50Li
Tilt Bracket
Provides full 360° rotation.
Order # For use with
EA9145 EFC50, EFC50x, EFC120, EFC120x, EFC150x, EFi50xx, EFi120xx, EFi150xx
Duct Adapter/(16"-40 cm)
Connect smoke ejectors to 16" duct.
Order # Description For use with EA7116 ABS Duct Adapter Inlet Side
EFC50, EFC50x, EFC150
EA7117 ABS Duct Adapter Outlet Side
Misting System
1.85 gal/min@100 psi 7 l/[email protected] bar.
Order # Description For use with
EB8111 16" Integrated Mister EV400, EV420, EX400, EX420
GH8112 18" Integrated Mister GX310, GX350, EX500, EX520, XP500, XP520
GE8111 21" Integrated Mister GX400, GF210
GD8111 24" Integrated Mister GX500
GJ8111 28" Integrated Mister GX600
Vehicle Mount
Custom mounts for the perfect fit.
Order # For use with
EL600K EX50Li
40V Battery Packs
Remain cordless & keep ventilating during extended ops. Spare Battery pack (recommend purchasing 2).
Order # For use with R2-360AHU EX50Li
Disposable Duct
Disposable, layflat polyethylene duct. No reinforcement.
Order # For use with
FDT-16DISP 16" fans or duct adapter
Battery Charger
Rapidly charge batteries in apparatus compartment or at the station.
Order # Description
R2C-5500AC Connects to AC Power Source
EX50Li
R2C-5500DC Connects to DC Power Source
Multi-Purpose Accessory Kit
Cooling collar & layflat duct.
Order # For use with
logo on darkbround
Ramfan Brand Logo Specification Sheet
Zurich Bold
Open Sans
Corporate Fonts
CMYK: 0, 0, 0, 0 CMYK: 0, 0, 0, 100 CMYK: 6, 25, 22, 0 CMYK: 18.5, 98.5 82, 8 RGB: 255, 255, 255 RGB: 35, 31, 32 RGB: 232, 192, 182 RGB: 188, 38, 54 Hex # FFFFFF Hex # 231F20 Hex # E8C0B6 Hex # BC2636 Pantone P 1-1 C Pantone P Black C Pantone 489 C Pantone 200 C
Size
Standard Size (w/h): 5in x 0.3in (127 mm x 43 mm) Minimum Size (w/h): 0.875in x 0.3in (22 mm x 7.6 mm)
