Polycon Lite - HDPE A15-B125
About Polycon Water Management
Polycon Water Management specialises in manufacturing, sourcing and the distribution of all types of surface water drainage.
Our unique look at the market ensures we can supply a wide range of surface water solutions to specifiers, architects, engineers and contractors. We are constantly looking to manufacture and source new products in order to satisfy market demands as well keep ahead of market changes. Our design team can provide hydraulic solutions which are innovative and cost effective and we will always offer the correct product and the correct solution.
From our distribution centre in Widnes, Cheshire, we can offer a same or next day service where applicable and our sales team are on hand to offer professional advice where needed.
Polycon is the only distributor in the UK that offers external channel drainage solutions in three different materials – Polymer Concrete, HDPE and GRC as well as Stainless Steel drainage for internal applications.
Urban Range
Polycon’s Urban Range constitutes all types of surface water drainage for domestic applications. Our channels are manufactured in High Density Polyethylene (HDPE), Glass Reinforced (GRC) and Polymer Concrete. Depending on application and preferred use, the three different channel bases will work over all urban and domestic projects. Channels in the Polycon Urban Range are available in 100mm, 150mm and 200mm internal widths as well as various depths. A complete range of accessories is also available with the range.
Benefits of Polymer Concrete
•
High compressive and flexural strength•
Good adhesion to most surfaces•
Good long-term durability with respect to freeze and thaw cycles•
Low permeability to water and aggressive solutions•
Good chemical and corrosion resistance•
LightweightBenefits of Glass Reinforced Concrete
•
Highly durable and safe•
Low maintenance•
High flexural and tensile strength•
Weather and fire resistant•
Economical•
Energy efficientBenefits of High Density Polyethylene (HDPE)
•
Lightweight•
Impact resistant•
Long lasting and weather resistance•
Resistant to mold, mildew, rotting and insects•
Resistant to corrosionPolycon Lite - HDPE
The Polycon Lite is manufactured from High Density Polyethylene (HDPE) which has a high resistance to temperature changes which make it ideal for all types of domestic applications. The robust channel is available with a composite, galvanised or stainless steel slotted grating, or a composite & galvanised steel discreet paveslot grating. A complete set of accessories is available for which ensures an easy and quick installation.
Conformity
•
Manufactured in compliance with ISO 9001:2000•
Certified in compliance with EN1433•
Fully CE certified with declaration of performance certificateApplications
•
Driveways•
Patios•
Garden paths•
Threshold drainage•
Houses•
Playgrounds•
Pool areas•
Pedestrian areas•
GaragesFeatures & Benefits
•
The Polycon Lite has a grating that clicks in and out, no screws required.•
Easy to assemble and lightweight.•
The smooth waterproof surface allows a quick waterflow drainage.•
High mechanical and chemical resistance.•
The external structure with ribs improves the anchoring between concrete and HDPE, and is designed for enhanced strength and rigidity.Load Class A15-B125
Polycon Lite - Channel
Channel Ref Level Invert
Description Lite100—100mm Internal Width
Height Invert Height
Overall Width
Weight KG
Load Class
Vertical Outlet 110mm Vertical outlet Sealing Groove
Channel & Corner Unit
Polycon Lite 100 - Gratings & Accessories
Galvanised /Stainless Steel Slotted
Composite Paveslot Ductile Iron
Narrow Slotted Composite
Slotted Galvanised
Paveslot
Gratings Ref Description Lite100 Gratings
Length Slot Width
Overall Width
Weight KG
Load Class
Locking Type GR.L100.1GS Galvanised Slotted Grating 1000mm 8mm 116mm 0.95g A Snaplock GR.L100.0GS Galvanised Slotted Grating 500mm 8mm 116mm 0.42kg A Snaplock GR.L100.1SSS Stainless Steel Slotted Grating 1000mm 8mm 116mm 0.98kg A Snaplock GR.L100.0SSS Stainless Steel Slotted Grating 500mm 8mm 116mm 0.98kg A Snaplock GR.L100.1CS Composite Slotted Grating 1000mm 8mm 116mm 0.52kg A Snaplock GR.L100.0CS Composite Slotted Grating 500mm 8mm 116mm 0.27kg A Snaplock GR.L100.0DINS Ductile Iron Narrow Slotted Grating 500mm 6mm 116mm 2.75kg A,B Snaplock GR.L100.1CPS Composite Paveslot 60mm Upstand 1000mm 10mm 116mm 1.40kg A,B Snaplock GR.L100.0CPS Composite Paveslot 60mm Upstand 500mm 10mm 116mm 0.35kg A,B Snaplock GR.L100.1GPS Galvanised Paveslot 60mm Upstand 1000mm 10mm 116mm 2.60kg A,B Snaplock GR.L100.0GPS Galvanised Paveslot 60mm Upstand 500mm 10mm 116mm 1.30kg A,B Snaplock
Accessory Ref Description Lite 100 Accessories
H1 Height
Invert Height
Overall Width
Weight KG
Load Class
Outlet Up To Lite.100.Acc.G Lite 100 Access Unit Galvanised Top 150mm n/a 130mm 0.42kg A,B n/a Lite.100.Acc.C Lite 100 Access Unit Composite Top 150mm n/a 130mm 0.40kg A,B n/a Lite.100.Ext Lite 100 Extension Unit 150mm n/a 130mm 0.35kg A,B n/a Lite.100.Sump Lite 100 Sump Unit 340mm 120mm 130mm 0.80g A,B 110mm Lite.100.EC Lite 100 End Cap 80mm n/a 110mm 0.3kg n/a n/a Lite100.ECO Lite 100 End Cap Outlet 80mm n/a 110mm 0.5kg n/a 110mm Lite100.VO Lite 100 Vertical Outlet 110mm n/a 90mm 0.8kg n/a 110mm
Sump Unit
End Cap End Cap Outlet Corner Unit Foul Air Trap
Polycon Lite - Installation Guide
We recommend the Polycon Installation guide is followed when laying channels. Ground conditions must be suitable and all dimensions shown are the minimum requirement. Engineering advice should be taken where necessary and any questions should be directed to Polycon’s technical team [email protected] or call 0151 422 9747.
Load Class A15 B125 C250 D400 E600
H2 - Channel Height 100mm 150mm 150mm 200mm 250mm
Y - Minimum Surround 100mm 150mm 150mm 200mm 250mm
Z - Minimum Surround 100mm 150mm 150mm 200mm 250mm
T1 - Minimum Depth 40mm 40mm 40mm 40mm 40mm
T2 - Maximum Depth 95mm 55mm 55mm 55mm 55mm
1 2 3 4 5 6 ** Minimum Concrete Haunch 25 N/mm2
Detail A
Allow for overbuild of 3mm to 5mm above the grating surface
Concrete Sub Base Earth Concrete
Haunch Sand Layer Expansion Joint
