OXYGEN
WITHOUT
PORTABLE OXYGEN CONCENTRATORS
LIGHTWEIGHT & HANDSFREE
NO CARTS! NO TANKS!
LONG LASTING BATTERY LIFE
FAA APPROVED
At Inova Labs, we develop oxygen products that empower users to lead active lifestyles. This brochure outlines our product family which includes the best-in-class LifeChoice® Activox®
Portable Oxygen Concentrators and the new Activox DUO2® Integrated Oxygen System.
>
STAY ACTIVE
LifeChoice Activox POCs are lightweight, reliable and ready to go — for life with no compromises. All models are tank-free, so there is no waiting to fill and no heavy carts to drag around. LifeChoice Activox POCs are the ideal portable oxygen therapy solution for active lifestyles.
>
BEST-IN-CLASS PORTABILITY
LifeChoice Activox is available in three lightweight models that offer the longest-lasting internal battery available in a POC. Don’t compromise with your oxygen therapy, experience the freedom of true mobility. > Up to 12.5 hours of portability with the
Pro Model.
> All models weigh less than 5 lbs. > No carts or tanks required.
> Provides up to 4 LPMeq PULSE-WAVE®.
> FAA-approved.
> Optional 3-hour external battery available.
Stay Active. Sleep Well.
NO TANKS
NO CARTS
NO DELIVERIES
>
LONGEST BATTERY LIFE AVAILABLE
The Pro Model offers up to 12.5 hours of internal battery life while the 4L Model offers 10.25 hours and the Sport Model up to 5.5 hours. All models can be used while charging at home or on the go with a DC charger.>
LIGHTWEIGHT AND HANDS-FREE
You can enjoy true freedom and mobility with all models. Convertible bag straps allow you to wear the system in multiple ways, giving you hands-free ability to complete more activities with comfort and ease. Plus, there are no heavy carts, tanks or refills to worry about.
>
PERFECT FOR TRAVEL
LifeChoice Activox POCs are FAA-approved for domestic and international airline travel.
>
INNOVATIVE AUTO MODE &
PULSE-WAVE TECHNOLOGY
Every LifeChoice Activox POC features powerful Auto Mode and PULSE-WAVE technologies which work together to keep you saturated around the clock.
Auto Mode detects changes to your breath rate and automatically adjusts the delivery of oxygen, while PULSE-WAVE Technology delivers that oxygen to you in a manner that is congruent with your breath rate so that all of the oxygen dose is received. This type of delivery is gentle and helps minimize uncomfortable side effects associated with other forms of oxygen delivery such as dry nose and nose bleeds.
>
EVERYTHING YOU NEED IN ONE
AFFORDABLE PACKAGE
LifeChoice Activox POCs are reimbursed by Medicare and most private insurance plans. The Standard Package includes all the necessary elements for easy use and portability.
AC Power Supply For charging at home or on the go through a standard wall outlet Standard 7-Foot LongSingle Lumen Nasal Cannula* Accessory Bag‡
To hold power supplies, extra straps and manual LifeChoice Activox
(4L Model Shown) 4-Way Carry Case Use as a backpack, shoulder bag, waist pack or briefcase
Adjustable Straps For use with 4-Way Carry Case
DC Power Supply‡
For charging on the go in a vehicle
1 2 4 5 6 7 3
Standard 3-Year Limited Warranty
(One year warranty for sieve bed, batteries and accessories)
*Nasal cannula may not be included.
†Not included in Standard Package. Sold separately.
‡Not included in Sport Standard Package.
1 2 3 4 5 6 7 Additional External Battery Available†
Feature
Model
4L Pro Sport
Weight 4.8 lbs. 4.3 lbs. 3.9 lbs.
Oxygen
Purity 90% ± 3% Oxygen
Delivery
PULSE-WAVEDelivery
1-4 LPMeq 1-3 LPMeq 1-3 LPMeq
Internal Battery Runtime*
10.25 H @ 1 8.25 H @ 2 5 H @ 3 4 H @ 4
12.5 H @ 1 7.25 H @ 2 6.25 H @ 3
5.5 H @ 1 4 H @ 2 3.25 H @ 3
External Battery Runtime* †
4.75 H @ 1 3.75 H @ 2 2.75 H @ 3 2.25 H @ 4
3 H @ 1 3 H @ 2 2 H @ 3
3 H @ 1 3 H @ 2 2 H @ 3
Charge Time*
4 H Internal 2 H External
4.5 H Internal 3 H External
3 H Internal 3 H External
Average
Sound @ 2 44 dB 46 dB 46 dB
Size 9.05” w x 7.875” h x 4.38” d
Display Type Transflective with Buttons Standard Buttons Standard Buttons
Warranty Standard 3-Year Limited
FAA
Approved
√
√
√
*Hours are approximate and based on breaths per minute.
POC CHARGING
TRANSPORT FRIENDLY
DATA LOGGING
INTEGRATED OXYGEN SYSTEM
>
THE BEST OF HOME AND PORTABLE
OXYGEN IN ONE INTEGRATED SYSTEM
Meet Activox DUO2®, the first fully-integratedstationary and portable oxygen concentrator system. The system combines the benefits of a home-use unit and the best-in-class mobility of a LifeChoice Activox POC into one reliable system with no compromises.
>
A 24-HOUR SOLUTION
With the Activox DUO2 system, you can be ready to go at a moment’s notice. The stationary base charges the POC’s batteries when connected and offers up to 5 LPM continuous flow capacity to support you during sleep. The POC component utilizes PULSE-WAVE Delivery and offers lightweight comfort with up to 12.5 hours of internal battery life.*
Standard 3-Year Limited Warranty
(One year warranty for POC Sieve Bed, POC batteries and accessories)
5
7
Activox DUO2 Stationary Concentrator
LifeChoice Activox POC AC Power Cord Replacement Air Filter LifeChoice Activox External Battery
(Sold Separately)
Maintenance Tool External Battery Crate Tool Holder 5 6 7 2 1 3 4 2 1 6 3 4
>
GRAB-AND-GO FLEXIBILITY
Activox DUO2 features a sleek design that takes up less space within your home while running quietly and efficiently. A retractable handle and large, soft rear wheels make it easy to transport the stationary base from room to room while handles on the side allow for easy lifting into a car. Convertible bag straps on the POC let you enjoy hands-free operation in multiple configurations — even as a backpack.
>
EASY TO USE
Simple controls adjust flow and there are no complicated tanks to attach or fill.
>
COST-EFFECTIVE
Activox DUO2 is Medicare-reimbursed and covered by most private insurance plans.
>
STANDARD PACKAGE
8 8
SPECIFICATIONS
Weight: Stationary: 37.5 lbs. (17kg)
POC: See POC section
Dimensions: 14.2” w x 24.8” h x 14.6”d
(36 cm w x 63 cm h x 37 cm d)
Mode of Stationary: Continuous
Operation: POC: PULSE-WAVE
Flow Setting Stationary: 0 to 5 LPM
Control: POC: See POC section
Oxygen Stationary: 93% (+/-3%)
Concentration: POC: 90% (+/-3%)
Oxygen
Concentration 82% or less
Sensor Alarm:
Average Sound Stationary: 50 dB(A)
Level: POC: 46 dB(A)
Power Supply: 110+/-10% VAC, 60 Hz
(Model 130-001); 220+/-10% VAC, 50 Hz (Model 130-002)
>
TO RECEIVE AN INOVA LABS
OXYGEN CONCENTRATOR:
1. Request a prescription from your doctor that includes the brand name of the product you would like to receive — LifeChoice Activox Portable Oxygen Concentrator or Activox DUO2 Oxygen System.
2. Contact your local provider or find one in your area by calling 1.800.220.0977 or by visiting www.InovaLabs.com.
© 2015 Inova Labs, Inc. All rights reserved. 13M-009 Rev E July 2015
Manufactured & Distributed by Inova Labs
3500 Comsouth Drive, Suite 100, Austin, TX 78744 USA Corporate Office 1.512.617.1700
