CI Class Product Categorization Tier 1 Product Categorization Tier 2 Product Categorization Tier 3 Other attributes to set
CI Type in BMC Remedy Asset Management
Imported by BMC Atrium Discovery and Dependency Mapping Imported by BMC BladeLogic Client Automation Imported by BMC BladeLogic Server Automation
Access router BMC.CORE:BMC_ComputerSystem Network Router Access router PrimaryCapability = "Router" System > Computer System Yes Yes
Access server BMC.CORE:BMC_ComputerSystem Hardware Processing unit Server PrimaryCapability = "Access Server" System > Computer System Yes Yes Yes
Account BMC.CORE:BMC_Account Miscellaneous Service Account Logical Entity > Account
ACD system BMC.CORE:BMC_ComputerSystem Hardware Telecommunication ACD system System > Computer System Yes Yes
Activity BMC.CORE:BMC_Activity Miscellaneous Service Activity Logical Entity > Activity Yes
Admin domain BMC.CORE:BMC_AdminDomain Network System > Admin Domain Yes
AirCard BMC.CORE:BMC_Card Hardware Card AirCard System Component > Card Yes Yes
AIT service BMC.CORE:BMC_BusinessService Miscellaneous Service AIT service Logical Entity > Business Service Yes
AIX virtual system BMC.CORE:BMC_ComputerSystem Hardware Server Yes
Allocated resource BMC.CORE:BMC_ResourceAllocationSettingData Unknown Unknown BMC Discovered Settings > Resource Allocation Setting Data
Analog circuit BMC.CORE:BMC_ConnectivityCollection Hardware Collection > Connectivity Collection Yes
Analog line BMC.CORE:BMC_HardwareSystemComponent Network System Component > Hardware System Yes
Analog telephone modem BMC.CORE:BMC_Equipment Network Modem Analog telephone modem System Component > Hardware System Yes
Analog trunk BMC.CORE:BMC_Equipment Network System Component > Hardware System Yes
Apple®Talk BMC.CORE:BMC_ProtocolEndpoint Miscellaneous Address Apple®Talk ProtocolType = "Apple®Talk" Access Point > Protocol Endpoint Yes
Application BMC.CORE:BMC_Application Software System > Application No
Application infrastructure BMC.CORE:BMC_ApplicationInfrastructure Software System > Application Infrastructure Yes
Application platform BMC.CORE:BMC_ApplicationInfrastructure Software Software application/system Application platform System > Application Infrastructure Yes
Application server BMC.CORE:BMC_ApplicationInfrastructure Hardware Processing unit Server ApplicationInfrastructureType = System > Application Infrastructure Yes
Application service BMC.CORE:BMC_ApplicationService System Service > Application Service Yes
Application system BMC.CORE:BMC_ApplicationSystem Hardware System > Application System Yes
ARIS business process activity BMC.CORE:BMC_Activity Miscellaneous Service Activity Logical Entity > Activity
ATM (network or access point?) BMC.CORE:BMC_ProtocolEndpoint Miscellaneous Address ATM ProtocolType = "ATM" Access Point > Protocol Endpoint Yes
ATM network BMC.CORE:BMC_WAN Network WAN ATM WANType = "ATM" Collection > Wide Area Network (WAN) Yes
ATM port BMC.CORE:BMC_ProtocolEndpoint Miscellaneous Address ATM port Access Point > Protocol Endpoint Yes
Backup and recovery BMC.CORE:BMC_BusinessService Miscellaneous Service Backup and recovery Logical Entity > Business Service Yes
Backup and recovery software BMC.CORE:BMC_Product Software Software application/system Backup and recovery software System Component > Product Yes Yes
Bar code BMC.CORE:BMC_LogicalSystemComponent Software Software application/system Bar code System Component > Product Yes
Bar code fonts BMC.CORE:BMC_Product Software Software application/system Bar code fonts System Component > Product Yes Yes
Barcode scanner BMC.CORE:BMC_Equipment Hardware Peripheral Scanner Equipment > Equipment
Base band modem BMC.CORE:BMC_Equipment Network Modem Base band modem System Component > Hardware System Yes
Battery BMC.CORE:BMC_Equipment Hardware Facilities Battery Equipment > Equipment
BGP (Border Gateway Protocol) BMC.CORE:BMC_ProtocolEndpoint Miscellaneous Address BGP (Border Gateway Protocol) ProtocolType = "BGP" Access Point > Protocol Endpoint Yes
BIOS element BMC.CORE:BMC_BIOS Software BIOS element System Component > BIOS Element Yes Yes Yes
BIOS/Firmware BMC.CORE:BMC_BIOS Software Operating system software BIOS/Firmware System Component > BIOS Element Yes Yes Yes
Blackberry BMC.CORE:BMC_ComputerSystem Hardware Processing unit PDA PrimaryCapability = "Mobile User Device" System > Computer System Yes Yes
Blade server BMC.CORE:BMC_ComputerSystem Hardware Hardware Processing unit PrimaryCapability = "Blade Server" System > Computer System Yes Yes
Blade system BMC.CORE:BMC_ComputerSystem Hardware Hardware Blade system PrimaryCapability = "Blade System" System > Computer System Yes Yes
Block server BMC.CORE:BMC_SoftwareServer Software Software application/system Software Server System > Computer System Yes
Border Gateway Protocol (BGP) BMC.CORE:BMC_ProtocolEndpoint Miscellaneous Address Border Gateway Protocol (BGP) ProtocolType = "BGP" Access Point > Protocol Endpoint Yes
Browser application BMC.CORE:BMC_Product Software Software application/system Browser application System Component > Product Yes Yes Yes
Building BMC.CORE:BMC_Equipment Hardware Facilities Building Equipment > Equipment
Business model BMC.CORE:BMC_BusinessService Miscellaneous Service Business model Logical Entity > Business Service Yes
Business process BMC.CORE:BMC_BusinessProcess Miscellaneous Service Business process Logical Entity > Business Service Yes
Business process server BMC.CORE:BMC_SoftwareServer Software Software application/system Software Server SoftwareServerType = "BusinessProcessServer" System > Computer System Yes
Business service BMC.CORE:BMC_BusinessService Miscellaneous Service Business service Logical Entity > Business Service Yes
Cabinet BMC.CORE:BMC_Chassis Hardware Data center Cabinet System Component > Chassis Yes
Call center speech software BMC.CORE:BMC_Product Software Software license certificate Call center speech software System Component > Product Yes Yes
Call logger system BMC.CORE:BMC_ComputerSystem Hardware Telecommunication Call logger system System > Computer System Yes Yes
Call logging BMC.CORE:BMC_Product Software Software application/system Call logging System Component > Product Yes Yes
Calling card BMC.CORE:BMC_BusinessService Miscellaneous Service Calling card Logical Entity > Business Service Yes
Camera BMC.CORE:BMC_Equipment Hardware Facilities Camera Equipment > Equipment
Camera shelf-mount BMC.CORE:BMC_Equipment Hardware Facilities Camera shelf-mount Equipment > Equipment
Card BMC.CORE:BMC_Card Hardware Card Card CardType = "Other" System Component > Card Yes Yes
CD-ROM drive BMC.CORE:BMC_CDROMDrive Hardware Peripheral CD-ROM drive System Component > CMDROM Drive Yes Yes
CD-ROM tower BMC.CORE:BMC_ComputerSystem Hardware Storage Network Attached Storage System > Computer System Yes Yes
Cell phone BMC.CORE:BMC_ComputerSystem Hardware Telecommunication Cell phone System > Computer System Yes Yes
Central office switch BMC.CORE:BMC_ComputerSystem Hardware Switch Central office switch PrimaryCapability = "Central Office Switch" System > Computer System Yes Yes
Channel attached mainframe BMC.CORE:BMC_ComputerSystem Hardware Storage Channel attached mainframe System > Computer System Yes Yes
Chassis BMC.CORE:BMC_Chassis Hardware System Component > Chassis Yes
Chip BMC.CORE:BMC_Card Hardware Card Chip System Component > Card Yes Yes
Circuit BMC.CORE:BMC_ConnectivityCollection Services Telecom Circuits Collection > Connectivity Collection Yes
Circuit board BMC.CORE:BMC_Card Hardware Card Circuit board System Component > Card Yes Yes
CLNP (Connectionless Network Protocol) BMC.CORE:BMC_ProtocolEndpoint Miscellaneous Address CLNP (Connectionless Network ProtocolType = "CLNP" Access Point > Protocol Endpoint Yes
Cluster node BMC.CORE:BMC_ComputerSystem Hardware Server Cluster node System > Computer System Yes Yes
Cluster resource BMC.CORE:BMC_SystemResource Unknown Unknown BMC Discovered
Cluster virtual server BMC.CORE:BMC_ComputerSystem Hardware Server Cluster virtual server System > Computer System Yes Yes
Clustered application BMC.CORE:BMC_Cluster Unknown Unknown BMC Discovered System > Cluster Yes
Clustered application server BMC.CORE:BMC_Cluster Unknown Unknown BMC Discovered System > Cluster Yes
Clustered file system BMC.CORE:BMC_Cluster Unknown Unknown BMC Discovered System > Cluster Yes
Communication endpoint BMC.CORE:BMC_ProtocolEndpoint Miscellaneous Address Communication endpoint Access Point > Protocol Endpoint Yes
Communication protocol endpoint BMC.CORE:BMC_CommunicationEndpoint Hardware Telecommunication Wireless access point Access Point > Communication Endpoint Yes
Communication server BMC.CORE:BMC_SoftwareServer Software Software application/system Software Server SoftwareServerType = "CommunicationServer" System > Computer System Yes
Communication software BMC.CORE:BMC_Product Software Software application/system Communication software System Component > Product Yes Yes
Compression software BMC.CORE:BMC_Product Software Software application/system Compression software System Component > Product Yes Yes
Computer program BMC.CORE:BMC_Product Software Software application/system Computer program System Component > Product Yes Yes Yes
Computer system BMC.CORE:BMC_ComputerSystem Hardware Processing unit Desktop System > Computer System Yes Yes Yes
This table maps configuration items (CI) found in your environment to the classes available for BMC Atrium CMDB in the Common Data Model. It contains only the information necessary to map a given type of CI. In some cases, this includes attribute values you must set to distinguish the CI from other CIs that are stored in the same class. Last published on January 27, 2011
Conference room BMC.CORE:BMC_PhysicalLocation Reference Configuration Facilities Space Management Logical Entity > Physical Location Yes
Connectivity collection BMC.CORE:BMC_ConnectivityCollection Network Collection > Connectivity Collection Yes
Connectivity segment BMC.CORE:BMC_ConnectivityCollection Network Collection > Connectivity Collection Yes
CONP (Connection-Oriented Network Protocol BMC.CORE:BMC_ProtocolEndpoint Miscellaneous Address CONP (Connection-Oriented Network ProtocolType = "CONP" Access Point > Protocol Endpoint Yes
Consulting BMC.CORE:BMC_BusinessService Miscellaneous Service Consulting Logical Entity > Business Service Yes
Contact management application BMC.CORE:BMC_Product Software Software application/system Contact management application System Component > Product Yes Yes
Copier BMC.CORE:BMC_Printer Hardware Image device Copier PrinterCapability = "Copier" System > Printer Yes (network printers) Yes (local printers)
CPU BMC.CORE:BMC_Processor Hardware Component CPU System Component > Processor Yes Yes Yes
CTI system BMC.CORE:BMC_ComputerSystem Hardware Telecommunication CTI system System > Computer System Yes Yes
Customer relationship management BMC.CORE:BMC_BusinessService Miscellaneous Service Customer relationship management Logical Entity > Business Service Yes
Customer support BMC.CORE:BMC_BusinessService Miscellaneous Service Customer support Logical Entity > Business Service Yes
Data circuit BMC.CORE:BMC_ConnectivityCollection Services Telecom Circuits Collection > Connectivity Collection Yes
Data exchange software BMC.CORE:BMC_Product Software Software application/system Data exchange software System Component > Product Yes Yes
Data switch BMC.CORE:BMC_ComputerSystem Network Switch Data switch PrimaryCapability = "Switch" or "Layer 3 Switch" System > Computer System Yes Yes
Database BMC.CORE:BMC_DataBase Miscellaneous Instance Database Logical Entity > Database Yes
Database server BMC.CORE:BMC_SoftwareServer Software Software application/system Software Server SoftwareServerType = "DatabaseServer" System > Computer System Yes
Database software BMC.CORE:BMC_Product Software Software application/system Database software System Component > Product Yes Yes
Database storage BMC.CORE:BMC_DataBaseStorage Hardware Storage Database storage System Component > Database Storage Yes
Database system BMC.CORE:BMC_ApplicationInfrastructure Hardware ApplicationInfrastructureType = System > Application Infrastructure Yes
DECnet BMC.CORE:BMC_ProtocolEndpoint Miscellaneous Address DECnet ProtocolType = "DECnet" Access Point > Protocol Endpoint Yes
Dedicated circuit BMC.CORE:BMC_ConnectivityCollection Services Telecom Circuits Collection > Connectivity Collection Yes
Department building BMC.CORE:BMC_PhysicalLocation Reference Configuration Facilities Space Management Logical Entity > Physical Location Yes
Desktop computer BMC.CORE:BMC_ComputerSystem Hardware Processing unit Desktop PrimaryCapability = "Workstation" System > Computer System Yes Yes Yes
Desktop productivity BMC.CORE:BMC_BusinessService Miscellaneous Service Desktop productivity Logical Entity > Business Service Yes
Dictaphone BMC.CORE:BMC_ComputerSystem Hardware Telecommunication Dictaphone System > Computer System Yes Yes
Digital line BMC.CORE:BMC_ConnectivityCollection Hardware Collection > Connectivity Collection Yes
Digital scanner BMC.CORE:BMC_Equipment Hardware Peripheral Scanner Equipment > Equipment
Digitizing pad BMC.CORE:BMC_PointingDevice Hardware Peripheral Digitizing pad System Component > Pointing Device Yes
Direct circuit BMC.CORE:BMC_ConnectivityCollection Services Telecom Circuits Collection > Connectivity Collection Yes
Directory server BMC.CORE:BMC_SoftwareServer Software Software application/system Software Server System > Computer System Yes
Disk BMC.CORE:BMC_HardwareSystemComponent Hardware Peripheral Disk System Component > Hardware System Yes
Disk array BMC.CORE:BMC_ComputerSystem Hardware Disk device Disk array PrimaryCapability = "Storage," System > Computer System Yes Yes
Disk controller BMC.CORE:BMC_HardwareSystemComponent Hardware Disk device Disk controller System Component > Hardware System Yes
Disk drive BMC.CORE:BMC_DiskDrive Hardware Disk device Disk drive System Component > Disk Drive Yes Yes Yes
Disk partition BMC.CORE:BMC_DiskPartition Hardware Disk device Disk partition System Component > Disk Partition Yes
Disk storage BMC.CORE:BMC_Chassis Hardware Storage Disk storage System Component > Chassis Yes
Display screen BMC.CORE:BMC_Monitor Hardware Telecommunication Display screen System Component > Monitor Yes Yes
DMA channel BMC.CORE:BMC_SystemResource System Component > System Resource Yes
DNS server BMC.CORE:BMC_SoftwareServer Software Software application/system Software Server SoftwareServerType = "DNSServer" System > Computer System Yes
Docking station BMC.CORE:BMC_HardwareSystemComponent Hardware Peripheral Docking station System Component > Hardware System Yes
Documentation BMC.CORE:BMC_Document Miscellaneous Documentation Documentation Document > Document
Driver BMC.CORE:BMC_SystemSoftware Software System Component > System Software Yes
DSL modem BMC.CORE:BMC_Equipment Network Modem DSL modem System Component > Hardware System Yes
Electronic conferencing BMC.CORE:BMC_BusinessService Miscellaneous Service Electronic conferencing Logical Entity > Business Service Yes
Email BMC.CORE:BMC_BusinessService Miscellaneous Service Email Logical Entity > Business Service Yes
Emergency power generator BMC.CORE:BMC_Equipment Hardware Power Supply Generator Equipment > Equipment
Employee BMC.Core:BMC_Person Miscellaneous Service Employee Yes
Employee provisioning BMC.CORE:BMC_BusinessService Miscellaneous Service Employee provisioning Logical Entity > Business Service Yes
ERP basis BMC.CORE:BMC_BusinessService Miscellaneous Service ERP basis Logical Entity > Business Service Yes
Ethernet BMC.CORE:BMC_LAN Network LAN Ethernet Collection > Connectivity Collection Yes
Extender BMC.CORE:BMC_ComputerSystem Network Hub Extender PrimaryCapability = "Bridge/Extender" System > Computer System Yes Yes
Facility BMC.CORE:BMC_Equipment Hardware Facilities Facility Equipment > Equipment
Facility item BMC.CORE:BMC_Equipment Hardware Facilities Facility item Equipment > Equipment
Fax machine BMC.CORE:BMC_Equipment Hardware Telecommunication Fax PrinterCapability = "Fax" Equipment > Equipment
FDDI BMC.CORE:BMC_ConnectivitySegment Network Segment FDDI ConnectivityType="FDDI" Collection > Connectivity Collection Yes
Fiber channel BMC.CORE:BMC_ComputerSystem Network Switch Fiber channel PrimaryCapability = "SANSwitch" System > Computer System Yes Yes
Fiber channel array BMC.CORE:BMC_ComputerSystem Hardware Storage Fiber channel array System > Computer System Yes Yes
Fiber optic modem BMC.CORE:BMC_Equipment Network Modem Fiber optic modem System Component > Hardware System Yes
File BMC.CORE:BMC_Share System Component > Share
File & Print BMC.CORE:BMC_BusinessService Miscellaneous Service File & Print Logical Entity > Business Service Yes
File server BMC.CORE:BMC_ComputerSystem Hardware Processing unit File server PrimaryCapability = "File Server" System > Computer System Yes Yes Yes
Finance BMC.CORE:BMC_BusinessService Miscellaneous Service Finance Logical Entity > Business Service Yes
Financial planning application BMC.CORE:BMC_Product Software Software application/system Financial planning application System Component > Product Yes Yes
Floppy drive BMC.CORE:BMC_FloppyDrive Hardware Peripheral Floppy drive System Component > Floppy Drive Yes Yes
Folder BMC.CORE:BMC_Share System Component > Share
Frame relay BMC.CORE:BMC_ProtocolEndpoint Miscellaneous Address Frame relay ProtocolType = "Frame Relay" Access Point > Protocol Endpoint Yes
Frame relay circuit BMC.CORE:BMC_ConnectivityCollection Hardware Collection > Connectivity Collection Yes
Frame relay network BMC.CORE:BMC_WAN Network WAN Frame relay WANType = "Frame Relay" Collection > Wide Area Network (WAN) Yes
FTP server BMC.CORE:BMC_SoftwareServer Software Software application/system Software Server SoftwareServerType = "FTPServer" System > Computer System Yes
Gateway BMC.CORE:BMC_ComputerSystem Hardware Telecommunication Gateway PrimaryCapability = "Gateway" System > Computer System Yes Yes
Generator BMC.CORE:BMC_Equipment Hardware Power Supply Generator Equipment > Equipment
Hard disk BMC.CORE:BMC_Media Hardware System Component > Media Yes
Hardware rack component BMC.CORE:BMC_Rack Hardware System Component > Rack
Hosting board BMC.CORE:BMC_Card Hardware Card Hosting board System Component > Card Yes Yes
Human resource BMC.CORE:BMC_BusinessService Miscellaneous Service Human resource Logical Entity > Business Service Yes
HVAC BMC.CORE:BMC_Equipment Hardware Facilities HVAC Equipment > Equipment
Infrastructure application BMC.CORE:BMC_Application Software ApplicationType = "InfrastructureApplication" System > Application No
Installation manual BMC.CORE:BMC_Document Miscellaneous Documentation Installation manual Document > Document
Interactive voice response system (IVR) BMC.CORE:BMC_Product Software Software application/system IVR System Component > Product Yes Yes
Internal storage BMC.CORE:BMC_Memory Hardware System Component > Memory Yes
Internet access BMC.CORE:BMC_BusinessService Miscellaneous Service Internet access Logical Entity > Business Service Yes
IP address BMC.CORE:BMC_IPEndpoint Network Address IP address Access Point > IP Endpoint Yes Yes Yes
IP connectivity subnet BMC.CORE:BMC_ConnectivityCollection Network Collection > Connectivity Collection Yes
IP phone BMC.CORE:BMC_ComputerSystem Hardware Telecommunication IP Phone PrimaryCapability = "IP phone" System > Computer System Yes Yes
iPOD BMC.CORE:BMC_Equipment Hardware Telecommunication Telephone Equipment > Equipment
IPX connectivity network BMC.CORE:BMC_ConnectivityCollection Network Collection > Connectivity Collection Yes
IPX network number BMC.CORE:BMC_IPXConnectivityNetwork Network Collection > IPX Connectivity Network
ISDN modem BMC.CORE:BMC_Equipment Network Modem ISDN modem System Component > Hardware System Yes
ITIL Change Management BMC.CORE:BMC_BusinessProcess Miscellaneous Service ITIL Change Management Logical Entity > Business Service Yes
ITIL Incident Management BMC.CORE:BMC_BusinessProcess Miscellaneous Service ITIL Incident Management Logical Entity > Business Service Yes
IVR (Interactive Voice Response) BMC.CORE:BMC_Product Software Software application/system IVR System Component > Product Yes Yes
Keyboard BMC.CORE:BMC_Keyboard Hardware Peripheral Keyboard System Component > Keyboard Yes
Label software BMC.CORE:BMC_Product Software Software application/system Label software System Component > Product Yes Yes
LAN BMC.CORE:BMC_LAN Network LAN Ethernet Collection > Local Area Network (LAN) Yes
LAN endpoint BMC.CORE:BMC_ProtocolEndpoint Miscellaneous Address MAC Address Access Point > Protocol Endpoint Yes
LAN segment BMC.CORE:BMC_ConnectivitySegment Network Segment Unknown, Other, Ethernet, TokenRing, Collection > Connectivity Segment Yes
Laptop computer BMC.CORE:BMC_ComputerSystem Hardware Processing unit Laptop PrimaryCapability = "Workstation" System > Computer System Yes Yes Yes
Layer 3 switch BMC.CORE:BMC_ComputerSystem Network Switch Data switch PrimaryCapability = "Layer 3 switch" System > Computer System Yes Yes
LDAP server BMC.CORE:BMC_SoftwareServer Software Software application/system Software Server SoftwareServerType = "LDAPServer" System > Computer System Yes
Line BMC.CORE:BMC_ConnectivityCollection Services Telecom Line Collection > Connectivity Collection Yes
LNs collection BMC.CORE:BMC_ConnectivityCollection Network Collection > Connectivity Collection Yes
Load balancer BMC.CORE:BMC_ComputerSystem Hardware PrimaryCapability = "LoadBalancer" System > Computer System Yes Yes
Local area network BMC.CORE:BMC_LAN Network LAN Ethernet Collection > Local Area Network (LAN) Yes
Local file system BMC.CORE:BMC_LocalFileSystem System Component > Local File System Yes Yes
Local printer BMC.CORE:BMC_Printer Hardware Peripheral Local printer System > Printer Yes (network printers) Yes (local printers)
Logical network (LN) BMC.CORE:BMC_LNsCollection Network Collection > LNs Collection Yes
Logical partition (LPAR) BMC.CORE:BMC_ComputerSystem Hardware Virtual systems LPAR VirtualSystemType = "LPAR", isVirtual = "Yes" System > Virtual System Yes Yes
Logistics BMC.CORE:BMC_BusinessService Miscellaneous Service Logistics Logical Entity > Business Service Yes
LPAR (logical partition) BMC.CORE:BMC_ComputerSystem Hardware Virtual systems LPAR VirtualSystemType = "LPAR", isVirtual = "Yes" System > Virtual System Yes
MAC address BMC.CORE:BMC_LANEndpoint Network Address MAC address Access Point > LAN Endpoint Yes
Mail server BMC.CORE:BMC_SoftwareServer Software Software application/system Software Server SoftwareServerType = "MailServer" System > Computer System Yes
Mainframe partition BMC.CORE:BMC_ComputerSystem Hardware Virtual systems Mainframe partition VirtualSystemType = "LPAR", isVirtual = "Yes" System > Computer System Yes Yes
Mainframe virtual system BMC.CORE:BMC_ComputerSystem Software Virtual Systems Mainframe Yes Yes
Mainframe virtual system enabler BMC.CORE:BMC_ComputerSystem Software Virtual Systems Mainframe Yes Yes
Maintenance tool BMC.CORE:BMC_Equipment Hardware Equipment > Equipment
Manufacturing BMC.CORE:BMC_BusinessService Miscellaneous Service Manufacturing Logical Entity > Business Service Yes
Memory BMC.CORE:BMC_Memory Hardware Component Memory System Component > Memory Yes Yes
Memory-mapped I/O BMC.CORE:BMC_SystemResource System Component > System Resource Yes
Message queue BMC.CORE:BMC_SystemResource System Component > System Resource Yes
Message server BMC.CORE:BMC_SoftwareServer Software Software application/system Software Server SoftwareServerType = "MessageServer" System > Computer System Yes
Microsoft® Windows NT network BMC.CORE:BMC_NTDomain Network System > NT Domain Yes
Mobile user device BMC.CORE:BMC_ComputerSystem Hardware Personal computer PDA PrimaryCapability = "Mobile User Device" System > Computer System Yes Yes
Modular switching system BMC.CORE:BMC_ComputerSystem Hardware Telecommunication PBX System > Computer System Yes Yes
Monitor BMC.CORE:BMC_Monitor Hardware Peripheral Monitor System Component > Monitor Yes Yes
Monitor wall-mount BMC.CORE:BMC_Equipment Hardware Telecommunication Video Conferencing equipment Equipment > Equipment
Monitoring appliance BMC.CORE:BMC_ComputerSystem Hardware Peripheral Monitoring appliance System > Computer System Yes Yes
Motherboard BMC.CORE:BMC_Card Hardware Card Motherboard System Component > Card Yes Yes
Mouse BMC.CORE:BMC_PointingDevice Hardware Peripheral Mouse System Component > Pointing Device Yes
Multi-function device BMC.CORE:BMC_Printer Hardware Peripheral Multi-function device PrinterCapability = "Multi-function device" System > Printer Yes (network printers) Yes (local printers)
Multimedia cart BMC.CORE:BMC_Equipment Hardware Telecommunication Video Conferencing equipment Equipment > Equipment
Multimedia messaging system BMC.CORE:BMC_Equipment Hardware Telecommunication Voice Mail System Equipment > Equipment
Music on hold system BMC.CORE:BMC_ComputerSystem Hardware Telecommunication Music on hold system System > Computer System Yes Yes
Named pipe BMC.CORE:BMC_SystemResource System Component > System Resource Yes
Network BMC.CORE:BMC_BusinessService Miscellaneous Service Network Logical Entity > Business Service Yes
Network attached storage BMC.CORE:BMC_ComputerSystem Hardware Storage Network attached storage System > Computer System Yes Yes
Network interface BMC.CORE:BMC_NetworkPort Hardware System Component > Network Port Yes Yes
Network interface card BMC.CORE:BMC_NetworkPort Hardware Card Network interface card System Component > Network Port Yes Yes Yes
Network management software BMC.CORE:BMC_Product Software Software application/system Network management software System Component > Product Yes Yes
Network port BMC.CORE:BMC_NetworkPort Network System Component > Hardware System Yes Yes
Network printer BMC.CORE:BMC_Printer Hardware Peripheral Network printer PrinterCapability = "Network printer" System > Printer Yes (network printers) Yes (local printers)
News server BMC.CORE:BMC_SoftwareServer Software Software application/system Software Server SoftwareServerType = "NewsServer" System > Computer System Yes
Non-windows workstation BMC.CORE:BMC_ComputerSystem Hardware Personal computer Non-windows workstation System > Computer System Yes Yes Yes
NT domain BMC.CORE:BMC_AdminDomain Network System > NT Domain Yes
Online documentation BMC.CORE:BMC_Document Miscellaneous Documentation Online documentation Document > Document
Operating system BMC.CORE:BMC_OperatingSystem Software Operating system software Operating system System Component > Operating System Yes Yes
Order processing BMC.CORE:BMC_BusinessService Miscellaneous Service Order processing Logical Entity > Business Service Yes
Package BMC.CORE:BMC_Package Software Software distribution Package System Component > Package Yes
Pager BMC.CORE:BMC_ComputerSystem Hardware Telecommunication Pager System > Computer System Yes Yes
Palm BMC.CORE:BMC_ComputerSystem Hardware Personal computer PDA System > Computer System Yes Yes
Patch BMC.CORE:BMC_Patch Software Software application/system Patch System Component > Patch Yes Yes
Patch panel BMC.CORE:BMC_HardwareSystemComponent Hardware Data center Patch panel System Component > Hardware System Yes
Payroll BMC.CORE:BMC_BusinessService Miscellaneous Service Payroll Logical Entity > Business Service Yes
PBX (Voice switch) BMC.CORE:BMC_HardwareSystemComponent Network Switch Voice switch System Component > Hardware System Yes
PDA (personal digital assistant) BMC.CORE:BMC_ComputerSystem Hardware Processing unit PDA PrimaryCapability = "Mobile User Device" System > Computer System Yes Yes
PDU BMC.CORE:BMC_ComputerSystem Hardware Image device PDU System > Computer System Yes Yes
Personal digital assistant (PDA) BMC.CORE:BMC_ComputerSystem Hardware Processing unit PDA PrimaryCapability = "Mobile User Device" System > Computer System Yes Yes
Personal printer BMC.CORE:BMC_Printer Hardware Peripheral Personal printer PrinterCapability = "Personal printer" System > Printer Yes (network printers) Yes
Personal router BMC.CORE:BMC_ComputerSystem Hardware Router Personal router System > Computer System Yes Yes
Physical cluster BMC.CORE:BMC_Cluster Hardware PrimaryCapability = "Physical Cluster" System > Cluster Yes
Physical location BMC.CORE:BMC_PhysicalLocation Reference Configuration Facilities Space Management Logical Entity > Physical Location Yes
Pocket PC BMC.CORE:BMC_ComputerSystem Hardware Personal computer PDA System > Computer System Yes Yes
Pointing device BMC.CORE:BMC_PointingDevice Hardware Peripheral Mouse System Component > Hardware System Yes
Port router BMC.CORE:BMC_ComputerSystem Hardware Router Port router System > Computer System Yes Yes
Print server BMC.CORE:BMC_SoftwareServer Software Software application/system Software Server SoftwareServerType = "PrintServer" System > Computer System Yes
Printer BMC.CORE:BMC_Printer Hardware Peripheral Printer PrimaryCapability = "Print" System > Printer Yes (network printers) Yes (local printers)
Process document BMC.CORE:BMC_Document Miscellaneous Documentation Process document Document > Document
Processing node BMC.CORE:BMC_Chassis Hardware System Component > Chassis Yes
Processor BMC.CORE:BMC_Processor Hardware Processing unit Processor System Component > Hardware System Yes Yes Yes
Product BMC.CORE:BMC_Product Software Software application/system Product System Component > Product Yes Yes
Production printer BMC.CORE:BMC_Printer Hardware Peripheral Production printer PrinterCapability = "Production printer" System > Printer Yes (network printers) Yes (local printers)
Projector BMC.CORE:BMC_Equipment Hardware Peripheral Projector DisplayType = "Projector" Equipment > Equipment
Protocol endpoint BMC.CORE:BMC_ProtocolEndpoint Miscellaneous Address Protocol endpoint Access Point > Protocol Endpoint Yes
Quality control BMC.CORE:BMC_BusinessService Miscellaneous Service Quality control Logical Entity > Business Service Yes
Rack BMC.CORE:BMC_Chassis Hardware Data center Rack System Component > Chassis Yes
Rack mount monitor BMC.CORE:BMC_Monitor Hardware Peripheral Rack mount monitor System Component > Monitor Yes Yes
Raid array BMC.CORE:BMC_ComputerSystem Hardware Storage Raid array System > Computer System Yes Yes
RAID storage device BMC.CORE:BMC_ComputerSystem Hardware Storage RAID storage device PrimaryCapability = "RAIDStorageDevice" System > Computer System Yes Yes
Remote access server BMC.CORE:BMC_ComputerSystem Network Router Remote access server PrimaryCapability = "Router" System > Computer System Yes Yes
Remote file system BMC.CORE:BMC_RemoteFileSystem System Component > Remote File System Yes
Reporting BMC.CORE:BMC_Product Software Software application/system Reporting System Component > Product Yes Yes
Resource planning application BMC.CORE:BMC_Product Software Software application/system Resource planning application System Component > Product Yes Yes
Resource pool BMC.CORE:BMC_ResourcePool Unknown Unknown BMC Discovered System Component > BMC Resource Pool
Resource server BMC.CORE:BMC_SoftwareServer Software Software application/system Software Server SoftwareServerType = "ResourceServer" System > Computer System Yes
Role BMC.CORE:BMC_Role Collection > Role Yes
Sales tracking BMC.CORE:BMC_BusinessService Miscellaneous Service Sales tracking Logical Entity > Business Service Yes
Scanner BMC.CORE:BMC_Equipment Hardware Peripheral Scanner Equipment > Equipment
Scheduling software BMC.CORE:BMC_Product Software Software application/system Scheduling software System Component > Product Yes Yes
Search engine software BMC.CORE:BMC_Product Software Software application/system Search engine software System Component > Product Yes Yes
Secure shell server BMC.CORE:BMC_SoftwareServer Software Software application/system Software Server SoftwareServerType = "SecureShellServer" System > Computer System Yes Security server BMC.CORE:BMC_SoftwareServer Software Software application/system Software Server SoftwareServerType = "SecurityServer" System > Computer System Yes
Security software BMC.CORE:BMC_Product Software Software application/system Security software System Component > Product Yes Yes
Self-service help desk BMC.CORE:BMC_BusinessService Miscellaneous Service Self-service help desk Logical Entity > Business Service Yes
Server BMC.CORE:BMC_ComputerSystem Hardware Processing unit Server PrimaryCapability = "Server" System > Computer System Yes Yes Yes
Service management BMC.CORE:BMC_BusinessService Miscellaneous Service Service management Logical Entity > Business Service Yes
Share BMC.CORE:BMC_LogicalSystemComponent System Component > Logical System Yes
Shared memory segment BMC.CORE:BMC_SystemResource System Component > System Resource Yes
Siebel Enterprise BMC.CORE:BMC_ApplicationInfrastructure Software ApplicationInfrastructureType = "SiebelEnterprise" System > Application Infrastructure Yes
Sign board BMC.CORE:BMC_Monitor Hardware Telecommunication Sign board System Component > Monitor Yes Yes
SIM card BMC.CORE:BMC_Card Hardware Card SIM card System Component > Card Yes Yes
SMDS network BMC.CORE:BMC_WAN Network WAN SMDS WANType = "SMDS" Collection > Wide Area Network (WAN) Yes
Software BMC.CORE:BMC_Product Software Software application/system Software System Component > Product Yes Yes
Software development software BMC.CORE:BMC_Product Software Software application/system Software development software System Component > Product Yes Yes
Software patch BMC.CORE:BMC_Patch Software Software application/system Patch System Component > Patch Yes Yes
Software server BMC.CORE:BMC_SoftwareServer Software Software application/system Software Server System > Computer System Yes
Software suite BMC.CORE:BMC_Product Software Software application/system Software suite System Component > Product Yes Yes
Solaris virtual system BMC.CORE:BMC_ComputerSystem Hardware Server Yes Yes
Standard application BMC.CORE:BMC_Application Software ApplicationType = "StandardApplication" System > Application
Standard operating system BMC.CORE:BMC_OperatingSystem Software Operating system software Standard operating system System Component > Operating System Yes Yes Yes
Subnet BMC.CORE:BMC_IPConnectivitySubnet Network Subnet TCP/IP Collection > IP Connectivity Subnet Yes
System management software BMC.CORE:BMC_Product Software Software application/system System management software System Component > Product Yes Yes
System software BMC.CORE:BMC_SystemSoftware Software System Component > System Software Yes
Tape BMC.CORE:BMC_Media Hardware System Component > Media Yes
Tape array BMC.CORE:BMC_HardwareSystemComponent Hardware Tape device Tape array System Component > Hardware System Yes
Tape controller BMC.CORE:BMC_HardwareSystemComponent Hardware Tape device Tape controller System Component > Hardware System Yes
Tape device BMC.CORE:BMC_TapeDrive Hardware Tape device Tape device System Component > Tape Drive Yes
Tape drive BMC.CORE:BMC_TapeDrive Hardware Tape device Tape drive System Component > Tape Drive Yes
Tape library BMC.CORE:BMC_ComputerSystem Hardware PrimaryCapability = "TapeLibrary" System > Computer System Yes Yes
Tape robot BMC.CORE:BMC_HardwareSystemComponent Hardware Tape device Tape robot System Component > Hardware System Yes
Tape storage BMC.CORE:BMC_Chassis Hardware Storage Tape storage System Component > Chassis Yes
Technical manual BMC.CORE:BMC_Document Miscellaneous Documentation Technical manual Document > Document
Telephone BMC.CORE:BMC_Equipment Hardware Telecommunication Telephone Equipment > Equipment
Telnet server BMC.CORE:BMC_SoftwareServer Software Software application/system Software Server SoftwareServerType = "TelnetServer" System > Computer System Yes
Terminal BMC.CORE:BMC_HardwareSystemComponent Hardware Peripheral Terminal System Component > Hardware System Yes
Terminal server BMC.CORE:BMC_ComputerSystem Hardware Processing unit Server PrimaryCapability = "Terminal server" System > Computer System Yes Yes
Token ring BMC.CORE:BMC_ConnectivitySegment Network Segment Token ring ConnectivityType="TokenRing" Collection > Connectivity Collection Yes
Touch pad BMC.CORE:BMC_PointingDevice Hardware Peripheral Touch pad System Component > Pointing Device Yes
Track ball BMC.CORE:BMC_PointingDevice Hardware Peripheral Track ball System Component > Pointing Device Yes
Transaction definition BMC.CORE:BMC_Transaction
Transaction server BMC.CORE:BMC_SoftwareServer Software Software application/system Software Server SoftwareServerType = "TransactionServer" System > Computer System Yes
Uninterrupted power supply BMC.CORE:BMC_UPS Hardware Power Supply Uninterrupted power supply System Component > UPS Yes
UNIX BMC.CORE:BMC_ComputerSystem Hardware Processing unit Server System > Computer System Yes Yes Yes
UNIX server BMC.CORE:BMC_ComputerSystem Hardware Processing unit Server System > Computer System Yes Yes Yes
UPS BMC.CORE:BMC_UPS Hardware Network Infrastructure UPS System Component > UPS Yes
User manual BMC.CORE:BMC_Document Miscellaneous Documentation User manual Document > Document
User productivity application BMC.CORE:BMC_Product Software Software application/system User productivity application System Component > Product Yes Yes
Vehicle BMC.CORE:BMC_Equipment Hardware Equipment > Equipment
Video card BMC.CORE:BMC_Card Hardware Card Video card CardType = "VideoCard" System Component > Card Yes Yes
Video circuit BMC.CORE:BMC_ConnectivityCollection Services Telecom Circuits Collection > Connectivity Collection Yes
Video conferencing BMC.CORE:BMC_BusinessService Miscellaneous Service Video conferencing Logical Entity > Business Service Yes
Video conferencing equipment BMC.CORE:BMC_Equipment Hardware Telecommunication Video conferencing equipment Equipment > Equipment
Video processor BMC.CORE:BMC_Processor Hardware Component Video processor ProcessorFamily = "Video processor" System Component > Processor Yes Yes
Viewer application BMC.CORE:BMC_Product Software Software application/system Viewer application System Component > Product Yes Yes
Virtual cluster BMC.CORE:BMC_Cluster Hardware Virtual systems Cluster (virtual) PrimaryCapability = "Virtual Cluster" System > Cluster Yes
Virtual server BMC.CORE:BMC_ComputerSystem Hardware Processing unit Server System > Computer System Yes Yes
Virtual system BMC.CORE.BMC_ComputerSystem Reference Configuration Server Virtual system System > Virtual System Yes Yes Yes
Virtual system configuration BMC.CORE:BMC_VirtualSystemSettingData Unknown Unknown BMC Discovered Settings > Virtual System Setting Data Yes Yes
Virtual system enabler BMC.CORE:BMC_VirtualSystemEnabler Reference Configuration System Component > Virtual System Enabler Yes
Virtualization operating system BMC.CORE.BMC_VirtualSystemEnabler Software Operating system software Virtualization operating system System Component > Virtual System Enabler Yes
VM BMC.CORE:BMC_VirtualSystemEnabler Reference Configuration Business service management VM System Component > Virtual System Enabler Yes
VMWare image BMC.CORE:BMC_ComputerSystem Hardware Server VMWare image VirtualSystemType = "VMWare", isVirtual = "Yes" System > Computer System Yes Yes
VMWare virtual host BMC.CORE:BMC_ComputerSystem Hardware Server VMWare virtual host System > Computer System Yes Yes Yes
VMWare virtual machine BMC.CORE:BMC_ComputerSystem Hardware Server System > Computer System Yes Yes Yes
Voice card BMC.CORE:BMC_Card Hardware Card Voice card CardType = "SoundCard" System Component > Card Yes Yes
Voice mail system BMC.CORE:BMC_ComputerSystem Hardware Telecommunication Voice mail system System > Computer System Yes Yes
Voice switch (PBX) BMC.CORE:BMC_HardwareSystemComponent Network Switch Voice switch System Component > Hardware System Yes
VPN BMC.CORE:BMC_ConnectivitySegment Network Segment Unknown, Other, Ethernet, TokenRing, Collection > Connectivity Segment Yes
WAN BMC.CORE:BMC_WAN Network WAN General? WANType = "Unknown" Collection > Wide Area Network (WAN) Yes
Warehouse management BMC.CORE:BMC_BusinessService Miscellaneous Service Warehouse management Logical Entity > Business Service Yes
Web conferencing BMC.CORE:BMC_BusinessService Services Telecom Web Conferencing Logical Entity > Business Service Yes
Web server BMC.CORE:BMC_SoftwareServer Software Software application/system Software Server SoftwareServerType = "WEBServer" System >Computer System Yes
Web server software BMC.CORE:BMC_Product Software Software application/system Web server software System Component > Product Yes Yes
Web services server BMC.CORE:BMC_SoftwareServer Software Software application/system Software Server SoftwareServerType = "WebServicesServer" System >Computer System Yes
Web site BMC.CORE:BMC_LogicalSystemComponent Miscellaneous Instance Web site System Component > Logical System Yes
Wide area network BMC.CORE:BMC_WAN Network WAN General? WANType = "Unknown" Collection > Wide Area Network (WAN) Yes
Windows server BMC.CORE:BMC_ComputerSystem Hardware Processing unit Server System >Computer System Yes Yes Yes
Wireless access point BMC.CORE:BMC_CommunicationEndpoint Hardware Telecommunication Wireless access point Access Point > Communication Endpoint Yes
Wireless card BMC.CORE:BMC_Card Hardware Card Wireless card CardType = "WirelessCard" System Component > Card Yes Yes
Wireless SIM card BMC.CORE:BMC_Card Hardware Card Wireless SIM card CardType = "WirelessSIMCard" System Component > Card Yes Yes
Workstation BMC.CORE:BMC_ComputerSystem Hardware Peripheral Workstation PrimaryCapability = "Workstation" System > Computer System Yes Yes
X.25 network BMC.CORE:BMC_WAN Network WAN X.25 WANType = "X.25" Collection > Wide Area Network (WAN) Yes
CDM 7.6.04 relationship class Name attribute value Source CI class Destination CI class Attribute Constraints or Notes
BMC_ApplicationSystemServices APPLICATIONSYSTEMSERVICES BMC_ApplicationSystem BMC_SystemService BMC_Component CONTAINEDDOMAIN BMC_AdminDomain BMC_AdminDomain BMC_Component COMPONENT BMC_BaseElement BMC_BaseElement BMC_Component DATABASEDATASTORAGE BMC_DataBase BMC_DataBaseStorage BMC_Component CLUSTEREDSYSTEM BMC_Cluster BMC_ComputerSystem
BMC_Component SUBHWCOMPONENT BMC_HardwarePackage BMC_HardwareSystemComponent BMC_Component PRODUCTINPACKAGE BMC_Package BMC_Product
BMC_Component PRODUCTPATCH BMC_Software BMC_Patch
BMC_Component HOSTEDRESOURCEPOOL BMC_System BMC_ResourcePool BMC_Component RESOURCEOFGROUP BMC_SystemResource BMC_SystemResource
BMC_ Component ROCONTRACTSASROLINE BMC_RequestableOffering BMC_ContractLine Destination.ContractLineType="RequestOfferingLine"
BMC_ Component SOCONTRACTSASSOLINE BMC_ServiceOffering BMC_ContractLine Destination.ContractLineType="ServiceOfferingLine"
BMC_ Component SOLINEISPARENTOFROLINE BMC_ContractLine BMC_ContractLine Source.ContractLineType="ServiceOfferingLine" AND Destination.ContractLineType="RequestOfferingLine"
BMC_ Component OFFERINGPRICE BMC_Offering BMC_Price
BMC_ Component OFFERINGCOST BMC_Offering BMC_Cost BMC_ Component OFFERINGOPTION BMC_Offering BMC_Option BMC_ Component OPTIONCOMPRISEDOFOPTIPONCHOICE BMC_Option BMC_OptionChoice
BMC_ Component OPTIONLINERECORDSOPTIONCHOICE BMC_OptionChoice BMC_ContractLine Destination.ContractLineType="SelectedOptionLine" BMC_ Component OPTIONCHOICECOST BMC_OptionChoice BMC_Cost
BMC_ Component OPTIONCHOICEPRICE BMC_OptionChoice BMC_Price
BMC_ Component OPTIONLINEPARTOFSOLINE BMC_ContractLine BMC_ContractLine Source.ContractLineType="ServiceOfferingLine" AND Destination.ContractLineType="SelectedOptionLine" BMC_Component ROCREATESADDONLINE BMC_RequestableOffering BMC_ContractLine Source.IsAddOn="Yes" AND Destination.ContractLineType ="AddOnServiceLine"
BMC_Component SOLINEISPARENTOFADDONLINE BMC_ContractLine BMC_ContractLine Source.ContractLineType="ServiceOfferingLine" AND Destination. ContractLineType ="AddOnServiceLine" BMC_Component SELECTEDOPTIONLINEPARTOFADDONLINE BMC_ContractLine BMC_ContractLine Source.ContractLineType="AddOnServiceLine" AND Destination. ContractLineType="SelectedOptionLine" BMC_Component CONTRACTLINECOVERSOFFERINGINSTANCE BMC_ContractLine BMC_ServiceOfferingInstance
BMC_Component DELVERYROLINE BMC_RequestableOffering BMC_ContractLine Destination. ContractLineType ="DeliveryROLine" BMC_Component SYSTEMPARTITION BMC_Mainframe BMC_ComputerSystem
BMC_ContractComponent CONTRACTLINEINCONTRACT BMC_Contract BMC_ContractLine
BMC_Dependency MANAGEDDATABASE BMC_SoftwareServer BMC_DataBase Source.SoftwareServerType= 2 (DatabaseServer) BMC_Dependency APPLICATIONSYSTEMDEPENDENCY BMC_ApplicationSystem BMC_ApplicationSystem
BMC_Dependency DEPLOYEDAPPLICATION BMC_ApplicationSystem BMC_Application BMC_Dependency SAPDBRESOURCEAPPLICATIONSYSTEM BMC_ApplicationSystem BMC_SystemResource BMC_Dependency DEPENDENCY BMC_BaseElement BMC_BaseElement BMC_Dependency RESOURCEPROVIDESACCESSTOELEMENT BMC_BaseElement BMC_SystemResource
BMC_Dependency SERVICEDELIVEREDBY BMC_BaseElement BMC_BusinessService Destination.ServiceType="20 (Technical)"
BMC_Dependency BUSINESSSERVICESUPPORTEDBYTECHNICALSERVICE BMC_BusinessService BMC_BusinessService Source.ServiceType="20 (Technical)" and Destination.ServiceType="10 (Business)" BMC_Dependency HOSTEDLOGICALSYSTEM BMC_Cluster BMC_ComputerSystem
BMC_Dependency APPLICATIONSYSTEMCOMPUTER BMC_ComputerSystem BMC_ApplicationSystem, BMC_SoftwareServer
BMC_Dependency HOSTEDVIRTUALSYSTEM BMC_ComputerSystem BMC_ComputerSystem Destination.IsVirtual="Yes" BMC_Dependency DISKDRIVEPARTITION BMC_DiskDrive BMC_DiskPartition
BMC_Dependency FILESYSTEMPARTITION BMC_DiskPartition BMC_LocalFileSystem BMC_Dependency BLADESYSTEMDEPENDENCY BMC_Equipment BMC_ComputerSystem
BMC_Dependency USEHARDWARE BMC_HardwareSystemComponent BMC_LogicalSystemComponent BMC_Dependency OFFERINGCOVERSCONTRACTLINE BMC_Offering BMC_ContractLine
BMC_Dependency OFFERINGENABLESOFFERING BMC_Offering BMC_Offering Source.OfferingType="10 (Service)" and Destimation.OfferingType="20 (Requestable)" BMC_Dependency APPLICATIONSYSTEMOS BMC_OperatingSystem BMC_ApplicationSystem
BMC_Dependency ORGANIZATIONPROVIDESSERVICE BMC_Organization BMC_BusinessService BMC_Dependency SERVICESUPPORTEDBYORGANIZATION BMC_Organization BMC_BusinessService BMC_Dependency ORGANIZATIONISCUSTOMERFORCONTRACT BMC_Organization BMC_Contract
BMC_Dependency ORGANIZATIONCOVEREDUNDERCONTRACTLINE BMC_Organization BMC_ContractLine BMC_Dependency SERVICESUPPORTEDBYPERSON BMC_Person BMC_BusinessService BMC_Dependency PERSONCOVEREDUNDERCONTRACTLINE BMC_Person BMC_ContractLine BMC_Dependency LOCATEDIN BMC_PhysicalLocation BMC_BaseElement BMC_Dependency BINDSTO BMC_ProtocolEndpoint BMC_AccessPoint
BMC_Dependency RESOURCEALLOCATIONFROMPOOL BMC_ResourcePool BMC_ResourceAllocationSettingData BMC_Dependency ELEMENTALLOCATEDFROMPOOL BMC_ResourcePool BMC_BaseElement
BMC_Dependency MEMBERALLOCATEDFROMPOOL BMC_ResourcePool BMC_BaseElement
BMC_Dependency MAILSERVERTOLDAPSERVER BMC_SoftwareServer BMC_SoftwareServer Source.SoftwareServer="11 (MailServer)" and Destination.SoftwareServerType="14 (LDAPServer)" BMC_Dependency AFFINITYDEPENDENCY BMC_System BMC_System
BMC_Dependency USERESOURCE BMC_SystemResource BMC_BaseElement BMC_Dependency RESOURCEGROUPDEPENDENCY BMC_SystemResource BMC_ComputerSystem BMC_Dependency RESOURCEDEPENDENCY BMC_SystemResource BMC_SystemResource BMC_Dependency SERVICEACCESSPOINT BMC_SystemService BMC_AccessPoint BMC_Dependency SYSTEMSERVICESERVICEDEPENDENCY BMC_SystemService BMC_SystemService
BMC_Dependency VIRTUALSYSTEMOS BMC_VirtualSystemEnabler BMC_ComputerSystem Distination.IsVirtual="Yes" BMC_Dependency RESIDESON BMC_LogicalDisk BMC_LocalFileSystem
BMC_Dependency MOUNTEDON BMC_LocalFileSystem BMC_RemoteFileSystem BMC_Dependency SOENABLESRO BMC_ServiceOffering BMC_RequestableOffering
BMC_ Dependency OFFERINGLINECOVERSPERSON BMC_ContractLine BMC_Person Source.ContractLineType = "SelectedOptionLine" OR Source.ContractLineType="ServiceOfferingLine" BMC_ Dependency OFFERINGLINECOVERSORG BMC_ContractLine BMC_Organization Source.ContractLineType="SelectedOptionLine" OR Source.ContractLineType="ServiceOfferingLine" BMC_ Dependency ADDONSERVCIECOVERSINFRASTRUCTURECI BMC_ContractLine BMC_BaseElement Source.ContractLineType="AddOnServiceLine" AND Destination.ContractLineType="SelectedOptionLine" BMC_ Dependency ADDONSERVICEFORPERSON BMC_ContractLine BMC_Person Source.ContractLineType=AddOnServiceLine
BMC_Dependency ADDONSERVICEFORORGANIZATION BMC_ContractLine BMC_Organization Source.ContractLineType="AddOnServiceLine"
This table shows logical relationships types that you can create using Common Data Model (CDM) 7.6.04 relationship classes. Most relationship classes can represent several logical relationships types, some of which relate different CI classes. The Name attribute specifies which logical relationship type an instance represents.
For example, to represent an installed software patch you should create an instance of BMC_Component to relate instances of BMC_Software and BMC_Patch. You should then set the Name attribute of the relationship to PRODUCTPATCH (see row 12). To represent an affinity dependency you should create an instance of BMC_Dependency to relate two instances of BMC_System and set the Name attribute of the relationship to AFFINITYDEPENDENCY (see row 70).
BMC_Dependency SOSUPPORTSSO BMC_ServiceOffering BMC_ServiceOffering BMC_Dependency TAGGEDWITH BMC_BaseElement BMC_Tag
BMC_Dependency NETWORKLINK BMC_ComputerSystem BMC_ComputerSystem (host) Source.PrimaryCapability="Switch", "Router" or Layer_3_Switch Destination.PrimaryCapability="Server" or "Desktop" or "Laptop" BMC_Dependency COUPLINGFACILITYOS BMC_MFCouplingFacility BMC_OperatingSystem
BMC_Dependency STORAGESUBSYSTEMOS BMC_StorageSubsystem BMC_OperatingSystem BMC_Dependency DASDOS BMC_DiskDrive BMC_OperatingSystem BMC_Dependency TAPEOS BMC_TapeDrive BMC_OperatingSystem BMC_ElementLocation ELEMENTLOCATION BMC_BaseElement BMC_PhysicalLocation
BMC_ElementLocation OFFERINGLINECOVERSLOCATION BMC_ContractLine BMC_PhysicalLocation Source.ContractLineType = "SelectedOptionLine" OR Source.ContractLineType= "ServiceOfferingLine" BMC_HostedAccessPoint HOSTEDACCESSPOINT BMC_ComputerSystem BMC_IPEndpoint
BMC_HostedAccessPoint HOSTEDACCESSPOINT BMC_System BMC_AccessPoint
BMC_HostedAccessPoint HOSTEDACCESSPOINT BMC_SoftwareServer BMC_RoutingGroupConnector BMC_HostedService HOSTEDSERVICE BMC_System BMC_SystemService
BMC_HostedSystemComponents INSTALLEDSOFTWARE BMC_ComputerSystem BMC_Product, BMC_Patch, BMC_Package BMC_HostedSystemComponents SYSTEMBIOS BMC_ComputerSystem BMC_BIOS_Element
BMC_HostedSystemComponents SYSTEMDEVICE BMC_ComputerSystem BMC_Card
BMC_HostedSystemComponents SYSTEMDEVICE BMC_ComputerSystem BMC_CDROMDrive BMC_HostedSystemComponents SYSTEMDEVICE BMC_ComputerSystem BMC_Chassis BMC_HostedSystemComponents SYSTEMDEVICE BMC_ComputerSystem BMC_DiskDrive BMC_HostedSystemComponents SYSTEMDEVICE BMC_ComputerSystem BMC_LogicalDisk BMC_HostedSystemComponents SYSTEMDEVICE BMC_ComputerSystem BMC_Memory BMC_HostedSystemComponents SYSTEMDEVICE BMC_ComputerSystem BMC_StorageVolume BMC_HostedSystemComponents HOSTEDSYSTEMCOMPONENTS BMC_ComputerSystem BMC_DiskPartition BMC_HostedSystemComponents HOSTEDSYSTEMCOMPONENTS BMC_System BMC_SystemComponent
BMC_HostedSystemComponents SYSTEMHARDWARE BMC_ComputerSystem BMC_HardwareSystemComponent BMC_HostedSystemComponents FILESYSTEMPARTITION BMC_ComputerSystem BMC_LocalFileSystem
BMC_HostedSystemComponents SYSTEMHARDWARE BMC_ComputerSystem BMC_Monitor BMC_HostedSystemComponents SYSTEMHARDWARE BMC_ComputerSystem BMC_NetworkPort BMC_HostedSystemComponents SYSTEMHARDWARE BMC_ComputerSystem BMC_Processor BMC_HostedSystemComponents SYSTEMOS BMC_ComputerSystem BMC_OperatingSystem BMC_HostedSystemComponents SYSTEMRESOURCES BMC_Cluster BMC_SystemResource BMC_HostedSystemComponents SYSTEMRESOURCES BMC_System BMC_SystemResource BMC_HostedSystemComponents HOSTEDFILESYSTEM BMC_ComputerSystem BMC_LocalFileSystem
