Day One – 29 April 2008
Module 1: Introduction to SolidWorks and Basic Sketching... 1
Introduction to SolidWorks...1
SolidWorks user interface & Toolbar menus ...2
FeatureManager Design Tree ...4
Keyboard shortcuts and mouse buttons...5
Tools-Options ...6
Basic 2D sketching...9
Sketch Entities/Geometry... 10
Status of a sketch... 11
Sketch Relations... 12
Tutorial 1.1: Sketch a Simple Nut with Circle and Polygon ... 20
Tutorial 1.2: Using 3D sketch ... 21
Tutorial 1.3: Apply Add Relations between Sketch Entities ………. 22
Exercise 1.1: Sketching Horizontal and Vertical Lines... 23
Exercise 1.2: Sketching Lines... 23
Exercise 1.3: Sketching using Rectangle and Circle... 24
Exercise 1.4: Sketching a Chair Frame using 3D sketch... 24
Module 2: Additional Sketching ... 25
Tutorial 2.1: Creating a Flat Bar ... 26
Tutorial 2.2... 31
Tutorial 2.3... 33
Exercise 2.1 ... 35
Exercise 2.2 ... 36
Module 3: Basic Part Modeling ... 37
Sketching and Creating Bosses... 38
Creating a Counterbore Hole ... 41
Cut Feature ... 43
Filleting... 46
Chamfering... 47
Define Material and Mass Properties ... 48
Editing features ... 49
Exercise 3.1: Glass Plate ... 51
Exercise 3.2: Bracket ... 51
Exercise 3.3 ... 52
Exercise 3.4: Gland ... 52
Exercise 3.5: PVC Tee Pipe ... 54
Day Two – 30 April 2008
Swept... 65
Tutorial 4.3: Creating a Worm Gear ... 66
Tutorial 4.4: Creating a Spring... 67
Tutorial 4.5: Creating a Bottle (with a guide curve)... 68
Lofted ... 69
Tutorial 4.6: Create lofted part with Centerline Parameters ... 70
Exercises 4.2: Chisel ... 72
Rib and Shell... 76
Tutorial 4.7: Using Shell to create wall thickness inside the Bottle... 77
Module 5: Assembly Modeling ... 78
Assembly toolbars ... 81
Basic assembly mates ... 81
Sliding Brace Assembly ... 82
Exploding and collapsing the assembly ... 93
Creating an explode line sketch ... 94
Module 6: Drawing... 96
Drawing toolbars... 97
Insert standard drawing views - Angle of projections... 97
Insert Component into Drawing... 98
Adding dimensions to drawing and modifying dimensions ... 100
Create Section View... 101
Insert a Note ... 105
Edit Sheet Format... 106
Assembly Drawing ... 112
Elements of an Assembly Drawing ... 112
Example of Assembly Drawing... 112
Opening drawing template and edit Sheet Format ... 113
Adding the Exploded View... 114
Creating Bill of Materials (BOMs) ... 115
Customizing BOMs ... 116
AutoBalloons... 116
Producing an e-drawing file ... 118
Exercises 6.1:... 119
Module 1: Introduction to SolidWorks and Basic
Sketching (1 hour 50 minutes)
Introduction to SolidWorks
(20 minutes)SolidWorks is a mechanical design software package to build parts, assemblies, and drawings, which take advantage of the Microsoft Windows graphical user interface.
In SolidWorks, a part, an assembly, and a drawing are all fully associated. Changes to the model are automatically reflected in the associated drawings and assemblies. Likewise, when you make change to the drawing and assembly, those changes will be reflected back to the model.
SolidWorks user interface & Toolbar menus
The interface is native Windows interface, and such behaves in the same manner as other Windows applications.
Menus
• It provides access to all commands that the SolidWorks offers.
• When a menu item has a right pointing arrow, it means there is a sub-menu associated with the choice,
FeatureManager Design Tree Main Menu Standard Toolbar Standard Views Toolbar View Toolbar CommandManager Status Toolbar
Toolbars menus
• Provide shortcuts enabling to quickly access the most frequently used commands.
• They are organized according to function and can be customized, removed and rearranged according to your preferences.
Example of a Toolbar
Standard toolbar as shown below contains commonly used function as opening new or existing documents, saving documents, printing, copying and pasting objects, undo, redo, and help.
You can turn toolbars on and off using one of three methods.
1. Click Tools – Customize. On the Toolbars page, click the check boxes to select each toolbar you want to display. Clear the check boxes of the toolbars you want to hide.
2. Right click on toolbar area of the SolidWorks window. Check marks indicate which toolbars are currently visible. Clear the check marks of the toolbar you want to hide.
FeatureManager Design Tree
• It is located on the left side of the SolidWorks Graphic window.
• It displays the details chronological sequence on how all the parts, assembly and drawing are created.
• It allows access to do editing of the models. • It consists of three default tabs:
o FeatureManager design tree o PropertyManager
o ConfigurationManager
The FeatureManager design tree makes it easy to: • Select items in the model by name.
• Identify and change the order in which features are created. You can drag items in the FeatureManager design tree list to reorder them. This changes the order in which features are regenerated when the model is rebuilt.
• Display the dimensions of a feature by double-clicking the feature’s name. • Rename items by slowly clicking two times on a name to select it and then
entering a new name.
• Suppress and Unsuppress part features and assembly components.
The PropertyManager appears on the PropertyManager tab in the panel to the left of the graphics area. It opens when you select entities or commands defined in the PropertyManager.
Title bar
Help. Open the
corresponding help topic. OK. Accept the selections,
execute the command, and close the PropertyManager.
Cancel. Ignore any selections and close the PropertyManager.
Preview. Display a preview of the feature.
Keyboard shortcuts and mouse buttons
Keyboard shortcuts
Some menu items indicate a keyboard shortcut such as:
Ctrl+O for File, Open Ctrl+S for File, Save Ctrl+Z for Undo And many more
You can customize SolidWorks by creating your own shortcuts. Click Tools – Customize. Find Keyboard tab as in figure shown.
Three mouse buttons
• Left – to select objects as geometry, menus buttons, and objects in the FeatureManager design tree. To select multiple items, you must hold down the Control (Ctrl) key. To deselect object, simply click anywhere in a blank (empty) portion of the work area.
• Right – activates a context sensitive shortcut menu. The contents of the menu is differ depending on what object the cursor is over.
• Middle – use for dynamically rotating, panning, zooming a part or assembly. o Rotate part or assembly – Holding down the middle button and drag
the mouse
o Zoom all document types – Hold down the Shift key while depressing the middle button and moving the mouse.
(Simply rotates the wheel of the middle mouse button for zooming in or out if your middle mouse button is a wheel.)
Tools-Options
The Options dialog box able you to customize the SolidWorks software based on your preferences.
Level of customization: • System Options
Every option under System Options will affect every document you open in SolidWorks session. For example, the viewport background, if you set the color to Black, it will remain as black every time you open the SolidWorks window until you change to another color.
• Document Properties
This setting only applied to individual documents. For example, units, drafting standard, material properties, image quality etc. They are saved with the document and do not change.
Example: Setting Units
Tools Æ Options Æ Document Properties Æ Units Æ MMGS (millimeter, gram, second)
Example: Set Dimensioning Standard
Basic 2D sketching
(1 hour 30 minutes)
Sketching is the act of creating 2-dimensional profile comprised of wireframe geometry. Sketches are used for all sketched feature in SolidWorks including:
• Extrusions
• Sweeps • Revolves • Lofts
Process of completing the sketches
Starting a New part
(It can be created in inch, millimeter or other units)
Sketches
(Collections of 2D geometry that are used to create solid features)
Sketch Entities/Geometry
(Types of 2D geometry such as lines, circles and rectangles that make up the sketch)
Sketch Relations
(Geometric relationships such as horizontal and vertical are applied to the sketch entities. The relations restrict the movement of the entities)
State of the sketch
(Each sketch has a status that determines whether it is ready to be used or not. The state can fully-, under- or over defined)
Sketch tools
(Tools can be used to modify the sketch geometry that has been created/ this often involves the trimming or extension of the entities)
Sketch Entities/Geometry
SolidWorks offers a rich variety of sketch tools for creating profile geometry. Sketch entity Toolbar button Geometry example
Line Circle Centerpoint Arc 3 Point Arc Tangent Arc Ellipse Partial Ellipse Parabola Spline Polygon Rectangle
Status of a sketch
The most common color codes are:
No. Color Diagnostic Case
1. Blue
Under constrained
(this is usually appears when first
drawn) 2. Black Fully constrained (when more constraints and dimensions are added to the sketch
– the sketch become completely defined) 3. Red Over constrained (adding any dimension to fully defined would serve to overdefine the sketch)
Only case 1 and 2 are allowable. For case 3, you must fix the error as soon as possible before quitting the sketch mode otherwise a warning message will pop-out and it will create more problems for yourself.
Sketch Relations
The following table describes the entities that you can select for a relation and the characteristics of the resulting relation.
Relation Entities to select Resulting relations Horizontal or
Vertical
One or more lines or two or more points.
The lines become horizontal or vertical (as defined by the current sketch space). Points are aligned horizontally or vertically.
Collinear Two or more lines. The items lie on the same infinite line.
Coradial Two or more arcs. The items share the same centerpoint and radius.
Perpendicular Two lines. The two items are perpendicular to each other.
Parallel Two or more lines. A line and a plane (or a planar face) in a 3D sketch.
The items are parallel to each other. The line is parallel to the selected plane.
Tangent An arc, ellipse, or spline, and a line or arc.
The two items remain tangent.
Concentric Two or more arcs, or a
point and an arc. The arcs share the same centerpoint. Midpoint Two lines or a point
and a line.
The point remains at the midpoint of the line.
Intersection Two lines and one
point. The point remains at the intersection of the lines. Coincident A point and a line, arc,
or ellipse.
The point lies on the line, arc, or ellipse.
Equal Two or more lines or
two or more arcs. The line lengths or radii remain equal. Symmetric A centerline and two
points, lines, arcs, or ellipses.
The items remain equidistant from the centerline, on a line perpendicular to the centerline.
A line may be constrained vertically or horizontally. Once the line is drawn horizontally, it will remain horizontal unless the relation is removed. The line can be repositioned and resized but must remain horizontal.
For an instance:
Where to find it
• Select the sketch entity or entities, and select the appropriate relation from the Add Relations section of the PropertyManager
• Or, right click the entity or entities, and select Add Relation from the short-cut menu
• Or, click Tools, Relations, Add…
• Or, on the Sketch toolbar click Add Relation
You can view all relations in your sketches by select View – Sketch Relations The line is in Horizontal The line is in vertical
The lines are in horizontal and have equal length
What are we going to sketch? How to start?
1. Open SolidWorks 2007.
2. Select New from the File menu, or click on the New icon on the Standard toolbar.
3. Select the type of new file (Part, Assembly, or
Drawing) from the New SolidWorks Document
window.
4. Click OK.
5. Open a new Sketch.
Open the sketch by either clicking or choosing Sketch from the Insert menu.
This will show all three default planes for selection in a trimetric orientation.
From the screen, choose the Front Plane. The plane will highlight and rotate.
7. Sketch lines Click the Line tool
1 2
3 4
9. Linear dimensions.
Add additional linear dimensions to the sketch as shown.
10. Angular dimension.
Using the dimension tool, create the angular dimension shown and set the value to 125°.
Where to find it?
• Tools menu, select Dimensions,
Smart
• Or Right click, select Smart
Dimension
• Or Dimensions/Relations toolbar, pick Smart Dimension tool,
11. Fillets.
Click Sketch Fillet
and set the Radius to 10 mm. Select all of the endpoints in the sketch.
Click OK.
12. Extrude menu.
Click Insert, Boss/Base, Extrude or the tool on the Features toolbar to access the command
Sketch Fillets are used to
round off sharp corners in a sketch.
Where to find it? • Tools menu, select
Sketch Tools, Fillet.
• Or Sketch toolbar, click
13. Edit the sketch
Right click on Extrude, and select Edit Sketch
a. Change the value of angular dimension
Double click on 125° and modify to 110°. You’ll see that other dimensions remain unchanged.
b. Length of the base
Double click on 100 mm and modify to 90 mm
Click here to Exit Sketch and update your part.
Tutorial 1.1: Sketch a Simple Nut with Circle and Polygon
1. Create a New part in SolidWorks.
2. Right click Top Plane from the FeatureManager design tree. This will be a Sketch plane.
3. Click Sketch from the toolbar.
4. Click Circle from the Sketch toolbar. Sketch a circle centered at the origin. Give dimension as illustrated.
5. Click Tools – Sketch Entities – Polygon from the Menu bar. Sketch a Polygon centered to the origin larger than the circle.
6. Extrude to 8 mm depth.
We can create equilateral polygons with any number of sides from 3 to 40.
Parameters
This box allows you to define the number of sides. Other parameters will automatically update when this parameter is
Tutorial 1.2: Using 3D sketch
1 2
3 4
5 6
Select 3D sketch and start sketching
You can change the plane sketch by pressing the Tab key
1 2
3 4
5 6 7
Tutorial 1.3: Sketch part using Lines, 3 Point Arc, Tangent Arc and apply Add Relations between Sketch Entities
8
Select these two arcs to make tangent
Exercise 1.1: Sketching Horizontal and Vertical Lines (15 minutes) Create this sketch on the Front Plane
using lines, automatic relations and dimensions. Fully define the sketch.
Extrude the sketch 30 mm in depth.
Save and close the part.
Exercise 1.2: Sketching Lines (5 minutes) Create this sketch on the Front
Plane using lines, automatic relations and dimensions. Extrude the sketch 30 mm in depth.
Exercise 1.3: Sketching using Rectangle and Circle (5 minutes) Create this sketch on the Front Plane using rectangle and circle, automatic relations and dimensions.
Exercise 1.4: Sketching a Chair Frame using 3D sketch (5 minutes) Create this sketch using 3D sketch (free dimension)
Module 2: Additional Sketching (2 hours)
This module is an extension of the previous module. Here, you will learn more about Sketch toolbar, Sketch Relations, Dimensions and edit the sketch.
On the completion of this module, you will be able to: • Apply other Sketch Entities:
o Rectangle o Centerline o Ellipse
• Understand and utilize the available tools from the Sketch toolbar to create and modify the sketch:
o Trim – able to trim the selected entities,
o Linear Pattern – able to create a linear pattern along one or both axes,
o Mirror – able to mirror existing sketch entities,
o Offset – able to offset one or more sketch entities, and selected model edges by a specified distance,
o Circular Pattern – able to create a circular pattern along one or both axes
• Apply Sketch Relations between sketch entities o Midpoint
o Horizontal o Coincident o Tangent • Edit the sketch
o Edit Linear Pattern o Change the sketch plane
Tutorial 2.1: Creating a Flat Bar
(20 minutes)
1. Open a New sketch and Save As Flat Bar2. Click Sketch from the toolbar. 3. Select the Front Plane.
4. Click Rectangle from the Sketch toolbar.
5. Click Centerline from the Sketch toolbar.
6. Select both Centerline and Origin Point (press Ctrl key while selecting) and choose Midpoint as their relations.
7. Click Trim Entities from the Sketch toolbar
8. Select Trim to closest from the Trim Options
9. Select the right and left vertical lines to remove.
10. Click Tangent Arc from the Sketch toolbar.
12. Click Circle from the Sketch toolbar with the diameter is 20 mm at the left end of the bar.
13. Click Linear Pattern from Tools – Sketch Tools drop down menus.
15. Save the part.
16. Editing
a. Reduce the number of holes to 5
i. Right click on Extrude and select Edit Sketch
ii. Select one of the Circle and right click and choose Edit Linear Pattern
iii. Change the number of holes from 9 to 5 and the distance between each holes to 50 mm
b. Change the Sketch Plane
i. Expand the Extrude. Right click on Sketch and select Edit Sketch Plane.
ii. You will see shows the Front Plane, which denotes your previous sketch plane.
iii. Expand this button
iv. Select Top Plane.
Tutorial 2.2: (20 minutes)
1. Open a new sketch.2. Click Sketch from the toolbar. 3. Select the Front Plane.
4. Sketch horizontal and vertical Centerlines.
5. Sketch two Circles with different diameters as shown in figure below. Connect these circles with 3 Point Arc.
6. We can see all relations between the sketch entities.
7. Trim the sketch as shown in figure below.
8. Select Mirror from the sketch toolbar and mirror the entity with respect to the vertical Centerline.
9. Next, Mirror with the horizontal Centerline.
10. Select Ellipse from the sketch toolbar and complete all dimensions as shown in figure below.
11. Extrude to 10 mm depth and save the part.
Tutorial 2.3: (15 minutes)
1. Open a new sketch.
2. Click Sketch from the toolbar. 3. Select the Front Plane.
4. Create a Circle with 50 mm in diameter.
6. Type 7 mm as distance parameter outside the first Circle.
7. Sketch one Line which 6.15 mm from the vertical Centerline and Mirror about the Centerline. Then Trim the lines carefully until you get as similar as in figure below. If you pick a wrong line, you may Undo the step.
8. Select Tools – Sketch Tools – Circular Pattern . 9. Select the lines and insert 8 as your number of pattern instances.
Trimming
Exercise 2.1: (20 minutes)
(c) Shift Lever
Exercise 2.2: Create a solid model of this 2 mm thick steel bicycle disk rotor. (25 minutes)
Module 3: Basic Part Modeling (2 hours)
This module provides an understanding of creating Extruded, Fillet, Chamfer, Simple Hole and Hole Wizard features.
These are the samples of Features toolbar: Boss/Base and Cut
Features
Pattern/mirror
Some of the icons (which are not circled) will be seen during Module 4 – Additional Part Modeling.
On the completion of this module, you will be able to: 1. Sketch at any planes,
2. Utilize extruded boss and extruded cut,
3. Create fillet and chamfer at the selected edges, 4. Create standard holes by applying the Hole Wizard, 5. Find the mass of your part and
6. Edit or manipulate features geometry to reduce or increase the mass properties of the component.
Sketching and Creating Bosses (45 minutes)
1. Open a new sketch.2. Click Sketch from the toolbar. 3. Select the Top Plane.
4. Sketch as shown in figure below. Add dimensions to the sketch.
5. Extrude 10 mm upwards.
Equal length
6. lnsert new sketch.
Create a new sketch using Insert, Sketch or by clicking the Sketch tool.
7. Sketch as shown in figure below. Select this side/plane
8. Add dimensions.
Creating a Counterbore Hole
10. Hole position.
Select the face indicated and Insert – Features – Hole – Wizard…
11. Choose Counterbore.
Set the properties of the hole as follows:
Standard: Ansi Metric
Screw Type: Hex Bolt – ANSI B18.2.3.5 Size: M8
Fit: Normal
End Condition: Through All
12. Turn to Hole Position.
13. Drop the point onto the center point.
14. Completed Hole.
Click Finish to complete the hole feature.
Cut Feature
15. Press the spacebar and double-click *Front.
16. Select the left vertical sketch line and the vertical model edge.
Add a Colinear relation between them.
Start a sketch on this large face and add a rectangle Coincident with the bottom model edge.
17. Add a dimension.
18. Through All Cut. Click Insert, Cut, Extrude,
Or pick Extruded Cut on the Features toolbar. Choose Through All and click OK
Holes
19. Change the view orientation. Press the spacebar and double-click *Top.
20. Hole.
Click the Hole tab and set the properties of the hole as follows:
Standard: Ansi Metric Screw Type: Drill sizes Size: ∅12.5
End Condition: Through All
21. Turn to Hole Position and locate the holes.
22. Set Dimensions add relation so that these points are aligned horizontally.
23. Return to Isometric.
Filleting 24. lnsert Fillet. Set a radius = 10 mm
25. Add fillets at selected edges and face, radius 2.5 mm, and using Full preview.
Chamfering
26. Add chamfer to the holes.
27. Save the part.
Define Material and Mass Properties
28. How to define material and check its mass properties
29. Choose Copper and its Alloys and select Brass. Right click on Material and select Edit Material
30. Drop down menus, Tools – Mass Properties…
Editing features
31. Mass of the part can be reduced by modified the thickness of the features. 32. Right click on Extrude and select Edit Feature.
Mass of the part (474.04 g)
33. Change the depth from 10 mm to 5 mm.
34. Click OK.
35. Check the current mass of the part. Now, the mass is 326.09 g which means more than 30 % of mass has been reduced.
36. The Cut Feature is still maintaining the dimension to be 2.50 mm from the bottom face.
Exercise 3.1: Glass Plate
(15 minutes)Create this part using the information and dimensions provided. Sketch and extrude profiles to create the part.
Exercise 3.2: Bracket
(15 minutes)Create this part using the information and dimensions provided. Sketch and extrude profiles to create the part.
4 x M20 Drilled Hole
R20 fillet 10
CBore M14 Hex Head Bolt
Exercise 3.3
: Create this part using the information and dimensions provided.Sketch and extrude profiles to create the part. (10 minutes)
Exercise 3.4: Gland
(15 minutes)Create this part using the information and dimensions provided. Sketch and extrude profiles to create the part.
Start sketching Give dimensions
Trimming
Mirror the sketch with vertical axis
Mirror
Sketch small circle and mirror for another circle Extrude 10
Exercise 3.5: PVC Tee Pipe
(30 minutes)Create a solid model of this plastic pipe tee. A tee is used to connect pipes together. The type of tee shown here is used to join pipes with solvent welding. A chemical is applied to the inside of the socket, and the pipe is then forced into the socket. The solvent softens the plastic, and when the solvent dries, a strong, permanent joint is created. The sockets are tapered slightly to allow for a tight fit with the pipe.
Module 4: Additional Part Modeling
This module provides a comprehensive understanding on additional modeling techniques such as:
Revolved, Patterning, Swept, Lofted, Rib and Shell features in SolidWorks. Below are examples of products that applied these types of features.
Revolved features
Revolved Boss/Base – material added by rotating the profiles about a centerline Revolved Cut – material removed by rotating the sketch
The Revolve parameters box provides the ability to select:
Centerline
One of the lines is collinear with the centerline to make a solid cylinder
Allow a small gap between rectangle and the centerline to create a hollow cylinder
Axis of Revolution Revolve Type • One-Direction • Mid-Plane • Two-Direction Angle
It controls the revolve thickness
Tutorial 4.1:
1. Draw a Centerline across the Origin
2. Using Line, sketch as follows (free dimension)
3. Exit the sketch and select Revolve from Features toolbar. Select the Centerline as the Axis of Revolution.
4. The direction of rotation and its angle can be changed, i.e. 180°.
5. Click OK.
6. To edit the feature. Right click Revolve and select Edit Feature.
Click here to change the rotation to counter clockwise
7. Change the angle of revolution to 360°.
8. We will make holes on the selected face.
9. Sketch a Circle and tick For construction box. The line will turn to construction line.
10. Sketch a small Circle and coincident with the construction line.
11. Extrude Cut, Through All.
12. The hole will be copied around the face by using Circular Pattern. Click View – Temporary Axes. The axis will be used as axis of rotation.
13. Select Circular Pattern from Features toolbar. Number of holes are 6.
Patterning
In Module 2, you have learnt the sketch pattern such as linear and circular pattern. There are other pattern tools that are available in SolidWorks. You may find them at Insert – Pattern/Mirror.
Pattern repeats the selected features in an array based on a seed feature. You can create a linear pattern, a circular pattern, a curve driven pattern, a fill pattern, or use sketch points or table coordinates to create the pattern.
Linear pattern Select the features, then specify the direction, the linear spacing, and the total number of instances.
Circular pattern Select the features and an edge or axis as the center of rotation, and then specify the total number of instances and the angular spacing between instances.
Curve driven
pattern Select the features and an edge or sketch segment on which to pattern the feature. Then you can specify the type of curve, the curve method, and the alignment method.
Fill pattern Fill a defined region with a pattern of features or a predefined cut shape. Typical uses include:
• Weight reduction • Ventilation holes Sketch points or Table coordinates to create the pattern
Select where to populate a seed feature by sketching points on model face, or Add or retrieve previously created X-Y coordinates to populate a seed feature on the face of the model.
Tutorial 4.2: Vary Sketch option
1 2
3 4
5 6 7
Sketch as illustrated (some of the entities are free dimension)
Extrude the sketch Sketch a slot on top of 3D part and give dimensions Hint: 8 mm at both sides will control the distance between the arcs and the
plate edges.
Exercises 4.1: Curve Driven Pattern
1 2
3
4
6 7
Sketch as illustrated using
Spline (free dimension) Extrude to 10 mm
Offset 5 mm
Sketch a Circle with diameter 3 mm on top of spline face
8 5
Swept
Swept Boss/Base – material added by sweeping a profile along the path Cut Sweep – material removed by sweeping a profile along the path
Follow path – the section remains at the same angle with
respect to the path at all times.
Keep Normal Constant – the section remains parallel to the beginning section at all times. Sample of applications:
Tutorial 4.3: Creating a Worm Gear
Sketch the profile (or the sketch can be taken from Tutorial 2.3, but you have to
modified a bit)
Tutorial 4.4: Creating a Spring
Sketch a Circle
Create a Plane Normal to Curve
Tutorial 4.5: Creating a Bottle (with a guide curve)
Create a Profile
1 2
3 4
Lofted
Loft creates a feature by making transitions between profiles. A loft can be a base, boss, cut, or surface. You create a loft using two or more profiles. Only the first, last, or first and last profiles can be points. All sketch entities, including guide curves and profiles, can be contained in a single 3D sketch.
You can drag to modify/change the location of these blue points
Tutorial 4.6: Create lofted part with Centerline Parameters
1. Create Rectangle on Front Plane.
2. Select and sketch 3 Point Arc at other Top Plane. One of its end points must coincident with the Origin.
3. View in Isometric.
5. Sketch another Rectangle on this Plane
6. Select Loft from Feature toolbar. Select Sketch 1 and Sketch 3 (both Rectangles) as the profiles.
Exercises 4.2: Chisel
1. Select Front Plane
2. To create another Plane, Hold Ctrl key and drag Front plane to the left.
5. Select Front Plane and sketch a square.
6. Exit sketch.
7. Select Plane1 and sketch a Circle.
8. Exit sketch.
9. Select Plane2 and sketch another Circle, which its radius is coincident with the vertex of the square. Exit the sketch.
10. Select and Copy larger Circle and Paste on Plane3.
11. Click Features – Lofted Boss/Base
12. Select sketches. You have to make sure that all the selected points are at the same corner.
14. Select Plane4 that you have just created and sketch a Rectangle as illustrated below.
15. Click Features – Lofted Boss/Base. Select the profile. Pick the point at the right bottom of square and rectangle.
Rib and Shell
Rib is a special type of extruded feature created from open or closed sketched contours. It adds material of a specified thickness in a specified direction between the contour and an existing part. You can create a rib using single or multiple sketches.
1. Sketch L shape and extrude the sketch.
2. Sketch a Line to use as the rib feature on a plane.
Rib
Tutorial 4.7: Using Shell to create wall thickness inside the Bottle
1 2 3
Module 5: Assembly Modeling
Stages in the process;
1. Creating a new assembly
• New assemblies are created using the same method as new parts
2. Adding the first component
• Components can be added in several ways. They can be dragged and dropped from an open part window or opened from standard browser.
3. Position of the first component
• The initial component added to the assembly is automatically fixed as it is added. Others components can be positioned after they are added.
4. Mating components to each other
• Mates are used to position and orient components with reference to each other. Mates remove degrees of freedom from the components.
Concentric mate between two cylindrical faces
5. Sub assemblies
• Assemblies can be created and inserted into the current assembly. They are considered sub-assembly components.
From assemblies, you can:
1. Perform mass properties calculations on entire assemblies and also interference (clashes) detection between parts in assembly,
Assembly toolbars
Basic assembly mates
• Coincident – place two flat surfaces in the same plane
• Parallel – define two flat surfaces as parallel • Perpendicular – define two lines or planes as perpendicular to one another
• Tangent – define a cylindrical feature as tangent to a line or plane
• Concentric – align the centerlines of two cylindrical features
• Distance – make two surfaces parallel, with a specified distance between them
• Angle – two lines or planes at a preset angle to one another
•
Insert components
•
Hide/show components
•
Change suppression state
•
Edit component
•
No external references
•
Mate
•
Move component
•
Smart fasteners
•
Exploded view
•
Explode line sketch
•
Interference detection
Sliding Brace Assembly
1. Create a new assembly2. Insert components (Browse the components from Desktop/SolidWorks Basic Training/Module5/Bracket)
3. Float and Fix components
By default, the first component inserted into an assembly is fixed (locked) in position.
4. Mate the faces of these two components (Bracket – C Link) and select Coincident
1
2
3
Select top Face of C Link
1
5. Moving and rotating the component – U Bolt
1
2
6. Mating components (select U Bolt’s right leg and Bracket’s hole) – choose Concentric
1
8. Select bottom faces of U-Bolt and C Link and constraint their Distance to maintain at 40 mm.
9. Continue with the other side. You have to insert other U-Bolt and C Link and apply mates on respective parts as before.
10. You will utilize the Design Library and take a standard nut from the library.
11. Save as the nut to Desktop/SolidWorks Basic Training/Module5/nut.
12. You will be asked to Select a Configuration of the nut size. Select M20-2.5. M – Metric, 20 – nut diameter (in mm)
13. Insert/copy four nuts.
15. A complete assembly.
2
16. Generate an assembly statistics - Generate a report of the components and mates in an assembly.
Exploding and collapsing the assembly
Exploded View - It is a view of an assembly where the components have been separated.
17. Select the component to be exploded – a triad will appear – place the cursor over the arrow on the triad that represents the direction in which component should be exploded – then drag to the desired distance.
18. Select the nuts (it will be highlighted in cyan color at the design tree). Then drag the triad downward.
Exploded step
Drag the triad downward
20.
Creating an explode line sketch
21. Make sure the assembly in its exploded view (not collapsed). 1
2
Expand the entries in the ConfigurationManager so that defined Explode Steps will appear
Exploding
22. Select edges or faces on components that the explode line will connect between.
23. Repeat for other components. Save the assembly.
Select edges
Module 6: Drawing
After completion of this module, you will be able to: -• make 2-D drawing from a SolidWorks part file. • create a custom drawing sheet format, and
• use eDrawings to create a drawing file that allows easy file sharing
1. To open a new drawing file, open SolidWorks 2007, click New icon on the
Standard toolbar.
2. Select Drawing icon and then OK.
3. You will be asked about the format and size of your drawing layout. Click Standard sheet size and select A-Landscape. Do not turn on the Display sheet format yet.
Drawing toolbars
In the drawing mode, the CommandManager has THREE groups of command:
Drawing
Sketch
Annotation
You will use some of the icons along the way.
Insert standard drawing views - Angle of projections
5. In the drawing space, right-click and select Properties from the menu.6. Select Third angle projection. Do not worry about the scale, it can be changed later,
Insert Component into Drawing
7. In Drawings CommandManager, select Standard 3 View
8. Then Browse…
Select Third
angle projection
9. Search the Bracket that you have created during Exercise 3.2 or go to Desktop/Module3/Exercise 3.2. Enable the Preview to view the part before you open.
10. Selected part in third angle projection.
11. All other views are aligned with the Front view. When you move/drag the front view up-down or left-right will move the other views.
Front view Top view
12. Enlarge the views by change the scale to 1:2
Adding dimensions to drawing and modifying dimensions
13. Select Annotation – Model Items, and in Dimensions tab, click Marked for Drawing
Make the Hidden Lines Visible
Marked for Drawing
14. To change the arrow direction, click this point.
Create Section View
15. Select the Section View Tool from the Drawing group.
1 2
3 Move the cursor over the edge
16. A Section View is created. To reverse the arrow direction – double click on the section line
17. To break alignment between section view and top view, right click the section view; go to Alignment-Break Alignment.
19. The location of Right view will be replaced by the Section view, but you need to rotate this view first. Right click the view; choose Zoom/Pan/Rotate – Rotate View.
20. Rotate the view to -90°.
21. Select the section view, and click Centerline Tool from Annotations group then centerlines will be added to the holes
22. Press and hold the Shift key and drag the dimension of 45 mm diameter hole from the top view into the Section View
23. You can also hide the dimension. Just select the dimension you want to hide, right click and find Hide. To show the dimension, go to View – Hide/Show Annotations, then click any hidden dimension
Press Shift key and select the Dimension
Insert a Note
24. Select Note Tool from the Annotation group
Edit Sheet Format
26. Right click in the drawing space and select Properties
28. Right click in the drawing area and select Edit Sheet Format.
29. The drawing Sheet Format. After this, you will learn how to do some modification to the sheet.
30. Drag your mouse from left to the right to select all the lines and information that you may not needed. Press Delete key and then use Trim Entities to trim the lines.
31. Trim until you get the drawing table like this.
32. Select Note Tool and type inside the Comments. Symbol plus/minus is inserted by clicking on the Add Symbol Tool under Text Format tab.
33. Fill up the form as shown; type your department and drawing title.
34. To modify the scale, you have to go to Sheet Properties and change the Scale 1:2.
35. Right click and select Edit Sheet.
36. You will get back to the other side of drawing. It includes your drawing part and sheet.
37. A trimetric view can often be helpful in interpreting a 2D drawing. To bring the view into the drawing layout, click Model View from Drawings.
38. Click arrow Next.
39. Select the Trimetric View, and arrange the view as figure below.
Assembly Drawing
Assembly drawings show all the parts and how they go together Dimensioning is not usually required
Hidden lines usually omitted
3D CAD packages can generate assembly drawings directly from assembly models
Elements of an Assembly Drawing
¾ All parts are shown in one drawing• assembled view • sectioned assembly • exploded assembly
¾ Parts list or bill of materials (BOMs)
• Part ID, quantity, description, catalogue number, etc. ¾ Balloons
• each part is identified by a numbered balloon, and referenced to the parts list
¾ Machining and assembly instructions
Example of Assembly Drawing
Opening drawing template and edit Sheet Format
1. Open the assembly file Desktop/SolidWorksBasic Training/Module5/Sliding brace assembly.sldasm”. Make sure that the assembly is in the ‘collapsed’ configuration
2. OK to accept the Drawing Template
3. Click Standard sheet size and select A-Landscape. Do not turn on the Display sheet format yet.
4. In the new drawing window, select the Standard 3 View, and make sure it is in Third angle projection
Uncheck the
box
5. Select the Model View Tool from Drawings group
Adding the Exploded View
6. Next, we will make an exploded view to the drawing. Select Trimetric
from the list Trimetric view
1 Right click the
7. Showing the assembly and exploded drawing.
Creating Bill of Materials (BOMs)
8. Select any of the drawing views9. From the main menu, select Insert: Tables: Bill of Materials
Customizing BOMs
11. Edit the title box12. The drawing is almost complete, but the item numbers in the Bill of Materials are not linked with the components in the drawing. We will add “balloons” with part numbers to the drawing.
AutoBalloons
13. Select the exploded Trimetric Views. Select the AutoBalloons Tool from the Annotations group of the CommandManager.
14. Balloons will be added to the view. Click on the Part Number cell, and select Column Properties
Edit the title box to read PART
NAME
2 1
16. Balloon styles
17. Completed assembly drawing. Circular –
Triangular –
Hexagon –
Circular split line – Item number
Producing an e-drawing file
1. Right click at the Main Menu and select eDrawings 2007. 2. Click Publish eDrawings 2007 File
3. A pop up window will come out. Click Retry button.
5. To save the file, go to File-Save As. The type of file is *.edrw.
Exercises 6.1:
In the PropertyManager, click Browse, and then open Desktop\ SolidWorks Basic Training/Module6/motor casing.sldasm. Do the assembly drawing as shown.
References
1. William E. Howard and Joseph C. Musto, (2006). Introduction to Solid Modelingusing SolidWorks. McGraw-Hill International Edition. ISBN 007-124956-7.
2. David Murray, (2006). Inside SolidWorks 4th Edition. Thompson Delmar Learning. ISBN 1-4180-2085-0.
3. David C. Planchard and Marie P. Planchard, (2008). A Commands Guide for SolidWorks 2008 – The reference edition including more than 200 integrated stand-alone tutorials. Thompson Delmar Learning. ISBN-10: 1-42835301-1, ISBN-13: 9781-4283-5301-5.
4. Frederick E. Giesecke, Alva Mitchell, Henry Cecil Spencer, Ivan Leroy Hill, John Thomas Dygdon and James E. Novak, (2003). Technical Drawing 12th Edition. Prentice Hall. ISBN 0-13-178446-3.
5. Albert William Boundy, (2002). Engineering Drawing 6th Edition. McGraw-Hill International Edition. ISBN 007-471043-5.
6. James H. Earle (2004). Engineering Design Graphics AutoCAD 2004 11th Edition. Pearson Prentice-Hall. ISBN 0-13-142573-0.
7. SolidWorks 2003 Training Manual. 8. http://www.solidworks.com/
