Preface

This practical laboratory manual complements the book enti-tled Cereal Grains: Properties, Processing, and Nutritional

Attributes. Its main goal is to assist students and research-ers interested in the fundamentals of analysis, quality con-trol, experimental studies, and product development of the wide array of cereal-based foods. This book is designed to emphasize the essential principles underlying prepara-tion of cereal-based products and to demonstrate the roles of ingredients. The manual is organized in such a way that the student progressively learns and applies the theoretical knowledge described in the parent book. For instructors, this manual will serve as a practical guide to implement and apply quality control measurements of grains, milled products, starches, and an ample array of finished products. The book is designed to facilitate the acquisition of practical knowledge and provides new innovative ideas for new devel-opments. Each chapter contains a set of key references so the reader can broaden the knowledge and study questions planned to motivate students to go beyond the boundaries of the covered material. In addition, each set of related proce-dures contains at the end research suggestions. A section of weight, volume, density, and other equivalences to convert kitchen and English units to metric measurements and vice versa is included.

The practical manual is divided into fourteen chapters. The first three chapters includes the main quality control measurements used to determine physical, morphological, chemical–nutritional properties, and sensory properties (color, texture, and organoleptic tests) of cereal grains and their products. In these chapters, the student will learn and practice grade and class determination, the most frequently used methods to assess chemical and physical properties and the viewing of the different anatomical parts of cereal grains. In addition, Chapter 3 deals with color, texture, and sensory evaluations of cereal products. The objective of the fourth chapter is to provide the practical knowledge of the most critical factors that affect grain stability throughout prolonged storage, identify the most common insects and pests responsible for grain storage losses, and practice the most common analytical techniques to determine insect fragments, filth, mycotoxins, and other sanitary indicators. The fifth chapter is designed to practice at the laboratory level the various types of dry-milling processes for produc-tion of dry-milled fracproduc-tions of maize, polished rice, refined wheat flour, groats, and decorticated sorghum that are used as raw materials for the production of prepared cereal based end-products. This section includes the most common physical and chemical tests to determine quality of refined products including the determination of dough rheological properties with the mixograph, farinograph, extensigraph,

alveograph, and the new assay with the mixolab. Chapter 6 includes laboratory wet-milling procedures aimed toward the production of maize, rice, and wheat starches and micro-scopic methods to determine birefringence, starch gran-ule morphology, and types of starches. This section also includes the two most common methods (amylograph and differential scanning calorimetry) to assess starch function-ality and the quantification of resistant starch. Chapter 7 is designed to practice production of nixtamalized fresh masa and dry masa flours used for the manufacturing of maize tortillas and related products. In this part, the reader will be exposed to the production of table tortillas and the most common laboratory methods to assess nixtamal, masa, and tortilla quality and shelf-life. Chapter 8 focuses in assess-ing activity of yeast and chemical leavenassess-ing agents critically important for the elaboration of bakery and other fermented products. The first part of this section thoroughly covers procedures to determine yeast activity using the pressur-ometer, gasograph, and maturograph, whereas the second part, laboratory procedures, is for the determination of the neutralization values of various types of chemical leavening agents. Chapter 9 describes laboratory and pilot plant proce-dures for the production of different types of yeast-leavened breads including official methods to test flour for baking purposes. The production of baguettes, Chinese steamed bread, white and whole wheat table bread, yeast-leavened donuts, Arabic breads, bagels, pretzels, sour breads, sweet breads, and pastries such as danish, croissants, cinnamon rolls, and an assort of pastries is covered. The laboratory procedures include different formulations so the student can learn ingredient functionality. Chapter 10 describes labora-tory procedures for the production of crackers and different sorts of chemically leavened bakery products including the most common method (spread factor) employed to assess soft wheat flour functionality. The student will have labo-ratory procedures for the elaboration of different sorts of cookies (rotary molded, wire-cut, laminated) and cakes and other related products such as pancakes, crepes, muffins, biscuits, and coffee donuts. This chapter also thoroughly covered the manufacturing of refined and whole wheat flour tortillas. Chapter 11 depicts laboratory procedures for the production of different types of short and long pasta products from semolina and regular and alkaline oriental noodles pro-duced from refined wheat flour. The next section contains a set of activities so the reader can practice the production of important breakfast cereals and snacks via traditional and extrusion processes. The reader will be exposed to dif-ferent protocols for the production of flakes, oven-puffed rice, granolas, and extruded products. Likewise, different laboratory and pilot plant procedures are included for the

(21)

xx Preface

production of popcorn, corn chips, tortilla chips, and sec-ond- and third-generation extruded snacks. The last two chapters of the manual contains protocols to bioenzymati-cally transform starch into modified starches and different types of syrups and sweeteners, laboratory processes for the production of regular and light beers, distilled spirits, and fuel ethanol.

By working carefully through the contents of this book, the reader will acquire the practical side and hands-on expe-rience of many quality control procedures and experimen-tal product development protocols of cereal-based products. Furthermore, from these foundations the developing profes-sional will be able to enhance research skills for product development, process design, and ingredient functionality.

(22)

xxi

Acknowledgments

The author wishes to thank all former and current under-graduate and under-graduate students who have shared with him, throughout the past 25 years, their interest in the fascinating fields of cereal science, technology, and processing. Their interest and dynamism is his upmost motivation. The author

wishes to especially recognize Dr. Esther Perez-Carrillo, Ana Chew-Guevara, Erick Heredia-Olea, Cristina Chuck-Hernandez, and Alexandra Robles for their skillful assis-tance in the elaboration of figures and photographs.

(23)

(24)

xxiii

Author

Dr. Sergio O. Serna-Saldivar is head and professor of the Biotechnology and Food Engineering Department, Tecnologico de Monterrey. Before this, he was research scientist at the Soil and Crop Science Department at Texas A&M University, consultant for EMBRAPA at Río de Janeiro, Brazil, and associate professor for the University of Sonora. He is cur-rently the research chair leader of “Nutraceutical Value of Indigenous Mexican Foods and Plants.” He has been a member of the American Association of Cereal Chemists for over 25 years and the Institute of Food Technologists and has acted as associate editor for the journals of Cereal Chemistry and

Cereal Science. He was a member of the AACC International Board of Directors. He received his B.S. in Animal Science/ Agricultural Engineering from ITESM and his M.Sc. and Ph.D. degrees in Scientific Nutrition and Food Science and Technology from Texas A&M University. He has published six books, 21 chapters, 80 referred journal articles, six pat-ents, and is the codeveloper of the wheat variety TAM-202. He has directed 52 M.Sc. and five Ph.D. students. His research interests focus on chemistry, nutraceutical/nutritional proper-ties, and biotechnology of maize, sorghum, and other grains. He belongs to the maximum level of the Mexican National Research System and the Mexican Academy of Sciences. In addition, he was awarded the “Luis Elizondo” award in Agricultural and Food Industries, the 2004 AACC Excellence in Teaching award, and is a six-time awardee of the Teaching and Research Award at Tecnologico de Monterrey.

(25)

(26)

xxv

List of Equivalences

Kitchen Unit Conversions

Cup 0.24 L or 240 mL or 0.5 pints or 16 tablespoons

Cup of water 230 mL

Cup of flour 100 g

Cup of powdered chocolate 100 g

Cup of fresh egg 227 g or 0.5 lb

Cup of egg whites 227 g or 0.5 lb

Cup of egg yolks 227 g or 0.5 lb

Cup of fluid milk 230 mL or 0.5 lb

Cup of dry milk 114 g or 0.25 lb

Cup of brown sugar 150 g or 0.33 lb

Cup of powdered sugar 130 g or 0.285 lb

Cup of honey 340 g or 12 oz

Cup of oil 225–230 mL

Cup of shortening 180 g

Teaspoon 0.33 large spoon

Tablespoon 3 teaspoons or 16 = 1 cup

1 butter stick 90–100 g

1 egg (without shell) 45–50 g or approximately 0.1 lb

1 egg white 29–33 g or 0.062 lb

1 egg yolk 17–18 g or 0.04 lb

1 tablespoon of salt 14 g

1 tablespoon of baking powder 11.3 g

1 tablespoon vanilla 14 mL

1 tablespoon of dry yeast 10 g

1 tablespoon of ground cinnamon 6.3 g

1 tablespoon of cream of tartar 9.5 g

1 tablespoon of lemon juice 14 mL

Length Conversion Factors

Meter (m) 100 cm or 39.37 in or 3.28 feet or 1.094 yards

Centimeter (cm) 10 mm

Inch 2.54 cm or 25.4 mm

Foot 12 in or 30.48 cm

Yard 3 ft or 36 in or 0.914 m

Weigh Conversion Factors

Kilogram (kg) 1,000 g or 2.2 lb or 35.3 oz

Gram (g) 0.001 kg or 1,000 mg

Ounce 28.35 g

Pound 454 g or 16 oz

Volume Conversion Factors

Cubic meter (m3₎ _{1,000 L}

Cubic meter (m3₎ _{33.3 ft}3

Hectoliter 100 L or 0.1 mt3

Liter (L) 1,000 mL or cm3_{or 4.22 cups or 1.057 pint}

Milliliter (mL) 0.001 L

Bushel (bu) USA 8 gal or 35.24 L

Bushel (bu) UK 8 gal or 36.37 L

Pint 0.473 L or 0.125 gal

(27)

xxvi List of Equivalences

Gallon 3.785 L or 8 pints or 4 quarts

Fluid ounce 29.6 mL

Density Conversion Factors

Pounds (lb)/bushel (bu) 1.247 kg/hL

Pressure Conversion Factors

1 kg/cm2 _{14.21 psi}

1 psi 0.07 kg/cm2

1 psi 6,894 Pa

1 kPa 0.145 psi

Temperature Conversion Factors

Degrees centigrade 5/9 (°F – 32)

(28)

1

1 Physical and Morphological

Properties of Cereal Grains

1.1 IntroductIon

Cereals are one-seeded fruits of the Gramineae family designed to store nutrients critically important for the per-petuation of the species. Kernels are protected by physical barriers and chemical compounds against external biotic agents. Nevertheless, the different genus, species, and types differ in their grains’ physical, chemical, and morphological characteristics. These features are also affected by the envi-ronment, especially during maturation in the field, and by storage conditions. The main criteria used to select grains for specific uses are related to their physical properties because they affect chemical composition, functionality, and end use.

Therefore, the determination of the physical properties, grade, and class plays an important and critical role in the market value of any given lot of grain. Grain classification and grading assures that a particular lot of grain meets preestab-lished quality parameters. Federal governments usually have impartial regulatory agencies in charge of assigning grain quality. Furthermore, the standardization of grain quality allows better and fairer marketing between sellers and buyers and also allows processors to blend lots of grains with similar grade or quality (Kiser 1991). The value of any given lot of grain depends on both grade and class. Grade is an indication of quality and grain health condition whereas class is related to the potential use or functionality of the grain (color, glu-ten type, hardness, etc.). The classification systems are aimed toward the facilitation of impartial commercialization of grains, providing information related to grain quality for stor-age and further processing, and providing information that can be further related to yields of products and by-products (milling yields, end-product quality, etc.).

All cereal plants produce protected or covered fruits. The kernel, which is botanically termed a caryopsis, is a mono-cotyledon. The caryopsis consists of a pericarp (fruit coat) and a true seed. The seed consists of a germ and endosperm covered by a seed coat or testa and a single or multilayered aleurone. Some cereal grains, such as oats, rice, and barley, tightly retain the glumes after harvesting and consequently are considered as husked grains. The rest of the cereals are commonly known as naked caryopses because they gener-ally lose the ventral and dorsal glumes known as lemma and

palea, respectively, during harvesting.

To understand the important changes that cereals undergo during processing, it is essential to comprehend the macro-structure and micromacro-structure, physiology, and the composi-tion of each anatomical part of the caryopsis. Among each type of cereal, important variations exist in endosperm

hardness due to the different proportions of vitreous and floury endosperm types, pericarp color and thickness, type of starch, and kernel size.

1.2 determInatIon of PhysIcal ProPertIes of cereal GraIns 1.2.1 TesT WeighT

The bushel, test or volumetric weight is the most critical cri-teria to determine grade and class. The test simply consists of first sampling the grain which is then placed in a con-tainer with a proven volume. The grain is weighed and the test weight or apparent density is calculated. Test weights are

generally expressed in pounds per bushel (2150.42 in.3_{) or in}

kilograms per hectoliter (100 L). The conversion factors of

pounds per Winchester bushel (2150.42 in.3_{) and pounds per}

imperial bushel (2219.36 in.3_{) to kilograms per hectoliter are}

1.297 and 1.247, respectively. The bushel weight is closely related to the true grain density and therefore is affected by grain condition, grain texture, and even grain protein con-tent. This test is very useful because insects, molds, and sprouted or heat-damaged kernels have a lower test weight when compared with healthy or sound counterparts. On the other hand, vitreous or corneous grains with a slightly higher protein content are usually denser. Lots of grains with higher moisture contents usually have a lower test weight because

water has a density of 1 g/cm3_{, whereas starch has a density}

of 1.6 g/cm3_{. Insect-perforated kernels have a lower}

appar-ent density because the air in the perforations has a density

of only 0.1 g/cm3_{. Both grade and class are affected by test}

weight. The most common way to measure test weight is by the Winchester bushel meter provided with different cups with a known volume.

1.2.1.1 test Weight Procedure

Grain test weights are usually measured according to Method 55-10 (American Association of Cereal Chemists; AACC 2000).

A. Samples, Ingredients, and Reagents

• Different lots of grains

B. Materials and Equipment

• Digital scale • Boerner divider • Ruler

• Seed clipper or Carter dockage test meter • Winchester bushel meter apparatus • Strike-off stick

(29)

2 Cereal Grains: Laboratory Reference and Procedures Manual

C. Procedure

1. Obtain a representative grain sample, preferably by using the Boerner divider.

2. Fill the hopper or the Cox funnel of the Winchester bushel meter with enough grain to fill the cup. Make sure the hopper gate is closed and to place a pan to collect excess grain. 3. Move the hopper so its gate is aligned right in

the center of the cup.

4. Open the gate and allow the grain to flow and overfill the cup (Figure 1.1).

5. Carefully remove excess grain from the cup with the aid of a strike-off stick moved verti-cally over the cup’s rim. Excess grain should be removed with a zigzag motion.

6. Weigh the grains in the cup with an accuracy of 0.1 g.

7. Calculate test weight or apparent density by dividing the weight/volume. Express test weight in pounds per bushel (lb/bu) and kilograms per hectoliter (kg/hL). To convert test weight from kilograms per hectoliter to pounds per bushel, multiply the number by 0.6674. One bushel is equal to 0.303 hL.

1.2.2 True DensiTy

True grain density, generally expressed in grams per cubic centimeter, is commonly determined by measuring the weight of a given volume that is displaced by a known weight of test material. True density can be determined by ethanol displacement or by air, nitrogen, or helium displacement using a pycnometer. Nitrogen is the most commonly used

gas. Another popular way to determine density is by alco-hol displacement. True density values are important because they are closely related to grain condition, endosperm tex-ture, and milling yields. Dense grains are less prone to insect damage and have better handling properties (less susceptible to breakage) during storage, commercialization, and pro-cessing. For wheat, density values are strongly associated to class and functional use. The density of other grains, such as maize and sorghum, is also important for dry and wet mill-ers. For dry-milling, the industry selects grains with higher density because they usually yield more and better quality products. The wet-milling industry typically uses less dense or softer kernels because these kernels require shorter steep-ing requirements and commonly yield more starch.

1.2.2.1 determination of true density with the Pycnometer

• Different lots of grains

• Scale

• Multipycnometer (model MUP-1) • Boerner divider

• Nitrogen gas

C. Procedure

1. Turn the multipycnometer power on 10 to 15 minutes before testing.

2. Obtain a representative grain sample, prefer-ably by using the Boerner divider. Make sure the sample is free of foreign material, broken kernels, and other types of kernels. If necessary, clean the grain with a clipper, air aspiration sys-tem, or a Carter dockage tester.

(a) (b) (c)

(30)

3

Physical and Morphological Properties of Cereal Grains

3. Weigh an 80-g sample to an accuracy of 0.01 g and place it in the pycnometer cup (Figure 1.2). Place cup with grain in the sample cell.

4. With the selector valve at the cell position, open the “gas out” toggle valve and wait for a stable reading near zero.

5. Close the gas out valve and set the meter to zero. 6. Open the “gas in” toggle valve to pressurize the

cell to 15 psi to 17 psi. Stop the gas flow by clos-ing the gas in valve.

7. Record the pressure reading as P1 after stabi-lization and then turn the selector valve to cell position and record the pressure as P2.

8. Release pressure by opening the gas out toggle valve.

9. Calculate the volume of gas using the

follow-ing equation: volume (cm3_{) = Vc − Vr × [(P1/}

P2) – 1], where Vc = large sample cell volume = 149.67, Vr = large reference volume = 71.60. Calculate the true density by dividing grain weight/volume. Express true density in grams per cubic centimeter (Figure 1.2).

1.2.2.2 determination of density with alcohol displacement

Density was calculated using the method of Rooney (2007).

• Different lots of grains • Anhydrous ethanol • Distilled water

• Digital scale

• Air-aspiration system

• Graduated cylinders (100 mL) • Boerner divider

• Carter dockage tester

C. Procedure

1. Prepare an 80% ethanol solution by mixing 20 mL of water and 80 mL of anhydrous ethanol. 2. Obtain a representative grain sample,

prefer-ably by using the Boerner divider. Make sure the sample is free of foreign material, broken kernels, and other types of kernels. If necessary, clean the grain with a clipper, air aspiration sys-tem, or a Carter dockage tester. The idea is to test only whole kernels.

3. Determine the weight of the empty graduated cylinder.

4. Fill the graduated cylinder to the 100 mL mark with the whole kernels. Tap the cylinder several times to settle the kernels and then add more kernels to bring the level back to the 100 mL mark.

5. Weigh the filled cylinder and subtract the empty weight to obtain the exact kernel weight. 6. Measure 100 mL of the 80% ethanol solution in

the second graduated cylinder.

7. Pour the ethanol slowly into the cylinder con-taining the whole kernels. Fill this cylinder to the 80 mL mark (the alcohol solution should cover all kernels). Tap the cylinder several times to remove trapped air bubbles and then refill to the 100 mL mark with the 80% ethanol solution.

8. Record the volume (in milliliters) of the ethanol solution left in the second cylinder. This volume is the volume of grain displaced.

9. Calculate the density by dividing the kernel weight by the volume of ethanol left in the second graduated cylinder. Express results within two decimal places in grams per cubic centimeter.

1.2.3 FloTaTion inDex

The flotation test was originally developed by the Quaker Oats Company as a quick index of grain density and dry- milling quality. The test simply consists of preparing one

(i.e., 1.275 g/cm3_{) or various sodium nitrate solutions with}

different specific gravities for the determination of the percentage of floating kernels. The number of floaters increases as moisture content increases, therefore, the per-centage of floaters is usually adjusted using a correction chart (Rooney and Suhendro 2001). Soft kernels contain larger quantities of air in the endosperm and float more than hard ones.

(31)

4 Cereal Grains: Laboratory Reference and Procedures Manual

1.2.3.1 determination of floating Kernels A. Samples, Ingredients, and Reagents

• Different types of maize kernels • Sodium nitrate

• Water

• 1 L beaker • Thermometer • Hydrometer (1.2–1.42 g/cm3_range) • 250 mL graduated cylinder • Hot plate • Stirring rod • Wire screen basket • Chronometer

C. Procedure

1. Clean the grain sample and discard broken ker-nels. Determine moisture content and test and thousand kernel weights (refer to procedures in Sections 2.2.1.1, 1.2.1.1, and 1.2.7.1).

2. Randomly select three sets of 100 sound kernels. 3. Prepare a solution of sodium nitrate (178.9 g in

250 mL of water) with a density of 1.275 g/cm3_.

Control the temperature of the solution to 21°C, preferably in a water bath (Figure 1.3). Read the density of the resulting solution with the hydrometer. If necessary, adjust density by adding water to reduce it or sodium nitrate to increase it.

4. Deposit 500 mL to 600 mL of the solution tem-pered to 21°C previously prepared in a 1-L beaker. 5. Add 100 kernels and agitate every 30 seconds

for 5 minutes (Figure 1.3).

6. Suspend agitation and after 1 minute, count the number of floating kernels. Express result as percentage of floating kernels = number of float-ing kernels/number of total kernels. Determine the standard error of the mean.

1.2.4 grain harDness

There are an ample number of subjective tests to estimate grain hardness. Hardness is mainly affected by the ratio of corneous to floury endosperm and apparent and true density values. The most practiced assays consist of subjecting, for a given time, a lot of grain to the abrasive action of a mechanical decorticator such as the tangential abrasive dehulling device or TADD mill. Softer kernels will lose more material or will break into smaller particles during decortication or impac-tion. There are other tests, mainly used by the wheat industry, in which kernels are milled using a standardized procedure. The particle size distribution of the resulting flour is related to hardness. Softer grains produce finer flours. The principle of determining particle size distribution has gained popularity because it can be adapted to near-infrared reflectance analysis (NIRA). The U.S. Department of Agriculture (USDA) is using this assay for grading wheat. There are many new methods to estimate hardness, especially developed for wheat varying from the estimation of hardness in single kernels and others based on the estimation of time, force, and even noise pro-duced in a standard mill during grinding. Recently, the NIRA has been used to predict hardness when a given ground sample is scanned at 1080 nm to 1180 nm. The NIRA hardness test proved to have a good correlation with kernel vitreousness and different parameters of the Stenvert test (Hoffman et al. 2010).

(a)

(c)

(b)

fIGure 1.3 Procedure to determine percentage of floating kernels. (a) Reagent necessary for sodium nitrate solution; (b) heating solution;

(32)

5

Physical and Morphological Properties of Cereal Grains

1.2.4.1 subjective determination of the ratio of soft to hard endosperm or endosperm texture

The subjective evaluation of the relative amount of corneous to floury endosperm is critically important because it is the main factor affecting grain hardness and density. This factor is greatly affected by genetics and environment. The deter-mination of the ratio of soft to hard endosperm is critically important in the wheat industry because different classes of wheat have different ratios of the two types of endosperms. Soft wheats are mostly floury whereas durum wheats contain vitreous endosperms. Most hard wheats contain intermediate endosperm textures. The same applies for maize kernels. The flint or corneous types, in which popcorn is included, contain hard endosperm whereas dent corns may contain genotypes with different proportions of hard to floury endosperms. The ratio of soft to hard endosperm greatly affects dry- and wet-milling operations and optimum cooking times. The subjective method simply consists of bisecting the kernel in preparation for the observation of the hard or vitreous (translucent) to soft or floury (opaque) endosperm. It is recommended that at least 10 kernels should be rated because of natural variations.

• Different types of grains • Distilled water

• Light box • Tweezers • Scalper

C. Procedure

1. Obtain a representative grain sample from the lot of grain preferably from the Boerner divider. Randomly select 10 kernels and place them on a light box for viewing.

2. Determine the ratio of soft-floury-chalky to vitreous-hard-glassy endosperm of each ker-nel using a 1 to 5 scale (1, totally vitreous; 2.5, 50% vitreous and 50% soft; and 5, totally soft or floury). The soft endosperm will have an opaque appearance whereas the vitreous endosperm will have glassy translucent appearance (Figure 1.4). 3. After rating whole kernels, cut each kernel

lon-gitudinally with a scalper. Make sure to hold the kernels with a tweezer before cutting. Rate the ratio of soft to hard endosperm using a 1 to 5 scale (1, totally vitreous; 2.5, 50% vitreous and 50% soft; and 5, totally soft or floury).

4. Calculate the average and standard deviation of the 10 observations and the correlation between ratings of whole and longitudinally dissected kernels.

1.2.4.2 Procedure to determine Grain hardness using the tadd mill

There are several laboratory equipments devised for deter-mining grain hardness. The TADD mill (Oomah et al. 1981)

is commonly used to indirectly determine grain hardness especially of coarse grains (maize and sorghum). The pro-cedure simply consists of subjecting samples to the abrasive mechanical action of the mill for a certain time. Hard- and soft-textured grains lose less and more dry matter, respec-tively, during the fixed and standardized milling procedures. The TADD measures the resistance of the kernels to the abrasive action of a horizontal aluminum oxide wheel sur-face rotating at a constant speed. The amount of material removed is inversely related to hardness (Rooney 2007).

• Different lots of samples (maize, sorghum, or wheat)

• Digital scale • Boerner divider • Aluminum oxide disk • Chronometer

• Clipper or dockage test meter

• TADD mill (Venables Machine Works, Saska-toon, Canada)

• Eight-hole base

C. Procedure

1. Set up the TADD mill with the eight-hole base and verify the condition of the abrasive disk. 2. Clean the lot of grain manually or using a

clip-per or dockage test meter.

3. Obtain a representative cleaned grain sample and determine its physical properties (test

(a)

(b)

fIGure 1.4 Subjective determination of ratio of soft to hard

endosperm on a light box. (a) Kernels viewed on a light box; (b) kernels with different endosperm textures.

Cereal Grains

K12596

Laboratory Reference and Procedures Manual

Cereal Grains

Sergio O. Serna-Saldivar

Food & Nutrition

Laboratory Refer

ence and Pr

ocedur

es Manua

l

Cer

eal Grains

F

OOD

P

RESERVATION

T

ECHNOLOGY

S

ERIES

Cereal Grains

Laboratory Reference

and Procedures Manual

FOOD PRESERVATION TECHNOLOGY SERIES

Gustavo V. Barbosa-Cánovas

Cereal Grains

Laboratory Reference

and Procedures Manual

Sergio O. Serna-Saldivar

This practical handbook is dedicated to my lovely father Dr. Pablo Serna Treviño,

who recently passed away. His love, guidance, motivation, and support

Contents

Preface

Acknowledgments

Author

List of Equivalences

1

Physical and Morphological

Properties of Cereal Grains
