Parallel Implementations of Dynamic Traffic Assignment
Models and Algorithms for Dynamic Shortest Path Problems
by
Hai Jiang
Submitted to the Department of Civil and Environmental Engineering
on Septermber 10, 2003, in partial fulfillment of the
requirements for the degree of
Master of Science in Transportation
Abstract
This thesis aims at the development of faster Dynamic Traffic Assignment (DTA)
models to meet the computational efficiency required by real world applications. A
DTA model can be decomposed into several sub-models, of which the most time
consuming ones are the dynamic network loading model and the user's route choice
model.
We apply parallel computing technology to the dynamic network loading model
to achieve faster implementations. To the best of our knowledge, this concerns the
first parallel implementations of macroscopic DTA models. Two loading algorithms
are studied: the iterative loading algorithm and the chronological loading algorithm.
For the iterative loading algorithm, two parallelization strategies are implemented:
decomposition by network topology and by time. For the chronological loading
algo-rithm, the network topology decomposition strategy is implemented. Computational
tests are carried out in a distributed-memory environment. Satisfactory speedups are
achieved.
We design efficient shortest path algorithms to speedup the user's route choice
model. We first present a framework for static shortest path algorithms, which
pri-oritize nodes with optimal distance labels in the scan eligible list. Then we apply the
framework in dynamic FIFO, strict FIFO, and static networks. Computational tests
show significant speedups.
We proceed to present two other shortest path algorithms: Algorithm Delta and
Algorithm Hierarchy. We also provide the evaluations of the algorithms.
Thesis Supervisor: Ismail Chabini
Acknowledgments
I would like to thank Professor Chabini for his guidance, insights and encouragement
throughout all stages of the research. I would like to thank his patience in explaining to me many concepts and ideas. He is not only a respectful advisor, but also a great friend of mine. In addition, I enjoy many of the discussions we had in the past two years about life.
I would like to thank my collegues in the ACTS group for their friendship and assistance.
Thanks to Ford Motor Company and the National Science Foundation ( CAREER Award Grant CMS-9733948 and ETI Award Grant CMS-0085830) for supporting this research.
