PANENE: A Progressive Algorithm for Indexing and

Querying Approximate k-Nearest Neighbors

Jaemin Jo, Jinwook Seo, Jean-Daniel Fekete

To cite this version:

Jaemin Jo, Jinwook Seo, Jean-Daniel Fekete.

PANENE: A Progressive Algorithm for

Index-ing and QueryIndex-ing Approximate k-Nearest Neighbors.

IEEE Transactions on Visualization and

Computer Graphics, Institute of Electrical and Electronics Engineers, 2020, 26 (2), pp.1347-1360.

�10.1109/TVCG.2018.2869149�. �hal-01855672�

(2)

PANENE: A Progressive Algorithm for Indexing

and Querying Approximate k -Nearest Neighbors

Jaemin Jo, Jinwook Seo, and Jean-Daniel Fekete, Senior Member, IEEE

Abstract—We present PANENE, a progressive algorithm for approximate nearest neighbor indexing and querying. Although the use of k -nearest neighbor (KNN) libraries is common in many data analysis methods, most KNN algorithms can only be queried when the whole dataset has been indexed, i.e., they are not online. Even the few online implementations are not progressive in the sense that the time to index incoming data is not bounded and cannot satisfy the latency requirements of progressive systems. This long latency has significantly limited the use of many machine learning methods, such ast-SNE, in interactive visual analytics. PANENE is a novel algorithm for Progressive Approximatek-NEarest NEighbors, enabling fast KNN queries while continuously indexing new batches of data. Following the progressive computation paradigm, PANENE operations can be bounded in time, allowing analysts to access running results within an interactive latency. PANENE can also incrementally build and maintain a cache data structure, a KNN lookup table, to enable constant-time lookups for KNN queries. Finally, we present three progressive applications of PANENE, such as regression, density estimation, and responsivet-SNE, opening up new opportunities to use complex algorithms in interactive systems. Index Terms—Approximate k -Nearest Neighbors, Progressive Data Analysis, Algorithm, Real-Time

F

1 I

NTRODUCTION

P

ROGRESSIVEdata analysis has recently gained in popu-larity due to its ability to deliver ongoing results before the whole computation is completed [1], [2]. However, de-spite the advantages, it is not always simple or even possible to convert a sequential algorithm directly to a progressive one. Such a hurdle hinders the applicability of progressive computation to a wider range of data analyses. In this arti-cle, we address one important problem: progressively find-ing k-nearest neighbors of a given point in a multidimen-sional space, i.e., the k-nearest neighbor problem. We present a novel progressive algorithm, PANENE, for Progressive Approximate k-NEarest NEighbors, broadening the bound-ary of progressive visual analytics. In contrast to sequential or online algorithms that have been proposed, PANENE is progressive; it guarantees to finish its operations in a given number of cycles and thus does not block the whole system when loading or processing data continuously.It allows us to bring useful machine learning methods, such as t-SNE [3], into interactive visual analytics, which has been limited due to their long computation time.

The k-nearest neighbor (KNN) problem is an optimiza-tion problem of finding the k closest points to a query point in a multidimensional metric space. Formally, given N points P = {p1, · · · , pN}, pi ∈ RD, and a query point

q ∈ RD

, a KNN search finds the k-nearest points of q in P . Formally, this operation can be stated as follows:

KNNk(q) 7→ {i1, i2, · · · ik}, where ij∈ [1, N ]

KNNk(q) is a set of indices that satisfy the following • Jaemin Jo is with Seoul National University, Korea,

E-mail: [email protected]

• Jinwook Seo is with Seoul National University, Korea, E-mail: [email protected]

• Jean-Daniel Fekete is with Inria, France, E-mail: [email protected]

Manuscript received April 19, 2005; revised August 26, 2015.

condition:

∀i ∈ KNNk(q) ∀j ∈ [1, N ] − KNNk(q), kq, pik ≤ kq, pjk,

where kq, pk is the distance between q and p. The KNN problem is a building block of many data mining and visu-alization methods, such as clustering [4], classification [5], embedding [6], and non-parametric density estimation [7]. Thus, designing an efficient progressive algorithm for the KNN problem is an important step towards extending the applicability of progressive computation.

One straightforward approach is to calculate the dis-tances from a query point q to every point in the dataset and take the k closest. However, this method is inefficient, since it has to iterate over all points and thus has time complexity of θ(N ). A more efficient approach is to use a search data structure or an indexing method such as a k-d tree, which usually reduces the time complexity to a logarithmic scale.

In recent years, there have been important advances in data structures and algorithms to speed up KNN queries. These advances have mostly focused on optimizing the query time, considering that the indexing was done once for all data points and thus the indexing time was less important than the query time [8]. However, for progres-sive systems, both times are important because data can be loaded progressively, the KNN queries can be done progressively, and therefore the index should be updated progressively as well.

A popular approach to improve the query time is to compute approximate k-nearest neighbors instead of ex-act ones. Approximate k-nearest neighbor search (AKNN) techniques are more efficient than exact KNN, but all of them also require building an index. For example, the most efficient method to date, the hierarchical navigable small-world graph (HNSW) [9], needs all data points to be loaded upfront and a special graph structure to be built before querying. From the visual analytics point of view, such

(3)

a precomputation leads to long loading time, hampering the interactivity of the entire system. Only few AKNN techniques, such as FLANN [10], support online updates; they allow inserting new points even after an index is built. However, this is not sufficient for interactive visual analytics because the insertion time is not bounded. Indeed, we observed that FLANN pauses longer than 10 seconds to update its index with a few hundred thousand points, exceeding the time limit to keep the user’s attention [11].

In this paper, we present aprogressive algorithm for in-dexing and querying approximate k-nearest neighbors.Our algorithm computes k-nearest neighbors iteratively with each iteration finishing in a given number of operations (i.e., progressively).The contributions of this article are

• a progressive k-d tree data structure that can sustain

a controlled latency while it is created, updated, and queried;

• an algorithm for building and updating a lookup data

structure that we call a KNN lookup table, which en-ables constant-time lookups for KNN queries; and

• progressive applications of PANENE, including

regres-sion, density estimation, and responsive t-SNE [3]. This paper is organized as follows: we first review pre-vious approaches to the KNN problem and discuss new challenges and requirements in interactive visualization sys-tems. In section 3, we show how we improve the sequential k-d tree algorithm to become first online and then progres-sive, which is the first contribution of PANENE. In Section 4, we elaborate on the second contribution of PANENE: KNN lookup tables, meant to speed up repeated KNN queries. In the following two sections, we evaluate the performance of PANENE through benchmarks (Section 5) and present applications in interactive analysis (Section 6). Finally, we discuss the limitations of this work and future work.

2 R

ELATED

W

ORK

In this section, we first introduce previous approaches to the k-nearest neighbor problem in parallel with progressive systems for interactive analysis of large-scale data. Then, we present the challenges and opportunities in designing a progressive algorithm for the k-nearest neighbor problem.

2.1 The k -Nearest Neighbor Problem

The early approaches to the k-nearest neighbor problem focused on finding the exact neighbors of a query point. First introduced in the seminal work by Bentley [12], k-d trees have been one of the most widely used methods for KNN queries. The original k-d tree iteratively splits the space with axis-aligned hyperplanes and builds a binary tree, allowing a logarithmic time complexity for KNN queries [13]. At each level in the tree, data is divided into two groups along the dimension in which the data has the highest variance. Then, the tree can be used to reject points in distant subspaces early on for a more efficient search.

While the original k-d trees are effective for searching in low-dimensional spaces, they suffer from significant perfor-mance degradation as the dimensionality of data increases; this problem is related to the so-called “curse of dimen-sionality” [14]. To overcome this limitation, recent research

relaxed the requirements of KNN search by allowing it to re-turn approximate neighbors with parameters for controlling the quality. These techniques, which are called approximate k-nearest neighbor (AKNN) search, are not guaranteed to return the exact k-nearest neighbors of a query point but good approximates of neighbors that are close to the query point in a short time. Due to their flexibility, AKNN tech-niques have become common in modern toolkits such as scikit-learn [5] and OpenCV [15]. We can categorize popular AKNN techniques in three families: space-partitioning trees, hash-based, and graph-based.

The simplest data structures for KNN are space-partitioning trees. They recursively divide a multidimen-sional space and build a tree structure that can be used to accelerate searching. Many k-d tree variants have been proposed to reduce the query time for KNN searches. Beis and Lowe [16] showed that limiting the number of visited nodes in a k-d tree could bring a large reduction in the query time with a small loss in accuracy. For KNN search in higher-dimensional spaces, Silpa-Anan and Hartley [17] presented the idea of multiple randomized k-d trees where data is recursively split along a dimension that is randomly chosen from a small set of candidate dimensions with the highest variance. Muja and Lowe [18] identified the two best algorithms for AKNN querying—randomized k-d trees and hierarchical k-means trees—and presented an algorithm that selects optimum parameters for the algorithms in terms of speed and accuracy criteria. Going one step further, they successfully extended their work to perform distributed nearest neighbor search on a cluster of machines [10].

Hash-based techniques use a set of locality-sensitive hashing (LSH) functions [19]. The core idea is that a pair of close points is more likely to fall into the same bucket after hashing than a pair of distant points. Therefore, hash-based techniques can efficiently search for neighbors by looking up the buckets that a query point falls into. The strength of hash-based techniques stems from the fact that they can provide a theoretical base on the search quality. Examples include LSH forest [20], multi-probe LSH [21], kernelized LSH [22], and circular random variable-based matchers [23]. Graph-based techniques model multidimensional data points as a graph by mapping points to vertices and the neighborhood relationships to edges. Once the graph is built, AKNN search can be done by exploring the graph. From a KNN graph, Sebastian and Kimia [24] selected a few well-separated vertices (i.e., seeds) and iteratively moved the seeds to points that are closer to the query point until satisfactory neighbors were found. Hajebi et al. [25] pro-vided theoretical guarantees for the accuracy and the com-putational complexity of such a greedy method. Recently, more sophisticated graph structures such as navigable small world graphs are used for KNN queries. In addition to short-range links in a traditional neighbor graph, navigable small world graphs have long-range links that connect two distant points. Malkov et al. [14] showed that these long-range links can be used for logarithmic scaling of neighbor exploration. Yet, the construction of the graphs is costly and cannot easily be done online.

Throughout a few decades of KNN research, query time (i.e., time taken to perform a KNN search) has been the key measure for evaluating the performance of various

(4)

techniques. Indeed, in most studies mentioned in this sec-tion, authors assumed that data points had already been inserted in an index and measured the time taken to process queries. This is also the case with benchmarks in the public domain [8], [26]. However, such benchmarks are meaningful only when the data is kept constant. In more interactive scenarios, such as interactive analysis by human analysts, the data can be changed dynamically through user inter-action, such as loading a new set of data or filtering out a subset of data. Thus, it is necessary to keep the whole process of KNN queries, including building and querying the index, interactive. In this paper, inspired by Progressive Visual Analytics [2], we introduce a progressive k-d tree for approximate k-nearest neighbor search that can keep the latency for building, maintaining, and querying the index within specified time bounds. We chose to start with the multiple randomized k-d tree algorithm, which is simple yet one of the most efficient algorithms for AKNN queries [18].

2.2 Progressive Systems

The latency of interactive systems has become a primary concern for visualization researchers and practitioners. As the size of datasets increases and analytic methods become more sophisticated, delivering results within a time limit becomes a new challenge in designing visual exploration systems. Reducing the latency is an essential problem in visual analytics, because long latency not only delays anal-ysis but also outpaces humans’ ability to focus their atten-tion, eventually degrading the quality of the analysis [27]. Nielsen [11] distinguishes three time limits for users’ percep-tion and attenpercep-tion: 0.1 second for feeling that the system is continuous (e.g., for animations), 1.0 second for maintaining the user’s flow of thought, and 10 seconds for keeping the user’s attention. Similar guidelines on latency have been also suggested by other researchers [28], [29]. However, sequential systems (i.e., systems that hang until the entire computation is done) cannot be guaranteed to comply with such time constraints, leading analysts to wait for a response without bounds and hurting their analytical capabilities.

Initially introduced by Stolper et al. [2], the Progressive Visual Analytics (PVA) paradigm considers humans’ per-ceptual and cognitive constraints as the primary concern in system designs. PVA systems deliver the partial results of computation on the fly without blocking analysis until the complete result becomes available. It is akin to the online computation paradigm [30] in that the user can grasp meaningful partial results before the whole computation is finished. PVA has significant benefits: it guarantees that the latency to have a new partial result will be bounded in time, meaning that analysts can expect to receive the new result within the human attention span.

The benefits of PVA have been advocated through the user experiments in the HCI field. For example, Fisher et al. [31] investigated how the user understands and interacts with incremental approximate visualizations. Their result suggested that users were capable of using incremental visualizations to make their decisions faster. More recently, Zgraggen et al. [27] compared progressive visualizations to blocking and instantaneous visualizations in terms of the insights that the user generated. They found progressive

visualizations outperformed blocking visualizations, even giving comparable performance to ideal instantaneous visu-alizations. Similar results can be elicited from Badam et al.’s user study [32], where a progressive interface, InsightsFeed, and its instantaneous version showed similar performance in terms of answer accuracy and user preferences.

Despite the benefits and established grounds of progres-sive computation, it is not always easy or even possible to convert a sequential algorithm into a progressive one. A vast body of research has attempted to provide the progressive version of sequential algorithms, widening the boundary of progressive visual analytics. The pioneering work of Stolper et al. [2] provided a progressive implemen-tation of the SPAM algorithm [33] for extracting common patterns in event sequences. Pezzotti et al. [6] presented approximate t-Distributed Stochastic Neighbor Embedding (A-tSNE) which can be used to progressively visualize multidimensional data in 2D spaces. Similarly, Turkay et al. [34] proposed DimXplorer, which enabled interactive exploration using the incremental PCA and mini-batch k-clustering algorithms. Fekete and Primet implemented the Progressivis Toolkit [1] to provide a general and system-atic platform for progressive implementations; we rely on the data structures and mechanisms they describe.Finally, M ¨uhlbacher et al. [35] characterized strategies for increasing user involvement in existing sequential algorithms.

In this paper, we focus on one important yet under-explored problem of developing a progressive algorithm for the k-nearest neighbor problem. To our best knowledge, no previous research has studied this problem in spite of its wide use in data analysis.

3 A

PPROXIMATE

k -N

EAREST

N

EIGHBOR

In this section, we first describe a sequential algorithm using randomized k-d trees for approximate k-nearest neighbor (AKNN) search, and then improve it, to become first online and then progressive. Among many algorithms mentioned in the related work section, we chose to improve a k-d tree because 1) it is known to be efficient and yet easy to implement [18] and 2) an online version of the algorithm is available as open-source [36], so we could directly compare our progressive version to the online version.

3.1 A Sequential Algorithm

A k-d tree is a binary tree built by recursively partitioning a multidimensional space using axis-aligned hyperplanes [12] and used thereafter to search, guaranteeing O(log N ) search time and O(N log N ) build time. At the root node, the algorithm chooses a cutting dimension that has the largest variance and assigns points to child nodes: The points whose values on the cutting dimension are less than the median are assigned to the left child, and the remaining points are assigned to the right child. This procedure repeats until only one point remains in a node. In the randomized k-d tree forest, we randomly choose a cutting dimension among the top n dimensions with the largest variance, typically, n = 5 (see Algorithm 1). This allows building mul-tiple randomized trees for the same data and representing neighborhood in high-dimensional spaces more effectively.

(5)

Algorithm 1A sequential algorithm for recursively building a randomized k-d tree of the given l points in L

1: procedureBUILDSEQUENTIAL(L)

Input: Lis a list of l points of D dimensions.

Output: The root node of a randomized k-d tree

2: if Lhas only one point then

3: node ← a new leaf node

4: node.point ← L[0]

5: return node

6: end if

7:

8: node ← a new internal node

9: calculate the variance of each dimension in L

10: node.cutdim ← a random dimension with large variance

11: node.cutval ← median([p[node.cutdim] for p in L])

12:

13: left ← [p for p in L if p[node.cutdim] ≤ node.cutval]

14: right ← [p for p in L if p[node.cutdim] > node.cutval]

15:

16: node.left ← BUILDSEQUENTIAL(left)

17: node.right ← BUILDSEQUENTIAL(right)

18: return node

19: end procedure

Algorithm 1 has three strong limitations: First, it requires all the points in L to be already loaded in main memory before it can build the randomized k-d trees. Such a con-straint forces analysts to wait until all data is read from disk or database before performing any analysis. Second, once the data structures are built, the algorithm does not allow any modification, such as inserting new points or removing points. Finally, the running time of the algorithm solely depends on the size of input (i.e., l), and thus its latency cannot be controlled.

3.2 An Online Algorithm

In contrast to a sequential algorithm, an online algorithm allows adding new points to the trees even after they are built. This benefits interactive systems in that analysts do not have to wait until all data is loaded. Rather, the data is split into batches, loaded onto the system incrementally, and can be used for further online algorithms. Analysts can access the running result between the batches, obtaining improved approximations of the final results.

However, we only found one implementation of online AKNN: the FLANN library [10]. It can build an initial k-d tree of the points in the first batch using Algorithm 1, and other points can be added into the tree thereafter.

The insertion procedure of the FLANN library is very akin to that of a binary tree: Starting from the root node, each point moves to either the left or the right child of an internal node by comparing its value at the dimension chosen to split the values at that node—called the cutdim—against the median value computed initially for that node—the cutval— until it reaches a leaf node. Then, the leaf node becomes an internal node, and the two points (i.e., the point being inserted and the point of the leaf node) become the children of the former leaf node. Algorithm 2 describes the insertion procedure in more details.

As more points are inserted into a k-d tree, it can become unbalanced, lengthening the query time. In the FLANN li-brary, the distribution of the points in the first batch heavily

Algorithm 2An algorithm for inserting a new point p into a randomized k-d tree with a root node node

1: procedureINSERTPOINT(node, p)

Input: nodeis the root of a k-d tree

Input: pis a new D-dimensional point

Output: pis inserted as one of the leaf nodes in the tree

2: if nodeis a leaf node then

3: mark node as an internal node.

4: calculate the absolute difference between p and node.point at each dimension

5: choose a cutdim dimension with the largest difference

6: cutval ← (p[cutdim] + node.point[cutdim])/2

7: if p[cutdim] ≤ cutval then

8: node.left ← a new leaf containing p

9: node.right ← a new leaf containing node.point

10: else

11: node.left ← a new leaf containing node.point

12: node.right ← a new leaf containing p

13: end if

14: return

15: end if

16:

17: if p[node.cutdim] ≤ node.cutval then

18: INSERTPOINT(node.left, p)

19: else

20: INSERTPOINT(node.right, p)

21: end if

affects the overall performance, since they are used to build the “skeleton” of the tree. At worst, if all the updates after the first batch are skewed to one side of the k-d tree, all the remaining points are inserted in a linked list, and the search time becomes linear with the number of points. This implies the need to rebalance the tree when it is too unbalanced. In real cases, the imbalance is never that extreme but can vary substantially if the data added has a different distri-bution than the initial tree. The imbalance leads to a slower query time with little degradation of the result quality. On the other side, when updating a tree for a large dataset, assuming the data is stationary, the distribution of incoming data will at some point converge to the distribution of the whole dataset, and the tree will remain balanced even after new points are inserted.

FLANN’s implementation of k-d trees uses a simple strategy for rebalancing the trees: It reconstructs all trees each time the dataset doubles in size from the initial dataset (i.e., the first batch). Therefore, the k-d trees can become unbalanced as new data is loaded but eventually will be reconstructed. When loading a large dataset progressively, even if the incoming distribution matches the current k-d tree structure, FLANN will always reconstruct its k-d trees when the dataset doubles in size. To sum up, the FLANN implementation suffers from three problems:

1) the k-d tree may become unbalanced when data is added, leading to longer KNN searches;

2) the k-d tree is always reconstructed when the dataset doubles in size, leading to long interruptions in the KNN search at unpredictable moments; and

3) the k-d tree is always re-created when the dataset doubles in size, even when it remains balanced.

(6)

3.3 A Progressive Algorithm

To overcome the limitations of online k-d trees, we made three main changes to the FLANN algorithm:

1) we maintain a quality measure for each k-d tree, 2) we construct a fresh and balanced k-d tree with all

the points when the measure reaches a bad quality threshold, and

3) the construction is done in a task parallel/interleaved with the query task, thus spreading the load and avoid-ing brutal changes in query times. When a new k-d tree is built, we drop the most unbalanced one and replace it with that new one.

To estimate the quality of a k-d tree, we use the following method: Assume a k-d tree of size N is balanced; its depth is dlog2N e. The points are stored as leaves, so accessing

a point will require log2N operations. When a k-d tree

becomes unbalanced, its depth will vary, and the query time for a point p will be proportional to the depth of p. On average, the query time for accessing p is φp × depth(p),

where φp is the probability of searching p and depth(p) is

the depth of p in the tree. On a balanced k-d tree, the cost of querying for an arbitrary point is log2N , whereas for a

specific k-d tree T , the cost c(T ) is c(T ) =X

p∈T

φp× depth(p) (1)

The loss of a tree is thus the difference between the actual cost and the lower bound, i.e., the number of additional operations we should perform to search a point on average. To decide when we should trigger the computation of a fresh tree, this loss should be compared to the cost of rebuilding the whole tree: N log2N . We compute the loss

during each query (i.e., c(T ) − log2N )and accumulate the

loss throughout all trees. Once the accumulatedloss exceeds a threshold or a specific proportion of the rebuilding cost (i.e., α × N log2N , where α is a reconstruction weight), we

start the reconstruction.

In practice, we do not compute Equation 1 for every update but maintain the cost incrementally. For each point p, we maintain the depth of the point, depth(p), and the number of times the point is searched, freq(p). Let’s de-fineP freq = P_p∈Pfreq(p); then φp can be calculated by

φp = freq(p)

P

freq. Suppose that we insert a new point q into the

tree with the INSERTPOINTprocedure and that q reaches an existing point p at a leaf node. As the leaf node becomes an internal node and p becomes its child, the depth and frequency of p increase by one. The updated cost C0 is computed from the current cost C as follows:

C0 =P freq ×C + freq(p) + depth(p) + 1 P freq +1

After the update, we increment freq(p) and depth(p) by one. When we need to reconstruct a k-d tree (i.e., the accu-mulated loss exceeds the threshold), we distribute the re-construction load across multiple iterations by building the tree incrementally. To this end, we implement a non-recursive version of Algorithm 1 using a build queue, allowing the whole procedure to be interleaved between iterations. The progressive reconstruction algorithm (Algorithm 3) is

simi-lar to Algorithm 1, except that recursive calls are replaced with insertion into the queue.

Algorithm 3A progressive algorithm for building a new k-d tree

1: procedureINITIALIZEBUILD(L)

Input: Lis a list of l points of D dimensions.

Output: returns the root node of the new tree

2: queue ← a new work queue

3: root ← a new node

4: queue.push((root, L))

5: return root

7:

8: procedurePROCESSBUILDQUEUE(ops)

Input: opsis the number of operations for reconstruction

Output: returns true if reconstruction is done

9: count ← 0

10:

11: while count < opsand queue is not empty do

12: node, L ← queue.pop()

13: count ← count + 1

14:

15: if Lhas only one point then

16: mark node as a leaf node.

17: node.point ← L[0]

18: continue

19: end if

20:

21: calculate the variance of each dimension in L

22: node.cutdim ← a random dimension with large variance

23: node.cutval ← median([p[node.cutdim] for p in L])

24:

25: left ← [p for p in L if p[node.cutdim] ≤ node.cutval]

26: right ← [p for p in L if p[node.cutdim] > node.cutval]

27:

28: node.left ← a new internal node

29: node.right ← a new internal node

30:

31: queue.push((node.left, left))

32: queue.push((node.right, right))

33: end while

34:

35: return trueif queue is empty

To achieve progressiveness, the algorithm should work only for a given number of operations and stop, allowing the system to access the ongoing results. Each time the progressive algorithm runs, it is given a certain quantum of time, specified as a maximum number of operations that the algorithm is allowed to perform before returning ongoing results and releasing the control. The algorithm assigns a fraction of the operations to insertion tasks and the rest to reconstruction tasks. An insertion task reads one data point and inserts it into the k-d trees as described in Algorithm 2. If reconstruction is needed after insertion, the algorithm builds a new k-d tree incrementally by calling the function INITIALIZEBUILD first and the function PRO

-CESSBUILDQUEUEin the following iterations, as described in Algorithm 3. When the new k-d tree is built, the algorithm replaces the most unbalanced tree with the new one.

Algorithm 4 describes two procedures for initializing and updating progressive k-d trees, respectively. Both pro-cedures take the ops parameter, which is the number of operations allowed for each iteration. The algorithm can freely use this number of operations to perform either

(7)

insertion or reconstruction tasks. It can be either specified by the user or adaptively tuned by the system to limit the latency. The update procedure takes an additional param-eter τ that dparam-etermines the fraction of insertion tasks over reconstruction tasks. For example, when τ = 0.5, half of the operations are used (i.e., ops/2) to insert new points and the other half to reconstruct a tree. A progressive k-d tree with a larger value of τ will prioritize indexing new points, giving a lower priority to maintaining the trees balanced. Note that τ is only used during reconstruction; if reconstruction has not been started due to small accumulated loss, or because the trees remain balanced, regardless of the value of τ , all ops operations will be assigned to the insertion task.

Algorithm 4 uses an abstract data structure, a data source, as an input stream. A data source is a virtual list that repre-sents N points of D dimensions. However, the data source does not need to have all points loaded at the beginning; it can load some of them when needed. The loadN ewP oints function (e.g., line 21 in Algorithm 4) loads a given number of points on demand, avoiding uncontrolled latency result-ing from a full initial loadresult-ing. In addition, the data source abstracts the implementation of the loading procedure from the progressive computation, allowing users to choose the best method for that purpose.

Finally, note that even though a tree is balanced almost perfectly, the loss (i.e., c(T ) − log N ) is a small positive number, eventually leading to the construction of a new tree. To prevent this, we can optionally accumulate the loss only when the loss exceeds a certain value.

3.4 Filtered AKNN Search

Visual analytics should allow users to explore data by applying filters dynamically. To avoid rebuilding whole k-d trees when the user filters points, our progressive search algorithm can restrict its search to a selection of points. This selection is implemented through a very fast bit vector library [37]: The list of filtered points is converted into a compressed bitmap and passed to the search function that gathers the k neighbors, making the search function ignore the points in the bitmap. This filtered search is slightly slower than a non-filtered search, depending on the number of points filtered, but always faster than rebuilding whole k-d trees before performing the query.

The original FLANN algorithm has a provision for re-moving points from the k-d trees, marking them as deleted. Deleted points, just like our filtered points, are ignored by the search method. They are also filtered out from the reconstruction of balanced trees. Our implementation offers a more flexible mechanism at a low cost.

4 k -N

EAREST

N

EIGHBOR

L

OOKUP

T

ABLE

One frequent application of nearest neighbor search is finding the neighbors for every single point in the data, which is known as all nearest neighbor search [38]. Similarly, we can think of a search problem of finding the approx-imate k-nearest neighbors for every single data point in data, which we will call all approximate k-nearest neighbor (AAKNN) problem. The AAKNN problem becomes common in modern analytic methods to replace a complete distance

Algorithm 4 An algorithm for initializing and building progressive k-d trees

1: procedureINITIALIZEPROGRESSIVETREES(dataSource, ops)

Input: dataSourceis an abstract input stream

Input: opsis the number of points for initialization

Output: return k-d trees initialized with ops points from data-Source

2: initPoints ← dataSource.loadN ewP oints(ops)

3: trees ← a new k-d tree forest built with initPoints

4: updating ← f alse 5: loss ← 0 6: N ← ops 7: return trees 8: end procedure 9:

10: procedure UPDATEPROGRESSIVETREES(dataSource, ops, α, τ)

Input: opsis the number of operations allowed for an iteration

Input: αis a reconstruction weight

Input: τis the fraction for insertion tasks

Output: a tuple of updated k-d trees and a list of newly inserted points

11: ifall points in dataSource have been inserted then

12: return(trees, []) 13: end if 14: if updating then 15: insertionOps ← τ × ops 16: updateOps ← (1 − τ ) × ops 17: else 18: insertionOps ← ops 19: updateOps ← 0 20: end if

21: newPoints ← dataSource.loadN ewP oints(insertionOps)

22: for pin newPoints do

23: N ← N + 1

24: for treein trees do

25: INSERTPOINT(p, tree)

26: incrementally update the imbalance cost of tree

27: end for

28: end for

29: ifnot updating and loss > α × N log2N then .loss is

accumulated by a search procedure

30: updating ← true

31: loss ← 0

32: newTree←INITIALIZEBUILD(dataSource)

33: end if

34: if updateOps > 0 then

35: done ← PROCESSBUILDQUEUE(updateOps)

36: if done then

37: replace the most unbalanced tree in trees with newT ree

38: end if

39: end if

40: return(trees, newPoints)

matrix with a useful approximation that remains manage-able in space and time. For example, the Approximate t-Distributed Stochastic Neighbor Embedding algorithm (A-tSNE) [6] uses AAKNN search to efficiently compute the distances between the k-nearest points. Therefore, providing an efficient data structure and algorithm for the AAKNN problem will allow progressive systems to support such general and sophisticated methods.

(8)

columns where N is the number of points in data P and k is the number of neighbors that we want to compute. Formally, a KNN lookup table T is defined as follows:

T [i] 7→ KN Nk(P [i]), where i ∈ [1, N ]

As a sequential approach,we can precompute and store in a N × k table the k-nearest neighbors for each point in P to enable constant-time lookup. Specifically, using any AKNN method, we fill each row of the N × k table so that the i-th row in the table contains the approximate k-nearest neighbors of the i-th point in the data; it can contain either its index, its distance to the i-th point, or both. This simple method suffers from similar limitations to those of sequential k-d trees such as Algorithm 1: It requires all points to be accessible when building the table, and the build time is not bounded.

To build the table progressively, we will use a forest of progressive k-d trees internally, built and maintained progressively as we described in the previous sections. We need an additional progressive algorithm to construct and maintain the table. Our algorithm is iterative, with each iteration having the following three phases:

1) (Indexing) Load new points from a data source and insert them into the internal progressive k-d trees. 2) (Appending) Compute the neighbors of the new points

and append the result to T .

3) (Update) Update the old neighbors in T with the new points.

In the indexing phase, a set of new points is loaded from a data source P and inserted into the progressive k-d trees. As we k-discussek-d in the previous section, we k-do not load a fixed number of points for each iteration, but the number is determined in Algorithm 4 based on three factors: the number of allowed operations for the current iteration (ops), the fraction of time used for insertion tasks vs. rebuilding tasks (τ ), and whether a new k-d tree is being built or not. Let Batch1 be the list of new points loaded in

the first indexing phase. In the following appending phase, we compute the k-nearest neighbors of the points in Batch1

and append the result to the table T as new rows. To this end, for each point p in Batch1, a single KNN query is

performed on the k-d trees updated in the indexing phase, which takes O(logN ) time. Then, the neighbors of the i-th point are stored in T [i], allowing constant-time lookup for future queries on the point. At this moment, since all neighbors in T are up to date, we skip the update phase and continue to the second iteration.

During the indexing phase in the second iteration, we load a set of new points, Batch2, and insert them

into the trees. As in the first iteration, we also append |Batch2| new rows with neighbors. So far, we have filled

in |Batch1| + |Batch2| rows into T with their approximate

k-nearest neighbors. The problem is that the neighbors for the points in the first batch Batch1, which were computed

during the first iteration, can be outdated because there can be closer neighbors in Batch2. Therefore, we need to find

what we call dirty points in T and update their neighbors. The update phase repairs the table by recomputing the neighbors of dirty points. One straightforward approach would be, each time a new point p is added to T , we

iterate over all points in T and check whether a point needs updating by comparing the distance to its k-th neighbor (i.e., the farthest neighbor) and the distance to p. Then, if the point is dirty, we drop its k-th neighbor and insert p into its neighbor set as a new neighbor. In this method, we need an O(N ) loop for dirtiness check each time we insert a point, which results in O(N2_{) complexity in total.}

Our implementation improves the time complexity of the update procedure by approximating the search process. Our assumption is that, for a new point p, its neighbors from older generations in KN Nk(p) are likely to have p

as a new neighbor. This means we can first inspect the dirtiness of the neighbors of the new point, KN Nk(p), to

narrow down the search space. As an extreme case, if the neighborhoods between points are completely mutual (i.e., q ∈ KN Nk(p) ⇒ p ∈ KN Nk(q)), we can greatly reduce the

search space by only considering the points in KN Nk(p).

Based on this optimistic assumption, we first search for dirty points in KN Nk(p). We define those dirty points as a

set S1(p). This can be written as follows:

S1(p) = {q | q ∈ KN Nk(p) ∧ p ∈ KN Nk(q)}

Note that in real cases, the neighborhood between two points is asymmetric, i.e., q ∈ KN Nk(p) ∧ p /∈ KN Nk(q).

Therefore, there can be dirty points that have p as a new neighbor but are not in the k-nearest neighbors of p, and we miss them in S1(p). To find these missing dirty points, we

expand our search space one step further by applying our assumption again on S1(p). We define S2(p) as follows:

S2(p) = {q | q ∈ S1(p) ∧ p ∈ KN Nk(q)} − S1(p)

From a global point of view, calculating S2(p) propagates the

dirtiness to the neighbors of the points in S1(p). We define

a set DP2(p) that accumulates all dirty points that we have

found so far:

DP2(p) = S1(p) ∪ S2(p)

Generally, we define Si(p) and DPi(p) as follows:

Si+1(p) = {q | q ∈ Si(p) ∧ p ∈ KN Nk(q)} − DPi(p)

DPi+1(p) = DPi(p) ∪ Si+1(p)

We continue to propagate dirtiness until no new dirty points are found, i.e., Si+1(p) becomes empty. Our

algo-rithm is approximate; it does not guarantee to find all dirty points. However, if the input points follow our assumption, our algorithm will find most of the dirty points by narrow-ing the search space to the vicinity of the query point p, not checking all the input points.The accuracy of a KNN lookup table is therefore determined by the approximation in both k-d trees and dirtiness propagation. In Section 5.2, we report on the overall accuracy of KNN lookup tables on real data.

At worst, our algorithm checks all the points, just as the na¨ıve approach does. In other words, the number of points searched in the third phase is not bounded, which can result in a long delay before completing the update phase. Note that our algorithm can be seen as a graph traversal if we regard points as vertices and the neighborhood be-tween points as edges. Therefore, taking a similar approach to breadth-first search (BFS), we can limit the number of checked points in the update phase by introducing an up-date queue. Specifically, for a point in Si(p), we first insert

(9)

it into the update queue. For each iteration, we take a fixed number of points from the queue and propagate a dirtiness check. We also use a bitmap as a set to prevent a point from being inserted into the queue more than once. This allows the update phase to finish after checking a fixed number of points, preserving the progressiveness of the algorithm.

Similar to the progressive k-d tree algorithm that used a parameter τ to choose the fraction of insertion and recon-struction tasks, the KNN lookup tables have an additional parameter, named a queue update fraction, λ, to balance the number of operations assigned to internal k-d trees (i.e., the indexing phase) and queue updates (i.e., the update phase). Given the two parameters (τ and λ) and the number of allowed operations (ops), the algorithm assigns the opera-tions as follows: First, (1 − λ)ops operaopera-tions are assigned to the indexing phase for updating internal progressive k-d trees. The algorithm calls the function UPDATEPRO

-GRESSIVETREES in Algorithm 4 with (1 − λ)ops and τ as arguments. The function returns the number of inserted points, which is the number of points that are inserted in the appending phase. Finally, in the update phase, at most, λops points are taken from the update queue and updated if dirty. Algorithm 5 shows the complete algorithm for progressive KNN lookup tables.

5 B

ENCHMARK

Online algorithms are usually evaluated using competitive analysis [39]: their performance are compared against an equivalent offline algorithm and the ratio is reported. This ratio only makes sense when the algorithm needs to com-plete to its end, but one premise of progressive data analysis is that some decision can be made before the algorithm ends. Competitive analysis does not account for these important early termination cases. On the other extreme, Eichmann et al. [40] have proposed benchmarks to compare the ef-fectiveness of databases to fulfill the requirements of data analysis sessions with or without progressive support. This benchmark requires a full system used on a realistic task, which is not our purpose. In our work, we remain at the algorithm level and compare our implementation with the only online implementation available, provided by FLANN. We conducted two benchmarks to evaluate our progres-sive k-d trees and KNN lookup table. The first benchmark compares the performance of online k-d trees and our pro-gressive k-d trees and the second measures the build and query time of a KNN lookup table.

5.1 Online and Progressive k-d Trees

In this benchmark, we compare the performance of online and progressive k-d trees. We used one real dataset (the GloVe [41] dataset) and one synthetic but more structured dataset (a Blob dataset). Both datasets had 1 million of 100-dimensional points. The GloVe dataset had embedding vectors of English words, while the synthetic Blob dataset had points sampled from 100 isotropic Gaussian blobs, 10,000 points for each. For reproducibility, the Blob dataset was generated through scikit-learn’s blob generator [5]. The points in the Blob dataset appear in an increasing order of clusters; for example, the first 10,000 points were from the

Algorithm 5An algorithm for building a progressive KNN lookup table

1: procedureINITIALIZEPROGRESSIVETABLE(dataSource, k)

Input: kis the number of neighbors we want to compute

Output: initialize an empty KNN lookup table

2: INITIALIZEPROGRESSIVETREES(dataSource, 0)

3: table ← an empty table with 0 rows and k columns

5:

6: procedure BUILDPROGRESSIVETABLE(dataSource,ops, k, τ , λ)

Input: ops is the number of operations allowed for an iteration

Input: kis the number of neighbors we want to compute

Input: τis a fraction for insertion tasks for internal k-d trees

Input: λis a queue update fraction

Output: a KNN lookup table

7: queue ← an empty queue

8: queued ← an empty bitmap dictionary

9:

10: functionUPDATEPOINT(trees, i) . Update the neighbors of a single point i

11: queued[i] ← f alse

12: neighbors ← trees.getKN eighbors(dataSource[i], k)

13: table[i] ← neighbors

14: foran integer j such that 0 ≤ j < k do

15: if not queued[neighbors[j]] then

16: queue.push(neighbors[j]) 17: queued[neighbors[j]] ← true 18: end if 19: end for 20: end function 21: 22: treeOps ← (1 − λ) × ops 23: tableOps ← λ × ops

24: trees, newP oints ← UPDATEPROGRESSIVE -TREES(dataSource, treeOps,τ )

25:

26: for pointin newPoints do

27: UPDATEPOINT(trees, point.index)

28: end for

29:

30: count ←0

31: while queueis not empty and count < tableOps do

32: index ← queue.pop()

33: if not queued[index] then

34: queued[index] ← true

35: UPDATEPOINT(trees, index) .Propagate changes

36: end if

37: count ← count + 1

38: end while

first Gaussian blob, the next 10,000 points were from the second Gaussian blob, and so on. As query points, we used another 1,000 embedding vectors for the GloVe dataset and random 100-dimensional vectors for the Blob dataset. To see the effect of the inserting order of points, we used two conditions: the order was 1) kept as in the original dataset (original) and 2) shuffled (shuffled), potentially producing balanced k-d trees earlier.

For each iteration, we gave 5,000 operations to both the online and the progressive k-d tree (i.e., ops = 5, 000). The online version used up all operations to add new points (i.e., 5,000 points were inserted to k-d trees during one iteration).

(10)

Fig. 1: Benchmark results of online and progressive k-d trees according to datasets (GloVe [41] and Blob) and ordering conditions (original and shuffled). FLANN’s online k-d tree (the red line) rebuilt the k-d trees each time the data size doubles, producing insertion times longer than 10 seconds (e.g., leftmost charts at the 62nd and 126th iterations). In contrast, progressive k-d trees (the green, blue, and purple lines) alleviated the spikes in insertion time by spreading the reconstruction load. Our progressive k-d trees yield a small loss in queries per second (middle column), yet with faster convergence to a mean distance error of 7% for the GloVe dataset and 3% for the Blob dataset (rightmost column).

For the progressive k-d tree, we used three different values for τ : 0.2, 0.35, and 0.5. A progressive tree with a higher value of τ prioritizes insertion tasks, assigning fewer oper-ations to maintaining the balance of the tree. Note that the value of τ only affects the algorithms when reconstruction occurs. For example, if the accumulated loss due to imbal-ance has not reached a certain threshold, all operations will be assigned to insertion tasks for the progressive k-d trees. We set the value of α (i.e., the reconstruction weight) to 100. The benchmark was conducted on a single machine, which was equipped with Intel Core i7-7700K CPU (4.2GHz) and 16GB of main memory. We used eight threads to process KNN queries in parallel. All algorithms used four random-ized k-d trees and searched 2,048 nodes.

We queried 20 neighbors (i.e., k = 20) for each point in the test data and measured insertion time, queries per second (QPS), and mean distance error for the neighbors found. Insertion time is the time taken to insert points into trees in a batch (e.g., 5,000 points in the case of online trees). Queries per second (QPS) is the mean number of queries processed in a second, indicating the balance of search trees.

The quality of sequential AKNN algorithms have usu-ally been measured using search precision [10], defined as the fraction of exact neighbors returned from an approximate algorithm. However, we found search precision underes-timates the quality of online and progressive algorithms; for example, if only 10% of the data is indexed and the exact neighbors are uniformly distributed in data, the search precision of a progressive algorithm cannot surpass 10%,

since 90% of the exact neighbors are not in the index. Therefore, we measured a relative error, mean distance error (MDE); for each query point, we first compute the ratio between the distances to its exact k-th nearest neighbor and to its approximate k-th nearest neighbor and then calculate the mean of the ratios for all query points. An MDE of one means that the exact neighbors were found, and an MDE of two means on average the algorithm found neighbors that are two times farther than the exact ones.

Figure 1 shows the changes in measures per iterations according to datasets and ordering conditions. Since the on-line trees used all 5,000 operations to insert new points, the corresponding red line ends at the 200th iteration (1,000,000 / 5,000 = 200). The online algorithm builds new trees each time the number of inserted points doubles. This behavior yields spikes in the insertion time (the red lines on the leftmost charts in Figure 1). The spikes clearly revealed the limitation of the online trees: At the 126th iteration, the online trees produced a peak latency in insertion time that was longer than 10 seconds. In contrast, regardless of datasets and ordering conditions, the progressive trees kept the insertion time under one second: in progressive k-d trees, abrupt changes in insertion time were removed. Since we controlled the number of operations in one iteration to achieve progressiveness, not execution time, insertion time varied depending on the numbers of insertion and reconstruction tasks.

Regarding QPS, the online trees had a performance gain after tree reconstruction, since the trees became well

(11)

balanced (i.e., at the 62nd and 126th iterations in the middle column of Figure 1). The progressive trees showed lower performance, but the gap could be narrowed by adjusting the value of α (i.e., the reconstruction weight). Progressive trees with a smaller value of τ yield better QPS, but the differences were small.

As more points were inserted to k-d trees, the mean dis-tance error (MDE) of answers decreased,finally converging to an MDE of 7% for the GloVe dataset and 3% for the Blob dataset. We measured the time from the beginning to the moment when the MDE converges and marked it in the rightmost charts in Figure 1. The online tree took the smallest number of iterations to reach the final MDE.

The reason may be that it used all its operations to insert new points, so exact neighbors were more likely to be in the trees and searched. Indeed, progressive k-d trees with a larger value of τ assigned more operations to index new points, producing faster convergence. However, due to the longer insertion time, the online trees took the longest time to reach the final MDE, which suggests the effectiveness of our progressive k-d trees.

In the Blob dataset under the shuffled condition, the pro-gressive trees generally took the fewest iterations to index the whole dataset and the shortest time to reach to the final MDE. The reason may be that the dataset had randomly sampled points in a random order, so the trees spent the fewest operations in rebalancing and the approximation in k-d trees was effective.

The benchmark showed that the value of τ can be tuned to achieve the desired behavior of progressive k-d trees. Using a smaller value of τ leads to shorter insertion time and larger QPS, improving the scenarios where high throughput is important. However, the downsides are that 1) more iterations are required to index input points and 2) it takes longer to reach a certain level of accuracy. Nonetheless, regardless of the value of τ , we found that our progressive trees outperforms online trees for progressive systems in that the insertion time can be maintained below a specific bound with comparable QPS and better accuracy.

5.2 k -Nearest Neighbor Lookup Tables

The second benchmark evaluates the performance of KNN lookup tables. As in the first benchmark, we used the GloVe and Blob datasets and the two ordering conditions (i.e., original and shuffled). For progressive k-d trees, we used the same settings as those used in the first benchmark

except ops = 4, 000 for shorter insertion time. Since KNN lookup tables were designed for the all approximate k-nearest neighbor problem, we sampled 1,000 points from the training data as test data instead of using an extra set of 1,000 points. We set the value of τ for internal progressive k-d trees to 0.5. To see the effect of dirtiness tests, we used three different values for λ (i.e., the queue update fraction): 0.3, 0.4, and 0.5. Other constants were identical to those of the first benchmark, such as k = 20 and α = 100. For the internal indexer, we used four progressive trees. KNN queries for updating lookup tables traversed at most 2,048 nodes in each tree. As in the first benchmark, we measured insertion time, queries per second (QPS), and mean distance error (MDE).

Figure 2 shows the result of the second benchmark. Overall, the insertion time of progressive KNN lookup tables increased compared to that of a progressive tree. We profiled the time to complete each phase in KNN lookup tables and found that the longer insertion times resulted from computing the k-nearest neighbors of every unseen point (i.e., points in a batch). However, since the KNN lookup tables can answer a KNN query in constant time (i.e., one table lookup operation), QPS of the KNN lookup tables was a few orders of magnitude higher than that of progressive trees. In a sense, a KNN lookup table increases build time but significantly reduces the query time with a complexity of O(1) instead of O(log2N ).

The effect of the queue update fraction (λ) was clearly seen in the benchmark. Using a smaller value of λ resulted in shorter insertion time at the cost of high mean distance error, since it gave a low priority to maintaining the table up to date (i.e., dirtiness tests). Note that QPS of the tables was not affected by the value of λ, since a query was merely a lookup operation that can be done in constant time. This provides flexibility in changing the behavior of KNN tables. For example, one can adjust λ to strike a balance between insertion time and accuracy depending on applications.

6 A

PPLICATIONS

The long computation time of sequential KNN methods has limited the potential use of data mining algorithms in in-teractive visualization systems. In this section, we improve three popular sequential algorithms to become progressive: KNN regression, KNN density estimation, and the t-SNE algorithm [3], adding them to the toolbox of interactive analysis tools.

6.1 Progressive Regression and Density Estimation

One common use of k-nearest neighbors is interpolating an unknown target value using training data, which is called KNN regression. Suppose that training data X consists of N instances, x1, x2, · · · , xN, and each instance has a target

value, yi. The target value of an unseen instance xnew can

be predicted based on the target values of its neighbors: ynew=

X

p ∈KNNK(xnew)

wpyp (2)

where wp is the weight for the neighbor p. The fractions

can be either a constant (i.e., 1/k) or inversely proportional to the distance to xnew. The training data X can be indexed

progressively using our k-d trees, which gives us an estimate of KN Nk(xnew). Finally, we can compute and improve ynew

using Equation 2 in a progressive manner.

Another possible application of PANENE is progressive KNN density estimation. KNN density estimation is similar to KNN regression except that it predicts the density of training data on a specific point instead of a target value. The goal of KNN density estimation is to provide density information on 2D input points to help users understand the distribution of the input points. Again, suppose that training data X consists of N instances, x1, x2, · · · , xN. Using a

Gaussian kernel with a bandwidth h, the density of X on a specific point p is given by ρ(p):

(12)

Fig. 2: Benchmark results of k-nearest neighbor lookup tables according to datasets (GloVe [41] and Blob) and ordering conditions (original and shuffled). Designed for repeated KNN queries for points in training data, KNN lookup tables can answer a KNN query in constant time (i.e., one table lookup operation).

ρ(p) ∝ X x ∈ X e−(p−x)22h2 ρˆ_K(p) ∝ X x ∈KNNK(p) e−(p−x)22h2 (3) which has a complexity of O(N ) since it iterates over all the points. The main idea of KNN density estimation is that, as the target point p becomes farther away from an instance x, the Gaussian kernel will give it a smaller value converging to zero, and its impact on ρK(p) becomes negligible. This

gives us an opportunity for approximating the density using only the neighbors of q. The approximated density ˆρK(p)

can be computed by Equation 3 (right).

Given 2D input points, we first choose sample points on a grid of r rows and c columns. Using a progressive k-d tree, we estimate and improve the density of input points on each sample point. Then, density isolines are computed using the marching square algorithm [42] and visualized through a contour plot. Note that the number of neighbors K should be chosen with care, since the estimated density can be saturated with small K as the data size grows. In the Appendix, we included an example of progressive KNN density estimation using three different values of K.

6.2 Responsive t-SNE

t-Distributed Stochastic Neighbor Embedding (t-SNE) [3] is a nonlinear dimensionality reduction algorithm that is widely used in data analysis. Given a set of high-dimensional points, x1, x2, ...xN, in a feature space, t-SNE

maps the points to low-dimensional points (i.e., embed-ding), y1, y2, ...yN, that describe the similarities between the

original points in the embedding space. Usually, the high-dimensional points are projected on a 2D space and visu-alized through conventional scatterplots or density plots, which can help the user to understand the distribution

and structure of the original points. The original t-SNE algorithm runs with a complexity of O(N2).

To improve the computation time of the original t-SNE algorithm, the Barnes-Hut Stochastic Neighbor Embedding (BH-SNE) [43] reduces the complexity to O(N log N ) by applying the Barnes-Hut approximation [44] to compute the contribution of points. BH-SNE is faster than the original t-SNE algorithm, but not enough to guarantee that the computation latency will remain under a few seconds [11].

From a high-level point of view, the BH-SNE algorithm consists of two parts: 1) computing the k-nearest neighbors of each point to measure the distance between the points and 2) a gradient descent iteration that minimizes a loss function between the distributions of points in the original space and the embedding space. The long initial delay of BH-SNE mainly stems from the neighbor computation. Any KNN methods covered in the related work section can be adopted to speed up the neighbor computation. However, those methods are still blocking, which eventually causes longer precomputation times as the data size grows.

To improve the responsiveness of BH-SNE, we created a variant that computes both the nearest neighbors and the embedding progressively; we call it responsive t-SNE. As a proof-of-concept prototype, we have implemented respon-sive t-SNE by integrating PANENE with the BH-SNE algo-rithm. Responsive t-SNE spreads the load of neighborhood computation to later iterations, alleviating the initial over-head coming from the blocking KNN methods. Specifically, we used PANENE’s KNN lookup table to progressively index and compute the k-nearest neighbors of each point. In contrast to the previous BH-SNE algorithm where neighbor computation must precede the gradient descent loop (i.e., loss minimization), we move the neighbor computation inside the training loop: The training loop of our algorithm

(13)

alternates between 1) updating the KNN lookup table (i.e., indexing new points) and 2) updating the projection to min-imize loss. As training proceeds, the projection is improved in terms of both quantity (i.e., the projection includes more points) and quality (i.e., the projection minimizes the error between the original points and the embedded points).

To compare our responsive t-SNE algorithm with the BH-SNE algorithm, we ran both algorithms on the MNIST dataset [45] as an exploratory benchmark. The MNIST dataset consists of 60,000 vectors, each vector representing 784 (28 × 28) pixels of a handwritten digit scanned. We used an open-source implementation of BH-SNE [46] as a baseline. In contrast to the BH-SNE algorithm, where the projection (i.e., yi) is randomly initialized for all points,

we used random initialization only for the points in the first batch. For each point in later batches, we set its initial position to the centroid of its k neighbors, which is a better starting point. We set the perplexity of t-SNE to 10, which led the algorithm to compute 30 neighbors for each point, and the threshold of the Barnes-Hut algorithm (i.e., θ) to 0.5. Figure 3 shows the time taken to initialize the two algorithms and the resulting embeddings over the iterations. Each point in the scatterplots represents a single vector, with its color encoding the corresponding digit (i.e., 0 to 9). The BH-SNE algorithm took 44.7 minutes to initially compute the nearest neighbors, while our algorithm produced an initial estimate in a few seconds. To assess the quality of embeddings, we measured the Kullback-Leibler divergence (i.e., loss) between the distributions of points in the original and embedding spaces as in the original paper [3]. The embeddings were improved over iterations, giving the final loss of 3.96 for BH-SNE and 4.59 for responsive t-SNE.

Since responsive t-SNE computes an embedding incre-mentally, the quality of the resulting embedding can be affected by the order of input points. For example, we can create an extremely skewed dataset by sorting the MNIST data by the digit each instance represents (e.g., from 0 to 9). To alleviate the bias resulting from the skewed data, we introduce a technique called periodic exaggeration, which is inspired by a technique from a previous study [3]. Periodic exaggeration regularly multiplies a constant factor to the conditional probabilities between points, which allows the clusters in the data to form separated clusters in the embed-ding. For instance, the responsive t-SNE algorithm increases the conditional probabilities by a factor at the beginning of the 100 first iterations, and restores them to 1 after 30 iterations. Close-by points become tightly grouped during the exaggeration phase, allowing points to move more easily to nearby groups, thus avoiding the algorithm to be trapped in local minima. The tension between points lessens after exaggeration, making the points distributed according to their original distances.

In the Appendix, we attached a figure that shows the effect of periodic exaggeration and how the embedding changes over time when the order of the input points is skewed. Exaggeration was applied for 30 iterations at the beginning of every 100 iterations. During exaggeration (i.e., the leftmost three columns of the figure in the Appendix), one can observe that points with the same color move to be densely packed. In our prototype, we fixed the duration and period of exaggeration, but in an interactive analysis, we can

involve users by allowing them to set those parameters and choose the moment to start the exaggeration.

One common task in exploratory visual analytics is to understand the overall distribution of multidimensional data. To support this task, we can construct a visualization pipeline by combining responsive t-SNE and progressive density estimation. The multidimensional data is first pro-jected on a 2D plane progressively through responsive t-SNE. Then, we measure the density of the embedding for each sample point on a grid using the progressive density estimation algorithm. Finally, we can draw a contour plot to show the density, giving an overview of the multidimen-sional data within a controlled latency.

7 I

MPLEMENTATION

We implemented the core of PANENE in C++ as well as a Python binding of PANENE called PyNENE, for a wider range of applications, such as its integration in the Progres-siVis toolkit [1]. PANENE relies on the OpenMP library [47] to process multiple queries in parallel, and on the Roaring Bitmaps library [37] to support efficient filtering. PANENE, the parameters for benchmarks, and applications presented in this paper are available at github.com/e-/PANENE under the BSD 2-clause “Simplified” License.

8 D

ISCUSSION

In this work, we controlled the running time of progressive algorithms by providing the number of allowed operations (ops) as a parameter of the algorithms. When we chose ops, our primary goal was maintaining the latency of our algorithms within the attention-preserving time limit (i.e., about 10 seconds) [11], which gave us a few thousands of operations for one iteration in our settings. However, in practice, this number should be determined and dynam-ically adjusted depending on various factors, such as the type of workload (e.g., disk access or CPU computation), the computing power of machines, and its impact on the performance of algorithms. Therefore, we need an extra step that maps the number of operations to the actual execution time so as to maintain the progressiveness of the system, which is related to time. One example is a time predictor, presented by Fekete and Primet [1], which dynamically infers the number of operations per second of algorithms by monitoring their execution.

In progressive k-d trees, we assumed that an insertion task (i.e., adding a point to trees) and a reconstruction task (i.e., splitting a node in a background tree reconstruction) were atomic, and that running either of these tasks takes the same time. However, in an extreme case where the data size is large, it can be impossible to run even one operation in the given time quantum. For example, splitting nodes into two groups on lines 25 in Algorithm 3 takes a time proportional to N , which will eventually block the system when N is large enough. One possible remedy is to make the split operation itself progressive.For now, in our benchmark settings, it took approximately 0.15 seconds on average to split a node with 10 millions of 100-dimensional points.

Finally, in this work, we assumed that our algorithms run on a single thread. However, the only constraint we
