Product Catalog 1200

(1)

(2)

A Half Century

of Success

Established in 1954 by Robert and Mary Lue Whiteside, Whiteside Manufacturing Company, Inc.

has been providing the world with innovation in professional mechanic’s creepers and seats for

half a century.

Robert started the company in a two-car garage on $800 he earned from refereeing high school

basketball games. His first product was a wooden creeper with cast iron casters. Over the course of

the next few decades, wooden creepers were the bread and butter of Whiteside’s business. In the

early ‘60’s, Robert developed a mechanic’s seat using the steel pan from the back of a truck seat

as the base of the mechanic’s seat. That seat remained in the product line until the mid-1990’s!

In the 1980’s, the evolution of a creeper with a metal frame took the world by storm, and

Whiteside began producing these new creepers. Whiteside quickly learned that protecting its

designs and utility of their products was essential, so now Whiteside has over 48 patents, and

several more are in the patent pending process!

Robert Whiteside is the picture of the “American Dream.” He saw an opportunity to get into

business and risked all he had saved to start his very own company. Robert has never believed in

debt, so his first month in business he made a small profit! His mission in 1954 was to supply the

most professional, long-lasting, innovative tools for the professional user, and after over 58 years

that mission is still Whiteside’s quest.

What sets Robert apart is his fundamental attitude toward business. He believes in quality,

working hard, never sitting satisfied, and most of all he believes in handshakes and giving people

his word (and he means it).

Over 58 years after Robert started the company, the Whiteside Manufacturing facility encompasses

almost 77,000 square feet with on-site warehouses, shipping and production facilities, and offices.

The mainstay of Whiteside’s business is made in Ohio, supporting their local community. Because

most items are custom and made-to-order, you have the flexibility of ordering what you need even

if it’s one unit.

With Whiteside Manufacturing’s custom artwork program you can order any design featured in this

catalog or supply your design and we can make it. With our flexibility and large selection of over

150 models of creepers and seats, we proudly stand above the competition.

Whiteside Manufacturing is now in its third generation of family leadership. Kirt and Terry Whiteside

(sons of Robert and Mary Lue) now own and operate the business, and Tenille Whiteside-Schoonover

(Kirt’s daughter) and Rob Whiteside (Terry’s son) are the latest to follow in Robert’s footsteps.

With quality and innovation in mind, Whiteside Manufacturing will continue on its path of success

long into the future.

(3)

• 40" metal frame creeper; 3/4" steel tube frame • “V” drop in shoulder area for comfort • Heavy-duty plywood board

• Fully padded with heavy-duty vinyl and raised headrest for support

• Six 2-1/2" oil-resistant rollers swivel easily with full ball bearings

• Powder coated to resist rusting • Overall dimensions: 17" x 40", 16 lbs. • Ground clearance: 1-1/4"

Other Models Available:

MTLV6:

Made with MDF board

MTLV6LE:

2" rollers and 12-gauge vinyl

#1

SELLE

R

SELLE

R

Professional Creepers

MTLV6P

40" Fully Padded Creeper

MTLV6ADJP

40" Fully Padded

Adjustable Headrest Creeper

• 40" metal frame creeper with adjustable headrest • 3/4" steel tube frame

• Headrest adjusts to multiple positions • “V” drop in shoulder area for comfort • Heavy-duty plywood board • Fully padded with heavy-duty vinyl • Six 2-1/2" oil-resistant rollers swivel easily • Powder coated to resist rusting

• Overall dimensions: 17" x 40", 18 lbs. • Ground clearance: 1-1/4"

Other Model Available:

MTLV6ADJ:

Made with MDF board

MTLVMONLOP

Extra-Wide Creeper

• 40" metal frame creeper is an extra-wide 20" • 1" steel tube frame runs the length of the pad for strength • Heavy-duty plywood board

• Four 4" oil-resistant rollers with cover • Fully padded with raised headrest • Powder coated to resist rusting • Overall dimensions: 20" x 40", 24 lbs. • Ground clearance: 1-1/4"

MTLVMONLO:

Made with MDF board

MTLVMONLOADJP

Extra-Wide Adjustable

Headrest Creeper

• 40" metal frame creeper is an extra-wide 20" • 1" steel tube frame runs the length of the pad for strength • Headrest adjusts in three positions for ultimate comfort • Heavy-duty plywood board

• Four 4" oil-resistant rollers with cover • Overall dimensions: 20" x 40", 26 lbs. • Ground clearance: 1-1/4"

(4)

Professional Creepers

MTLPNEUP

Creeper with No-Matic

®

Rollers

• 40" metal frame creeper; heavy-duty 1" steel frame • Skewed rails provide added comfort while working • Heavy-duty plywood board

• Powder coated to resist rusting • Fully padded with raised headrest

• Four 6" No-Matic® wheels with 1-1/4" width roll easily on smooth and rough surfaces

• Overall dimensions: 24-1/2" x 40", 30 lbs. • Frame width: 15"

• Ground clearance: 3-3/4"

MTLPNEU:

Made with MDF board

MTLPNEUADJP

Adjustable Creeper

with No-Matic

®

Rollers

NEW

• 40" metal frame creeper; heavy-duty 1" steel frame • Skewed rails provide added comfort while working • Heavy-duty plywood board

• Powder coated to resist rusting • Headrest adjusts in three positions for ultimate comfort

• Four 6" No-Matic® wheels with 1-1/4" width roll easily on smooth and rough surfaces • Overall dimensions: 24-1/2" x 40", 32 lbs. • Frame width: 15"

MTLPNEUADJ:

Made with MDF board

NEW

MTLV6WC

40" Flame-Resistant Creeper

• 40" metal frame creeper with flame-resistant plywood, foam, and material

• Flame-resistant material comes in orange • “V” drop in shoulder area for comfort •Six 2-1/2" oil-resistant rollers swivel easily with full ball bearings

(5)

MTL2UP

Either End Adjustable Creeper

• 44" metal frame creeper adjusts from either end • Back pad adjusts to multiple positions • Six 2-1/2" oil-resistant rollers swivel with ease • Fully padded with heavy-duty vinyl

Professional Creepers

Shown flat

CRS

Convertible Creeper Seat

• 40" creeper converts from creeper to seat • 3/4" steel tube frame

• Six 2-1/2" oil-resistant rollers • Fully padded

• Powder coated to resist rusting • Push-pin release for easy conversion • Positive locking mechanism • Overall dimensions: 17" x 40", 28 lbs. • Ground clearance: 2-1/2"

OTE

Gooseneck

Over-the-Engine Creeper

• Heavy-duty steel frame creeper fits easily over the engine of most vehicles • Powder coated finish to resist rusting • Top adjusts from 43-1/4" to 57-3/4" height • Padded top for comfort while working

• Wheels allow for easy maneuvering around vehicle • Shipped unassembled, load rating 300 lbs. • Dimensions of top pad: 14-1/2" x 15" x 1-1/2" • Overall dimensions: 41-1/4" x 55" x 27-1/4", 52 lbs.

(6)

Conventional Creepers

GBL36

36" Metal Frame Creeper

• Fully padded leatherette back and headrest • 3/4" steel tube frame

• Six 2" rollers

• Powder coated to resist rusting • Overall dimensions: 17" x 36", 14 lbs. • Ground clearance: 1"

MTL36:

Four 2" rollers

GBL32A

40" Tilted Headrest Creeper

• 40" metal frame creeper with permanent tilted headrest for support

• 3/4" steel tube frame • Four 2-1/2" oil-resistant rollers • Powder coated to resist rusting • Overall dimensions: 17" x 40", 14 lbs. • Ground clearance: 1"

GBL40

40" Metal Frame Creeper

• Fully padded leatherette with raised headrest • 3/4" steel tube frame

• 4 cross-rails for support • Six 2-1/2" oil-resistant rollers • Powder coated to resist rusting • Overall dimensions: 17" x 40", 16 lbs. • Ground clearance: 1-1/4"

GBL40ADJ

40" Metal Frame

Adjustable Creeper

• Fully padded leatherette with adjustable headrest • 40" metal frame creeper adjusts at the neck • 3/4" steel tube frame

• Multiposition adjustable headrest • Six 2-1/2" oil-resistant rollers • Powder coated to resist rusting • Overall dimensions: 17" x 40", 18 lbs. • Ground clearance: 1-1/4"

(7)

Conventional Creepers

GBL40ADJTP

Adjustable Creeper

with Tool Pockets

• 40" adjustable headrest creeper with tool pockets • 3/4" steel tube frame

• Multiposition adjustable headrest • Six 2-1/2" oil-resistant rollers • Powder coated to resist rusting • Overall dimensions: 17" x 40", 20 lbs. • Ground clearance: 1-1/4"

UNIBODY

36" Plastic Creeper

• 36" injected plastic creeper

• Padded headrest provides comfort while working • Four 2-1/2" polyolefin wheels

• Overall dimensions: 15-1/2" x 36", 11 lbs. • Ground clearance: 2"

MC

Creeper with Metal Corners

• 3/4" solid hardwood creeper with metal corners for strength

• Fully padded 9" x 2-1/2" headrest for comfort • Handhold for easy carrying

• Four 2-1/2" polyolefin wheels • Overall dimensions: 17" x 36", 16 lbs. • Ground clearance: 1"

LD445

Hardwood Frame Creeper

• 36" hardwood frame creeper

• Fully padded 9" x 2-1/2" headrest for comfort • Five supporting cross members for strength • Four 3" steel casters swivel with ease • Overall dimensions: 15" x 36", 11 lbs. • Ground clearance: 1"

(8)

Design Without Limits!

There is no limit to all the possible

designs you can create with our

Whiteside Manufacturing custom

creeper and seat program. If you

have your own artwork or image as a

300dpi eps file, we can put it on your

favorite creeper and seat. If you have

a concept in mind but no artwork,

we can help bring it to life.

Please call the Whiteside sales team

today to get your custom piece!

Full Color and

Custom Capability

MTLV6PATR12

MTLV6OSKL12

MTLV6RACE12

(9)

Full Color and

Custom Capability

SPP25PATR12

SPP25RACE12

SPP25OSKL12

SPP25FLAM12

(10)

Professional Seats

HS07

Mechanic’s Seat

• Heavy-duty steel frame mechanic’s seat; 1" round tubular frame provides excellent strength

• Ergonomic design with wide footprint for stability

• Heavy-duty tractor seat with PVC covering; comfortable, durable, rigid

• Plastic tray built in the bottom of the frame for easy storage

• Swing-out tray with removable built-in holders

• Four 2-1/2" inline rollers provide smooth maneuverability • Overall dimensions: 23" x 20-1/4" x 21", 24 lbs. • Ground clearance: 3"

17"

16"

HRS

Large Padded Shop Seat

• Large heavy-duty shop seat • Wide base for better stability • 3" oil-resistant rollers swivel with ease • Comfortable, large high-back padded seat; 17" to seat height

• Heavy-duty 1" steel tube frame • 15" x 15" storage tray with magnetic strip to hold small parts and tools

• Overall dimensions: 15" x 15" x 25", 22 lbs. • Ground clearance: 3-3/4"

HRSRED:

Seat cover in red

22"

17"

GRSRB20

Round Adjustable Seat

• Large adjustable heavy-duty shop seat • Gas-filled lift cylinder adjusts from 17" to 22" • Large 20" base provides both stability and room for storage

• Five 2-1/2" oil-resistant wheels for smooth maneuverability

• Overall dimensions: 20" x 20" x 25", 26 lbs. • Ground clearance: 3-3/4"

GRSRB20R:

Seat cover in red

22"

17"

HRAS

Adjustable Height Shop Seat

• Adjustable height shop seat is ultimate in comfort with generous high-back padded seat; 17" to seat height

• Gas-filled lift cylinder with easy adjustment from 17" to 22"

• Wide base for stability • Four 3" oil-resistant rollers • Heavy-duty 1" steel tubular frame • Overall dimensions: 15" x 15" x 25", 26 lbs. • Ground clearance: 3-3/4"

HRASRED:

Seat cover in red

HRAST

Adjustable Height Shop Seat

with 5" Taller Cylinder

• Gas-filled lift cylinder with easy adjustment from 22" to 27"

• Overall dimensions: 15" x 15" x 25", 26 lbs.

GBLNEU

Shop Seat with Wide Base

• Large heavy-duty shop seat with easy access to tool storage tray

• Comfortable, large high-back padded seat • Extra-wide 13-7/8" long x 12" wide base for ultimate stability

• Four 2-1/2" oil-resistant rollers

• Overall dimensions: 20.5" x 25" x 20", 31 lbs. • Ground clearance: 2-1/2"

(11)

Professional Seats

HS05

Mechanic’s Seat

• Heavy-duty steel frame mechanic’s seat; 1" round tubular frame provides excellent strength • Ergonomic design with wide footprint for stability • Flat padded seat is covered with vinyl; generous size • Plastic tray built in the bottom of the frame for easy storage

• Swing-out tray with removable built-in holders • Four 2-1/2" inline rollers provide smooth maneuverability • Overall dimensions: 16" x 20-1/4" x 21", 24 lbs.

GRSRB

Round Adjustable Seat

• Padded adjustable seat with storage tray • Seat pad is 12" while storage tray is 16" • Steel cast collars at base of seat and base of cylinder for added strength

• Adjusts by gas-filled cylinder • Five 2-1/2" oil-resistant rollers

• Overall dimensions: 16" x 16" x 16", 16 lbs.

20.5"

16"

HSPJR

Padded Creeper Seat

• Padded creeper seat with large storage pan for tools and small parts

• Pan is powder coated to resist rusting

• 7" x 14" padded seat is covered with heavy-duty vinyl • Sturdy square legs for support

• Four 2-1/2" polyolefin wheels

• Overall dimensions: 13-1/4" x 15-1/8" x 15-1/8", 14 lbs. • Ground clearance: 2-3/4"

• Ships unassembled

SPPKD

Mechanic’s Seat

(not pictured) • Mechanic’s seat with 1" steel tube frame

• Handy 3-section red tool tray for small parts and tools • Four 2" red wheels swivel with ease

• Overall dimensions: 15-1/2" x 14-1/4" x 19", 12 lbs. • Ground clearance: 2"

• Ships unassembled

Replacement Wheel Available:

#SPPKD-R:

2"wheel in black

SPP25B

Mechanic’s Seat

• Mechanic’s seat with heavy-duty 1" steel tube frame • Handy 3-section tool tray for small parts and tools • Heavy-duty plywood board

• Four 2-1/2" oil-resistant rollers swivel easily • 7" x 14" padded seat

• Powder coated to resist rusting

• Overall dimensions: 15-1/2" x 14-1/4" x 19", 14 lbs.

#SPP:

2"rollers, MDF board and 12-gauge vinyl

SPP25DTB

Mechanic’s Seat

with Swing Tray

• Mechanic’s seat with removable swing tray for easy access to tools and small parts while working • Heavy-duty 1" steel tube frame • Heavy-duty plywood board

• Middle tray adds 166 sq. in. storage space and holds over 20 lbs. when user is seated • Four 2-1/2" oil-resistant rollers

• Overall dimensions: 15-1/2" x 14-1/4" x 19", 16 lbs. • Ground clearance: 2-1/2"

16"

HRS2

Mechanic’s Seat

• 1" round tubular frame • Wide base for better stability • 3" oil-resistant rollers swivel with ease • 15" x 15" storage tray with magnetic strip to hold small parts and tools

• Overall dimensions: 15" x 15" x 15-1/2", 14 lbs.

HRS2RED:

Seat cover in red

NEW

HRS2WS

Flame-Resistant

Welder’s Seat

•1" round tubular frame with flame-resistant plywood, foam, and material

• Flame-resistant material comes in orange •Wide base for better stability

•3" oil-resistant rollers swivel with ease •15" x 15" storage tray with magnetic strip to hold small parts and tools

•Overall dimensions: 15" x 15" x 15-1/2", 14 lbs.

(12)

KP

Kneeling Pad

• 9" x 20" kneeling pad

• 3/4" solid foam allows for ultimate comfort while working

• Heavy-duty neoprene fabric is durable and rigid • Ideal for automotive, home,

garden, etc. • Handle for carrying • Great giveaway item • Weight: 1 lb.

FNLBDY

Funnel Storage System

• Keeps funnel where you can find it and free of dust • Safely drains all residual fluids into the collection for proper disposal

• Mounts to toolboxes and most surfaces • Transparent funnel and collection bottle are included

• A “must have” for garage or workshop

• Overall dimensions: 20-1/2" x 5-5/8" x 5-1/2", 2 lbs.

FCPRO

Fender Cover

• 24" x 40" professional grade fender cover with nonskid backing

• Heavy-duty oil-resistant vinyl construction • Weight: 3 lbs.

Shop Support

FCMAG

Fender Cover

• 32" x 24" fender cover with sewn-in magnets • Oil-resistant vinyl • Weight: 3 lbs.

FCNP

Neoprene Fender Cover

• Prevent scratching to your vehicle with this comfortable one-of-a-kind fender cover • 34-1/2" x 23-1/2" fender cover with pockets • Convenient pockets hold tools on either side • Two large pockets: 5-1/4" W x 9-7/8" D • Two medium pockets: 2" W x 9-7/8" D • Two small pockets: 1-3/4" W x 9-7/8" D • Weight: 3 lbs.

(13)

MB6

Round

MB9X5

Rectangle

Metal Bowls with Magnetic Bases

• Easy-to-clean stainless steel • Great for small parts

• Heavy-duty magnet with rubber cover • Available in 6" round bowl, 1 lb.; or 5-1/2" x 9-1/2" rectangular tray, 2 lbs.

WD18X24

Heavy-Duty Hardwood Dolly

• Constructed of solid hardwood • Bolted-through construction • Weight capacity of 800 lbs. • Four 3" rubber rollers

• Overall dimensions: 18" x 24", 20 lbs. • Ground clearance: 3"

WD12X20:

Same as above except overall dimensions: 12" x 20"

ALUMWP

Aluminum Platform

• Folding aluminum platform has 330 lb. load rating • Platform width: 33-1/2", depth: 12"

• Total footprint width: 45-1/2" • Platform height: 18-1/4" • Footprint depth: 16-3/8" • Step height: 9" • Weight: 14 lbs.

Shop Support

SKSK

Skat Skaters

• Genuine hardwood construction

• 6-1/2" x 8-1/2" pads are connected by articulating slats • Length extends from 24" to 32"

• 2-1/2" ground clearance

• 700 lb. load rating per set (equally distributed) • Sold in pairs

• Weight: 6 lbs. each

Replacement Wheel Available:

(14)

#22

• 2" polyolefin wheel with threaded stem • Includes hardware • Standard on model MTL36 • For model SPP, use part #22SPP

• Fits model MTLV6 • A retrofit requires a full set

#25

• 2-1/2" polyolefin wheel with threaded stem

• Includes hardware • Standard on models MTLV6, MTL2UP, CRS, and MTLV6ADJ • For models SPP25DT, SPP25B, SPP25DTB and SPP25, use part #25SPP • Also fits model MTL36 • A retrofit requires a full set

#33

• 3" polyolefin wheel with grip ring stem

• Includes hardware • Standard on models HRS, HRAS, and HRS2

Also Available:

#33S:

Plastic socket only

#25INL

• 2-1/2" polyurethane wheel with mounting bracket • Includes hardware • Fits model MTLV6-RIV • Universal roller

• Standard on model RC1000

#25VIP

• 2-1/2" Vipor rubber wheel with threaded stem • Includes hardware

• Fits models MTLV6, MTLV6ADJ, MTL2UP, CRS, and MTL36 • A retrofit requires a full set

#40

• 4" polyolefin wheel with threaded stem • Includes hardware

• Standard on models MTLVMON and MTLVMONADJ

• Also fits model MTLPNEU • A retrofit requires a full set

#44

• 3" steel wheel with mounting bracket

• Mounting bracket dimensions: 1-15/16" x 1-1/2"

• Hardware not included • Standard on model LD445 • Universal wheel

#60

• 6" x 1-1/4" wide solid rubber roller with threaded insert • Hardware not included • Tire only can be sold separately, use part #60T • Standard on model MTLPNEU

#66S

• 3" steel wheel with mounting bracket

• Hardware not included • Fits models MC and HSPJR • A retrofit requires a full set • Universal wheel

#66R

• 2-1/2" polyolefin wheel with mounting bracket

• Hardware not included • Standard on models MC, UNIBODY and HSPJR • Universal wheel

#72

• 2" polyolefin roller with mounting bracket

• Hardware not included • Universal roller

• Fits models MC, UNIBODY and HSPJR

• A retrofit requires a full set

#GBL22

• 2" polypropylene wheel with threaded stem • Includes hardware • Standard on model GBL36 • Also fits models GBL40 and GBL40ADJ

• A retrofit requires a full set

#GBL25

• 2-1/2" polypropylene wheel with threaded stem • Includes hardware

• Standard on models GBL32A, GBL40, and GBL40ADJ • Also fits model GBL36 • A retrofit requires a full set

#GBL25B:

Black wheel standard

#GRSRB25

• 2-1/2" polypropylene wheel with threaded stem • Includes hardware • Standard on models GRSRB and GRSRB20

#DTS225

• 2-1/2" polypropylene wheel with threaded stem • Includes hardware • Standard on model DTS2 • Universal roller

(15)

“The Whiteside Difference”

What Makes Whiteside

Manufacturing Different?

• We use heavy-duty 18-gauge steel

on many of our creepers

• We give our customers the option

of choosing heavy-duty plywood

or MDF backing

• We have a wide variety of different

sizes and quality of wheels to give

our customers the best wheel to fit

their need. Let us know if you are

looking for a different wheel option

other than what is in the catalog.

• We have many patents to ensure

you are getting a professional

quality product

• We offer promotional products

including T-shirts and hats that we

can tailor to match your customized

creepers and seats. Ask us to put a

custom pack together for you!

Thank you for being a part of the

Whiteside family. We look forward to

offering you quality and innovation

for another half century and beyond!

Whiteside Manufacturing takes

pride in customizing our products

for our consumers. By making

many of our products in the United

States, we provide you with a

quality family touch.

(16)

America’s leading manufacturer of creepers,

seats, and other related items.

CEO & Product Development

Kirt E. Whiteside

Ext. 423

[email protected]

Account Manager

Heather Murphy

Ext. 321

[email protected]

CFO

Terry L. Whiteside

Ext. 421

[email protected]

Director of Sales and Marketing

Brad Schenk

Ext. 222

[email protected]

Director of

Purchasing

Chad Mays

Ext. 324

[email protected]

Office Manager/Customer Service

Tenille Whiteside-Schoonover

Ext. 223

[email protected]

President & Founder

Robert E. Whiteside

Ext. 425

[email protected]

Whiteside Manufacturing Company, Inc.

309 Hayes Street, P.O. Box 322, Delaware, Ohio 43015

© 2012 Whiteside Manufacturing, Inc. All rights reserved. Manufacturer reserves the right to alter the product. All products used with the owner’s permission. All of the items in this catalog are either trademarked, trade dress, patent pending, or patented and covered under these patent numbers: 396,920; 401,724; 398,433; 403,822; 401,715; 701,714; 402,432; 403,824; 417,937; 403,825; 410,128; 6,010,187; 409,344; 6,425,590; 6,705,622; 7,213,815; 436,708; 6,733,073; 456,657; 458,432; 6,578,857; 469,592; 503,254; 521,708; 521,206; 522,707; 522,208; 511,416; 531,423; 7,293,783; 7,478,818; 522,261; 7,658,442; 556,419; 531,419; 530,108; 556,972; 539,002; 555,920; 566,374; 575,024; 7,712,750; 570,572; 576,374; 576,373; 569,572; 585,647; 7,712,750.
