INTEGRATION GUIDE. General Radius Config

1

DIGIPASS Authentication for Microsoft Forefront

Disclaimer of Warranties and Limitation of Liabilities

All information contained in this document is provided 'as is'; VASCO Data Security assumes no responsibility for its accuracy and/or completeness.

In no event will VASCO Data Security be liable for damages arising directly or indirectly from any use of the information contained in this document.

Copyright

Copyright © 2012 VASCO Data Security, Inc, VASCO Data Security International GmbH. All rights reserved. VASCO®_{, Vacman}®_{, IDENTIKEY}®_{, aXsGUARD™™, DIGIPASS}® _and ® _logo

are registered or unregistered trademarks of VASCO Data Security, Inc. and/or VASCO Data Security International GmbH in the U.S. and other countries. VASCO Data Security, Inc. and/or VASCO Data Security International GmbH own or are licensed under all title, rights and interest in VASCO Products, updates and upgrades thereof, including copyrights, patent rights, trade secret rights, mask work rights, database rights and all other intellectual and industrial property rights in the U.S. and other countries. Microsoft and Windows are trademarks or registered trademarks of Microsoft Corporation. Other names may be trademarks of their respective owners.

2

DIGIPASS Authentication for Microsoft Forefront

Reference guide ... 3

1 Introduction... 4

2 setup ... 4

3 Basic Identikey configuration ... 5

3.1 IDENTIKEY Server ... 6

3.1.1 Policies ... 6

3.1.2 Client ... 7

3.1.3 User ... 7

3.1.4 DIGIPASS ... 8

3.2 Test the Solution ... 10

4 Challenge/Response ... 11

4.1 Architecture ... 11

4.2 [Solution Partner] ... 12

4.3 IDENTIKEY Authentication Server ... 12

4.3.1 Policy ... 12

4.3.2 User ... 12

4.4 Test the Solution ... 13

5 FAQ ... 14

3

DIGIPASS Authentication for Microsoft Forefront

4

DIGIPASS Authentication for Microsoft Forefront

This is a general document which will help to configure your device in combination with Identikey Authentication Server over RADIUS.

RADIUS is a standard authentication protocol used in most security appliances and products. The Identikey Authentication Server is installed with RADIUS protocol enabled on the standard ports:

 Authentication: 1812

 Accounting: 1813

This can be changed in the Identikey configuration if necessary.

2

setup

Topology

To configure the source device please consult the device documentation for RADIUS authentication

Server configuration info:

IP address of source device [IP address of source device]

Shared Secret [Shared Secret]

Authentication Port 1812

Accounting Port 1813

In order to test the Identikey Authentication Server a test user needs to be created. That user needs to be added in the Identikey Authentication Server and linked to a Digipass.

User configuration info:

5

DIGIPASS Authentication for Microsoft Forefront

Publishing applications with Microsoft Forefront UAG

Step 1 Configuring the radius server in UAG

http://technet.microsoft.com/en-us/library/dd857368.aspx

Step 2 Configuring Kerberos Constraint Delegation

6

DIGIPASS Authentication for Microsoft Forefront

4.1 IDENTIKEY Server

There are lots of possibilities when using IDENTIKEY Server. We can authenticate with:

 Local users (Defined in IDENTIKEY Server)

 Active Directory (Windows)

In this whitepaper we will use Local users to authenticate.

4.1.1

Policies

In the Policy the behavior of the authentication is defined. It gives all the answers on: I have got a user and a password, what now?

 Create a new Policy

 Policy ID : Test

 Inherits From: Base Policy

Inherits means: The new policy will have the same behavior as the policy from which he inherits, except when otherwise specified in the new policy.

Example:

Base

Policy

New

Policy

Behaviour

1 a

New policy will do a

2 b

New policy will do b

3 c

f

New policy will do f

4 d

New policy will do d

5 e

g

New policy will do g

7

DIGIPASS Authentication for Microsoft Forefront

 Local Authentication : Digipass/Password

 Click Save

4.1.2

Client

In the clients we specify the location from which IDENTIKEY Server will accept requests and which protocol they use.

We are going to add a new RADIUS client.

 Client Type : select Radius Client from “select from list”

 Location : [IP address of source device]

 Policy ID : Select the Policy that was created in Policies  Protocol ID: RADIUS

 Shared Secret: [Shared Secret]

 Confirm Shared Secret: [Shared Secret]

 Click Save

4.1.3

User

8

DIGIPASS Authentication for Microsoft Forefront

 User ID: [Test username]

4.1.4

DIGIPASS

The purpose of using IDENTIKEY Server, is to be able to log in using One Time Passwords (OTP). To make it possible to use OTP we need to assign a DIGIPASS to the user. The Digipass is a device that generates the OTP’s.

 Open the user by clicking on its name

 Select Assigned Digipass

 Click ASSIGN

9

DIGIPASS Authentication for Microsoft Forefront

 Grace period: 0 Days

Grace period is the period that a user can log in with his static password. The first time the user uses his DIGIPASS the grace period will expire.

 Click ASSIGN

10

DIGIPASS Authentication for Microsoft Forefront

The configuration can be tested by tying to login with [Test username] and an OTP from the assigned Digipass.

11

DIGIPASS Authentication for Microsoft Forefront

5 Challenge/Response

The easiest way to test challenge/response is to use (Back-Up) Virtual Digipass. Virtual Digipass is a solution where an OTP is sent to your E-mail account or mobile phone, after it was triggered in a user authentication. The trigger mechanism is configured in the policy (see later).

 Virtual Digipass is a Digipass that can be ordered like a Hardware Digipass

 Back-Up Virtual Digipass is a feature that must be enabled while ordering other Digipass (Hardware, Digipass for mobile, Digipass for web or Digipass for windows)

Availability of Back-Up virtual Digipass can be checked in the IDENTIKEY web administration.

Select a Digipass>Click on the first application and scroll down.

For test purposes a demo DPX file with Virtual Digipass is delivered with every IDENTIKEY Authentication Server

5.1 Architecture

This solution makes use of an sms-gateway (for sms’s or text messages) or SMTP-server (for mail). The first step is to configure one of the servers. This is done in the Message Delivery Component (MDC) configuration. For more information see the IDENTIKEY Authentication Server manuals.

12

DIGIPASS Authentication for Microsoft Forefront

http://www.cm.nl

http://www.callfactory.com

5.2 [Solution Partner]

[Different steps that need to be taken, to change the setup in order support challenge/Response. A combination of screenshots and short explanations]

5.3 IDENTIKEY Authentication Server

5.3.1

Policy

The configuration virtual Digipass can be used is done in the policy. Select the policy created in Policies. This should be Test.

Select Test

Go to Virtual Digipass Click Edit

 Delivery Method: SMS

 BVDP Mode: Yes – Permitted

 Request Method: KeywordOnly

 Request Keyword: IwantOTP Click Save

The request method is the trigger to send the message. The trigger can be:

 Static password: in IDENTIKEY Authentication Server

 Keyword: a text message

5.3.2

User

IDENTIKEY Authentication Server needs to know, where to send the mail or SMS. Therefor User should be add.

Select a user: [Test username] Click User Info

13

DIGIPASS Authentication for Microsoft Forefront

 Mobile: +32… (for the sms)

 Email Address: [email protected] (for mail) Click save

5.4 Test the Solution

[Screenshots of the solution test] Steps 1: [ Login with  username: Demo  Password: IwantOTP ] Step 2:

[What is the feedback message]

Step 3:

[enter the OTP received by mail or text message]

Step 4: [logon]

14

DIGIPASS Authentication for Microsoft Forefront

6 FAQ
