WEB LCT

AGS-20

Software application for the management

of AGS-20 equipment

Release 1.1

User manual

(2)

The information contained in this handbook is subject to change without notice.

Property of SIAE MICROELETTRONICA. All rights reserved according to the law and according to the inter-national regulations. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, without written permission from SIAE MICROELETTRONICA.

Unless otherwise specified, reference to a Company, name, data and address produced on the screen dis-played is purely indicative aiming at illustrating the use of the product.

MS-DOS®, MS Windows® are trademarks of Microsoft Corporation

HP®, HP OpenView NNM and HP–UX are Hewlett Packard Company registered trademarks. UNIX is a UNIX System Laboratories registered trademark.

Oracle® is a Oracle Corporation registered trademark. Mozilla Firefox is a Mozilla Foundation registered trademark.

Linux term is a trademark registered by Linus Torvalds, the original author of the Linux operating system. Linux is freely distributed according the GNU General Public License (GPL).

(3)

WEB LCT AGS-20

MANUAL CONTENT

This manual describes the commands and the functionalities of the WEB Local Craft Terminal application (release 1.1) present in the equipment AGS-20.

The WEB LCT release present in the equipment can be verified opening the relevant WEB Local Craft

Ter-minal page and selecting Main > Equipment Properties - General Info tab - WEB LCT Version parameter.

In this manual, to make the writing easier, the wording:

• WEB LCT identifies the WEB Local Craft Terminal application for AGS-20. • WEB LCT page identifies the WEB Local Craft Terminal page for AGS-20.

(14)

WEB LCT APPLICATION

The WEB LCT application allows a user connecting to equipment via his own machine (PC, Workstation, etc.) using the operating system and the Web browser at his disposal.

WEB LCT is an application resident in the equipment controller. It does not require any additional module installed on the user PC (see Installation).

At start-up of WEB LCT, the browser displays the WEB Local Craft Terminal (WEB LCT) page that is the application graphical interface (GUI).

The WEB LCT page can be opened directly from browser (see Open/close the WEB LCT page - Fig.1). Through WEB LCT application, the user can check the equipment operating status and directly intervene to manage it, verifying/modifying the configuration parameters (see Functionalities and Menu and com-mands (Equipment Menu).

Fig.1 WEB LCT application (start-up of the WEB LCT page from browser)

* * See Installation Controller Equipment (e.g. 172.18.60.33) Supervision port

WEB LCT

application

WEB LCT page

equipment

(172.18.60.33)

User PC Browser Internet

SSH Server

SFTP/SSH FTP

FTP Server

Help Web Server

Web Lct Console

Help file

NE management (HTTP/ HTTPS)

(15)

FUNCTIONALITIES

Through the WEB LCT application, it is possible to manage:

• The properties (identifier, addresses, reference date/time, hardware, features key, etc.) and to execute the reset of the equipment software (Equipment Properties).

• The measures of Performance Monitoring (Performance Monitoring).

• The log of the equipment alarms, the log of the operations executed by the users and the equip-ment configuration (Report & Logger).

• The Wake Up trap (NMS Wake Up Config.).

• The equipment software/firmware and the restore of the default equipment settings (Software Info & Maint.).

• The backup/restore of the whole equipment configuration (Backup/Restore Config.). • The forward status of the alarms and their severity (Alarm Severity Config.). • The equipment users list (Group/User Management).

• The equipment communication protocols (SNMP, HTTP, Telnet, FTP, SSH, SFTP, HTTPS) ( Secu-rity Management).

• The equipment general configuration (radio configuration, modulation/capacity, adaptive mod-ulation, etc.) (Equipment).

• The Ethernet Switch main configuration, the TDM tributaries and cross connection matrix (TDM) (Base Band).

• The sources and the outputs of synchronism (Synchronisation). • The radio parameters (Radio).

• The maintenance parameters (S/N, PRBS, Radio loops, RMon and Radio switch) (Maintenance). • The User Input (local and remote) and the User Output (Alarm In/Out).

• The remote element list (Remote elements list area)

(16)

LIMITS

The following limits must be considered for every single piece of equipment.

Remote equipment list

Maximum number of equipment in the list: 100 Maximum number of stations in the list: 30 Remote equipment list (info)

User list

Maximum number of groups in the list: 10 Maximum number of users in the list: 10 Users management (info)

WEB LCT Session

Maximum number of equipment which can be connected at the same time by means of a single

WEB LCT session: 1

Login to equipment

Maximum number of contemporary connections (login): 10

The system supports at most 10 groups, 10 users and 10 login at the same time. As regards the logged users, these are distributed in the following mode:

CLI users* connected at the same time to a piece of equipment: 10. SNMP users** connected at the same time to a piece of equipment: 10. WEB users*** connected at the same time to a piece of equipment: 4. * CLI user. User of SM-OS (Siae Microelettronica - Operating System) application. ** SNMP user. User of NMS5UX-B/NMS5LX system.

*** WEB user. User of WEB LCT application.

Area Events

(17)

CHARACTERS SET

The GUI accepts and recognizes the character set defined by the ISO/IEC 8859-1.

Only exception are the fields relevant to the management of user/groups, which accept and recognize only the characters 0÷9, a÷z and A÷Z.

(18)

INSTALLATION

WEB LCT

WEB LCT is an application resident in the equipment controller. It does not require any installation on the user PC.

At the first equipment switch-on, the user can immediately connect to it via WEB LCT because the application is already present in the controller.

Then you can Update the software/firmware of the equipment.

Add-ins

As help to equipment WEB LCT for the management of:

• FTP protocol, it is necessary to install the program WEB Lct Console or a FTP Server (see Equipment.

• Help online of WEB LCT (Help Web Server), it is necessary to install the program WEB Lct Console.

• SFTP protocol, it is necessary to install a SSH server on one’s PC (see Installation and configuration of SSH server).

The instructions for the installation of the Web Lct Console (WLC) are reported in the relevant manuals. WEB LCT Console work in MS Windows® environment.

WARNING AGS-20 equipment is managed from version 1.2.0 of WLC or later.

Help online

WEB LCT is equipped with a help on-line which can be opened selecting the option [Help] or in WEB LCT page.

The help on-line must be installed on one’s PC using the installation file specific for the WEB LCT of the equipment you wish to use.

(19)

WEB LOCAL CRAFT TERMINAL (WEB LCT) PAGE

Open/close the WEB LCT page

Elements of the WEB LCT page

(20)

OPEN/CLOSE THE WEB LCT PAGE

Open the WEB LCT page from Browser Open more WEB LCT pages

Close the WEB LCT page

Open the WEB LCT page from Browser

WARNING If Ethernet connection is used, checks or settings are not generally necessary. Only if more net-work cards are equipped, it will be necessary to select the card you wish to use (Host Adapter) (see Web

Lct Console user manual).

When the equipment is connected to the PC via LAN network, the relevant WEB LCT page can be opened also selecting the equipment from the address book of Web Lct Console (see relevant documentation). The following procedure requires that:

• The relevant WEB LCT application is present on the equipment which you are connecting to. • The user, you wish to use to open the WEB LCT page, is valid. With valid user

(username/pass-word) we mean a user present in the users list stored in the controller. The user must be asso-ciated to a group for which the protocol HTTP and/or HTTPS is active (see Users management (info).

For the first connection or after a Factory Default operation (see Advanced tab) use the creden-tials Username: admin, Password: admin.

The opening of the WEB LCT page is supported with: • Internet Explorer 9 or later.

• Firefox 4.0 or later.

As help for the WEB LCT application in order to manage:

• The FTP Server and Help Web Server, run the program WEB Lct Console version 1.2.0 or later. Alternatively, for the management of FTP, it is possible to use a FTP Server already present on PC (see FTP/SFTP protocol (info).

• The protocol SFTP, it is necessary to install and configure a SSH server (see Installation and con-figuration of SSH server).

1. Run a browser.

2. In the address box type the IP Address of the equipment.

WARNING If the use of HTTPS protocol is active on the equipment (see Services Status Config), an error page could be displayed, indicating that the connection you are activating is not secure because trou-bles have been detected with the security certificates.

For the detailed description of the error messages of the browser, refer to the relevant documentation. To download the SSL certificate see Download the SSL certificate in an equipment.

Generally, the browser asks the user to accept or refuse the connection. If you decide to accept how-ever the connection with the equipment, the confidential transfer of the data is nor ensured.

The WEB LCT login page opens.

3. Type the name of the user, in the Username box. 4. Type the password, in the Password box.

5. Check the Remember Me box if you wish that, on the next opening of the application, the current user name and password are automatically displayed; otherwise uncheck the considered box.

6. Press Login.

If the typed values are correct, the system displays the WEB LCT page of the equipment (see Fig.2). As regards the messages that can be displayed during the start procedure of WEB LCT see Messages displayed in the WEB LCT page.

(21)

Open more WEB LCT pages

It is possible to open:

• More WEB LCT pages on more machines or on the same machine, using the same user or dif-ferent users.

• Only one WEB LCT page relevant to the same equipment. • More WEB LCT pages relevant to different equipment.

For more information about the limits of the application, refer to the Limits paragraph.

Close the WEB LCT page

(22)

ELEMENTS OF THE WEB LCT PAGE

1 - Equipment Menu area 2 - Equipment info area 3 - Users area

4 - Remote elements list area 5 - Contextual area

6 - Equipment status area

Fig.2 shows an example of WEB LCT page on an AGS-20 equipment.

Fig.2 Elements of the WEB LCT page (AGS-20)

1

3

2

6

4

5

(23)

Equipment Menu area

This area contains the commands to manage the equipment configuration (see Fig.2).

Commands

The commands are subdivided in groups:

Main. Commands to manage the general equipment parameters: supervision ports, Routing Table, Performance Monitoring measures, etc.

Equipment, Synchronisation, etc. Commands to manage the configuration parame-ters typical of the equipment type which the WEB LCT page refers to.

For the description of every group/command see Menu and commands (Equipment Menu). The selection of a group expands or compresses the list of the underlaying commands. At each selection, the list takes the status complementary to the previous one (if compressed it becomes expanded, or vice versa). The symbol:

identifies an expanded group. identifies a compressed group. It is possible:

• Expand all the groups at the same time, pressing • Compress all the groups at the same time, pressing .

The symbol identifies a command which, once selected, displays the parameters associated to it in the context area (see Contextual area).

Display/hide area

When the WEB page is opened, the Equipment Menu area is displayed. Press to hide the area. Press to display the area again.

(24)

Equipment info area

This area shows the equipment general properties.

Parameters

Equipment Type. Equipment type. Equipment ID. Equipment identifier.

Agent IP. IP Address assigned to the agent SNMP of the equipment.

Bridge Mode. Bridge mode (according to IEEE 802.1ad) of the Ethernet Switch:

• Customer Bridge. The Switch is in Customer Bridge mode. In this mode, the Switch

operates as a Bridge 802.1Q VLAN.

• Provider Bridge (802.1ad). The Switch is in Provider Bridge mode. In this mode, the

Switch operates as a Bridge Q-in-Q.

• Provider Edge Bridge. The Switch is in Provider Edge Bridge mode. In this mode, the

Switch operates as a Provider Edge Bridge 802.1ad with one S-VLAN component and at least one C-VLAN component.

Tables

LEFTTABLE (see Fig.2). Status and radio parameters of the transmitter and receiver. Every row of the table corresponds to a radio branch for which is displayed:

Branch which the data, present in the relevant row, refer to:

• Tx <radio branch>. Operating status and parameters of the specific branch

relevant to transmission (ODU A/ODU B).

• Rx <radio branch>. Operating status and parameters of the specific branch

relevant to reception (ODU A/ODU B). RF frequency. The wording:

• ODU Hardware Failure. Hardware problem.

• Must be Set (Dplx). The specific frequency is not set.

Power in input to the receiver (lines Rx...) and in output to the transmitter (lines Tx...). Both the powers are measured at the antenna flange.

The wording Tx Off (lines Tx...) indicates that the transmitter is off because of an action of the user (see Verify/modify the operation of the transmitter - selection of Off or

Per-manent Off option) or because of the activation of one or more alarms which cause the

switch-off of the transmitter (for example, RADIO Vco Fail Alarm).

RIGHTTABLE. Channel/modulation and radio transport (Tx/Rx) subdivision between Ethernet and

TDM:

Bandwidth & Modulation. Current channel and modulation. TDM Capacity. Radio capacity reserved to the TDM tributaries (E1). ETH Capacity. Radio capacity reserved to Ethernet tributaries. The parameters are subdivided by radio branch:

Tx <Radio Link name> [1+0] and Rx <Radio Link name> [1+0]. Respectively transmission and reception radio branches of a Radio Link in not protected configuration. Tx <Radio Link name> [1+1 HS] and Rx <Radio Link name> [1+1 HS]. Respec-tively transmission and reception radio branches of a Radio Link in protected configura-tion of isofrequential type.

Tx <Radio Link name> [1+1 FD] and Rx <Radio Link name> [1+1 FD]. Respec-tively transmission and reception radio branches of a Radio Link in protected configura-tion of heterofrequential type.

Tx <Radio Link name> [2+0 XPIC] <radio branch> and Rx <Radio Link name> [2+0 XPIC] <radio branch>. Respectively transmission and reception radio branches of a Link with two radio directions in XPIC configuration.

The presence of two different Radio Links in 1+0 configuration indicates that the equipment is in radio configuration 2x(1+0) or 2x(1+0) E-W.

If the Radio module is not equipped or a Radio Link has not been defined yet, the parameters present in the table are not meaningful. The area displays the wording Data Unavailable.

(25)

Update data

The information present in the Equipment Info area is updated every 15 seconds (timeout). Press to force the Equipment Info area updating.

Display/hide area

When the WEB page is opened, the Equipment Info area is displayed. Press to hide the area. Press to display the area again.

(26)

Users area

User Profile parameter [Logout] parameter [Open Far End] parameter [Help] parameter

User Profile parameter

Profile of the user who has opened the WEB LCT page.

Options

Admin. The user has Administrator profile.

The user with this profile can both verify the parameters and send commands or change the equipment configuration with no exception.

Read/Write. The user has Read/Write profile.

The user with this profile can as check the parameters as send commands or execute changes to the equipment configuration except for the following operations: modifying the user list, aligning the date/time of the equipment, force the logout of a user and all those operations avail-able only to the Admin. user.

Maint. The user has Maintenance profile.

The user with this profile can check the parameters and execute only maintenance operations (MAN OP) in the Manual Operations contextual area.

Read Only. The user has Read Only profile.

The user with this profile can only check the parameters.

Login/Logout

At the opening of the WEB LCT page, the user will be connected to the equipment with the user/ profile entered during the login request.

In any moment it is possible to execute the logout and re-execute the login using the same or a different user with respect to that used for the login.

NMS

If the equipment is managed also by the NMS5UX-B/NMS5LX supervisory system, the supervi-sory system considers the connection of a WEB user with Read Only or Maintenance profile a WEB LCT connection in Monitoring mode.

While the supervisory system considers the connection to the equipment of a WEB user with

Read/Write or Administrator profile a WEB LCT connection in Configuration mode.

[Logout] parameter

This parameter executes the logout of the current user.

When selected, the WEB LCT page to login to the equipment is displayed. To reconnect equipment, set Username and Password and press Login.

(27)

[Open Far End] parameter

This parameter opens the WEB LCT page of remote equipment to contained in the Remote Element Table.

Operations

Open the WEB LCT page of equipment (Remote Link)

Open the WEB LCT page of equipment (Remote Link) User Profile | Read Only, Maint., Read/Write, Admin.

1. Select the [Open Far End] parameter. If the remote equipment list contains:

• Only one item of equipment of type Remote Link, the WEB LCT login page of the remote equip-ment is displayed.

Type the name (Username box) and the access code (Password box) of the WEB user to use to activate the connection and press Login. In a new page the WEB LCT of the remote equipment is displayed.

If the WEB LCT login page is not displayed when the login is required, this means that the remote equipment is unreachable.

• No equipment of type Remote Link, a message is displayed pointing out the absence of the re-mote equipment.

• More equipment of type Remote Link, the Available Remote Elements window is displayed, con-taining the list of equipment configured as Remote Link present in the remote equipment list. For each equipment, the following characteristics are reported:

• Station. Station name.

• Equipment ID. Equipment identifier.

• IP Address. IP address.

• OSI. Parameter not meaningful in this context.

Select the remote equipment and press Open or double click on the equipment. The WEB LCT page to login to the remote equipment opens.

Type the name (Username box) and the access code (Password box) of the WEB user to use to activate the connection and press Login. In a new page the WEB LCT of the remote equipment is displayed.

[Help] parameter

This parameter opens the help online of application.

The message Unable to contact help support... indicates that the program WEB Lct Console necessary for the management of the Help Web Server has not been started (see Installation).

(28)

Remote elements list area

In this area, you can manage the remote equipment list stored in the equipment controller.

Parameters

Station/Equip. Name of the station and equipment in the list. STATION( )

Equipment is subdivided into stations.

Selecting the symbol of a station expands or compress the list of underlaying equipment. At each selection, the list takes the status complementary to the previous one (if com-pressed it becomes expanded and vice versa).

The name of the station is assigned by the user during the creation of the station itself. The stations are displayed in the same order as they are inserted in the list.

An empty station, that is a station without associated equipment, cannot be stored in the list.

EQUIPMENT( or )

The symbol represents the equipment of type Remote Link (see column Type). The symbol represents other types of the equipment.

The name of the equipment is automatically assigned by the application during the cre-ation of the equipment itself: Equipment <progressive number>.

Within the station, the equipment are listed in increasing order with respect to the IP ad-dress.

IP Addr. IP address (Agent SNMP) of the equipment. Type. Type of equipment:

• Managed by SCT. Equipment managed by WEB LCT application.

• Remote Link. Equipment, managed by WEB LCT application, constituting the

ment placed on the other end of the radio connection with respect to the local equip-ment (equipequip-ment which the user is connected to by WEB LCT).

• Elem. Manager. Element Manager of the equipment (IP address of the machine where

the NMS5UX-B/NMS5LX system resides).

• Not Managed. Element not managed by the WEB LCT application.

• Nodal X. Equipment belonging to the local node.

With local node we mean a set of minimum 2 and maximum 8 equipment (ALCplus2/ ALCplus2e) interconnected by a Ethernet nodal Bus and/or by a TDM nodal Bus, where the considered equipment is an element. The X value correspond to a number between 1 and 8 and indicates the subset.

• 2x1+1-Xpic-Main. IDU Master belonging to an ALCplus2e equipment in XPIC 1+1

configuration.

• 2x1+1-Xpic-Res. IDU Reserve belonging to an ALCplus2e equipment in XPIC 1+1

configuration.

OSI. Equipment NSAP (GOSIP) Address.

Parameter available only for the equipment managed with the OSI protocol.

Push-button

GENERAL

Apply. Confirm the changes. Refresh. Update the list.

Clear. Reset the remote equipment list

Open. Open the WEB LCT page of equipment of the list (Remote Link) STATION

Add. Add a station to the list

Remove. Remove a station of the list Rename. Rename a station of the list

(29)

ELEMENT

Add. Add equipment to the list

Remove. Remove equipment from the list

Display/hide area

When the WEB page is opened, the Remote elements list area is hidden. Press to hide the area. Press to display the area again.

Add a station to the list

User Profile | Read/Write, Admin.

WARNING It is possible to insert a maximum of 30 stations into a list. 1. In the Remote elements list area, press Add (Station group).

2. Type, into the text box, the name to be assigned to the station (alphanumeric string with minimum 1 and maximum 11 characters).

The program does not create two stations with the same name in the same list. Moreover, a digit cannot be used as first character and the space character cannot be used at the beginning or within the name string.

3. Press OK.

The application displays the new station into the Remote elements list area, at the end of the list rele-vant to the already existing stations.

4. Press Apply and confirm.

An empty station, that is a station without associated equipment, is not saved in the list.

Rename a station of the list

1. In the Remote elements list area, select the station to be renamed. 2. Press Rename.

3. Type, into the text box, the new name (alphanumeric string with minimum 1 and maximum 11 char-acters).

The program does not create two stations with the same name in the same list. Moreover, a digit cannot be used as first character and the space character cannot be used at the beginning or within the name string.

4. Press OK.

The application displays the new name of the station into the Remote elements list area. 5. Press Apply and confirm.

Remove a station of the list

WARNING The deleting of the station causes also the removal of all pieces of equipment coupled with such a station.

(30)

1. In the Remote elements list area, select the station to be removed. 2. Press Remove (Station group).

The application removes the station from the Remote elements list area. 3. Press Apply and confirm.

Add equipment to the list

WARNING It is possible to add to the list a maximum of 100 equipment.

Equipment cannot be created if at least one station has not been created before.

1. In the Remote elements list area, select the station to which the equipment has to be coupled. If the user does not select any station, the application will automatically couple the equipment with the last selected station.

2. Press Add (Element group).

3. Into the IP Address box, type the IP address of the equipment.

The program does not create two pieces of equipment with the same IP Address in the same list (even if in different stations).

4. Set the Type of element box, selecting the option relevant to the element type to be inserted: • Managed By SCT. Equipment managed by the WEB LCT application.

• Remote Link. Equipment managed by the WEB LCT application that constitutes the equipment

placed on the other end of the radio connection with respect to the local equipment.

• Element Manager. Element Manager of the equipment (IP address of the machine where the

NMS5UX-B/NMS5LX system resides).

• Not Managed. Element not managed by WEB LCT application.

This option can be used to insert into the remote equipment list for instance the coupling be-tween the IP address and the NSAP (Gosip) one piece of equipment inserted into an OSI net-work.

• 2x1+1-Xpic-Main. IDU Master belonging to an ALCplus2e equipment in XPIC 1+1 configuration.

Option to use only if problems have occurred regarding the automatic configuration of the re-mote equipment list during the creation of a XPIC 1+1 system.

• 2x1+1-Xpic-Res. IDU Reserve belonging to an ALCplus2e equipment in XPIC 1+1 configuration.

Option to use only if problems have occurred regarding the automatic configuration of the re-mote equipment list during the creation of a XPIC 1+1 system.

5. Press OK.

In the Remote elements list area, under the selected station, a record named Equipment <progressive

number> is displayed with the characteristics of the new equipment.

Remove equipment from the list

1. In the Remote elements list area, select the equipment to be removed. 2. Press Remove (Equipment group).

The application removes the station from the Remote elements list area. 3. Press Apply and confirm.

(31)

Reset the remote equipment list

1. In the Remote elements list area, press Clear.

The application clears all the records (stations and equipment) present into the Remote elements list area.

Open the WEB LCT page of equipment of the list (Remote Link)

1. In the Remote elements list area select the equipment of Remote Link type to be opened the WEB LCT page.

2. Press Open.

The WEB LCT page to login to the remote equipment opens.

3. Type the name (Username box) and the access code (Password box) of the WEB user to use to activate the connection and press Login.

(32)

Remote equipment list (info)

Each equipment has a remote equipment list stored in its own controller.

With remote equipment list we mean a list containing all the network remote equipment which you wish to connect to.

For a better vision of the equipment during the setting of the list, it is possible to subdivide the equipment into stations, in such a way that, at the selection of a station, the application will display only the detail of the equipment associated with such a specific station. The station does not have any particular meaning; it has been simply introduced to help the user during the localization of the equipment.

Into each remote equipment list, it is possible to create a maximum of 100 equipment and 30 station. The remote equipment list can be used to connect, at the same time, to more equipment only if the pro-gram WEB LCT is available.

When the user requests the connection to a generic equipment present into the network (local equipment), at the connection of such equipment, the WEB LCT program reads its remote equipment list and automat-ically forwards the connection command to all pieces of equipment present into the list.

In such a way, the application displays, into the Station List area of the WEB LCT window, all the stations that group the equipment and, into the Equipment List area (selecting the relevant station), it displays the functional status of the local equipment (that results in connected/login status) and the functional status of all the remote equipment present into the list. The equipment that have answered to the connection request of the application will result in connected/monitor status.

The application will cyclically forward the connection command, to the equipment that have not answered to the connection request, until to:

• It is deactivated the connection with the local equipment. • The user disables the equipment.

• The equipment is deleted from the remote equipment list of the local equipment. More information concerning the WEB LCT program are reported into the relevant manuals.

(33)

Contextual area

This area is the part of the WEB LCT page where the equipment parameters are displayed.

Its content changes accordingly to the selected command in the Equipment Menu area, which is indicated in the top part of the contextual area.

Push-button

Apply. Selecting it makes the changes, executed on the parameters present in the contextual area, effective.

Its selection opens a confirmation window. The confirmation windows are timed. When this pe-riod is elapsed (pointed out by the progress bar), if the user has not confirmed the operation, the window is closed and the operation cancelled.

The confirmation window displays the option Don’t ask again. Activate the option to avoid the system displays the confirmation request when Apply is selected in any context of WEB LCT page. This setting remains valid until the exit from the current session (logout or page closing). If the Apply push-button is not available:

• It is not possible to execute changes because the user profile does not allow this or the equipment is in connected/monitor status.

• No parameter present in the window has been modified. In this case, the push-button becomes available when the value of a parameter is changed.

• Another push-button is present in the contextual area for the confirmation of the op-eration or the change of the parameters.

Refresh. Force the reading of the data from equipment.

If the push-button is not available, the connection with the equipment is not active. Help. Open the help on-line.

WARNING For some commands, other push-buttons are displayed relevant only to the context which contains them. These push-buttons are described in the paragraph relevant to the specific command.

Tabs

For some commands, the parameters are subdivided in tabs. The selection of a tab dynamically changes the content of the contextual area.

Parameters

The parameters present in the contextual area can be read-only or set or modified.

The description of the single commands (see Menu and commands (Equipment Menu) indicates the parameters which can be modified and modalities to do that.

Generally, for the parameter setting, the following rules are valid: • Entering a value (alphanumeric string) in a text box.

If a red line is displayed below the text box, the entered value is not allowed because, for example, a number of characters greater than the allowed one or an invalid value has been entered (for example, entering of value 172.18.70.334 as IP address). • Box with possible values displayed in a drop-down menu.

When the value is changed, a red triangle is displayed in the top left edge of the box. It signals that the value has been changed, but the change has not been communi-cated yet to the equipment (pressure of push-button Apply).

(34)

Equipment status area

This area shows the functional status of the equipment.

Parameters

URGENT <alarms number>. Number of Critical and/or Major alarms. Colour box: • Orange. The most serious alarm present into the equipment has Major severity • Red. The most serious alarm present into the equipment has Critical severity. • Grey. The equipment has no active alarms with Critical or Major severity. Select the box to display the active alarm.

NOT URG. <alarms number>. Number of Minor and/or Warning alarms. Colour box:

• Light blue. The most serious alarm present into the equipment has Warning severity. • Yellow. The most serious alarm present into the equipment has Minor severity. • Grey. The equipment has no active alarms with Minor or Warning severity. Select the box to display the active alarm.

DOWNLOAD. Update of the equipment software/firmware. Colour box: • Light blue. The update is in progress.

• Grey. The update is not in progress.

MAN. OP. Activation of the manual operations. Colour box: • Light blue. A manual forcing is enabled (e.g. a loop). • Grey. No manual forcing is active.

Events (area). List of the status/alarm signals of the equipment. Each signal corresponds to a record that is displayed:

• Colour box. Signal type and alarm gravity: • Green/Status. Status signal.

• Light blue/Warning. Alarm detected with Warning severity.

• Yellow/Minor. Alarm detected with Minor severity.

• Orange/Major. Alarm detected with Major severity.

• Red/Critical. Alarm detected with Critical severity.

• White/Cleared. Alarm detected/cleared.

• Alphanumeric string which details the nature of the signal. • Logic group which the signal belongs to: COMMON, etc. • Date/time of the signal detection.

If the row refers to a detected/cleared alarm, the date/time of alarm detection will be pointed out under the date/time of alarm clearing.

The date/time is set by the network element that has generated the signal. The for-mat of date/time changes depending on the setting made in the operating system.

Operations

Verify the active manual operations

Verify/modify the manual operation timeout

Update data

The information present in the Events area are dynamically updated when an alarm is generated or cleared.

Press to force the Events area updating and remove the detected and cleared alarms (box

White/Cleared).

Display/hide area

When the WEB page is opened, the Events area is displayed. Press to hide the area. Press to display the area again.

(35)

Verify the active manual operations

User Profile | Read Only, Maint., Read/Write, Admin. 1. Select the MAN. OP box.

A window displays the manual operations actually activated into the equipment. The wording None active manual operation shows that no manual operation is active. The information are not dynamically updated. Press to update the information.

Verify/modify the manual operation timeout

User Profile | Verify: Read Only, Maint. Modify: Read/Write, Admin.

WARNING The timeout setting is common for all the manual forcing operations of the equipment. 1. Select the MAN. OP box.

The Manual Operation Timeout box displays the current timeout of the manual operations.

Value 0 indicates that the timeout has not been activated, this means that the activation of a manual operation remains active until when the user deactivates it. The activation of a manual forcing (for in-stance a loop) affects the traffic.

2. To change the parameter, set a value between 0 and 172800 sec. (48 hours). The setting of the value 0 corresponds to the disabling of the timeout. 3. Press Change and confirm.

(36)

MESSAGES DISPLAYED IN THE WEB LCT PAGE

Opening page

Login Failed! Invalid User o Password!. It means that the typed username and/or password is

wrong and/or not present in the equipment user list.

The equipment is update protected by element manager, retry to login as Read Only user. It

means that the equipment is managed also by the NMS5UX-B/NMS5LX supervisory system and the NMS5UX user has prevented the possibility, for the WEB user, to be able to execute the login of the equipment. In this case, it is necessary that the NMS5UX user enables again the WEB user for the execution of the operation.

Too many WEB users!. It means that the equipment has been connected to the maximum

num-ber of allowed users (see Limits).

Open page

When the page is open, self-explanatory messages are usually displayed about the result of an opera-tion or the impossibility to carry out an acopera-tion because of the incongruence of the selected parameters. Moreover, one of the following messages can be displayed:

Warning. Invalid or time-out session. You will be redirected to login form The equipment is in

disconnected status. In this condition, the parameters cannot be verified/modified.

Press Ok to display the WEB LCT page of login to the equipment. Fill the fields Username and

Password and press Login to reconnect to the equipment.

Access Denied. The selected context is available only to the user with profile Administrator. Warning: You are forcing a manual operation. Operation timeout: <value>. The setting you wish

to execute is a manual operation subjected to timeout.

For each equipment, a timeout can be set after which the relevant active manual operations are automatically deactivated. The wording No Timeout indicates that the timeout is disabled; this means that a manual operation remains active until when the user deactivates it.

Loading The request of data is in progress between the PC and the equipment.

Updating, Applying Changes The sending of data is in progress between the PC and the

equip-ment.

Operation Fail! Unable to Get or Update parameter(s). Wrong user profile or not logged yet! The

operation cannot be executed because the user profile in use is not enabled to execute the action or is not logged to the equipment yet.

(37)

MENU AND COMMANDS (EQUIPMENT MENU)

Main. It manages the general equipment parameters.

Equipment. It manages the radio equipment configuration.

Base Band. It manages the Ethernet Switch main configuration, and the DCN parameters and the TDM traffic.

Synchronisation. It manages the sources and the outputs of synchronism. Radio. It manages the Radio parameters.

Maintenance. It manages the maintenance parameters (S/N, PRBS, Radio loops, RMon). Alarm In/Out. It manages the User Input (local and remote) and the User Output.

The description of every single command indicates the status of login/user profile (User Profile parameter) necessary to use the command or execute the relevant procedures.

(38)

MAIN

Equipment Properties. It manages the basic configuration of equipment. Performance Monitoring. It manages the Performance Monitoring measures.

Report & Logger. It manages the log of the equipment alarms, the log of the operations executed by the users and the equipment configuration.

NMS Wake Up Config. It manages the Wake Up trap.

Software Info & Maint. It manages the equipment software/firmware and the restore of the default equipment settings.

Backup/Restore Config. It manages the backup/restore from file of the whole equipment configuration. Alarm Severity Config. It manages the alarm transmission and their severity.

Group/User Management. It manages the users list of the equipment.

Security Management. It manages the equipment communication protocols (SNMP, HTTP, Telnet, FTP, SSH, SFTP, HTTPS).

(39)

Equipment Properties

User Profile | Read Only, Maint., Read/Write, Admin.

The Equipment Properties command manages the basic configuration of the equipment.

Operations

Verify the basic configuration of the equipment Modify the equipment identifier

Modify the IP address of the agent SNMP of the equipment Execute the equipment software reset

Align the reference date/time of the equipment to the current date/time of the PC Verify the equipment feature

Enable a new equipment feature Verify the equipment units

GUI

Equipment Properties contextual area

Verify the basic configuration of the equipment

User Profile | Read Only, Maint., Read/Write, Admin.

1. Select Main > Equipment Properties.

The General Info tab displays the basic configuration of the equipment.

Modify the equipment identifier

2. In the Equipment ID field set an alphanumeric string with minimum 1 and maximum 50 characters. 3. Press Apply and confirm.

Modify the IP address of the agent SNMP of the equipment

2. In the Agent IP Address box type the new IP address. 3. Press Apply and confirm.

Execute the equipment software reset

WARNING Operation is no traffic affecting.

(40)

1. Select Main > Equipment Properties. 2. Press System Restart and confirm.

Align the reference date/time of the equipment to the current date/time of the PC

User Profile | Admin.

WARNING The operation could cause the logout of the user. 1. Select Main > Equipment Properties.

2. Press Align to PC time and confirm.

The values present in the System Date/Time area are updated by the values of one’s PC.

Verify the equipment feature

User Profile | Read Only, Maint., Read/Write, Admin. 1. Select Main > Equipment Properties. 2. Select the Equipment Features tab.

The tab displays the equipment feature enabled on demand.

Enable a new equipment feature

User Profile | Admin.

WARNING Depending on the protocol set for the file transfer (see Ftp/Sftp contextual area), check out that: • Protocol FTP. The program WEB Lct Console or a FTP Server is active, otherwise start them.

If you use an FTP Server, the credentials used to access to the WEB LCT page must be the same configured for the FTP Server and the file (certificate) must be present into a sub-folder of the

Shared Folder set during the configuration of FTP Server (see FTP/SFTP protocol (info). • Protocol SFTP. A SSH server is installed on one’s PC (see SSH protocol (info).

The default SFTP credentials are the same used by the user to access to the WEB LCT page. For a correct management of the data transfer, the SFTP credentials shall correspond to the user (or to one of the users) defined during the installation of the SSH server (see Installation and configuration of SSH server).

In order to enable one or more features, IT IS NECESSARY to require the enabling certificate, represented by a file (with sfc extension), to the company that provides the equipment.

For each equipment you wish to enable one or more feature, a specific enabling certificate is required, be-cause there is an univocal Link between each certificate and each specific equipment.

1. Select Main > Equipment Properties. 2. Select the Equipment Features tab. 3. Press Upgrade.

4. In the Cert. file path, type the path/name of the certificate. If the equipment uses the:

• FTP protocol and the FTP Server activated at start-up of WLC, it is necessary to enter the full path (c:\..). Otherwise, if you use own FTP Server, it is necessary to enter the partial path (only the sub-folder and the filename of the Shared Folder).

• SFTP protocol you must set the path defined during the configuration of the SSH server (see Installation and configuration of SSH server - SFTP tab).

(41)

5. Set, in the FTP Server IP Addr. box, the IP address of the FTP Server o r the SSH Server (if not otherwise set at the configuration of Server, it corresponds to the IP address of the PC).

6. Press Send.

A message indicates the end and the result of the operation:

• Operation Done. The operation has been executed with success.

• Invalid operation for this equipment…. The selected certificate and equipment are not

compati-ble (wrong serial number or wrong MIB version, etc.).

Verify the equipment units

User Profile | Read Only, Maint., Read/Write, Admin. 1. Select Main > Equipment Properties. 2. Select the Equipment Units tab.

Manual Web Lct Mn00327e 002 Ags-20 1.1

WEB LCT

AGS-20

Software application for the management

of AGS-20 equipment

Release 1.1

User manual

WEB LCT AGS-20

Contents

MANUAL CONTENT

WEB LCT APPLICATION

WEB LCT

application

WEB LCT page

equipment

(172.18.60.33)

SSH Server

FTP Server

Help Web Server

Web Lct Console

Help file

FUNCTIONALITIES

LIMITS

CHARACTERS SET

INSTALLATION

WEB LOCAL CRAFT TERMINAL (WEB LCT) PAGE

OPEN/CLOSE THE WEB LCT PAGE

Open the WEB LCT page from Browser

Open more WEB LCT pages

Close the WEB LCT page

ELEMENTS OF THE WEB LCT PAGE

1

3

2

6

4

5

Equipment Menu area

Equipment info area

Users area

User Profile parameter

[Logout] parameter

[Open Far End] parameter

[Help] parameter

Remote elements list area

Add a station to the list

Rename a station of the list

Remove a station of the list

Add equipment to the list

Remove equipment from the list

Reset the remote equipment list

Open the WEB LCT page of equipment of the list (Remote Link)

Remote equipment list (info)

Contextual area

Equipment status area

Verify the active manual operations

Verify/modify the manual operation timeout

MESSAGES DISPLAYED IN THE WEB LCT PAGE

MENU AND COMMANDS (EQUIPMENT MENU)

MAIN

Equipment Properties

Verify the basic configuration of the equipment

Modify the equipment identifier

Modify the IP address of the agent SNMP of the equipment

Execute the equipment software reset

Align the reference date/time of the equipment to the current date/time of the PC

Verify the equipment feature

Enable a new equipment feature

Verify the equipment units
