An Introduction to Statistical Methods in GenStat

(1)

An Introduction to

Statistical Methods

in GenStat

Alex Glaser

VSN International, 5 The Waterhouse,

Waterhouse Street, Hemel Hempstead, UK

email:

[email protected]

Many thanks to Roger Payne for the original slides

(2)

Programme

• Day 1

• Introduction to GenStat

• From t-test to one-way anova

• Basic principles of design and blocking

• Treatment structure

−

factorials & interactions

and checking the assumptions

• Day 2

• Simple linear regression

• Multiple linear regression

• GLM –

counts and binomial data

(3)

Aim of course

To give you an overall

introduction to the

GenStat 13th Edition

system.

(4)

Learning

objectives

• By the end of the course, you will be able to

•Navigate the GenStat interface

•Obtain help from the system where necessary

•Input and manage data

•Analyse data through GenStat menus

(5)

• What happens when you select

input log

in

the

window navigator

?

• Can you see yourself using this feature in you

work? If so, how?

• What happens to status bar when you click the

button?

• Resize the

input log

and

output

window so

that you can see both simultaneously

• What happens when you click the button?

• Use the

tools|customize toolbar

menu to

add or remove buttons from the toolbar to suit

your needs.

(6)

Exercise 1.2

• What happens to the text in right hand corner

of the

status bar

if you press the

insert

key?

• What do you think this part of the

status bar

means?

• Open a new text window using the

button.

In this window, type the following GenStat

command

PRINT ‘This is my first time using GenStat’

• Execute the command using the

Run|Submit

Line

menu option. Now select the

Window|

Event Log

entry for this action. Is there an

(7)

GenStat Client

Menus Commands

(8)

Exercise 2

• Find help for what’s new in the 13

th

_{edition of}

GenStat

• Find help on the GenStat spreadsheet

• Open the

Tools|Options

menu and find help

about the

ECHO COMMANDS

setting on the

AUDIT TRAIL

tab.

• Open a new test window and type in the word

FIT

. Place the cursor in the word and press the

F1

key. What is

FIT

? Type in a statistical term

and press the

F1

key.

• View the Introduction to GenStat guide (pdf

format)

• View an example program for a two-sample

t-test.

(9)

Spread

File

Data / Load

Exercise 3.1

• Clear all the data from GenStat and use the

file|open

menu to read the data from the

file

sulphur.xls

from installsets\Data

• Clear all the data from GenStat. Go to the

tools|spreadsheet options|file

menu and

uncheck the

use excel import wizard on

file open

option. Repeat part 1 using the

file|open

menu. Which approach best suits

your way of working?

• The file

bacteria.xls

, that you met earlier,

contains data from a second experiment in

the worksheet called Bacteria Counts. The

data are not stored in standard format; the

data can be found in the range of cells

D3:E13

. Clear the

data core

. Read the

data into GenStat using the

Excel import

(11)

Exercise 3.2 & 3.3

• Using the data in the

iris.gsh

file:

• Produce a scatter plot of

Sepal Width

versus

Petal

Width

. There is one point in this plot that stands

alone. What are the coordinates of this point? Can

you suggest a method of easily identifying to which

species of iris this unusual point belongs?

• Produce a scatter plot of

Sepal Length

versus

Petal

Length

. Give each factor a different symbol and

colours. Experiment with labelling.

• Produce a histogram of

Petal lengths

versus

Petal

widths.

• Using your own data, experiment with the

different aspects of the

graphics

window.

That is, explore the different menus and

toolbars. If you have not brought your on data

sets, experiment with any of the course data

files.

(12)

Exercise 4.1

• Using the Excel Import Wizard,

load in the file

Traffic.xls

• On the second screen enter B3:D43 in

the Specified Range box.

• Click OK on the Select Columns to

Convert to Factors menu

• Convert Day and Month to factors

using the methods of your choice.

(13)

Exercise 4.2

• Continue using the file

Traffic.xls

• Select a cell in the

Day

column.

Delete the value, type ‘F’

and then

press return. Repeat the process but

with the value ‘G’. What property of

the GenStat spreadsheet do you think

this illustrates.

• Select the

Tools|Spreadsheet

Options |Conversions

menu. Check

the

Allow new factor levels in Edit

box. Now repeat the above question.

What happens now?

(14)

Exercise 4.3

• Continue using the file

Traffic.xls

• Create a new variate which contains

the log of the Counts.

• Sort the columns in descending order

of the Counts.

• Use the

Spread| Manipulate|

Unstack

to create separate variables

for each day of the week.

• Experiment with the

Calculate

with your own data.

(15)

1 From t‐test to one‐way anova

• In this session you will learn

•

how to use the t-test to compare two treatments

•

the T-Test menu

•

how to use one-way ANOVA to compare several treatments

•

the model fitted in one-way anova

•

the statistical philosophy behind one-way anova

•

the relationship between one-way anova and the t-test for two treatments

•

how to use the One- and two-way ANOVA menu for one-way anova

•

how to plot the means from one-way anova

•

how to do multiple comparisons

(16)

t‐test

•

suppose we have 2 sets of units, that have received 2

different treatments:

•

animals that have been fed two different diets

•

plots that have been given different fertilisers

•

subjects with different drugs

•

plants with different fungicides .

•

assume the units do not have any special structure e.g.

•

the animals are all of the same breed

•

the plots are in a fairly uniform field

•

the subjects are of similar ages, weights and heights

•

with 2 treatments we may then do a t-test

•

assume each group from a Normal distribution

•

usually assume distributions have the same s.e. (can check)

(17)

•

filter by the course

Guide to Anova and Design

•

select the file

•

click on Open data

• data sets for the examples

and practicals

can be

accessed using the

Example Data Sets

t‐test

• experiment to study yields from 2

manufacturing methods

• data in

Manufacture.gsh

• do yields differ more than we

would expect from the random

variation?

• can we estimate mean yields from

each method?

(19)

t‐test menu

(20)

(21)

Practical 1.2

• spreadsheet

Pots.gsh

stores

data from a fertilizer

experiment

•

7 plants grown in pots with no

fertilizer

•

8 plants grown in similar

conditions with fertilizer

• do a two-sample t-test to

assess whether fertilizer has

an effect

(22)

One‐way analysis of variance

• linear model y

_ij

= μ

+ a

_i

+ ε

_ij

• represent each mean by

•

grand mean μ

•

+ effect a_i

• observations described by

•

fitted value μ + a_i

(23)

Residual

variation

• may arise from many different causes:

• the units may not be absolutely identical (discuss

later how to allocate units to treatments to take

account of this)

• they may experience slightly different conditions

during the experiment

• there may be measurement errors

• they may be being dealt with by different people

during the experiment

• and you can no doubt think of others!

• so estimation is not exact

• analysis must estimate the amount of variation

(24)

One‐way anova

• linear model

y

_ij

=

μ

+

a

_i

+

ε

_ij

• if treatments have no effect

•

a₁ = a₂ = 0

•

y_ij = μ + ε_ij

•

estimate grand mean by average of all data values

•

assess lack of fit of model by sum of squared residuals (RSS₀)

•

degrees of freedom (d.f.) is n₁+n₂−1 (fitted 1 parameter μ)

• fit full model

•

estimate a_i by average for group i minus grand mean

•

assess lack of fit of model by sum of squared residuals (RSS₁)

•

this has n₁+n₂−2 d.f. (2 parameters as (n₁a₁+n₂a₂)/(n₁+n₂)=0)

• assess treatments

•

sum of squares due to treatments is TSS=RSS₀−RSS₁ on 1 d.f.

•

assess underlying variation by residual from full model RSS₁

•

variance ratio is treatment mean square / residual mean square

(25)

(26)

Output

Å

aov table

Å

tables of means

Å

s.e.'s for

differences

between means

(m1 – m2)/sed = t

(27)

ANOVA

Options

ANOVA

Further

Output

• Further Output

menu provides more output

(29)

ANOVA

Means

Plots

• Means Plots

menu plots means

•

as points

•

or joined by lines

•

or with original data points too

(30)

Practical 1.4

• spreadsheet

Pots.gsh

stores

data from a fertilizer

experiment used in Practical

1.2

•

7 plants grown in pots with no

fertilizer

•

8 plants grown in similar

conditions with fertilizer

• do a one-way analysis of

variance to assess if fertilizer

has an effect

• compare results with t-test

from Practical 1.2

(31)

One‐way anova

with >2 treatments

• spreadsheet Rat.gsh

has data

from an experiment to study

effect of dietary supplements

on gain in weight of rats

• 5 diet

treatments (a-e)

• 20 rats allocated at random, 4

per treatment

• can use One-and two-way

ANOVA

menu, and plot means,

(32)

Output

Å

aov table

Å

means

(33)

Plot of means

• suppose a-e

represent

amounts 0-4

of supplement

• might want to

assess linear

(& quadratic?)

effects of

supplement

(34)

Multiple comparison tests

•

in favour

•

there may be many possible comparisons between pairs of

treatment means (with t treatments there are t×(t–1)/2)

•

so some researchers feel their significance levels should be

adjusted to take account of all the tests that they might make

•

against

•

multiple-comparisons are unnecessary if you have only a small

number of comparisons to make – either because there are few

treatments, or because you should have identified beforehand the comparisons that you feel are likely to be of interest

•

they are inappropriate also if the treatments have any sort of

structure e.g. levels may represent different amounts of a

substance like a fertiliser or a drug, then illogical to assume that

only some of the amounts might have an effect

(35)

Multiple comparisons

• check that they

are enabled on

the Menus tab

of the Options

Multiple comparisons

• the

Multiple Comparisons

button will then be available to

click on the ANOVA Further Output menu

•

check Multiple Comparisons

•

select Treatment and type of Test

(37)

Practical 1.9

• spreadsheet

Octane.gsh

stores

data from an experiment to study

the effect of different additives

A

-

E

on the octane level of gasoline

used in Practical 1.7

• do a one-way analysis of variance

to assess if

Gasoline

has an effect

• do a Bonferroni

multiple-comparison test to compare the

types of gasoline

(38)

2 Blocking structures

• In this session you will learn

•

how to improve the precision of an experiment by grouping the units into similar sets called "blocks"

•

how randomization can avoid bias by guarding against unforeseen differences amongst the units

•

how to design and analyse a complete randomized block design

•

how to recognise situations that may require more than one type of blocking

•

how to design and analyse a Latin square design

(39)

Completely‐randomized design

• design used for all examples so far

•

no formal structure is imposed on the units

• assumes units effectively identical e.g.

•

in a field experiment, no systematic differences in underlying fertility, drainage etc of the plots

•

in a glasshouse, assumes that light and temperature are the same for each row of pots

•

in a factory, that workforce behaves in essentially the same way at different times of day, days of the week etc

•

in educational studies, that children in different schools are approximately the same, or students studying different

subjects at Universities, or in different year groups etc

(40)

Non‐uniform units

• for example field experiment on a slope

•

best plots may be at top of slope

•

random allocation of treatments to plots may not seem "fair"

• e.g. replicates of treatment A mainly on "good" plots & replicates of treatment B mainly on "bad" plots − if no actual difference between A & B, could lead to A appearing to be much better than B

•

systematic differences between plots increase the residual sum of

squares, & hence the estimate of random variability

• treatment differences must be larger to give a significant F-test

• standard errors of differences between treatments will be larger i.e. experiment will give less precise results

• if you know there are differences between units

•

avoid bias & improve precision by grouping (blocking) units into

(41)

Randomized block design

• single grouping factor usually known as blocks

• within each block

•

same number of units for each treatment (one per treatment in a randomized-complete-block design)

•

treatments are allocated randomly to the units

• in analysis block-effects are estimated and

removed, leading to more-precise estimates

• e.g.

(42)

One‐way anova

with blocks

• another experiment to

study effect of dietary

supplements on gain in

weight of rats

• 8 litters of 5 rats

• assume rats from same

litter more similar than

those from different litters

• 5 Diet

treatments (A-E),

allocated at random to

rats within each litter

(43)

No blocking

Å

residual m.s. 206.8

variance ratio 0.42

(44)

With litters as blocks

Differences between litters

residual m.s.

40.63 (c.f. 206.8)

Å

variance ratio

2.13 (c.f. 0.42)

(45)

Practical 2.3

• spreadsheet

Wheatstrains.gsh

contains

the results from a

randomized block design to

assess 4 strains of wheat

• analyse

the experiment

• give your assessment of

whether the blocking was

worthwhile

(46)

Blocking in 2 directions

• e.g. experiment on pot plants in a glasshouse

•

door in east wall which may cause temperature differences

•

sunlight mainly from the south

• other e.g.

•

weekday × time-of-day

•

school × year-group

•

factory × weekday

(47)

Latin square design

• a design for t

treatments

• arranged in t

rows and t

columns (i.e. t

2

_units)

• each treatment occurs exactly once in each row

and once in each column

• randomized by randomly permuting rows &

columns

(48)

Latin square example

• experiment to assess the

(in?)consistency

of 6

samplers in assessing the

heights of wheat plants

• 6 areas of wheat to assess

• may also be ordering

effects (accuracy of

samplers may vary during

experiment)

• so 6×6 Latin square used

with blocking factors Areas

and Orders

(49)

Analysis

of

Variance

Output

Å

between Areas

Å

between Orders

Å

Samplers more

precisely

estimated

(residual m.s.

3.328 c.f. 5.801)

(51)

Practical 2.5

• spreadsheet

Fabric.gsh

contains

the results from

a Latin square design to

assess wear resistance of

rubber-covered fabrics

• column factor is 4

different runs

• row factor is four

positions on testing

machine used to

generate wear under

simulated natural

conditions

(52)

3 Treatment structure

• In this session you will learn how to

•

recognise the need for more than one treatment factor

•

analyse designs with two treatment factors using the One-and two-way ANOVA menu

•

define and interpret interactions between factors

•

analyse designs with two treatment factors using the general Analysis of Variance menu

•

use the Anova Contrasts menu

•

estimate comparisons between levels of treatments

•

interpret interactions between treatment contrasts

•

use model formulae to define the treatment terms to be fitted

•

include control treatments in a factorial experiment

•

use covariates to improve precision by using additional background information about the experimental units (not used for blocking

(53)

Types of treatment

• experiments may study different types of treatment e.g.

•

several different drugs at a range of different doses

•

several different types of fertiliser

•

varieties of wheat and types of fungicide

• represent each type of treatment by a different treatment

factor, with levels to represent the various possibilities

e.g.

•

Drug − levels Morphine, Amidone, Phenadoxone, Pethidine;

•

Dose − levels 2.5, 5, 10, 15;

•

Nitrogen − levels 0, 50, 100, 150;

•

Phosphate − levels 50, 100;

•

Fungicide − levels Carbendazim, Prochloraz;

(54)

Two treatment factors

• experiment on canola

(oil-seed rape)

• 2 treatment factors

•

N (nitrogen) 0, 180, 230

•

S (sulphur) 0, 10, 20, 40

• randomized-block

design

•

with 3 blocks (factor

block)

(55)

One

and

two

‐

way

ANOVA

• Two-way

analysis (Treatment

factors N

& S)

(56)

Output

Å

line for each term: N

& S main effects,

and N.S interaction

Å

table of means for

each treatment term

Å

s.e.d. for each table

of means

(57)

Linear model

• y

_ijk

= μ

+ β

_i

+ n

_j

+ s

_k

+ ns

_jk

+ ε

_ijk

•

β_i represent the block effects (block stratum in the aov)

•

ε_ijk are the residuals

•

n_j represent the main effect of nitrogen (N)

•

s_k represent the main effect of sulphur (S)

•

ns_jk represent the interaction between nitrogen & sulphur (N.S)

• analysis fits each term in turn, so you can

decide how complicated a model is required

•

analysis-of-variance table has a line for each term, so you can assess whether its parameters are needed in the model

(58)

(59)

Without

interaction

• lines are parallel

• can decide on best level of

S without considering N

• or best level of N without

considering S

• need present only one-way

tables of means

(60)

General

Analysis

of

Variance

• Design:

Two-way ANOVA (in Randomized Blocks)

• click on

Contrasts

button to fit comparisons (or

other contrasts)

(61)

Comparison

contrasts

• 1 comparison between levels of N

• clicking

OK

opens matrix spreadsheet

Cont

(62)

General

Analysis

of

Variance

• notice function Comp in Treatment 1

(1 comparison of N

defined by Cont)

(63)

Output

Å

extra line for N

assesses the

comparison

Å

also extra line

for N.S to assess

interaction of

comparison

with S

(64)

Practical

3.3

• spreadsheet

Ratfactorial.gsh

contains

the results from an

experiment to study the effect

of 6 different diets on the gain

in weight of rats

• treatment factors concern the

protein in the diet

•

Amount (High or Low)

•

Source (Beef, Cereal or Pork)

• analyse the data as a

two-way factorial

• fit 2 comparison contrasts

between levels of Source

• Animal vs

Vegetable

(65)

Model formula

• define a model to be fitted in an analysis

•

formed automatically by the menus – or can define your own

• list of model terms, linked by operator "

+

”

•

e.g. A + B

•

2 terms representing main effects of factors A & B

• Higher-order terms

specified as series of

factors separated by dots (e.g. interactions):

meaning depends on contents of formula

•

e.g. N + S + N.S N.S is an interaction

•

e.g. Block + Block.Plot Block.Plot represents

plot-within-block effects: differences between individual plots after removing the overall similarity between plots in same block

(66)

Operators for formulae

• crossing operator

* specifies factorial

structures

e.g. N * S

is expanded automatically to become N + S + N.S

• nesting operator

/ occurs most often in block

formulae

e.g Block / Plot

(67)

Several operators

• 3-factor factorial model

A * B * C

becomes A + B + C + A.B + A.C + B.C + A.B.C

• 3 nested factors (e.g. block model of split-plot)

block / wplot / subplot

becomes block + block.wplot + block.wplot.subplot

• factorial-plus-added-control

treatment structure Control / (Drug * Dose)

expands to Control + Control.Drug + Control.Dose + Control.Drug.Dose

• NB: many commands and menus have a

FACTORIAL

option to control the number of factors/variates in the

terms to fit

(68)

Factorial plus added control

• 4 different fumigants to

control nematodes

•

CN, CS, CM and CK

• 2 levels of dose

•

single and double

• also include a control

treatment

•

none (no fumigant at any dose)

• randomized-block design

•

4 blocks

•

12 plots per block

•

(4 replicates of control treatment in each block)

• effects proportional

(69)

Analysis

of

Variance

• select Design

to be General Treatment

Structure (in Randomized Blocks)

(70)

Factorial plus added control

• treatment structure Fumigant / ( Level * Type )

•

Fumigant represents the overall effect of any

fumigant at any (non-zero) dose

•

Fumigant.Level represents comparison between single and

double doses (averaged over different types)

•

Fumigant.Type represents overall differences between types

(averaged over single and double doses)

•

Fumigant.Level.Type represents the interaction between Level and Type (given that some sort of fumigant has been applied)

(71)

(72)

Output

Å

notice different

sed's according to

the replication of

the means

(73)

Covariates

•

provide additional background information

•

often measurements made before expt (not used for blocking)

•

e.g. (log) prior nematode counts

•

incorporated in model as linear (regression) terms

•

y_ijkl = μ + β_i + f_j + ft_jk + fl_jl + ftl_jkl + b × (x_ijkl− x_mean) + ε_ijkl

•

improve precision

•

remove potential biases caused by non-uniformity of units

•

in aov table

•

extra line(s) to assess effect of covariate(s) on y-variate, after

removing effects of treatments

•

treatment s.s. (and effects) adjusted to take account of the fact

that the plots with the various treatments have different covariate values

•

cov.ef. for treatment is efficiency remaining after adjustment

(74)

Output

Å

regression coefficient for

adjustment in Blocks stratum

Å

regression coefficient for

adjustment within Blocks

Å

combined estimate

(75)

(76)

Practical 3.7

•

spreadsheet Ratmuscles.gsh contains data from an experiment to study the effect of electrical stimulation in

preventing the wasting away of denervated muscles of rats

•

3 treatment factors

• length of each treatment

• number of treatment periods per day

• type of current

•

randomized block design with 2 blocks

•

denervated muscles were

gastrocnemius muscles on one side of each rat

•

the normal muscle on the other side of each rat was also measured, for use as a covariate in the analysis

(77)

4 Checking the assumptions

• In this session you will learn

•

what assumptions are needed to ensure validity of an aov

•

why the variance must be homogeneous (e.g. variability of residuals should be the same at high as low response values)

•

how to assess whether the variance is homogeneous

•

that residuals should come from identical and independent Normal distributions

•

how to assess the Normality of the residuals

•

why the model must be additive (i.e. differences between treatment effects must remain the same however large or small the underlying size of the response variable)

•

how to identify outliers

•

how transforming the response variate may correct for failures in the assumptions

•

how to print back-transformed tables of means

•

how to do a random permutation test

(78)

Homogeneity of variance

• random variation must be similar over all units

• beware: it may change with the size of response

• assess by plotting residuals against fitted values

(79)

Non‐homogeneity of variance

• if variation increases with size of response

• s.e.d.'s

between treatment means will be

•

over-estimated for differences between low means

•

under-estimated for differences between larger means

• this could lead you to the wrong conclusions!

• if plot of residuals against fitted values

indicates non-homogeneity of variances

•

consider transforming the response variate

•

(or using a generalized linear model; see Guide to Linear, Nonlinear and Generalized Linear Models in GenStat)

(80)

Normality of residuals

• histogram –

should be "bell-shaped"

• Normal plot

•

residuals in ascending order plotted against Normal quantiles

•

should give an approximately straight line

• half-Normal plot

(81)

Additivity

•

differences between treatment effects remain the same

however large or small the underlying size of the response

•

e.g. in randomized-block design, assume that theoretical value

of difference between two treatments remains the same within a block where responses are low, as in one where they are

high

•

fitting an additive model when non-additivity is present

•

often leads to detection of (spurious) interactions

•

analysis will be harder to interpret

•

predictions will be unreliable

•

but take care – genuine interactions may also occur e.g. if one treatment modifies the mode of action of another

•

data that shows signs of non-additivity often also violates

other assumptions

•

use background knowledge of the process

•

if a multiplicative model appropriate take a log transformation

(82)

Outliers

•

are extreme observation, leading to very large residuals

•

look for warnings in ANOVA Information Summary

•

or for extreme points in histogram of residuals

•

or high or low points in plot of residuals against fitted values

•

or points away from line at end of Normal or half-Normal plot

•

outliers may arise from

•

errors in recording or punching data

•

if the wrong treatment has been applied to a unit

•

where there is a problem in the experimental procedure

•

outliers

•

distort treatment means

•

inflate the error variance, decreasing the precision of estimates

•

if you have outliers investigate to see if errors have

occurred

•

if you find an error try to recover the correct data value

•

if you cannot find the correct data value, insert a missing value

•

if you cannot find any possible source of error, perhaps the outlier might be a true data value – is your model wrong?

(83)

Transformations

• can correct failures of assumptions

• e.g. to stabilize variance

•

counts square root

•

binomial percentages angular

i.e. arcsine(sqrt(p/100))

•

s.e. proportional to mean log

• e.g. non-additivity

•

multiplicative effects log

e.g. log10(n+1) for counts

•

percentages logit = log(p/(100-p)) p=100×(r+½)/(n+1) for binomial

• note: must make inferences on transformed

scale

•

but can present back-transformed means using Save and

(84)

Log transformed data

• study of plankton numbers

• 4 types of plankton (treatments)

• sampled in 12 hauls (blocks)

• compare analyses for

untransformed and log10

transformed numbers

(85)

(86)

(87)

Practical 4.6

• spreadsheet

Wine.gsh

contains results from an

experiment to assess the %

alcohol of wine

• 5 types of wine A-E

• 3 bottles of each type were

tested in a random order

• analyse

the percentages &

plot residuals against fitted

values

• transform the percentages

using a logit

transformation,

re-analyse

the data & replot

residuals against fitted values

(88)

Permutation tests

• if the distributional assumptions are not satisfied, you

might use a random permutation test as an alternative

way to assess the significance of the terms in the analysis

•

model must still be additive for results to be meaningful

•

but residuals need no longer follow Normal distributions with equal

variances

• click on

Permutation Test

in

ANOVA Further Output

to open

ANOVA Permutation Test

•

specify Number of permutations

•

select Seed (0 automatic)

•

click on Run

•

probability for each treatment

term is now determined from its distribution over the randomly permuted data sets
