Sauer Engineering (SE) is pleased to submit a quotation for training on Thermal Spray

(1)

December 2014

Mr./Ms. Potential Student Engineer or Operator Thermal Spray Industry Anywhere in the World

Proposal Number

:

SE Train-TS Neth

Project Title

:

Thermal Spray Process Training

Period-of-Performance

:

February 2015

Dear Potential Student:

Sauer Engineering (SE) is pleased to submit a quotation for training on Thermal Spray (TS) Processes . The target for training is the week starting 2/23/15.

Item Cost Total

Cost for one student at neutral training site

(Netherlands)

$3000 $3000

TOTAL $3000

This training will include:

 Five (5) days of training (approximately 40 hrs) per the attached outlines  Lunch to be provided

 Use of the plume sensor for spray characterization and training  Textbooks for students on TS Processing

 Maximum of 6-8 students in TS hands-on

 $1000 of the training fee will be expected upon receipt of the PO

 Thermal Spray (TS) Process Training will be Monday 2/23 to Friday 2/27  Trainer will provide booth time, powder, and gun parts for hands-on training

o Student can bring samples of difficult to spray powder if desired  Customer/student will be expected to fill out both an ITAR questionairre and

(2)

With the International Traffic In Arms Regulations (ITAR) 22 CFR 120.10 and the Export Administration Regulations (EAR) 15 CFR Parts 730 – 780 laws which must be followed, the Thermal Spray (TS) Process Courses will be generic in nature. No specific parts or the coating substrate combinations listed below will be discussed per ITAR and EAR regulations.

Coating Substrate Process

Thermal Barrier Coating Superalloys Refractory metals Corrosion Resistant Steel

Aluminum Carbides

Plasma

Abaradables Superalloys Plasma

MCrAlX Superalloys Aluminum

Refractory metals Corrosion Resistant Steel

Carbides

Plasma/HVOF

Carbides Titanium Plasma/HVOF

Export of this material may be controlled by these regulations and may not be exported or transferred to non-U.S. persons without prior written approval from the U.S.

government."

All material is copyrighted and should not be used for any training outside of the February 2015 class. No copying, scanning, or transmission of the training materials is allowed outside of the Sauer Engineering corporate structure per this quotation. Per acceptance of this training quote, YOUR COMPANY will not hire outside consultants or instructors to use the material for training purposes.

The cancellation policy will be as follows:

Cancel 3-4 weeks before class starts 1/4 of teaching fee

Cancel 1 week before class starts full teaching fee Sincerely,

John P. Sauer TS Consultant

(3)

December 2014

Thermal Spray Process Training

Course Description

With any technical process, trained and experienced operating and engineering personnel are a key ingredient for success. This is important in both development and production implementation of any technology. Thermal spray is no exception to this requirement. This course provides a practical mix of theory and hands-on instruction at your facility that results in operators and process engineers with “problem solving” capabilities.

During an FAA Approved 5 day on-site course, students fill their “thermal spray

toolbox” with valuable tools to solve real time thermal spray issues when they return to the production environment. The training is customized to your processes, equipment, and coating issues and can be modified to meet a 2-3 day format if required. Testing of personnel is focused on your needs and requirements.

The course includes:

 Outline of Standard Thermal Spray (TS) Processes  Theory of Thermal Spray Processes

 Cleaning and Grit Blasting  Cooling, Fixturing, and Masking

 Process Control, Testing, Powders, and Applications  Practical Hands-on Use of the Equipment

 Hands-on rebuild of Equipment

(4)

Learning Objectives

Upon completion of this course, participants should be able to:  Comprehend the basics of thermal spray technology

 Focus on the critical nature of each step in the thermal spray process and identify needed procedures for each sequence

 Use the tools in the “thermal spray toolbox” to solve thermal spray problems  Rebuild the necessary equipment for the processes in question

 Understand the use and benefits of plume sensor technology

Who Should Attend

 Thermal Spray Operators and Supervisors  Thermal Spray Process Engineers

 Engineers associated with thermal spray design and applications Sincerely,

John P. Sauer President

(5)

SE TS Process Training TOPICS

1 Training Outline

2 Thermal Spray (TS) Background

3 Clean-Grit Blast

4 Plasma Theory

5 HVOF General/Specific

6 Powders (as time permits)

7 Consoles

8 Masking Cooling Fixturing

9 Process Control Plume Sensor and Metallography/Testing etc.

10 Plasma System/Gun-Lessons Learned

11 Safety 12 Maintenance

13 Technical Papers

Hands-on and Rebuilds

A Booth and Plume Sensor-Changing Parameters Plasma, HVOF

B Testing-Tensile Testing, Metallography, etc.

C Grit blasting, Masking, and Cooling
