DIGITAL SIGNATURE & ENCRYPTION IMPLEMENTATION FOR INCREASING AUTHENTICATION, INTEGRITY,

SECURITY AND DATA NON-REPUDIATION

Ida Nurhaida Computer Science Faculty

Universitas Mercu Buana, Jakarta 11650, Indonesia [email protected]

Desi Ramayanti Computer Science Faculty

Universitas Mercu Buana,Jakarta 11650, Indonesia [email protected]

Rhema Riesaputra Computer Science Faculty

Universitas Mercu Buana,Jakarta 11650, Indonesia [email protected]

Manuscript History

Number: IRJCS/RS/Vol.04/Issue11/NVCS10080 DOI: 10.26562/IRJCS.2017.NVCS10080

Received: 08, October 2017 Final Correction: 23, October 2017 Final Accepted: 02, November 2017 Published: November 2017

Citation:Nurhaida, I., Ramayanti, D. & Riesaputra, R. (2017). DIGITAL SIGNATURE & ENCRYPTION IMPLEMENTATION FOR INCREASING AUTHENTICATION, INTEGRITY, SECURITY AND DATA NON-REPUDIATION. IRJCS:: International Research Journal of Computer Science, Volume IV, 04-14. doi: 10.26562/IRJCS.2017.NVCS10080

Editor: Dr.A.Arul L.S, Chief Editor, IRJCS, AM Publications, India

Copyright: ©2017 This is an open access article distributed under the terms of the Creative Commons Attribution License, Which Permits unrestricted use, distribution, and reproduction in any medium, provided the original author and source are credited

Abstract— A digital signature is a method that serves to improve the integrity, authenticity, non-repudiation, and confidentiality of digital data in transmission. This paper discusses digital signature and encryption functions for data communication. In this study, implementing the data transmission is done by email using digital signatures and encryption functionality on Open PGP. In the end, this research resulted that the function of the digital signature and encryption can be implemented effectively in the process of sending data/

information via email.

Keywords — Digital Signature, Email, Integrity, Authenticity, non-repudiation.

I. INTRODUCTION

E-mail or electronic mail is one of information technology that widely used by the business/employee in communication activities. As it grows, the email not only as an additional component to communicate but also has become a crucial requirement in business development itself [1][2]. Email is often incorporated as personal data as well as the company in the communication business. During the process of sending an email, while the destination address is correct, then the email will not lead problem in the future. However, the problem will occur when email is sent to the wrong address and accepted by the unauthorized recipient. On the other hand, it also needed the system that could verify if the parties are not responsible for any changes of email content while the sender does not know about it [3]. This condition will arise a problem and misunderstanding between the sender and the recipient.

(2)

ISSN: 2393-9842 Issue 11, Volume 4 (November 2017) www.irjcs.com

________________________________________________________________________________________________

Page -5

Digital Signature is a system that can be used to prevent the problem of email sending process. In this process, the Digital Signature can perform the function of authentication, integrity, and non-repudiation for checking email content [4]. Digital Signature is expected to prevent an error while sending the document via email and can execute a verification process. Furthermore, the email can be categorized as a correct or legitimate email. The implementation of Digital Signature including an encryption function that can protect the data, so that the content of the data will not be able to understand by unauthorized parties [5]. Therefore, there is a requirement of a system that can integrate the implementation of digital signature and encryption in the process of sending data via email. The digital signature will increase the security of email users regarding the legitimacy or validity of the receiving data [6]. On the other hand, the public awareness about the importance of an email communication must be improved. The transaction has to be maintained according to validity and safety process of sending data/information via email [4]. The user can understand regarding how the digital signature is working and the process of its integrity to the client email application. The objectives of this study are:

1. To perform analysis and to demonstrate that the use of digital signature can improve the authentication, integrity, security, and non-repudiation of data that is sent by email

2. To implement the data encryption for protecting content from the unauthorized user.

The organization of this paper is as follows. Section II presents the research methodology. Section III discuss the research methodology. Section III describes the topology design of implementation and testing. Section IV discusses the findings. This paper is closed by a conclusion in Section V.

II. FUNDAMENTALTHEORY

Information security has become a critical issue. Various steps have been taken to improve and develop the level of security [7]. The research method used refers to the framework that can be seen in Figure 1.

Figure 1. Research methodology A. Cryptography

Cryptography is a method of storing and transmitting data or information in a form that can only be read or processed by those who are entitled [7]. One of the purposes of using cryptographic techniques is to hide information from unauthorized parties to know the contents of the information [8]. Cryptography has been widely used to secure information. This research uses a cryptographic algorithm for data security on e-Passport [9]. This research performs a modular multiplication method comparison on the RSA algorithm for keys of 1024 bits long.

Feizi et al. [10] use cryptographic algorithms to serve as a major component of information security in the form of block and data flow cipher. Analysis of Simon cipher block is done through algorithm simulation on FPGA.

B. Symmetric Key

The symmetric key is a cryptographic method that uses the same key as the encryption and decryption process [11][12]. Each encryption method, either symmetric or asymmetric, has an identical algorithm between sender and receiver of data/ information. This algorithm is combined with symmetric keys to perform the encryption process and decryption on a data/ information.In Figure 2, we can see the transformation process from the plaintext, into a random and unreadable encryption format (ciphertext) until the decryption process is performed by a symmetric key method:

C. Asymmetric Key

Public Key Cryptography is a method that uses asymmetric keys as an encryption method, which is utilized for an authentication process on Digital Signature. Public key cryptography uses two certificate key pairs that are private key and a public key. Both of the key are created using asymmetric key algorithm [13].

(3)

________________________________________________________________________________________________

Page -6

Plaintext ^Encryption ^Ciphertext ^Decryption ^Plaintext

Secret Key = X

Figure 2. Symmetric Key

The key pair is a unity that has a connection with each other. The data/information encrypted using private key can only be decrypted by using the public key pair, and vice versa. If a document is encrypted using a public key, then it can only be decrypted by using its private key pair. Figure 3 is a transformation of plaintext, into a random and unreadable encryption format (ciphertext). Furthermore, the decryption process is done by the asymmetric key method.

Plaintext Encryption Ciphertext Decryption Plaintext

Public Key = X

Private Key = X

Public Key = X

Figure 3. Asymmetric Key

An example of an asymmetric key algorithm used to create two keys both private key and public key. They serves as key in the encryption and decryption process as follows ([14], [15]):

For example, the value of p = 5 and q = 21, then:

 n = p * q = 5 * 21 = 105

 φ(n) = (p - 1) * (q - 1) = 4 * 20 = 80

 Select one of prime number from the equation 1 < e < φ(n) , from example, we choose e = 7

 d = 5 ((5 * 7) mod 80) = 5(35 mod 80) = 5*35 = 175

The generated key as public key and private key are paired and known as asymmetric keys

 Public key (e, n) = (7, 105)

 Private key (d, n) = (175, 105)

Another example of using asymmetric keys in the encryption and decryption process at a certain value can be seen below:

 Encryption on m = 17 is c = 17⁷mod 105 = 38

 Decryption on c = 38 is m = 38¹⁷⁵ mod 105 = 17 D. Hash Function

The hash function is a function that takes a string of variable-length message and returns a fixed length value called a hash value [16]. The characteristics of one-way Hash function, namely:

1. The H function can be applied to any size of data block.

2. H produces a value with fixed-length.

3. H(x) easily calculated for each value of x which is given.

4. For each h which is produced, it is impossible to return an x value such that H (x) = h. That is why the H function is said to be a one-way Hash function.

(4)

Issue 11, Volume 4 (November 2017) www.irjcs.com

________________________________________________________________________________________________

Page -7

5. For each x which is given, it is impossible to find y≠x so that H(y)=H(x).

6. It is impossible to find x and y pairs so that H(x) = H(y).

Illustration of Hash function can be seen in Figure 4 below:

One way Hash Function

 ^, _ ₁ 

 _i _i

i H M h

h

M i 1



h i h ⁱ

Figure 4. Hash Function E. Digital Signature

Digital Signature is applied to authentication functions, integrity checking, and non-repudiation functions on data or document. Digital Signature created in the cryptographic values that depend on message and message sender.

Some functions of Digital Signature are as follows:

a. Provides Integrity checking process

Data integrity is related to securing of unauthorized data changes. For maintaining data integrity, the system must have the ability to detect data manipulation by unauthorized parties, including insertion, deletion, and another data submission into actual data.

b. Provide Authentication process

Authentication relates to identification/ recognition, both in the system and the information itself. Two parties who communicate with each other must introduce each other. The information transmitted over the channel must be authenticated, the contents of the data, the delivery time, and so on.

c. Provide non-repudiation process

Non-repudiation is an attempt to prevent any denial of the transmission/creation of any information by the sender. In the data sending process using Digital Signature, the encryption method is only in the data hash/Message Digest which is intended to authentication processing for the sender. Here is an overview of the process, and the basic concepts of Digital Signature [17][18]. Figure 5 shows a public key exchange illustration. If User A and User B want to exchange keys and communicate, then:

a. User A and User B create two keys

 User A creates two keys, public key Kpublic [User A] and a private key Kprivate [User A]

 User B creates two keys, public key Kpublic[User B] and a private key Kprivate[User B]

b. They communicate each other to exchange the key

 User A and User B exchange public keys each other. User B gets Kpublic[User A] from User A, and User A gets Kpublic [User B] from User B.

 User A encrypts Message Digest P to User B with function C = E(P, Kprivate[User A])

 User A sends the C data to User B

 User B receives C from User A and open the text-light with the function P = D(C, Kpublic[User A]) The same process occurs when User B is going to sending a message to User A:

 User B encrypt Message Digest P to User A with function C = E(P, Kprivate[User B])

 User A receives C from User B and opens the Message Digest data with function:

P = D(C, Kpublic[User B])

The Digital Signature is performed in data/document through several steps as follows:

a. A hash function is used on data to be sent based on the Hashing / Message algorithm. The result in Message Digest or a Hashing value to the data to be sent.

b. Message Digest is encrypted using the private key and generates data called Digital Signature.

c. Each data submission which accompanied by Digital Signature to ensure that the data is valid and no one to make changes without the consent of the data sender (called integrity).

(5)

________________________________________________________________________________________________

Page -8

Figure 5. Public Key Exchange Process

Data

Hash

Message Digest

Sender Private Key Encryption Algorithm

Digital Signature

Digital Signature Process Verification Digital Signature Process

Data Digital Signature

Digital Signature

Message Digest Data

Hash

Message Digest

Are they have same value?

Sender Public Key Encryption Algorithm

The sender data is authenticated The sender data is

not authenticated

Yes No

Figure 6. Digital Signature Process

The verification process is doing by the recipient of data to ensure that the data is completely valid and correctly transmitted by the authorized sender. After the data/document arrives at the destination, the recipient will do the Digital Signature verification process by decrypting using the public key. It will ensure that the authorized sender correctly sends the received data.

a. The recipient decrypts the data/documents sent and matches the result with the Message Digest (data Hash) from the sender (integrity process).

b. After the data decryption process, the Message Digest is matched by comparing the Message Digest data to the authentic using the same Hash algorithm.

c. If there is conformity, then the data is valid. Whereas if there is no match on the value of Hash (Message Digest), then the data is not valid.

In the data sending process using Digital Signature, the encryption method is only on data Hash /Message Digest for authentication process.

(6)

________________________________________________________________________________________________

Page -9

Digital Signature combines the Hash function to checking data integrity and encryption functions using public key cryptography for the authentication process. Figure 6 illustrates the formation process and digital signature verification.

F. Encryption Function in Data Delivery Process

The use of encryption in the data delivery process is doing for the following purposes [19] :

a. Preventing from sniffing, or the existence of data tapping during the data transmission process which affects the existence of data during the transmission process/data.

b. Improving data security if the data is on the parties who are not entitled. The process will perform if there is an error found in data delivery due to human error.

Figure 7 illustrates the encryption and decryption process by using asymmetric encryption. This process can be described in the following:

1. Public key exchanges are performed as outlined in the previous chapter.

If User A and User B want to exchange keys and communicate, then:

 User A and User B exchange public-keys with each other. User B gets Kpublic[User A] from User A, and User A gets Kpublic[User B] from User B.

 User A encrypts data to be transmitted P to User B with function C = E(P, Kpublic[User B])

 User A is sending the C data to User B

 User B receives C from User A and open the text-light with the function P = D(C, Kprivate[User B]) 2. The same thing happens when User B is going to sending a message to User A:

 User B encrypt Message Digest P to User A with function:

C = E(P, Kpublic[User A])

 User A receives C from User B and open Message Digest data with function:

P = D(C, Kprivate[User A])

Encryption Process

Data (Plain text)

Receiver Public Key Encryption

Algorithm

Cipher text

Decryption Process

Cipher text Receiver Publi c Key

Encryption Algorithm

Data (Plain text)

Figure 7. Encryption and Decryption Process III. DESIGNIMPLEMENTATIONANDTESTINGTOPOLOGY

Problems that exist in the process of sending data by email without digitally sign and encryption process follows:

1. There is no authenticating process at sender site so that it can lead a problem to the existence of fraud identity to the email sender (email spoofing).

2. Integrity checking of the document/data is not available. It means there is a potential change of the data tacitly or unnoticed by both parties either the sender or the recipient.

3. Non-repudiation process becomes difficult to prove due to the lack of audit trail. This process will determine the validation email of sender's data

The sending and receiving data process through email has no authentication process, integrity checking, data encryption process, and prevention of denial of data sent by data sender (non-repudiation). Figure 8 shows the proses the sending and receiving data process through email with the following process:

1. User A sends the data through email to User B using SMTP (Simple Mail Transfer Protocol) port 25 and uses Google Mail Server as an intermediary.

2. Likewise, User B sends the data through email to User A using SMTP (Simple Mail Transfer Protocol) port 25. Google Mail Server as an intermediary as well.

3. User A and User B retrieve email content using IMAP (Internet Messaging Access Protocol) port 993.

(7)

________________________________________________________________________________________________

Page -10

Figure 8. Email delivery terminology

The topology design for the experimental scenario can be seen in Figure 9. There are 3 (three) email users and 1 (one) email spoofer which is divided based on some functions as follows:

a. HOST A ([email protected])

Figure 9. Implementation Topology

HOST A employ google mail server as MTA (mail transfer agent) and MDA (mail delivery agent), while Open PGP is applied to perform digital signature and encryption functions. HOST A will send data/information via email without digital signatures and encryption to HOST C. Furthermore, HOST A will send data/information via email using a digital signature and encryption functionality to HOST B.

(8)

________________________________________________________________________________________________

Page -11

b. HOST B ([email protected])

HOST B uses google mail server as MTA and MDA, while Open PGP act to perform digital signature and encryption function. HOST B will deliver data/information via email using a digital signature and encryption functionality to HOST A.

c. HOST C ([email protected])

HOST C uses yahoo mail server as MTA and MDA without digital signature and encryption functions. HOST C is used for acceptance process email testing from HOST A. Those emails are encrypted using a digital signature.

d. HOST X (fake identity for [email protected])

HOST X employs as fake email sender in Android for email spoofing or email address identity fraud. HOST X will try to transmit data/information to HOST B while HOST A faked email addresses without the use of digital signatures and encryption.

For the test environment in this research, several preparatory steps are taken to implement, and testing process in the following:

1. Implementation preparation stage

Several steps should be prepared namely: Create a new email account, enable IMAP protocol for withdrawal the email content, installation process of gpg4win-2.1.0, add-on installation process, and installation process Enigmail-1.4.6-sm + tb.xpi to access email by using a software program related to e-mail content delivery, receipt of email content, digital signatures, and encryption

2. Implementation and Function Testing Stage

Implementation and testing run on the overall function of data/information transmission through email, and the digital signature on the transfer of data/information.

3. Test Result Analysis

This stage we conduct analysis results of the implementation and testing function that has been done so that it can be concluded that a comprehensive review of case studies carried out.

IV. RESULTSANDDISCUSSION The test results analysis based on design implementation topology is as follows:

a. In the case of sending email without digital signatures and encryption, it is hard to identify the origin of recipient email message. The contents of email cannot be ascertained according to its validity because it cannot be verified. Furthermore, it cannot be ensured the confidentiality of the email contents because it is not encrypted during the sending process (Figure 10).

From: [email protected] To: [email protected]

Message-ID: <1122906176.1.1392477533843.JavaMail.javamailuser@localhost>

Subject: Bonus Transfer MIME-Version: 1.0 Content-Type: multipart/mixed;

boundary="----=_Part_0_1122470856.1392477533734"

X-Sent-Thru: : FakeMail Sender 1.0 for Android

X-IMPORTANT-NOTICE: : The real sender of this message might be different ---=_Part_0_1122470856.1392477533734

Content-Type: text/plain; charset=us-ascii Content-Transfer-Encoding: 7bit

Hi bro, mama minta pulsa, tolong kirim pulsa 1jt buat si mama...

---=_Part_0_1122470856.1392477533734--

Sender email (HOST X) Receipt email (HOST B)

Subject email including Data/

information sent by HOST X

Data/information content that sent by HOST X

Sender email is doubtful, however it cannot be verified

Figure 10. The result of receiving Host X email to Host B

(9)

________________________________________________________________________________________________

Page -12

data transmitted remained safe and kept confidentially. This process is performed in the case of incorrect of the recipient address. For example, email delivery error from Host A to Host C. The contents of the email cannot be read by the recipient of the email (Host C) which is not entitled to receive it (Figure 11).

c. It can be proved that the process of sending data/information by email which uses digital signature and encryption have particularly the ability to make the process of digitally sign and encryption processes.

Furthermore, the recipient can do the verification and decryption process on the email content which is received. The test result can be seen in Figure 12.

From Rhema.Riesaputra Sat Feb 15 18:22:49 2016

X-Apparently-To: [email protected] via 98.139.211.222; Sat, 15 Feb 2016 18:22:54 -0800

Return-Path: <[email protected]>

Received-SPF: pass (domain of gmail.com designates 209.85.160.54 as permitted sender)

cnlwdGVkLmFzYwNhcHBsaWNhdGlvbi9vY3RldC1zdHJlYW0DAzI- X-YMailISG: 8gdi9vMWLDvSOsTAUHc1iY1rgivNTr..7QX.5kAyfZ2.1.X4 k6WEBi3KY.djmpQR1SUyMVDQtYMT._GgBM7hpfWLmUpvLGMLRpX2BpLjYE51

KaCBtapJvgaEtos3_VjLVBqg1OstjaxvvoCT1Joa7ATGKNw.pZnSDc1BTA7D 8Id6bHjjH5yOvqVwyRUhOnXrGAPpB9WuAMODB4kucG3RbL6VTwRMnj6drgkh

IJ3dfk.hwmyvNDExw2ERtzFd7Cznaxwn6irR_UVdQgRWZJ.IV5_6W4TrcpWu .YHgedDtcjkIzdXGm1egNocCxiBRoVg0GZYt8RAPRmJCks9AKnhwN0m53oEY DTU4s0b29d8.XfnwKkOwTFJdx1Q3rmHnr58LqwWxCqZa8WeRJ3r8HcgVX0v0

0tEiTNvrne8fNZtXFSEkPH0nmARFCVS4YOCxHbVc8fEzSinjkyXuQ1yyyPWH M3E9x3wSPPbxJqw9TxSukPYwKdmX3ERru9c2xMi3dVW5DToAQoOxBSLS78N6

yC4Se7qAACSDAdfLQz62_IQ7Bca57r77HAKrCZnlvB_d0fskAMJyfDkgqhDx zzbr4PBMHeFSA3p.IGRwxKUVAUeTohZbpV5XD528fJc9hqLGoyoZkuzt.10y vw_rvs6bHR21mjK2SpP1TzZW6DbE8PjwGt1vVPVWOBe6OLYRxVGVsJUVLNJ9

Rk0Vj4PNhzE.XqCwX1aZIgunMbz3yfZ0XH092XAANsUpDT4y5cjhJ12wOz96 DT9U3C0R3aq2_M6rbZK0tCNWhOd9VLlBVDpQywa7I7u9Zo6IiiQNsPMuxxLw

eZm9fSC0HqQ.AFfleSzphnRSmt6vRD12po0xL.FHpySB01m7LMkDG9ip5bBM bWrwtfcaAcBezyQcO2T3NCiUKNLSjZ6R7y0R8.jkoCDRq3J4.w4rQKRViG5G 7vzc.maNqkLxNLTVwX2aCH6m2_VqGdk4M_JffdiTSeH_KYw4LrCfJ6M8p6eY

vKI.faFZGM_XcaZfSB7T9TCUKhNHHR9nNtOlu.uejxPY__YPvJSr6fLrex9h Sw20MAh2AfQeu64Oc.jDPrrFWpjqlRPSuu3QRbOKZkrl3ZEafL19yrd4.Yr5 LX_8xHeg447.TDusgGeQ37vFWsTUgT4SwMTQS9SHNPfPXqeo3I5Ffv7oeQj0

wKY4euYVrAc4uAD48lNOasvWpZYeQ12OjnI7nCfscxcKKXXtxQt88Pc7zswY .ViPLVMTYdykueVAJXoU5ZBaFiS.IlDJSD3Wxh.nCkXyMxa60rKfAA9MyqLV cP.p136HdzYC317f64rptVa_Npnesr8gblKrCFeSWR47o24Sea3c.zkXwLAP HZpFoPW6jkQ4ww5uAK1f4B.TIsOmkm2oQdQTrd38ZGTJ0Yy4mk.hvsAH2q1r

GHRZcKFquBTNVLPFtwsjo4OlfNrBiM.nZGjm36jAWMXqEtSzMH_ia1aAgFML 7AQ9o_dyeLBaswxUyGJg8rIk.uysECXm4KuiMz22W_Aurhyi9HfgHbJZO8IY

02X4qIvYmCIGq7kQCSfmzj3f7RpvGG_nBJUL.bY-

Received: by mail-pb0-f54.google.com with SMTP id uo5so13844460pbc.41 for <[email protected]>; Sat, 15 Feb 2016 18:22:53 -0800 (PST)

DKIM-Signature: v=1; a=rsa-sha256; c=relaxed/relaxed;

d=gmail.com; s=20120113;

h=message-id:date:from:user-agent:mime-version:to:subject :content-type;

bh=TGyU/F7c97Ipvnbpmc8Y9/UP+MK+G29ueUQJxi/RqQY=;

b=geUtHafTx95geaEXKyOzYSWY4scW5GHBtLPe0fFbGqdheqwZ+2JhoapZGKNCWnY18h vuFVeQyd1E0oZP5f7R+A/

rip4MCA7ekxEf9PPQOyURA9TFXHUCnqxt3E9xunek4E+ioM

kBn6jAB3X9shHgu7uNRy23oKtCJyd+W6QoE2Cuwx2zPA/3CxjRyA48SlqUiFdftXBU05 4tWMPo+715Pchez7ImOQxKUnD0NbJ8I8464xx6xIP/

keLLTRloMuFvPW+WFuzH68Jzvo

WpnsdRMi0aT+DrhmeD7/w4JRM7C2sj3qpwpzlxWDl2HOR/

eS4tCyerJZ+5piSUFDMhvr 9pJQ==

Recipient Address (HOST C)

HOST A sent an encrypted email Sender Address (HOST A)

Encrypted email from HOST A can not be verified

Figure 11. The result of email sent from HOST A to HOST C V. CONCLUSIONS

This conclusion is taken based on the test results analysis that has been obtained. The conclusions that can be drawn from this research are:

1. The data/information delivery through email without digital signatures and encryption is vulnerable to the threat. From the test results can be seen that any email sender address can be falsified easily (email spoofing).

Furthermore, it is hard to verify the process because it required additional software to conduct the examination and identification process. The method of sending data by email using digital signature technology can improve alertness of the email recipient to check the integrity of email sender.

2. The application of digital signature technology and Open PGP encryption on the email is ideal for the delivery of corporate data, and personal/private were deemed important, confidential, or which is included in sensitive data/information. Certificate key both the private key and public key must be stored securely and not be given to other parties outside the relevant requirements.

(10)

________________________________________________________________________________________________

Page -13

Suggestion

As for suggestions and to improve the function of digital signature and encryption technology related to this case study, can be described as follows:

1. It is recommended to determine the time/expiration period on each key certificates are created and transmitted. The period key certificate can be adjusted to the needs how long the delivery of communications data/information via email will be done.

2. The additional applications for digital signature and email encryption such as Open PGP applications should not be downloaded from unreliable sources. Verify with the checksum method to see if the application is obtained from a trusted source. Verify the checksum method to determine whether the application is obtained from reliable sources.

Delivered-To: [email protected] Return-Path: <[email protected]>

spf=pass (google.com: domain of [email protected] designates 2607:f8b0:400e:c03::22e as permitted sender) [email protected];

dkim=pass [email protected];

dmarc=pass (p=NONE dis=NONE) header.from=gmail.com Received: by mail-pa0-f46.google.com with SMTP id rd3so13525960pab.19

for <[email protected]>; Sat, 15 Feb 2016 09:02:55 -0800 (PST) DKIM-Signature: v=1; a=rsa-sha256; c=relaxed/relaxed;

d=gmail.com; s=20120113;

h=message-id:date:from:user-agent:mime-version:to:subject :content-type;

bh=JM7wjomoLU2Zf1ZK1fDhSgo79J8hOUunWn+StwxdgL4=;

b=qHdYbj1nvQ4rGdgoVDuyZR7FQO8QcrSsiag83kv1VWXxh6Z+PCLUBwMGVXFadbjQSN zT5IhtgZSCjYNX3J/p6KHTxpEAZS0fmYDqCU8oh45wAEZ40yIiWp9vDXGe0xX2fNlJ3m q09UYGuTta+qojsdcai80wz6jL7S8ZMjTr69Sft2teczlgMwNQ9eC8JmaJuvq53PMQ5x InSjtTDEkX9x3V3kVMAYFQjiyQjwCB4B1kivRbHAGoYgEE7TxSU4EJR4uiQa/ggTz6jN YJbjNPSy04/5OxttHm+dh6AVNyEm6/8f9VBTlYghkJXS9I/zyOJTNrTknBSkvSUDysPG

+OhA==

X-Received: by 10.68.112.164 with SMTP id ir4mr16079439pbb.153.1392483775384;

Sat, 15 Feb 2016 09:02:55 -0800 (PST) Return-Path: <[email protected]>

Received: from [127.0.0.1] ([203.176.181.60])

by mx.google.com with ESMTPSA id qq5sm28760033pbb.24.2014.02.15.09.02.53 for <[email protected]>

(version=TLSv1 cipher=ECDHE-RSA-RC4-SHA bits=128/128);

Sat, 15 Feb 2016 09:02:54 -0800 (PST) Message-ID: <[email protected]>

Date: Sun, 16 Feb 2016 00:02:48 +0700 From: "Rhema.Riesaputra" <[email protected]>

User-Agent: Mozilla/5.0 (Windows NT 6.1; WOW64; rv:17.0) Gecko/20130801 Thunderbird/17.0.8

Subject: Bonus Transfer X-Enigmail-Version: 1.5.2

This is an OpenPGP/MIME encrypted message (RFC 4880 and 3156) --OWQkRscQI5glTBhEi0bKs2QqhaP1sKEbI

Content-Type: application/pgp-encrypted Content-Description: PGP/MIME version identification

---BEGIN PGP MESSAGE--- Version: GnuPG v2.0.17 (MingW32)

Comment: Using GnuPG with Thunderbird - http://www.enigmail.net/

hQELAwHK4MrK5+PgAQf4wgZ0fmGpHSk1+grv/Lgc2LKhy+633eJTaQwcA2ciZb0T dHd/5sDWlV+5iDkwmy7EGAB8YUM+zF3xLe4OAIeidu+qoImk1Ks+GmuoMVZeZWFp

Jp4F/hBx1jmmgBrWGsh8xxsw0nMELLHyQvnalNM5EUPMxwU0lTIHkKoKjq5UXLKb L/qUyJF3izIAaoG0VvU0vg3ZdeHY/f6cSl2YOYHl1G5C3ZGRnizbEsaylVC0fekR /1knXoCbzVIx07PNAsO6Ld/R2OAKDt36z/Rzdfawu1T/2lnF7fKo9vU091yA2CLL sErObyGwNZ1VkveuNSFAw+QOZ0tNtrOJi1pU6iczhQEMA6jIyC1aVcTcAQf/aaZt b9APb3umRqQxX6q9YzqvHheDR9O0RqgvL+hDPPWvL5QYjwn0rOQgcTlC0sEISgR1

Wx6QD/c2fNvTNYqpKgZnG3xSzcP7AxBZEjh62Rg9jkaiqYEU7s1k/oKIxvqtvr+7 XJ4azMT25Rx2evhNNg5iJyb7XwY2OkAJIRF10qU8lcNA0fHFERBuUcCYsEiO+m2W UGpPATFxrRv2JM6lg4joaaHDv96QZG1iUW+W3PO9ajoI6SqbwDzIJzaZ8rmTU1KU Mkq3/j+LaQkpbcFkMtdvfSLd1I1w/LDqhIz69U4R63d0YWxThMfunC1dUA2olSHI

yR+/VthcFzFk6GgrcdLpAaLhyhOHB4YIGtDZHjpuESZ01WkzxCCr8WSF0/I26qgu fOUv/xtOl4xeIgBi4aB5g5pCkocpUrJV5M/n9J9erKrwryorOFiY8sg77MEPBftf KX5YAqpfmHaRdWp240+FxSUXkezRwMvQzq5gc5R0AmwUKPIVdIzIW2IbBHOFwq08

ECIKWIXntjboC7zIiINj6NjbMesjkgVXRkgC+iH+RvAeg7AVaI8Xr3vbiYYfHb58 PxMs0Z3xVJQ1hEYqL8Yov6spdIkEHHmpK7LA8HBVqqNBkiuALRG+lF3jjmJvaHdJ v8OohUGm8j27wILAZUtXGMb9iSgPp9hnQFG3jqdwLpuh9kBSZliC+JnpNoY1aRWR

DMKfeYEV6rk0qfNsRNuvH5yZuHfEk7ckATl84n/7Y3FdHRa8w7UOzf7GfQ2etwEH /VmmyZnmtC1e8WFlhK/wHbH0mQrTzduceoI/iT4n3hnEZ3YO68QJTWW+BRrxXFXE

Z2FC2f6YFuR/muv00FLTHV8GvQlFD600JVYWTym+m4lvhrZPOaircWErKLbqxkvQ BaDlBAuQtW07jdZVpdUI+Jp9J6xuh8ufchGrb0YVfL3GFJIQC4xRYlYK9ba11XDW wzYWi/7Do3kLYeYcNKqgYpxDwn4Tv9+hv//5hT4/gUZ7T+Iq8AiZzSwQXTN4GYta

ztiP8foI7dcNgTbEPDptey9ch3mYvOtvE5lJbWZ2t+CDMf01eZ0kSc5ppFE/Gcii b0wvgcudUndZ6TP68x5IpaZe7pK5gqzfFvg1zBuampDgrsXNyJPQahwz

=mJzV ---END PGP MESSAGE---

The example of encrypted data/

information that sent by HOST A using application Open PGP Recipient email (HOST B) Sender email (HOST A)

The email contained authenticate data/information

Digital Signature

Information concerning Mail User Agent HOST A

Add-On Information according to Mail User Agent HOST A

Information about Subject Email that sent by HOST A

Figure 12. Email data Host A goes to Host B

(11)

________________________________________________________________________________________________

Page -14

1. Danielle S. Agnew and K. Hill, “EMAIL ETIQUETTE RECOMMENDATION FOR TODAY’S BUSINESS STUDENT,” in Academies International Conference, 2009.

2. A. Adriansyah and Kasmad Ariansyah, “APLIKASI SHORT MESSAGE SERVICE (SMS)DAN EMAIL SEBAGAI MEDIAKOMUNIKASI DATA DALAM SISTEM PEMANTAUAN SUHU,” Bul. Pos dan Telekomunikasi., vol. 9, no. 2, 2011.

3. Lijun Liao and Jorg Schwenk, “Secure Emails in XML Format Using Web Services,” in Web Services, 2007.

ECOWS ’07. Fifth European Conference on, 2007.

4. S. Koppula and J. Muthukuru, “Secure Digital Signature Scheme Based on Elliptic Curves for Internet of Things,”

Int. J. Electr. Comput. Eng., vol. 6, no. 3, pp. 1002–1010, 2016.

5. Yoshiaki Shiraishi, M. Mohri, and Hitoshi Miyazaki, “A Three-Party Optimistic Certified Email Protocol Using Verifiably Encrypted Signature Scheme for Line Topology,” in Cyber Security and Cloud Computing (CSCloud), 2015 IEEE 2nd International Conference on, 2016.

6. M. A. Sadikin and R. W. Wardhani, “IMPLEMENTATION OF RSA 2048-BIT AND AES 256-BIT WITH DIGITAL SIGNATURE FOR SECURE ELECTRONIC,” Commun. Inf. Technol. J., vol. 10, no. 2, pp. 63–69, 2016.

7. Eric Conrad, S. Misenar, and J. Feldman, CISSP Study Guide. Syngress, 2010.

8. Rafik Hamza, “A novel pseudo random sequence generator for image-cryptographic applications,” J. Inf. Secur.

Appl., vol. 35, pp. 119–127, 2017.

9. S. Sharma and Harshali Zodpe, “Implementation of cryptography algorithm for E-passport security,” in International Conference on Inventive Computation Technologies (ICICT), 2016.

10.[10] S. Feizi, A. Ahmadi, and Ali Nemati, “A hardware implementation of Simon cryptography algorithm,” in International Conference on Computer and Knowledge Engineering (ICCKE), 2014, 2014. S. Harris, ALL IN ONE CISSP. Mc Graw Hill, 2008.

11.A. Wahab, R. B. Bahaweres, A. Mudrik, Muhaemin, and R. Sarno, “Performance analysis of VoIP client with integrated encryption module,” in Communications, Signal Processing, and their Applications (ICCSPA), 2013 1st International Conference on, 2013.

12.A. Roy and S. Karforma, “A Survey on Digital Signatures and Its Applications,” J. Comput. Inf. Technol., vol. 3, 2012.

13.E. F. Yakhya, “Penerapan Algoritma Kriptografi Kunci Publik untuk Repository Organisasi,” no. Bandung, Institut Teknologi Bandung, Jl Ganesha, 2013.

14.“RSA Algorithm.” H. Bidgoli, Handbook of Information Security, Key Concepts, Infrastructure, Standards, and Protocols. John Wiley & Sons, Inc, 2012.

15.X. Weihua, “An Digital Signature Method Applied for Distributed Rending Submit System,” in IEEE ICIS, 2017.

16.H. K. B. Ponnapalli and A. Saxena, “A Digital Signature Architecture for Web Apps,” IT Prof., no. April, pp. 42–49, 2013.

17.Y. A. N. Xu, M. Wang, H. Zhong, J. I. E. Cui, L. U. Liu, and V. N. L. Franqueira, “Verifiable Public Key Encryption Scheme With Equality Test in 5G Networks,” IEEE Access, vol. 5, 2017.

DIGITAL SIGNATURE & ENCRYPTION IMPLEMENTATION FOR INCREASING AUTHENTICATION, INTEGRITY, SECURITY AND DATA NON-REPUDIATION

Page -4

DIGITAL SIGNATURE & ENCRYPTION IMPLEMENTATION FOR INCREASING AUTHENTICATION, INTEGRITY,

SECURITY AND DATA NON-REPUDIATION

Page -5

Page -6

Page -7

One way Hash Function

 ,  1 

 i i

i H M h

h

M i 1



h i h i

Page -8

Page -9

Page -10

Page -11

From: [email protected] To: [email protected]

Message-ID: <1122906176.1.1392477533843.JavaMail.javamailuser@localhost>

Subject: Bonus Transfer MIME-Version: 1.0 Content-Type: multipart/mixed;

boundary="----=_Part_0_1122470856.1392477533734"

X-Sent-Thru: : FakeMail Sender 1.0 for Android

X-IMPORTANT-NOTICE: : The real sender of this message might be different ---=_Part_0_1122470856.1392477533734

Content-Type: text/plain; charset=us-ascii Content-Transfer-Encoding: 7bit

Hi bro, mama minta pulsa, tolong kirim pulsa 1jt buat si mama...

---=_Part_0_1122470856.1392477533734--

Sender email (HOST X) Receipt email (HOST B)

Subject email including Data/

information sent by HOST X

Data/information content that sent by HOST X

Sender email is doubtful, however it cannot be verified

Page -12

Page -13

Page -14

 ^, _ ₁ 

 _i _i

h i h ⁱ
