S.SenthilRajan, D.Radhika, G.Vasanthi, B .ShenbagaRajeshwari.
Department Of Electronics and Communication Engineering, Sri Venkateswara College of Engineering,
Email- [email protected] and contact no – 9941942397.
Abstract— This paper presents a micro strip star patch antenna on a FR4 substrate (glass epoxy) having thickness of 3.2mm. This antenna consists of a star shape radiating patch along with a partial ground plane. Two equilateral triangles of same dimensions (30x30 mm) are mounted to get a star shaped patch. The star patch and the ground plane is made up of conducting material (copper).
The star patch is excited using a micro-strip feed line from the edge of the patch which results in enhanced bandwidth. Antenna parameters such as return loss; radiation pattern; gain & Voltage Standing Wave Ratio (VSWR) are investigated. The proposed antenna has high gain at 2.4GHz frequency. This antenna finds application in Wireless Local Area Network (WLAN) and Bluetooth.
Advanced Design System (ADS) software is used to model and simulate this micro-strip patch antenna.
Keywords— Antenna; Micro strip star patch; Probe feed; ADS software; Return loss; Radiation pattern; VSWR.
INTRODUCTION
The rapid development of wireless communication systems and the subsequent burst of wireless devices place several demands on the antenna designs. Compared to conventional microwave antennas, Microstrip antennas (also known as Printed antennas) have several advantages, and therefore various applications cover the broad frequency range from 100MHz to 100GHz [1]. Microstrip antennas are characterized by a large number of physical parameters and they can be designed to have numerous geometric shapes and dimensions. A Microstrip Patch Antenna (MPA) consists of a radiating patch of any planar or non-planar geometry on one side of the dielectric substrate with ground plane on other side. Various patch configurations such as square, annular-ring, ellipse, rectangular, equilateral triangular and dipole have been investigated for past few years [2][6].
These patch antennas possess many desirable features like low profile, light weight, relatively inexpensive to manufacture, thin profile configuration , linear and circular polarization are possible with simple feed and can be easily integrated with microwave integrated circuits. These antennas have excellent low power handling capacity and hence they can be used in low power transmitting and receiving applications. These features make microstrip patch antennas useful for many applications in radar and wireless communication systems [7][10].
Besides having more advantages, one of the principal limitations of such microstrip patch antennas is their very narrow bandwidth, which is on the order of a few percent and low directive gain. Many techniques have been suggested to enhance the impedance bandwidth of microstrip antennas. Among the various patch configurations available the equilateral triangle patch has more advantages. They occupy less metalized area on the dielectric substrate than other existing configurations and a low radiation loss.
In this paper two equilateral triangles of same dimensions are considered and are placed one above the other to get a star shape patch [11][15]. The star shape radiating patch is energized by probe-feed line. Microstrip line feed is one of the easier methods to fabricate as it is a just conducting strip connecting to the patch and therefore can be consider as extension of patch. It is simple to model and easy to match by controlling the inset position. The modified equilateral triangle patch in the form of star is simulated using ADS momentum software. The results obtained in accordance with the proposed antenna are given below. The designed antenna has high gain at the frequency 2.4GHz respectively.
ANTENNA GEOMETRY
Figure.1 shows the structural view of equilateral triangular patch of dimension 30mm.Two equilateral triangles of same
dimensions (30mm) are considered. The star shaped patch is formed by inverting and adding these two equilateral triangles of same dimensions as shown in figure 2.
ISSN 2091-2730
36mm
30mm
30mm
Figure: 1 Equilateral triangle Figure 2: Star shaped patch
Figure3: shows the antenna with patch size of 30mm × 36mm with substrate size of 38mm × 48mm is preferred in this design. A microstrip probe-feed line of 0.5mm × 13.7mm is used to energize the radiating patch. The dimension of the ground plane is 17.5mm
× 11.5mm. Star patch and ground plane is made up of copper. The antennas are printed on one side of a FR4 Epoxy substrate of thickness 3.2 mm, relative permittivity Ɛr= 4.4 and loss tangent tan ± = 0:019.
38mm
48mm
Figure 3: 3D representation of simulated antenna RESONANT FREQUENCY
The resonant frequency of the microstrip star patch antenna can be determined from the empirical formula is given in equation (1)
(1) Where,
fr = Resonant frequency(GHz)
Equations (2) and (3) are used to calculate the side length of the equilateral triangle and relative permittivity of the substrate effectively.
(2) Where,
aeff = Effective side length of the equilateral triangle(mm)
(3)
Where,
Ԑr = Substrate relative permittivity Ԑeff =Effective relative permittivity
a =Side length of the equilateral triangle(mm) h =Height of dielectric substrate (mm)
SIMULATED RESULTS
Figure 4 shows the Voltage Standing Wave Ratio (VSWR) plot against the frequency in terms of GHz. The proposed star patch antenna has a value of 1.181 at 2.4GHz. Figure 5 shows the plot of return loss (dB) against the frequency(GHz).The value of S11 at 2.4 GHz is -21.592dB. Figure 8 and 9 shows the radiation pattern of the star patch antenna.
Figure 4: Voltage standing wave ratio (VSWR) Figure 5: Return loss (S11)
ISSN 2091-2730
Figure 6: Efficiency of the star patch antenna Figure 7: Gain and Directivity of the star patch antenna
Figure 8: Radiation pattern (E) Figure 9: Radiation pattern (E- Theta)
Figure10: Circular axial ratio Figure11: Linear axial ratio
The compact microstrip star patch antenna with a probe-feed line is presented. A partial conducting ground plane was used to enhance the bandwidth of the antenna. The design and simulated results were performed using ADS software. Antenna parameters such as return loss, VSWR, gain, directivity and radiation pattern are shown in the figures achieves relatively high gain. This antenna is applicable for various wireless applications like Bluetooth, Wireless Local Area Network (WLAN).
