What is BIS Access Engine ?
Î It is one of the central software modules of the
Building Integration System
Î It’s a fully integrated access control solution with
corresponding access hardware
Î It is “just” a license to use a wide range of access control
features inside the entire BIS system
Î The installable software you got with BIS installation CD
Î It extends your existing BIS security or video management
What is BIS Access Engine ?
Î It offers solutions to monitor and control
z Bosch AMC and LACi access controller series with the
corresponding readers and I/O boards
z Elevators
z Parking lots with barriers and traffic lights z Guard tours
Access Engine meets your requirements
Î BIS Access Engine is designed modular
Î Start with the basic package already including
sophisticated features, such as anti-passback, route check, blacklist and other
Î Extend your system by licensing the number of
cardholders and necessary entrances
Î Extend seamlessly the access control’s security level
Access Engine meets your requirements
Î Use your access control hardware as guard tour
equipment
Î Arm/disarm your intrusion detection system via access
reader*
Î Extend seamlessly to access alarm management using
the BIS common features, such as location maps or action plans
Î Combine with video for a video verification or additional
door monitoring
The system structure
BIS basic package BIS common extensionsBasic licensing + common features
zdisplay features as location maps znumber of licensed operators,
detectorpoints, interfaces zdivisions ztimer zalarm operating z… BIS Automation Engine BIS Video Engine BIS Access Engine BIS Security Engine* Access Engine extensions Video Engine extensions Automation Engine extensions Security Engine* extensions
Integrated access control software
zelevator control
zparking lot management zarea balancing
The individual user interface (default layout)
alarm queue
individual alarm document list
alarm details
combo control element with
- location tree
The BIS user interface with Access Engine
alarm queue with
Video Verification alarm
action plan with - live image from door - cardholder photograph - action buttons to cycle
door or deny access alarm details
The door template philosophy
Î Select, configure individual settings, load and use
Î Select from a wide range of door scenarios, such as
standard door with in/out reader, turnstile, mantrap, elevator, …
Î Change standard door settings, such as open time, if they
differ from your requirements
Î Load to controller and use
Î Each template provides the corresponding wiring plan for
Parking lot and elevator management
Î Specific door templates to manage your parking areas or
the access to specific floor levels
Î Provides the balancing for the number of cars with the
corresponding control of barriers and traffic lights
Î Control an elevator with one reader and up to 56 logical
Guard tour and IDS arming
Î Use your access hardware for sophisticated guard tour
z up to 20 tours simultaneous z up to 10 readers per tour z use standard cards
z actual status in BIS user interface with alarm
processing on abnormalities
Î Arm and disarm your intrusion detection system*
z use standard cards z use keypad readers
z get informed on actual status
Access control and video
Î Direct reaction on any access control alarm, such as door
open time exceeded, duress alarm, video verification
Î Local storage or triggering archives in connected DVR
Access Engine features at a glance
Î Wide range of pre-defined door models, click and use,
providing the corresponding wiring table
Î Anti-passback
Î Blacklist
Î Route
Î Area balancing and access sequence check
Î Parking lot management and elevator control
Access Engine features at a glance
Î Import and export of cardholder master records
Î Random screening
Î Mantrap control and video verification
Î Visitor management
Î Arming and disarming intrusion detection systems
Î Detailed event log for recording access events and alarms
Access Engine features at a glance
Î Export in standard CSV-format for further use in other
applications
Î PIN code with duress alarm
Î Time profiles and scheduler for access permissions and
time based automatic control
Î Remote control of doors and readers individually by
location map icons, action buttons, device list, action plan or other common BIS features
Î Full security management on top with display of location
Access Engine features at a glance
Î In combination with Video Engine direct support of Bosch
and 3rd party video systems
Î Direct support of DVR systems using their alarm archives
AMC controller series overview
AMC2-4W-CF AMC-I/O-EXT
AMC and enclosures
Î Enclosures
z for UL approval
The AMC V2 controller
Î Up to 4 reader channels
z supporting iClass, Mifare and compatible readers with
Wiegand interface
z auto-assigned to corresponding ACE door templates
including the in- and outputs
Î Ethernet and serial host interface to ACE server
z supporting DHCP
z password protected access for setup
Î Display with step-through-button for
perfect device status overview
The AMC V2 controller
Î RS485 bus for I/O extension support
Î 2- and 4-state operation on inputs with software selectable
terminators
Î CF-card memory
z default 64MB z up to 1GB
z for up to 200,000 cardholders
Î Internal, offline capable associations of
The AMC I/O extension
Î standard rail-mountable Î 8 and 16 I/O version
Î 2- and 4-state operation on inputs with software selectable
terminators
Î internal and external power supply for in- and outputs
selectable
Î up to 3 connectable to 1 AMC by RS485 Î extends elevator door template to 56 floors Î supports simple intrusion functionality
Î I/Os could be used inside the AMC
The power supply and charging unit
Î integrated charging unit for batteries Î Nominal output power 60 W
Î Nominal output voltage 12 V and 24 V Î Input voltage range 100 VAC to 240 VAC Î Battery support up to 14 Ah
Î Short circuit protection Î Overload protection
Î Regulation of battery charging voltage with
temperature monitoring by external NTC-resistor
Î Signaling for AC-OK, DC-OK, BAT-OK
Supported readers and formats
Î Wiegand interface readers
