wattage weight dimensions input output frequency protection rating 20W 1 lb. 8 oz. L=5.03 in., W=2.14 in., D=2 in. 120V AC 12V DC 60 Hz IP32 / Nema 3R 60W 4 lb. 1 oz. L=6.06 in., W=2.59 in., D=2.2 in. 120V AC 12V DC 60 Hz IP32 / Nema 3R 100W 5 lb. 12 oz. L=9.8 in., W=3 in., D=2.75 in. 120V AC 12V DC 60 Hz IP32 / Nema 3R
12V Dimmable Driver
EL-TMDRVRETL Listed #4001928 CSA Listed
Class 2 (20W & 60W)
Compatible with: 120V AC magnetic low voltage dimmers Minimum load: none
Working Temp.: < 158°F / 70°C
(104°F / 40°C ambient temp.) Knockouts: 2 x 3/4 in.
The 12V Dimmable Driver is perfect for supplying low voltage power to our dim-mable LED lights. Have you been searching everywhere for a way to dim your LED lights by using a household dimmer switch, whether you have one already in-stalled or for a new construction project? Look no further. This 12V DC transform-er can be used to powtransform-er any of our dimmable LED lights, and allows you to install our low voltage LED light fixtures while using a common 120V dimmer switch. Our 12V Dimmable LED Drivers are compatible with many models of dimmer by brands such as Lutron and Leviton, which are commonly used in home and com-mercial installations, and widely available at home improvement stores.
The following Lutron brand 120V dimmers are examples of switches that are com-patible with our Dimmable Drivers: Ariadni, Diva, Glyder, Maestro Wireless, Nova, RadioRA, Skylark, Skylark Contour, Vareo, Vierti. These drivers are also compati-ble with the Control 4 Wireless Dimmer. These switches are examples of standard AC dimmers described as “magnetic low voltage.” This driver is NOT COMPAT-IBLE with our Reign Dimmer Switches, or with our 12V Inline Dimmer Switch. This 12V indoor power supply is ETL and CSA Listed, and has a sturdy powder-coated black steel housing, for protection against the elements. The driver comes with full instructions, safety guidelines, and wiring diagrams.
