There can be only one! Well in this case two. This dual port Gigabit, Power over Ethernet injector, fuses PoE technology (up to 30 watts) and Gigabit data allowance. From one port, provide data & power in a singular run to your PoE compatible devices such as security cameras, VOIP phones, Wireless Access Points, etc. over 400ft away. The other port is a Gigabit uplink port only. Use this un-managed switch to power individual 12v network devices for demonstrations, dedicated power data solutions, bench testing and single device setups. Its unique design allows you to quickly and easily mount the unit securely. Port status lights to view connectivity and we offer a 1 year warranty.

MPIX-POEINJ

POE Devices

Specs

Input Voltage 100-240VAC Output Voltage 48VDC

Network standards IEEE802.3i 10 BASE-T, IEEE802.3i 100 BASE-TX,

IEEE802.3x flow control IEEE802.3af /I E~E802.3at PoE power Max30W

Processing types Store-and forward Data Rate 10/100/1000Mbps Installation and

Management

Plug and play installation

Midspan automatically detect all devices support for PoE Working Temp. 0·c- 40·c

Storage Temp. -10·c-70·c Operating Humidity 20%-85%

LED indicator Link,speed,PoE active, PoE error, Data Port green

Safety CE/FCC/RoHs

Features

(4)

8 Port POE switch, 4 Ports of POE

Our MPIX-POE-4 is an 8 Port POE switch, 4 Ports of POE with (4 Power Over Ethernet ports) that has enough power to power our POE compatible cameras in each of the 4 ports. If you need to power more than 4 POE cameras, you can use additional POE-4 switches.

MPIX-POE4

Specs

Power: PoE power up to 15.4W for each PoE port

Supports PoE power up to 53W for all PoE ports

Standards and Protocols: IEEE802.3, 802.3u, 802.3x,

802.3af, CSMA/CD

TCP/IP Ports: 8x 10/100M Auto-Negotiation RJ45 ports with 4 PoE ports (port-1~port-4), Auto MDI/MDIX

Basic Function: Compatible with IEEE 802.3af compliant

PDs Port Priority Function Wire-speed Performance MAC Address Auto-Learning and Auto-aging IEEE802

100BASE-TX: UTP category 5, 5e cable(maximum

100m) EIA/TIA-568 100? STP (maximum 100m) LED Indicator: Power, Link/Act, 100Mbps, PoE Status,PoE MAX, 3x flow control for Full-Duplex Mode and backpressure for Half-Duplex Mode

Backbound Bandwidth: 1.6Gbps MAC Address Table:

1k Forwarding Rate: 10BASE-T: 14880pps/port 100BASE-TX: 148800pps/port

Safety & Emission: FCC, CE Power: External Power

Adapter

Transmission Method: Store-and-Forward Network

Media: 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100?? STP (maximum 100m)

Features

8 Port POE switch, 4 Ports of POE

(5)

MPIX-POE8

8 Port POE Switch with 1 Gigabit Uplink

Our newly manufactured 8 port PoE with 1 Gigabit uplink port now gives you the freedom to send, receive and power your data devices. Confidently integrate non-powered PoE data devices which will come to no harm due to the smart "Automatic Detect" feature. This compact design switch is suitable for Indoor use to power all and any compliant PoE devices such as but not limited to: Phones, security cameras, access points, etc. Monitor your data activity with convenient LED indicator lights providing you with easy to troubleshoot network issues. Each PoE port provides up to 15.4 watts to power 12v devices up to 328ft away. This un-managed switch makes things simple with its plug and play ability and comes with a 1 year warranty. MPIX-POE8

POE Devices

Specs

Standard IEEE802.3, 802.3u, 802.3af, 802.3x Protocal CSMA/CD TCP/IP

Basic Function Wire-speed Performance MAC Address Auto-Learning and Auto-aging IEEE802.3x flow control for Full-Duplex Mode and backpressure for

Half-Duplex Mode Bandwidth 3.6 Gbps

Power support Max power: 15.4W for each POE port -48V 2A Power adapter

Transmission Store-and-Forward

Ports 8 10/100/Mbps Auto-Negotiation PoE RJ45 ports (Auto MDI/MDIXL

9th is Gigabit Uplink port

Network Media l0Base-T: UTP category 3, 4, 5 cable (maximum l00m)

EIA/TIA-568 l00U STP (maximum l00m)

l00Base-Tx: UTP category 5, 5e cable (maximum l00m} EIA/TIA-568 lOOU STP (maximum l OOm)

l000Base-T: UTP category 5, 5e cable (maximum l00m) LED Indicators Power, Link/Act ( 10/100/l000Mbps) Safety & Emission FCC,CE,RoHS

Humidity Relative Humidity: 5% - 95%

Dimensions 430mm W x 256mm D x 66.4mm H EMI FCC Class B, CE Mark Class B

Safety 110VAC to 240VAC power supply UL listed. Environment Operating Temperature: O C~50 C Storage Temperature: -10° c~70 C

Operating Humidity: 10%~90% non-condensing Storage Humidit y: 5%~90% non-condensing Product Size 225*121 *35 mm

Security Standard UL

Features

(6)

16 Port POE Switch with 2 Gigabit RJ45 Ports

PoE (Power over Ethernet) integrates 48v power and data through individual Ethernet cable feeds, eliminating the need to have power available for all your devices. This unit will support data and power up to 328 feet via Cat5/Cat5e/Cat6 applications. Powers PoE compliant devices such as VOIP phones, Wireless Access Points, Security Cameras, etc. Product is labeled with conveniently marked activity lights for simple identifying and comes with a 1 year warranty. Weighing in at only 13.2 pounds, this device will safely fit for all your shelf, media center and desktop applications. This device is also rack mountable (rack mounting ear brackets included).

MPIX-POE16

Specs:

Standard IEEE 802.3 10 BASE-T Elhemet IEEE 802.3u 100 BASE-TX Fast Elhemet IEEE 802.3ux100 Full Duplex Flow Control IEEE 802.3af Power Over Elhemet

IEEE 802.3ab 1000Base-T Gigabit Elhemet (twisted pair copper)

Protocal CSMA/CD

Data Transfer Rate Ethernet 10Mbps (half Duplex). 20Mbps (Full Duplex)

Fast Ethernet: 100Mbps (half-duplex). 200Mbps (full-duplex)

Gigabit Ethernet: 2000Mbps (full duplex) Electronic Shutter Speed 1/1 - 1/10,000s

Network Cables 10Base-T: 2-pair UTP Cat 3, 4, 5 up to 100 meters.

100Base-T : 2-pair UTP Cat 5, 5e up to 100 meters. 1000Base-T: 4-pair UTP Cat5e 6, up to 1 OOmeters. 50/62.5um LC signal model or Multi model fiber cable. Number of Ports 16 x 10/100Mbps auto-MDIX RJ-45 ports with 16 PoE enabled

ports.

2 x 10/100/1 OOOMbps RJ-45 ports. 2 x 10/100/1000Mbps SFP ports (option)

PoE power on RJ-45 Power +: pin 3 & pin 6 : Power -· pin 1 & pin 2

Power Supply Input 100V- 240VAC, 50Hz- 60Hz. Output 48VDC 7.3A(350W)

Power Consumption 10.0 watts (max with no PD device connected)

Temperature 340 watts (350W Power) Humidity Relative Humidity: 5% - 95%

Safety 110VAC to 240VAC power supply UL listed. RAM buffer 2.75Mb bytes per device

Filtering Address Table 4K entries per device Packet Filtering Foward

Rate

10Mbps Ethernet: 14,880/pps 100Mbps Ethernet: 148,800/pps 1000MBase-T Ethernet: 1,488,000/pps.

Features

(7)

MPIX-POE24

24 Port POE Switch with 2 Gigabit RJ45 Ports

PoE (Power over Ethernet) combines 48v power and data through an individual Ethernet cable feeds, eliminating the need to have power source available amongst your devices. This unit will support data and power up to 328 feet via Cat5/Cat5e/Cat6 applications. Powers PoE compliant devices such as printers, wireless access points, security cameras, NAS (network attached storage) device, etc. With conveniently marked LED activity lights, this product allows you to quickly identify troubled lines and devices.

Presenting the new exquisite PoE-24. This item features 24 10/100 ports with PoE (Power over Ethernet) for your cameras along with two additional dedicated Gigabit RJ45 ports for the NVR and network connections.

MPIX-POE24

POE Devices

Specs

Standard IEEE 802.3 10 BASE-T Elhemet IEEE 802.3u 100 BASE-TX Fast Elhemet IEEE 802.3ux100 Full Duplex Flow Control IEEE 802.3af Power Over Elhemet

IEEE 802.3ab 1000Base-T Gigabit Elhemet (twisted pair copper)

Protocal CSMA/CD

Data Transfer Rate Ethernet 10Mbps (half Duplex). 20Mbps (Full Duplex)

Fast Ethernet: 100Mbps (half-duplex). 200Mbps (full-duplex)

Gigabit Ethernet: 2000Mbps (full duplex) Electronic Shutter Speed 1/1 - 1/10,000s

Network Cables 10Base-T: 2-pair UTP Cat 3, 4, 5 up to 100 meters.

100Base-T : 2-pair UTP Cat 5, 5e up to 100 meters. 1000Base-T: 4-pair UTP Cat5e 6, up to 1 OOmeters. 50/62.5um LC signal model or Multi model fiber cable. Number of Ports 24 x 10/100Mbps auto-MDIX RJ-45 ports with 24 PoE enabled

ports.

2 x 1 0/100/1 OOOMbps RJ-45 ports. 2 x 10/100/1000Mbps SFP ports (option)

PoE power on RJ-45 Power +: pin 3 & pin 6 : Power -· pin 1 & pin 2

Power Supply Input 100V- 240VAC, 50Hz- 60Hz. Output 48VDC 7.3A(350W)

Power Consumption 15.0 watts (max with no PD device connected)

Temperature 335 watts (350W Power) Humidity Relative Humidity: 5% - 95%

Safety 110VAC to 240VAC power supply UL listed. RAM buffer 2.75Mb bytes per device

Filtering Address Table 4K entries per device Packet Filtering Foward

Rate 10Mbps Ethernet: 14,880/pps 100Mbps Ethernet: 148,800/pps

Features

Authentication

•

IP Configuration

•

System Statuses

•

Reboot Device

•

Port Management Properties: Port Configuration

(8)

(9)

MPIX-WIRELESSAP

Indoor/Outdoor Wireless Access Point/Bridge

Our Indoor/Outdoor Wireless Access Point/Bridge will allow you the ultimate flexibility when it comes to IP cameras and DVR wireless transmission. The TP-LocoM5 are very versatile and can be used in several different ways. The most common use is as a wireless IP bridge. You can use 2 of these units to allow you to mount an IP camera or DVR outside in a location that would be either difficult or impossible to wire too. You will connect an ethernet cable from your network to one of these wireless devices, then mount the device outside (these units are weatherproof) facing in the direction of where the IP camera or DVR will be mounted. The second unit will be mounted on the pole, tree, wall or wherever you have the IP camera or DVR mounted. This will allow you to create a wireless bridge between your network and the IP camera or DVR you have mounted outside. One of these units is powerful enough to provide wireless transmission of several IP cameras or DVRs if they are in the same general location and connected to a switch. With up to 150mbps of bandwidth available and up to 15KM of line of sight distance capability, you are sure to be thrilled with the results. Each of these devices can be configured as an access point

MPIX-WIRELESSAP

Wireless Transmission

Specs:

Processor Specs: Atheros MIPS 24KC, 400MHz Memory Information: 32MB SDRAM, 8MB Flash Networking Interface: 1 x 10/100 BASE-TX (Cat. 5,

RJ-45) Ethernet Interface

Wireless Approvals: FCC Part 15.247, IC RS210, CE RoHS Compliance: Yes

Enclosure Size: 6.42in x 1.22in x 3.15in Weight: 0.18kg

Enclosure Characteristics: Outdoor UV Coated Plastic Mounting Kit: Pole Mounting Kit Included

Max Power Consumption: 5.5 Watts

Power Supply: 24V, 0.5A Surge Protection Integrated

POE Adapter Included

Power Method: Passive Power Over Ethernet (pairs 4,5+;

7,8 return)

Operating Temperature: -22°F - 176°F Operating Humidity: 5 - 95% Condensing

Shock & Vibration: ETSI300-019-1.4

Features:

(10)

Wall/Window Mount for Nanostation wireless devices

These Wall/Window Mount for Nanostation wireless devices makes installation easy when you need to get that signal.

MPIX-WIRELESSWMNANO

Information

For use with our Indoor/Outdoor Wireless Access Point/Bridge for IP cameras & DVRs, 150+MBPs, 15 KM Line of Sight Range
