TruStore:
The storage
system that grows
with you
Machine Tools / Power Tools
Everything
from a
single source.
Everything from a single source: there are no inter-face problems because everything works together. Quick access to material increases the machine’s production run-time.
More efficient workflow, such as automated material flow, reduces time and costs.
The compact storage system saves up to 85 % in storage space and guarantees the best possible use of space.
TruStore grows along with your storage needs. The storage system can be flexibly upgraded.
Contents
Everything from a single source. 2
TruStore optimizes production. 3
Your personalized storage system. 4
TruStore for every situation. 5
TruStore Series 1000
Uncomplicated storage for your
2D laser machine. 6
TruStore Series 3000
The compact storage system
for dynamic future plans. 7
Automation:
Components for the best connection. 8
Software:
Programmed for success. 10
TruServices:
Service like no other. 11
TruStore from TRUMPF is the first storage system that is per-fectly tailored for TRUMPF punching, combination and laser cutting machines. Now you can get the machine, automation, storage and services from a single source – all with high TRUMPF quality. There are no interface problems because
everything works together.
TruStore is based on a system of modules that can be up-graded and expanded at any time. The entry-level model is the TruStore Series 1000. The next step up, the TruStore Series 3000, allows you to select a compact storage system for tight spaces with one or two storage towers in different extension levels.
How TruStore supports your production
1
2
3
4
5
TruStore
optimizes
production.
The TruStore storage system structures workflow, saving time and money. Without a storage system, stacks of material pal-lets are often scattered around the production facility. This means that production space is wasted, forklift truck drivers have to go around or waste time looking for their materials. TruStore optimizes material flow, making work easier. Capacity grows while the need for space greatly diminishes. In addition, the integrated storage management system facilitates general inventory control.
65 x 3,000 mm x 1,500 mm = 292.5 m² 5,000 mm x 8,200 mm = 41.0 m²
Practical example for space and cost savings:
Our practical example shows: The TruStore storage system reduces required space – compared to floor storage – by up to 85 %, which, in this example, is the equivalent of a savings of € 30,180 per year.
Floor storage of 65 pallets: Storage in TruStore ¹: Savings:
Space 292.5 m² 41.0 m² 251.5 m²
Costs 35,100.00 € / p.a. ² 4,920.00 € / p.a. ² 30,180.00 € / p.a. ²
¹ With 2 storage towers, each with 2 extension modules, 90 mm load height and 65 storage spaces. ² Monthly space costs: 10.00 € / m².
Your
personalized
storage system.
TruStore consists of a basic module and extension modules. You can select and customize your storage space from these components.
The TruStore Series 1000 contains one basic module. Your storage system is operated by a LiftMaster Store or LiftMaster Store Linear. You can automatically upgrade your TruStore Series 1000 to a TruStore Series 3000 by adding a shelf servic-ing device.
The TruStore Series 3000 has its own shelf servicing device. As a space-saving alternative, you can use a TruStore with one storage tower. For larger storage requirements, the two-tower model is ideal. Select the height of your storage system from three possible options. Storage compartments are adjustable to 90 mm or 170 mm.
TruStore is the perfect solution for your storage needs. So take advantage of your options.
Stay flexible with TruStore
Let’s say you have decided on a small model of our TruStore storage system and later want to expand your capacity. This is the advantage of the TruStore: You don’t have to invest in a brand new and expensive storage system. Instead, you can extend your TruStore by adding additional modules. We will quickly and efficiently install the module directly on-site. The main advantage: You can get started with the storage system that is the most profitable for you. At the same time, you are perfectly prepared for growth.
TruStore 3030 basic module
TruStore 3030 with one extension module
TruStore 3030 with two extension modules
TruStore 3030 with two towers, each with two extension modules
TruStore
for every
situation.
The TruStore storage system can ex-pand your automated sheet production smoothly and makes it even more effi-cient. You can connect your TruLaser, TruMatic or TruPunch machine to a TruStore storage system very easily with automation.
We have put together a few examples for you: TruLaser TruStore 1030 LiftMaster Store TruLaser TruStore 3030 LiftMaster Compact TruStore 3030 TruMatic SortMaster Pallet Storage cart SheetMaster
TruStore
Series 1000
Uncomplicated storage for your 2D laser machine.
n An economical introduction to TRUMPF storage
technology.
n LiftMaster Store or LiftMaster Store Linear operate
as a shelf servicing device.
n Easy to set up and quickly installed. n Minimal space requirements.
n Can be upgraded to a TruStore Series 3000
by adding a shelf servicing device.
TruStore 1030 TruStore 1040
Max. sheet size 3,000 x 1,500 mm 4,000 x 2,000 mm
Loading heights 90 / 170 mm 90 / 170 mm
Max. load per pallet 3,000 kg 5,000 kg
System height ¹ 5,000 mm 5,100 mm
Max. pallets per stack 10 7
TruStore
Series 3000
The compact storage system for dynamic
future plans.
n Larger storage capacity allows the machine to
operate for several shifts with minimal manpower.
n More reliable material flow with the integrated
shelf servicing device.
n Can be upgraded on a modular basis depending
on need.
n Height of storage compartments can be adjusted
by simply screwing/unscrewing.
n Easy to set up and quick to install. n Minimal space requirements.
You can find out more about TruStore at www.trumpf-machines.com/TruStore
TruStore 3030
Max. sheet size 3,000 x 1,500 mm
Loading heights 90 / 170 mm
Max. load per pallet 3,000 kg
Max. system height 8,200 mm
Max. pallets per stack 35
Shelf servicing device:
Speed 12 m/min Acceleration 0.5 m/s² Pallet retrieval: Speed 30 m/min Acceleration 0.5 m/s² Cycle time 0.5 s ¹
Automation:
Components
for the best
connection.
LoadMaster
The LoadMaster is the first step toward automation in laser machines. Using suction cups, it reliably loads the machine’s pallet changer with blank sheets. It is connected to the TruStore by storage carts.
LiftMaster Store
Compared to the LiftMaster, the LiftMaster Store shortens cycle time by up to 40 % in the thin sheet range. Its vacuum frame moves vertically across the pallet changer. It transports sheets from the storage system directly to the laser machine and returns with cut sheets. For a TruStore Series 1000, the LiftMaster Store functions as the shelf servicing device.
LiftMaster Store Linear
The LiftMaster Store Linear is the ideal solution for completely automated production processes. It has the advantages of both the LiftMaster Store and LiftMaster Linear. This means it directly accesses the storage compartments and transports sheets to the machine and back again. Its biggest advantage: it connects up to three TruLaser machines to one TruStore.
SheetMaster
The SheetMaster loads the punching or combination machine with blank sheets and, parallel to production, unloads finished workpieces using vacuum suction cups mounted on a frame. Its configuration corresponds to typical sheet shapes and sizes, but it can be adapted to custom-shaped parts, too. Storage carts retrieve the blank sheets from the TruStore and return with finished parts.
LiftMaster
The LiftMaster loads and unloads your laser machine using up to three variable pivot positions. It uses a vacuum frame for loading and a rake for unloading. The vacuum frame trans-ports sheets from the raw material cart to the pallet changer. The unloading rake moves the workpieces and the sheet skel-eton from the pallet changer to the finished parts cart, to the storage system or to an additional third location.
LiftMaster Compact
The LiftMaster Compact together with the TruStore Series 3000 forms a compact unit. The machine is directly loaded and unloaded with storage pallets. Vacuum and rake frames are used for this purpose. The advantages of the combination of TruStore and LiftMaster Compact include extremely short cycle times and a minimal setup area.
LiftMaster Linear
The LiftMaster Linear loads and unloads up to three laser machines very efficiently because it can also move laterally to the machine. This means you can connect numerous carts, storage carts and pallets. Storage carts ensure a direct con-nection to the TruStore. Using the TruTops FMC, you can easily control the interaction between your machines.
LoadMaster LiftMaster LiftMasterCompact LiftMasterLinear LiftMasterStore LiftMaster Store Linear SheetMaster Functions Individualize sheets n n n n n n Loading n
Loading and unloading n n n n n n
Assisted pallet operation n n n n
Possible machines TruLaser 2525 n TruLaser 3030 n n n n n n TruLaser 3030 NEW n n n n n n TruLaser 3040 n n n n n TruLaser 3060 n TruLaser 3530 n n n n n n TruLaser 5030 n n n n n n TruLaser 5040 NEW n n n n n TruLaser 5060 NEW n TruLaser 7025 n n n TruLaser 7040 n n n n n TruLaser 7040 NEW n n n n n TruPunch 3000 n TruPunch 5000 n TruMatic 3000 n TruMatic 6000 n TruMatic 7000 n
Software:
Programmed
for success.
To get the best out of your TruStore storage system, put your trust in our Cell-Server software that controls the entire materi-al flow, manages your storage system and ensures the best connection to your machine. The software also manages inven-tory and makes it possible for you to control operating com-mands and material requirements directly from the machine. A file interface can be used to easily circulate inventory data.
An overview of the benefits of
Cell-Server software:
n Your machine independently controls the
material flow.
n You can manually intervene in the production
sequence at any time.
n You can always keep an eye on your inventory. n You can easily integrate the software in your
TruServices:
Service
like no
other.
Throughout the lifecycle of your machine.
Regardless of the TRUMPF technology you use, you will always get the best service. And, thanks to TRUMPF’s award-winning spare parts logistics, all parts can be shipped to you in the shortest time possible. TRUMPF Leasing offers you indi-vidual financing solutions quickly and without a lot of paper-work. Our service technicians are highly trained and always available when you need them. A Service Agreement is the ideal way of ensuring the best usability of your machine.
Should your requirements change, we have flexible upgrading options and technical innovations that will make your machine even better. Our broad range of training courses with experi-enced trainers and hands-on practice will also give you a head start in understanding and operating your machine.
You can find out more about our services at www.trumpf-machines.com/Services
The TRUMPF Group ranks among the world’s leading manufacturers of production technology and industrial lasers. Technical and efficient solutions for our customers have been our focus since 1923. As a leading technology supplier, TRUMPF is a one-stop shop for all of your technology needs: machines, automation, storage technology and services.
