Lightweight Tile. Collection

(1)

Lightweight Tile

Collection

(2)

1

Tile. For the way it looks.

And the way it lasts.

Few roof products are as beautiful or enduring as MonierLifetile

concrete roof tiles. With so many styles and colors to choose from, you’ll

find that adding a tile roof to your home is one of the easiest and most effective ways to

complement its look and increase its value.

Tile is timeless

Only tile enables you to achieve authentic, old-world aesthetics with the benefits of

durable, modern materials. MonierLifetile has captured all the characteristics of

natural slate, clay and wood – which are

historically the world’s most widespread

roofing materials – in a concrete tile.

The result is a tile roof of unmatched beauty

and a home with incredible curb appeal.

MonierLifetile is continually acknowledged by the industry

for our product innovations. And three of our most popular products -

MonierLifetile Madera, Cedarlite and Boosted Barcelona - replicate authentic

materials, while reducing installation costs and increasing longevity and energy efficiency.

(3)

2 Code Approval: Complies with all building codes including but not limited to ICC ESR-1647. Some approvals are regional and only apply

to locally produced products; please contact MLT before transporting product across state lines. Specifically, products used in the Miami Dade County region of Florida require special testing and recognition.

Disclaimer: The printed colors shown in this brochure may vary from actual available tile colors. Before making a final selection, be sure to review actual tile samples and roof installations. Please contact your local sales office for further assistance. Categories, typographical errors subject to change without notice. No performance guarantee is offered or implied beyond that expressly indicated.

Efflorescence is a temporary surface condition which is common to all concrete products. The process is caused by the chemical nature of cement. This reaction can appear as an overall chalky white bloom (a softening of color) or in more concentrated patches. It is difficult to predict how long the effects of efflorescence will last. It depends on the type and amount of deposit as well as local weather conditions. The action of carbon dioxide and rainwater will gradually remove the deposit, in most cases, leaving the original color of the roof intact without further efflorescence occurring. It is superficial and in no way affects the quality or functional properties of the tile. Installation: Please consult the Tile Roofing Institute (TRI) Installation guides for application recommendations.

Technical specifications do not constitute a warranty by MonierLifetile. The only applicable warranty with respect to this product is the Limited Lifetime, Fully Transferable, Non-Prorated Product Warranty for tile contained in MonierLifetile’s product literature, dated most recently prior to the installation of this product on the owner’s roof. For more warranty information, please call (888) 926-2585.

Being Green - Our Tradition and Promise

3

Fire Resistant Roof System

3

Profile Overview - Lightweight Tile

4

Cedarlite

®

600

5

MonierLifetile Madera 700

™

6

Saxony Split Shake 600

™

& 700

™

9

Saxony Slate 600

™

& 700

™

10

Saxony Shake 600

™

& 700

™

11

España 600

13

Villa 600

15

Technical Specifications

17

Finishing Touches

18

Roof System Components

19

Energy Efficient Roof System

21

(4)

3

Being Green

Our Tradition and Promise

Protect Your Home And Family With MonierLifetile's

Fire Resistant Roof System

It’s long been known that concrete roof tile is the

best choice available for a fire resistant roofing

material. MonierLifetile’s concrete roof tile systems

undergo the most stringent testing for fire safety

and pass with a Class A fire rating, the best rating

available. Topping your home with a MonierLifetile

roof is a smart decision indeed, but there are other

fire resistant roof system components that can

protect your home from wind blown flames and embers

that can enter through a home's vulnerable vents.

MonierLifetile is pleased to offer Brandguard Vents, the leading flame and ember

resistant vents. They protect homes and buildings from the threat of wildfire and

nearby structural fires. The overlapping baffles in the vents act as a barrier to prevent

the intrusion of flames and embers, through a structure’s vulnerable vent openings.

The patent pending design has comparable net free vent area (NFVA) to conventional

vents and allows for sufficient exchange of air to prevent mold issues and save

energy. Brandguard Vents were the first commercially available vents designed to

meet the new Chapter 7A requirements of the California Building Code. This new

code requires builders and roofers to use vents that resist the intrusion of flames

and embers when building in fire-prone areas. All Brandguard vents are made with

26 gauge G-90 galvanized steel for durability, are readily paintable, and carry a 20-year

manufacturer’s warranty.

A Single Roof Can Impact Our World

MonierLifetile is the roofing product that has been green for decades in the U.S. and for a generation through our European

lineage. As a leader in the Green Building movement, MonierLifetile is committed to using naturally available materials

which mitigates the negative impact to the environment and emphasizes conservation and energy efficiency.

Concrete roof tile is inherently sustainable. The durable lifecycle of MonierLifetile products – from beginning to end – meets

the needs of the present without compromising those of the future. MonierLifetile is committed to reducing the total

amount of greenhouse gases produced – from the environmentally conscious manufacture of the product; to the plant to

market transport radius; to the ultimate re-use and recyclability – thereby minimizing our carbon footprint.

Concrete roof tile is known for its longevity and small footprint on the planet. Being a Green leader, MonierLifetile

is committed to providing the most energy efficient and environmentally friendly tile roof system in the U.S.

Class A Fire Rating Test

Brandguard Vents is a complete line of flame and ember resistant vents that also block wind-driven rain and snow

Results: Undamaged concrete tile following Class A Fire Rating Test

(5)

Cedarlite 600 and MonierLifetile Madera 700 are the most

affordable, authentic replication of a hand-split cedar shake roof

available. With its realistic wood shake surface, MonierLifetile

Madera will complement any architectural style.

España 600 reflects the classic style and distinctiveness of

Spanish architecture, popular in the early California missions that

stretched from San Diego de Alcalá to San Francisco Solamo.

Villa 600 emulates the most popular tile in the world; faithfully

recreating the beautiful Mediterranean style popular in Italy

and Southern France.

4

When you’re considering a new roof, take a good look at MonierLifetile. You’ll find our roof tile enhances

your home or building’s appearance like no other roofing material.

MonierLifetile is the first manufacturer to create a lightweight tile. Our 600 Series tiles weigh less than 6

pounds per square foot, and are truly lightweight. They are designed from the outset to be sub-600, while

still passing our stringent requirements for strength and weather resistance.

So discover the lasting beauty of MonierLifetile’s Lightweight Collection. It could quite possibly be the last

roof you’ll ever need.

España 600

This beautiful range of designs is representative of the roof styles

found in England, northern Europe and the Eastern Seaboard

states and is versatile enough to accentuate any architectural style.

Saxony 600

™

& 700

™

Split Shake

Slate

Shake

Villa 600

Cedarlite 600 &

MLT Madera 700

™

Profile Overview

Lightweight Tile

(6)

5

Known as “The Ultimate Shake Replacement

®

,” Cedarlite

®

600 and MonierLifetile

®

Madera 700 represent

a quantum leap in concrete roof tile. Modeled after the highest quality hand-split cedar shakes, Cedarlite

600 and MonierLifetile Madera 700 were developed with a unique manufacturing process that gives such

a realistic appearance, most would be hard-pressed to tell the difference between it and real wood shake.

Cedarlite 600 and MonierLifetile Madera 700 feature all of the variations and detail you would find in real

cedar shake, while adding the benefits inherent in concrete roof tile. They are Class A fire-rated and come

with our exclusive Limited Lifetime, Fully Transferable, Non-Prorated Warranty.

Cedarlite 600 Ironwood

Ironwood 2CLCL5773

90˚ Rake 19CCL5773

V-Ridge 1VCCL5773

Tapered Eave Starter 1CECL5773

Silverwood 2CLCL5780

90˚ Rake 19CCL5780

V-Ridge 1VCCL5780

Heartwood 2CLCL3783

90˚ Rake 19CCL3783

V-Ridge 1VCCL3783

Take Your Home Improvement to New Heights

(7)

6

Sagewood 3MDCL4002

90˚ Rake 19CCL4002

V-Ridge 1VCCL4002

Autumnwood 3MDCL3002

90˚ Rake 19CCL3002

V-Ridge 1VCCL3002

Vintagewood 3MDCL5011

90˚ Rake 19CCL5011

V-Ridge 1VCCL5011

Heartwood 3MDCL3783

90˚ Rake 19CCL3783

V-Ridge 1VCCL3783

Mountainwood 3MDCL5001

90˚ Rake 19CCL5001

V-Ridge 1VCCL5001

MonierLifetile Madera 700 Mountainwood

(8)

7

Cedarlite 600 Silverwood

(9)

8

(10)

9

Saxony 600 - Camouflage 2FDCV3963

Saxony 700 - Camouflage 3FDCV3963

90˚ Rake 1R9CB3963

3-Sided Ridge 1R3CB3963

3-Sided Hip Starter 1FHCB3963

Apex 3-Way 13ACB3963

Saxony 600 Split Shake Camouflage

Split-face tiles look best when installed with a random offset between courses. Half-bond layout may result in uniform patterns that do not achieve the wood shake appearance of this product.

Saxony 600 - Smokey 2FDCV3958

Saxony 700 - Smokey 3FDCV3958

90˚ Rake 1R9CB3958

Saxony 600 - Wolf Grey 2FDCV5969

Saxony 700 - Wolf Grey 3FDCV5969

90˚ Rake 1R9CB5969

600/700

This classic variation of both

shake and slate tile adds

distinctiveness to any style.

(11)

10

Slate 600/700

Saxony 600 - Lincoln Green 2FACS4087

Saxony 700 - Lincoln Green 3FACS4087

90˚ Rake 1R9CS4087

3-Sided Ridge 1R3CS4087

3-Sided Hip Starter 1FHCS4087

Apex 3-Way 13ACS4087

Saxony 600 - Hillside 2FACS3935

Saxony 700 - Hillside 3FACS3935

90˚ Rake 1R9CS3935

Saxony 600 - Cobblestone 2FACS3957

Saxony 700 - Cobblestone 3FACS3957

90˚ Rake 1R9CS3957

Saxony 600 - Stone Mountain Blend 2FACS5354 Saxony 700 - Stone Mountain Blend 3FACS5354

90˚ Rake 1R9CS5354

Achieve the natural appearance of authentic

slate - ideal for a variety of traditional styles.

(12)

11

Saxony 600 - Silver Smoke 2FBCF5932

Saxony 700 - Silver Smoke 3FBCF5932

90˚ Rake 1R9CF5932

3-Sided Ridge 1R3CF5932

3-Sided Hip Starter 1FHCF5932

Apex 3-Way 13ACF5932

Shake 600/700

Saxony 600 Shake Charcoal

Saxony 600 - Saddle 2FBCF3934

Saxony 700 - Saddle 3FBCF3934

90˚ Rake 1R9CF3934

The printed colors shown in this brochure may vary from actual available tile colors.

Saxony 600 - Charcoal 2FBCF1130

Saxony 700 - Charcoal 3FBCF1130

90˚ Rake 1R9CF1130

(13)

12

Saxony 600 - Walnut 2FBCF3453

Saxony 700 - Walnut 3FBCF3453

90˚ Rake 1R9CF3453

Saxony 600 - Smokey 2FBCF3958

Saxony 700 - Smokey 3FBCF3958

90˚ Rake 1R9CF3958

Saxony 600 Shake Walnut

Capture the rustic warmth and beauty of

hand-hewn shakes with our shake tiles.

(14)

13

España 600 Casa Grande Blend with standard weight Boosted Barcelona Caps (as used on Extreme Home Makeover)

California Mission Blend 2ESCS6464

Capri Trim 1CTCS6464L

Capri Hip Starter 1CHCS6464 Capri Apex 3-Way 1C3CS6464

Casa Grande Blend 2ESCS6169

New Clay 2ESCS6931

Capri Trim 1CTCS6931

Terra Cotta Flashed 2ESCS6300

Capri Hip Starter 1CHCS6300

Capri Apex 3-Way 1C3CS6300

España 600

Achieve the classic style and distinctivness of

Spanish architecture with our España tile.

Reflectance: .23 Emittance: .91 SRI: 24 Reflectance: .19 Emittance: .91 SRI: 18 Reflectance: .25 Emittance: .93 SRI: 27

(15)

9

España 600 California Mission Blend

(16)

15

Known as “The Ultimate Shake Replacement,” Cedarlite®_{and Monierlifetile Madera 700 represent a quantum leap in concrete roof}

tile. Modeled after the highest quality hand-split cedar shakes, Cedarlite and Monierlifetile Madera 700 were developed with a unique manufacturing process that gives such a realistic appearance, most would be hard-pressed to tell the difference between it and real wood shake. Cedarlite and Monierlifetile Madera 700 feature all of the variations and detail you would find in real cedar shake, while adding the benefits inherent in concrete roof tile. They are ideal for reroof applications, fireproof and comes with our exclusive Limited Lifetime, Fully Transferable,

Non-Prorated Warranty.

The Ultimate Shake Replacement

™

Villa 600 Terra Cotta Flashed

Pacific Red Blend Slurry Finish C/T 2VIBS7161

Capri Trim 1CTBS7161

Capri Hip Starter 1CHBS7161 Capri Apex 3-Way 1C3BS7161

Terra Cotta Gold 2VICS6440

Capri Hip Starter 1CHCS6440 Capri Apex 3-Way 1C3CS6440 Sedona Gold Slurry Finish 2VISS6566

Capri Trim 1CTSS6566

Capri Hip Starter 1CHSS6566 Capri Apex 3-Way 1C3SS6566 Casa Grande Blend 2VICS6169

Villa 600

Reflectance: .23 Emittance: .91 SRI: 24 Reflectance: .44 Emittance: .92 SRI: 51 Reflectance: .33 Emittance: .92 SRI: 37 Reflectance: .23 Emittance: .91 SRI: 23

(17)

16

Villa 600 Granite Grey

Terra Cotta Flashed 2VICS6300

Granite Grey 2VICS5309

Capri Hip Starter 1CHCS5309

Capri Apex 3-Way 1C3CS5309

Reflectance: .19 Emitance: .91

SRI: 18

Creating a Mediterranean look, our Villa tile

emulates the most popular tile in the world.

(18)

17

Cedarlite

®

600

MLT Madera 700

™

Size and Coverage

Weight in Place

Individual tile nominally 13-1/2”x 13”.

At 3-1/2" minimum headlap, approx. 120 field tiles will cover 100 square feet of roof area.

Installed weight per square approx.: Cedarlite 600 - 590 lbs.

MLT Madera 700 - 720 lbs.

Saxony 600

™

& 700

™

Size and Coverage

Weight in Place

Individual tile nominally 17”x 13”.

At 3”minimum headlap, approx. 85 field tiles will cover 100 square feet of roof area.

Installed weight per square approx.: Saxony 600 - 570 lbs.

Saxony 700 - 720 lbs.

España 600

Size and Coverage

Weight in Place

Individual tile nominally 17”x 12-3/8”. At 3” minimum headlap, approx. 89 field tiles will cover 100 square feet of roof area.

Installed weight per square approx.: 590 lbs.

Villa 600

Size and Coverage

Weight in Place

At 3” minimum headlap, approx. 87 field tiles will cover 100 square feet of roof area.

Installed weight per square approx.: 580 lbs. Split Shake

Shake Slate

(19)

18

Cedarlite

®

600

MLT Madera 700

™

90° Rake V-Ridge Tapered Eave Starter

Saxony 600

™

& 700

™

90° Rake 3-Sided Ridge 3-Sided Hip Starter Apex 3-Way Apex 4-Way

España 600

Capri Trim Capri Hip Starter Capri Apex 3-Way

Villa 600

Capri Trim Capri Hip Starter Capri Apex 3-Way

MonierLifetile provides all of the products for a durable and beautiful roof installation. Our precision production

techniques ensure that our trim tile provides a consistent look and beautiful finishing touch to your project.

Utilizing MonierLifetile’s trim products is also the most efficient way to complete your roof since it reduces the

labor time and expense of mixing colored mortar on site to finish the roof. In addition to rake and ridge pieces,

MonierLifetile manufactures hip starters and apex tiles that ease installation. All of MonierLifetile’s trim products

are protected by our Limited Lifetime, Fully Transferable, Non-Prorated Product Warranty.

Shake Split Shake Slate

(20)

19

Valleys

While standard roofing nails are typically used according to local code requirements, MonierLifetile recommends premium fasteners that offer added performance and security.

QuikDrive

®_Screws

Fasteners

Hips and ridge weather blocking helps prevent wind-driven rain, snow and other debris from entering the peaks and corners of a roof, and increases ventilation.

Figaroll Zephyr Roll ® Zephyr Block MLT RidgeVent

Vents

Hip & Ridge

Channeling water properly helps prevent it from collecting on the deck – which can damage the underlayment and cause the roof deck and underlying structure to rot.

Ribbed Valley Metal

At MonierLifetile we view a roof as not a mere tile covering but a dynamic, performing system that protects, breathes

and ages with the structure. By studying roof performance characteristics and failure points, we have created Roof System

Components – a collection of components that, when installed properly and used comprehensively, result in a tile roof

that lasts longer and increases energy savings.

Ensures all areas of a roof are protected and utilized for optimum performance

Improves weatherproofing and “breatheability” of a tile roof

Helps prevent water damage

Increases airflow and ventilation

Provides aesthetically pleasing design elements

When used together, selected products form MLT's Energy Efficient Roof System

further reinforcing our belief that we must strive to perfect not only a roof’s

aesthetic form, but also its primary function. Only then can we provide

our customers with a roofing solution unmatched by any other

roofing company.

It is estimated 75% of homes have deficient attic ventilation, which increases energy costs and diminishes the lifespan of roofing underlayments. These products ensure proper ventilation and help reduce energy costs.

Brandguard Flame and

Ember Resistant Vents Zephyr Vent

®

Roof System Components -

(21)

20

Our Elevated Battens are a crucial aspect of MonierLifetile’s Energy Efficient Roof System, and improve the performance of any tile installation. They provide positive anchoring for each tile, raising each tile off the roof deck to provide ventilation and the unrestricted flow of any moisture on the underlayment.

Elevated Batten System™ (EBS)

- Fire Retardant EBS Batten Extenders

Proper flashings prevent water, snow and debris from entering joints where the walls meet the roof deck. The use of flashing creates the proper barrier in this situation.

Wakaflex

®

Ribbed Tile Pan

Flashing

Battens

ENERGY EFFICIENT

Selected products part of the MonierLifetile®

Energy Efficient Roof System

While tile is ultimately the first line of defense against the elements, underlayments provide a secondary level of protection directly on top of the roof deck from deterioration, moisture and leaks.

MLT TileSeal

®

RoofTopGuard II

Underlayment

MonierLifetile’s alternative to rake tiles provide aesthetic options and protection against weather, animal infestation and debris accumulation.

Gable End Rubber Wedges

Metal Rake Trim

Rake & Gable End

Proper eave treatment creates a finished look for the roof and enhances its overall functionality. By elevating the first course of tile to the proper height, it completes the overall aesthetic of the roof, and protection against infestation.

Vented Eave Riser

Eave Closure

Anti-ponding Taper Strip

(22)

21

• Raises tile off deck, creating air space • Provides effective thermal barrier • Air flow prevents heat build-up

Ele vated Batten System

™

2

• Additional air space ventilation at the eaves • Allows cooler air to enter the sub-tile area • Patented decorative aesthetics

Vented Eave Riser

3

• Lighter colors reduce heat absorption • High-profile tile increases air space between

the deck and tile; and generates the largest reductions

• Also functions with medium and low-profile tile

Light-Color, High-Profile Tile

1

* Up to 50% reduction Steep-slope Assembly Testing of Clay and Concrete Tile with and without Cool Pigmented Colors, Oak Ridge National Laboratory, 2005. Results vary based on profile of tile installed.

** Up to 22% reduction Steep-slope Assembly Testing of Clay and Concrete Tile with and without Cool Pigmented Colors, Oak Ridge National Laboratory, 2005. Results vary based on profile of tile installed.

Delivers a structurally superior tile roof while reducing energy costs for homeowners.

• Allows hot air to exhaust at the ridge • Provides ventilation and weather-blocking

Zephyr Roll

®

or Figaroll

4

The numbers tell the story

50%

Reduction in the amount of heat

penetrating the conditioned space

versus direct-to-deck installations

*

22%

Reduction in energy consumption

**

A Long-Term Solution

• Breathable assembly allows roof to ventilate and dry out

• Dry components last longer

• Entire roof lasts longer

Energy Efficient Roof System

ENERGY EFFICIENT

MonierLifetile

®

As the sun slowly heats the tiles during the day, the air beneath the tiles in the sub-tile space is slowly heated. Rising heated air escapes through a vented ridge weather block, such as Figaroll, Zephyr Roll®_{or MLT RidgeVent.}

Elevated battens create a continuous pathway for the heated air to rise and flow up to the ridge while drawing in cool, fresh air through the Vented Eave Risers.

“ ...venting offers a significant 50% reduction in

the heat penetrating the conditioned space as

compared to an asphalt shingle roof in direct

contact with the roof deck.”

William A. Miller, Ph.D.

(23)

2222

(24)

MonierLifetile Madera 700 Heartwood

Member of A joint venture of

SALES OFFICES NATIONWIDE:

Phoenix, ARIZONA Gilroy, CALIFORNIA Lathrop, CALIFORNIA Stockton, CALIFORNIA Rialto, CALIFORNIA Denver, COLORADO Pompano Beach, FLORIDA Lake Wales, FLORIDA Atlanta, GEORGIA Kapolei, HAWAII Kansas City, MISSOURI Henderson, NEVADA Katy, TEXAS Tacoma, WASHINGTON CORPORATE OFFICE: MonierLifetile P.O. Box 19792 Irvine, CA 92623-9792 (949) 756-1605 A NATIONAL PRESENCE

MonierLifetile LLC, with headquarters in Irvine, CA, is backed by the strength and financial resources of Monier, based in Europe, and Boral Ltd., based in Australia. MonierLifetile has 13 manufacturing plants and service offices throughout the United States and a plant in Guadalajara, Mexico.

For more information, please call or visit our website at:

Lightweight Tile. Collection
