AXF – Archive eXchange Format:

Interchange & Interoperability

for Operational Storage and Long-Term Preservation

Report to SMPTE Washington DC Section

Bits By the Bay Conference

21 May, 2014

S. Merrill Weiss / Merrill Weiss Group LLC

Chairman, TC-31FS30 AXF Working Group

• History

– Proprietary Systems • Formats on Media • Interface Protocols

• Same System Type Required for Recovery • Media Migration Not Easy

– Danger of Orphaned Archives — If System Support Ended – High Costs of Implementation & Operation

• Individualized System Integration Requirements

• Transfer Costs Resulting from Inability to Interchange Media

• User Requirements

– Movement of Material Between Different Archive Systems • Between Different Operations of Same Company

• Between Companies

• Retrieving Files & Metadata from Media Into Different Systems – Flexibility in Changing Archive Management Vendors

• No Loss of Data or Metadata When Changing Vendors • No Requirement for Native Use of Format

• User Requirements – cont’d.

– Archive Investment Protection

• Ability to Retrieve Files & Metadata In Absence of Creating System • Ability to Read Media Into Other Archive Systems

• Ability to Retrieve Media Contents w/Simple Utility on Many OSs – Automation Metadata Support

• Inclusion of Metadata for Systems Interacting w/Archive Systems – E.g., Traffic, Automation, Color Correction, Editing Systems • Allow Importing “Discovered” Items into Databases

• Additional Requirements

– Providing Unlimited Storage Capability

• File Size, Number of Files, Number of Media, etc.

– Providing an Implementation Strategy

– Providing Support for All Types of Media – Current & Future – Providing for Storage on More Than One Medium – “Spanning” – Providing for Updates/Changes to Archive Objects over Time – Providing for Information Recovery from Damaged Media

– Providing for File Exchange via Communications Channels • Enables Use of Cloud Storage

• Underlying Assumption

–

• Source of Medium & Recipient of Medium • Drives, Drivers, & Control Software

• Large Existing Installed Base & Large Archive Inventory

• Initially, Explicit Export & Import

– Export of Archive Objects to Media Specifically for Interchange

– Importing of Archive Objects into Receiving Systems • By Translating to Native Formats of Receiving Systems • By Inclusion of Interchanged Objects in Databases

• Later, Adoption of Format as Native in Archive Systems

– Eliminating Need for Separate Export/Import Steps – Permitting Direct Transfer of Media Between Systems

• Data Recovery Utilities Available Through SMPTE

– To Be Contributed by WG Participants – For Wide Variety of Operating Systems – For All Media Types

– Permitting Data Recovery without an Archive System – To Help Ensure Access to Archived Files & Associated

Metadata

• SMPTE ST 2034 Part 1 Written & In Ballot

– Result of Years of Work & Refinement

– Uses XML Schema to Define Most Structures – Expected to Be Completed This Year

• Part 2 Will Be Standard on Use of AXF Schema Upstream

– Providing Mechanism for Communicating Metadata to Archive Systems

– Most Major Functions Defined – Writing of Document Begun

• Steps Required to Ensure Long-Term Accessibility

– Valuable File-Based Assets Stored in Digital Archives in All Industries

• Key Goals of the “Ideal Storage Format”

–

– Self-Describing Assets & Self-Describing Storage Media

– Encapsulation to Maintain Important Metadata & File Relationships – Scalability for Any Number of Elements of Any Size & Type

– Standardized Regardless of Storage Media Technology – Transportability & Compatibility between Systems

– Preservation (OAIS) Features such as Fixity, Provenance, etc.

• TAR

– Tape ARchive Format (Originally from UNIX) • Has Been Around for Many Decades

– No Truly Universal TAR “Standard”

• Rather, Many “Customized” Implementations – TAR Is a Legacy Format

• Cannot Support Many Core Functionalities Required in M&E Space

– TAR Misses Many of Storage Format Goals Outlined

• LTFS

– Linear Tape File System is Simple File System for Linear Data Tape

– Makes Data Tapes Appear as “Removable Storage”

– Currently No Standards Bodies Have Documented LTFS • Often Mistakenly Referred to as a “Standard”

• Being Documented by Storage Networking Industries Association – Considered By Itself, Has Some Significant Limitations

• With Respect to Storage Format Goals Outlined

– By Itself, Is Very Useful for Physical “Transport” of Content • But Not for Long Term Storage or Preservation

– Why Not?

• LTFS cont’d.

– No Media Encapsulation

• Relies on Simple Folder Hierarchies to Form Important Asset Relationships

• Lacks Context

– Does Not Scale Well

• Due to Lack of Support for Spanning Across Storage Media

– A Significant Problem in M&E

– Only Supports Modern Data Tape Technologies

• Is Not Applicable to Any Other Storage Technologies

• TAR & LTFS

– Neither Achieves 100% of Long-Term Storage & Preservation Goals

• What other choices are there?

•

Caution: Following Detailed Descriptions Are Not

Adopted Yet

– Some Details Still May Change in Response to Ballot Inputs

• AXF – A File Collection “Wrapper”

– Essentially an Advanced ZIP

– Can Encapsulate Any Number of Files of Any Type & Size

• Brings Universal Transport & Interoperability to

Storage

– At Same Level as MXF Brings to Content

• Designed to Support All Storage Technologies

– Now and into the Long-Term Future

• IT‐Centric and Not Tied to Media Applications Alone

• Being Standardized by SMPTE

• Considered within an IT System Stack

AXF Layered Context

AXF-Aware Application

Server/Storage Stack with AXF support

Archive eXchange Format (AXF), Including Internal File System Block Level Addressing File System

Medium (without File System) Medium (with File System) Operating System – Hardware Abstraction Layer

Driver Physical Drive

• Unlimited Storage Support

– Any Number of Files, Any Size of Files, Plus Media Spanning

• Resilience to Media Damage and Corruption

– Redundancy in All Structures

– Payload Independently Recoverable

• Support for Media With & Without a File System

– Raw Data Tape, LTFS Data Tape, Spinning Disk, Flash Media, Optical Storage, Holographic Storage, & Anything in Future

• Support for Any Operating System and/or File System

– Embedded File System Abstracts Underlying Systems

• Self Describing Objects & Self Describing Media

– Enable Simple Transport of Objects & Media between Systems

• Object Versioning & Collection Support

– Support Complex Relationships between Objects – Support Additions, Updates, etc.

• Support for All File Types – Not Just Media Files

– IT‐Centric Implementation

• Based on Experience Handling Big Data in M&E

• Streaming & File-Based Asset Transport & Delivery

– Support for Streaming De‐Encapsulation

– Support for In‐Path Checksums for Structures & Files – Support for Cloud Storage & Delivery Applications – Streaming Design Maximizes Transfer Speeds

• To/from All Media Types

What Is AXF?

Control Provenance Fixity Context Reference

Universal Storage-Agnostic File System

Metadata _PayloadFile Ancillary _Files

Asset Components Preservation Elements File System AXF Object

Storage Technology & File Systems

AXF Object Spinning Disk

(NTFS, FAT, etc.) Solid State Disk (NTFS, FAT, etc.) Holographic (UDF, etc.) Blu-Ray (BDFS, UDF, etc.) Flash Media (NTFS, FAT, etc.) DVD (UDF, etc.) Data Tape (Block-Based, LTFS, etc.) Future Storage Technologies

AXF on Storage Medium

AXF Medium Ide

nt ifi er _{AXF Object} 1 AXF Object 2 AXF Object N … A XF Objec t He ade r Me ta da ta Co nt ain er Me ta da ta Co nt ain er Fi le ₁ A XF F il e Fo ot er Fi le ₂ A XF F il e Fo ot er Fi le _N A XF F il e Fo ot er A XF Objec t Fo ot er … … Metadata Payload File Payload

• Binary Structure Containers Define Elements

• File Tree Acts as

Light-Weight

File System

Sizes, & Other Characteristics

Spanned Sets

Medium 1 (Initial Medium of a Spanned Set)

Medium Identifier: Medium.UUID = Um1 Object Header: Object.UUID = Uo1 Fragment Footer:

FragmentPairUUID = Uf1 FragmentNumber = 1 NextMediumUUID = Um2

Medium 2 (Intermediate Medium of a Spanned Set)

Medium Identifier: Medium.UUID = Um2 Object Header: Object.UUID = Uo1 Fragment Header: FragmentPairUUID = Uf1 FragmentNumber = 2 PreviousMediumUUID = Um1 Fragment Footer: FragmentPairUUID = Uf2 FragmentNumber = 2 NextMediumUUID = Um3 Medium Content Medium Content

Medium 3 (Final Medium of a Spanned Set)

Medium Identifier: Medium.UUID = Um3 Object Header: Object.UUID = Uo1 Fragment Header:

FragmentPairUUID = Uf2 FragmentNumber = 3 PreviousMediumUUID = Um2

Medium Content Object Footer: Object.UUID = Uo1

Collected Sets

Anchor Object (Initial Object of a Collected Set)

Medium Identifier: Medium.UUID = Um1 Object Header: Object.UUID = Uo1 CollectedSetUUID = Uo1 SetSequence = 1 File: Video1 (processing=default) File: Audio1 (processing=default) File: Audio2 (processing=default) Object Footer: Object.UUID = Uo1 CollectedSetUUID = Uo1 CollectedSetSequence = 1

Subsequent Object (Final Object of a Collected Set)

Medium Identifier: Medium.UUID = Um1 Object Header: Object.UUID = Uo2 CollectedSetUUID = Uo1 CollectedSetSequence = 2 Object Footer: Object.UUID = Uo2 CollectedSetUUID = Uo1 CollectedSetSequence = 2 File: Audio1 (processing=REPLACE) File: Audio2 (processing=DELETE)

File: Closed Caption1 (processing=ADD)

Anchor Object

+ Subsequent Object(s)

Compile per Instructions

Product Object

Processing Instructions: ADD

REPLACE DELETE

New Files Carried with ADD & REPLACE No Files Carried with

• Objects Scale to Any Size & Encapsulate Any Number of Files

– With Full Support for Media Spanning

• No Need to Upgrade Existing Storage Infrastructures • Ensures Long-Term Compatibility & Resiliency

– With Self-Describing Features for Both AXF Objects & AXF Media

• Overcomes All Technical, Operational, & Functional Limitations

– Of TAR & LTFS, Works Harmoniously with LTFS

• An IT‐Centric Implementation Not Limited to Media Files Alone

– Supports Documents, Imaging Data, etc.

• Satisfies All of Ideal Storage Format Goals Outlined
