90 MM MODULES GENERAL OVERVIEW.

(1)

www.hella.com

90 MM MODULES

GENERAL OVERVIEW

(2)

2

When installing and using our products in road traffic, please follow the appropriate legal requirements.

90 mm configurator

3

90 mm range overview

6-7

90 mm L 4060

8-9

90 mm L 70

10

90 mm Premium

11

90 mm Performance

12

90 mm Classic

13

Accessories for 90 mm modules

14-15

Light distributions in comparison

16-17

(3)

3 90 mm configurator:

www.hella.com/90mm-modules

90 mm modules are used in almost all vehicles. They are small but powerful.

They stand for quality, practicality, safety and cost-efficiency.

Their modular construction enables an individual front design.

This tool is aimed at original equipment fitters, vehicle fleet operators and end customers in the

agricultural sector, sports cars, electric cars, mobile homes, bus companies and municipal vehicles.

It offers the following benefits:

Original Equipment

In our 90 mm configurator, you can design and put together your own front lighting.

This process is aided by a simple menu guide.

This results in a parts list, which you can then send to HELLA directly from the tool.

Upgrade to LED

HELLA is currently the only provider that can offer you conversion to LED light technology for all 90 mm single

and multifunctional modules in halogen and xenon. Existing halogen versions can easily be converted to LED

modules! Based on the currently used halogen modules, the tool can be used to show which adaptations are

necessary to convert to LED products whilst retaining the same lighting functions. This is simple with the

compatible assembly solutions.

Illumination comparison

You can compare the lighting technologies for selected main light functions. See the difference between halogen and LED with realistic images from Europe's largest light testing facility! Compare

light distribution to make the right decision for your application. You will also receive all the relevant information on the technical data. The complete range is clearly described in a PDF.

(4)

(5)

(6)

90 mm modules - Range overview

6 LED

Xenon

Halogen

(conventional

lighting

technology)

Main light functions

Low beam

High beam

Low beam

and

high beam:

High beam

and

daytime running light

High beam

and

indicator

(7)

7 90 mm modules - Range overview

Fog light and

cornering light

Fog light

and daytime

running light

LED

Xenon

Halogen

(conventional

lighting

technology)

Auxiliary light functions

Daytime

running light

Daytime

running light

and

position light

Indicator and

position light

Indicator

Indicator,

daytime running

light and

position light

Position light

(8)

90 mm: L 4060 high beam

High-end illumination. High beam, daytime running and position lights in one module or as a separate high beam module. 40 x 60 mm PC lens in new design. Pattern-free and hardened plastic cover lens.

Spotlight with either pre-mounted carrier frame or as a 90 mm performance module mount for a 1:1 conversion.

Integrated FEP plug and control electronics.

LED spotlight L 4060

Modular headlight with 40 x 60 mm polycarbonate lens Sturdy die-cast aluminium housing

Silver design cover, (black design cover on request) Multivoltage 9-33 V,

Pre-mounted carrier frame

1F0 011 988-021

Performance mount

1F0 011 988-121

LED spotlight L 4060, with daytime running light / position light

Silver design cover, (black design cover on request) Multivoltage 9-33 V

1F0 011 988-031

Performance mount

1F0 011 988-131

LED spotlight L 4060 with indicator

Silver design cover (black design cover on request) multi-voltage 9-33 V With control unit

1F0 011 988-081*

Performance mount

1F0 011 988-181*

Without control unit

1F0 011 988-071*

Performance mount

1F0 011 988-171*

*Available from May 2014

8

Performance module mount for 1:1 conversion of existing halogen versions

73.5 73.5 Ø5.5 (4x) 90.6 54.6 1.25 Ø90 4 96 42 117.8 116 85 85 Ø14(4x) Ø6.5(6x) 52 51 52 50 3 14.8 33.4

With pre-mounted carrier frame

ew

desig

g

n. Pattern-free and

ha

ardene

LED spotlight L 4060 with indicator

odular headlight with 40 x 60 mm polycarbonate dy die-cast aluminium housing

sign cover (black design cover on re l unit

(9)

9 90 mm: L 4060 fog light

LED fog light L 4060

Silver design cover, (black design cover on request) Multivoltage 9-33V,

1N0 011 988-001

LED fog light L 4060, with daytime running light and position light

Silver design cover (black design cover on request) Multivoltage 9-33V,

1N0 011 988-011

LED fog light L 4060, with cornering light

Silver design cover, (black design cover on request) Multivoltage 9-33V,

Right

1N0 011 988-061

Left

1N0 011 988-051

Uniform illumination similar to daylight. Fog light in various combinations as a separate module, with daytime running light, position light and turning light. 40 x 60 mm PC lens, hardened plastic cover lens,

integrated FEP plug.

(10)

10

LED low beam headlight (Mono-LED)

Mono LED, right-hand traffic (LHD)

1BL 010 820-001

Mono LED, left-hand traffic (RHD)

1ML 010 820-011

LED low and high beam headlight L 70 (Bi-LED)

Bi-LED, right-hand traffic (LHD)

1AL 010 820-021

Bi-LED, left-hand traffic (RHD)

1LL 010 820-031

Type approval Mono-LED ES 3159 and LES 3160, Bi-LED ES 3351 and LES 3352

Set packaging

(One headlight and one 12 V control unit for functional monitoring)

Mono-LED, right-hand traffic (LHD) and 12 V control unit

1BL 010 820-801

Mono-LED, left-hand traffic (RHD) and 12 V control unit

1ML 010 820-821

Bi-LED, right-hand traffic (LHD) and 12 V control unit

1AL 010 820-841

Bi-LED, left-hand traffic (RHD) and 12 V control unit

1LL 010 820-861

Set packaging

(One headlight and one 24 V control unit for functional monitoring)

Mono LED, right-hand traffic (LHD) and 24 V control unit

1BL 010 820-811

Mono LED, left-hand traffic (RHD) and 24 V control unit

1ML 010 820-831

Bi-LED, right-hand traffic (LHD) and 24 V control unit

1AL 010 820-851

Bi-LED, left-hand traffic (RHD) and 24 V control unit

1LL 010 820-871

90 mm: L 70 low beam and high beam

The light colour, which is similar to daylight, offers more safety and comfortable, fatigue-free driving. Three white high-power LEDs form the light source for each light function. The light is projected through the

70 mm DE lens homogeneously on the street. The service life of the headlight, normally more than 15,000* real operating hours, offers major cost savings when it comes to maintenance and repair costs

compared to other light systems**. No moving parts, passive cooling, plastic cover lens, multi-volt

Set pack (One he M

ble, fatigue-free driving. Three wh

h

it

e

hi

h

t, normally more than 15,000* real oper

over lens, multi-volt

(11)

11 High-end illumination. Low beam and high beam from a single headlight module, choice of xenon or halogen technology. 70 mm DE lens. Pattern-free and hardened glass cover lens. High-quality aluminium

reflector. Preinstalled adjustment-screws. Including light source. Splashwater-proof electronic ballast for xenon variants. Connection using 0.5 metre shielded supply cable with detachable plug-type connection.

90 mm: Premium low beam and high beam

w beam and high beam from a single headli

ule, choice of xenon or halogen technology. 70

oof electronic ballast for xenon variants. C

Bi-Xenon low beam and spotlights*

12 V, right-hand traffic (LHD), D2S

1AL 009 997-001

12 V, left-hand traffic (RHD), D2S

1LL 009 997-011

12 V, right-hand traffic (LHD), D2S, USA version

1AL 009 997-021

24 V, right-hand traffic (LHD)

1AL 009 997-041

24 V, left-hand traffic (RHD)

1LL 009 997-051

*Xenon low beam light only permitted with headlight range adjustment and lens cleaning system.

Bi-halogen low beam and spotlight

12 V, right-hand traffic (LHD), H7

1AL 009 998-001

12 V, left-hand traffic (RHD), H7

1LL 009 998-011

12 V, right-hand traffic (LHD), H9, USA version

1AL 009 998-021

1AL 009 998-041

1LL 009 998-051

24 V, right-hand traffic (LHD), H7, with fording capability

1AL 009 998-201

24 V, left-hand traffic (RHD), H7, with fording capability

1LL 009 998-221

Halogen low beam headlight

Ideal in combination with the matching spotlights and fog lights.

1BL 009 999-001

1ML 009 999-011

12 V, right-hand traffic (LHD), H7, USA version

1BL 009 999-021

1BL 009 999-041

1LL 009 999-051

free and hardened glass cover lens. High-qua

shielded supply cable with detachable plu

(12)

12

Halogen low beam headlight Module headlight with 50 mm DE lens

12 V, right-hand traffic (LHD). H1, for premium fixing

1BL 247 042-177

12 V, left-hand traffic (RHD), H1, for premium fixing

1ML 247 042-187

24 V, right-hand traffic (LHD), H1, for premium fixing

1BL 247 042-197

24 V, left-hand traffic (RHD), H1, for premium fixing

1ML 247 042-207

24 V, right-hand traffic (LHD), H1, for classic fixing

1BL 247 042-157

24 V, left-hand traffic (RHD), H1, for classic fixing

1ML 247 042-167

Halogen spotlight

Module headlight with FF reflector

12 V, with position light, H1, for premium fixing

1K0 247 043-117

12 V, without position light, H1, for premium fixing

1K0 247 043-127

24 V, with position light, H1, for premium fixing

_{1K0 247 043-137}

_{1K0 247 043-147}

24 V, with position light, H1, for classic fixing

_{1K0 247 043-097}

_{1K0 247 043-107}

90 mm: Performance low beam and high beam

Optimised illumination. Modules in enhanced quality for use on long hauls. Pattern-free and hardened glass cover lens. High-quality aluminium reflector.

With splashwater-proof plug-type connector. Perfectly fitting adjustment-screws included in the scope of supply.

(13)

13 90 mm: Classic low beam and high beam light

Xenon low beam headlight 12 V, D2S, right-hand traffic (LHD)

1BL 008 194-001

12 V, D2S, USA version

1BL 008 194-041

12 V, D2S, left-hand traffic (RHD)

1LL 008 194-037

24 V, D2S, right-hand traffic (LHD)

1BL 008 194-027

24 V, D2S, left-hand traffic (RHD)

1LL 008 194-051

Low-beam headlight,

Module headlight with 50 mm DE lens

Halogen low beam headlight

12 V, H7, right-hand traffic (LHD)

1BL 008 193-001

12 V, H9, USA version

1BL 008 193-021

12 V, H7, left-hand traffic (RHD)

1LL 008 193-111

24 V, H7, right-hand traffic (LHD)

1BL 008 193-011

24 V, H7, left-hand traffic (RHD)

1LL 008 193-121

Spotlight

Module headlight with FF reflector

Xenon spotlight 12 V, D2S with P0 light

1K0 008 192-001

12 V, D2S without P0 light

_{1K0 008 192-011}

24 V, D2S with P0 light

1K0 008 192-027

24 V, D2S without P0 light

_{1K0 008 192-091}

Halogen spotlight 12 V, H7 with P0 light

1K0 008 191-001

12 V, H7 without P0 light

1K0 008 191-011

12 V, H9 with P0 light, USA version

1K0 008 191-131

12 V, H9 without P0 light, USA version

1K0 008 191-051

24 V, H7 with P0 light

1K0 008 191-021

24 V, H7 without P0 light

1K0 008 191-041

Proven illumination. Low beam and high beam from one headlamp module, optionally xenon or halogen technology. Pattern-free and hardened glass cover lens. Magnesium reflector. Splashwater-proof

electronic ballast for xenon variants. Perfectly fitting adjustment-screws included in the scope of supply. Including light source.

(14)

14 90 mm: LED accessories

LED 40/60

Low-beam LED 010 820 Low beam and high beam bi-LED 010.820 Fog light LED 011.988-001 Fog light + daytime running light + position light 011.988-011 LED high beam 011.988-021 LED high beam 011.988-121 Highbeam + daytime running light + position light 011.988-031 Highbeam + daytime running light + position light 011.988-131 Fog light + LED bend light 011.988-051/061 High beam + turn indicator (with impulse) 011.988-081 High beam + turn indicator (with impulse) 011.988-181 High beam + turn indicator (without impulse) 011.988-071 High beam + turn indicator (without impulse) 011.988-171

Accessory components Part number Features

Carrier frames

9AH 169 580-011 black • • • • • • • • • • • •

Surplus supply LED AMP Supersealed, 3-pin

Mounting hole 8JA 746 184-032 10 units • •

Female socket connector 8KW 744 837-002 50 units • •

Strand insulation 9GD 746 185-002 50 units • •

Surplus supply LED FEP 4-pin plug

Mounting hole 8JA 202 231-002 • • • • • • • • • • •

Blade contact 8KW 863 933-013 50 units • • • • • • • • • • •

Strand insulation 0.35-0.5mm² or 8KW 863 952-022 • • • • • • • • • • •

Strand insulation 0.75mm² 8KW 863 952-012 • • • • • • • • • • •

Blind plug 9GB 863 952-002 50 units • • • • • • • •

Surplus supply LED 4-pin German plug (only together with adapter cable see 1)

Male connector housing 8JA 201 022-042 10 units • • • • • • • • • • •

Interlock / wedgelock 9NB 201 024-042 10 units • • • • • • • • • • •

Contact sleeve 0.5-1.5 mm² 9NB 201 025-112 50 units • • • • • • • • • • •

Blind plug 9NB 201 026-012 50 units • • • • • • • •

Packaged set of dummy plugs (comprising 1 male connector housing, 1 interlock, 5 contact sleeves and 3 dummy plugs)

8JA 201 022-821 • • • • • • • • • • •

Headlight range adjustment systems

Headlamp leveling system 6NM 007 282-221 • • • •

Bracket for right-side mounting of actuator 8HG 138 619-007 • • • •

Bracket for left-side mounting of actuator 8HG 138 620-007 • • • •

Headlight cleaning systems

Headlight cleaning system set with fixed nozzles 8WS 008 549-001 4 nozzles ▲ ▲ • •

Headlight cleaning system set with telescoping single nozzles 8WT 008 549-101 Two single nozzles ▲ ▲ • •

Headlight cleaning system set with telescoping double nozzles 8WT 008 549-201 Two double nozzles ▲ ▲

Bend lighting accessories

Lead for LED module - bend lighting control unit 8KB 163-160-011 1 unit

Bend lighting control unit 5DF 009 244-007 24 units

Adapter lead

1)_{Adapter from FEP plug to (4-pin) German plug} _{8KA 202 117-001} _{1 unit} _{• •} _{• •} _{• •} _{• •} _{• •} _{• •} _{• •} _{• •} _{• •} _{• •} _{• •}

Adapter from FEP plug to performance module (247.043) or DynaView (009 295)“

8KA 202.117-011 1 unit • • • • • • • • • •

Legend

•) Accessories needed for proper attachment. ••) Optional accessories, tailor-made for the headlights.

•**) Required for xenon low beam lights, permitted as an option for halogen and LED.

▲) Required for xenon low beam lights and in some countries according to local approval regulations. Permitted as an option for halogen and LED.

(15)

15

Premium Performance Classic

Low beam / high beam

Bi-Xenon 009 997 Low beam / high beam Bi-halogen H7 009 998 Bi-halogen H7 with fording capability Low beam / high beam Bi-halogen H9 009 998-02 Halogen low beam H7 009 999 Halogen low beam 247 042 Halogen high beam 247 043 High beam, halogen H1 with pos. light 247 043 Low beam xenon 008 194 High beam xenon 008 192 High beam xenon with pos. light 008 192 Halogen low beam H7 008 193 Halogen low beam H9 008 193 Halogen high beam H7 008 191 Halogen high beam H7 with pos. light 008 191 Halogen high beam H9 008 191 Halogen high beam H9 with pos. light 008 191

Product details on page 13 13 13 13 14 14 14 15 15 15 15 15 15 15 15 15

Accessory components Part number Features

Carrier frame

9AH 169 580-011 black • • • • • • • • • • • • • • • •

9AH 157 659-007 silver • • • • • • • • • • • • • • • • • •

Caps

flat for angled plugs

ventilated 9GH 152 654-007 • •

non-ventilated 9GH 152 654-012 •

deep for receptacle housings

ventilated 9GH 145 943-001 • •

non-ventilated 9GH 145 943-012 •

Plug (vehicle side)

Surplus supply H1 / H7 / xenon 8JD 156 151-807 20 systems • • • • • • • • • •

Surplus supply H9 8JD 158 175-807 20 systems • • • •

Parking light 8JD 156 150-807 20 systems • • • •

Toggle high beam AMP Supersealed, 2-pin

Housing 8JA 746 184-022 10 units • • • • •

Female contact 8KW 744 837-002 50 units • • • • •

Strand insulation 9GD 746 185-002 50 units • • • • •

Fording-capable version

Ventilation hose 9GS 190 794-002 50 m •

T-pieces for ventilation hose 9XL 190 733-002 10 units •

Headlight range adjustment systems

For halogen 12 V 6NM 007 282-221 • • • • • • • • • • • • • •

For xenon versions 12 V 6NM 007 282-231 • • • •

For halogen 24 V 6NM 008 299-501 • • • • • • • • • • •** • • • •

Mounting set for actuator 8HG 183 586-001 1 set • • • • • • • • • • • • •

Bracket for right-side mounting of actuator 8HG 138 619-007 • • • • • •

Bracket for left-side mounting of actuator 8HG 138 620-007 • • • • •

Automatic headlight range adjustment •**) 8XX 010 315-001 1 Sensor •** •**

Lens cleaning systems ▲)

Headlight cleaning system set with fixed nozzles 12 V 8WS 008 549-001 4 nozzles ▲ ▲ ▲ ▲ ▲ ▲ ▲ ▲ ▲

Headlight cleaning system set with fixed nozzles 24 V 8WS 008 549-501 4 nozzles ▲ ▲ ▲ ▲ ▲ ▲ ▲ ▲ ▲

Headlight cleaning system set with telescopic single nozzles 12 V 8WT 008 549-101 Two single nozzles ▲ ▲ ▲ ▲ ▲ ▲ ▲ ▲ ▲

Headlight cleaning system set with telescopic single nozzles 24 V _{8WT 008 549-601} _{Two single nozzles} ▲ ▲ ▲ ▲ ▲ ▲ ▲ ▲ ▲

Headlight cleaning system set with telescopic double nozzles 12 V 8WT 008 549-201 Two double nozzles ▲ ▲ ▲ ▲ ▲ ▲ ▲ ▲ ▲

Headlight cleaning system set with telescopic double nozzles 24 V 8WT 008 549-701 Two double nozzles ▲ ▲ ▲ ▲ ▲ ▲ ▲ ▲ ▲

90 mm: Halogen and

xenon accessories

(16)

16 Comparison between LED, halogen and xenon low beam

Classic halogen low beam

Premium halogen and Bi-Xenon® low beam

Classic xenon low beam

Classic Bi-Xenon® low beam

Premium Bi-Xenon® low beam

L 70 low beam

Performance halogen low beam

Did you know these facts about xenon?

Xenon > 2000 lumens, resulting in a generally stronger illumination.

Headlight power wash system and headlight range adjustment are required.

New applications are no longer permitted for the vehicle classes

(17)

17 Comparison between LED, halogen and xenon high beam

Premium Bi-Xenon® high beam

L 4060 high beam

Bi-LED high beam

Premium Bi-halogen® high beam

Performance halogen high beam

Classic halogen high beam

Classic xenon high beam

Bi light distributions

Are created when the low beam light is switched on

and are only available as a bi version.

(18)

18

LED daytime running lights set, round design 2 lights including harness, universal bracket, 3 high-performance LEDs per light, multi-voltage 9-33V 12 V / max. 5.5 W, current consumption = 2.18 A

Set for surface-mounting

2PT 009 599-811

Type approval 2372 Optional accessories

Universal carrier frame

9AH 165 968-001

Harness, pre-assembled

8KA 165 959-001

90 mm: Supplementary lighting functions

The 90 mm range is expanded with round LED lights. Available as either a daytime running light function or as a 3-function light. Together with the main light functions, there are many combination possibilities

that can meet all lighting requirements in the popular 90 mm lens format.

Optional accessory - 90 mm adapter ring The adapter ring is used to replace a 90 mm light with the 83 mm light.

This means that vehicles that have come equipped with a HELLA 90 mm light can be

easily converted to 83 mm lights.

9GD 980 696-001

83 mm LED 3-function light (indicator, position and daytime running light) Pre-wired with 2.5 m sheathed four-core cable

Single light 12 V

_{2BE 980 691-101*}

83 mm LED 2-function light (Indicator and position light)

Pre-wired with 2.5 m sheathed four-core cable

Single light 24 V

_{2BE 980 690-301*}

Type approval 5854 and 03 1962 Indicator ECE-Reg. No. 6

Position light ECE-Reg. No. 7 Daytime running light ECE-Reg. No. 87

*No integrated impulse

ghts set, round design sal bracket

range is expanded with ro

et all lighting requiremen

3V

ghts. Available as either

pular 90 mm lens forma

n

ound LED lig

nts in the popu

(19)

19 90 mm: Supplementary lighting functions

The 90 mm module range is expanded with the following signal lights. Together with the main light functions, there are many combination possibilities that can meet all lighting requirements in the popular 90

mm lens format. The pattern-free real glass or plastic cover lenses are the perfect fit for the headlights in our range.

m

ain

i

li

ght

h

f

func

tions, t

i

h

here are many c

or the headlights in our range.

e

le

r

an

ge

i

s

ex

expa

nded with the follow

d

. The pattern-free real glass or plastic co

ssibilities that can meet all l

l lighting re

equirements in the pop

Indicator/position light 12 V

2BE 010 102-001

2BE 010 102-011

with fording capability for ventilation hose

2BE 010 102-201

90 mm indicator / position light combination

Modular headlight with pattern-free glass cover lens, with PY21W/12 V silver bulb and Kartoval® LED

Indicator / position light

2BE 010 102-001

Type approval 2586, ECE R6, ECE R7 and SAE

90 mm indicator/position light

Indicator with amber bulb, 12 V

2BA 965 039-061

Indicator with amber bulb, 24 V

2BA 965 039-141

Position light, 12 V

2PF 965 039-071

Position light, 24 V

2PF 965 039-151

Daytime running/position light 12 V

2BE 010 102-101

Daytime running/position light 24 V

2PT 010 102-011

Daytime running/position light 24 V with fording capability for ventilation hose

2PT 010 102-221

Plug set, 3-pin

_{8JD 162 581-802}

Optional carrier frame with 3 screws

For fording-capable version only:

9AH 165 968-001

25 m ventilation hose

9GS 190 794-002

10 T-pieces for ventilation hose

9XL 190 733-002

90 mm indicator / position light combination

Modular headlight with pattern-free glass cover lens, with P 21 W P 12 V Longlife bulb and Kartoval® LED

With daytime running light/position light

2BE 010 102-101

(20)

9Z2 999 134-774 J00704/KB/12.13/1.7 Printed in Germany
