perfSONAR MDM Deployment

PERT workshop, TNC2012

Szymon Trocha, Poznań Supercomputing and Networking

Centre

Reykjavik, 21 May 2012

The research leading to these results has received funding from the European Community’s Seventh Framework Programme (FP7/2007-2013) under grant agreement no 238875 (GÉANT) Credits to D.Vicinanza (DANTE) for parts of slides

(2)

Internet measurements

„Internet measurements is fun” „We need to share our data”

N.Brownlee, „Measuring Internet Evolution - If We Don't Measure, We Don't Know What's Happening!”, APAN26

(3)

Agenda

perfSONAR MDM overview Diagnostic Service

Diagnostic Service deployment

Diagnostic Service deployment scenarios Deployment status

Development status and roadmap

Demonstration of installation and usage

(4)

perfSONAR MDM overview

(5)

connect • communicate • collaborate 5

What’s In A Name?

perfSONAR stands for “Performance Service Oriented Network Monitoring Architecture”

(6)

Four Aspects to perfSONAR

Architecture and protocols

Define web services based on roles

Define their communication syntax and semantics

–

Protocols based on the Open Grid Forum (OGF) Network

Measurement Working Group (NM-WG) schemas

Allow anyone to develop web service implementations

A set of interoperable software implementations

Java, Perl, Python etc.

A collaboration by many organisations

A deployed measurement infrastructure

(7)

7 / 17

Across Network Boundaries

Performance data fragmented and hard to access Difficult to find measurement capability

Multi-domain problem diagnoses difficult and slow

National Network X National Network X Backbone X X Network Administrator Network Administrator Network Administrator User Campus Network X Network Administrator User Campus Network X Network Administrator

Key: X = locally held performance data = path

(8)

(9)

perfSONAR MDM Diagnostic Service

(10)

What is perfSONAR MDM service?

perfSONAR MDM (Multi-Domain-Monitoring) is the multi-domain diagnostic service for the GÉANT Service Area

Part of the GEANT portfolio

Based on the perfSONAR protocol

Interoperable with other deployments around the world

(from the perfsonar.geant.net website)

(11)

11 / 8

perfSONAR MDM Service

Access to a set of monitoring functionalities (e.g. accessing metrics or performing tests) offered to a group of users accessible directly through an XML interface (perfSONAR protocol) or through a visualisation tools. Based on an underlying set of perfSONAR web-services

Own OwnUser

GN2 Visualisation

perfSONAR SOAP XML + JRA5 AA

GN2 Visualisation Domain A BWCTL MP OWD MA Lookup Domain B BWCTL MP OWD MA Lookup Domain C BWCTL MP OWD MA Lookup User Visualisation

perfSONAR SOAP XML + JRA5 AA

11

(12)

A real answer to real use cases

Services built around real use cases:

Network performances and monitoring

Circuit monitoring (both statically and dynamically provisioned) SLA verification

Federated deployment facilitated by a dedicated deployment

team

Each NREN provides at least one MP (and possibly a MA)

In turn it get access to GEANT and other participant NRENs MPs and MAs

Supported

(13)

13 / 8

Shared Responsibility

An domain has two roles

Data supplier

–

Deploys the service instances

–

Provides the required data and functionalities

–

Administers and minimizes unavailability

Data user

–

Uses the infrastructure, solves issues

–

Updates operational procedures to take the MDM service into account

–

Raises awareness internally

(14)

Simplicity for concrete benefits

Simplicity:

Revised list of metrics to meet network engineers requirement No hardware-dependent software

No need for GPS antenna Running on Debian or RHEL

Benefits:

Immediate access to the complete picture:

–

No more waiting for other NRENs to provide their network monitoring data that affects your users’ experience.

Improving multi-domain network performance troubleshooting

–

Enabling consistent monitoring across multiple domains

–

Tackling potential problems which may adversely impact the researchers’ voice, video or data communications

(15)

A new perfSONAR MDM:

Compatible, open, interoperable

Restructuring of perfSONAR MDM

Progressively endorsed by EU NRENs and other R&E networks

in the world

Using direct user feedback to meet user expectations

perfSONAR User Panel to gather requirements and constantly

listen to the user community

Simplifying installation procedure

Revised documentation (lightweight and modular)

Interoperable with perfSONAR-PS

Use-case scenario

See TNC session on …

(16)

Service deployment overview

(17)

Deployment process

The main goal is to deploy the perfSONAR MDM service to the GÉANT backbone and NRENs connected

In each participating domain, the focus is to have measurement infrastructure deployed within the domain boundaries (interdomain), even though domains are encouraged to extend deployment across their infrastructure (intradomain)

Starts with becoming a perfSONAR Early Adopter

Deployment team…

Is responsible to ensure the domain has all the means and required tools available to fully deploy all the components to operate the service

Follows up the entire deployment cycle and provides the required support during the whole deployment process

User is responsible for the day-to-day operations of the service and its components within his domain

(18)

Deployment process stages

Definition • Use case presented • Infrastructure evaluated • Environment understood • Initial plan ready Deployment • Deploy main components in the few main intra-domain paths and inter-domain boundaries • Start developing monitoring Transition • Spread all components to most of the desired PoPs • monitoring fully deployed • Visualisation tools deployed • Tools integrated to the NOC and/or PERT Operation • Ensure all components are operational • Ensure elements provide consistent delivery to the GÉANT Service Area • Monitoring fully operational to operate the service • Transfer to MDSD 18

(19)

Diagnostic service deployment scenarios

(20)

Service architecture

(21)

Service architecture cont.

perfSONAR MDM Service Architecture and Scenarios document

This document ensures common understanding of elements of the monitoring infrastructure and their configurations to provide

consistent perfSONAR MDM monitoring service support and delivery to the GÉANT Service Area users by participating domains. Where to find? https://intranet.geant.net/sites/Services/SA2/T3/Documents/perfSO NAR%20Deployment%20Subtask%20documents/perfSONAR%20 MDM%20Service%20Architecture%20and%20Scenarios.pdf Or easier 

–

GN3 SA2 T3 Documents -> perfSONAR Deployment Subtask

documents -> perfSONAR Deployment Subtask documents.pdf

(22)

Early adopters deployment scenarios

3 tiers of the deployment are considered: Upper Tier (e.g. GEANT), Domain (e.g. NREN), Lower Tier (e.g. MAN or RAN)

The difference in deployment scenario depends on the scope of deployment within a domain and the depth of deployment in the hierarchy

Minimal case: a domain deploys MP(s) located near the domain’s

interconnection points to upper tier domains (upstream) and enables on-demand measurements. It allows the upper tiers as well as the other

domains at the same level to run on-demand multidomain measurements between their interconnection points

Recommended case: a domain in addition deploys MPs within its infrastructure, next to at least lower tier (downstream) interconnection

points, neighboring domains and possibly also other points of interest (intra-domain)

Domains are encouraged to extend the basic scenario enabling scheduled measurements between deployed MPs

Domain deploys a Measurement Archive (MA) to store data from intra-domain measurements

(23)

Tier model

(24)

Modified tier model

(25)

Coments to service architecture

perfSONAR MDM Product Manager

Domenico Vicinanza [email protected] GN2 SA2 T3 leader

Jan Hertzberg [email protected]

(26)

Service architecture cont.

„perfSONAR MDM Service Configuration Recommendations”

document

Recommends configuration of the proper elements of the

monitoring infrastructure to provide consistent perfSONAR MDM monitoring service support and delivery to the GÉANT Service Area users by participating domains

Where to find?

http://downloads.perfsonar.eu/repositories/documents/perfSONAR %20MDM%20Service%20Configuration%20Recommendations.pdf

Or easier 

–

perfSONAR MDM Forge -> Documentation -> perfSONAR MDM Service Configuration Recommendations

(27)

Diagnostic Service software components

(28)

perfSONAR MDM Monitoring Service

Achievable bandwidth One-way delay

Delay variation

One-way packet loss Traceroute

On-demand Scheduled Visualization

(29)

Deployment scope

BWCTL

MP

HADES

MA

SQL

MA*

29 * 3.3 release

(30)

Current verion(s) of perfsonarUI

Location of the tool reflects users’ privacy concerns Public version for general users

–

Access to MAs for link utilisation, one way delay, jitter, packet loss and traceroute. Does not allow any on-demand bandwidth tests.

–

perfsonar.geant.net -> Resources -> Stable version, for general users (perfsonar-0.22-pub.jnlp)

Partners’ version for NOC/PERT engineers

–

Access to MAs for link utilisation, one way delay, jitter, packet loss, traceroute, bandwidth. It allows on-demand bandwidth tests.

–

GÉANT Partner Portal -> perfSONAR User Interface (perfsonar-0.22-prod.jnlp)

Partners’ experimental version for developers

–

In addition includes Playground, Lookup Service Playground, Qflow MA client, Looking Glass and both LinkStatus and Links tabs.

–

GÉANT Partner Portal -> perfSONAR User Interface (perfsonar-0.22-exp.jnlp)

LIVE DEMO

(31)

New version of perfsonarUI

Has all essential functionalities of the existing desktop

perfsonarUI (RRD MA, HADES MA, SQL MA and BWCTL MP) Developed as a web

application

Allows the user to compare two interfaces (overlayed graphs and comparison of numerical values)

Compare two routes which

were active in the selected time period

Service status check

TODO: configuration panel, which will allow the user to configure the UI to use a global service list, a local service list (kept in an DB) or combine both of them

(32)

Give it a try

Go to:

NOT PUBLICLY AVAILABLE

(33)

Hardware possibilities

(34)

Handover of existing servers

There are servers coming from GN/GN2 Used as HADES and BWCTL MP

Practical approach to handover

Acknowledge you’d like to manage them Give us details

We will

–

remove the servers from the central HADES MDM server and our configuration management repository

–

delete the "labor" user

–

deregister the servers from the DANTE Red Hat Enterprise Linux subscriptions

–

add an SSH key securely supplied by the domain to the server's root account

–

change the eRIC remote management super/admin account to a shared password

(35)

Handover of existing servers cont.

It will be the NREN's responsibility to (assuming you want to keep the existing installation):

change the root and eRIC card password review the authorized SSH keys

register the installation with Red Hat under their own subscription set up their own HADES domain (BWCTL will likely simply keep working)

or boot the system from an installation DVD and start fresh (e.g. choosing Debian)

–

Then only need access to the eRIC remote management

–

On how to reset a remote management card back to factory defaults, see https://forms.raritan.com/support/eric-express/user-guide/

Let us know if paperwork is needed

(36)

Reference hardware

DELL Server Hardware Compatibility Testing with HADES / BWCTL (by DFN-Labor)

Test System 1

DELL PowerEdge R415, AMD Opteron 4176HE, 8GB RAM, 250GB SATA disk

NICs: Internal Broadcom, Intel Gigabit ET Quad Port Cu PCIe x4, Myricom Myri-10G

Red Hat Enterprise Linux 6.2, 64 bit

Test System 2

DELL PowerEdge R710, Intel Xeon E5645, 8GB RAM, 250GB SATA disk NICs, OS and measurement software: As above

OWAMP + BWCTL tests

There were some minor issues with delay on the R710 model, while no problems noticed related to the R415

R415 will be deployed over GEANT

(37)

RIPE TTM servers

RIPE NCC announced the end of life for the Test Traffic Measurement service (TTM)

What does this mean

They will not extend any existing TTM contracts

They will continue to operate TT measurements as long as necessary but until no later than 1 October 2012

On 1 October 2012, they will shut down the central server and website

If one wants to continue operating the test boxes they will support that on a best-effort basis. In particular, provide with the root password and best-effort parts replacement for clock hardware as long as they have spare parts

Lower tier domains/projects - use them for LHC Tier 2s

(38)

Deployment status

(39)

Early Deployers

39 HEAnet (IE) RedIRIS (ES) RENATER (FR) DFN (DE) PIONIER (PL) SWITCH (CH) BREN (BG) IUCC (IL) and GRNET (GR) CYNET (CY) FCCN (PT) _GARR (IT) Janet (UK)

(40)

GÉANT deployment example

8 sites

Geneva (CH), Paris (FR), Madrid (ES), Milan (IT), Amsterdam (NL), Frankfurt (DE)

London (GB), Vienna (AT) for Internet2 and ESNet interdomain measurements Components BWCTL MP HADES HADES MA SQL MA

On-demand and scheduled

Includes early OWAMP functionality

(41)

GÉANT deployment example cont.

BWCTL

MP(scheduled)

(42)

Development status

(43)

perfSONAR MDM latest deliveries (1/2)

RRD MA 3.4 in unstable repository .deb and .rpm packages

The backend has changed to the relational database

To support the continuity of the service there are tools available that allow users to convert their old databaes to the new one Serves all the requests as the previous one

Installation guide covers both installation process and convert operations for both packages as well as provides the examples of using new database

BWCTL MP 0.53-4 in unstable repository Bug fixes reported after training

Internal performance improvements Lookup Service 1.6 in unstable repository

Simplified WebAdmin

Internal review of code and improvements Embeded eXist

(44)

perfSONAR MDM latest deliveries (2/2)

OWAMP controller (not released, internal testing)

Allows measurement requests to HADES system over OWAMP protocol

HADES looks as the OWAMP server OWAMP MP 0.53 in unstable repository

Service to request on demand OWAMP measurement Data stored into SQL MA

perfsonarUI (web-based) Usability modifications Service status window Bug fixing

(45)

HADES new UI for configuration

45

Friendly interface for the installation and configuration of HADES.

The process of installation of HADES is easy to understand.

Reduction of the errors made in places where no changes are needed Adjustment of the specific resources that are needed for a HADES installation

(46)

Other changes

Pending

Changes from perfSONAR MDM training comments

–

Installation documentation improvement and clarifications

–

BWCTL scheduler scripts

–

Service configuration documentation improvements

–

Fixing repositories for RHEL

–

Fixing perfsonarUI

–

Clarification of OWAMP components concept

Lookup service improvements

–

Interoperability

–

UI cooperation

Target supported operating systems: Debian 6, RHEL 5

(47)

perfSONAR MDM roadmap

(48)

perfSONAR MDM roadmap (1/2)

(49)

perfSONAR MDM roadmap (2/2)

(50)

Information sources

(51)

Multi-Domain Service Desk

The Multi-Domain Service Desk provides first level support for

MDS related incidents raised by NREN NOC staff. The calls

placed to the MDSD by NRENs are logged into the incident

management system

If the calls can be resolved by the MDSD, the ticket will indicate

the steps taken to resolve the incident.

MDSD provides first point of contact for perfSONAR MDM

service users

(52)

(53)

(54)

(55)

(56)

Thank you

(57)

Live deployment of BWCTL MP

From stable repository Debian 6 Prerequisities Repository Installation Installation check Tests Local script perfsonarUI 57
