cf push: Push your Scala/Play

apps to Cloud Foundry

(2)

• Rags (not to Riches) and work for EMC CODE

• Middleware and Application programmer

• Architect and Evangelist

• Part time teaching at UML and writing at InfoQ

• Philosophy: It’s better to have an unanswered question than a

unquestioned answer

(3)

• Overview and Architecture

• Applications and Services

• Evolving Data Schemas

• Demos

• Resources and Summary

Agenda

(4)

Business Expectations Exceed IT

Capabilities

Cloud

IT Technology Eras

Mainframe

Client-Server

The exponential

_{increase in}

business

expectations is

unsustainable for

IT

MILLIONS OF

APPS BILLIONS

OF USERS

ABILITY OF IT TO

DELIVER S/W

BUSINESS

EXPECTATIONS

(5)

PaaS (On Premise & Off Premise)

Traditional IT

Storage

Servers

Networking

O/S

Middleware

Virtualization

Data

Applications

Runtime

Yo

u

M

an

age

O/S

IaaS

Storage

Servers

Networking

Middleware

Virtualization

Data

Applications

Runtime

Yo

u

M

an

age

IaaS

Business Value, Agility &

Cost Savings

PaaS

Storage

Servers

Networking

Middleware

Virtualization

Data

Applications

Runtime

O/S

Cloud

Foundry

+

OpenStack

Yo

u

M

an

age

(6)

• Microservices: a radical departure from traditional

monolithic applications

• 12 Factor Linux applications

• In both cases, the enterprise is

forced to “think different.”

(7)

Provision VM

Install Applica;on Run;me

Deploy Applica;on

Conﬁgure Load Balancer

Conﬁgure Service Connec;vity

Conﬁgure Firewall

cf push

Conﬁgure SSL Termina;on

cf bind-‐service

Application Development – IaaS vs PaaS

(8)

Cloud Foundry

Enterprise Capabilities At A Glance

Application Containerization

Monitoring, Logs

and Performance

as-a-Service

Integrated

Services: Data, Mobile,

Platform

High Availability and

Scaling

Network Isolation

and Security

Groups

Automatic Middleware

Configuration

Simple

_{Service Binding}

Automatic IaaS

Provisioning

Roles and Policy

Management

(9)

Removing Developer and Operator

Constrains

BUILD

APPLICATION

PUSH FIRST

RELEASE

MAINTAIN

APPLICATION

UPDATE

APPLICATIONS

RETIRE

APPLICATIONS

• Auto-detect frameworks

• Link to PaaS

• Self-service deploy

• Dynamic routing

• CI/CD

• Elastic scale

• Integrated HA

• Autoscaling and APM

• Log aggregation

• Policy and Auth

• A/B versioning

• Live upgrades

• Self-service

(10)

Gold

Silver

(11)

Cloud Foundry Runtime Architecture

Ops Manager UI

Ops Manager Director

Operations Manager

Service

Service Broker

Service Nodes

Service Broker

Service Nodes

Service

App Log Aggregator

Login Server

Dynamic Router

Cloud Controller

UAA

Health Manager

DEA Pool

Messaging (NATS)

Apps

Metrics Collec;on

Apps

HA Proxy LB

Elastic Runtime

(12)

BOSH

DB

Blob

_Store

Worker

NATS

Health

_Monitor

CPI

Director

CLI

Inner

shell

When you deploy Cloud Foundry the

following sequence of steps occur:

1.  Target a BOSH director using CLI

2.  Upload a Stemcell

3.  Get a Release from a repo

4.  Create a deployment manifest

5.  BOSH Deploy Cloud Foundry:

• Prepare deployment

• Compile packages

• Create and bind VMs

• Pull in job configurations

• Create needed job

(13)

Message Bus

Behind the Scenes - BOSH

IaaS

DB

BOSH

Director

Blobs

Health

Monitor

Deploy

Worker VMs

Messaging

Target VM

Health Manager

Target VM

Cloud Controller

Target VM

PaaS

Ops

Deployment

•  Packages

•  Blobs

•  Source

•  Jobs

•  Manifest

(14)

(15)

Stage an

Application

Ro

ute

r

Blobstore

DB

DEA

Detect

Compile

Upload

No

Yes

System

Buildpacks

+ =

Cloud

Controller

App

Ops

Pivotal CF

Elas;c Run;me

(16)

Application Deployment Overview

App

Ops

①

 

Upload app

bits and

metadata

push app

Ro

ute

r

②

Create and bind services

③

Stage application

④

Deploy application

Cloud Foundry

Blobstore

DB

Cloud

Controller

Service

Broker

Node(s)

DEA

+ app MD

+ =

Service

credentials

(17)

Creating and Binding a

Service

Ro

ute

r

_{Cloud
Foundry}

Run;me (ERS)

DB

Service

_credentials

reserve resources

create service

(HTTP)

create service

(HTTP)

bind service

(HTTP)

bind service

(HTTP)

obtain connection

data

CLI

Cloud

Controller

Service

Broker

Service

Data

App

Ops

(18)

DEA

Apps

Service Broker

Service Nodes

Cloud Controller

create

bind

Service Brokers generate

connection details and credentials

for managed services

CC encrypts and stores

credentials in CCDB

Credentials are exposed to bound

applications via

VCAP_SERVICES environment

connect

(19)

VCAP_SERVICES

environment variable is

visible only to members

of the org and space

containing the service

instance

VCAP_SERVICES=" {

"p-mysql": [

{

"name": "music-db",

"label": "p-mysql",

"tags": [ "mysql", "relational” ],

"plan": "100mb-dev",

"credentials": {

"hostname": "192.168.1.147",

"port": 3306,

"name": "cf_aceae021_7f27_48db_9844_d7c151f29195",

"username": "Tr12ZI4hPu4OPJPY",

"password": "fuTWBqpGeyvv0qge",

"uri": "mysql://Tr12ZI4hPu4OPJPY:[email protected]:3306/

cf_aceae021_7f27_48db_9844_d7c151f29195?reconnect=true”

}

]

} "

Managed Services

(20)

(21)

• Scripts written in plain old SQL

• Evolutions to default database at conf/evolutions/

default(1.sql, 2.sql, …)!

# --- !Ups!

CREATE TABLE User (!

);!

# --- !Downs!

DROP TABLE User;!

(22)

(23)

(24)

 

Sign up for the CF and BOSH

mailing lists

.

 

Install Cloud Foundry on OpenStack (

blog out soon

)

 

Learn how to write

12-factor

applications.

 

Free workshop and

roadshows

. CFAD!

 

Register for the next

Cloud Foundry Summit

(May)

 

Try out Pivotal Web Services (

http://run.pivotal.io

)

(25)

https://ace.ng.bluemix.net/

http://www.hpcloud.com/products-services/

application-paas

http://www.anynines.com/

https://run.pivotal.io/
