Recommended Land Pattern: [mm]

(1)

Dimensions: [mm]

2 ,3

±

0 ,1

7

2 ,4

±

0 ,2

5 4,32 ±0,25

1,14 ±0,4

5,4 ±0,2

2 ,0

8 ±

0 ,1

2 Cathode Band

3 ,6

2 ±

0 ,3

2 Scale - 5:1

Product Marking:

Recommended Land Pattern: [mm]

2 ,3

2,2

6,8

2,3

Scale - 5:1

Schematic:

Cathode

Anode

Electrical Properties:

Properties

Test conditions

Value

Unit

Tol.

DC Operating Voltage

V

DC

20 V

max.

(Reverse) Breakdown Voltage

V

BR

1 mA

23.35 V

±5%

Clamping Voltage

V

Clamp

I

PEAK

32.4 V

max.

(Reverse) Peak Pulse Current

I

Peak

10/1000 µs

18.6 A

max.

(Forward) Peak Pulse Current

1)

I

Peak

100 A

max.

Leakage Current

I

Leak

V

DC

1 µA

max.

Steady State Power Dissipation

P

Diss

T

A

= 50 °C

5 W

max.

Power Dissipation

2)

P

Diss

10/1000 µs

600 W

max.

Polarity

Unidirectional

1)

8.3 ms single half-sine wave or equivalent square wave. Duty cycle = 4 pulses per minute

2)

Mounted on 5.0 mm x 5.0 mm (0.03 mm thick) Copper Pads to each terminal

Certification:

RoHS Approval

Compliant [2011/65/EU&2015/863]

REACh Approval

Conform or declared [(EC)1907/2006]

Halogen Free

Conform[JEDEC JS709B]

Halogen Free

Conform [IEC 61249-2-21]

UL Approval

UL497B: E478010, UL 1449: E332875

Plastic Housing Flammability

Rating

UL94 V-0

General Information:

It is recommended that the temperature of the component does not exceed +150°C under worst

case conditions

Operating Temperature

-65 up to +150 °C

Storage Conditions (in original

packaging)

< 40 °C ; < 75 % RH

Moisture Sensitivity Level (MSL)

1

(2)

Maximum Peak Pulse Power Rating

0.1

1.0

10.0

100.0

1

10

100 1000

P

ow

er

[k

W

]

Pulse Width [µs]

Peak Pulse Power and Current Derating

0

10

20

30

40

50

60

70

80

90

100

0

50

100

150 Der

ati

ng

[%]

Ambient Temperature [°C]

Würth Elektronik eiSos GmbH & Co. KG EMC & Inductive Solutions Max-Eyth-Str. 1 74638 Waldenburg Germany Tel. +49 (0) 79 42 945 - 0 www.we-online.com [email protected]

CHECKED REVISION DATE (YYYY-MM-DD) GENERAL TOLERANCE PROJECTION METHOD

RoD

001.001 2020-05-11

DIN ISO 2768-1m

DESCRIPTION

WE-TVSP Power TVS Diode

ORDER CODE

824520201

SIZE/TYPE BUSINESS UNIT STATUS PAGE

DO-214AA

eiSos

Valid

2/8

(3)

Steady State Power Dissipation Derating

0

1

2

3

4

5

6

0

50

100

150 P

ow

er

[W

]

Ambient Temperature [°C]

Maximum Non-Repetitive Forward Surge Current

0

20

40

60

80

100

120

1

10

100 Cur

ren

t

[A

]

Number of Cycles at 60 Hz

(4)

Typical Junction Capacitance

1

10

100

1.000

10.000

1

10

100 1000

Capa

c

itan

c

e

[pF]

Reverse Breakdown Voltage [V]

V = 0V

V = VDC

RoD

001.001 2020-05-11

DIN ISO 2768-1m

DESCRIPTION

WE-TVSP Power TVS Diode

ORDER CODE

824520201

DO-214AA

eiSos

Valid

4/8

(5)

Packaging Specification - Tape and Reel: [mm]

End

Feeding direction

_Start

F

E

2 E

1 W

B

0 P2

P0

D0

D1

T

K0

T1

T2

Carrier Tape

Cover Tape

No Component

min. 160mm

Components

No Component

min. 100mm

Cover Tape

min. 400mm

A0

P1

Top Cover

Tape

A

Packaging is referred to the international standard IEC 60286-3:2019

Tape Type

A0

_(mm)

B0

_(mm)

W

_(mm)

T

T1

_(mm)

T2

_(mm)

K0

_(mm)

P0

_(mm)

P1

_(mm)

P2

_(mm)

D0

_(mm)

D1

_(mm)

E1

_(mm)

E2

_(mm)

F

_(mm)

Material

Qty.

_(pcs.)

typ.

+0,3/ -0,1

ref.

max.

typ.

±0,1

±0,05

+0,1/ -0,0

min.

±0,1

min.

±0,05

2a

3,86

5,65

12,00

0,25

0,10

2,75

4,00

8,00

2,00

1,50

1,75

10,25

5,50

Polystyrene

500 B

D

C

A

N

W3

W2

W1

close to center

detail B

Cover Tape

Chip Cavity

Sprocket Hole

Embossment

B

A

(mm)

B

(mm)

C

(mm)

D

(mm)

N

(mm)

W1

(mm)

W2

(mm)

W3

(mm)

W3

(mm)

Material

± 2,0

min.

+ 2,0

max.

min.

max.

(6)

Classification Reflow Profile for SMT components:

Time

Temperature

T

_p

t

_p

t

L

t

S

T

_{s max}

T

_{s min}

T

C

–5°C

T

_L

25 Time 25°C to Peak

Preheat Area

Max. Ramp Up Rate

Max. Ramp Down Rate

Classification Reflow Soldering Profile:

Profile Feature

Value

Preheat Temperature Min

T

s min

150 °C

Preheat Temperature Max

T

s max

200 °C

Preheat Time t

s

from T

s min

to T

s max

t

s

60 - 120 seconds

Ramp-up Rate (T

L

to T

P

)

3 °C/ second max.

Liquidous Temperature

T

L

217 °C

Time t

L

maintained above T

L

t

L

60 - 150 seconds

Peak package body temperature

T

p

T

p

≤ T

c

, see Table below

Time within 5°C of actual peak

temperature

t

p

20 - 30 seconds

Ramp-down Rate (T

P

to T

L

)

6 °C/ second max.

Time 25°C to peak temperature

8 minutes max.

refer to IPC/ JEDEC J-STD-020E

Package Classification Reflow Temperature (T

c

):

Properties

Volume mm³

_<350

Volume mm³

_350-2000

Volume mm³

_>2000

PB-Free Assembly | Package Thickness

< 1.6 mm

260 °C

PB-Free Assembly | Package Thickness

1.6 mm - 2.5 mm

260 °C

250 °C

245 °C

PB-Free Assembly | Package Thickness

≥ 2.5 mm

250 °C

245 °C

refer to IPC/ JEDEC J-STD-020E

RoD

001.001 2020-05-11

DIN ISO 2768-1m

DESCRIPTION

WE-TVSP Power TVS Diode

ORDER CODE

824520201

DO-214AA

eiSos

Valid

6/8
