JULY 2015 | Volume 94 Number 7 HydrocarbonProcessing.com
SPECIAL REPORT: REFINERY OF THE FUTURE
33 European refiner revamps delayed coker to meet Euro 5 specifications C. Bolohan, L. Manafu and J. D. Ward
39 Use advanced automation and project management to simplify refinery construction
E. Spiropoulos
43 Turning a Tier 3 profit J. Esteban and M. Hartman
49 How to cost-effectively adapt to a tight oil world D. Lindsay, M. Griffiths, A. Sabitov, D. Sioui and B. Glover BONUS REPORT: LNG
57 US liquefaction projects to drive global expansion of LNG trade
A. Slaughter
REGIONAL REPORT
59 China’s ‘energy revolution’ strives for sustainable growth
M. Rhodes
PROJECT MANAGEMENT
69 Better risk-management methods ensure project success C. Rentschler and G. Shahani
GAS TREATING
73 Improve LPG treating via advanced amine-solvent recovery technologies D. Engel, H. Burns and B. Spooner
MANAGEMENT
79 A data-driven, experience-based approach to workforce optimization
B. Glasscock
PROCESS AUTOMATION
82 Automate environmental monitoring at petrochemical plants with LIMS
T. Meek
Cover Image: Klesch Group’s Heide refinery, located north of Hamburg, Germany, is a distillates-focused plant. It produces mainly diesel, heating oil, jet fuel and some gasoline and petrochemicals. While servicing the inland markets, the refinery is well integrated with the local industrial community of Brunsbüttel, with access to road and rail networks and local pipelines. Photo courtesy of Photo Raffinerie Heide.
DEPARTMENTS 10 News 17 Industry Metrics 84 Innovations 86 Marketplace 88 Advertiser Index 89 Events 90 People COLUMNS 9 Editorial Comment
Courage amid challenge and change
19 Reliability
Trends from the 2015 AFPM Maintenance and Reliability Conference
21 Automation Strategies
Safety lifecycle management challenges in hydrocarbon processing plants
23 Global
Investment in Egypt’s downstream on the rise
25 Petrochemicals
Higher international sales boost 2015 earnings above forecast for many chemical leaders
27 Engineering Case Histories
Case 85: Learnings on hydraulically fitted hubs
29 Viewpoint
Advice for the downstream: Keep the faith
