LIFECYCLE-BASED DISCRETIZATION OF
BRIDGE PERFORMANCE INDICATORS
Dimosthenis Kifokeris
– Ph.D. candidate, Aristotle University of Thessaloniki,
• Damage degree, frequency, response, wearout, settlement and
foundation deficiency of the constituent bridge parts due to SSI
(soil-structure interaction) during ground motions
• Ductility demand
• Fragility and vulnerability curves, most often interconnected
• Stiffness
• Seismic resilience
The above were the results of a targeted and filtered literature review of
the recent (2006-2016) Greek research output
All BPIs were aggregately researched under the light of the above
performance indices categories. Hence, each one is simultaneously
part of every indices group.
• Project performance: the level of the desirable success in meeting
the stated technical performance specifications and the mission to
be performed
• Success determinants of project performance:
(i) Cost of completion
(ii) Time of completion
(iii) Quality of deliverables
• Additional determinants (considered separately or as aspects of the
quality of the deliverables): safety, client satisfaction etc.
• Constructability: the optimum use of construction knowledge and
experience in planning, design, procurement and field operations to
achieve overall project objectives
• Sustainability: the promotion of the development that meets the
needs of the present without compromising the ability of future
generations to achieve their own
• Risk analysis: the collective methodology of risk assessment,
through a systematic process of decision-making in order to accept
a known or assumed risk and/or reducing the harmful consequences
or probability of occurrence of the risk
LIFECYCLE MANAGEMENT RELATED
NOTIONS
Constructability, sustainability and risk analysis, separately and in
combination, aim for the achievement of the highest level of project
performance by optimizing the success determinants.
Each utilizes distinct cognitive, methodological and mathematical tools
and applications.
For a holistic lifecycle management, from the feasibility study of a
project until its end of life, all three should be integrated, interconnected
and facilitated.
RELATED NOTIONS AND LIFECYCLE
MANAGEMENT
•
Constructability
- implemented through 23
Constructability Concepts (CCs)
- pertains mainly the initiation,
execution and delivery phases
- extends in the use phase
•
Sustainability
- implemented through 32 economic
(EcSPI), 19 social (SoSPI) and 36
environmental (EnSPI) sustainability
performance indicators
- pertains all of the project lifecycle,
but more heavily the use and
end-of-life phases
•
Risk analysis
- performed through risk identification,
qualitative and/or quantitative
assessment, response and monitoring
- pertains all of the project lifecycle
• Each index encompasses all
the noted BPIs
• All BPIs should be checked
for the corresponding
lifecycle phases pertained by
the index and in conjunction
with the CCs and SPIs
• Where the indices overlap,
the corresponding BPIs
should be multiply checked
under the light of every index
• In the recent literature originating from Greek researchers, the most
commonly researched BPIs account mainly for the cost efficiency,
durability, safety, service life, serviceability and traffic safety of a
bridge
• A true holistic lifecycle management plan for bridges should
incorporate, interconnect and integrate the distinctive BPIs, grouped
under the corresponding performance indices, along with the SPIs,
CCs and risk analysis procedures
• The discretization and integration of BPIs, SPIs and CCs could
expand to cover more data and also include several types of new
indicators, towards the production of a general approach for
enhanced lifecycle management for bridges and the standardization
of bridge quality standards at the European level
[1] Anton De Wit, editor. Measuring project success: an illusion. Project Management Institute, Montreal, Canada, 1986.
[2] Anastasios Kotsoglou and Stavroula Pantazopoulou. Response simulation and seismic assessment of way overcrossings. Earthquake Engineering and Structural Dynamics, 39:991-1013, 2010.
[3] Anastasios G. Sextos, George E. Mylonakis and Elli-Konstantina V. Mylona. Rotational excitation of bridges supported on pile groups in soft or liquefiable soil deposits. Computers and Structures, 155: 54-66, 2015.
[4] Anastasios Sextos, Periklis Faraonis, Costas Papadimitriou and Panagiotis Panetsos. System identification of a R/C bridge based on ambient vibrations and 3D numerical simulations of the entire soil-structure system. In COMPDYN 2011, 3rd ECCOMAS Thematic Conference on Computational Methods in Structural Dynamics and Earthquake Engineering, Corfu, Greece, 25-28 May 2011.
[5] Andreas J. Kappos, M. Saiid Saiidi, M. Nuay Aydinoglu and Tatjana Isakovic, editors. Seismic design and assessment of bri dges. Springer Science and Business Media Dordrecht, Dordrecht, The Netherlands, 2012. [6] Construction Industry Institute (CII). Constructability: a primer. CII, The University of Texas at Austin, Austin, U.S.A., 1986.
[7] Christos Katsaras, Telemachos B. Panagiotakos, Basil Kolias. Effect of torsional stiffness of prestressed concrete box girders and uplift of abutment bearings on seismic performance of bridges. Bull Earthquake Engineering, 7:363-375, 2009.
[8] Demos C. Angelides. Project management and good technical and business practices. Journal of Management in Engineering, 15(3):78-88, 1999.
[9] Dimitrios Timosidis and Stavroula J. Pantazopoulou. Limit state model for R.C. bridge joints under seismic loading. Bull Earthquake Engineering, 5:391-423, 2007.
[10] Dimosthenis Kifokeris and Yiannis Xenidis.Towards the combination of risk analysis, constructability and sustainability forthe lifecycle management of construction projects. In IALCCE ’16 Fifth International Symposium on Life-Cycle Civil Engineering, forthcoming in 2016.
[11] George C. Manos, Konstantinos Katakalos and Vladimiros Kourtides. Cyclic behavior of a hybrid anchoring device enhancing the flexural capacity and ductility of an R/C bridge-type pier strengthened with CFRP sheets. Journal of Civil Engineering Research, 3(1):52-63, 2013.
[12] George C. Manos, Vladimiros Kourtides and Anastasios Sextos. Model bridge pier-foundation-soil interaction implementing in-situ / shear stack testing and numerical simulation. In The 14th World Conference on Earthquake Engineering, Beijing, China, 12-17 October 2008.
[13] Georgios Tsionis and Michael N. Fardis. Seismic fragility of concrete bridges with deck monolithically connected to the piers or supported on elastomeric bearings. In 15th World Conference on Earthquake Engineering, Lisbon, Portugal, 24-28 September 2012.
[14] Ioannis F. Moschonas and Andreas J. Kappos. Assessment of concrete bridges subjected to ground motion with an arbitrary angle of incidence: static and dynamic approach. Bull Earthquake Engineering, 11:581-605, 2013. [15] Ioannis F. Moschonas, Andreas J. Kappos, Panagiotis Panetsos, Vissarion Papadopoulos, Triantafyllos Makarios and Panos Thanopoulos. Seismic fragility curves for Greek bridges: methodology and case studies. Bull Earthquake Engineering, 7:439-468, 2009.
[16] Li-Yin Shen, Jian Li Hao, Vivian Wing-Yian Tam and Hong Yao. A checklist for assessing sustainability performance of construction projects. Journal of Civil Engineering and Management, 13(4):273-281, 2007. [17] Mekdam A. Nima. Constructability factors in the Malaysian construction industry. Ph.D. thesis, University Putra Malaysia, Putrajaya, Selangor, Malaysia, 2001.
[18] Michael N. Fardis and Georgios Tsionis. Eigenvalues and modes of distributed-mass symmetric multispan bridges with restrained ends for seismic response analysis. Engineering Structures, 52:141-149, 2013.
[19] Nikolaos Lesgidis, Oh-Sung Kwon and Anastasios Sextos. A time-domain seismic SSI analysis method for inelastic bridge structures through the use of a frequency-dependent lumped parameter model. Earthquake Engineering & Structural Dynamics, 44:2137-2156, 2015.
[20] Olympia Taskari and Anastasios Sextos. Multi-angle, multi-damage fragility curves for seismic assessment of bridges. Earthquake Engineering & Structural Dynamics, 44:2281-2301, 2015.
[21] Olympia Taskari and Anastasios Sextos. Probabilistic assessment of abutment-embankment stiffness and implications in the predicted performance of short bridges. Journal of Earthquake Engineering, 19:822-846, 2015. [22] Patrick T. I. Lam and Franky W. H. Wong. Improving building project performance: how buildability benchmarking can help. Construction Management and Economics, 27(1): 41-52, 2009.
[23] Philip B. Crosby, editor. Quality is free. McGraw-Hill, New York, U.S.A., 1979.
[24] Stylianos Farantakis, Anastasios Kotsoglou and Stavroula Pantazopoulou. Exploiting SSI to mitigate seismic demands in bridge piers. In Tenth U.S. National Conference on Earthquake Engineering – Frontiers of Earthquake Engineering , Anchorage, Alaska, July 21-25 2014.
[25] Stergios A. Mitoulis, Magda D. Titirla and Ioannis A. Tegos. A new earthquake resistant abutment as means to reduce the seismic demand ofa railway bridge. In 15th World Conference on Earthquake Engineering, Lisbon, Portugal, 24-28 September 2012.
[26] Sevasti D. Tegou, Stergios A. Mitoulis and Ioannis A. Tegos.An unconventional earthquake resistant abutment with transversely directed R/C walls. Engineering Structures, 32:3801-3816, 2010. [27] Stergios A. Mitoulis and Ioannis A. Tegos.An unconventional restraining system for limiting the seismic movements of isolated bridges. Engineering Structures, 32:1100-1112, 2010.
[28] Themelina S. Paraskeva, Andreas J. Kappos and Anastasios G. Sextos. Extension of modal pushover analysis to seismic assessment of bridges. Earthquake Engineering and Structural Dynamics, 35:1269-1293, 2006. [29] Vijay P. Singh, Sharad K. Jain and Aditya Tyagi. Risk and reliability analysis: a handbook for Civil and Environmental Engineers. The American Society of Civil Engineers (ASCE) Publications, Reston, U.S.A., 2007. [30] Vasileios G. Pilitsis, Vassilis K. Papanikolaou, Ioannis A. Tegos and Kosmas-Athanasios Stylianidis. A novel mechanism for restraining seismic actions in ductile bridges: analytical modeling and experimental verification. In COMPDYN 2015, 5thECCOMAS Thematic Conference on [31] Computational Methods in Structural Dynamics and Earthquake Engineering, Crete Island, Greece, 25-27 May 2015.
