Modbus - Interface Report Generator

(1)

Floating Point Example Modbus Holding Register 40401, 40402

40402 Bit 15 - MSB Sign Bit

Bit 14 Exponent MSB

Bit 7 Exponent LSB

Bit 6 Fraction MSB [Bit 22]

Bit 0 - LSB Fraction Bit 16

40401 Bit 15 - MSB Fraction Bit 15

Bit 0 - LSB Fraction LSB [Bit 0]

Modbus H Access Solar Tag Name Solar Tag Description Active State

40001 Read Bit 0 - LSB AL_Controller_Battery_Low Controller Battery Voltage Low 1

Read Bit 1 AL_Forces_Enabled Forces Enabled 1

Read Bit 2 AL_Forces_Installed Forces Installed 1

Read Bit 3 AL_Logic_Fault Controller Logic Fault 1

Read Bit 4 AL_OSM_STest_Req Backup Overspeed Monitor System Test Required 1

Read Bit 5 AL_OSM_Tracking_Error Backup Overspeed Monitor Speed Tracking Error 1

Read Bit 6 AL_Task_Overlap Controller Task Overlap Time Exceeded 1

Read Bit 7 AL_Turb_CNet_Ch_A_Fault Turbine ControlNet Channel A Fault 1

Read Bit 8 AL_Turb_CNet_Ch_B_Fault Turbine ControlNet Channel B Fault 1

Read Bit 1 AL_ZF2291_Calib_Fault Node 29 XM-Node 1 Calibration Fault 1

Read Bit 2 AL_ZF2291_Ch0_Fault Node 29 XM-Node 1 Channel 0 Fault 1

Read Bit 3 AL_ZF2291_Ch1_Fault Node 29 XM-Node 1 Channel 1 Fault 1

Read Bit 4 AL_ZF2291_Comm_Fault Node 29 XM-Node 1 Communication Fault 1

Read Bit 5 AL_ZF2291_IEPE_Pwr_Fault Node 29 XM-Node 1 IEPE Module Power Fault 1

Read Bit 6 AL_ZF2291_Internal_Pwr_Fault Node 29 XM-Node 1 Internal Power Fault 1

Read Bit 7 AL_ZF2291_In_Program_Mode Node 29 XM-Node 1 Module in Program Mode 1

Read Bit 8 AL_ZF2291_Mod_Fault Node 29 XM-Node 1 Module Fault 1

Read Bit 9 AL_ZF2291_Mod_Pwr_Fault Node 29 XM-Node 1 Module Power Fault 1

Read Bit 10 AL_B799_Fail Turbine Air Inlet Filter Blower Motor Failure 1

Read Bit 11 AL_BC520_Fail 120 Vdc Battery Charger Failure 1

Read Bit 12 AL_Supply_Voltage_24Vdc_H Control System 24 Vdc Supply Voltage High 1

Read Bit 13 AL_Supply_Voltage_24Vdc_L Control System 24 Vdc Supply Voltage Low 1

Read Bit 14 AL_TPD358_Fail Turbine Air Inlet Duct DP Transmitter Failure 1

Read Bit 15 MSB AL_TPD799_H- Turbine Air Inlet Filter DP High 1

40008 Read Bit 0 LSB- AL_B596_1_Fail Turbine Enclosure Vent Fan 1 Failure 1

Read Bit 1 AL_B596_2_Fail Turbine Enclosure Vent Fan 2 Failure 1

Read Bit 2 AL_Encl_Door_Open Enclosure Door(s) Open 1

Read Bit 3 AL_Encl_Fire Enclosure Fire Alarm 1 Out of N Voting Flame Detector 1

Read Bit 4 AL_Encl_Fire_R_Congfiguration_Fault QPR EDIO Configuration Fault 1

Read Bit 5 AL_Encl_Fire_Sys_Inhibited Fire System Inhibited, Enclosure Unprotected 1

Read Bit 6 AL_Encl_Fire_Sys_Manual_Release Enclosure Fire System Manual Discharge Activated 1

Read Bit 7 AL_Encl_Fire_Sys_Trouble Enclosure Fire System Trouble 1

Read Bit 8 AL_Encl_Gas_LEL_H Turbine Enclosure Combustible Gas Level High 1

Read Bit 9 AL_Fire_Damper1_Closed Enclosure Fire Damper #1 Closed 1

Read Bit 10 AL_Fire_Damper2_Closed Enclosure Fire Damper #2 Closed 1

Read Bit 11 AL_Gas_Sensor_Config_Error Gas Sensor Configuration Error 1

Read Bit 12 AL_N2_Rack1_Press_L Nitrogen Rack 1 Pressure Low 1

Read Bit 13 AL_RT396_H Turbine Enclosure Temperature High 1

Read Bit 14 AL_TPD396_2_L Turbine Enclosure Pressure Low 1

Read Bit 15 - MSB AL_TPD396_2_LL Turbine Enclosure Pressure Low while Fire System is Inhibited 1

40009 Read Bit 0 - LSB AL_WM_Rack1_Not_Released Water Mist Rack 1 Never Released 1

Read Bit 1 AL_XA5961 Enclosure Vent Fan Tripped1 1

Read Bit 2 AL_XA5962 Enclosure Vent Fan Tripped2 1

Read Bit 3 AL_Z298_1_Configuration_Fail Controller Failed to Download Configuration Parameters to Quantum Premier 1

Read Bit 4 AL_Z298_1_Node_Fault Quantum Premier CNet Node Fault 1

Read Bit 5 AL_Z298_1_Read_Fail Quantum Premier Read Failure 1

Read Bit 6 AL_Z298_1_Water_Mist_Fault Quantum Premier Enclosure Water Mist System Fault 1

Read Bit 7 AL_Cpsr_Fail_To_Load Compressor Failed to Load 1

Read Bit 8 AL_PAH520107 Stage Suction 2 Gas Pressure High 1

Read Bit 9 AL_PAH520117 Stage 3 Discharge Gas Pressure High 1

Read Bit 10 AL_PAH520121 Stage Discharge 2 Gas Pressure High 1

Read Bit 11 AL_PAHH520122 Stage 3 Suction Gas Pressure High Shutdown Exceeded 1

Read Bit 12 AL_PAL520107 Stage Suction 2 Gas Pressure Low 1

Read Bit 13 AL_PAL520117 Stage 3 Discharge Gas Pressure Low 1

Read Bit 14 AL_PAL520121 Stage 2 Discharge Gas Pressure Low 1

Read Bit 15 - MSBA L_PALL520105 Stage 1 Suction Gas Pressure Low Shutdown Exceeded 1

40010 Read Bit 0 - LSB AL_PALL520120 Stage 2 Suction Gas Pressure Low Shutdown Exceeded 1

Read Bit 1 AL_PALL520121 Stage 2 Discharge Gas Pressure Low Shutdown Exceeded 1

Read Bit 2 AL_PALL520123 Stage 3 Suction Gas Pressure Low Shutdown Exceeded 1

Read Bit 3 AL_TAH520102 Stage Suction 1 Gas Temperature High 1

Read Bit 5 AL_TAH520108 Stage Discharge 2 Temperature High 1

Read Bit 7 AL_TAH520116 Stage 3 Discharge Gas Temperature High 1

Read Bit 8 AL_TAHH520110 Stage 2 Discharge Temperature High Shutdown Exceeded 1

Read Bit 9 AL_TAHH520117 Stage 3 Discharge Gas Temperature High Shutdown Exceeded 1

Read Bit 10 AL_FAH5201125 2BCL458 Discharge Primary Vent Flow High 1

Read Bit 11 AL_FAH5201126 2BCL458 Suction Primary Seal Flow High 1

Read Bit 12 AL_FAH5201129 MCL525 Discharge Seal Vent Flow High 1

Read Bit 13 AL_FAH5201130 MCL525 Suction Seal Vent Flow High 1

Read Bit 14 AL_FAL5201125 2BCL458 Discharge Primary Vent Flow Low 1

Read Bit 15 MSBA L_FAL5201126- 2BCL458 Suction Primary Vent Flow Low 1

40011 Read Bit 0 LSB- AL_FAL5201129 MCL525 Discharge Seal Vent Flow Low 1

Read Bit 1 AL_FAL5201130 MCL525 Suction Seal Vent Flow Low 1

Read Bit 2 AL_Man_Seal_Duration_Expired Manual Seal System Duration Too Long 1

Read Bit 3 AL_PDAH5201142 Seal Gas Filter DP High 1

Read Bit 4 AL_PDAL5201137 2BCL458 Balance Line DP Low 1

Read Bit 5 AL_PDAL5201139 MCL525 Balance Line DP Low 1

Read Bit 6 AL_PDIT5201142_Fail Seal Gas Filter DP Transmitter Failure 1

Read Bit 7 AL_PIT5201123_L Compressor N2 Inlet Pressure Low 1

Read Bit 8 AL_PIT5201137_Fail 2BCL458 Balance Line DP Xmtr Failed 1

Read Bit 9 AL_PDIT5201139_Fail MCL525 Balance Line DP Xmtr Failed 1

Read Bit 10 AL_SSV5201145_Cmd_Disagree Seal Gas Isolation Valve Command Disagree 1

Read Bit 11 AL_TAL5201136 2BCL458 Internal Process Gas Temperature Low 1

Read Bit 12 AL_TAL5201137 MCL525 Internal Process Gas Temperature Low 1

Read Bit 13 AL_Unexpected_Case_Pressure Unexpected Case Pressure Alarm 1

Read Bit 15 - MSBA L_CCC_Xmit_Fail CCC Surge Controller Transmitter Fault 1

Serial / Modbus - Report Generator -Version 2.0.3.0

C:\Jobs\C2750\MM01264\RSLogix\0002_999\PDC2750_MM01264_0002_999.ACD Initial Composite Software Revision = 342

(2)

1/15/2013 10:04:09 AM

40012 Read Bit LSB- 0 AL_FAH5201011 Stage Suction 1 Flow DP High 1

Read Bit 1 AL_FAH5201031 Stage Suction 2 Flow DP High 1

Read Bit 2 AL_FAH5201051 Stage Suction 3 Flow DP High 1

Read Bit 3 AL_FAL5201011 Stage Suction 1 Flow DP Low 1

Read Bit 6 AL_Stg_1_Pos_Dev Stage 1 Anti-Surge Valve Position Deviation 1

Read Bit 7 AL_Stg_1_Safety Stage Surge 1 Safety On 1

Read Bit 12 AL_BPA520701 Blowdown Pressure 1

Read Bit 13 AL_PDAH520301 Stage Inlet 2 Valve DP High 1

Read Bit 14 AL_PDAH520501 Associated Gas Inlet Valve DP High 1

Read Bit 15 - MSB AL_PDIT520301_Fail Stage 2 Inlet Valve Differential Pressure Transmitter Fail 1

40013 Read Bit 0 - LSB AL_PDIT520501_Fail Associated Gas Inlet Valve Differential Pressure Transmitter Fail 1

Read Bit 1 AL_SXA520204 Stage Inlet 1 Valve Partial Stroke 1

Read Bit 2 AL_SXA520303 Stage Inlet 2 Valve Partial Stroke 1

Read Bit 3 AL_SXA520503 Associated Gas Inlet Valve Partial Stroke 1

Read Bit 4 AL_SXA520504 Lift Gas Inlet Valve Partial Stroke 1

Read Bit 5 AL_SXA520506 Associated Gas Loading Valve Partial Stroke 1

Read Bit 6 AL_SXA520703 Discharge Valve Partial Stroke 1

Read Bit 7 AL_EGV339_FC_Fail Guide Vane Actuator Force Transmitter Failure 1

Read Bit 8 AL_Gas_Fuel_Filter_DP_H Gas Fuel Filter DP High 1

Read Bit 9 AL_Gas_Vent_Fail Gas Fuel Vent Failure 1

Read Bit 10 AL_Gas_Vent_LP_Fail Gas Fuel Vent LP Failure 1

Read Bit 11 AL_Gas_Vlv_Ck_Fail_To_Press Gas Fuel Valve Check Primary Failure to Open or Secondary Leaking 1

Read Bit 12 AL_Gas_Vlv_Ck_Fuel_Press_L Gas Fuel Pressure Too Low to Check Valves 1

Read Bit 13 AL_Gas_Vlv_Ck_HP_Leak_Fail Gas Fuel Valve High Pressure Leak Check Failure 1

Read Bit 14 AL_Gas_Vlv_Ck_LP_Leak_Fail Gas Fuel Valve Low Pressure Leak Check Failure 1

Read Bit 15 - MSB AL_Gas_Vlv_Ck_Track_Check_Fail Main Gas Fuel Valve Tracking Check Failure 1

40014 Read Bit 0 - LSB AL_Gas_Vlv_Ck_Vent_Fail Gas Fuel Vent Valve Check Failure 1

Read Bit 1 AL_GV_Force_H Guide Vane Actuator Force High 1

Read Bit 2 AL_Pcd_Signal_Diff_H Gas Producer Compressor Discharge Pressure Signal Difference High 1

Read Bit 3 AL_RT339_Fail Turbine Air Inlet Temperature RTD Failure 1

Read Bit 4 AL_S349_Fail Flameout Switch Appears Failed Open 1

Read Bit 5 AL_S532_1_H Gas Fuel Filter Upper Sump Level High 1

Read Bit 6 AL_S532_2_H Gas Fuel Filter Lower Sump Level High 1

Read Bit 7 AL_T1_RTD_Fail_Hi_Emissions Low Emissions Mode Disabled due to T1 RTD Failure 1

Read Bit 8 AL_T5_Comp_Limit T5 Compensation Out of Limits 1

Read Bit 9 AL_T5_Delayed_H T5 Delayed Temperature High 1

Read Bit 10 AL_T5_Max_Ch T5 Thermocouple Reading High 1

Read Bit 11 AL_T5_TC_Fail T5 Thermocouple Failure 1

Read Bit 12 AL_TP342_1_H Gas Fuel Shutoff Valves Pressure Alarm 1

Read Bit 13 AL_TP349_2_Fail Gas Producer Compressor Discharge Pressure Transmitter #2 Failure 1

Read Bit 14 AL_TP349_Fail Gas Producer Compressor Discharge Pressure Transmitter Failure 1

Read Bit 15 MSB AL_TP386_1_H- Gas Fuel Supply Pressure High 1

40015 Read Bit 0 LSB- AL_TPD532_1_Fail Gas Fuel Filter DP Transmitter Failure 1

Read Bit 1 AL_XM_BAM_Band0_Peak_H XM BAM Band 0 (10-100 Hz) Max Peak Amplitude High 1

Read Bit 4 AL_XM_BAM_Band3_Peak_H XM BAM Band 3 (750-1k Hz) Max Peak Amplitude High 1

Read Bit 5 AL_XM_BAM_Signal_Fail Burner Acoustic Monitor Signal Failure From XM System 1

Read Bit 6 AL_B330_Temp_H Starter Motor Temperature High 1

Read Bit 7 AL_Ngp_Slow_Roll_Speed_L Ngp Slow Roll Speed Low 1

Read Bit 8 AL_Power_Turbine_Spinning Power Turbine Not Stopped 1

Read Bit 9 AL_Slow_Roll_Interrupted Slow Roll Sequence Interrupted Before Completion 1

Read Bit 10 AL_VFD430_Config_Fail Start VFD Configuration Failure 1

Read Bit 11 AL_VFD430_Fault Start VFD Fault 1

Read Bit 12 AL_VFD430_Node_Fault Start VFD Turbine CNet Node Fault 1

Read Bit 13 AL_B320_1_Fail Main Lube Oil Pump Failure1 1

Read Bit 14 AL_B320_1_Temp_H Lube Pump 1 Motor Temperature High 1

Read Bit 15 MSB AL_B320_2_Fail- Main Lube Oil Pump Failure2 1

40016 Read Bit 0 - LSB AL_B320_2_Temp_H Lube Pump 2 Motor Temperature High 1

Read Bit 1 AL_Backup_Lube_Oil_Pump_Test_Fail Backup Lube Oil Pump Test Failure 1

Read Bit 2 AL_BU_Sys_Relay_Failure Backup System Relay Failure. S HUTDOWN to follow if failure not corrected. 1

Read Bit 3 AL_Fire_Post_Lube Post Lube Resumed With Fire Detected 1

Read Bit 4 AL_RT380_H Lube Oil Header Temperature High 1

Read Bit 5 AL_RT380_L Lube Oil Header Temperature Low 1

Read Bit 6 AL_RT380_LL Lube Oil Header Temperature Low, Start Delayed For Warmup 1

Read Bit 7 AL_RT390_Fail Lube Oil Tank Temperature RTD Failure 1

Read Bit 8 AL_S322_3_Fail AC Lube Oil Pump #1 Discharge Pressure Switch Failure 1

Read Bit 9 AL_S322_4_Fail AC Lube Oil Pump #2 Discharge Pressure Switch Failure 1

Read Bit 10 AL_S322_5_Fail Backup Lube Oil Pump Discharge Pressure Switch Failure 1

Read Bit 11 AL_S598_1_H Lube Oil Cooler Fan Vibration 1 High 1

Read Bit 14 AL_TL388_1_H Lube Oil Tank Level High 1

Read Bit MSB AL_TL388_1_L15 - Lube Oil Tank Level Low 1

40017 Read Bit LSB- 0 AL_TP380_H Lube Oil Header Pressure High 1

Read Bit 1 AL_TP380_L Lube Oil Header Pressure Low 1

Read Bit 2 AL_TP324_H Lube Oil Tank Press High 1

Read Bit 3 AL_TPD397_Fail Lube Oil Filter DP Transmitter Failure 1

Read Bit 4 AL_TPD397_H Lube Oil Filter DP High 1

Read Bit 5 AL_VFD420_1_Config_Fail Lube Pump VFD Parameter Configuration Failure 1

Read Bit 6 AL_VFD420_1_Fault Lube Pump #1 VFD Fault 1

Read Bit 7 AL_VFD420_1_Hardwire_Fail Lube Pump #1 VFD Hardwire Failure 1

Read Bit 8 AL_VFD420_1_Node_Fault Lube Pump #1 VFD CNet Node Fault 1

Read Bit 9 AL_VFD420_2_Config_Fail Lube Pump VFD Parameter Configuration Failure 1

Read Bit 10 AL_VFD420_2_Fault Lube Pump #2 VFD Fault 1

Read Bit 11 AL_VFD420_2_Hardwire_Fail Lube Pump #2 VFD Hardwire Failure 1

Read Bit 12 AL_VFD420_2_Node_Fault Lube Pump #2 VFD CNet Node Fault 1

Read Bit 13 AL_XA322 Backup Lube Pump Tripped 1

Read Bit 14 AL_XA391 Lube Oil Tank Heater Tripped 1

Read Bit MSB AL_XA598115 - Lube Oil Cooler Fan Trip1 1

40018 Read LSBBit - 0 AL_XA5982 Lube Oil Cooler Fan Trip2 1

Read Bit 1 AL_XA5983 Lube Oil Cooler Fan Trip3 1

Read Bit 2 AL_BN3500_FAIL BN3500 Vibration Monitor System Fault 1

Read Bit 3 AL_BN3500_H BN3500 Vibration Detected High Common Alarm 1

Read Bit 4 AL_Eng_Brg_1_Drn_Delta_Temp_H Engine Bearing 1 Drain Delta Temperature High 1

(3)

1/15/2013 10:04:09 AM

Read Bit 6 AL_Eng_Brg_4_5_Drn_Delta_Temp_H Engine Bearing 4&5 Drain Delta Temperature High 1

Read Bit 7 AL_Eng_GP_Thr_Brg_Delta_Temp_H Engine GP Thrust Bearing Delta Temperature High 1

Read Bit 8 AL_Eng_PT_Thr_Brg_Delta_Temp_H Engine PT Thrust Bearing Delta Temperature High 1

Read Bit 9 AL_RT320_H Engine PT Thrust Bearing Temperature High 1

Read Bit 10 AL_RT321_H Engine GP Thrust Bearing Temperature High 1

Read Bit 11 AL_TV351X_Fault Engine Bearing 1 X-Axis Radial Vibration Channel Fault 1

Read Bit 12 AL_TV351X_H Engine Bearing 1 X-Axis Radial Vibration High 1

Read Bit 13 AL_TV351Y_Fault Engine Bearing 1 Y-Axis Radial Vibration Channel Fault 1

Read Bit 14 AL_TV351Y_H Engine Bearing 1 Y-Axis Radial Vibration High 1

Read Bit 15 MSBA L_TV351Z_Fault- Engine GP Axial Vibration Channel Fault 1

40019 Read_Read _BitBit LSB- 0 ₁ AL_TV351Z_H_{AL_TV352X_Fault} Engine _EngineGP Axial _BearingDisplacement ₂_X-AxisHigh_Radial_Vibration_Channel_Fault 1 ₁

Read Bit 15 - MSBA L_TV355Y_Fault Engine Bearing 5 Y-Axis Radial Vibration Channel Fault 1

40020 Read Bit 0 - LSB AL_TV355Y_H Engine Bearing 5 Y-Axis Radial Vibration High 1

Read Bit 1 AL_TV355Z_Fault Engine PT Axial Vibration Channel Fault 1

Read Bit 2 AL_TV355Z_H Engine PT Axial Displacement High 1

Read Bit 3 AL_TE5201100A_H MCL525 DE Journal Bearing Temperature High 1

Read Bit 4 AL_TE5201100B_H MCL525 DE Journal Bearing Temperature High 1

Read Bit 5 AL_TE5201101A_H MCL525 NDE Journal Bearing Temperature High 1

Read Bit 6 AL_TE5201101B_H MCL525 NDE Journal Bearing Temperature High 1

Read Bit 7 AL_TE5201102A_H MCL525 NACT Thrust Bearing Temperature High 1

Read Bit 8 AL_TE5201102B_H MCL525 NACT Thrust Bearing Temperature High 1

Read Bit 9 AL_TE5201103_H MCL525 ACT Thrust Bearing Temperature High 1

Read Bit 10 AL_TE5201104_H MCL525 ACT Thrust Bearing Temperature High 1

Read Bit 11 AL_XE5201100X_Fault MCL525 DE X-Axis Radial Vibration Channel Fault 1

Read Bit 12 AL_XE5201100X_H MCL525 DE X-Axis Radial Vibration High 1

Read Bit 13 AL_XE5201100Y_Fault MCL525 DE Y-Axis Radial Vibration Channel Fault 1

Read Bit 14 AL_XE5201100Y_H MCL525 DE Y-Axis Radial Vibration High 1

Read Bit 15 - MSBA L_XE5201101X_Fault MCL525 NDE X-Axis Radial Vibration Channel Fault 1

40021 Read Bit 0 - LSB AL_XE5201101X_H MCL525 NDE X-Axis Radial Vibration High 1

Read Bit 1 AL_XE5201101Y_Fault MCL525 NDE Y-Axis Radial Vibration Channel Fault 1

Read Bit 2 AL_XE5201101Y_H MCL525 NDE Y-Axis Radial Vibration High 1

Read Bit 3 AL_ZE5201100A_Fault MCL525 Axial A Vibration Channel Fault 1

Read Bit 4 AL_ZE5201100A_H MCL525 Axial A Displacement High 1

Read Bit 5 AL_ZE5201100B_Fault MCL525 Axial B Vibration Channel Fault 1

Read Bit 6 AL_ZE5201100B_H MCL525 Axial B Displacement High 1

Read Bit 7 AL_TE5201105A_H 2BCL458 DE Journal Bearing Temperature High 1

Read Bit 8 AL_TE5201105B_H 2BCL458 DE Journal Bearing Temperature High 1

Read Bit 9 AL_TE5201106A_H 2BCL458 NDE Journal Bearing Temperature High 1

Read Bit 10 AL_TE5201106B_H 2BCL458 NDE Journal Bearing Temperature High 1

Read Bit 11 AL_TE5201107A_H 2BCL458 NACT Thrust Bearing Temperature High 1

Read Bit 12 AL_TE5201107B_H 2BCL458 NACT Thrust Bearing Temperature High 1

Read Bit 13 AL_TE5201108_H 2BCL458 ACT Thrust Bearing Temperature High 1

Read Bit 14 AL_TE5201109_H 2BCL458 ACT Thrust Bearing Temperature High 1

Read Bit 15 - MSBA L_XE5201102X_Fault 2BCL458 DE X-Axis Radial Vibration Channel Fault 1

40022 Read Bit 0 - LSB AL_XE5201102X_H 2BCL458 DE X-Axis Radial Vibration High 1

Read Bit 1 AL_XE5201102Y_Fault 2BCL458 DE Y-Axis Radial Vibration Channel Fault 1

Read Bit 2 AL_XE5201102Y_H 2BCL458 DE Y-Axis Radial Vibration High 1

Read Bit 3 AL_XE5201103X_Fault 2BCL458 NDE X-Axis Radial Vibration Channel Fault 1

Read Bit 4 AL_XE5201103X_H 2BCL458 NDE X-Axis Radial Vibration High 1

Read Bit 5 AL_XE5201103Y_Fault 2BCL458 NDE Y-Axis Radial Vibration Channel Fault 1

Read Bit 6 AL_XE5201103Y_H 2BCL458 NDE Y-Axis Radial Vibration High 1

Read Bit 7 AL_ZE5201101A_Fault 2BCL458 Axial A Vibration Channel Fault 1

Read Bit 8 AL_ZE5201101A_H 2BCL458 Axial A Displacement High 1

Read Bit 9 AL_ZE5201101B_Fault 2BCL458 Axial B Vibration Channel Fault 1

Read Bit 10 AL_ZE5201101B_H 2BCL458 Axial B Displacement High 1

Read Bit 11 AL_AIC5201103_H N2 Skid Oxygen Level High 1

Read Bit 12 AL_BPA520901 Fuel Skid Blowdown Pressure 1

Read Bit 13 AL_CEMS_Dilution CEMS Cabinet Low Dilution Air Detected 1

Read Bit 14 AL_CEMS_Fault CEMS System Fault 1

Read Bit 15 MSB AL_CEMS_Purge- CEMS Cabinet Purge Failure 1

40023 Read Bit LSB- 0 AL_FAH521101 Fuel Skid Outlet Flow DP High 1

Read Bit 1 AL_FAL521101 Fuel Skid Outlet Flow DP Low 1

Read Bit 2 AL_Fuel_Skid_Valve_Check Fuel Skid Valve Position Check Fail 1

Read Bit 3 AL_LAH520201 Stage Suction 1 KO Drum Level High 1

Read Bit 6 AL_LAH520701 Stage 3 Discharge KO Drum Level High 1

Read Bit 7 AL_LAH520901 Fuel Skid KO Drum Level High 1

Read Bit 8 AL_LAHH520502 Stage 3 Suction KO Drum Level High Shutdown Exceeded 1

Read Bit 9 AL_LAHH520702 Stage 3 Discharge KO Drum Level High Shutdown Exceeded 1

Read Bit 10 AL_LAL520201 Stage Suction 1 KO Drum Level Low 1

Read Bit 13 AL_LAL520701 Stage 3 Discharge KO Drum Level Low 1

Read Bit 14 AL_LAL520901 Fuel Skid KO Drum Level Low 1

Read Bit 15 MSB AL_LALL520203- Stage 1 Suction KO Drum Level Low 1

40024 Read Bit LSB0 - AL_LALL520303 Stage 2 Suction KO Drum Level Low 1

Read Bit 1 AL_LALL520503 Stage Suction 3 KO Drum Level Low 1

Read Bit 2 AL_LALL520703 Stage 3 Discharge KO Drum Level Low 1

Read Bit 3 AL_LALL520903 Fuel Skid KO Drum Level Low 1

Read Bit 4 AL_LSV520903_Reset Fuel Skid KO Drum Drain Valve Reset Request 1

Read Bit 5 AL_PAH521101 Fuel Skid Outlet Pressure High 1

Read Bit 6 AL_PAHH520702 Stage 3 Discharge KO Drum Outlet Pressure High Shutdown Exceeded 1

Read Bit 7 AL_PAHH520902 Fuel Skid Inlet Pressure High Shutdown Exceeded 1

Read Bit 8 AL_PAL5201167 N2 Backup Bottle Pressure Low 1

Read Bit 9 AL_PAL521101 Fuel Skid Outlet Pressure Low 1

Read Bit 10 AL_PALL520704 Stage 3 Discharge KO Drum Outlet Pressure Low Shutdown Exceeded 1

Read Bit 11 AL_PALL521102 Fuel Skid Outlet Pressure Low Shutdown Exceeded 1

(4)

1/15/2013 10:04:09 AM

Read Bit 13 AL_PDAH521001 Fuel Skid Filter DP High 1

Read Bit 14 AL_SSV520203_Cmd_Disagree Stage 1 Suction KO Drum Drain Valve Command Disagree 1

Read Bit 15 - MSB AL_SSV520505_Cmd_Disagree Stage 3 Suction KO Drum Drain Valve Command Disagree 1

40025 Read Bit 0 - LSB AL_SSV520704_Cmd_Disagree Seal Gas Isolation Valve Command Disagree 1

Read Bit 1 AL_SXA520102 N2 Feed Air Inlet Valve Partial Stroke 1

Read Bit 2 AL_SXA520103 Fuel Skid Outlet Valve Partial Stroke 1

Read Bit 3 AL_SXA520203 SSV-5202-03 Partial Stroke 1

Read Bit 6 AL_SXA520903 Fuel Skid KO Drum Drain Valve Partial Stroke 1

Read Bit 7 AL_SXA520904 Fuel Skid Inlet Partial Stroke 1

Read Bit 8 AL_SXA521101 Fuel Skid Bypass Valve Partial Stroke 1

Read Bit 9 AL_TAH520401 Stage Aftercooler 2 Temperature High 1

Read Bit 10 AL_TAH520403 Stage 2 Aftercooler Temperature High 1

Read Bit 13 AL_TAH521104 Fuel Skid Heater Temperature High 1

Read Bit 14 AL_TAHH520501 Stage 3 Suction KO Drum Inlet Temperature High Shutdown Exceeded 1

Read Bit 15 MSB AL_TAL520401- Stage 2 Aftercooler Temperature Low 1

40026 Read Bit LSB0 - AL_TAL520403 Stage 2 Aftercooler Temperature Low 1

Read Bit 1 AL_TAL520502 Stage 3 Suction KO Drum Condensate Temperature Low 1

Read Bit 2 AL_TAL520601 Stage Aftercooler 3 Temperature Low 1

Read Bit 3 AL_TAL520604 Stage Aftercooler 3 Temperature Low 1

Read Bit 4 AL_TAL520702 Stage 3 Discharge KO Drum Temperature Low 1

Read Bit 5 AL_TDAH521102 Fuel Skid Delta-T High 1

Read Bit 6 AL_TDAL521102 Fuel Skid Delta-T Low 1

Read Bit 7 AL_TIT521104_OT Fuel Skid Heater Over Temperature 1

Read Bit 8 AL_X521103 Thyristor Panel Common Fault 1

Read Bit 9 AL_XA520203 Stage 1 Suction KO Drum Drain Valve Reset Request 1

Read Bit 10 AL_XA5204A01 Stage Aftercooler 2 Fan A Tripped 1

Read Bit 11 AL_XA5204B01 Stage Aftercooler 2 Fan B Tripped 1

Read Bit 12 AL_XA5206A01 Stage Aftercooler 3 Fan A Tripped 1

Read Bit 13 AL_XA5206B01 Stage Aftercooler 3 Fan B Tripped 1

Read Bit 14 AL_XA5206C01 Stage Aftercooler 3 Fan C Tripped 1

Read Bit 15 MSB AL_XA5206D01- Stage 3 Aftercooler Fan D Tripped 1

40027 Read Bit 0 LSB- AL_XS5204A01 Stage 2 Aftercooler Fan A Vibration High 1

Read Bit 1 AL_XS5204B01 Stage 2 Aftercooler Fan B Vibration High 1

Read Bit 2 AL_XS5206A01 Stage 3 Aftercooler Fan A Vibration High 1

Read Bit 3 AL_XS5206B01 Stage 3 Aftercooler Fan B Vibration High 1

Read Bit 4 AL_XS5206C01 Stage 3 Aftercooler Fan C Vibration High 1

Read Bit 5 AL_XS5206D01 Stage 3 Aftercooler Fan D Vibration High 1

Read Bit 6 AL_MB_Comm_Fail Modbus Data Read Communication Failure 1

Read Bit 7 AL_ZZ2013_F15_Invalid Force Multiple Coils Error - Invalid Coil Number 1

Read Bit 8 AL_ZZ2013_F5_Invalid Force Single Coil Error - Invalid Coil Number 1

Read Bit 9 AL_ZZ2013_F6_16_Invalid Preset Float Register(s) Error - Invalid Register Number 1

Read Bit 10 AL_ZZ2013_Module_Fault ZZ2013 Modbus Module Fault 1

Read Bit 11 AL_ZZ2014_F15_Invalid Force Multiple Coils Error - Invalid Coil Number 1

Read Bit 12 AL_ZZ2014_F5_Invalid Force Single Coil Error - Invalid Coil Number 1

Read Bit 13 AL_ZZ2014_F6_16_Invalid Preset Float Register(s) Error - Invalid Register Number 1

Read Bit 14 AL_ZZ2014_Module_Fault Modbus Module Fault 1

Read Bit 15 - MSB AL_G583_Fail Gas Producer Speed External Set Point Analog Input Range Check Fail 1

40028 Read Bit LSB0 - AL_SD_Bypass_Active Shutdown Bypass Active 1

Read Bit 1 AL_TM_Power_Fail Torquemeter PowerTransmitter Failure 1

Read Bit 2 AL_TM_Torque_Fail Torquemeter Torque Transmitter Failure 1

Read Bit 3 AL_CEMS_CO_Fail CEMS CO Transmitter Failure 1

Read Bit 4 AL_CEMS_NOX_Fail CEMS NOX Transmitter Failure 1

Read Bit 5 AL_CEMS_O2_Fail CEMS O2 Transmitter Failure 1

Read Bit 6 AL_CEMS_Part_Fail CEMS Particulate Transmitter Failure 1

Read Bit 7 AL_CEMS_SO2_Fail CEMS SO2 Transmitter Failure 1

Read Bit 8 AL_CEMS_THC_Fail CEMS THC Transmitter Failure 1

Read Bit 1 CN_TPD799A_Fail Turbine Air Inlet Filter DP Transmitter Failure 1

Read Bit 2 CN_TPD799B_Fail Turbine Air Inlet Filter DP Transmitter Failure 1

Read Bit 4 CN_TPD799_HH Turbine Air Inlet Filter DP High 1

Read Bit 5 CN_Cpsr_Fail_To_Load Compressor Failed to Load 1

Read Bit 6 CN_PIT520105_Fail Stage 1 Suction Gas Pressure Transmitter Failure 1

Read Bit 8 CN_PIT5201101_Fail Compressor Lube Oil Pressure Transmitter Failure 1

Read Bit 12 CN_TIT520102_Fail Stage 1 Suction Gas Temperature Transmitter Failure 1

Read Bit 13 CN_TIT520105_Fail Stage 2 Suction Gas Temperature Transmitter Failure 1

Read Bit 14 CN_TIT520108_Fail Stage 2 Discharge Gas Transmitter Transmitter Failure 1

Read Bit 15 - MSB CN_TIT520110_Fail Stage 2 Discharge Gas Transmitter Transmitter Failure 1

40032 Read Bit 0 - LSB CN_TIT520112_Fail Stage 3 Suction Gas Transmitter Transmitter Failure 1

Read Bit 3 CN_FIT5201011_Fail Stage Suction 1 Flow DP 1

Read Bit 6 CN_FIT520701_Fail Discharge Flow DP 1

Read Bit 7 CN_Stg1_Hot_Bypass_Pos Stage 1 Hot Bypass Valve Not Closed 1

Read Bit 8 CN_Stg2_Hot_Bypass_Pos Stage 2 Hot Bypass Valve Not Closed 1

Read Bit 9 CN_T5_Delayed_HH T5 Delayed Temperature High 1

Read Bit 10 CN_RT380_Fail Lube Oil Header Temperature RTD Failure 1

Read Bit 11 CN_RT380_HH Lube Oil Header Temperature High 1

Read Bit 12 CN_RT380_LL Lube Oil Header Temperature Low, Start Inhibited 1

Read Bit 3 CN_FIT521101_Fail Fuel Skid Outlet Flow DP Transmitter Fail 1

Read Bit 4 CN_LIT520201_Fail Stage 1 Suction KO Drum Level 1 Transmitter Fail 1

Read Bit 13 CN_LIT520701_Fail Stage 3 Discharge KO Drum Level 1 Transmitter Fail 1

Read Bit 14 CN_LIT520702_Fail Stage 3 Discharge KO Drum Level 2 Transmitter Fail 1

Read Bit 15 - MSBC N_LIT520703_Fail Stage 3 Discharge KO Drum Level 3 Transmitter Fail 1

40034 Read Bit 0 - LSB CN_LIT520901_Fail Fuel Skid KO Drum Level Transmitter Fail 1

Read Bit 1 CN_LIT520902_Fail Fuel Skid KO Drum Level Transmitter Fail 1

(5)

1/15/2013 10:04:09 AM

Read Bit 3 CN_N2_Not_Ready N2 Skid Not Ready 1

Read Bit 4 CN_PAL501167 N2 Backup Bottle Pressure Low 1

Read Bit 5 CN_PDIT521001_Fail Fuel Skid Filter DP Transmitter Fail 1

Read Bit 6 CN_PIT520702_Fail Stage 3 Discharge KO Drum Outlet Pressure Transmitter Fail 1

Read Bit 9 CN_PIT520902_Fail Fuel Skid Inlet Pressure Transmitter Fail 1

Read Bit 10 CN_PIT521101_Fail Fuel Skid Outlet Pressure Transmitter Fail 1

Read Bit 11 CN_PIT521102_Fail Fuel Skid Outlet Pressure Transmitter Fail 1

Read Bit 12 CN_PZT521101_Fail Fuel Skid PCV Position Transmitter Fail 1

Read Bit 13 CN_TIT520401_Fail Stage 2 Aftercooler Temperature Transmitter Fail 1

Read Bit 15 - MSB CN_TIT520501_Fail Stage 3 Suction KO Drum Inlet Temperature Transmitter Fail 1

40035 Read Bit 0 - LSB CN_TIT520502_Fail Stage 3 Suction KO Drum Condensate Temperature Transmitter Fail 1

Read Bit 4 CN_TIT520701_Fail Stage 3 Discharge KO Drum Outlet Temperature Transmitter Fail 1

Read Bit 5 CN_TIT520702_Fail Stage 3 Discharge KO Drum Condensate Temperature Transmitter Fail 1

Read Bit 6 CN_TIT521101_Fail Fuel Skid Outlet Temperature Transmitter Fail 1

Read Bit 7 CN_TIT521102_Fail Fuel Skid Outlet Temperature Transmitter Fail 1

Read Bit 8 CN_TIT521103_Fail Fuel Skid Inlet Temperature Transmitter Fail 1

Read Bit 9 CN_TIT521104_Fail Fuel Skid Heater Temperature Transmitter Fail 1

Read Bit 12 CN_ESD_Lvl_2_CCC CCC MPU Fault 1

Read Bit 13 CN_HS520101 Start Permissvie from DCS Required 1

Read Bit 14 CN_Normal_Stop_Aux_Terminal Normal Stop from Auxiliary Terminal 1

Read Bit 15 MSB CN_Normal_Stop_Console- Normal Stop Console 1

40036 Read Bit 0 LSB- CN_Normal_Stop_Customer_HardwireD CS Normal Stop 1

Read Bit 1 CN_Normal_Stop_Customer_Terminal Normal Stop from Customer Terminal 1

Read Bit 2 CN_Normal_Stop_Local_Terminal Normal Stop from Local Terminal 1

Read Bit 3 CN_Normal_Stop_Remote_Terminal Normal Stop from Remote Terminal 1

Read Bit 4 CN_Normal_Stop_Station_Terminal Normal Stop from Station Terminal 1

40043 Read Bit LSB0 - FN_PAHH520122 Stage 3 Suction Gas Pressure High 1

Read Bit 1 FN_TAHH520110 Stage 2 Discharge Temperature High 1

Read Bit 2 FN_TAHH520117 Stage 3 Discharge Gas Temperature High 1

Read Bit 3 FN_FIT5201125_Fail 2BCL458 Discharge Secondary Seal Vent Flow Transmitter Failure 1

Read Bit 4 FN_FIT5201126_Fail 2BCL458 Suction Primary Seal Vent Flow Transmitter Failure 1

Read Bit 5 FN_FIT5201129_Fail MCL525 Discharge Primary Seal Vent Flow Transmitter Failure 1

Read Bit 6 FN_FIT5201130_Fail MCL525 Suction Primary Seal Vent Flow Transmitter Failure 1

Read Bit 7 FN_SSV5201145_Sw_Fail Seal Gas Isolation Valve Limit Switch Fail 1

Read Bit 8 FN_TE5201136_Fail 2BCL458 Internal Process Gas Temperature RTD Failure 1

Read Bit 9 FN_TE5201137_Fail MCL525 Internal Process Gas Temperature RTD Failure 1

Read Bit 10 FN_Fail_To_Unload Failure To Unload Driver 1

Read Bit 11 FN_Assoc_Gas_Inlet_Cmd_Disagree Associtated Gas Inlet Valve Command Disagree 1

Read Bit 12 FN_Assoc_Gas_Inlet_Valve_Sw_Fail Associated Gas Inlet Valve Limit Switch Fail 1

Read Bit 13 FN_Discharge_Valve_Sw_Fail Discharge Valve Limit Switch Fail 1

Read Bit 14 FN_Dis_Cmd_Disagree Discharge Valve Command Disagree 1

Read Bit 15 MSBF N_Fail_To_Pressurize- Compressor Fail to Pressurize 1

40044 Read Bit 0 - LSB FN_Flare_Cmd_Disagree Flare Valve Command Disagree 1

Read Bit 1 FN_Flare_Valve_Sw_Fail Flare Valve Limit Switch Fail 1

Read Bit 2 FN_Lift_Gas_Inlet_Cmd_Disagree Lift Gas Inlet Valve Command Disagree 1

Read Bit 3 FN_Lift_Gas_Inlet_Valve_Sw_Fail Lift Gas Inlet Valve Limit Switch Fail 1

Read Bit 4 FN_Loading_Valve_Sw_Fail Associated Gas Loading Valve Limit Switch Fail 1

Read Bit 5 FN_Load_Cmd_Disagree Associated Gas Loading Valve Command Disagree 1

Read Bit 6 FN_Stg1_Inlet_Cmd_Disagree Stage 1 Inlet Valve Command Disagree 1

Read Bit 7 FN_Stg1_Inlet_Valve_Sw_Fail Stage 1 Inlet Valve Limit Switch Fail 1

Read Bit 8 FN_Stg2_Inlet_Cmd_Disagree Stage 2 Inlet Valve Command Disagree 1

Read Bit 9 FN_Stg2_Inlet_Valve_Sw_Fail Stage 2 Inlet Valve Limit Switch Fail 1

Read Bit 10 FN_Stg3_Hot_Bypass_Pos Stage 3 Hot Bypass Valve Not Closed 1

Read Bit 11 FN_Bleed_Valve_Pos_Fail Bleed Valve Actuator Position Failure 1

Read Bit 12 FN_EBV338_Fault Bleed Valve Actuator Fault 1

Read Bit 13 FN_EBV338_FB_Fail Bleed Valve Position Transmitter Failure 1

Read Bit 14 FN_EBV338_OverTemp Bleed Valve Actuator Over Temperature 1

Read Bit 15 MSB FN_EGF344_Fault- Main Gas Fuel Valve Actuator Fault 1

40045 Read Bit 0 - LSB FN_EGF344_FB_Fail Main Gas Fuel Valve Position Transmitter Failure 1

Read Bit 1 FN_EGF344_OverTemp Main Gas Fuel Valve Actuator Over Temperature 1

Read Bit 2 FN_EGF345_Fault Pilot Gas Fuel Valve Actuator Fault 1

Read Bit 3 FN_EGF345_FB_Fail Pilot Gas Fuel Valve Position Transmitter Failure 1

Read Bit 4 FN_EGF345_OverTemp Pilot Gas Fuel Valve Actuator Over Temperature 1

Read Bit 5 FN_EGV339_Fault Guide Vane Actuator Fault 1

Read Bit 6 FN_EGV339_FB_Fail Guide Vane Position Transmitter Failure 1

Read Bit 7 FN_EGV339_OverTemp Guide Vane Actuator Over Temperature 1

Read Bit 8 FN_Flameout_High_Fuel_Cmd Engine Flameout Detected By High Fuel Command 1

Read Bit 9 FN_Flameout_High_Fuel_Flow Engine Flameout Detected By High Fuel Flow 1

Read Bit 10 FN_Flameout_Low_T5 Engine Flameout Detected By Low Engine Temperature 1

Read Bit 11 FN_Flameout_Under_Speed Engine Under Speed Possibly Due to Flameout 1

Read Bit 12 FN_Gas_Fuel_Main_Vlv_Pos_Fail Main Gas Fuel Valve Position Failure 1

Read Bit 13 FN_Gas_Fuel_Pilot_Vlv_Pos_Fail Gas Fuel Pilot Valve Position Failure 1

Read Bit 14 FN_Gas_Fuel_Vlv_Check_Fail Gas Fuel Valve Check Failure 1

Read Bit 15 - MSBF N_Guide_Vane_Pos_Fail Guide Vane Actuator Position Failure 1

40046 Read Bit LSB0 - FN_High_Start_Fuel_Flow High Start Gas Fuel Flow 1

Read Bit 1 FN_Ignition_Fail Ignition Failure 1

Read Bit 2 FN_Ngp_Accel_Rate_L Gas Producer Acceleration Rate Low 1

Read Bit 3 FN_Ngp_Over_Speed Gas Producer Over Speed 1

Read Bit 4 FN_Ngp_Under_Speed Gas Producer Under Speed 1

Read Bit 5 FN_Npt_Brkaway_Fail Power Turbine Fail to Break Away 1

Read Bit 6 FN_Npt_Over_Speed Power Turbine Over Speed 1

Read Bit 7 FN_Npt_Under_Speed Power Turbine Under Speed 1

Read Bit 8 FN_S349_Fail Flameout Switch failure to transfer on shutdown 1

Read Bit 9 FN_Accel_Failed Fail To Accelerate 1

Read Bit 10 FN_B330_Temp_HH Starter Motor Temperature High 1

Read 11Bit FN_Crank_Fail CrankFail To 1

Read Bit 12 FN_Crank_Speed_H Crank Speed High 1

Read Bit 13 FN_Crank_Speed_L Crank Speed Low 1

Read Bit 14 FN_VFD430_Fault Start VFD Fault 1

Read Bit 15 MSBF N_VFD430_Node_Fault- Start VFD Turbine CNet Node Fault 1

40047 Read Bit 0 - LSB FN_B320_1_Press_Decay_Check_FailM ain Lube Pump 1 Pressure Decay Check Failure 1

Read Bit 1 FN_B320_2_Press_Decay_Check_FailM ain Lube Pump 2 Pressure Decay Check Failure 1

Read Bit 2 FN_B322_Fail Backup Lube Oil Pump Failure 1

Read Bit 3 FN_B322_Press_Decay_Check_Fail Backup Lube Pressure Decay Check Failure 1

Read Bit 4 FN_Backup_Pump_Test_Fail Backup Lube Oil Pump Test Failure 1

(6)

1/15/2013 10:04:09 AM

Read Bit 6 FN_Lube_Decay_Check_Fail Lube Pressure Decay Check Failure 1

Read Bit 7 FN_RT390_LL Lube Oil Tank Temperature Low Start Permissive 1

Read Bit 8 FN_BN3500_HH BN3500 Vibration Detected High Common Shutdown 1

Read Bit 9 FN_TV351X_HH Engine Bearing 1 X-Axis Radial Vibration High 1

Read Bit 10 FN_TV351Y_HH Engine Bearing 1 Y-Axis Radial Vibration High 1

Read Bit 11 FN_TV351Z_HH Engine GP Axial Displacement High 1

Read Bit 15 - MSBF N_TV353Y_HH Engine Bearing 3 Y-Axis Radial Vibration High 1

40048 Read_Read Bit _Bit₁0 LSB- FN_TV354X_HH_{FN_TV354Y_HH} Engine _EngineBearing _Bearing4 X-Axis ₄_Y-AxisRadial _RadialVibration _VibrationHigh_High 1₁

Read Bit 4 FN_TV355Z_HH Engine PT Axial Displacement High 1

Read Bit 5 FN_XE5201100X_HH MCL525 DE X-Axis Radial Vibration High 1

Read Bit 6 FN_XE5201100Y_HH MCL525 DE Y-Axis Radial Vibration High 1

Read Bit 7 FN_XE5201101X_HH MCL525 NDE X-Axis Radial Vibration High 1

Read Bit 8 FN_XE5201101Y_HH MCL525 NDE Y-Axis Radial Vibration High 1

Read Bit 9 FN_ZE5201100A_HH MCL525 Axial A Displacement High 1

Read Bit 10 FN_ZE5201100B_HH MCL525 Axial B Displacement High 1

Read Bit 11 FN_XE5201102X_HH 2BCL458 DE X-Axis Radial Vibration High 1

Read Bit 12 FN_XE5201102Y_HH 2BCL458 DE Y-Axis Radial Vibration High 1

Read Bit 13 FN_XE5201103X_HH 2BCL458 NDE X-Axis Radial Vibration High 1

Read Bit 14 FN_XE5201103Y_HH 2BCL458 NDE Y-Axis Radial Vibration High 1

Read Bit 15 MSBF N_ZE5201101A_HH- 2BCL458 Axial A Displacement High 1

40049 Read Bit 0 LSB- FN_ZE5201101B_HH 2BCL458 Axial B Displacement High 1

Read Bit 1 FN_Feed_Air_Cmd_Disagree N2 Feed Air Inlet Valve Command Disagree 1

Read Bit 2 FN_Feed_Air_Vlv_Sw_Fail N2 Feed Air Inlet Valve Limit Switch Fail 1

Read Bit 3 FN_Fuel_Skid_Bypass_Cmd_DisagreeF uel Skid Bypass Valve Command Disagree 1

Read Bit 4 FN_Fuel_Skid_Bypass_Sw_Fail Fuel Skid Bypass Valve Limit Switch Fail 1

Read Bit 5 FN_Fuel_Skid_Inlet_Cmd_Disagree Fuel Skid Inlet Valve Command Disagree 1

Read Bit 6 FN_Fuel_Skid_Inlet_Sw_Fail Fuel Skid Inlet Valve Limit Switch Fail 1

Read Bit 7 FN_Fuel_Skid_KO_Drain_Cmd_DisagreFuel Skid KO Drum Drain Valve Command Disagree 1

Read Bit 8 FN_Fuel_Skid_Outlet_Cmd_Disagree Fuel Skid Outlet Valve Command Disagree 1

Read Bit 9 FN_Fuel_Skid_Outlet_Sw_Fail Fuel Skid Outlet Valve Limit Switch Fail 1

Read Bit 10 FN_Fuel_Skid_Vent_Cmd_Disagree Fuel Skid Blowdown Valve Command Disagree 1

Read Bit 11 FN_Fuel_Skid_Vent_Sw_Fail Fuel Skid Blowdown Valve Limit Switch Fail 1

Read Bit 12 FN_PAHH520702 Stage 3 Discharge KO Drum Outlet Pressure High 1

Read Bit 13 FN_PAHH520902 Fuel Skid Inlet Pressure High 1

Read Bit 14 FN_PALL521102 Fuel Skid Outlet Pressure Low 1

Read Bit 15 - MSB FN_SSV520203_Sw_Fail Stage 1 Suction KO Drum Drain Valve Limit Switch Fail 1

40050 Read Bit 0 - LSB FN_SSV520505_Sw_Fail Stage 3 Suction KO Drum Drain Valve Limit Switch Fail 1

Read Bit 1 FN_SSV520704_Sw_Fail Seal Gas Isolation Valve Limit Switch Fail 1

Read Bit 2 FN_TAHH520501 Stage 3 Suction KO Drum Inlet Temperature High 1

Read Bit 3 FN_TAHH520602 Stage 3 Aftercooler Temperature High 1

Read Bit 4 FN_TAHH521101 Fuel Skid Outlet Temperature High 1

Read Bit 5 FN_TALL521102 Fuel Outlet Temperature Low 1

Read Bit 6 FN_Depress_Stop_Aux_Terminal Depressurized Fast Stop from Auxiliary Terminal 1

Read Bit 7 FN_Depress_Stop_Customer_TerminalD epressurized Fast Stop from Customer Terminal 1

Read Bit 8 FN_Depress_Stop_Local_Terminal Depressurized Fast Stop from Local Terminal 1

Read Bit 9 FN_Depress_Stop_Remote_Terminal Depressurized Fast Stop from Remote Terminal 1

Read Bit 10 FN_Depress_Stop_Station_Terminal Depressurized Fast Stop from Station Terminal 1

Read Bit 11 FN_Pressurized_Stop_Customer ESD Fast Stop Pressurized_X520102 1

40053 Read LSBBit - 0 FL_Backup_Overspeed Backup Overspeed 1

Read Bit 1 FL_Backup_Speed_Probe_Fail Backup Speed Probe Failure 1

Read Bit 2 FL_BU_Overspeed_BU_LatchAct_MismBackup Overspeed Detected vs Backup System Latch Active Mismatch 1

Read Bit 3 FL_Ext_Watchdog_Fault External Watchdog Fault 1

Read Bit 4 FL_Fast_Stop_Latch Fast Stop Latch 1

Read Bit 5 FL_First_Pass Controller Executed First Pass 1

Read Bit 6 FL_MicroP_Fail_BU_LatchAct_MismatcM icro Processor Fail vs Backup System Latch Active Mismatch 1

Read Bit 7 FL_OSM_Overspeed Backup Overspeed Monitor Analog Overspeed 1

Read Bit 8 FL_OSM_PTest_Fail Backup Overspeed Monitor Processor Test Fail 1

Read Bit 9 FL_OSM_STest_Fail Backup Overspeed Monitor System Test Fail 1

Read Bit 10 FL_OSM_Tracking_Error Backup Overspeed Monitor Speed Tracking Error 1

Read Bit 11 FL_OSM_Xmtr_Fail Backup Overspeed Monitor Speed Transmitter Failure 1

Read Bit 12 FL_UF2050_Node_Fault Turbine CNet Node Fault5 1

Read Bit 15 MSB FL_UF2080_Node_Fault- Turbine CNet Node 8 Fault 1

40054 Read Bit LSB0 - FL_UF2090_Node_Fault Turbine CNet Node 9 Fault 1

Read Bit 1 FL_UF2120_Node_Fault Turbine CNet Node 12 Fault 1

Read Bit 12 FL_ZZ2011_Node_Fault Turbine CNet Node Fault1 1

Read Bit 13 FL_ZZ2012_Node_Fault Turbine CNet Node Fault3 1

Read Bit 14 FL_Supply_Voltage_24Vdc_LL Control System 24 Vdc Supply Voltage Low 1

Read Bit 15 - MSBF L_B596_1_And_2_Fail Turbine Enclosure Vent Fans 1 and 2 Failure 1

40059 Read Bit 0 - LSB FL_Encl_Exhaust_Damper_Closed Enclosure Exhaust Damper Indicates Closed When Commanded Open 1

Read Bit 1 FL_Encl_Gas_LEL_HH Turbine Enclosure Combustible Gas Level High 1

Read Bit 2 FL_Encl_Inlet_Damper_Closed Enclosure Inlet Damper Indicates Closed When Commanded Open 1

Read Bit 3 FL_Fire_Detected Enclosure Fire Detected 1

Read Bit 4 FL_Fire_Detected_BU_LatchAct_Mism Enclosure Fire Detected vs Backup System Latch Active Mismatch 1

Read Bit 5 FL_Fire_Sys_Discharged Enclosure Fire System Discharged 1

Read Bit 6 FL_Gas_Detected_BU_LatchAct_Mism Turbine Enclosure Gas Detected vs Backup System Latch Active Mismatch 1

Read Bit 7 FL_Gas_Detect_Prestart_H Turbine Enclosure Combustible Gas Detection Level High During Prestart 1

Read Bit 8 FL_RT396_Fail Turbine Enclosure Temperature RTD Failure 1

Read Bit 9 FL_RT396_HH Turbine Enclosure Temperature High 1

Read Bit 10 FL_S396_1_Fail Turbine Enclosure Vent Flow Switch Failure Start Permissive 1

Read Bit 11 FL_TPD396_1_Fail Turbine Enclosure Air Flow DP Transmitter Failure 1

Read Bit 12 FL_TPD396_2_Fail Turbine Enclosure Pressure Transmitter Failure 1

Read Bit 13 FL_TPD396_2_LL Turbine Enclosure Pressure Low 1

Read Bit 14 FL_PAHH520117 [SAFETY CRITICAL] HPC Discharge Gas Pressure High 1

Read Bit 15 MSB FL_PAHH520121- Stage 2 Discharge Gas Pressure High 1

40060 Read Bit LSB0 - FL_PALL520105 Stage 1 Suction Gas Pressure Low 1

Read Bit 1 FL_PALL5201101 Compressor Lube Oil Pressure Low 1

Read Bit 2 FL_PALL520120 Stage Suction 2 Gas Pressure Low 1

Read Bit 3 FL_PALL520121 Stage 2 Discharge Gas Pressure Low 1

(7)

1/15/2013 10:04:09 AM

Read Bit 5 FL_PIT520110_Fail Stage 2 Discharge Gas Pressure Transmitter Failure 1

Read Bit 8 FL_PAHH5201129 2BCL458 Discharge Primary Seal Vent Pressure High 1

Read Bit 9 FL_PAHH5201131 2BCL458 Suction Primary Seal Vent Pressure High 1

Read Bit 10 FL_PAHH5201133 MCL525 Discharge Primary Seal Vent Pressure High 1

Read Bit 11 FL_PAHH5201135 MCL525 Suction Primary Seal Vent Pressure High 1

Read Bit 12 FL_PALL5201124 Compressor N2 Inlet Pressure Low 1

Read Bit 13 FL_PIT5201123_Fail Compressor N2 Inlet Pressure Transmitter Failure 1

Read Bit 14 FL_PIT5201124_Fail Compressor N2 Pressure Transmitter Failure 1

Read Bit 15 - MSB FL_PIT5201129_Fail 2BCL458 Discharge Primary Seal Vent Transmitter Failure 1

40061 Read Bit 0 - LSB FL_PIT5201131_Fail 2BCL458 Suction Primary Seal Vent Transmitter Failure 1

Read Bit 1 FL_PIT5201133_Fail MCL525 Discharge Primary Seal Vent Transmitter Failure 1

Read Bit 2 FL_PIT5201135_Fail MCL525 Suction Primary Seal Vent Transmitter Failure 1

Read Bit 3 FL_Stg_1_Surge Stage Surge 1 Trip 1

Read Bit 6 FL_GV_Force_HH Guide Vane Actuator Force High 1

Read Bit 7 FL_L341_1_IO_Fail Primary Gas Fuel Shutoff Valve Output Module Failure 1

Read Bit 8 FL_L342_1_IO_Fail Secondary Gas Fuel Shutoff Valve Output Module Failure 1

Read Bit 9 FL_Ngp_Loss_Speed_Sig Loss of Gas Producer Speed Signal 1

Read Bit 10 FL_Ngp_Max_Momentary Gas Producer Maximum Momentary Speed Exceeded 1

Read Bit 11 FL_Npt_Max_Momentary Power Turbine Maximum Momentary Speed Exceeded 1

Read Bit 12 FL_Pcd_Dual_Xmtr_Fail Gas Producer Compressor Discharge Pressure Dual Transmitter Failure 1

Read Bit 13 FL_T5_Inst_HH T5 Instantaneous Temperature High 1

Read Bit 14 FL_T5_TC_Delay_High Delayed Single T5 Thermocouple High 1

Read Bit 15 MSB FL_T5_TC_High- Single T5 Thermocouple High 1

40062 Read Bit 0 - LSB FL_T5_TC_Light_Around_Fail T5 Thermocouples Fail to Completely Light Around 1

Read Bit 1 FL_TP342_1_Fail Gas Fuel Valve Check Pressure Transmitter Failure 1

Read Bit 2 FL_TP342_1_HH Gas Fuel Shutoff Valves Pressure High 1

Read Bit 3 FL_TP386_1_Fail Gas Fuel Supply Pressure Transmitter Failure 1

Read Bit 4 FL_TP386_2_Fail Gas Fuel Supply Pressure Transmitter Failure 1

Read Bit 5 FL_TP386_2_HH Gas Fuel Supply Pressure High 1

Read Bit 6 FL_TPD344_Fail Gas Fuel Control DP Transmitter Failure 1

Read Bit 7 FL_VFD430_Lube_Press_Func_Loss Low Start Pressure Lube Oil Inhibit 1

Read Bit 8 FL_BU_Sys_Relay_Failure Backup System Relay Failure 1

Read Bit 9 FL_Lube_Module_Fail Lube Pump Output Module Failure 1

Read Bit 10 FL_Possible_Bearing_Fail_Post_Lube Possible Engine Bearing Failure Due to Interrupted Post Lube 1

Read Bit 11 FL_Possible_Bearing_Fail_Rotating Possible Engine Bearing Failure Due to Low Header Pressure While Rotating 1

Read Bit 12 FL_RT390_Fail Lube Oil Tank Temperature RTD Failure 1

Read Bit 13 FL_RT391_Fail Lube Oil Tank Circulation Heater Temperature RTD Failure 1

Read Bit 14 FL_TP380_1_Fail Lube Oil Header Pressure Transmitter Failure 1

Read Bit 15 - MSBF L_TP380_2_Fail Lube Oil Header Pressure Transmitter Failure 1

40063 Read Bit LSB- 0 FL_TP380_LL Lube Oil Header Pressure Low 1

Read Bit 1 FL_Eng_Brg_1_Drn_Delta_Temp_HH Engine Bearing 1 Drain Delta Temperature High 1

Read Bit 2 FL_Eng_Brg_2_3_Drn_Delta_Temp_H Engine Bearing 2&3 Drain Delta Temperature High 1

Read Bit 3 FL_Eng_Brg_4_5_Drn_Delta_Temp_H Engine Bearing 4&5 Drain Delta Temperature High 1

Read Bit 4 FL_GP_Thr_Brg_Delta_Temp_HH Engine GP Thrust Bearing Delta Temperature High 1

Read Bit 5 FL_PT_Thr_Brg_Delta_Temp_HH Engine PT Thrust Bearing Delta Temperature High 1

Read Bit 6 FL_RT320_Fail Engine PT Thrust Bearing Temperature RTD Failure 1

Read Bit 7 FL_RT320_HH Engine PT Thrust Bearing Temperature High 1

Read Bit 8 FL_RT321_Fail Engine GP Thrust Bearing Temperature RTD Failure 1

Read Bit 9 FL_RT321_HH Engine GP Thrust Bearing Temperature High 1

Read Bit 10 FL_RT327_1_Fail Engine Bearing 1 Drain Temperature RTD Failure 1

Read Bit 11 FL_RT327_2_Fail Engine Bearing 2&3 Drain Temperature RTD Failure 1

Read Bit 12 FL_RT327_4_Fail Engine Bearing 4&5 Drain Temperature RTD Failure 1

Read Bit 13 FL_TE5201100A_Fail MCL525 DE Journal Bearing Temperature RTD Failure 1

Read Bit 14 FL_TE5201100A_HH MCL525 DE Journal Bearing Temperature High 1

Read Bit 15 - MSBF L_TE5201100B_Fail MCL525 DE Journal Bearing Temperature RTD Failure 1

40064 Read Bit 0 - LSB FL_TE5201100B_HH MCL525 DE Journal Bearing Temperature High 1

Read Bit 1 FL_TE5201101A_Fail MCL525 NDE Journal Bearing Temperature RTD Failure 1

Read Bit 2 FL_TE5201101A_HH MCL525 NDE Journal Bearing Temperature High 1

Read Bit 3 FL_TE5201101B_Fail MCL525 NDE Journal Bearing Temperature RTD Failure 1

Read Bit 4 FL_TE5201101B_HH MCL525 NDE Journal Bearing Temperature High 1

Read Bit 5 FL_TE5201102A_Fail MCL525 NACT Thrust Bearing Temperature RTD Failure 1

Read Bit 6 FL_TE5201102A_HH MCL525 NACT Thrust Bearing Temperature High 1

Read Bit 7 FL_TE5201102B_Fail MCL525 NACT Thrust Bearing Temperature RTD Failure 1

Read Bit 8 FL_TE5201102B_HH MCL525 NACT Thrust Bearing Temperature High 1

Read Bit 9 FL_TE5201103_Fail MCL525 ACT Thrust Bearing Temperature RTD Failure 1

Read Bit 10 FL_TE5201103_HH MCL525 ACT Thrust Bearing Temperature High 1

Read Bit 11 FL_TE5201104_Fail MCL525 ACT Thrust Bearing Temperature RTD Failure 1

Read Bit 12 FL_TE5201104_HH MCL525 ACT Thrust Bearing Temperature High 1

Read Bit 13 FL_TE5201105A_Fail 2BCL458 DE Journal Bearing Temperature RTD Failure 1

Read Bit 14 FL_TE5201105A_HH 2BCL458 DE Journal Bearing Temperature High 1

Read Bit 15 - MSBF L_TE5201105B_Fail 2BCL458 DE Journal Bearing Temperature RTD Failure 1

40065 Read Bit 0 - LSB FL_TE5201105B_HH 2BCL458 DE Journal Bearing Temperature High 1

Read Bit 1 FL_TE5201106A_Fail 2BCL458 NDE Journal Bearing Temperature RTD Failure 1

Read Bit 2 FL_TE5201106A_HH 2BCL458 NDE Journal Bearing Temperature High 1

Read Bit 3 FL_TE5201106B_Fail 2BCL458 NDE Journal Bearing Temperature RTD Failure 1

Read Bit 4 FL_TE5201106B_HH 2BCL458 NDE Journal Bearing Temperature High 1

Read Bit 5 FL_TE5201107A_Fail 2BCL458 NACT Thrust Bearing Temperature RTD Failure 1

Read Bit 6 FL_TE5201107A_HH 2BCL458 NACT Thrust Bearing Temperature High 1

Read Bit 7 FL_TE5201107B_Fail 2BCL458 NACT Thrust Bearing Temperature RTD Failure 1

Read Bit 8 FL_TE5201107B_HH 2BCL458 NACT Thrust Bearing Temperature High 1

Read Bit 9 FL_TE5201108_Fail 2BCL458 ACT Thrust Bearing Temperature RTD Failure 1

Read Bit 10 FL_TE5201108_HH 2BCL458 ACT Thrust Bearing Temperature High 1

Read Bit 11 FL_TE5201109_Fail 2BCL458 ACT Thrust Bearing Temperature RTD Failure 1

Read Bit 12 FL_TE5201109_HH 2BCL458 ACT Thrust Bearing Temperature High 1

Read Bit 13 FL_AAHH5201103 N2 Skid Oxygen Level High 1

Read Bit 14 FL_AIC5201103_Fail N2 Skid Oxygen Analyzer Failure 1

Read Bit 15 - MSBF L_IT5201155_Fail Instrument Air Supply Pressure Transmitter Failure 1

40066 Read Bit LSB0 - FL_LAHH520202 Stage 1 Suction KO Drum Level High 1

Read Bit 1 FL_LAHH520302 Stage Suction 2 KO Drum Level High 1

Read Bit 2 FL_LAHH520502 Stage Suction 3 KO Drum Level High 1

Read Bit 3 FL_LAHH520702 Stage 3 Discharge KO Drum Level High 1

Read Bit 4 FL_LAHH520902 Fuel Skid KO Drum Level High 1

Read Bit 5 FL_N2_Gen_SD N2 Generating System Shutdown 1

Read Bit 6 FL_PALL5201155 Instrument Air Supply Pressure Low 1

Read Bit 7 FL_PALL520704 Stage 3 Discharge KO Drum Outlet Pressure Low 1

Read Bit 8 FL_PDIT5201156_Fail Instrument Air Inlet Filter DP Transmitter Failure 1

Read Bit 9 FL_PIT5201167_Fail N2 Backup Bottle Pressure Transmitter Failure 1

Read Bit 10 FL_Emerg_Stop_Cpsr Emergency Stop Customer (Cpsr) 1

(8)

1/15/2013 10:04:09 AM

Read Bit 1 2 FL_Emer_Stop_BU_LatchAct_MismatchEmergency Stop S kid vs Backup S ystem Latch A ctive M ismatch 1

Read Bit 13 FL_Emer_Stop_Cpsr_BU_LatchAct_MisEmergency Stop Customer (CPSR) vs Backup System Latch Active Mismatch 1

Read Bit 14 FL_Emer_Stop_DCS_BU_LatchAct_MisEmergency Stop Customer (DCS) vs B ackup S ystem Latch A ctive Mismatch 1

Read Bit 15 MSB FL_Fast_Stop_Console- Fast Stop Console 1

40067 Read LSBBit - 0 FL_Fast_Stop_On_Skid Fast Stop On Skid 1

40071 Read Bit 0 - LSB ST_OSM_STest Backup Overspeed Monitor System Test In Progress 1

Read Bit 1 ST_OSM_STest_Pass Backup Overspeed Monitor System Test Pass 1

Read Bit 2 ST_ZF2291_Ch0_Ok Node 29 XM-Node 1 Channel OK0 1

Read Bit 3 ST_ZF2291_Ch1_Ok Node 29 XM-Node 1 Channel OK1 1

Read Bit 4 ST_ZF2291_Net_Pwr_ON Node 29 XM-Node 1 Network Power ON 1

Read Bit 5 ST_Acceleration Startup Acceleration Active 1

Read 6Bit ST_Cooldown Cooldown 1

Read 7Bit ST_Ignition Ignition 1

Read Bit 8 ST_Not_Ready_To_Run Engine Not Ready to Run. Clearing Alarms is Required. 1

Read 9Bit ST_On_Load LoadOn 1

Read Bit 10 ST_Pre_Start Engine Pre-Start 1

Read Bit 11 ST_Pre_Start_Pre_Crank Pre-Start, Pre-Crank Mode Summary 1

Read Bit 12 ST_Pre_Start_Seq Pre Start Sequences Ready 1

Read 13Bit ST_Purge_Crank Purge Crank 1

Read Bit 14 ST_Ready_To_Load Ready To Load 1

Read MSB ST_Ready_To_RunBit 15 - Ready To Run 1

40072 Read LSBS- Bit 0 T_Running Driver Running 1

Read Bit 1 ST_Starter_Dropout_Speed_EstablisheS tarter Dropout Speed Established 1

Read 2Bit ST_Starting Driver Starting 1

Read 3Bit ST_Stopping Driver Stopping 1

Read 4Bit ST_Test_Crank Test Crank 1

Read Bit 5 ST_Test_Crank_Ready Ready Test to Crank 1

Read Bit 6 ST_B799 Turbine Air Inlet Filter Blower Fun Command 1

Read Bit 7 ST_L390_1_ON On-Crank Cleaning Shutoff Valve Open 1

Read Bit 8 ST_L390_2_ON On-Line Cleaning Shutoff Valve Open 1

Read Bit 9 ST_Water_Wash_OnCrank_Enabled On-Crank Water Wash Enabled 1

Read Bit 10 ST_Water_Wash_OnLine_Enabled On-Line Water Wash Enabled 1

Read Bit 11 ST_Encl_Being_Purged Turbine Enclosure Is Being Purged 1

Read Bit 12 ST_Encl_Door_Open Enclosure Door(s) Open 1

Read Bit 13 ST_Encl_Vent_Fan_1_Run Turbine Enclosure Vent Fan 1 Run Command ON 1

Read Bit 14 ST_Encl_Vent_Fan_1_Selected Turbine Enclosure Vent Fan 1 Selected as Primary 1

Read Bit 15 - MSBS T_Encl_Vent_Fan_2_Run Turbine Enclosure Vent Fan 2 Run Command ON 1

40073 Read Bit 0 - LSB ST_Encl_Vent_Fan_2_Selected Turbine Enclosure Vent Fan 2 Selected as Primary 1

Read Bit 1 ST_Fire_Damper_1_Closed Enclosure Fire Damper #1 Closed 1

Read Bit 2 ST_Fire_Damper_2_Closed Enclosure Fire Damper #2 Closed 1

Read Bit 3 ST_WM_Dampers_Close Water Mist Dampers Commanded to Close 1

Read Bit 4 ST_XI5961 Enclosure Vent Fan Running1 1

Read Bit 5 ST_XI5962 Enclosure Vent Fan Running2 1

Read Bit 6 ST_Fail_To_Load_Inhibited Compressor Fail To Load Shut Down Inhibited 1

Read Bit 7 ST_Case_Pressurized Compressor Case Pressure Sensed 1

Read Bit 8 ST_Man_YV_Engage Engage Manual Yard Valves 1

Read Bit 9 ST_PALL5201124 Compressor N2 Inlet Pressure Low Shutdown Bypassed 1

Read Bit 10 ST_Seal_System_Manual_Active Compressor Seal System in Manual 1

Read Bit 11 ST_ZSC5201122 Seal Gas Isolation Valve Fully Closed 1

Read Bit 12 ST_ZSO5201123 Seal Gas Isolation Valve Fully Open 1

Read Bit 13 ST_520102_Open Stage 1 Anti-Surge Valve Fully Open 1

Read Bit 14 ST_520104_Open Stage 2 Anti-Surge Valve Fully Open 1

Read Bit 15 MSB ST_520106_Open- Stage 3 Anti-Surge Valve Fully Open 1

40074 Read Bit 0 - LSB ST_Min_Npt_Control_Active Minimum Power Turbine Speed Limiting Active 1

Read Bit 1 ST_Assoc_Gas_Inlet_Valve_Closed Associated Gas Inlet Valve Fully Closed 1

Read Bit 2 ST_Assoc_Gas_Inlet_Valve_DP_L Associated Gas Inlet Valve DP Low 1

Read Bit 3 ST_Assoc_Gas_Inlet_Valve_Open Associated Gas Inlet Valve Fully Open 1

Read Bit 4 ST_Compressor_Pressurizing Compressor Pressurizing 1

Read Bit 5 ST_Compressor_Ready Compressor Ready to Run 1

Read Bit 6 ST_Cpsr_Press_Hold Pressurized Hold Mode 1

Read Bit 7 ST_Depressurized_Start Depressurized Start In Progress 1

Read Bit 8 ST_Discharge_Valve_Closed Discharge Valve Fully Closed 1

Read Bit 9 ST_Discharge_Valve_Open Discharge Valve Fully Open 1

Read Bit 10 ST_Engage_Man_YV Engage Manual Yard Valves Prompt 1

Read Bit 11 ST_Flare_Valve_Closed Flare Valve Fully Closed 1

Read Bit 12 ST_Flare_Valve_Open Flare Valve Fully Open 1

Read Bit 13 ST_Lift_Gas_Inlet_Valve_Closed Lift Gas Inlet Valve Fully Closed 1

Read Bit 14 ST_Lift_Gas_Inlet_Valve_Open Lift Gas Inlet Valve Fully Open 1

Read Bit 15 - MSBS T_Loading_Valve_Closed Associated Gas Loading Valve Fully Closed 1

40075 Read Bit 0 - LSB ST_Loading_Valve_Open Associated Gas Loading Valve Fully Open 1

Read Bit 1 ST_Pressurized_Start Pressurized Start In Progress 1

Read Bit 2 ST_Process_Valves_Manual Process Gas Valves In Manual Control Mode 1

Read Bit 3 ST_Sequence_0B Open Stage 1 Inlet Valve SDV520204 1

Read Bit 4 ST_Sequence_0C Reset Stage 1 Inlet Valve SDV520204 1

Read Bit 5 ST_Sequence_0D Open Associated Gas Loading Valve SDV520506 1

Read Bit 6 ST_Sequence_0E Reset Associated Gas Loading Valve SDV520506 1

Read Bit 7 ST_Sequence_0F Close Blowdown Vlave BDV520701 1

Read Bit 8 ST_Sequence_0G Reset Blowdown Valve BDV520701 1

Read Bit 9 ST_Sequence_0H Open Associated Gas Inlet Valve SDV520503 1

Read Bit 10 ST_Sequence_0I Reset Associated Gas Inlet Valve SDV520503 1

Read Bit 11 ST_Sequence_0J Close Associated Gas Loading Valve SDV520506 1

Read Bit 12 ST_Sequence_0K Reset Stage 2 Inlet Valve SDV520303 1

Read Bit 13 ST_Sequence_0L Open Discharge Valve SDV520703 1

Read Bit 14 ST_Sequence_0M Reset Discharge Valve SDV520703 1

Read Bit 15 MSB ST_Sequence_0N- Open LG Inlet Valve SDV520504 1

40076 Read Bit LSB0 - ST_Sequence_0O Reset LG Inlet Valve SDV520504 1

Read Bit 1 ST_Stg1_2_Purge Stage and 1 2 Compressor Purging 1

Read Bit 2 ST_Stg1_Hot_Bypass_Valve_Closed Stage 1 Hot Bypass Valve Fully Closed 1

Read Bit 3 ST_Stg1_Inlet_Valve_Closed Stage 1 Inlet Valve Fully Closed 1

Read Bit 4 ST_Stg1_Inlet_Valve_Open Stage 1 Inlet Valve Fully Open 1

Read Bit 6 ST_Stg2_Inlet_Valve_Closed Stage 2 Inlet Valve Fully Closed 1

Read Bit 7 ST_Stg2_Inlet_Valve_DP_L Stage 2 Inlet Valve DP Low 1

Read Bit 8 ST_Stg2_Inlet_Valve_Open Stage 2 Inlet Valve Fully Open 1

Read Bit 10 ST_Stg3_Purge Stage Compressor 3 Purging 1

Read Bit 11 ST_Control_Vlv_Tracking_Test Gas Valve Check Control Valve Tracking Test Active 1

Read Bit 12 ST_EBV338_Enabled Bleed Valve Actuator Enabled 1

Read Bit 13 ST_EGF344_Enabled Gas Fuel Control Valve Enabled 1

Read Bit 14 ST_EGF345_Enabled Gas Fuel Pilot Control Valve Enabled 1

Read Bit 15 MSB ST_EGV339_Enabled- Guide Vane Actuator Enabled 1

(9)

1/15/2013 10:04:09 AM

40077 Read Bit 0 - LSB ST_Engine_Cleaning_Req GV Ngp Offset Limited, Check Engine Compressor For Cleaning 1

Read Bit 1 ST_Fuel_Control_Inactive Fuel Control Inactive 1

Read 2Bit ST_G340_ON Ignitor Energized 1

Read Bit 3 ST_Gas_Flow_Mode Gas Fuel Flow Control Mode 1

Read Bit 4 ST_Gas_Main_Vent_Prog Gas Main Vent In Progress 1

Read Bit 5 ST_Gas_Valve_Check_Complete Gas Fuel Valve Check Sequence Complete 1

Read Bit 6 ST_Gas_Vlv_Ck_Prog Gas Fuel Valve Check In Progress 1

Read Bit 7 ST_GV_Cycle_Test_Active Guide Vane Cycle Test Active 1

Read Bit 8 ST_GV_Cycle_Test_Failed Guide Vane Cycle Test Failed 1

Read Bit 9 ST_GV_Cycle_Test_Passed Guide Vane Cycle Test Passed 1

Read Bit 10 ST_GV_Manual_Cycle_Test_Enable Guide Vane Manual Cycle Test Enabled 1

Read Bit 11 ST_Initial_Vent_Active Gas Valve Check Initial Venting is Active 1

Read Bit 12 ST_L340_1_ON Gas Fuel Torch Valve Energized 1

Read Bit 13 ST_L341_1_ON Primary Gas Fuel Shutoff Valve Energized 1

Read Bit 14 ST_L341_3_ON Gas Fuel Vent Valve Energized 1

Read Bit 15 - MSBS T_L342_1_ON Secondary Gas Fuel Shutoff Valve Energized 1

40078 Read LSB- 0 Bit ST_Light_Off Light Off 1

Read Bit 1 ST_Light_Ramp_Mode Light Off Ramp Control Mode 1

Read 2Bit ST_Load_Mode Load Control Mode 1

Read Bit 3 ST_Max_Fuel_Mode Max Fuel Command Mode 1

Read Bit 4 ST_Min_Fuel_Mode Min Fuel Control Mode 1

Read Bit 5 ST_Ngp_Accel_Mode Gas Producer Acceleration Control Mode 1

Read Bit 6 ST_Npt_Control_Mode Power Turbine Speed Control Mode 1

Read Bit 7 ST_Primary_SO_Valve_Check Gas Valve Check - Primary Shutoff Leak Check Test Active 1

Read Bit 8 ST_Secondary_SO_Valve_Check Gas Valve Check - Secondary Shutoff Leak Check Test Active 1

Read Bit 9 ST_SoLoNox_Min_Pilot Solonox Control Min Pilot Mode 1

Read Bit 10 ST_SoLoNox_Mode_Active Solonox Control Mode Active 1

Read Bit 11 ST_Start_Fuel_Flow_High Start Gas Fuel Flow High 1

Read Bit 12 ST_Start_Ramp_Mode Start Ramp Control Mode 1

Read Bit 13 ST_T5_Control_Mode T5 Temperature Control Mode 1

Read Bit 14 ST_Crank_Speed_Established Engine At Crank Speed 1

Read Bit 15 MSB ST_Slow_Roll_Enabled- Slow Roll Enabled 1

40079 Read LSBBit - 0 ST_Slow_Roll_Mode Slow Roll Mode 1

Read Bit 1 ST_VFD430_Config_Done Start VFD Configuration Complete 1

Read Bit 2 ST_VFD430_Config_Enable Start Motor VFD Parameter Configuration Enabled 1

Read Bit 3 ST_VFD430_Run_Command Start VFD Run Command ON 1

Read Bit 4 ST_AC_Main_Lube_Pump_1_Comman Main Lube Oil Pump 1 Run Command ON 1

Read Bit 5 ST_AC_Main_Lube_Pump_1_Main Main Lube Oil Pump 1 Selected as Main 1

Read Bit 6 ST_AC_Main_Lube_Pump_1_Press Main Lube Oil Pump 1 Pressurized 1

Read Bit 7 ST_AC_Main_Lube_Pump_2_Comman Main Lube Oil Pump 2 Run Command ON 1

Read Bit 8 ST_AC_Main_Lube_Pump_2_Main Main Lube Oil Pump 2 Selected as Main 1

Read Bit 9 ST_AC_Main_Lube_Pump_2_Press Main Lube Oil Pump 2 Pressurized 1

Read Bit 10 ST_Backup_Lube_Oil_Pump_Test_Fail Backup Lube Oil Pump Test Failed 1

Read Bit 11 ST_Backup_Lube_Oil_Pump_Test_Pas Backup Lube Oil Pump Test Passed 1

Read Bit 12 ST_Backup_Lube_Pump_Command Backup Lube Oil Pump Run Command ON 1

Read Bit 13 ST_Backup_Lube_Pump_Press Backup Lube Oil Pump Pressurized 1

Read Bit 14 ST_Backup_Pump_Test_Active Backup Lube Oil Pump Test In Progress 1

Read Bit 15 MSB ST_Compressor_Mode- Lube Oil Compressor Mode 1

40080 Read Bit LSB0 - ST_Controller_Active Controller Active Relay Set 1

Read Bit 1 ST_Engine_Turning_Mode Lube Oil Engine Turning Mode 1

Read Bit 2 ST_Engine_Turning_Post_Lube_Mode Lube Oil Engine Turning and Post Lube Mode 1

Read Bit 3 ST_Lube_Oil_Circ_Heater_Mode Lube Oil Circulation Heater Mode 1

Read Bit 4 ST_Lube_Oil_Clr_1_Man Lube Oil Cooler 1 Manual Run Command 1

Read Bit 7 ST_Lube_Oil_Cooler_Fan_1_On Lube Oil Cooler Fan 1 Run Command 1

Read Bit 10 ST_Lube_Oil_Header_Press Lube Oil Header Pressurized 1

Read Bit 11 ST_Lube_Oil_Tank_Heater_On Lube Oil Tank Heater ON 1

Read Bit 12 ST_Lube_Startup_Sequence Lube Oil Pump Startup Sequence 1

Read Bit 13 ST_Manual_Lube Manual Lube Active 1

Read Bit 14 ST_Oil_Clr_1_2 Lube Oil Cooler Fans 1 and 2 Selected 1

Read Bit 15 MSB ST_Oil_Clr_1_3- Lube Oil Cooler Fans 1 and 3 Selected 1

40081 Read Bit 0 LSB- ST_Oil_Clr_2_3 Lube Oil Cooler Fans 2 and 3 Selected 1

Read Bit 1 ST_Post_Lube_Active Post Lube Active 1

Read Bit 2 ST_Post_Lube_Mode Lube Oil Post Lube Mode 1

Read Bit 3 ST_Pre_Engine_Turning_Mode Lube Oil Pre Engine Turning Mode 1

Read Bit 4 ST_Pre_Lube_Mode Lube Oil Pre Lube Mode 1

Read Bit 5 ST_Pump_Check_Mode Lube Oil Pump Check Mode 1

Read Bit 6 ST_Restart_BU_Pump_Check Backup Pump Check Request During Restart Without Complete Pump Check Required 1

Read Bit 7 ST_VFD420_1_Config_Done Main Lube Oil Pump 1 VFD Parameter Configuration Complete 1

Read Bit 8 ST_VFD420_1_Config_Enable Main Lube Oil Pump 1 VFD Parameter Configuration Enabled 1

Read Bit 9 ST_VFD420_2_Config_Done Main Lube Oill Pump 2 Lube VFD Parameter Configuration Complete 1

Read Bit 10 ST_VFD420_2_Config_Enable Main Lube Oil Pump 2 VFD Parameter Configuration Enabled 1

Read Bit 11 ST_XI322 Backup Lube Pump Running 1

Read Bit 12 ST_XI391 Lube Oil Tank Heater Running 1

Read Bit 13 ST_XI5981 Lube Oil Cooler Fan Running1 1

Read Bit 14 ST_XI5982 Lube Oil Cooler Fan Running2 1

Read Bit MSB ST_XI598315 - Lube Oil Cooler Fan Running3 1

40082 Read Bit 0 - LSB ST_AIC5201103_HH N2 Skid Oxygen Level High Shutdown Bypassed 1

Read Bit 1 ST_Auto_Fuel Fuel Skid Auto Valve Control 1

Read Bit 2 ST_Auto_Fuel_PCV Fuel Skid Auto PCV Control 1

Read Bit 3 ST_BSV520901_Closed Fuel Skid Blowdown Valve Fully Closed 1

Read Bit 4 ST_BSV520901_Open Fuel Skid Blowdown Valve Fully Open 1

Read Bit 5 ST_CEMS_AutoCal CEMS Auto Calibration Cycle Active 1

Read Bit 6 ST_CEMS_Blowback CEMS Blowback Cycle Active 1

Read Bit 7 ST_CEMS_Span_1 CEMS CO/O2/HC Span Gas On 1

Read Bit 8 ST_CEMS_Span_2 CEMS NOX Span Gas On 1

Read Bit 9 ST_CEMS_Zero_Gas CEMS Zero Gas On 1

Read Bit 10 ST_Cooler_Ctrl_Inhibited Aftercooler Tuning and Control Inhibited 1

Read Bit 11 ST_Engage_Man_Fuel Engage Manual Fuel Valves Prompt 1

Read Bit 12 ST_Engage_Man_Lube Engage Manual Lube 1

Read Bit 13 ST_Feed_Air_Vlv_Close N2 Feed Air Inlet Valve Fully Closed 1

Read Bit 14 ST_Feed_Air_Vlv_Open N2 Feed Air Inlet Valve Fully Open 1

Read Bit 15 MSB ST_Fuel_Sequence_01- Open Fuel Inlet Valve 1

40083 Read Bit LSB- 0 ST_Fuel_Sequence_02 Reset Fuel Inlet Valve 1

Read Bit 1 ST_Fuel_Sequence_03 Close Fuel Blowdown Valve 1

Read Bit 2 ST_Fuel_Sequence_04 Reset Fuel Blowdown Valve 1

Read Bit 3 ST_Fuel_Sequence_05 Reset Fuel Outlet Valve 1

Read Bit 4 ST_Fuel_Sequence_06 Reset Fuel Bypass Valve 1

Read Bit 5 ST_Fuel_Skid_Heater_Run Fuel Skid Heater Run Command 1
