Measuring Signal Generator Response Through
An Adc Evaluation Board
Limuel R. Landicho, Irvin B. Garcia, Glenn N. Ortiz, Mark Joseph B. Enojas
Abstract Many semiconductor industries use Automated Test Equipment (ATE) which comprises of linear and mixed signals instruments. External Signal generators are usually not associated to the equipment’s calibration or checker routine. This research introduces a method of testing the functionality of the signal generators by establishing a signal generator checker for automated test equipment using Analog to Digital Converter (ADC) evaluation board and Field Programmable Gate Array (FPGA) capture board. This setup will enable the system to focus on fundamental frequency and amplitude level of the signal generator. A Visual Basic Application (VBA) program was created to control the desired frequency and amplitude level of the signal generator. The FPGA evaluates the digital signal and graphically presents it in a system data platform software. In result, the graphical output displays the quality of the signal generator through the full-scale fundamental frequency and amplitude levels. The common problems encountered using ATEs, namely; loosed RF cable, incorrect RF cable connections on ATE configuration, and noisy signal generators can be detected. This research is precedent to a more intelligent and complex signal generator checker to ensure signal integrity.
Index Terms: analog to digital converter, automated test equipment, device under test, field programmable gate array, signal generator, visual basic application
—————————— ——————————
1
INTRODUCTION
There are several means to ensure ATEs are working properly. Some methods of tests for ATEs are based on parameters such as reliability, maintenance, and testability [1]. It is vital to ensure that each of the test equipment used in ATEs are checked. Signal generators play an important role in providing RF signals to test equipment. Examples of such devices tested are nonlinear microwave devices where the phase and amplitude are critically monitored [2]. Signal generators need to be checked based on frequency and amplitude of signals. Frequency band from 500 kHz to 20 MHz can be tested using a simple crystal oscillator and high power amplifier [3]. The signal quality is evaluated based on the signal to noise ratio
and distortion (SINAD) given the formula of eq. (1), where PAll
is the total power of all signal components, P0 the component
power, and P1, the carrier power [3]. Common values of
SINAD for signal generators in these frequencies are in 130 dB.
For pulsed RF signals, the device under test (DUT) is being evaluated based on its amplitude and phase. Evaluation and verification for such signals are done using digital sampling oscilloscopes [4].
Another method of testing components in ATEs for RF signals is through matching networks. This method tries to address the degradation in RF signal. However, it can cover but not all the frequencies defined for such ranges [5]. Some model of a mobile signal viewer was developed for convenience [6]. However, interference is more felt in the airwaves, especially when mobile devices such as smart phones are used. Therefore, development of a more robust and reliable system needs to be established that is insusceptible to such interference or noise. In order to retain the integrity of signals, a method of signal transformation is needed [7]. The FPGA reinforces the integrity of digital signal measurement. [8]. In tests, debugging, and calibration of signal generators for ATEs, visuals and interface for engineers and technicians to the equipment or machine is a great advantage [6], [9], [10]. This paper presents a method of testing and measurement of the Signal Generators used for ATEs based on its fundamental frequency and amplitude level response from the instrument itself up to the test head. As an improvement, an excel VBA graphical user interface (GUI) was created to control the signal generator’s desired input frequency and amplitude level as well as the value of clock frequency based on the ADC evaluation board product specifications. An ADC evaluation board was used to convert the analog frequency signal into digital codes in lieu of the ADC voltage reference along with its complementary FPGA capture board that evaluates the results of the signal response of the signal generator. A system data platform was used to demonstrate the fundamental frequency and amplitude level response of the signal generator via graphical representation of the signal on a computer software. In addition, this study highlights an alternative application of ADC evaluation board, which is also used as a customer-based systems data analyzer to ensure that the product performs on the conditions set by the product specification data sheet. It is utilized to check the signal generator’s functionality by connecting the fundamental frequency and amplitude response which is defined by eq. (2) based on the full scale power response. The succeeding sections are discussed: Section 2, the methodology which explains the process flow and tests and evaluation, Sectionv3, presents and discusses the results of the tests, and Section 4, the concluding statement.
