glassSCREENS
2 0 2 0 © C A R V A R T I N F O @ C A R V A R T . C O M 2 1 2 . 6 7 5 . 0 0 3 0 g l a s s S C R E E N S > W O R K S T A T I O N S 2 C A R V A R T . C O M
Types
DISK-TOP
Workstations>DISK>TOP (GS_SWD)LINE-TOP
LEVEL
Workstations>LINE>TOP (GS_SWL) Workstations>LEVEL (GS_SWLV) Workstations>LINE>SIDE (GS_SWL_S)EDGE
Workstations>EDGE (GS_EDG) Workstations>DISK>SIDE (GS_SWD_S)LINE-SIDE
DISK-SIDE
Workstations>LINE>Top
TYPICAL DETAILS EXAMPLE CONFIGURATIONS (GS_SWL)Specifications
A P P L I C A T I O N S —Protection for staff and for clients, customers, visitors.
Work station protection, Lobbys, Reception Area, Hospitals, Restaurants, Cafeterias, Transaction Areas.
H A R D W A R E M A T E R I A L S / F I N I S H E S —
Standard: White, Metallic Silver, Black Inquire for more finish options
PANEL WIDTHS (OVERALL MAXIMUM)
Maximum Width (2 Brackets): 60”
Larger sizes available with engineering approval
PANEL HEIGHTS —
Maximum Height: 32”
MOUNTING OPTIONS —
VHB Tape, Mechanically Fastened GLASS THICKNESS —
1/4” [6mm] 5/16 [8mm]
WARRANTY —
10 Year Limited Warranty
Workstations>LINE>Top (GS_SWL)
CARVART’s benching screens offer a timeless architectural design that are flexible and adapt-able, while providing hygienic protection for our ever-changing workplace. The sleek aesthetics blend into any space and are ideal for protection and engagement with non-porous, scratch resis-tant tempered glass that is increasingly durable, ensuring a greater product longevity.
1134" [299] 234" [70] 12 3 16 " [310] 11516" [50] MAX HEIGHT: 32" CARVART GLASS MAX THICKNESS: 516" [8]
2 0 2 0 © C A R VA R T I N F O @ C A R VA R T. C O M 2 1 2 . 6 7 5 . 0 0 3 0
g l a s s S C R E E N S > W O R K S T A T I O N S
4 C A R VA R T. C O M
Workstations>LINE>Side
TYPICAL DETAILS EXAMPLE CONFIGURATIONS (GS_SWL_S)Specifications
A P P L I C A T I O N S —Protection for staff and for clients, customers, visitors.
Work station protection, Lobbys, Reception Area, Hospitals, Restaurants, Cafeterias, Transaction Areas.
H A R D W A R E M A T E R I A L S / F I N I S H E S —
Standard: White, Metallic Silver, Black Inquire for more finish options
PANEL WIDTHS (OVERALL MAXIMUM)
Maximum Width (2 Brackets): 60”
Larger sizes available with engineering approval
PANEL HEIGHTS —
Maximum Height: 32”
MOUNTING OPTIONS —
Clamp, Mechanically Fastened GLASS THICKNESS —
1/4” [6mm] 5/16 [8mm]
WARRANTY —
10 Year Limited Warranty
Workstations>LINE>Side (GS_SWL_S)
CARVART’s benching screens offer a timeless architectural design that are flexible and adapt-able, while providing hygienic protection for our ever-changing workplace. The sleek aesthetics blend into any space and are ideal for protection and engagement with non-porous, scratch resis-tant tempered glass that is increasingly durable, ensuring a greater product longevity.
CARVART GLASS MAX HEIGHT: 32" 512" [139] 115 16 " [50] 11516" [50] 13 34" [350] MAX THICKNESS: 516" [8] 115 16 " [50] ADJUSTABLE FASTENING UP TO 1-1/2"
2 0 2 0 © C A R VA R T I N F O @ C A R VA R T. C O M 2 1 2 . 6 7 5 . 0 0 3 0
g l a s s S C R E E N S > W O R K S T A T I O N S
6 C A R VA R T. C O M
TYPICAL DETAILS
Workstations>DISK>Top
A P P L I C A T I O N S —
Protection for staff and for clients, customers, visitors.
Work station protection, Lobbys, Reception Area, Hospitals, Restaurants, Cafeterias, Transaction Areas.
H A R D W A R E M A T E R I A L S / F I N I S H E S —
Material: Powdercoated Steel Base Finishes: Black, Grey-White
PANEL WIDTHS —
Maximum Width (2 Brackets): 36”
Larger sizes available with engineering approval
PANEL HEIGHTS —
Maximum Height: 26-3/4”
MOUNTING OPTIONS —
VHB Tape, Mechanically Fastened
GLASS THICKNESSES —
1/4” [6mm]
WARRANTY —
10 Year Limited Warranty
EXAMPLE CONFIGURATIONS (GS_SWD)
Specifications
Workstations>DISK>Top (GS_SWD)CARVART’s benching screens offer a timeless architectural design that are flexible and adapt-able, while providing hygienic protection for our ever-changing workplace. The sleek aesthetics blend into any space and are ideal for protection and engagement with non-porous, scratch resis-tant tempered glass that is increasingly durable, ensuring a greater product longevity.
R3116" [R78] 618" [156] MAX HEIGHT: 26 3 4 " MAX THICKNESS: " [5] POWDER COATED STEEL BASE R1516" [R24] 518" [130] 1 8" [4 ] 34" [19] UNDERCUT 14
2 0 2 0 © C A R VA R T I N F O @ C A R VA R T. C O M 2 1 2 . 6 7 5 . 0 0 3 0
g l a s s S C R E E N S > W O R K S T A T I O N S
8 C A R VA R T. C O M
TYPICAL DETAILS
Workstations>DISK>Front
A P P L I C A T I O N S —
Protection for staff and for clients, customers, visitors.
Work station protection, Lobbys, Reception Area, Hospitals, Restaurants, Cafeterias, Transaction Areas.
H A R D W A R E M A T E R I A L S / F I N I S H E S —
Material: Powdercoated Steel Base Finishes: Black, Grey-White
PANEL WIDTHS —
Max Width: 60”
PANEL HEIGHTS —
Max Height: 26-3/4”
MOUNTING OPTIONS —
Clamp, Mechanically Fastened
MAX TABLE THICKNESS —
1-1/4”
GLASS THICKNESSES —
1/4” [6mm]
WARRANTY —
10 Year Limited Warranty
EXAMPLE CONFIGURATIONS (GS_SWB_F)
Specifications
Workstations>DISK>Front (GS_SWB_F)
CARVART’s benching screens offer a timeless architectural design that are flexible and adapt-able, while providing hygienic protection for our ever-changing workplace. The sleek aesthetics blend into any space and are ideal for protection and engagement with non-porous, scratch resis-tant tempered glass that is durable, ensuring a greater product longevity.
2 0 2 0 © C A R VA R T I N F O @ C A R VA R T. C O M 2 1 2 . 6 7 5 . 0 0 3 0
g l a s s S C R E E N S > W O R K S T A T I O N S
1 0 C A R VA R T. C O M
Workstations>LEVEL
EXAMPLE CONFIGURATIONS (GS_SWLV)
Specifications
A P P L I C A T I O N S —
Space division between working areas
H A R D W A R E M A T E R I A L S / F I N I S H E S —
Satin Anodized
PANEL WIDTHS (OVERALL MAXIMUM)—
Inquire for layout options
PANEL HEIGHTS —
Max Height: 32”
MOUNTING OPTIONS —
Clamp, Mechanically Fastened
MAX TABLE THICKNESS —
1-1/4”
GLASS THICKNESSES —
1/4” - 1/2”
WARRANTY —
10 Year Limited Warranty
Workstations>LEVEL (GS_SWLV)
CARVART’s benching screens offer a timeless architectural design that are flexible and adapt-able, while providing hygienic protection for our ever-changing workplace. The sleek aesthetics blend into any space and are ideal for protection and engagement with non-porous, scratch resis-tant tempered glass that is increasingly durable, ensuring a greater product longevity.
TYPICAL DETAILS 3 11 16 " [94] 534" [146] 3316" [82] 4516" [110] CARVART GLASS MAX HEIGHT: 32"
2 0 2 0 © C A R V A R T I N F O @ C A R V A R T . C O M 2 1 2 . 6 7 5 . 0 0 3 0 g l a s s S C R E E N S > W O R K S T A T I O N S C A R V A R T . C O M 1 2
Workstations>EDGE
EXAMPLE CONFIGURATIONS (GS_EDG)Specifications
A P P L I C A T I O N S —Space division between working areas
H A R D W A R E M A T E R I A L S / F I N I S H E S —
Refer to Finish Chart for standard colors
PANEL WIDTHS (OVERALL MAXIMUM)—
Inquire for layout options
PANEL HEIGHTS —
Maximum Height: 32” Maximum 48” per return
MOUNTING OPTIONS —
VHB Tape, Mechanically Fastened
GLASS THICKNESSES —
1/4”
WARRANTY —
10 Year Limited Warranty
NOTE: All EDGE workstations must have glass return or be mounted to wall.
Workstations>EDGE (GS_EDG)
CARVART’s benching screens offer a timeless architectural design that are flexible and adapt-able, while providing hygienic protection for our ever-changing workplace. The sleek aesthetics blend into any space and are ideal for protec-tion and engagement with non-porous, scratch resistant tempered glass that is more resistant to bacteria and increasingly durable, ensuring a greater product longevity.
