Honda Solenoid Identification Guide
It is often difficult to distinguish between the various Honda solenoids because of the close physical similarities
between them. We developed this Identification Guide to help eliminate the confusion. This Guide features
extremely detailed application information, plus sharp color pictures to visually compare and identify the solenoids.
At the beginning of the Guide is a 2-page Index which cross-references the solenoids by Vehicle, and by
Transmission Code. Whether you’re searching for solenoids by vehicle or by transmission code, the Index provides
a quick reference to the correct page of the following ID Guide, as well as the page number in the 2005 Axiom
Parts Catalog.
Vehicle Years Solenoids ID Guide Page Catalog Page
2.2CL 1996-97 All 7 440 2.3CL 1998-99 All 3 427 2.5TL 1995-98 All 10 458 3.0CL 1996-99 All 4 432 3.2TL 1996-98 All 9 452 3.2TL 1999 All 4 432 3.2TL 2000-03 (4 Speed) All 4 432
3.2TL 2000-03 (5 Speed) Linear Solenoids 11 460
3.2TL 2000-03 (5 Speed) Shift Solenoids 12 460
3.2TL 2004 Linear Solenoids 11 460
3.2TL 2004 Shift Solenoids 12 460
3.5RL 1996-03 All 9 452
Accord 1990-93 All 7 440
Accord 1994 All 7 440
Accord 1995-97 (4 cyl) All 7 440
Accord 1995-97 (V6) All 4 432
Accord 1998-02 (4 cyl) All 3 427
Accord 1998-02 (V6) All 4 432
Accord 2003-Up Linear Solenoids 11 460
Accord 2003-Up Shift Solenoids 12 460
Civic 1988-91 (2wd) All 1 414
Civic 1992-03 All 6 435
CR-V 1997-01 All 5 435
CR-V 2002-04 All 5 435
CRX 1988-91 All 1 414
Del Sol 1992-97 All 6 435
Integra 1990-01 All 8 447
Legend 1986-90 All 2 423
Legend 1991-95 All 9 452
MDX 2001-Up Linear Solenoids 11 460
MDX 2001-Up Shift Solenoids 12 460
Oasis 1995-97 All 7 440 Oasis 1998 All 3 427 Oasis 1999-01 All 4 432 Odyssey 1995-97 All 7 440 Odyssey 1998 All 3 427 Odyssey 1999-01 All 4 432
Odyssey 2002-04 Linear Solenoids 11 460
Odyssey 2002-04 Shift Solenoids 12 460
Prelude 1988-91 All 1 414
Prelude 1992-96 All 7 440
Prelude 1997-01 All 3 427
RSX 2002-Up Linear Solenoids 11 460
RSX 2002-Up Shift Solenoids 12 460
Honda Code
ID
Guide
Page
Catalog
Page
Honda Code
ID
Guide
Page
Catalog
Page
A24A 6 435 M6HA 3 427A2YA 6 435 M7WA (Linear Solenoids) 11 460
A4RA 6 435 M7WA (Shift Solenoids) 12 460
A6VA 7 440 M7ZA 4 432
AOYA 7 440 MAXA 3 427
APXA 7 440 MAYA (Linear Solenoids) 11 460
B46A 6 435 MAYA (Shift Solenoids) 12 460
B4RA 6 435 MCLA (Linear Solenoids) 11 460
B6VA 3 427 MCLA (Shift Solenoids) 12 460
B7TA 4 432 MCVA, MRVA 5 435
B7VA 4 432 MDKA (Linear Solenoids) 11 460
B7WA (Linear Solenoids) 11 460 MDKA (Shift Solenoids) 12 460
B7WA (Shift Solenoids) 12 460 MDLA 5 435
B7XA 4 432 MDMA 5 435
B7YA 4 432 MDWA 3 427
BAXA 3 427 ML4A 1 414
BAYA (Linear Solenoids) 11 460 MP1A 7 440
BAYA (Shift Solenoids) 12 460 MP1B 7 440
BCLA (Linear Solenoids) 11 460 MP7A 8 447
BCLA (Shift Solenoids) 12 460 MPJA 7 440
BDRA 6 435 MPOA 7 440
BGFA (Linear Solenoids) 11 460 MPRA 8 447
BGFA (Shift Solenoids) 12 460 MPWA (Accord) 7 440
BGHA (Linear Solenoids) 11 460 MPWA (Vigor) 10 458
BGHA (Shift Solenoids) 12 460 MPXA 7 440
BMXA 6 435 MPYA 9 452
BOYA 7 440 MPZA 4 432
BYBA (Linear Solenoids) 11 460 MY8A 1 414
BYBA (Shift Solenoids) 12 460 P24A 6 435
G4 2 423 PL5X 2 423 K4 1 414 PX4B 8 447 L4 1 414 PY8A 1 414 L5 2 423 S24A 6 435 M1WA 10 458 S4RA 6 435 M24A 6 435 S4XA 8 447 M4RA 6 435 SKWA 8 447 M4TA 5 435 SLXA 6 435 M5DA 9 452 SP7A 8 447 M5HA 9 452 SPX4 7 440
Index by Transmission Code
Honda Solenoids
2005 Catalog page 414
AXIOM Part No: D60420E
OEM Part No: 28203 PK4 305
DESCRIPTION: Solenoid Assembly (Inside of Case) 1988-89 (K4 code)
AXIOM Part No: D60420EA
OEM Part No: 28300 PK4 013
DESCRIPTION: Solenoid Assembly (Outside of Case)
1988 (K4 code)
AXIOM Part No: D60420L
OEM Part No: 28200 PL4 681
DESCRIPTION: Solenoid (Outside of Case) 1988-91 (L4, ML4A code)
AXIOM Part No: D60425E
OEM Part No: 28300 PK4 901
DESCRIPTION: Solenoid, TCC (Lockup)
1989 (K4 code)
AXIOM Part No: D60425EA
OEM Part No: 28300 PY8 J10
DESCRIPTION: Solenoid, TCC (Lockup) 1990-91 (MY8A, PY8A code)
External Wire Harness Repair Kits:
60445EK 60445EAK 60445HAK 60445YK
PRODUCT INFORMATION
“Copyright 2007 Axiom Automotive Technologies, Inc. No part of this work may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, or by any information storage or retrieval system without the prior written approval of Axiom Automotive Technologies, Inc."
1988-91 K4, MY8A, PY8A 1988-91 L4, ML4A
1988-91 Prelude
Honda Solenoids
2005 Catalog page 423
AXIOM Part No: D60420H
OEM Part No: 27720 PG4 003
DESCRIPTION: Solenoid Assembly (Inside of Case) 1986-87 (G4 code)
AXIOM Part No: D60420HA
OEM Part No: 28200 PL5 033
DESCRIPTION: Solenoid Assembly (Outside of Case) 1987-90 (L5, PL5X code)
AXIOM Part No: D60425H
OEM Part No: 28300 PL5 033
DESCRIPTION: Solenoid, Lockup 1987-90 (L5 code)
External Wire Harness Repair Kits:
60445EK 60445EAK 60445HAK 60445YK
PRODUCT INFORMATION
Contact Your Axiom Salesperson Today
PI#200702jro01 page 2 of 12
“Copyright 2007 Axiom Automotive Technologies, Inc. No part of this work may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, or by any information storage or retrieval system without the prior written approval of Axiom Automotive Technologies, Inc."
1986-87 G4 1988-89 L5 1990 PL5X
Honda Solenoids
2005 Catalog page 427
AXIOM Part No: D80425
OEM Part No: 28300-PX4-003 / 014
DESCRIPTION: Solenoid, Lockup
1997-02
AXIOM Part No: D80428
OEM Part No: 28250-P6H-024
DESCRIPTION: Solenoid, Linear
1997-02
AXIOM Part No: D80420
OEM Part No: 28200-PX4-003 / 014
DESCRIPTION: Solenoid, Shift
1997 (M6HA code)
AXIOM Part No: 80430A
OEM Part No: 28400-P6H-003
DESCRIPTION: Solenoid, 3 Way Shift (Black connector) 1998-02
AXIOM Part No: 80430B
OEM Part No: 28500-P6H-003
DESCRIPTION: Solenoid, 3 Way Shift (Brown connector) 1998-02
** In the 2005 parts catalog page 427, please delete lines with 80420A and 80420C (Shift Assemblies)
PRODUCT INFORMATION
“Copyright 2007 Axiom Automotive Technologies, Inc. No part of this work may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, or by any information storage or retrieval system without the prior written approval of Axiom Automotive Technologies, Inc."
80430A 80430B 1998-99 B6VA 1998-02 BAXA, MAXA 1997-01 M6HA 1998 MDWA 1998-99 2.3CL 1998-02 Accord 4 cyl 1997-01 Prelude 1998 Odyssey, Oasis 2.3L
Honda Solenoids
2005 Catalog page 432
AXIOM Part No: 80420B
OEM Part No: 28200-POZ-003
DESCRIPTION: Solenoid, Lockup
* change # in catalog from 80425B to 80420B
AXIOM Part No: 80428
OEM Part No: 28250-P6H-024
DESCRIPTION: Solenoid, Linear
1998-02
AXIOM Part No: 80420B
OEM Part No: 28200-POZ-003
DESCRIPTION: Solenoid, Shift
1995-97
AXIOM Part No: 80430A
OEM Part No: 28400-P6H-003
DESCRIPTION: Solenoid, Shift B (Black connector) 1998-02
AXIOM Part No: 80430B
OEM Part No: 28500-P6H-003
DESCRIPTION: Solenoid, Shift C (Brown connector) 1998-02
** In the 2005 parts catalog page 432, please delete line with 80420BK (Shift Assembly)
PRODUCT INFORMATION
Contact Your Axiom Salesperson Today
PI#200702jro01 page 4 of 12
“Copyright 2007 Axiom Automotive Technologies, Inc. No part of this work may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, or by any information storage or retrieval system without the prior written approval of Axiom Automotive Technologies, Inc."
80430A 80430B 1995-97 MPZA
1997-02 B7XA, M7ZA 1999-01 B7TA, B7VA, B7YA
1995-02 Accord V6 1999-01 Odyssey, Oasis 1996-99 3.0L CL 1999-03 3.2L TL
Honda Solenoids
2005 Catalog page 435 (CR-V)
AXIOM Part No: 90420A
OEM Part No: 28200-P4R-003
DESCRIPTION: Solenoid, Shift
1997-01 (CR-V)
AXIOM Part No: D90430A
OEM Part No: 28400-PRP-004
DESCRIPTION: Solenoid, Shift (2 required) 2002-04 (CR-V) Brown connector
AXIOM Part No: D90430B
OEM Part No: 28500-PRP-004
DESCRIPTION: Solenoid, Shift (2 required) 2002-04 (CR-V) Black connector
AXIOM Part No: 90425A
OEM Part No: 28300-P24-J01
DESCRIPTION: Solenoid, Lockup
1997-01 (CR-V)
AXIOM Part No: 90428A
OEM Part No: 28250-P4R-315
DESCRIPTION: Solenoid, Linear (Single)
1997-01 (CR-V)
AXIOM Part No: 90428B
OEM Part No: 28250-PRP-013
DESCRIPTION: Solenoid, Linear (Single)
2002-04 (CR-V)
AXIOM Part No: 90428D
OEM Part No: 28250-PLX-305
DESCRIPTION: Solenoid, Linear (Dual)
2002-04 (CR-V)
PRODUCT INFORMATION
“Copyright 2007 Axiom Automotive Technologies, Inc. No part of this work may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, or by any information storage or retrieval system without the prior written approval of Axiom Automotive Technologies, Inc."
90428B 90428D 1997-01 M4TA, MDLA, MDMA
2002-04 MCVA, MRVA 1997-01 CR-V 2002-04 CR-V 90430A 90430B 90420A 90425A 90428A
Honda Solenoids
2005 Catalog page 435 (exc CR-V)
AXIOM Part No: 90420A
OEM Part No: 28200-P4R-003
DESCRIPTION: Solenoid, Shift
1996-00 (exc CR-V)
AXIOM Part No: 90420B
OEM Part No: 28200-PLX-003
DESCRIPTION: Solenoid, Shift (Mounts on Case)
2001-03 (exc CR-V)
AXIOM Part No: 90425A
OEM Part No: 28300-P24-J01
DESCRIPTION: Solenoid, TCC (Lockup)
1992-00 (exc CR-V)
AXIOM Part No: 80430A
OEM Part No: 28400-P6H-003
DESCRIPTION: Solenoid, TCC (Lockup) (Mounts on Bell Hsg)
2001-03 (exc CR-V)
AXIOM Part No: 90428A
OEM Part No: 28250-P4R-315
DESCRIPTION: Solenoid, Linear (Single)
1996-00 (exc CR-V)
AXIOM Part No: 90428D
OEM Part No: 28250-PLX-305
DESCRIPTION: Solenoid, Linear (Dual)
2001-03 (exc CR-V)
PRODUCT INFORMATION
Contact Your Axiom Salesperson Today
PI#200702jro01 page 6 of 12
“Copyright 2007 Axiom Automotive Technologies, Inc. No part of this work may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, or by any information storage or retrieval system without the prior written approval of Axiom Automotive Technologies, Inc."
90428A 90428D 1992-03 A24A, A2YA, A4RA,
B4RA, B46A, BDRA, BMXA, M24A, M4RA, P24A, S24A, S4RA, SLXA
1992-03 Civic 1992-97 Del Sol
Honda Solenoids
2005 Catalog page 440
AXIOM Part No: 80425
OEM Part No: 28300-PX4-003 / 014
DESCRIPTION: Solenoid, Lockup
AXIOM Part No: 80420
OEM Part No: 28200-PX4-003 / 014
DESCRIPTION: Solenoid, Shift
External Wire Harness Repair Kits:
80445AK 80445AAK 80445AAEK 80445AEK
** In the 2005 parts catalog page 440, please delete line with 80420D (Solenoid, Shift)
PRODUCT INFORMATION
“Copyright 2007 Axiom Automotive Technologies, Inc. No part of this work may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, or by any information storage or retrieval system without the prior written approval of Axiom Automotive Technologies, Inc."
1990-97 A6VA, SPX4, APXA, AOYA, BOYA, MPOA, MPJA, MPWA (Accord), MPXA 1992-96 MP1A, MP1B
1990-93 Accord (91 Accord Wagon) 1994-97 Accord (4 cyl)
1995-97 Odyssey, Oasis 1992-96 Prelude Si 1996-97 2.2CL
Honda Solenoids
2005 Catalog page 447
AXIOM Part No: 70420A
OEM Part No: 28200-PRO-010
DESCRIPTION: Solenoid, Shift (1990-93)
AXIOM Part No: 70420
OEM Part No: 28200-P56-003
DESCRIPTION: Solenoid, Shift (1994-01)
AXIOM Part No: 70425A
OEM Part No: 28300-PRO-010
DESCRIPTION: Solenoid, TCC (Lockup) (1990-93)
AXIOM Part No: 90425A
OEM Part No: 28300-P24-J01
DESCRIPTION: Solenoid, TCC (Lockup) (1994-01)
External Wire Harness Repair Kit:
70445AK
PRODUCT INFORMATION
Contact Your Axiom Salesperson Today
PI#200702jro01 page 8 of 12
“Copyright 2007 Axiom Automotive Technologies, Inc. No part of this work may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, or by any information storage or retrieval system without the prior written approval of Axiom Automotive Technologies, Inc."
1990 PX4B 1991-93 MPRA
1994-99 MP7A, S4XA, SP7A 2000-01 SKWA
Honda Solenoids
2005 Catalog page 452
AXIOM Part No: 70420B
OEM Part No: 28200-PY4-004
DESCRIPTION: Solenoid, Shift
AXIOM Part No: 70425B
OEM Part No: 28300-PY4-034
DESCRIPTION: Solenoid, TCC (Lockup)
PRODUCT INFORMATION
“Copyright 2007 Axiom Automotive Technologies, Inc. No part of this work may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, or by any information storage or retrieval system without the prior written approval of Axiom Automotive Technologies, Inc."
1991-95 MPYA 1996-03 M5DA 1996-98 M5HA 1991-95 Legend 1996-03 3.5RL 1996-98 3.2TL
Honda Solenoids
2005 Catalog page 458
AXIOM Part No: 70420C
OEM Part No: 28200-PW4-043
DESCRIPTION: Solenoid, Shift
AXIOM Part No: 70425C
OEM Part No: 28300-PW7-003, 28300-P1V-004
DESCRIPTION: Solenoid, TCC (Lockup)
AXIOM Part No: 70428
OEM Part No: 28250-PYZ-003, 28250-PW4-003
DESCRIPTION: Solenoid, Linear
PRODUCT INFORMATION
Contact Your Axiom Salesperson Today
PI#200702jro01 page 10 of 12
“Copyright 2007 Axiom Automotive Technologies, Inc. No part of this work may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, or by any information storage or retrieval system without the prior written approval of Axiom Automotive Technologies, Inc."
1991-94 MPWA (Vigor) 1995-98 M1WA
1991-94 Vigor 1995-98 2.5TL
Honda Linear Solenoids
2005 Catalog page 460
AXIOM Part No: 90428B
OEM Part No: 28250-PRP-013
DESCRIPTION: Solenoid, Linear (Single)
2003-Up Accord 4 cyl (BCLA, MCLA)
2002-Up RSX (MRMA)
AXIOM Part No: 90428C
OEM Part No: 28260-PRP-014
DESCRIPTION: Solenoid, Linear (Dual)
2003-Up Accord 4 cyl (BCLA, MCLA)
2002-Up RSX (MRMA)
AXIOM Part No: 30428D
OEM Part No: 28260-RDK-023
DESCRIPTION: Solenoid, Linear (Single) 2003-Up MDX (MDKA)
AXIOM Part No: 30428C
OEM Part No: 28260-RDK-004
DESCRIPTION: Solenoid, Linear (Dual) 2003-Up MDX (MDKA)
AXIOM Part No: 90428E
OEM Part No: 28250-P7W-003
DESCRIPTION: Solenoid, Linear (Single)
2003-Up Accord V6 (BAYA, MAYA) 2001-02 MDX (BGHA, MGHA) 2002-04 Odyssey (BYBA) 2000-04 3.2TL (B7WA, M7WA)
AXIOM Part No: 80428
OEM Part No: 28250-P6H-024
DESCRIPTION: Solenoid, Linear (Dual)
2003-Up Accord V6 (BAYA, MAYA) 2001-02 MDX (BGHA, MGHA) 2002-04 Odyssey (BYBA) 2000-04 3.2TL (B7WA, M7WA)
PRODUCT INFORMATION
Contact Your Axiom Salesperson Today
“Copyright 2007 Axiom Automotive Technologies, Inc. No part of this work may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, or by any information storage or retrieval system without the prior written approval of Axiom Automotive Technologies, Inc."
B7WA, BAYA, BCLA, BGFA, BGHA, BYBA
M7WA, MAYA, MCLA, MDKA
2003-Up Accord 2001-Up MDX 2002-04 Odyssey 2002-Up RSX 2000-04 3.2TL 90428B 90428C 30428D 30428C 90428E 80428
Honda Shift Solenoids
2005 Catalog page 460
AXIOM Part No: 90430A
OEM Part No: 28400-PRP-004 (3 required)
DESCRIPTION: Solenoid, Shift “A” (Brown Connector) 2003-Up Accord 4 cyl (BCLA, MCLA)
2002-Up RSX (MRMA)
AXIOM Part No: 90430B
OEM Part No: 28500-PRP-004 (2 required)
DESCRIPTION: Solenoid, Shift “B” (Black Connector) 2003-Up Accord 4 cyl (BCLA, MCLA)
2002-Up RSX (MRMA)
AXIOM Part No: 30430C
OEM Part No: 28400-RDK-003 (2 required)
DESCRIPTION: Solenoid, Shift “A” (Brown Connector) 2003-Up MDX (MDKA)
AXIOM Part No: 30430D
OEM Part No: 28500-RDK-003 (2 required)
DESCRIPTION: Solenoid, Shift “B” (Black Connector) 2003-Up MDX (MDKA)
AXIOM Part No: 80430A
OEM Part No: 28400-P6H-003
DESCRIPTION: Solenoid, Shift “B” (Black Connector) 2003-Up Accord V6 (BAYA, MAYA) 2001-02 MDX (BGHA, MGHA) 2002-04 Odyssey (BYBA) 2000-04 3.2TL (B7WA, M7WA)
AXIOM Part No: 80430B
OEM Part No: 28500-P6H-003
DESCRIPTION: Solenoid, Shift “C” (Brown Connector) 2003-Up Accord V6 (BAYA, MAYA) 2001-02 MDX (BGHA, MGHA) 2002-04 Odyssey (BYBA) 2000-04 3.2TL (B7WA, M7WA)
PRODUCT INFORMATION
Contact Your Axiom Salesperson Today
PI#200702jro01 page 12 of 12
“Copyright 2007 Axiom Automotive Technologies, Inc. No part of this work may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, or by any information storage or retrieval system without the prior written approval of Axiom Automotive Technologies, Inc."
B7WA, BAYA, BCLA, BGFA, BGHA, BYBA
M7WA, MAYA, MCLA, MDKA,
2003-Up Accord 2001-Up MDX 2002-04 Odyssey 2002-Up RSX 2000-04 3.2TL 90430A 90430B 30430C 30430D 80430A 80430B
