QUICK START GUIDE
TruPortal
™
TruPortal
™access control solutions have been engineered
and designed to install quickly and easily right out of the box.
These units are ideal for small- to mid-size applications, with
a user-friendly Install Wizard
™feature to assist with each step.
We’ve made configuring TruPortal solutions simple and efficient
for you and intuitive and convenient for your customers.
This quick start guide provides easy to follow instructions to
get your installation started. For more detailed information,
refer to the installation manual included in the kit.
Base System Components
• TruPortal System Controller Board with integrated power supply and standby battery charger and two (2) T-100 series readers (TP-SYS-2D2R only)
• Enclosure with transformer • Installation sheets and quick
reference guides
• CD with Installation Wizard and documentation
Browser compatibility:
Windows: IE, FireFox, Chrome, Safari (PC only)
Note: Not compatible with Mac at this time
Installer Provided Items:
-Door Hardware -Backup Battery
-Power for Base System Door Strikes
- Wiring Infrastructure (Recommended Type for 485: Belden 9842) - Reader Wiring (Recommended Type: 22 Gauge, 6 Conductor, Shielded,
Door Reader Reader Reader Reader Door TP-SYS Controller TVR-10, TVR-30 Digital Video Recorders RS485 SNAP TP-ADD-IO
TruPortal I/O Expansion Module
Install TruPortal
hardware
Make sure to document each device
by location & serial number
1.1
Connect RS485 bus between door
controllers and main controller
1.2
Connect door hardware
Main
Controller
RS485 Bus
Door
Controller
Main & Door
Controllers
Door
Reader
Reader
• There are 4 independent RS485 buses
• You can use any or all of the four buses (31 2-door add-ons
maximum; 8 I/O add-ons maximum; 24 modules per bus maximum).
Using multiple buses provides redundancy • Maximum distance for each bus is 2000 feet
• Refer to wiring diagram on panel door for additional details Caution: Do not power 2-door add-ons from the RS485 bus.
Only connect A+, B-, and 0V to 2-door add-on. Note: Additional Power Supply required.
• Wiring will depend on reader type selected — refer to reader documentation for details
• Optional I/O boards should be wired at this time • Refer to main controller or door controller overlays
for wiring locations
• Make note of serial numbers and locations of door controllers
1.4
Power up panel, connect battery
and let boot properly
Left Panel
Network Socket
Network Cable
• Connect network wiring to Ethernet Port 1 using standard network cable (no crossover cable required) • Connect to network switch or directly to PC
• Connect AC power cable to AC input terminals • Connect to available non-switched AC power source
1.3
Connect network cable
to Ethernet Port 1
Power Up
Connect
2.1
Run “Discovery Utility” on TruPortal
resource CD
2.2
IP Address verification and programming
(DHCP to Fixed)
Configure TruPortal
system
• Insert CD into PC and double-click on “Start.hta” if CD does not Autorun
• If necessary, install .NET 4 Framework and Bonjour prerequisites • Click on Discovery and Installation Wizard icon
• Discovery and Installation Wizard will identify attached panels connected to network or PC
• Alternative connection method: directly connect panel to PC and run Wizard or proceed to Step 3.1 and connect via browser to default IP address of 169.254.1.200
• Configure admin password and IP settings
2.3
Discover the door controllers
2.4
Configure hardware of the door controllers
• Discovery and Installation Wizard will identify attached door controllers
• Confirm each door controller setup in the system configuration by selecting each door controller in the list and clicking “Accept”
Note: Door controllers must be selected and accepted before settings can be configured. If door controllers do not appear, check power and wiring to the door controller.
• Configuration of door controllers is optional • Optionally modify door input supervision settings
Configure TruPortal
software
3.1
Log-in via a browser
• Navigate to panel IP address configured in Step 2.2 in Web browser
• Log-in using admin password (Note: Default user for logging in
is ‘admin’ and the password is “demo”)
• Accept any certificate/security warnings presented by browser • Read and accept the End User License Agreement
• From Home screen, click on Add Person. This will launch the Add Person Wizard.
• Follow Wizard steps
• Wizard will prompt you to create access levels, schedules and holidays (Suggested: create a master access level with sublevels) • Repeat Wizard for additional person(s) (optional)
3.3
Finalize hardware configuration (optional)
3.4
Check for firmware updates (optional)
• Provide meaningful/logical device names (recommended) • Add video devices to system (Recorders and Cameras);
other access control hardware may also be added • Enable time synchronization with time server • Configure security parameters
Note: To finalize hardware configuration, you must be in the System Administration menu.
• This step is optional but suggested to ensure latest firmware is loaded
IP Address: _____________________________
Username: _____________________________
Password: _____________________________
Notes:
Document the physical location of each
device by serial number
As each door configuration (locks, sensors, readers) is installed, provide a description for each, and list the serial numbers of devices associated with each door. This will assist you later when performing the detailed configuration, naming the devices, reader groups and areas when you configure the devices on the TP-Controller.
Door
Specifications subject to change without notice. © 2012 Interlogix, A UTC Fire & Security Company
