DATA SHEET
CISCO NETWORK ASSISTANT
PRODUCT OVERVIEW
Cisco® Network Assistant is a PC-based network management application optimized for LANs of small and medium-sized business with up to 250 users. Cisco Network Assistant offers centralized management of Cisco Systems® switches, routers, and WLAN access points. It supports a wide range of Cisco Catalyst® Intelligent switches from Cisco Catalyst 2950 through Cisco Catalyst 4506. Through a user-friendly GUI, users can configure and manage a wide array of switch functions and start the device manager of Cisco routers and Cisco wireless access points. Cisco Network Assistant is available at no cost and can be downloaded from Cisco.com.
KEY FEATURES AND BENEFITS Configuration
• Intuitive GUI simplifies complicated and repetitive network management tasks. Configuration tools and interactive mode make configuring port setting, quality of service (QoS), security, and access control lists (ACLs) on switches easy.
• Front panel view allows ports to be selected across multiple switches, and parameters (such as a virtual LAN) can be applied in a few mouse clicks.
Monitoring
• Automatically discovers Cisco network devices (such as switches, routers, wireless access points, or IP phones) that are in the LAN and displays them in a physical topology map. This physical topology map displays how the devices are interconnected and gives status updates on device behavior, providing a full view of the network to the administrator.
• Front panel view displays the state, duplex, and speed of switch ports. • Provides detailed reports on switch inventory, ports, QoS, and ACL statistics. • Generates reports that graphically represents bandwidth, link, and QoS utilization. Dynamic Application Update
• Cisco Network Assistant automatically checks for new device and application updates on cisco.com. This facilitates keeping Cisco Network Assistant updated so that new Cisco devices are supported from day one and network administrators have access to the latest features. Smartports
• Smartports automatically implement Cisco best practices during device or port configuration.
• Smartports enable consistent and reliable configuration of security, availability, QoS, and manageability with minimal effort and without requiring prior knowledge of Cisco IOS® Software.
• Smartports save hours of time for network administrators, eliminate human errors, and help ensure that the configuration of the switch is optimized for their applications.
Point and Click Software Upgrade
Launch of Embedded Device Managers
• Allows start of individual device managers for Cisco routers (Security Device Manager) and Cisco wireless LAN (WLAN) access points from the topology view.
• Simplifies management of the network by providing entry to the network via a single IP address while allowing more complex device specific configurations to be performed.
SYSTEM CAPACITY
Cisco® Network Assistant is optimized for small and medium-sized business networks of up to 250 employees.
FEATURES
Switch Configuration
• Host name, IP address, subnet mask, default router, Domain Name System (DNS) server • Port configuration (state, speed, duplex)
• Users and passwords (HTTP, console, Telnet) • Cluster management
• Simple Network Management Protocol (SNMP) parameters, traps management, and event notification • System time, time zone, and Network Time Protocol (NTP) management
• HTTP port setting • Console port settings • Archive configuration • System reload
• Configuration tools and wizards – Security – Voice – Video – Data – Inter-VLAN routing – IP Multicast – Fallback bridging
– Layer 3 switch router redundancy • Switch software upgrade
– HTTP and TFTP software upgrade simultaneously multiple switches Feature Configuration
• Smartports
• VLAN (port, management, voice VLAN, VMPS]) • Access control list (ACL)
• MAC address (dynamic, static, secure)
• Address Resolution Protocol (ARP) cache timeout • QoS
– Trust – Queues
– Maps (class of service [CoS], differentiated services code point [DSCP], IP Precedence) – Classes
– Policers • Rate Limiting
• Spanning Tree Protocol
– Per VLAN Spanning Tree (PVST) – Rapid Per VLAN Spanning Tree (R-PVST) – UplinkFast – Backbone Fast – Root Guard • Port security • Protected port • Flooding prevention • EtherChannel® • Layer 3 switch routing
• Internet Group Management Protocol (IGMP) snooping (multicast groups, multicast router ports) • Cisco Group Management Protocol (GMP) (setting, groups, router ports)
Monitoring • Network topology • Front panel view • Inventory • VLAN map • ARP table
• Spanning Tree Protocol – Status – Roots – Port parameters – Bridge parameters • QoS – Parameters – QoS report – QoS graph • Link – Link report – Link graph • SPAN • Port statistics • Bandwidth graph • ACL report
• Layer 3 switch routing report
• IGMP snooping (multicast groups, multicast router ports) • CGMP (groups, router ports)
PRODUCTS SUPPORTED Fixed Configuration Switches Cisco Catalyst 2950 Series switches Cisco Catalyst 2970 Series switches Cisco Catalyst 3550 Series switches Cisco Catalyst 3560 Series switches Cisco Catalyst 3750 Series switches Cisco Catalyst 2900XL Series switches Cisco Catalyst 2940 Series switches
Cisco Catalyst 2900/2950 LRE Series switches Cisco Catalyst 2955 switch
Cisco Catalyst 3500XL Series switches
Modular Configuration Switches Cisco Catalyst 4500 Series switches Chassis
Cisco Catalyst 4503 switch Cisco Catalyst 4506 switch Supervisors
Cisco Catalyst 4500 Series Supervisor Engine II + Cisco Catalyst 4500 Series Supervisor Engine II +TS Cisco Catalyst 4500 Series Supervisor Engine IV Line Cards
Cisco Catalyst 4500 24 ports 10/100 line card Cisco Catalyst 4500 48 ports 10/100 line card
Cisco Catalyst 4500 24 ports 10/100 Power over Ethernet (PoE) line card Cisco Catalyst 4500 48 ports 10/100 PoE line card
Cisco Catalyst 4500 24 ports 10/100/1000 line card Cisco Catalyst 4500 48 ports 10/100/1000 line card
Power Supplies
Cisco Catalyst 4500 1000 Watts AC Cisco Catalyst 4500 1300 Watts AC
Access Routers*
Cisco 1700 and 1800 series routers Cisco 2600XM and 2800 Series routers
Cisco 3600, 3700, and 3800 series multiservice routers
Wireless Access Points* Cisco Aironet® 1100 and 1200 series Cisco Aironet 350 Series
IP Phones* All Cisco IP Phones
*Discoverable through Cisco Discovery Protocol in the Topology View and management available through respective embedded device managers
SYSTEM REQUIREMENTS Table 1. System Requirements
Disk Space 50 MB of free disk space
Hardware PC with a 233 MHz Pentium processor
Memory 128 MB of RAM
Operating System Windows 98*, NT 4.0, 2000, XP
*Management of Cisco Catalyst 4500 is not supported under Windows 98 Network Network containing at least one of the supported Cisco Catalyst switches
TO DOWNLOAD THE SOFTWARE
Visit http://www.cisco.com/go/NetworkAssistant to download Cisco Network Assistant.
For more information about Cisco Network Assistant, visit http://www.cisco.com/go/NetworkAssistant or contact your local Cisco account representative.
