Lenovo Diagnostics - LOG

(1)

Lenovo Diagnostics - LOG

10/3/2021 15:39:12 - Canceled

The tests were canceled

Final Result Code: W3RPMRHZHKPD-93EM6T

Model: IdeaPad Flex 5 14ARE05

Serial Number: R90Y3XAH

BIOS Version: EECN36WW

Application Version: Lenovo Diagnostics Windows 4.40.2.6 Machine Type-Model: 81X20003US

Wireless MAC Address 1: 8C:C8:4B:95:01:09 Test Start Time & Date: 10/3/2021 15:39:11 Test End Time & Date: 10/3/2021 16:26:30

Modules Test results

Audio Controller Passed

Battery Passed

Bluetooth Canceled

Processor Passed

Display Passed

Display Interface Passed

Keyboard Passed

Memory Passed

Motherboard Passed

PCI Express Passed

Sensors Passed

Storage Passed

Video Card Passed

Wireless Passed

Total modules tested: 14 Passed: 13 Failed: 0 Canceled: 1 Warning: 0 Not Applicable: 0

Audio Controller

Audio Controller Result Code:WAC0000700000-WH7V8F

UDI: ac1

Manufacturer: AMD

High Definition Audio specification: 1.0

Number of input streams: 4

Number of output streams: 4

Number of bidirectional streams: 0

Driver version: 10.0.19041.1081

10/3/2021 15:39:12 - CORB Status Test Passed (1s)

10/3/2021 15:39:13 - Output Stream Test Passed (6s)

10/3/2021 15:39:19 - Input Stream Test Passed (5s)

Audio Controller Result Code:WAC0000300000-WH7V8F

UDI: ac2

Manufacturer: AMD

High Definition Audio specification: 1.0

(2)

Number of input streams: 0

Number of output streams: 4

Number of bidirectional streams: 0

Driver version: 10.0.19041.1081

10/3/2021 15:39:24 - CORB Status Test Passed (1s)

10/3/2021 15:39:25 - Output Stream Test Passed (6s)

Battery

Batter y Result Code:WBA0000100000-WH7V8F

UDI: bat

Resources:

Resource type: Battery

Index: 0

Manufacturer: Celxpert

Serial number: 3670

Design voltage: 11.52 Volts

Full charge capacity: 44.05 Wh (3823 mAh)

Design capacity: 52.5 Wh (4557 mAh)

Cycle count: 170

FRU part number: L19C3PD6

Firmware version: 0006-0088-0100-0004

Driver version: 10.0.19041.1

10/3/2021 15:39:31 - Battery Health Test Passed (1s)

10/3/2021 15:39:31 - Message: Total Battery Charge: 100%

Bluetooth

Bluetooth Adapter Result Code:WBT0000000000-WH7V8F

UDI: Bluetooth Adapter

Resources:

Resource type: Bluetooth

Index: 0

Bluetooth Device Name: Realtek Bluetooth Adapter

Manufacturer: Realtek Semiconductor Corp.

Driver version: 1.8.1030.3008

10/3/2021 15:39:32 - Scan Test Canceled (0s)

10/3/2021 15:39:32 - Message: The Bluetooth device was disconnected

Processor

AMD Ryzen 7 4700U with Radeon Graphics Result Code:WCP0023E00000-WH7V8F

UDI: AMD Ryzen 7 4700U with Radeon Graphics - AMD (0)

Model: AMD Ryzen 7 4700U with Radeon Graphics

Vendor: AMD

Number of Cores: 8

Number of Threads: 8

Signature: 860F01h

(3)

Current Speed: 1.989209 GHz

Features: MMX, AMD64, SSE, SSE2, SSE3, SSSE3, SSE4.1, SSE4.2, AES, AVX, CLMUL, FMA, XOP, PSE, PSE-36, NX, SVM

Cache L1: 8 x 32 KB CPU_DATA_CACHE, 8 x 32 KB CPU_INSTRUCTION_CACHE

Cache L2: 8 x 512 KB CPU_UNIFIED_CACHE

Cache L3: 4 MB CPU_UNIFIED_CACHE

Driver version: 10.0.19041.546

10/3/2021 15:39:32 - BT Instruction Test Passed (0s)

10/3/2021 15:39:32 - x87 Floating Point Test Passed (0s)

10/3/2021 15:39:32 - MMX Test Passed (1s)

10/3/2021 15:39:33 - SSE Test Passed (0s)

10/3/2021 15:39:33 - AES Test Passed (0s)

10/3/2021 15:39:33 - Stress Test Passed (600s)

Display

Generic Display Result Code:WMO000G000000-WH7V8F

UDI: dpy1

Display Index: 1

Current Resolution: 1920x1080

Manufacturer ID: BOE

EDID Version: 1.4

Native Resolution: 1920x1080

Screen Size: 31cm x 17cm

Input Type: Digital

Driver version: 10.0.19041.1151

10/3/2021 15:49:33 - Resolution Fitting Test Passed (1s)

10/3/2021 15:49:34 - Message: Your system can take full advantage of your display resolution.

Display Interface

Generic Display Result Code:WDI0000300000-WH7V8F

UDI: dpy1

Display Index: 1

Current Resolution: 1920x1080

Manufacturer ID: BOE

EDID Version: 1.4

Native Resolution: 1920x1080

Screen Size: 31cm x 17cm

Input Type: Digital

Driver version: 10.0.19041.1151

10/3/2021 15:49:34 - EDID Checksum Test Passed (0s)

10/3/2021 15:49:34 - Message: Checksum valid.

10/3/2021 15:49:34 - Display Communication Test Passed (3s)

10/3/2021 15:49:37 - Message: Test executed with success.

Keyboard

Keyboard Result Code:WKB0000300000-WH7V8F

(4)

UDI: Keyboard Resources:

Resource type: Keyboard

Index: 1

PS/2 keyboard: Detected

Resource type: Keyboard

Index: 2

Vendor ID: 9639

Product ID: 64035

USB keyboard: [Compx - 2.4G Receiver]

10/3/2021 15:49:37 - PS/2 keyboard test Passed (5s)

10/3/2021 15:49:42 - USB keyboard test Passed (0s)

Memory

Physical Memor y Result Code:WME00RVV00000-WH7V8F

UDI: Physical Memory

Physical Memory: 8.000 GB

Resources:

Resource type: Bank

Index: 0

Manufacturer: Hynix

Speed: 3200 MHz

Size: 4.000 GB

Part number: HMA851S6CJR6N-XN

Serial: 00000000

Type: DDR4

Resource type: Bank

Index: 1

Manufacturer: Hynix

Speed: 3200 MHz

Size: 4.000 GB

Part number: HMA851S6CJR6N-XN

Serial: 00000000

Type: DDR4

10/3/2021 15:49:42 - Quick Random Pattern Test Passed (34s)

10/3/2021 15:50:16 - Advanced Integrity Test Passed (10s)

10/3/2021 15:50:26 - Address Test Passed (5s)

10/3/2021 15:50:31 - Bit Low Test Passed (10s)

10/3/2021 15:50:41 - Bit High Test Passed (8s)

10/3/2021 15:50:49 - Walking Ones Left Test Passed (49s)

10/3/2021 15:51:38 - Walking Ones Right Test Passed (49s)

10/3/2021 15:52:27 - Modulo-20 Test Passed (95s)

10/3/2021 15:54:02 - Moving Inversions 8bit Test Passed (103s)

(5)

10/3/2021 15:55:45 - Moving Inversions 32bit Test Passed (110s)

10/3/2021 15:57:35 - Random Pattern Test Passed (148s)

10/3/2021 16:00:03 - Random Number Sequence Test Passed (151s)

10/3/2021 16:02:34 - Block Move Test Passed (88s)

10/3/2021 16:04:02 - Nibble Move Test Passed (28s)

Motherboard

Motherboard Result Code:WMB0000F00000-WH7V8F

UDI: LENOVO-LNVNB161216

Number of USB Host Controllers: 2

Number of PCI: 29

RTC presence: Yes

Resources:

Resource type: PCI Resource

Index: 1

Slot: 00:18.2

Class name: Bridge

Subclass name: Host bridge

Index: 2

Slot: 04:00.3

Class name: Serial bus controller

Subclass name: USB controller

Index: 3

Slot: 04:00.4

Index: 4

Slot: 00:00.0

Index: 5

Slot: 04:00.0

Class name: Display controller

Subclass name: VGA compatible controller

Index: 6

Slot: 04:00.5

Class name: Multimedia controller

Subclass name: Multimedia controller

Index: 7

Slot: 00:18.7

(6)

Index: 8

Slot: 04:00.6

Subclass name: Audio device

Index: 9

Slot: 00:14.3

Subclass name: ISA bridge

Index: 10

Slot: 00:18.4

Index: 11

Slot: 04:00.2

Class name: Encryption controller

Subclass name: Encryption controller

Index: 12

Slot: 04:00.1

Index: 13

Slot: 00:18.0

Index: 14

Slot: 00:14.0

Subclass name: SMBus

Index: 15

Slot: 00:18.6

Index: 16

Slot: 00:01.0

(7)

Index: 17

Slot: 00:02.0

Index: 18

Slot: 00:08.0

Index: 19

Slot: 04:00.7

Class name: Signal processing controller

Subclass name: Signal processing controller

Index: 20

Slot: 00:08.1

Subclass name: PCI bridge

Index: 21

Slot: 00:18.3

Index: 22

Slot: 02:00.0

Class name: Network controller

Subclass name: Network controller

Index: 23

Slot: 00:01.2

Index: 24

Slot: 00:02.2

Index: 25

Slot: 00:02.4

(8)

Index: 26

Slot: 03:00.0

Class name: Mass storage controller

Subclass name: Non-Volatile memory controller

Index: 27

Slot: 00:18.5

Index: 28

Slot: 01:00.0

Class name: Unassigned class

Subclass name: Not available

Index: 29

Slot: 00:18.1

Resource type: USB Resource

Index: 30

USB Version: 1.1

Class name: Human interface device (HID)

Subclass name: Boot interface subclass

Vendor ID: 0x25A7

Product ID: 0xFA23

Vendor: Compx

Product: 2.4G Receiver

Index: 31

Class name: Wireless

Subclass name: Radio frequency

Vendor ID: 0x0BDA

Product ID: 0xC123

Vendor: Not available

Product: Not available

Index: 32

Class name: Miscellaneous device

Subclass name: Not available

Vendor ID: 0x5986

Product ID: 0x212A

Vendor: SunplusIT Inc

Product: Integrated Camera

(9)

10/3/2021 16:04:30 - Chipset Test Passed (0s)

10/3/2021 16:04:30 - PCI/PCI-e Test Passed (0s)

10/3/2021 16:04:30 - RTC Test Passed (9s)

10/3/2021 16:04:39 - USB Test Passed (0s)

10/3/2021 16:04:39 - Message: The parallel data transfer in USB 3.0 is available.

10/3/2021 16:04:39 - Message: One or more devices could not be tested because access to them is blocked by the system.

PCI Express

PCI Express System Result Code:WPE0000100000-WH7V8F

UDI: PCI Express System

PCI0: 4:0.3

PCI1: 4:0.4

PCI2: 4:0.0

PCI3: 4:0.5

PCI4: 4:0.6

PCI5: 4:0.2

PCI6: 4:0.1

PCI7: 4:0.7

PCI8: 2:0.0

PCI9: 3:0.0

PCI10: 1:0.0

Resources:

Resource type: Device

Index: 0

Bus: 0x4

Device: 0x0

Function: 0x3

Device Connected: NO

Vendor Id: 0x1022

Vendor Name: Advanced Micro Devices [AMD]

Class: 0xc

Class Name: Serial bus controller

Subclass: 0x3

Index: 1

Bus: 0x4

Device: 0x0

Function: 0x4

Class: 0xc

Class Name: Serial bus controller

Subclass: 0x3

Index: 2

Bus: 0x4

(10)

Device: 0x0

Function: 0x0

Vendor Name: Advanced Micro Devices [AMD] nee ATI

Class: 0x3

Class Name: Display controller

Subclass: 0x0

Subclass name: VGA compatible controller

Index: 3

Bus: 0x4

Device: 0x0

Function: 0x5

Class: 0x4

Class Name: Multimedia controller

Subclass: 0x80

Subclass name: Multimedia controller

Index: 4

Bus: 0x4

Device: 0x0

Function: 0x6

Class: 0x4

Subclass: 0x3

Index: 5

Bus: 0x4

Device: 0x0

Function: 0x2

Class: 0x10

Class Name: Encryption controller

Subclass: 0x80

Subclass name: Encryption controller

Index: 6

Bus: 0x4

Device: 0x0

Function: 0x1

(11)

Vendor Name: Advanced Micro Devices [AMD] nee ATI

Class: 0x4

Subclass: 0x3

Index: 7

Bus: 0x4

Device: 0x0

Function: 0x7

Class: 0x11

Class Name: Signal processing controller

Subclass: 0x80

Subclass name: Signal processing controller

Index: 8

Bus: 0x2

Device: 0x0

Function: 0x0

Device Connected: YES

Vendor Id: 0x10ec

Vendor Name: Realtek Semiconductor Co., Ltd.

Class: 0x2

Class Name: Network controller

Subclass: 0x80

Subclass name: Network controller

Index: 9

Bus: 0x3

Device: 0x0

Function: 0x0

Vendor Id: 0x1c5c

Vendor Name: Unknown

Class: 0x1

Class Name: Mass storage controller

Subclass: 0x8

Subclass name: Non-Volatile memory controller

Index: 10

Bus: 0x1

Device: 0x0

Function: 0x0

Vendor Id: 0x10ec

Vendor Name: Realtek Semiconductor Co., Ltd.

Class: 0xff

(12)

Class Name: Unassigned class

Subclass: 0x0

Subclass name: Unknown

10/3/2021 16:04:39 - Status Test Passed (2s)

Sensors

Sensors Collection Result Code:WSE0000100000-WH7V8F

UDI: Sensors Collection

SENSOR 0: Accelerometter - 3D Accelerometer (AMD Version : 4.0.6.4,P-ID=3001)

SENSOR 1: Lid Sensor

10/3/2021 16:04:41 - Accelerometer Noise Test Passed (5s)

Storage

SKHynix_HFM256GDHTNI-87A0B - 238.47 GBs Result Code:WHD3OF0000000-WH7V8F

UDI: SKHynix_HFM256GDHTNI-87A0B-NS9BN85731070C51K

Model: SKHynix_HFM256GDHTNI-87A0B

Serial: NS9BN85731070C51K

Current 8S label: 8SSSS0V27608K1KN9C507TJ

Firmware: 11000C00

Size: 238.47 GBs

Temperature: 40 °C

Logical Sector Size: 512

Logical Sectors: 500118192

Protocol: NVMe

Partition Schema: GPT

Unallocated: 1.34 MBs

Driver version: 10.0.19041.789

Resources:

Resource type: Partition

Index: 1

Partition Type: EFI system partition

Size: 260.00 MBs

Index: 2

Partition Type: Microsoft reserved partition

Size: 16.00 MBs

Index: 3

Partition Type: Windows basic data partition

File system: ntfs

Label: Windows-SSD

Mount Point: C:\

Serial: 9039EB34

Size: 237.23 GBs

Used: 61.06 GBs

Free: 176.16 GBs

(13)

Index: 4

Partition Type: Windows recovery environment

Size: 1000.00 MBs

10/3/2021 16:04:46 - SMART Wearout Test Passed (0s)

10/3/2021 16:04:46 - NVME Controller Status Test Passed (0s)

10/3/2021 16:04:46 - NVME SMART Temperature Test Passed (0s)

10/3/2021 16:04:46 - NVME SMART Reliability Test Passed (1s)

10/3/2021 16:04:47 - NVME SMART Spare Space Test Passed (0s)

10/3/2021 16:04:47 - Device Read Test Passed (14s)

10/3/2021 16:05:01 - Device Write Test Passed (228s)

10/3/2021 16:08:49 - Full Disk Scan Passed (329s)

Video Card

AMD Radeon(TM) Graphics Result Code:WVC1600T00000-WH7V8F

UDI: AMDRadeon(TM)Graphics04:00.0

Location: PCI bus 4, device 0, function 0

Driver version: 27.20.11044.4003

Vendor ID: 1002

Device ID: 1636

Video Card Memory: 496 MB

10/3/2021 16:14:18 - Video Memory Test Passed (20s)

10/3/2021 16:14:28 - Message: Total surfaces tested: 50/50

10/3/2021 16:14:38 - Texture Pipeline Test Passed (50s)

10/3/2021 16:15:28 - DirectCompute Standard Mathematical Operations Test Passed (1s) 10/3/2021 16:15:29 - DirectCompute Advanced Mathematical Operations Test Passed (0s)

10/3/2021 16:15:29 - Extended Video Memory Test Passed (55s)

10/3/2021 16:16:14 - Message: Total surfaces tested: 103/103

10/3/2021 16:16:24 - Stress Test Passed (301s)

10/3/2021 16:21:25 - Message: Minimum 10/3/2021 16:21:25 - Message: Temperature: 59°C 10/3/2021 16:21:25 - Message: GPU Usage: 21%

10/3/2021 16:21:25 - Message: FPS: 20 10/3/2021 16:21:25 - Message: Maximum 10/3/2021 16:21:25 - Message: Temperature: 82°C 10/3/2021 16:21:25 - Message: GPU Usage: 100%

10/3/2021 16:21:25 - Message: FPS: 29 10/3/2021 16:21:25 - Message: Average

10/3/2021 16:21:25 - Message: Temperature: 75°C 10/3/2021 16:21:25 - Message: GPU Usage: 99%

10/3/2021 16:21:25 - Message: FPS: 25

10/3/2021 16:21:25 - Wireframe Stress Test Passed (301s)

10/3/2021 16:26:26 - Message: Minimum 10/3/2021 16:26:26 - Message: Temperature: 80°C 10/3/2021 16:26:26 - Message: GPU Usage: 71%

10/3/2021 16:26:26 - Message: FPS: 772

(14)

10/3/2021 16:26:26 - Message: Maximum 10/3/2021 16:26:26 - Message: Temperature: 85°C 10/3/2021 16:26:26 - Message: GPU Usage: 100%

10/3/2021 16:26:26 - Message: FPS: 794 10/3/2021 16:26:26 - Message: Average

10/3/2021 16:26:26 - Message: Temperature: 82°C 10/3/2021 16:26:26 - Message: GPU Usage: 99%

10/3/2021 16:26:26 - Message: FPS: 788

Wireless

Realtek 8822CE Wireless LAN 802.11ac PCI-E NIC Result Code:WWF0000700000-WH7V8F

UDI: RealtekSemiconductorCorp.-Realtek8822CEWirelessLAN802.11acPCI-

ENIC-8C:C8:4B:95:01:09

MAC Address: 8C:C8:4B:95:01:09

Manufacturer: Realtek Semiconductor Corp.

Network name(s): {A814D009-8F80-4BC6-BFE7-1F98F363A434}

Product Name: Realtek 8822CE Wireless LAN 802.11ac PCI-E NIC

10/3/2021 16:26:26 - Radio Enabled Test Passed (1s)

10/3/2021 16:26:27 - Message: Hardware/Software state is on

10/3/2021 16:26:27 - Network Scan Test Passed (2s)

10/3/2021 16:26:28 - Message: 1 Network(s) available to connect

SSID Security Protocol MAC Address Signal Quality

Taffer WPA2-Personal 802.11ac 74:85:2A:FA:93:90 100%

10/3/2021 16:26:29 - Signal Strength Test Passed (1s)

10/3/2021 16:26:30 - Message: Wireless network found with sufficient signal quality: Taffer
