TTK DIAGNOSTIC MONITORS

(1)

TTK

DIAGNOSTIC MONITORS



Greyscale and colour diagnostic displays



Resolution of 2 to 15 megapixels with ISD



Five-year diagnostic guarantee

(2)

TOTOKU is a leading

glo-bal manufacturer of

me-dical monitors.

TOTOKU

has been producing

reli-able and innovative

dis-plays and workstations

since 1972.

TOTOKU colour monitors are ultra

bright and rich in contrast.

Color Monitor

Thanks to ISD, TOTOKU greyscale

monitors are able to reach a

resolu-tion of up to 15.7 megapixels.

Grayscale Monitor

TOTOKU diagnostic monitors

are used in a variety of applications. These

include mammography, CT, MRT, PET and

angiography.

PET / CT

CT / MR

Thorax CR

Angio

TOTOKU DIAGNOSTIC MONITORS – INTELLIGENT, RELIABLE, UNIQUE!

CERTAINTY THROUGH INNOVATION

Continuous further development allows

TOTOKU

to ensure even greater

certainty in primary diagnostics along with technological progress in the

me-dical imaging market.

As well as equipping the diagnostic monitors with innovative technical

fea-tures,

TOTOKU

also provides a diagnostic guarantee for up to fi ve years.

This ensures maximum investment security for diagnostic monitors with

reso-lutions of 2, 3 and 5 megapixels.

THREE SENSORS FOR

STABILITY

All

TOTOKU

i2 models have a

relia-ble stabilisation system: Three sensors

continuously monitor all important

parameters and ensure that image

reproduction is always stable.

Not only is the temperature

measu-red inside the display; the current

brightness of the display is also

mea-sured. The brightness in the room is

also monitored.

The measurements are

monito-red and recorded using the

PM-MEDIVISOR.

This software is

optionally available.

ISD TECHNOLOGY

ISD

(Independent Sub-pixel Drive) technology allows the sub-pixels of

greys-cale displays to be controlled independently of each other. This is a revolution

for diagnostic monitors as it allows the resolution of a display to be tripled. For

example,

ISD

turns a 2 MP display into a 6 MP display.

ISD

provides

substan-tial cost savings while improving quality.

ISD

is optionally available for most

greyscale monitors and can also be activated later.

Stabilisation sensors

also provides a diagnostic guarantee for up to fi ve years.

This ensures maximum investment security for diagnostic monitors with

reso-THREE SENSORS FOR

i2 models have a

relia-ble stabilisation system: Three sensors

(3)

TOTOKU DIAGNOSTIC MONITORS – INTELLIGENT, RELIABLE, UNIQUE!

6 Megapixel

TOTOKU

colour monitors

can display even the fi nest details

in sharp clarity with a resolution

of up to 6 MP.

ISD increases the visible resolution

of greyscale monitors to up to 15

megapixels.

ISD increases the visible resolution

ISD-Technologie

optional

LED Backlight

The new LED backlight ensures an

even more consistent illumination

of the display surface.

1800 cd/m²

The luminance of up to 1800 cd/

m2 provides suffi cient reserves to

signifi cantly extend the lifetime of

the monitors.

Uniformity

Uniformity Correction ensures

uniform brightness over the entire

display.

Energy saver

New models featuring an LED

backlight reduce power

consump-tion by over 20% while providing

better illumination.

LED BACKLIGHT

The latest generation of

TOTOKU

monitors is equipped with an LED

back-light. The LED backlight ensures a better and more consistent illumination of

the entire display in the CCL 258i2, CCL 358i2, CCL 650i2 and MS55i2 models.

The power consumption of these monitors is also reduced by around 20%

com-pared to models with conventional lighting.

BACKLIGHT WITH

SELF-PROTECTION

The Backlight-Lifetime-Extender is

additio-nal software that extends the lifetime of the

background light. When the display is not in

use, the backlight switches to a particularly

resource-conserving operating mode. In

cont-rast to normal screensavers, the display always

remains ready for use.

COLOUR MONITORS

WITH HIGH

BRIGHTNESS

The new CCL 650i2, CCL 258i2 and CCL 358i2

colour monitors achieve a brightness of up to

950 cd/m2. The devices are precalibrated at the

factory to 410 and 300 cd/m2. Thanks to the high

level of brightness, these models can be used for

Class A diagnostics.

2048 GREYSCALES AT

NO EXTRA COST

A patented technology makes it possible for the

fi rst time to display up to 2048 greyscales (= 11 bits)

simultaneous-ly with

TOTOKU

monitors. Provided that your viewing software

(PACS) supports this technology, you can save the cost of purchasing

expensive graphic cards without compromising on quality.

UNIFORMITY EQUALIZER

The uniformity equalizer ensures excellent brightness distribution over the

en-tire display surface and even eliminates minimal fl uctuations in luminance. In

the case of colour monitors, the uniformity equalizer also provides an even

dis-tribution of colours over the entire screen. Of course, each display is measured

and calibrated at the factory prior to delivery.

A major benefi t of

TOTOKU

monitors is that the user can repeat this

calibra-tion themselves as often as required using the opcalibra-tional CAL012 calibracalibra-tion set.

This guarantees a consistent brightness distribution, even after years of use.

fi rst time to display up to 2048 greyscales (= 11 bits)

simultaneous-ly with

TOTOKU

(4)

Software and hardware

work hand in hand in

TOTOKU

monitors. The

Medivisor software

au-tomatically detects the

available sensors, fi nding

both integrated and

op-tional sensors.

Three diff erent sensors permanently

monitor the status of i2 models.

Sensors integrated

All TOTOKU monitors connected to

the network are calibrated centrally.

Remote calibration

Acceptance and constancy testing

in accordance with DIN V 6868-57

and AAPM TG18.

Constancy Testing

6868-57V

DIN

Greyscale calibration according to

GSDF/DICOM Part 14

DICOM

Reports generated during

calibra-tion can be saved as PDF fi les. They

can be viewed and printed at any

time.

PDF-Reporting

CALIBRATION: SIMPLE AND AUTOMATIC

The many years of experience that

TOTOKU

has in producing monitors for

the medical industry is also refl ected in the company’s

MEDIVISOR NX

calibration software. The software automatically detects the monitor type and

available sensors. No program wizard or manual input is required to perfectly

calibrate a monitor. All it takes is two clicks to perform the calibration and

optimally adjust the monitor.

An icon in the user interface info area indicates the current status of the

monitor in real time. This provides greater diagnostic certainty and consistent

image quality without the user having to think about maintenance intervals.

All values measured during the calibration are represented graphically and

archived.

ACCEPTANCE AND CONSTANCY

TESTING

The German X-Ray Regulation (Röntgenverordnung) requires the users of

diagnostic monitors to carry out regular acceptance and constancy tests in

accordance with DIN V 6868-57. For this purpose, the

QA MEDIVISOR

works hand in hand with the

MEDIVISOR NX

: The calibration reports are

obtained from here and the required test reports are created in PDF format.

REMOTE CALIBRATION

The optional

PM MEDIVISOR

goes one step further: All

TOTOKU

i2

series monitors located on the

net-work are calibrated and verifi ed

remotely and automatically. This

is carried out completely

autono-mously and is fully time-controlled.

It is no longer necessary to perform

the calibration on site. Measures

that are carried out include:



Central control of all monitor

information



Remote calibration according

to GSDF/DICOM Part 14



Remote monitoring of monitor

values



Automatic notifi cation by

e-mail



Generation of PDF reports

(5)

For more information on the technical

details of TOTOKU diagnostic monitors,

please visit our website:

CCL358I2

The look-up table with up to 3826

greyscales provides a balanced

display of diagnostic images.

The look-up table with up to 3826

11.9 LUT

An optional calibration kit is

available for monitors that do not

have integrated sensors.

available for monitors that do not

Calibration Kit

Option

An invisible protective fi lter

pro-tects the display from scratches

and can be replaced at any time.

Protective Filter

TOTOKU monitors can be ordered

in pairs. The display of images in

these monitors is particularly well

harmonised.

these monitors is particularly well

Matched Pair

TOTOKU monitors feature a

position sensor that

automa-tically identifi es whether the

device is operated in portrait or

landscape format.

Hardware Pivot

INTEGRATED LUT (LOOK-UP TABLE)

Conventional monitors usually work with 8 bits per colour channel and can

therefore only display 256 greyscales.

TOTOKU

, on the other hand, uses special

greyscale displays that can represent up to 3826 diff erent greyscales (= 11.9 bits).

A look-up table (LUT) is used to

ad-apt this incredible range of shades

to human sight. This takes place in

accordance with the

DICOM

stan-dards. The result: An excellent,

ba-lanced and homogenous greyscale

gradient.

HARDWARE PIVOT

FUNCTION

The pivot function of a monitor

al-lows you to rotate the screen by

90° in order to switch from portrait

mode to landscape format. This

ro-tation requires that the respective

screen format on the computer is

converted (for example, from 1920

x 1200 to 1200 x 1920). Many

mo-nitors off er a software solution for this.

However, the solution usually requires a lot of computing power and slows down

the display of images.

In the hardware pivot function featured in

TOTOKU

monitors, the display of

images is equally fast in both modes and responds to changes of mode at

light-ning speed.

DUAL MONITORS

Due to production-related reasons, it is not possible to completely avoid

varia-tions in the colour temperature of diff erent greyscale monitors. As two monitors

are often used side by side in medical imaging, it is particularly important that

screens have identical reproduction values.

TOTOKU

off ers to synchronise monitor pairs before they are delivered. This

re-sults in perfect and symmetrical colour reproduction on both monitors.

(6)

COLOUR MONITORS – TECHNICAL DATA

CCL210

Available from September 2014

CCL230

CCL242

CCL 256i2

CCL 258i2

CCL 352i2

CCL 356i2

CCL 358i2

CCL 650i2

Application Colour monitor with

a 21.3" diagonal, resolution of 2 mega-pixels and greyscale calibration according to DICOM Part 14.

19.6" monitor with a 2 MP resolution. With up to 700 cd/m2_{, it}

is suitable for X-ray diagnostics.

Diagnostic monitor with high brightness, good contrast and a very wide viewing angle.

Ultra bright 2 MP monitor that knows how to convince with its colour and greyscale diagnostic images.

20.8" diagnostic monitor with a 3 MP resolution. Excellent display quality and many service options.

High luminance and exceptional contrast enable colour and greyscale diagnostics on this 3 MP monitor.

With 6 MP and a diagonal of more than 76 cm, the CCL 650i2 offers a screen area that is equivalent to two monitors but requires considerably less space.

Display

Technology TFT Colour Active _{Matrix IPS} TFT Colour Active _{Matrix IPS} TFT Colour Active _{Matrix IPS} TFT Colour Active _{Matrix IPS} TFT Colour Active _{Matrix IPS} TFT Colour Active _{Matrix IPS} TFT Colour Active _{Matrix IPS} LED backlight Yes No Yes CCL 256i2: No_{CCL 258i2: Yes} No CCL 356i2: No_{CCL 358i2: Yes} Yes

Display size 21.3" (54 cm) 19.6" (49.8 cm) 24.1" (61.1 cm) 21.3" (54 cm) 20.8" (53.0 cm) 21.3" (54.1 cm) 30" (76.1 cm) Resolution (native) 1600 x 1200 (2 MP) 1200 x 1600 (2 MP) 1920 x 1200 (2.3 MP) 1200 x 1600 (2 MP) 1536 x 2048 (3.1 MP) 1536 x 2048 (3.1 MP) 3280 x 2048 (6 MP) Pixel pitch 0.27 mm x 0.27 mm 0.249 mm x 0.249 mm 0.27 mm x 0.27 mm 0.27 mm x 0.27 mm 0.207 mm x 0.207 mm 0.2115 mm x 0.2115 mm 0.197 mm x 0.197 mm Colour reproduction via

DVI-D 16.7 million colours LUT: 1.1 billion colours 16.7 million colours LUT: 68 billion colours 16.7 million colours 16.7 million colours LUT: 68 billion colours 16.7 million colours 16.7 million colours LUT: 68 billion colours 16.7 million colours LUT: 68 billion colours Colour reproduction via

DisplayPort 16.7 million colours 16.7 million colours 16.7 million colours 1.1 billion colours — 1.1 billion colours Number of greyscales 256 from a palette of _{1021 greyscales} 256 256 1024 via DisplayPort 256 1024 via DisplayPort Maximum brightness 440 cd/m2 _{700 cd/m}2 _{300 cd/m}2 CCL 256i2: 950 cd/m2

CCL 258i2: 900 cd/m2 650 cd/m2 800 cd/m2 800 cd/m2 Factory

calibration 180/200 cd/m2 410 cd/m2 150 cd/m2 300/410 cd/m2 250 cd/m2 300/410 cd/m2 300/410 cd/m2 Contrast ratio 1500:1 1000:1 1000:1 CCL 256i2: 900:1_{CCL 258i2: 1400:1} 600:1 CCL 356i2: 750:1_{CCL 358i2: 1400:1} 1000:1

Viewing angle h: 178° / v: 178° h: 170° / v: 170° h: 178° / v: 178° CCL 256i2: h: 170° / v: 170° CCL 258i2: h: 176° / v: 176° h: 170° / v: 170° CCL 356i2: h: 170° / v: 170° CCL 358i2: h: 176° / v: 176° h: 170° / v: 170°

Stabilisation _sensors)λ-Sentinel (integrated λ-_sensors)Sentinel (integrated λ-_sensors)Sentinel (integrated λ-_sensors)Sentinel II (integrated _sensors)λ-Sentinel II (integrated λ-_sensors)Sentinel II (integrated λ-_sensors)Sentinel II (integrated Backlight lifetime at ‘defined brightness’ *1 25,000 h 200 cd/m2 30,000 h 30,000 h 320 cd/m2 30,000 h 300 cd/m2 30,000 h 320 cd/m2 40,000 h 320 cd/m2

Protective filter No No No Yes Yes Yes No

Portrait function Yes Yes No Yes Yes Yes No

Connections

Signal inputs DVI-I (1.0), DisplayPort _(1.1a) DVI-D (1.0), VGA DVI-D (1.0), DisplayPort _{(1.1a), VGA} DVI-D (1.0), DisplayPort _(1.1a) DVI-D (1.0), DisplayPort _(1.1a) DVI-D (1.0), DisplayPort _(1.1a) DVI-D (1.0), DisplayPort _(1.1a) USB hub USB 2.0, 1 x Up / 2 _{x Down} USB 2.0, 1 x Up / 2 _{x Down} USB 2.0, 1 x Up / 2 _{x Down} USB 2.0, 1 x Up / 2 _{x Down} USB 2.0, 1 x Up / 2 _{x Down} USB 2.0, 1 x Up / 2 _{x Down}

General device data

Power consumption 42 W 120 W 60 W CCL 256i2: 120 W_{CCL 258i2: 75 W} 130 W CCL 356i2: 120 W_{CCL 358i2: 80 W} 180 W

Power save mode Yes Yes Yes Yes Yes Yes

Power supply 100-240 V, 50/60 Hz_{Internal power supply} 100-240 V, 50/60 Hz_{Internal power supply} 100-240 V, 50/60 Hz_{Internal power supply} 100-240 V, 50/60 Hz_{Internal power supply} 100-240 V, 50/60 Hz_{Internal power supply} 100-240 V, 50/60 Hz_{Internal power supply} 100-240 V, 50/60 Hz_{Internal power supply} Dimensions in landscape

mode W: 473 | H: 476.4 - 537.9 | D: 220 W: 420 | H: 404.7 - 456.2 | D: 220 W: 561 | H: 467 - 529 | D: 220 W: 474 | H: 468.4 - 529.9 | D: 220 W: 474 | H: 468.4 - 529.9 | D: 220 W: 474 | H: 471.4 - 532.9 | D: 220 W: 695.6 | H: 512.1 - 573.6 | D: 243.5 Dimensions in portrait

mode W: 377 | H: 524.4 - 585.9 | D: 220 W: 340 | H: 508.9 - 560.3 | D: 220 — W: 367 | H: 521.9 - 583.4 | D: 220 W: 367 | H: 521.9 - 583.4 | D: 220 W: 367 | H: 524.9 - 586.4 | D: 220

Tabletop stand functions Portrait, tilt, turn_{Height adjustment} Portrait, tilt, turn_{Height adjustment} Tilt, turn_{Height adjustment} Portrait, tilt, turn_{Height adjustment} Portrait, tilt, turn_{Height adjustment} Portrait, tilt, turn_{Height adjustment} Tilt, turn_{Height adjustment} Mounting 100 mm VESA Standard 100 mm VESA Standard 100 mm VESA Standard 100 mm VESA Standard 100 mm VESA Standard 100 mm VESA Standard 100 mm VESA Standard_{100 x 200 mm VESA}

Anti-theft device Yes Yes Yes Yes Yes Yes

Weight with base

Weight without base 10.7 kg6.5 kg 11.6 kg8.1 kg 11.1 kg6.9 kg Approx. 12 kgApprox. 8 kg 11 kg6.8 kg Approx. 12 kgApprox. 8 kg Approx. 15.5 kgApprox. 10 kg

Conformity

TBA UL60601-1, CSA C22.2 N601.1 Part1, FCC Part15 Subpart J Class B, DOC Class B MDD/CE (EN5011, EN60601-1-2) VCCI Class B CE, ANSI/ AAMI ES60601-1(2005)+A1(2012), CAN/CSA-C22.2 N O. 60601-1(2008), FCC-B, ICES-003-B, CE, VCCI-B

CE, UL60601-1, CSA C22.2 No. 601.1, MDD/ CE, FCC-B, VCCI-B, RoHS, FDA510(k)

CE, UL60601-1, CSA C22.2 No. 601.1, MDD/ CE, FCC-B, VCCI-B, FDA510(k)

CE, UL60601-1, CSA C22.2 No. 601.1, MDD/ CE, FCC-B, VCCI-B, RoHS,CCC, FDA510(k) ANSI/AAMI ES60601-1(2005) +A1(2012), CAN/CSA-C22.2 No. 60601-1(2008), CE, FCC-B, ICES-003-B, VCCI-B, FDA510(k) Pending_,

J-Moss, RoHS Warranty (bring-in) Five years Five years Five years Five years Five years Five years Five years

(7)

MS23i2

MS25i2

MS33i2

MS35i2

MS53i2

MS55i2

ME 193

Application Good image reproduction thanks to ISD.

Inexpensive diagnostic monitor. Resolution of more than 9 megapixels thanks to ISD. Very well suited for mammography diagnosis.

Ultra-high resolution mammography monitor with a resolution of more than 15 MP thanks to ISD.

Medical monitor for universal use with analogue and digital inputs.

Display

Technology TFT Greyscale IPS Technology TFT Greyscale IPS Technology TFT Greyscale IPS Technology TFT Greyscale IPS Technology

IPS (Independent Sub Pixel) Yes Yes Yes No

LED backlight MS23i2: No_{MS25i2: Yes} MS33i2: No_{MS35i2: Yes} MS53i2: No_{MS55i2: Yes} No Display size 21.3" (54 cm) MS33i2: 20.9" (52.9 cm) _{MS35i2: 21.3" (54.1 cm)} 21.3" (54.1 cm) 19" (48.19 cm) Resolution (native) 1200 x 1600 (2 MP) 1536 x 2048 (3.1 MP) 2048 x 2560 (5.2 MP) 1280 x 1024 (1.3 MP) Resolution via ISD

(Subpixel) 1200 x 4800 (5.8 MP) 1536 x 6144 (9.4 MP) 2048 x 7680 (15.7 MP) —

Pixel pitch 0.270 mm x 0.270 mm MS33i2: 0.207 mm x 0.207 mm_{MS35i2: 0.2115 mm x 0.2115 mm} 0.165 mm x 0.165 mm 0.294 mm x 0.294 mm Maximum displayable greyscales (LUT) 13.6 bits_{12241 greyscales} 13.6 bits_{12241 greyscales} 13.6 bits_{12241 greyscales} 12 bits_{4096 greyscales} Simultaneously displayable greyscales

(DVI) 11 bits / 2048 greyscales without ISD10.3 bits / 1276 greyscales with ISD 11 bits / 2048 greyscales without ISD10.3 bits / 1276 greyscales with ISD 11 bits / 2048 greyscales without ISD10.3 bits / 1276 greyscales with ISD 11 bits / 2048 greyscales without ISD10.3 bits / 1276 greyscales with ISD Maximum brightness MS23i2: 1800 cd/m²_{MS25i2: 1900 cd/m²} MS35i2: 1000 cd/m²_{MS35i2: 1700 cd/m}_² MS53i2: 1100 cd/m²_{MS55i2: 1200 cd/m²} 1500 cd/m²

Factory calibration 410 cd/m² 410 and 500 cd/m² 410 and 500 cd/m² 410 cd/m² Contrast ratio MS23i2: 700:1_{MS25i2: 1400:1} MS33i2: 900:1_{MS25i2: 1400:1} MS53i2: 850:1_{MS55i2: 1200:1} 1000:1 Viewing angle h: 170° / v: 170° h: 170° / v: 170° MS53i2: h: 170° / v: 170°_{MS55i2: h: 176° / v: 176°} h: 170° / v: 170°

Stabilisation l-Sentinel II (integrated sensors) l-Sentinel II (integrated sensors) l-Sentinel II (integrated sensors) l-Sentinel I (integrated sensors) Backlight lifetime

Guaranteed brightness after lifetime has expired

30,000 h

300 cd/m2 30,000 h_{300 cd/m}2 30,000 h_{410 cd/m}2

Protective filter Yes Yes Yes No

Portrait function Yes Yes Yes Yes

Connections

Signal inputs DVI-D (1.0), DisplayPort (1.1a) DVI-D (1.0), DisplayPort (1.1a) DVI-D (1.0), DisplayPort (1.1a) Analogue: BNC (Sync on Video, Separate),NTSC/PAL Composite, Analogue VGA

Digital: DVI-D

USB hub USB 2.0, 1 x Up / 2 x Down USB 2.0, 1 x Up / 2 x Down USB 2.0, 1 x Up / 2 x Down —

General device specifications

Power consumption MS23i2: 80 W_{MS25i2: 60 W} MS33i2: 90 W_{MS25i2: 60 W} MS53i2: 90 W_{MS55i2: 80 W} 65 W

Power save mode Yes Yes Yes Yes

Power supply 100-240 V, 50/60 Hz_{Internal power supply} 100-240 V, 50/60 Hz_{Internal power supply} 100-240 V, 50/60 Hz_{Internal power supply} 100-240 V, 50/60 Hz_{Internal power supply}

Dimensions in landscape mode W: 474 | H: 468.4 - 529.9 | D: 220 W: 474 | H: 468.4 - 529.9 | D: 220 W: 474.5 | H: 479.9 - 541.4 | D: 220 W: 416.3 | H: 458.7 - 520.2 | D: 220 Dimensions in portrait mode W: 367 | H: 521.9 - 583.4 | D: 220 W: 367 | H: 521.9 - 583.4 | D: 220 W: 390 | H: 522.2 - 583.7 | D: 220 W: 344 | H: 496.1 - 557.6 | D: 220 Mounting 100 mm VESA Standard 100 mm VESA Standard 100 mm VESA Standard 100 mm VESA Standard

Anti-theft device Yes Yes Yes Yes

Weight with base

Weight without base Approx. 12 kg7.8 kg Approx. 12 kg7.8 kg Approx. 12 kgApprox. 7.8 kg 9.2 kgApprox. 6 kg Approvals CE, UL1950, CSA950 EN60950, DHHS, FCC-A, IEC950 UL2601, CSA601 IEC601-1, TCO-95, IEC601-1-2, TÜV-GM

UL60601-1, CSA C22.2 No. 601.1, MDD/ CE, FCC-B, VCCI-B, RoHS, FDA510(k), CCC pending

UL60601-1, CSA C22.2 No. 601.1, MDD/CE, FCC-B, VCCI-B, RoHS, CCC, FDA510(k)

UL60601-1, CSA C22.2 No. 601.1, MDD/

CE, FCC-B, VCCI-B, RoHS,FDA510(k), CCC UL60601-1, CSA C22.2 No.601.1, MDD/CE(EN60601-1,EN60601-1-2), CCC, FCC-B, VCCI-B, J-Moss, RoHs

Warranty (bring-in) Five years Five years Five years Three years

Options

Remote calibration With TOTOKU PM Medivisor software (optional) Uniformity Correction Factory Uniformity Correction prior to delivery

New correction possible with CAL008 calibration kit (optional)

GREYSCALE MONITORS – TECHNICAL DATA

Warranty conditions

The warranty period starts from the date of delivery of the device. The following items are not covered by the warranty: • If the monitor is operated above the factory-set calibration, the lifetime of the backlight cannot be guaranteed. • Increase in pixel defects of the LCD display

• ‘Ghost images’ or ‘image sticking’ on the LCD display • Reduction in the colour uniformity of the LCD display

(8)

ALWAYS ON OUR MIND

CUSTOMER AND MARKETS

» Europe has always been the core

market of Rein Medical.

The family business, with headquarters in the

west of Germany, combines all the product

strategy organisational units under one roof.

Our sales and service teams in Germany, Spain

and Switzerland allow us to focus on our

customers and ensure customer satisfaction.

Long term cooperation with our customers is

our top priority.

Germany

Rein Medical GmbH Monforts Quartier 23 Schwalmstraße 301 41238 Mönchengladbach Phone +49 (0) 2161 / 69 84 0 Fax +49 (0) 2161 / 69 84 259 www.reinmedical.com [email protected]

Switzerland

Rein Medical AG Büfelderstrasse 1 CH-8370 Sirnach Phone +41 (0) 71 / 929 55 99 Fax +41 (0) 71 / 929 55 90 www.reinmedical.com [email protected]

Spain

Rein Medical System, SA C/ Téllez 30

1ª Planta, Oficina 2 Puerta 3 28007 Madrid

Phone +34 91 / 530 88 24

Fax +34 91 / 574 32 93

www.reinmedical.com [email protected]

Visit us on the web: This QR-Code guides you directly to our homepage.
