MOTION IN ONE AND
TWO DIMENSIONS
O
ur Universe has been in constant motionsince its formation, which physicists now believe occurred 14 billion years ago in the so-called ‘Big Bang’. In that one act, the Universe as we know it began and its matter and energy have been occupying an increasing space ever since. Today, on any scale of nature, there is movement of one form or another. At the very largest levels we can observe clusters of galaxies orbiting about their common centre of mass. Our own galaxy rotates about its centre every 250 million years. At the smallest scale, we can detect the continual movement of atoms and molecules, and even the motion of the subatomic particles within atoms.
Between these extremes are the types of motion we can see around us in the natural world—people walking, birds flying, water
In order to describe all the motion we can observe, both on Earth and in the Universe generally, physicists have developed a system of quantities that describe the movement and help us to understand why it occurs. Displacement, velocity and acceleration, along with time, can be used to describe the behaviour of a body, but force is needed to explain why the body moves in the way it does. Energy is useful when considering what caused a body to move, and for how much longer it may continue to move. Physicists have also formulated ‘laws’ to explain why various forms of motion occur. Mathematical models are used to analyse situations and are helpful in predicting the outcomes of events involving motion.
Motion
I
saac Newton was born in England in 1642. He is considered tobe one of the greatest scientific minds of all time, most famous for his laws of motion, but also for contributions in optics, astronomy and the nature of light and colour. He was driven by a desire to better understand the Universe, and developed theories to explain its behaviour.
Newton studied at Cambridge, but returned to his birthplace of Woolsthorpe in 1665 when the plague swept through the cities of Europe. It was here that he realised that the force that keeps the Moon in its orbit around the Earth was the same force that caused objects to fall to the ground. His law of universal gravitation will be studied in Chapter 3.
Newton was a reclusive man and never married or had children. He is credited with some of the greatest scientific discoveries of all time. He developed his laws of motion, building upon work previously done by Galileo. These laws describe very precisely the behaviour of objects when forces act upon them and can be used with great confidence in everyday situations. However, for objects travelling at extreme speeds or in very strong gravitational fields, these laws are inaccurate.
Newton’s use of mathematics and the scientific method of investigation revolutionised the study and development of scientific ideas. His most famous publication, the Principia
Mathematica was written in Latin and published in 1687. In this
book, he demonstrated for the first time that complex motions as experienced by falling objects, projectiles and satellites can be explained and predicted by using a few simple rules. This is what you will be studying in the following chapters.
you will have covered material
from the study of motion,
including:
• motion in one and two
dimensions
• Newton’s laws of motion
• relative motion and frames of
reference
• inclined planes
• projectile motion.
CHAPTER 1 BY THE END OF THIS CHAPTERBefore building on the mechanics that you learned in year 11, it will be useful to revise the concepts and ideas that have been covered in the year 11 course. This section is designed to provide a brief tour of the ideas and concepts that are used to describe and understand the motion of an object.
Vectors and scalars
Physical quantities can be divided into two distinct groups: vectors and scalars. • A vector quantity requires both a magnitude, or size, and a direction for it to be fully described. In mechanics, displacement, velocity, acceleration, force and momentum are common vector quantities.
• A scalar quantity requires only a magnitude for it to be completely described. Common scalar quantities include distance travelled, speed, time, mass and energy.
Vector techniques
Multiplying a vector by a scalar
When a vector is multiplied by a number (i.e. a scalar) the magnitude of the vector is changed by the appropriate factor but the direction remains the same. If the scalar is negative, this is interpreted as reversing the direction of the vector. For example, if x=5 m east, then 2x=10 m east and −x=5 m west.
Vector addition and subtraction
Adding scalars is straightforward. The amounts are just added as one would
add numbers. If a person walked 20 metres and then a further 30 metres, the total distance travelled is 50 metres, regardless of direction.
When adding vectors, seemingly unusual results are sometimes obtained. For example, 3 +4 =5! This occurs because vectors have direction and are not always combined in one dimension. In adding two vectors, the tail of the second vector is placed at the head of the first vector. The sum of the vectors is the resultant vector. This is drawn as a directed line segment starting at the tail of the first vector and finishing at the head of the second vector. To describe the resultant, both the magnitude (given by the length of the vector) and its
direction are required. General vectors are used in Figure 1.1 to illustrate this
technique. + − = = = A = 3 A = 3 A A A R = 5 R = 5 B = 4 + –B B = 4 B –B (a) (b)
1.1
Mechanics review
Vector subtraction is required from time to time. This technique should be handled as a vector addition, but with the direction of the subtracted vector being reversed. For example, a change in velocity is given by: ∆v=v−u=v+(−u).
Describing motion
When a body moves from one place to another, its displacement x is the vector given by the directed line segment from the start of the motion to the finish of the motion. Displacement is a vector, and indicates how far and in what direction the body has moved from the starting point. The displacement of a body may be different from the distance it has travelled. The displacement of a year 12 student over a 24-hour period may be zero, but he or she may have travelled many kilometres during the day. Distance d is a scalar quantity, and does not require a direction. The odometer in a car measures the distance travelled by the car.
Speed and velocity both indicate how fast a body is travelling but there is an
important difference between these quantities. The average speed v of a body is given by its rate of change of distance, whereas the average velocity v of a body is its rate of change of displacement. The SI unit for both quantities is metres per second, m s−1, but speed is a scalar quantity and velocity is a vector
quantity.
Average speed v= = Average velocity v= =
An instantaneous velocity or speed is the velocity or speed of a body at a particular instant in time. The speedometer in a car gives the instantaneous speed of the car.
The average acceleration of a body is given by the rate of change of velocity over a given time interval. For example, if a car speeds up from 20 km h−1to
60 km h−1in 4.0 seconds, its average acceleration is 10 km h−1per second.
Acceleration is a vector quantity with its SI unit being metres per second squared (m s−2). The symbols u and v are used to denote the initial velocity and
the final velocity of a body over a given time interval. Average acceleration is given by a= =
where ∆v is the change in velocity over the time interval ∆t.
Worked example 1.1A
.
Rebecca is pulling her toy dog along the lawn with a force of 20 N applied at an angle of 25°to the horizontal. There is a frictional force of 10 N acting on the toy dog. Determine the net horizontal force acting on the dog.
v −u ∆t ∆v ∆t x ∆t displacement time taken d ∆t distance travelled time taken Ff = 10 N 20 N 25˚ PRACTICAL ACTIVITY 1 Analysing a student’s motion
W E Before collision After collision ∆v = v − u = − = = + 2.0 3.0 2.0 3.0 5.0 3.0 m s–1 2.0 m s–1
Solution
The horizontal component of the pulling force is: Fh=20cos25° =18.1 N
The net horizontal force is: 18.1 −10 =8.1 N.
Worked example 1.1B
.
A white cue ball travels over a pool table at 3.0 m s−1east. It collides with
the cushion and rebounds at 2.0 m s−1west. If the collision time with the
cushion is 25 ms, calculate:
a the change in speed of the ball
b the change in velocity of the ball
c the average acceleration of the ball during its collision with the cushion.
Solution
a The white ball has slowed from 3.0 m s−1to 2.0 m s−1. The change in
speed is: ∆v=v−u=2.0 −3.0 = −1.0 m s−1.
b The velocity has changed from 3.0 m s−1east to 2.0 m s−1west. The
change in velocity of the ball is found by vector subtraction, as shown.
Fh 20 N 25° vplane= 300 km h–1 S v θ The change in velocity of the billiard ball is 5.0 m s−1west.
c To determine the average acceleration of the ball during the collision, the contact time of 25 ms must first be converted to 0.025 s:
Acceleration = = =200 m s−2west
Worked example 1.1C
.
A pilot is trying to fly her plane due south at an air speed of 300 km h−1.
However, it has been blown off course by a crosswind of 75 km h−1to the
west. What is the ground speed of the plane, and in what direction does it actually fly?
Solution
This involves a vector addition as shown in the diagram.
The ground speed of the plane is the magnitude of its actual velocity, v. This is the vector sum of its air velocity vplaneand the wind velocity vwind,
i.e. v=vplane+vwind.
Using Pythagoras’s theorem: v = =310 km h−1
Using trigonometry to find θ: tanθ =75/300 =0.25, so θ =14°. 3002+ 752= 95625
√
√
5.0 0.025 ∆v ∆tCentre of mass
The motion of many objects is quite complex. For example, as a person runs their arms and legs swing in different directions and with different speeds from that of the rest of their body. To analyse the motion of each of these body parts would be very complicated, but we can simplify this system as a single mass located at a single point. This point is called the centre of mass of the system. For most people, the centre of mass is just above the waist. An athlete sprinting down a track at 9 m s−1with arms and legs in rapid motion can thus
be treated as a single point mass moving down the track at 9 m s−1.
The significance of the centre of mass is that it enables the motion of a complex object or system to be thought of as a simple point mass located at the centre of mass. Consider the multiflash photograph shown in Figure 1.2. It is the view from above of a spanner sliding and spinning as it travels across an ice surface. The centre of mass of the spanner is marked with a cross.
The positions of the centre of mass form a straight line and are equally spaced, so the centre of mass of the spanner is moving with a constant velocity. The motion is the same as for a simple point mass: the spanner is behaving as though its total mass is located at its centre of mass.
Graphing motion
The motion of a body in a straight line can be represented in graphical form. One significant advantage for this form of representation is that a com-plicated motion can be conveyed to the reader far more easily than a table of data. Graphs with any of distance, displacement, speed, velocity or acceler-ation can be drawn as a function of time.
Position–time graphs
A position–time graph indicates the position of a body relative to an arbitrary origin as a function of time. Figure 1.4 shows the graph for a swimmer completing two 50 m laps of a pool. For motion in a straight line, the direction represented by a positive displacement (e.g. left/right, east/west) must be agreed upon. The velocity of the body can be determined from the position– time graph as the gradient over the time interval in question. An
instan-Figure 1.3 Even though Cathy Freeman is running at around 9 m s−1, her actual motion is rather more complicated. Her arm and leg that are swinging forwards are travelling faster than 9 m s−1, while her arm that is swinging back is moving slower than this. Her foot that is in contact with the ground is stationary! To simplify this complex motion, we treat her as a point mass located at her centre of mass.
Figure 1.2 The centre of mass (marked +) of a spanner moves with a constant velocity as it slides across an ice surface, even though the spanner is spinning. Use your ruler to confirm this.
PRACTICAL ACTIVITY 2 Locating the centre of mass
taneous velocity can be found from a curved graph as the gradient of the tangent to the line at the time of interest. This is shown in Worked example 1.1D.
Velocity–time graphs
A velocity–time (v–t) graph provides information about the speed and direction of a body during its motion. The sign of the velocity indicates the direction of the motion, but again, there must be agreement about what, say, a positive direction actually represents. Where the graph cuts the time axis, the body is stationary. The displacement of the object being investigated can be found as the area under the graph. The total displacement will be the vector sum of all the component displacements (i.e. the sign of the area is included in the calculation), and the total distance covered will be the scalar sum of the areas. Further to this, the average acceleration of the body whose motion is being investigated can be found as the gradient of the graph, for the relevant time interval.
Figure 1.5 describes the motion of a dancer moving back and forth across a stage during a 6-second movement. Assume that motion to the right is in the positive direction. The dancer initially moves at 4 m s−1towards the left. For
the first 2 seconds he continues to move towards the left while slowing down. After 2 seconds the dancer stops, then moves towards the right of the stage and speeds up for 2 seconds. For the final 2 seconds he moves with a constant velocity of 4 m s−1towards the right.
The gradient of the graph gives the acceleration of the dancer—a constant acceleration of +2 m s−2for the first 4 seconds. This applies when he is moving
left and slowing down, when momentarily stationary, and when moving right and speeding up. For the final 2 seconds he is moving with a constant velocity and so has an acceleration of zero.
The graph can also be used to calculate the displacement of the dancer at any time. By finding the area under the graph, we see that during the first 2 seconds he moves 4 m to the left. After 4 seconds his displacement is zero (i.e. he is back at his starting position). After 6 seconds he has a displacement of +8 m, so he finishes the movement 8 m to the right of his starting position.
Acceleration–time graphs
An acceleration–time (a–t) graph indicates the acceleration of the body at any time. The area under an a–t graph is the change in velocity for the object over the time in question. To establish the actual velocity of the object, the initial velocity must be known.
Worked example 1.1D
.
A car being driven by a learner-driver travels along a straight-line path for 20 s. The following graph represents the motion of the car. The positive direction is understood to be east.
a In general terms, describe the motion of the car.
b For how long does the car move in an easterly direction?
50 25 40 80 Time (s) P osition (m) 120 0 4 2 –2 –4 0 4 1 2 3 5 6 V elocity (m s – 1) Time (s) Figure 1.4 A graph of the motion of a swimmer travelling 50 m in a pool, then turning and swimming back to the starting position. The second lap is slower than the first.
Figure 1.5 This v–t graph represents the motion of a dancer moving back and forth across a stage.
PRACTICAL ACTIVITY 3 Velocity–time graphs
Solution
a The car is initially moving east at 5.0 m s−1. It then accelerates uniformly
for 6 seconds until it reaches a velocity of 20 m s−1east. It maintains
this velocity for 2 seconds but then starts to slow down, still moving east. It stops and turns around at t = 16 s, accelerating west for the last 4 seconds.
b The velocity of the car is positive for the first 16 seconds of its motion, and it is therefore moving east during this time.
c The acceleration can be found by calculating the gradient of the line over the first 6 seconds. During this time the car has a constant acceleration of:
Acceleration =gradient = = +2.5 m s−2
d To find the acceleration at 12 seconds, it is necessary to draw a tangent to the curve and calculate its gradient. This gives an instantaneous acceleration of:
Acceleration =gradient = = −1.9 m s−2
e The displacement is the area under the v–t graph. ‘Counting squares’ is a good way of doing this. For this graph, each ‘square’ represents a displacement of 5 ×2 =10 m. The displacement between 8 and 16 seconds is an estimation due to the curved nature of the line. The overall displacement for the 20 seconds is approximately 75 +40 +110 −20 = +205 m, i.e. 205 m towards the east.
f The average velocity over the 20 s time interval will be:
vav= = =10.3 m s−1east
Equations of motion
When an object is moving in a straight line with constant acceleration, the following equations of motion developed in year 11 are used to quantitatively describe its motion. The equations are:
x= (u+v)t v=u+at x=ut+ at2 x=vt− at2
v2=u2+2ax
Notice that each equation contains four of the five quantities relating to the motion of the body. A quick method of deciding which equation to use is to look at which quantity you do not need. For example, if you know u, v and a and need to find x, the only quantity that you are not concerned with is t. A quick glance through the five equations reveals that the last one (v2=u2+2ax)
is the only one that does not contain t, so that is the one you should use. When solving problems using the equations of motion, the following steps could be useful:
1 Try to visualise what is happening in the problem and draw a simple diagram of the situation.
2 If the problem involves a change of direction, call one direction positive and the other negative.
3 Identify all the facts given in the question so that you can select an equation that will solve the problem for you.
4 Show your working, and make sure that you use the appropriate number of significant figures in your answer.
1 2 1 2 1 2 205 m east 20 s displacement time rise run 20 −5 6 −0 20 10 15 5 –5 –10 0 12 V elocity (m s – 1) 14 2 4 6 8 10 16 18 20 Time (s)
The equations of motion can be derived from the definitions for velocity and acceleration. a= By rearrangement, at= ∆v, so that at=v−u, or v=u+at Also, vav= , or x = vavt Substituting for vav, x= (u+v)t
and substituting v=u+at for v : x= (u+u+at)t
x = ut + at2
Try to derive the other equations yourself.
1 2 1 2 1 2 x t ∆v t Physics file
5 Include units with the answer, and specify the direction if the quantity is a vector.
Worked example 1.1E
.
Alison rides her skateboard up a ramp. She begins with a speed of 8.0 m s−1
but slows with a constant acceleration of 2.0 m s−2. She travels some
distance up the ramp before coming to rest, then rolls down again. Ignoring air resistance and friction, calculate:
a the distance that Alison travels up the ramp before stopping
b the time that it takes Alison to reach this highest point, and
c Alison’s velocity after 5.0 s has elapsed.
Solution
Take the direction up the ramp as positive.
a When Alison stops, her velocity is zero.
u=8.0 m s−1 v=0 a= −2.0 m s−2 x=?
v2=u2+2ax
0 =8.02+2 × −2.0 ×x
−64 = −4x
x=16 m
b To find the time that she takes to reach her highest point on the ramp:
u=8.0 m s−1 v=0 a= −2.0 m s−2 x=16 m t=?
v=u+at
0 =8.0 + −2.0 ×t t=4.0 s
c After 5.0 s, Alison will be rolling down the ramp and so you should expect to get a negative answer for her velocity.
u=8.0 m s−1 a= −2.0 m s−2 t=5.0 s v=?
v=u+at
=8.0 + −2.0 ×5.0
=8.0 −10.0 = −2.0 m s−1
After 5.0 s she is rolling down the ramp at 2.0 m s−1.
• Physical quantities can be divided into scalars and vectors; scalars can be described fully by a magnitude, while vectors must have both magnitude and direction.
• Vectors can be added and subtracted.
• An object’s centre of mass is the point at which the total mass of the object can be considered to be concentrated.
• A position–time graph indicates the position of a body relative to an arbitrary origin, as a function of time.
• A velocity–time (v–t) graph describes the speed and direction of a body during its motion.
• An acceleration–time (a–t) graph indicates the acceleration of a body at any time.
• Five equations are used to quantitatively describe motion with a uniform acceleration:
x= (u+v)t v=u+at x=ut+ at2 x=vt− at2 v2=u2+2ax 1 2 1 2 1 2
1.1 QUESTIONS
In the following questions, assume that the acceleration due to gravity is 9.8 m s−2.
1 A plane is flying due south at 100 m s−1on an initially still
day. Then a crosswind with a velocity of 25 m s−1towards
the west begins to blow.
a What is the velocity of the plane under the influence of this crosswind?
b In which direction should the pilot steer the plane to maintain a velocity of 100 m s−1south?
2 Which of the following represents the area under a velocity–time graph?
A Average acceleration over the time interval.
B Average velocity over the time interval.
C The displacement during the time interval.
D The change in velocity for the object over the time interval.
3 The following velocity–time graph was derived from a test drive of a prototype sports car. The car started from rest and initially travelled north.
a What distance did the car travel:
i during the first 4 seconds of its motion?
ii between 4 s and 12 s?
iii between 12 s and 28 s?
b Calculate the displacement of the car after 28 s.
c What was the total distance that the car travelled during the trip?
d What was the average speed of the car during the 28 s interval?
e Calculate the acceleration of the car between 4 s and 12 s.
4 A car travelling with a constant speed of 80 km h−1passes
a stationary motorcycle policeman. The policeman sets off in pursuit, accelerating to 80 km h−1in 10.0 s and
reaching a constant speed of 100 km h−1after a further
5.0 s. At what time will the policeman catch up with the car?
In the following questions, ignore the effects of air resistance.
5 A golf ball is dropped from the top of a sheer cliff 78 m above the sea.
a Calculate the velocity of the golf ball after 1.00 s.
b How far will the ball fall in the first 2.00 s?
c Calculate the velocity of the golf ball after it has travelled 10.0 m.
d When will the golf ball hit the water?
e What is the acceleration of the golf ball at:
i 1.50 s?
ii 3.50 s?
6 Andrew is dragging a 60 kg crate of books across the garage floor. He pulls with a force of 120 N on a rope that is at an angle of 35°to the horizontal.
a Calculate the horizontal component of the pulling force.
b Calculate the vertical component of the pulling force.
7 Cassie starts from rest at the top of a 3.2 m long playground slide and slides to the bottom with a constant acceleration. If she takes 2.4 s to reach the bottom, calculate:
a her average speed
b her average acceleration
c her final speed
d her speed when she is halfway down the slide.
8 Vinh is investigating the bouncing ability of a golf ball and a tomato. He drops both objects from a height of 2.00 m and measures the rebound heights. He found that the golf ball rebounded to 1.50 m and the tomato just splattered without rebounding at all. Ignore air resistance when answering these questions.
a What was the speed of the golf ball just before it landed?
b What was the speed of the tomato just before it hit the ground?
c Calculate the speed of the golf ball as it rebounded.
d Which object had the greater change in speed as it landed? Calculate the speed change of this object.
e Which of these objects experienced the greater change in velocity as it landed? Calculate the velocity change of this object.
0 –10 –20 10 20 4 8 12 16 20 24 28t (s) V elocity (m s – 1)
When Newton published his three laws of motion in 1687, he revolutionised our understanding of the physical world. Up until then, people thought differently about why things moved the way they did. The ideas of the ancient Greeks were prevalent. These ideas, proposed by Aristotle, were that there were two types of motion—natural and violent. It was also thought that when a constant force acted on an object, the object would move with a constant speed. To many people even today, these ideas seem to be correct. In fact, Galileo and Newton showed them to be incorrect over 300 years ago!
Today, even though Einstein’s theories have superseded those of Newton, we still use Newton’s laws for most situations. After a car accident, investigators will use Newton’s laws to analyse the motion of the vehicles. When NASA scientists program the courses of spacecraft on flights to Mars, Jupiter and beyond, they use Newton’s laws. Solar and lunar eclipses can be predicted with great precision many centuries into the future by using Newton’s laws. Similarly, they can be applied to predict times and sizes of the tides that alter the ocean depths around the globe. In fact, it is only in situations involving extremely high speeds (greater than 10% of the speed of light) or strong gravitational fields that Newton’s laws become imprecise and Einstein’s theories must be used.
Newton’s laws describe how the concept of force can be used to explain why a body moves in the way that it does. The first law describes what happens to a body when it experiences zero net force (i.e. ΣF=0). Galileo had previously called this behaviour inertia. The second law explains how the body will respond when an unbalanced force is acting (i.e. ΣF≠0), and the third law states that all forces act in pairs, known as action–reaction pairs.
1.2
Newton’s laws of motion
Figure 1.6 Sir Isaac Newton (1642–1727) is widely considered to be the greatest scientist of all. He developed the scientific method of experimental research. This paved the way for others to extend the boundaries of knowledge and has led to the scientific and technological revolution that has transformed the world over the past 300 years.
Figure 1.7 The passengers in this jumbo jet are moving with a constant velocity. The forces acting on them, according to Newton’s first law, are in balance.
NEWTON’S FIRST LAW
states that every object continues to be at rest, or continues with constant velocity, unless it experiences an unbalanced force. This is also called the law of inertia.NEWTON’S SECOND LAW
states that the acceleration of a body experiencing an unbalanced force is directly proportional to the net force and inversely proportional to the mass of the body.ΣF=ma
The net (or resultant) force ΣF is measured in newtons (N), when the mass is
measured in kilograms (kg) and the acceleration, a, is measured in metres per second squared (m s−2).
NEWTON’S THIRD LAW
states that when one body exerts a force on another body (an action force), the second body exerts an equal force in the opposite direction on the first (the reaction force).magnitude, but since the masses are different the resulting accelerations of the wall and your body will also be different!
Figure 1.8 The passengers in this roller-coaster ride are accelerating. The forces acting on them, according to Newton’s second law, are unbalanced.
Figure 1.9 Action/reaction forces. (a) The hammer exerts a downward force on the nail, and the nail exerts an upward force on the hammer; these forces are equal in magnitude. (b) The rocket exerts a downward force on the fuel and gases, and the fuel and gases exert an upward force on the rocket; these forces are equal in magnitude. (c) The car exerts a forward force on the insect, and the insect exerts a backward force on the car; these forces are equal in magnitude.
F (N on H) F (H on N) hammer nail F (I on C) F (C on I) (a) (b) (c)
Worked example 1.2A
.
A man drags a 60 kg Christmas tree across a floor at a constant speed of 1.5 m s−1. If the force of friction between the tree and the floor is 50 N and
it is being pulled at an angle of 35°to the horizontal, calculate:
a the net force on the tree
b the force that the man exerts on the tree
c the force that the tree exerts on the man.
PRACTICAL ACTIVITY 5 Action and reaction
Solution
a The tree has a constant velocity, so from Newton's first law there is zero net force acting on it.
b If the net force on the tree is zero, the horizontal forces must be in
balance. This means that the frictional force of 50 N must be equal but opposite to the horizontal component of the pulling force.
Fh=Fcos35°
50 =F×0.82
So, F=61 N (i.e. the tree is being pulled with a force of 61 N at an angle of 35° to the horizontal).
c The force that the man exerts on the tree and the force that the tree exerts on the man are an action/reaction pair. According to Newton’s third law they are equal and opposite. Thus the tree must exert a force on the man of 61 N at an angle of 35°below the horizontal.
Worked example 1.2B
.
In each of the situations shown in the diagrams below, one of the forces in the action/reaction pair is given.
i In each case, draw the other force as suggested by Newton’s third law, being mindful of its location and size.
ii For each of the forces that you have drawn, complete the following statement: Force exerted on _________by _________.
F FN Fg (a) (b) (c)
Solution
i F F F (a) (b) (c)ii a Force exerted on head by ball.
b Force exerted on floor by brick. (Note: this is not the weight Fg.)
Gravitational force exerted on brick by Earth.
F = ?
Fh = 50 N
Air resistance (or drag) acts whenever a solid or a liquid has to travel through air. For example, when a raindrop falls it collides with millions of air molecules which impede its motion. In fact, if it were not for air resistance, raindrops would be travelling at thousands of kilometres per hour by the time they reached the ground! Air resistance is a force
that particularly affects objects with small masses and large surface areas. Hang-gliders are light and have a large wing area, so their motion is strongly influenced by the air. Air resistance increases with the speed of an object and is also greatly affected by the object’s shape. Streamlined bodies pass through the air more easily.
Air resistance (Fa) varies as the square of the speed (v) of an object. Mathematically, this can be expressed as:
Fa∝v2
or Fa=kv2
The constant k depends on the density (ρ) of the air, the surface area (A) perpendicular to the motion and the drag coefficient (CD) of the object. The drag coefficient indicates how smoothly the air flows past the object. Spheres have a drag coefficient of about 0.5, but it can be as high as 2 for oddly shaped bodies. The complete relationship for air resistance is:
Fa= ρACDv2
Skysurfing depends entirely on air resistance. Skysurfers attach their feet to a small surfboard, place a parachute on their back and then jump from aeroplanes from an altitude of several kilometres. As they fall, skysurfers can reach speeds of around 170 km h−1. If the
board is horizontal the skysurfer will fall vertically. However, by tipping the board forwards, backwards or sideways, skysurfers are able to control their motion to some extent and ‘surf’ through the air as they fall towards the ground.
To estimate the drag coefficient of the skysurfer, we can assume that the skysurfer and the equipment have a total mass of 75 kg and that they are falling vertically with a constant velocity of 170 km h−1on a board with an area of
about 0.20 m2. If the arms of the skysurfer are raised, they
contribute an additional area of about 0.20 m2. The density
of air is 1.25 kg m−3. The only forces acting on the skysurfer
during the fall are the gravitational force Fg and air resistance Fa. The skysurfer is falling with a constant velocity, and so these forces are in balance, i.e. Fa=Fg, so:
Fa=Fg=mg =75 ×9.8 =735 N ρ =1.25 kg m−3 A=0.40 m2 v=170 km h−1=47 m s−1 Since Fa= ρACDv2 735 =0.5 ×1.25 ×0.40 ×CD×472 So CD=1.33
This would seem to be a reasonable value for the drag coefficient, given the irregular shape of the skysurfer.
1 2 1
2
Figure 1.10 A major consideration in many competitive sports is the effect of air resistance. Greater speeds can be attained by these cyclists if the effects of air resistance are minimised by streamlining. The skysurfer makes use of air resistance to manoeuvre the board and to perform stunts.
Air resistance and skysurfing
PHYSICS IN ACTION• Newton’s first law states that a body will either remain at rest or continue with constant velocity unless it is acted upon by an unbalanced force.
• Newton’s second law states that the acceleration of a body is directly proportional to the net force acting on it and inversely proportional to its mass. This is usually written as:
ΣF=ma
• Newton’s third law states that when one body exerts a force on another body (an action force), the second body exerts an equal force in the opposite direction on the first (the reaction force):
F(A on B) = −F(B on A)
• It is important to remember that the action/reaction forces act on different objects. It is therefore incorrect to add them and so they never cancel each other.
1.2 SUMMARY NEWTON’S LAWS OF MOTION
1.2 QUESTIONS
1 Vickie’s car has a flat battery and will not start. She gets a few friends to help push her car so that she can jump-start it. Vickie is surprised to find that it takes six friends pushing to start the car rolling, but then only one friend needs to push to keep the car rolling. Explain, in terms of Newton’s laws, why this is so.
2 Phil is standing inside a tram when it starts off suddenly. Len, who was sitting down, commented that Phil was thrown backwards as the tram took off. Is this a correct statement? Explain in terms of Newton’s laws.
3 A table tennis ball of mass 10 g is falling towards the ground with a constant speed of 8.2 m s−1. Calculate the
magnitude and direction of the air resistance force acting on the ball.
4 A wayward willy wagtail crashes into a large window and knocks itself out. Which one of the following statements correctly describes the forces that act during this collision?
A The force that acts on the willy wagtail is greater than the force that acts on the window.
B The force that acts on the willy wagtail is smaller than the force that acts on the window.
C The force that acts on the willy wagtail is the same size as the force that acts on the window.
D The forces that act on the window and willy wagtail cancel each other out.
5 Ishtar is riding a motorised scooter along a level bike path. The combined mass of Ishtar and her scooter is 80 kg. The frictional and drag forces that are acting total to 45 N. What is the magnitude of the driving force being provided by the motor if:
a she is moving with a constant speed of 10 m s−1?
b she is accelerating at 1.5 m s−2?
6 A cyclist and his bike have a combined mass of 80 kg. When starting off from traffic lights, the cyclist accelerates uniformly and reaches a speed of 7.5 m s−1
c The cyclist keeps riding along with a constant speed of 7.5 m s−1. Assuming that the force being provided
by his legs is now 60 N, determine the magnitude of the frictional forces that are acting.
7 During pre-season football training, Matt was required to run with a bag of sand dragging behind him. The bag of mass 50 kg was attached to a rope, which made an angle of 25°to the horizontal. When Matt ran with a constant speed of 4.0 m s−1, a frictional force of 60 N
was acting on the bag.
a What was the net force acting on the bag of sand?
b Calculate the size of the tension force acting in the rope.
c What was the magnitude of the force that the rope exerted on Matt as he ran?
8 During a game of table tennis, the table tennis ball is hit by the bat. Due to this contact, there are forces acting on both the ball and the bat. How do these forces compare in:
a magnitude? b direction?
9 A fully laden supermarket trolley is stationary at a check-out. The shopper wishes to push the trolley to their car. When they push the trolley, it will, according to Newton’s third law, exert an equal but opposite force on them. Will the trolley move? Explain.
10 Complete each of these force diagrams showing the reaction pair to the action force that is shown. For each force that you draw, state what the force is acting on and what is providing the force.
F
FN
Imagine that you are in a car that is travelling along a straight, flat stretch of freeway at 100 km h−1. You have an apple in your hand that you toss up and
down and side to side. In the car, we can say that your frame of reference is moving with a constant velocity relative to the ground. Now, say that you repeat exactly the same actions on the apple when the car is stationary. The motion of the apple, its mass and acceleration are exactly the same in this stationary reference frame as they were when the car was moving with constant velocity.
A stationary frame of reference and a frame of reference with constant
velocity are called inertial frames of reference. Newton’s laws of motion are valid
in these inertial frames of reference.
Newton also assumed that physical quantities such as mass, time, distance and so on were absolute quantities. This means that their values did not change whatever the frame of reference. This would seem to make sense. After all, the mass of an apple and the length of a metre ruler don’t change as they travel faster—or do they?
About 200 years after Newton published his laws of motion, Albert Einstein showed that Newton’s laws did not work at speeds approaching the speed of light. In fact, at these high speeds, the mass of an object is greater, time slows down and lengths shrink! These ideas are outlined in Einstein’s theory of special relativity, which you may be doing as a Detailed Study. In this theory, Newton’s ideas of the absolute nature of space and time were replaced by Einstein’s ideas of the relative nature of space and time. In fact, history has shown that Newton’s laws were a special case of Einstein’s theories, applying only to situations involving comparatively slow-moving objects.
Relative motion
When you discuss the velocity of an object, you usually assume, without saying so, that the frame of reference is the Earth. If you describe an emu as walking with a constant velocity, you really mean that the emu has a constant velocity relative to Earth. In the past, this omission has not been an issue because the frame of reference has usually been Earth. In this section, however, we will be analysing motion from different frames of reference and so the frame of reference needs to be stated.
Imagine that you are in train A that is moving east with a constant speed of 10 m s−1and you are walking along the aisle towards the front of the train at
2 m s−1. What velocity are you travelling at? The answer to this question is that
it depends on which frame of reference you are using. To a person sitting in the train, your velocity is 2 m s−1east. Here, your frame of reference is the moving
train. However, to a person standing on the station platform, your velocity will be 12 m s−1east. In this case, your frame of reference is the ground or Earth.
Now imagine that you sit down and that another train, train B, passes in the opposite direction at 5 m s−1relative to the ground. What is the velocity of this
train relative to your train?
The velocity of train B relative to train A gives the apparent motion of train B when seen from train A. In other words, this gives train A’s view of how fast
Figure 1.11 Albert Einstein’s theory of special relativity was published in 1906 when he was 26 years old. In this theory, Einstein described the relativistic nature of the Universe. These ideas came to replace Newton’s theories, which were based on the absolute nature of the Universe.
1.3
Frames of reference and the nature of
space and time
Newton’s book, Principia, is one of themost important publications in the history of science. At the start of this book, Newton wrote down his assumptions about the absolute nature of space and time. He wrote ‘The following two statements are assumed to be evident and true. Absolute, true and
mathematical time, of itself, and from its own nature, flows equably without relation to anything external. Absolute space, in its own nature, without relation to anything external, remains always similar and immovable.’ Physics file A 10 m s–1 2 m s–1 W E
Figure 1.12 The velocity of this person relative to the ground is 12 m s−1east, but their velocity relative to the other passengers is 2 m s−1east.
From your frame of reference in train A, train B seems to be travelling to the west but faster than 5 m s−1. To calculate the relative velocity, a vector
subtraction is required.
Figure 1.13 To determine the velocity of train B relative to train A, a vector subtraction is performed, giving a relative velocity of 15 m s−1west. = – = = + W E A B 10 m s–1 5 m s–1 5 m s–1 10 m s–1 5 m s–1 10 m s–1 15 m s–1 vB,A=vB−vA
Worked example 1.3A
.
A car is travelling along a highway at 110 km h−1north as it overtakes a
bus travelling in the same direction at 95 km h−1.
a What is the velocity of the car relative to the bus?
b What is the velocity of the bus relative to the car?
c Relative to the car, what is the velocity of a truck that is travelling south at 110 km h−1?
Solution
a
Relative to the bus, the car is moving at 15 km h−1north.
b
Relative to the car, the bus is travelling at 15 km h−1south.
c
It is clear from this why head-on collisions are so dangerous. If these vehicles collided, it would be the same as a truck travelling at
− vT,C=vT−vC= 110 − 110 = 110 + 110 = 220 N vB,C=vB−vC= 95 − 110 = 95 + 110 = 15 N vC,B=vC−vB= 110 − 95 = 110 + 95 = 15 N velocity of B relative to A =velocity of B −velocity of A
vB,A=vB−vA
As shown below, this gives a relative velocity of 15 m s−1west.
A flight from Melbourne to Perth usually takes over 4 hours. The return trip, however, can be up to 1 hour less than this. Is the flight distance shorter on the way back? No, the shorter flight time is because the prevailing winds at the cruising altitude blow towards the east. The speed of the plane relative to the air will be the same on each trip, but the speed of the plane relative to the ground is greater with the benefit of a tailwind on the return trip.
Physics file
PRACTICAL ACTIVITY 6 Relative motion
These topics are covered in the ‘Einstein’s Relativity’ Detailed Study on the Heinemann Physics 12 CD.
1.3 SUMMARY
1.3 QUESTIONS
1 Which one or more of these statements is correct?
A Newton’s laws apply to stationary frames of reference.
B Newton’s laws apply to accelerating frames of reference.
C Newton’s laws apply to constant velocity frames of reference.
D All of the above.
The following information relates to questions 2–4. One of the moving walkways at Tullamarine Airport carries people horizontally at 3.5 m s−1west.
2 What is the velocity, relative to the ground, of:
a a man who stands on the walkway?
b a girl who walks west on the walkway at 1.4 m s−1?
c a boy who runs east on the walkway at 5.7 m s−1?
3 Rami is running along the walkway so that his velocity relative to the ground is zero. How fast and in which direction is he running?
4 Sylvia’s mother is walking along the floor with a velocity of 2.5 m s−1east. Sylvia is on the moving walkway. How fast
and in which direction must Sylvia run if she is to keep pace with her mother?
5 A jogger is running north along a footpath at 4.0 m s−1.
A dog in the distance is running south at 6.0 m s−1along
the same footpath.
a What is the velocity of the dog relative to the jogger?
b What is the velocity of the jogger relative to the dog?
c If they are now 100 m apart, how long will it be until their paths cross?
6 In a 400 m relay, Cathy is passing the baton to Lauren. Cathy is running at 8.2 m s−1south and Lauren’s velocity
is 6.8 m s−1south.
a What is Cathy’s velocity relative to Lauren’s?
b What is Lauren’s velocity relative to Cathy’s?
c In a successful and smooth baton change, to what value should the relative velocity of the runners be close?
Solution
We will need to use trigonometry and Pythagoras’s theorem to answer these questions.
a
Relative to Noor, Mary is travelling at 5.0 m s−1at a bearing of 37°
south of east or 127°T.
b
From Mary’s frame of reference, Noor is travelling at 5.0 m s−1at a
bearing of 53°west of north. This is the opposite of Mary’s motion relative to Noor. vN,M=vN−vM= vN,M= 5.0 = 4.0 4.0 4.0 3.0 − 3.0 + = 3.0 53° vM,N=vM−vN= vM,N= 5.0 − 4.0 4.0 4.0 3.0 = = + 3.0 3.0 37°
• An inertial frame of reference is one where the frame of reference is stationary or moving with a constant velocity. Newton’s laws are valid in inertial frames of reference.
• Relative motion is the apparent motion of one object when observed from a different frame of reference.
The velocity of object A relative to object B is:
vA,B=vA−vB
• In situations involving speeds approaching that of light, or in the presence of extreme gravitational fields, Einstein’s theories on the relativistic nature of the Universe must be used.
FRAMES OF REFERENCE AND THE NATURE OF SPACE AND TIME
7 A Ford is travelling at 59 km h−1while a Holden has a
speed of 60 km h−1.
a Calculate the velocity of the Holden relative to the Ford when they are travelling in:
i the same direction
ii the opposite direction.
b How serious would a collision be between these cars in each of the above situations? Explain.
8 Four birds are in flight as shown in the diagram. Calculate the velocity of:
a the albatross relative to the shag
b the shag relative to the albatross
c the crow relative to the drongo
d the shag relative to the drongo.
9 A ferry is cruising south towards Tasmania at a speed of 35 km h−1. A passenger on the ferry is watching a
container ship that is cruising at 25 km h−1west.
a What velocity does the container ship have relative to this passenger?
b In which direction and how fast does the ferry seem to travel relative to the container ship?
10 In 2025, a spaceship is travelling away from Earth at 2.0 ×108m s−1. At the same time, a spaceship from an
alien solar system is travelling in the opposite direction at 2.5 ×108m s−1.
a According to Newton’s theories, what is the speed of the alien craft relative to the spaceship from Earth?
b Is this answer possible according to Einstein’s theory of relativity? albatross 30 km h−1 drongo 40 km h−1 shag 25 km h−1 crow 15 km h−1 N S W E
