WIZprobe
General
WIZprobe is an advanced non-contact optical laser scanning sensor for high precision scanning and geometry data collection WIZprobe combines vision and laser technologies with patented optics and image processing
WIZprobe is an integrated component in many Nextec inspection products
WIZprobe measurement accuracy is guaranteed over a wide range of material types, colors, surface finish types and laser beam angles due to advanced real time close loop adaptive control
WIZprobe Head PH10M Motorised Head
Dynamic Range 10mm Center of
Dynamic Range
170
43
5
5
WIZprobe dimensions
Key Benefits
• Quick measurement of high precision parts
• WIZprobe measurement principle is a patented full ring triangulation method • Real time adaptive control
• Ability to measure very small geometry features • Ability to measure soft or warm material
• Fast measurements - dramatically reduces inspection time • High and adjustable data collection scanning resolution • Ultimate life cycle and high reliability
• Maintenance free
• Can be used in hostile environment • Wide dynamic range
• PH-10 indexing head compatibility
Performance Specifications
Scanning rate: 40-50 points per second
Stand-off distance(1): 43 mm
Dynamicrange: ±5 mm
Maximumpermissible probe error(2)(MPEp): 6.5 µm
Maximum permissible beam angle for inspection of a flat surface(3): 70˚
Probe weight: 230 g
(1) Stand-off distance is defined as object-to-probe lens distance (2) MPEp value is a maximum probe uncertainty value
(3) Maximum permissible beam angle is the maximum angle of scanning for valid measurements
WIZpen 18-4
General
WIZpen is an advanced non-contact white light optical scanning probe based on patented technology for top precision measurement Nextec WIZpen is a key integrated component in many Nextec top precision metrology inspection and surface finish measurement products
Performance Specifications
Scanning rate: 100-2000 points per second
Stand-off distance(1): 18.2 mm
Dynamic range: ±2 mm
Maximum permissible probe error(2)(MPEp): 4 µm
Maximum permissible beam angle for inspection of a flat surface(3): 50˚
Spot diameter: 7 µm
Probe weight: 325 g
(1) Stand-off distance is defined as object-to-probe lens distance (2) MPEp value is a maximum probe uncertainty value
(3) Maximum permissible beam angle is the maximum angle of scanning for valid measurements
Key Benefits
• Quick measurement of top precision parts • Real time adaptive control
• Ability to measure small geometry features • Ability to scan very shiny surfaces
• Ability to measure glass and all other fully transparent materials
• Ability to measure glass thickness from one side – no need to flip the part • Ability to measure soft or warm material
• Ability to measure coating thickness
• Fast measurements - dramatically reduces measuring time • High and adjustable data collection scanning resolution
• No moving parts and no wear - ultimate life cycle and high reliability • Maintenance free
• Can be used in hostile environment • Wide dynamic range
• PH-10 indexing head compatibility • Transparent materials
• Super reflective materials
WIZpen 18-4 dimensions PH10M Motorised Head 2 2 18.2 145 101 Ø45 Ø27 151 91 50 Center of Dynamic Range
5
WIZinspect
General
WIZinspect is a turn-key Inspection Solution for rapid high precision measurement of parts and components
Key Benefits
WIZinspect system offers a large variety of options: • CAD model and tolerance input
• CAD based program preparation using high level soft keys • A variety of part alignment functions and scenarios • Data collection from a predefined path
• Automatic surface tracking capability • GD&T analysis
• Flexible structure of graphical and text reports using default or customized templates • Creation of geometric elements from the scanned data and export in CAD format • Adjustable and user friendly interface
• Users authorization control - optional levels of Administrator / Operator mode • 3 times faster than standard touch probe CMM systems
WIZinspect System Major Integrated Components:
• Top precision CMM platform including PH10M motorized indexing head • Non-contact optical scanning probes – Laser or White light family of probes • 4 axis motion controller
• WIZinspect application software • Optional top precision rotary table
WIZinspect can be integrated with PLCs, conveyors and robots to provide easy, fast, precise and reliable inspection on the production-floor
WIZinspect can also be integrated into the plant SPC data base
Nextec supplies a wide variety of CMM platform designs and dimensions to inspect parts of different geometry and size
Potential
Applications
• Geometry inspection• Advanced quality inspection and on-line process control • Measurements in tough production floor environment • Thin profiles
• Fully transparent parts
Performance Specifications
Maximum scanning speed: 100 mm/sec. Total system accuracy: ± 7 µmWIZprobe Total system accuracy: ± 5 µmWIZpen
Notes
• System accuracy verification is performed according to ISO 10360-8 International Standard for non-contact CMMs
• Total system accuracy = ± (MPEE)2+(MPEP)2
WIZblade
General
WIZblade is a turn-key Blade Inspection Solution for rapid high precision measuring of both aerospace and industrial jet engine turbine and compressor blades WIZblade can effectively replace conventional CMMs with mechanical probes
Key Benefits
• WIZblade can perform automatic inspection of forged, cast or machined blades • WIZblade software has a variety of parameters calculation, fully comply with various
known blade manufacturers (vendors): GE, Pratt & Whitney, Rolls Royce, SNECMA • CAD model and tolerance input
• CAD based program preparation of new blades using high level soft keys • No need for high precision part clamping
• A variety of blade alignment functions and scenarios • Data collection from predefined cross sections
• Blade aerofoil analysis including Leading Edge & Trailing Edge • Special qualified features for Elliptical leading edge analysis
• Compatibility with a large variety of blade manufacturers, designs and standards • All WIZinspect GD&T features are included in WIZblade
• Additional integrated automatic blade specific GD&T functions
• Flexible structure of graphical and text Reports using customized templates • Simplified definition of blade cross sections
• Large variety of blade calculation functions • Flexible definitions of best fit calculations • Adjustable and user friendly interface
• Eliminate the expensive mechanical jigs for blade parts
Potential Applications
• A large variety of Aerospace Blades geometry measurements • A large variety of Industrial Blades geometry measurements • Unique quality inspection and on-line process control • Measurements in tough production floor environment • Blade inspection capability with no CAD model input • Reverse engineering and digitizing of blades
• Measurement of soft materials, such as wax or sand, for turbine blade cores
• Inspection of new blades during manufacturing stage • Inspection of working blades for the repair and after-market
Typical Inspection Time
Free form alignment time (average): 60 sec
A single cross section inspection time (average)
- Forging blade: 15 sec - Final blade: 22 sec
A single cross section inspection time using rotary table (average)
- Forging blade: 12 sec - Final blade: 18 sec
WIZblade System Major Integrated Components:
• Top precision CMM platform including PH10M motorized indexing head
• Non-contact optical scanning probes – Laser or White light family of probes
• 4 axis motion controller • WIZblade application software • Optional top precision rotary table
WIZblade can be integrated with PLCs, pallets and robots to provide easy, fast, precise and reliable inspection on the production-floor
WIZblade can also be integrated into the plant SPC data base Nextec supplies a wide variety of CMM platform designs and dimensions to inspect parts of different geometry and size
11
General
Nextec WIZglass system is integrated in our WIZinspect system
WIZglass system uses the full functionality of Nextec WIZinspect measurement software for alignment, data analysis and flexible results reporting system WIZglass system excels in scanning and measuring glass and other transparent materials from 0.1 mm thickness and up
Glass flexibility is not a problem due to the non-contact measurement method
Nextec WIZglass can perform in different modes • Scanning outer surfaces
• Scanning inner surfaces
• Thickness mode, scanning both sides of thin transparent material simultaneously
Modes switch is performed "on the fly" without any user intervention in the process
Nextec WIZglass system can measure parts in any 3D surface orientation
Key Benefits
• WIZglass system accuracy for glass and other transparent materials is equal to our standard WIZinspect system accuracy with WIZpen sensor • WIZglass system suits both laboratory and manufacturing environments • WIZglass system single sensor is used for both topology measurement
of transparent part geometric features, coordinate-system establishment (alignment) and thickness measurement
• PH10 rotary head allows to set sensor orientation perpendicular to the measured surface
• Both graphical and text reports can be easily customized to the application
Performance Specifications
Maximum scanning rate: 2000 points/sec Scanning speed: up to 40 mm/sec Stand-off distance: 18 mm
Dynamic range: ± 2 mm
Notes
• Above parameters can be changed according to the specific application requirements with different WIZpen models • System can perform measurement of material thickness in
range of 0.1 mm to 4mm
• Range can be extended with different WIZpen models • Transparent material thickness can be measured both on
flat or on curved surfaces
Surface Finish Profilometer
General
Nextec Surface Finish Profilometer delivers fast, reliable and contactless surface roughness measurement.
It can also provide surface finish inspection for special applications such as soft or flexible materials, a large spectrum of surface finish types from very reflective to very rough surfaces, or totally black materials and special coatings.
Nextec Surface Finish Profilometer provides quick and reliable results for any surface quality for both periodic and non-periodic surface profiles starting from N4 (0.2 µm Ra) for any kind of manufacturing process inspection: machining, forging, casting, milling, turning, grinding, etc. Nextec Surface Finish Profilometer can operate on flat, curved or tilted surface in any 3D orientation of the surface.
Nextec Surface Finish Software has a flexible and extensive functionality for surface quality control with various filter types, cut-offs and algorithms to calculate a wide list of surface finish parameters.
Nextec Surface Finish software allows to provide graphical representation of scanned profile or area, including waviness, graphical and numerical profile deviation with waviness profile overlaid on the primary profile (if required).
Nextec WIZinspect System can also come with an integrated
interchangeable WIZpen and WIZprobe sensors on the same WIZinspect platform and can use them one by one sequentially within a single measurement program: WIZprobe for geometry measurement and WIZpen for surface finish measurement on the same part.
Primary Profile mm 0.000 0.800 µm -0.800 4.958 Wavelength Content (From Supressed)
From: Polynomial (7)
Filter: Robust Gaussian (coef: 4.45): 0.800 mm (38:1)
Ra
Rt 0.1261.376 µmµm RzDINRdsm 0.9390.992 µmmm
µm 0.000
0.001 (0.0213) mm (0.4619) 10 0.300
Nextec Technologies 2001 Ltd.
Key Benefits
• 3D freeform or plane surfaces inspection • Line, curve or area in any PH10 orientation • Full Integration to the WIZinspect software
• ASME, ISO 13565, and DIN surface roughness parameters • High-speed scanning: up to 2000 points per second and up to
1mm/sec
• Fast analysis: Measured points data is real-time analyzed for surface finish roughness and waviness
• Easy visual inspection and data export control for surface qualities
• Very short Cycle Time (6 sec. for Ra = 0.2 µm) • Variety of profile displays
• Multi-probe system option
• Switch modes in a single WIZinspect measurement program
Performance Specifications
Surface profiles starting from: N4 (0.2 µm Ra) List of calculated parameters:
Averaging: Ra
Peak-to-valley: Rp, Rt, Rz, Pt, Wc etc. Slope and spacing: Rsm, Pdsm
WIZpen 11-04
WIZpen 11-04 dimensions
Performance Specifications
Scanning rate: 100-2000 points per second
Stand-off distance(1): 11 mm
Dynamicrange: ±200 µm
Maximum permissible beam angle for inspection of a flat surface(2): 60˚
Spot diameter: 4 µm
Probeweight: 385 g
(1) Stand-off distance is defined as object-to-probe lens distance
(2) Maximum permissible beam angle, is the maximum angle of scanning for valid measurements Ø45
Center of Dynamic Range
11
Ø27
180
0.2
0.2
174
130
91 50
PH10M Motorised Head
CMM Platforms Gallery
A variety of different CMM (Coordinate Measuring Machine) platform models and sizes are available to accommodate customer specific applications for WIZinspect or WIZblade • L = Measuring length in mm
• Maximum Permissible Error per ISO 10360-8 (Temp. 18 - 22 °C): MPEP WIZprobe 7C = 6.5 [µm]
MPEP WIZpen 18-4 = 4 [µm]
KRONOS: Specifications
Z [mm] Y [mm]
X [mm]
MPEE [µm]
Models 1000 1300 2000 3.7+L/250 20.13.10 1300 1500 2000 5.0+L/200 20.15.13 1300 1500 2500 5.0+L/200 25.15.13 1300 1500 3000 5.0+L/200 30.15.13 1500 2000 3300 6.5+L/200 33.20.15 1500 2000 4000 6.5+L/200 40.20.15 1500 2000 5000 6.5+L/200 50.20.15
ARES: Specifications
Z [mm] Y [mm] X [mm]MPEE [µm]
Models 500 500 700 2.2+L/300 07.05.05 500 650 700 2.5+L/300 07.07.05 500 650 1000 2.5+L/300 10.07.05 500 650 1200 2.5+L/300 12.07.05 650 650 700 2.5+L/300 07.07.07 650 650 1000 2.5+L/300 10.07.07 650 650 1200 2.5+L/300 12.07.07
17
HERA: Specifications
UNIVERSAL: Specifications
Z [mm] Y [mm]
X [mm]
MPEE [µm]
Models 800 900 1200 1.9+L/333 12.09.08 800 900 1500 1.9+L/333 15.09.08 800 900 2000 1.9+L/333 20.09.08 800 1000 1200 2.0+L/333 12.10.08 800 1000 1500 2.0+L/333 15.10.08 800 1000 2000 2.0+L/333 20.10.08 Z [mm] Y [mm] X [mm]
MPEE [µm]
Models 500 700 700 2.0+L/333 07.07.05 500 700 1000 2.0+L/333 10.07.05 650 700 700 +2.2L/333 07.07.07 650 700 700 +2.2L/333 07.07.07 650 700 1000 +2.2L/333 10.07.07 700 850 1200 +2.5L/333 12.09.07 700 850 1500 +2.5L/333 15.09.07 700 850 1800 +2.5L/333 18.09.07 850 1000 1200 +3.0L/312 12.10.09 850 1000 1500 +3.0L/312 15.10.09 850 1000 1800 +3.0L/312 18.10.09 850 1000 2000 +3.2L/312 20.10.09
18
Performance Verification
System Performance Verification is performed according to ISO 10360-8 International Standard for non-contact CMMs, while the total permissible error is defined as
± (MPEE)2+(MPE
P)2
where
MPEE: Maximum Permissible Error of indication for size measurement
MPEP: Maximum Permissible Probing Error
The following procedure is used to evaluate the MPEE:
Five different calibrated test lengths are placed in each of seven different positions (locations and orientations) in the measuring volume of the CMM, and each length is measured three times, for a total of 105 measurements. Four of the seven positions are the space diagonals. The default remaining three positions are parallel to each of the CMM axes.
The following procedure is used to evaluate the MPEP:
25 points are selected from the measuring area on the test sphere. The points are approximately evenly distributed to cover all measurement points. Using all 25 representative points, unconstrained Gaussian (i.e. least-squares) best fit is computed to the associated sphere. For each of the 25 representative points, the Gaussian radial distance is calculated. The range of Gaussian radial distances of the 25 representative points with respect to the least-squares sphere center is recorded, i.e. the apparent sphere form. The absolute value of this difference is the probing form error.
Rotary Table
General
The rotary table is used as a 4th axis for fast and efficient inspections of parts. The rotary table significantly
reduces the inspection cycle time by eliminating the usage of multiple tip orientations and safety moves.
Performance
Specifications
Travel: 360� Continuous
Resolution: 0.0001�
Repeatability: 0.001�
Max speed: 80�/sec
Load: 270 kg.
General
Nextec designs and supplies customized automatic inspection systems according to customer requirements.
Our automatic inspection systems can be integrated inline in many automatic production lines or as a standalone automatic inspection cell.
Over the years, Nextec gained extensive experience in providing automated inspection solutions for the Automotive, Aerospace, Cellular and Plastic industries worldwide Nextec automatic inspection systems improves production line capacity, reduces cycle time, increases stability and ensures better inputs to improve production process
Key Benefits
• Fast, accurate and repeatable measurement(1)
• Inline automatic inspection without human interference • Customized inspection solutions per customer requirements • Collecting inspection data and pairing it to each part ID number • Automatic part alignment done by software(2)
• Maximum flexibility in measurement program changes – part geometry, alignment and measurement features
• Customized data analysis
• Customized graphical and text report
• User friendly CAD based measurement program preparations • Full range of feature recognition
• Simple interface to other production floor equipment and peripheral accessories – robot handling, traversing, marking, stamping, reading etc.
(1) Volkswagen measures 1,300 cylinder heads per day in a single Nextec automatic inspection cell (2) No need for precision part position
Automatic Inspection Systems
ELE
Blade Edges
Grinding System
General
The ELE system is replacing current manual grinding process while significantly improving the accuracy and repeatability of the grinding process Designed to carry out automatic grinding of Jet Engine compressor blade edge profiles
Operates around the clock with system uptime of up to 95%
The ELE system includes on-board WIZblade inspection system, profile grinding, automatic loading & unloading system
Based on pre & post grinding inspection and analysis the ELE system adapts the grinding process to each individual blade according to its actual edge geometry
The ELE system was tested, qualified, and approved by Rolls Royce Headquarters for high precision edge profile grinding
Performance Specifications
Cycle time: 2.5 – 5 (minutes) per blade(1)
Cartridge capacity: up to 96 blades(2)
WIZblade 5.4.4 Measurement Volumetric Accuracy: ±7 µm
Grinding tolerance bend: ±35 µm
(1) Depends on blade size & number of inspected cross-sections (2)Depends on blade size
Key Benefits
• Improved engine fuel consumption & efficiency • High edge profile accuracy and repeatability • Short production time
Our Company
• Nextec Technologies 2001 Ltd. is a hi-tech company specialized in
production floor geometry inspection and quality control
• Nextec developed the core technology of fast and accurate products required to successfully replace many mechanical inspection systems
• This patented technology implements laser, innovative optics, vision, white light and sophisticated image processing
• Nextec products can be fully integrated to automatic mass production lines • Nextec products bring significant value by reducing delivery time, lowering
production cost and improving productivity and yield
Our Key Products
• WIZinspect is a high volume, general purpose GD&T part inspection system
• WIZblade is a turbine and compressor blade inspection for aerospace and
electric power jet engine blades. The WIZblade software includes all WIZinspect software functionality plus a dedicated blade inspection software package.
Our Advantages
• Setup Time – Short and simple setup
• Speed and Throughput – Much faster data collection and analysis than
conventional CMMs
• Accuracy – More accurate than mechanical inspection devices
• Precision Jigs and Fixtures are Unnecessary – alignment is performed
on the measured part itself
• Features – Measuring very small features (i.e. leading and trailing edge
profiles, coins etc.)
• Adaptive Turn-key Tailored Solution – Meeting customer specifications
and requirements
• Advanced Deployment and Support Services – Part of each product or
project which we undertake
• Internet Remote Support – Allowing Nextec to remote support the client,
troubleshoot problems and software installation updates Photo: Zvi Roger
Concept & Design:
StudioGE
| Photos:
Miki K
or
en
Re
v: 01
Technologies 2001 Ltd.
Nextec Technologies 2001 Ltd.
Carmel Business Park, Carmel Bldg. 2 HaEtgar St., P.O.B 2037
Tirat Hacarmel 39120, Israel
+972-4-857-1308 +972-4-857-1435 www.nextec-wiz.com Tel:
Fax: Web:
