Quantitative comparison of camera technologies for cost-effective
super-resolution optical fluctuation imaging (SOFI)
Robin Van den Eynde1,3 , Alice Sandmeyer2,3 , Wim Vandenberg1 , Sam Duwé1 , Wolfgang Hübner2 ,
Thomas Huser2 , Peter Dedecker1,4 and Marcel Müller1,2,4 1 Lab for NanoBiology, Department of Chemistry, KU Leuven, B-3001 Leuven, Belgium 2 Biomolecular Photonics, Faculty of Physics, Bielefeld University, D-33501 Bielefeld, Germany 3 These authors contributed equally to this work.
4 Authors to whom any correspondence should be addressed.
E-mail:[email protected]@kuleuven.be
Keywords: superresolutionfluorescence imaging, super-resolution optical fluctuation imaging (SOFI), quantitative performance evaluation, microscopy democratization
Supplementary material for this article is availableonline
Abstract
Super-resolution
(SR) fluorescence microscopy is typically carried out on research microscopes
equipped with high-NA TIRF objectives and powerful laser light sources. Super-resolution optical
fluctuation imaging (SOFI) is a fast SR technique capable of live-cell imaging, that is compatible with
many wide-field microscope systems. However, especially when employing fluorescent proteins, a key
part of the imaging system is a very sensitive and well calibrated camera sensor. The substantial costs of
such systems preclude many research groups from employing SR imaging techniques. Here, we
examine to what extent SOFI can be performed using a range of imaging hardware comprising
different technologies and costs. In particular, we quantitatively compare the performance of an
industry-grade CMOS camera to both state-of-the-art emCCD and sCMOS detectors, with
SOFI-specific metrics. We show that SOFI data can be obtained using a cost-efficient industry-grade sensor,
both on commercial and home-built microscope systems, though our analysis also readily exposes the
merits of the per-pixel corrections performed in scientific cameras.
1. Introduction
The ability to quantitatively and specifically image biological structures of interest makes fluorescence microscopy an essential tool in the life sciences. However, its spatial resolution is limited in a conventional imaging system due to the diffraction of light. To overcome this limitation, a range of super-resolution(SR) techniques has been developed and enhanced over the last two decades[1,2]. These techniques offer a
tremendous improvement in spatial resolution, though they typically have at least one trade-off: methods like stimulated emission depletion or variants of structured illumination microscopy maintain high temporal resolution, but require highly complex additions to the microscopes illumination system. Techniques in the group of single molecule localization microscopy(SMLM), on the other hand, require thousands of images to be recorded, and thus yield very low temporal resolution. They also typically require high-end imaging systems, with powerful laser light sources and high-NA objectives, limiting their use to those scientists who have access to such equipment. Driven by this observation, several initiatives have been started over the past years to
‘democratize’ fluorescence microscopy. These aim for a careful trade-off between performance and cost, instead of maximizing system performance. This goal can be achieved by a combination of open-source/open-access software and hardware blueprints, as well as repurposing commodity industrial or consumer hardware[3–9].
Highly sensitive cameras often pose a substantial portion of a microscope’s cost. A high-end sCMOS camera, for example, can exceed 10.000 Euro at the time of this writing. In comparison to conventional industry-grade cameras, priced under 1000 Euro, the value of these scientific-grade cameras lies in their higher performance in
