Controlling Network Flow with the OpenFlow Protocol

The idea of Software-Defined Networking — and OpenFlow specifically — has garnered significant interest, curiosity, as well as skepticism recently among developers of network switches, routers, and servers, and the companies that build them.

Software-Defined Networking (SDN) is a concept that emerged out the research community and a specific implementation is being driven by the Open Networking Foundation (www.opennetworking.org). SDN is a networking architecture designed to create higher-level abstractions on top of which can be built the hardware/software infrastructure needed to support the many new cloud-computing applications.

An example of SDN is described in the OpenFlow specification, a new networking protocol that emerged out of the university research environment. OpenFlow provides access to the forwarding plane of a network switch or router over the network and allows software running on a separate server to determine what path the network packets will take through the network of switches.

Some factions in the industry believe OpenFlow is the next big thing in computer networking and that it will revolutionize the way data centers and carrier networks are built and maintained in the new era of cloud computing. They believe that SDN is the final and missing link between the virtualized network infrastructure and virtualized computing resources and that it will make cloud computing and massive data centers more efficient and less costly to operate. Others purport that OpenFlow is just the newest fad and will fade away while existing networking technologies and methods continue to be prevalent.

Will OpenFlow live up to the excitement or is it another flash in the pan?

Background

Virtualized network infrastructure has been around for years. Notable technologies, like Ethernet VLANs, IPsec and SSL virtual private networks (VPNs), and Layer 3 VPNs via MPLS or virtual routing, are all examples of tried- and-true technologies for virtualizing networks. These techniques allow a single set of physical resources to be shared among a

A new twist on network flow processing gives network administrators program- matic control of network flows to strategically place traffic where resources exist.

This whitepaper addresses why you may be building the open-source specification OpenFlow (or similar protocol) into routers, switches, and other devices to realize the benefits of Software-Defined Networks.

For more information about other Netronome products, please visit netronome.com.

continued on next page

Processing

^THE

Flow

COMPANY diverse group of users, providing isolation,

performance guarantees, and security. Each of these benefits can also apply to virtualized application hosting platforms. Mechanisms to virtualize servers are now commonplace, and server virtualization is being heralded as the key to the convergence of networking and computing in the data center.

These virtualized networks are still fundamentally based on the combination of Ethernet at the data plane and TCP/IP for higher-layer addressing and application processing. Other data-plane technologies like Token Ring, FDDI, and ATM, while still in existence in legacy mode, are certainly dwindling rapidly in number of ports in existence. In addition, the days of other non-IP Layer 3 networking protocols like Novell’s IPX and Apple’s Appletalk have come and gone.

These technologies are no longer used and are largely forgotten.

Management and control of these virtualized Ethernet/IP networks has remained largely unchanged for many years. These networks are operated with a completely distributed control plane where, in most cases, each device is running one or more in- stances of a Layer 2 and Layer 3 control plane.

In the case of bridged Ethernet networks, each Ethernet switch contains a forwarding table that maps MAC (Media Access Control) addresses to physical or virtual interfaces.

These MAC addresses are learned, based on determining address locations in the network, in turn based on traffic flow and caching that information in a Layer 2 forwarding table. Control protocols such as Spanning Tree (STP) and derivatives including Rapid Spanning Tree (RSTP) and Multiple Spanning Tree (MSTP) are tried and tested protocols to ensure a loop-free topology for this switched infrastructure.

For routed networks, there exists an entire set of protocols that determine the optimal path that data should follow in order to travel across multiple networks from source to destination. These include options like Routing Information Protocol (RIP), Open Shortest Path First (OSPF), and the Border Gateway Protocol (BGP), among other examples.

(2)

In most cases, a combination of these switched and routed approaches exists simultaneously to control the forwarding behavior of traffic through a network. Regardless of the protocol specifics, usually traffic is forwarded solely on the basis of its ultimate destination, with each intermediate switch or router looking at the destination MAC address and/or destination IP address in the Ethernet and IP headers. All packets destined to the same device are relegated to use the same path through the infrastructure.

Although these methods have fueled the incredible growth in the size and scope of computing networks, they also have inefficiencies that carriers and enterprise networks would like to control.

By virtue of being solely based on destination forwarding, all traffic to a particular host or server ultimately traverses the same network path. This does not provide network architects the amount of control they require over how flows move through their networks. Additionally, considering the explosive use of virtualized servers, network configurations must provide the capability to be changed instantaneously in response to changes in the server topology.

Traditional switching and routing protocols take seconds if not minutes to reconverge, which is orders of magnitudes longer than can be tolerated. Today’s networks need to be smarter, faster, and more flexible. What carriers and data- center network designers want is the ultimate control of how flows are routed through the network as well as the treatment that those flows receive, while not being held hostage to how IP routing protocols or spanning tree decides how traffic moves through the network.

What is OpenFlow?

OpenFlow is an open standard that was originally designed to allow researchers to run experimental protocols in their campus networks. Prior to OpenFlow, there was no practical way for researchers to try new protocols and networking techniques in a real network infrastructure carrying real traffic.

OpenFlow allows network administrators or programmable software to define the paths that flows take through a network, regardless of the underlying network topology and the particular hardware over which the traffic traverses.

OpenFlow allows networks to be carved into “slices” where a particular slice is allocated a flow-specific path through the infrastructure and may optionally allocate portions of the network resources across that path.

OpenFlow wrests the distributed, address-based control of packet forwarding out of the switches and routers that traffic goes through, and gives programmatic control of flows to the administrator of the network itself. This per-flow forwarding capability allows data-center and carrier networks to strategically place flows where the required resources exist.

The resources that can be exploited might include network path, bandwidth, security policy, and latency, to name only a few of the many possibilities.

While originally designed for network researchers, other interesting applications of the technology have become evident as the standard has progressed. OpenFlow has caught the attention of those building massive data centers and cloud-based virtualized network infrastructure as well as telecommunications carriers.

SDN enables inexpensive feature insertion for new services and new revenues and allows networks to be built with common off the shelf (COTS) hardware to lower equipment expenditures, while giving programmatic control of network infrastructure back to those responsible for building and administrating these networks.

Do Flows Really Matter?

More users and more applications are driving an increase in throughput that networks need to support. This results in more individual “network conversations” or flows per segment.

So how does one define a flow? A flow is a unidirectional sequence of packets all sharing a set of common packet header values. Importantly, in OpenFlow, the concept of a flow is not defined in a rudimentary fashion considering only the destination to which the traffic is addressed.

OpenFlow optionally uses numerous packet header fields to define the concept of a flow, as shown in Figure 1. In the OpenFlow standard specification (v 1.1), the following fields may be used in flow definition:

•

Ingress interface

•

Packet metadata

•

Ethernet source address

•

Ethernet destination address

•

Ethernet type

•

VLAN ID

•

VLAN priority

•

MPLS label

•

MPLS traffic class

•

IPv4 source address

•

IPv4 destination address

•

IPv4 protocol/ARP opcode

•

IPv4 ToS bits

•

TCP/UDP source port/

ICMP type

•

TCP/UDP destination port/

ICMP code

NETRONOME WHITEPAPER: Controlling Network Flow with the OpenFlow Protocol 2

Figure 1: OpenFlow’s flow identification fields

(3)

The concept of flow processing is not new--it has been a main- stay in many network and security devices for many years. As examples, with stateful firewalls, security processing happens at beginning of the flow and this flow state is used to process the session afterwards.

Security applications like intrusion detection and preven- tion (IDS/IPS) rely on flow state because attacks may be spread across packets, TCP payloads, or even fragmented IP packets.

In particular, the open-source IDS/IPS application Snort uses the Stream5 preprocessor to reassemble TCP flows to run signature-based rules against the whole TCP payload.

Antivirus applications take this a step further and actually terminate flows at the TCP layer, parse the application protocol (such as HTTP, SMTP, and peer to peer) potentially even reassembling file attachments and scanning these for threats.

Next generation firewalls are taking the concept even further by combining user and application identification and flow- based security processing with data plane L2 switching, L3 routing, network address and port translation, and VPN termination. These applications are impossible without stateful flow-based processing but differ from OpenFlow in a funda- mental fashion in that they don’t use flow-based processing for forwarding but rather for higher-layer processing.

OpenFlow Operation

OpenFlow is based on a switching device with an internal flow-table and a standardized interface to add and remove flow entries. Openflow provides an open, programmable, virtualized switching platform where the underlying switching hardware is controlled via software that runs in an external, decoupled control plane.

As previously described, traditional switches and routers combine packet forwarding and control-plane functionality into a single device. These devices work in a distributed man- ner with other switches and routers to determine topology and packet forwarding through a network.

OpenFlow switches upset this architecture by separating these two functions such that data-plane flow forwarding still resides on the switch, but flow-forwarding decisions are determined in a separate, out-of-band OpenFlow controller or hierarchy of controllers, typically implemented in a standard x86 server(s) that have a communications path to all OpenFlow switches in the network to install the per-flow forwarding policies.

This architecture puts the network intelligence into the controller(s) where flow forwarding is centrally defined; this intelligence is downloaded to the flow tables in the switching infrastructure, as illustrated in Figure 2. The OpenFlow switches and controllers communicate via the OpenFlow protocol that defines messages, such as packet-received, send-packet-out, modify-forwarding-table, and get-stats.

The data path of an OpenFlow enabled switch abstracts the switching plane as a flow table where each flow table entry contains a configured set of the defined 15 packet fields (or implied fields) to match traffic against and determine how to treat the flow in the form of an action.

There are numerous actions possible, but some examples

are: to send the packet to a particular destination interface; rewrite the packet header fields in some fashion; or to drop the traffic. When an OpenFlow Switch receives a packet that doesn’t contain a flow entry in the cached flow table, it sends this packet to the Open- Flow controller that is responsible for making a decision on how to handle this packet. It can drop the packet, or alternatively it can send instructions in the form of a flow entry back to the switch that popu- lates the flow-table cache and directs the switch as to how to forward all subsequent packets in the flow.

OpenFlow Hybrid Architecture

One of the major changes between the OpenFlow 1.0 specification and the 1.1 revision is the notion of nested or recursive flow forwarding. Switches can have one or more flow tables and a group table where, when a packet arrives, the switch first finds the highest-priority matching flow entry and applies instructions or actions based on the flow fields. Figure 3 illus- trates the concept.

The action from this first lookup may be to send the matched data and action set to next table in the switch for subsequent processing. Flow entries may also direct the switch to forward traffic to a port (physical, virtual, internal) or to a group table for packet flooding, multipath forwarding, fast reroute, or link-aggregation use cases. Unknown flows may be forwarded to the OpenFlow controller, dropped, or sent to the next table for processing.

While the promise that OpenFlow offers is disruptive and revolutionary, traditional Ethernet switched and IP routed networks will not disappear overnight. In support of the promise of OpenFlow, properly implementing the technology in light of existing techniques needs to be considered.

OpenFlow switches are often implemented in traditional L2/L3 switching and routing hardware, and there is a need to support both OpenFlow operation and traditional switching simultaneously to ensure a smooth transition to flow forwarding. In addition, one can consider that not all traffic in a network needs to be controlled in network slices.

Accordingly, OpenFlow-hybrid switches that support both OpenFlow operation and normal Ethernet switching operation are needed. These hybrid devices offer the most practical way Figure 2: Separation of OpenFlow Switch and Controller

(4)

to move to flow-processing while supporting traditional L2 Ethernet switching, VLANs, L3 routing, ACLs, and QoS processing. Initial flow classification is responsible for routing traffic to either the OpenFlow pipeline or the traditional, destination- based switched or routed pipeline. Through this hybrid approach, the benefits of OpenFlow can be realized in a man- ner that allows slow but realistic adoption of the technology rather than through an immediate change from traditional techniques to a pure SDN.

Processor considerations

Most network equipment based on network processor units (NPUs) including Ethernet switches and routers offers a very low instruction rate and processes traffic solely based on IP and Ethernet source and destination packet-header fields.

These devices are, by design, not flow aware and are completely stateless.

Although flow state is not specifically required to be kept on each forwarding decision to support OpenFlow, there are numerous benefits to doing so. When implementing OpenFlow in these types of processors, many examples exploit the fact that these processors contain flow-tables where flow-forwarding rules are implemented as “rules” or access control list (ACL) action processing in on-chip TCAMs (ternary content addressable memories).

Any flow-forwarding rules implemented in TCAM can be used for OpenFlow processing, but these architectures strug- gle mightily in other aspects. These ACL rules are implemented in small on-chip memories that only scale to support several thousand flow-forwarding rules.

To scale to support the massive number of flows travers- ing carrier networks and massive data centers, individual forwarding entries for millions of flows is necessary to provide the level of utility that OpenFlow promises.

In addition, these processors typically operate in a pipeline-based processing paradigm and therefore don’t support recursive flow forwarding with multiple table support. Rather, they would only support a single flow table and action match and not implement the nested, multi-tiered flow-processing behavior that the OpenFlow specification calls out.

The important question to consider is, can traditional Ethernet switching silicon and NPUs with little or no program- mability support the needed complex security and flow- forwarding interactions to support OpenFlow for millions of flows with arbitrary recursive flow lookups? Also, can these processors adapt and change over time as the OpenFlow specification matures and changes?

A more appropriate processing architecture for implementing OpenFlow uses specialized flow-aware programmable processors that support line-rate flow forwarding, can rein- sert packets into a separate pipeline for nested lookups based on the OpenFlow controller’s view of the network, and support massive flow tables in external memories. Flow processors, by nature, are completely programmable, and offer a very high instruction rate that can be applied to incoming flows.

Flow processors provide stateful flow-based forwarding/

pinning, nested flow-forwarding actions for millions of flows, and dynamic flow-based load balancing. Additional benefits that flow processors provide is the ability to off-load traffic classification, provide flow-content analysis, perform protocol off-loads, packet rewriting, connection splicing, protocol termination, and support PKI/symmetric and public key cryp- tography operations.

Stay tuned

The revolutionary idea of OpenFlow is to provide a compre- hensive flow-forwarding architecture that separates the packet switching and control functions in networks. This will enable users to freely develop applications independently of network topology, provide the ability to carve out network resources on a per-flow, per-application basis, give customers per-application and per-service throughput and latency guarantees, and open the door to new applications and services.

For OpenFlow to ultimately succeed and meet the lofty goals that the industry has theorized that SDNs can provide, one needs to carefully consider the processors used to implement OpenFlow. In addition, the open standard itself needs to continue to advance to augment the specification in obvious areas where it’s remiss.

Figure 3: OpenFlow processing pipeline

NETRONOME WHITEPAPER: Controlling Network Flow with the OpenFlow Protocol 4

(5)

Netronome has operations in:

USA (Santa Clara [HQ], Pittsburgh & Boston), UK (Cambridge), Malaysia (Penang), South Africa (Centurion) and China (Shenzhen, Hong Kong) [email protected] 877.638.7629 netronome.com

®Netronome is a registered trademark, and the Netronome Logo and “The Flow Processing Company”are trademarks of Netronome Systems, Inc.

recently completed an update to the OpenFlow SDN standard.

Version 1.2 adds support for IPv6, extensible matches, and experimental extensions. Other examples of areas that the specification doesn’t explicitly include at this time are QoS and traffic shaping, security, and fault tolerance. Considering the utility that the current specification gives to network operators and provided careful consideration is given to these important areas for extension, the skeptics may ultimately be proven wrong and programmable SDNs may be the next big thing in networking.

15 years of experience in the networking and telecommunications spanning product management, strategic planning and engineering.

Daniel has a BS in mechanical engineering from Carnegie Mellon and an MS in information science and telecommunications from the University of Pittsburgh. Contact him at [email protected].

Netronome is a member of the Open Networking Foundation, which is standardizing OpenFlow.
