Application of NX Wave
Technology in Die Design
Process
Application of NX Wave
Technology in Die Design Process
Seamless integration of part design information into tooling
design process
Presentation Layout
•Overview of wave
•Demonstration of using wave illustrated
through a case study, “COOL RIM”
•Best practices
We’ll talk about
Application of WAVE functionality:
create and control upstream flow of design
information
Our case study – ‘COOL RIM’
Techniques for die-cast tooling design process:
applied to any popular molding technology
‘COOL RIM’ – WAVE Facts
WAVE – UG/NX technology of
linking inter-part geometry
creation of inter-part dependencies
Works on part topology level
Wave Geometry Linker
Requires assembly environment
does not require WAVE control
license
‘COOL RIM’ – Flow of Information
Machined
Part Casting Part Cavity Trim Part
‘COOL RIM’ – Machined Part
Step 1: “as machined” model
Development of end product (as machined)
Integration of casting design intent
For effective design
‘clean geometry’
is essential
Proper file organization
‘COOL RIM’ – Flow of Information
Machined
Part Casting Part Cavity Trim Part
‘COOL RIM’ – Casting Part
Step 2: ”As cast” model
Vertical wave link in
time stamp
Additional casting features:
‘COOL RIM’ – Flow of Information
Machined
Part Casting Part Cavity Trim Part
‘COOL RIM’ – Cavity Trim Part
Step 3: Cavity Trim Part
Vertical wave link to casting model
Apply shrinkage factor for cast material
(
scale
feature)
Extracted cavity regions – along parting line
divisions
Tooling seal-off faces developed and
attached to appropriate cavity regions to
form unique cavity trimming tools
‘COOL RIM’ – Flow of Information
Die Top Level Assembly
Cover Insert
Cavity Trim Part
Horizontal WAVE Linking
(in parallel)
Ejector
Insert Slide#1 Slide#2 Die Component
‘COOL RIM’ – Die Component
Startup die component model:
extruded block controlled by sketch
Add to top level die assembly:
waved into each cavity component
horizontal
wave link
Overall die dimensions:
‘COOL RIM’ – Ejector Insert
Step#1 WAVE linked bodies Step#2 Cavity trim operation Step#3 Final component
Use trim sheet to create the ‘ejector insert’ from
‘COOL RIM’ – Slide#2
Step#1 WAVE linked bodies Step#2 Cavity trim operation Step#3 Final component
Use trim sheet to create the ‘slide#2’ from the
‘COOL RIM’ – Die Top Level Assembly
Final step in design integration process
From part model level to tool assembly level
Part design changes will propagate to tooling
components through top level die assembly
model
‘COOL RIM’ – How does it work?
FROM
TO
UPDATED ‘COVER
INSERT`
Change
Propagation
‘COOL RIM’ – How does it work?
FROM
TO
UPDATED ‘COVER
INSERT`
Change
Propagation
What is important for successful design?
File organization: keep it simple and
straightforward
Proper and efficient use of modeling
techniques
GOOD Design Practices
Layer structure / category naming
File Organization:
Modeling tree structure –
feature sequence/grouping/naming
Expression/formula definition
GOOD Design Practices
Fixed datums and primitives: as startup features only
Modeling Techniques:
GOOD Design Practices
Fixed datums and primitives: as startup features only
Modeling Techniques:
Don’t be afraid of using sketches: avoid using
non-parametric “flying” wireframe
GOOD Design Practices
Fixed datums and primitives: as startup features only
Modeling Techniques:
Don’t multiply features: especially datums
Don’t patch model by adding features over existing ones
Don’t build deep model dependencies
Always check validity of model geometry
Don’t be afraid of using sketches: avoid using
non-parametric “flying” wireframe
GOOD Design Practices
Upfront planning investment into model and file organization
and diligence in keeping model files “clean & lean” will bring
multiple benefits to seamless flow of design information
WAVE Management
Efficient WAVE management without WAVE Control License
Vertical (serial) WAVE linking
Horizontal (parallel) WAVE linking
Managing WAVE links - breaking, reattaching, up
dating links
WAVE Geometry Linker – What are the benefits?
Full parametric integration of part design data into tooling
design process
Flexible management of linking process
“Geometry safe” method
Problem Geometry – How to deal with it?
Topology problems must be fixed – clean topology is a
Problem Geometry – How to deal with it?
Well defined and simplified parting lines
With clean part geometry, even non-parametric data
integration can proceed
Topology problems must be fixed – clean topology is a
